Power Sunroof System Cadillac DeVille Concours I final

DESCRIPTION & OPERATION

Sun roof has 3 end point positions: fully open, fully closed and vent. When sun roof is in vent position, rear of glass panel is raised to limit of travel, above roof panel. When opening, glass panel retracts into storage space between roof and headliner. Major components of the power sun roof assembly are: sliding glass panel, sun roof switch, sunshade panel, wind deflector, drain channel, lifter arms, track, motor, module, limit switch, and wiring harness.

Sun roof control module determines sun roof motor direction based on inputs received from sun roof switch and limit switch. When ignition switch is in RUN or ACCY position or when retained accessory power (RAP) is active, voltage is applied to sun roof control module enabling operation. Sun roof motor direction is determined by polarity of voltage applied to motor.

Sun roof motor limit switch input must be closed before sun roof will vent, slide or open. Limit switch is used to inform sun roof control module that sun roof glass is parallel to roof.

Sun roof uses 3 position rocker type switch to provide control module input selections. With sun roof closed, press switch to FORWARD/OPEN VENT and released, sun roof moves to vent position. From vent position, press switch to REARWARD/CLOSE VENT position again and release, motor will move sun roof to fully closed position. From closed position, press switch to REARWARD/CLOSE VENT and release. Sun roof opens motor runs until motor stall is sensed, sun roof switch is pushed to FORWARD/OPEN VENT position, sun roof limit switch is closed or sun roof module times out (20 seconds after express mode is started).

When switch is pressed to FORWARD position, sun roof will move to closed position as long as switch is held. Sun roof opens motor runs until motor stall is sensed, sun roof switch is pushed to neutral position, sun roof limit switch is closed or sun roof module times out (20 seconds after express mode is started). Sunshade will open with sun roof automatically, must be opened manually in vent position and closed manually.

MANUAL OPERATION OF SUN ROOF

This procedure applies when power operation to close sunroof is inoperative and sunroof must be closed. Access power sun roof motor. Use large, flat-bladed screwdriver to insert and press down on slot for gear. (Scheme 15) Turn screwdriver until sunroof is closed.

Scheme 15

COMPONENT LOCATIONS

COMPONENT LOCATIONS

DRAIN HOSES

Pour about a pint of water slowly into drain channel. Check for water drainage from all 4 hoses. If water flow is restricted, blow out drain hose system with compressed air. If water leaks from headliner, lower headliner and ensure drain hoses are attached to drain tubes.

TRACK & MOTOR SYNCHRONIZATION

Note. If sun roof motor and track are both removed from vehicle, motor and track must be synchronized before installation to ensure proper operation.

Inspection

Note. This procedure is a functional check to see if sun roof panel lines up and operates to proper positions to determine if synchronization will need to be performed. If vehicle has been brought into shop after sun roof has been worked on by another source, synchronization is recommended.

1. With sliding glass in full closed position, verify that glass panel is centered in opening and lifter arms hold glass firmly in place.
2. Open sliding glass to full or partially open position. Close sliding glass to full closed position. Verify that sliding glass and motor are in closed position, sliding glass is even with top of roof and centered in opening.
3. Adjust motor synchronization if rear of sliding glass is noticeably lower or higher than roof line or if rear of sliding glass is loose or can be moved up and down by hand. See «SYNCHRONIZING»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__synchronizing) .
4. If sliding glass in not centered in opening or not level with top of roof, change to «GLASS HEIGHT & OPENING FIT»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__glass-height-opening-fit) .

Synchronizing

1. Remove sun roof cover. Remove motor from mounting. See «SUN ROOF ACTUATOR»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__sun-roof-actuator) under REMOVAL & INSTALLATION. Do not disconnect motor wiring connector. With motor removed, move sun roof switch to rear position for several seconds, and release switch. Push switch forward and hold until motor stops. Turn ignition off, do not move sun roof switch until after motor is reinstalled.
2. Slide sunshade fully rearward. Remove 3 screws from front edge of shield ring, and slide shield ring rearward. Locate sun roof track transmission drive gear. (Scheme 16) Turn sun roof track transmission drive gear clockwise or counterclockwise as necessary to align lifter arm guide pin with fourth rib from rear of lifter arm.
3. Ensure rear of glass panel is held tightly in position by lifter arms and cannot be moved in up or down direction by hand. If glass panel is loose, check tightness of glass panel mounting screws.
4. Install motor and cover. Tighten screws to 27 INCH lbs. (3 N.m). Turn ignition switch to RUN position and verify proper operation by cycling through all sun roof positions.

Scheme 16

GLASS HEIGHT & OPENING FIT

1. Adjust one corner at a time. Close sun roof. Slide sun shade completely open. Remove 3 screws at front edge of shield ring and slide shield ring rearward.
2. To adjust any corner, loosen glass panel mounting screw nearest corner being adjusted. Also loosen center mounting screw on side being adjusted. DO NOT loosen all 3 screws on side being adjusted. Move glass panel up or down by hand and tighten 2 screws. Glass panel should be flush to 1/32" (0.1 mm) below roof surface.
3. Check glass panel height at each corner. Adjust as necessary. Slide shield ring forward and install 3 retaining screws.

GLASS PANEL FORE/AFT ADJUSTMENT

1. In fully closed position, glass panel should contact weatherstrip around entire perimeter. Check by inserting.0015" feeler gage or business card between seal contact area and metal roof panel. Continuous contact should exist around entire seal contact area. If gap is excessive at front or rear of glass panel, adjust as necessary.
2. To adjust, fully open sun roof. From top of vehicle, note position of track assembly on fore/aft scale. Loosen track cover rail screws on both sides of sun roof module. (Scheme 17) Slide track cover rail on both sides forward or rearward as required. Tighten screws. Ensure left and right tracks are positioned evenly. Close sun roof and inspect seal position again using feeler gage or business card. Readjust as necessary.

Scheme 17

PRELIMINARY INSPECTION

1. Check WINDOWS circuit breaker (30-amp) located in left MaxiFuse(R) block, by checking operation of power windows. If sun roof does not operate during retained accessory power, check BODY 3 fuse (50-amp) in left MaxiFuse(R) block. If fuse is open, check for short to ground in power circuit (Red wire).
2. Check for mechanical binding. Repair as necessary.
3. Check for proper installation of aftermarket electronic equipment that may affect integrity of other systems.
4. Ensure connectors and grounds are clean and tight. Check for broken or partially broken wire inside insulation which could cause system malfunction but prove good in continuity/voltage check.

SUN ROOF WATER LEAK OR WIND NOISE

1. Check alignment of glass panel to roof. Adjust as necessary. See «GLASS HEIGHT & OPENING FIT»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__glass-height-opening-fit) under ADJUSTMENTS.
2. Ensure glass panel closes completely. Check motor and track synchronization. See «MOTOR & TRACK SYNCHRONIZATION»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__track-motor-synchronization) under ADJUSTMENTS.
3. Ensure drain hoses are not disconnected, frozen, kinked or clogged.
4. Check for improperly positioned or damaged weatherstrip.

GLASS PANEL OPERATES SLUGGISHLY

1. Check glass panel alignment to roof. Adjust an necessary.
2. Check glass panel weatherstrip seal for proper attachment and placement. Install or re-cement as necessary.
3. Check tracks and troughs for obstructions or foreign objects.
4. Ensure rear guide pin is engaged properly in cam slot of lifter arm.
5. Check for bent plastic slides on lifter arms. Ensure lifter arm front slides are in track slot.
6. Ensure lifter arm is connected properly to glass panel.
7. Check voltage supplied to motor (12.6 volts) or amp range with glass running (3-5 amps).
8. Ensure tracks are securely mounted to housing.
9. Check for worn cables or motor drive gear. Replace as necessary.
10. Ensure sunshade is installed properly in tracks.

NOISY OPERATION/RATTLES

1. Check that rear guide pin is properly engaged in cam slot of lifter arm.
2. Ensure lifter arm is properly attached to glass panel.
3. Ensure lifter arm plastic slides are properly installed in track slots.
4. Ensure guide tracks are properly secured to housing.
5. Ensure sunshade is installed properly.

SUN ROOF IS INOPERATIVE OR OPERATES INTERMITTENTLY

1. Check for blown fuse. Replace as necessary. Recheck system operation.
2. Check for poor connection at the control switch, travel limit switch, express module or motor.
3. Check for poor ground connections for motor.

GLASS DOES NOT STOP AT CLOSED POSITION

1. Check for defective travel limit switch. Replace as necessary. Recheck system operation.
2. Check motor and track synchronization. See «MOTOR & TRACK SYNCHRONIZATION»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__track-motor-synchronization) under ADJUSTMENTS.

SUN ROOF OPERATES IN ONE DIRECTION ONLY

1. Check for faulty control switch. Replace as necessary. Recheck system operation.

POWER SUN ROOF SYSTEM CHECK

Note. Perform a functional sun roof system check and refer to appropriate system check (symptom) for diagnostic procedure.

1. Turn ignition switch to RUN position. Momentarily press sun roof switch FORWARD/OPEN VENT, and release before sun roof is completely open (express open mode). Sun roof should move smoothly to fully open position. To stop express open mode, press switch once in any direction.
2. Press sun roof switch to REVERSE/CLOSE VENT position and release before sun roof is fully closed. Sun roof should move to closed position and stop when switch is released.
3. Press and hold sun roof switch to REVERSE/CLOSE VENT position. Sun roof should move to closed position and stop.
4. Release sun roof switch, then press and hold to REVERSE/CLOSE VENT position. Sun roof should move to vent position.
5. Momentarily press sun roof switch to FORWARD/OPEN VENT position. Sun roof should move to closed position, and then stop.
6. Close all doors. Turn ignition off. Operate sun roof, power windows and radio. Wait 10 minutes and operate sun roof, power windows and radio again. If sun roof, power windows and radio do not operate after ignition is turned off or if sun roof, power windows and radio operate after 10 minutes, check for faulty circuits in Retained Accessory Power (RAP). See appropriate wiring diagram in POWER DISTRIBUTION article in WIRING DIAGRAMS.

SYSTEM TESTS

SUN ROOF DOES NOT OPEN

1. If sun roof system check was performed, go to next step. If power sun roof diagnostic system check was not performed, change to «POWER SUN ROOF SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__power-sun-roof-system-check) under TROUBLE SHOOTING.
2. Turn ignition on. Check operation of power windows. If power windows do not operate, change to appropriate POWER WINDOWS article. If power windows operate, go to next step.
3. Turn ignition off. Disconnect sun roof control module connectors C1 and C2. Turn ignition switch to RUN position. Using DVOM, check voltage between sun roof control module connector C1 terminal "C" (Pink wire) and ground. If battery voltage is present, go to next step. If battery voltage is not present, go to step 5 .
4. Check for voltage between sun roof control module connector C1 terminals "C" (Pink wire) and "D" (Black wire). If battery voltage is present, go to step 6 . If battery voltage is not present, go to step 7 .
5. Repair open in Pink wire between accessory time delay relay and sun roof control module. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . Recheck system operation.
6. Using DVOM, check resistance between sun roof module connector C2 terminals No. 5 (Dark Blue wire) and No. 6 (Brown wire). Press sun roof switch to FORWARD/OPEN VENT position. If resistance changes from infinite to 5 ohms or less, go to step 11 . If resistance does not change from infinite to 5 ohms or less, go to step 8 .
7. Repair open in Black wire between sun roof control module and ground. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . Recheck system operation.
8. Check resistance between sun roof control module connector C2 terminals No. 5 (Dark Blue wire) and No. 7 (Orange wire). Press sun roof switch to REVERSE/CLOSE VENT position. If resistance changes from infinite to 5 ohms or less, go to step 10 . If resistance does not change from infinite to 5 ohms or less, go to next step.
9. Check for poor terminal contact in sun roof switch connector. Check for short to ground in Dark Blue wire between sun roof switch and sun roof module. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . If terminal contact and Dark Blue wire circuit are okay, replace sun roof switch. See «SUN ROOF SWITCH»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) under REMOVAL & INSTALLATION. Recheck system operation.
10. Check for poor terminal contact in sun roof switch connector is clean and tight. Check for open or short to ground in Brown wire between sun roof control module and sun roof switch. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . If terminal contact and brown wire circuit are okay, replace sun roof switch. See «SUN ROOF SWITCH»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) under REMOVAL & INSTALLATION. Recheck system operation.
11. Check resistance between sun roof control module connector C2 terminals No. 5 (Dark Blue Wire) and terminal No. 7 (Orange wire). Press sun roof switch to REVERSE/CLOSE VENT position. If resistance changes from infinite to 5 ohms or less, go to next step. If resistance does not change from infinite to 5 ohms or less, go to step 13 .
12. Open sun roof manually if needed. See «MANUAL OPERATION OF SUN ROOF»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__manual-operation-of-sun-roof) under DESCRIPTION & OPERATION. Check resistance between sun roof control module connector C2 terminals No. 1 (Yellow wire) and No. 8 (Red wire) while opening sun roof manually. If resistance changes from infinite to 5 ohms or less, go to step 14 . If resistance does not change from infinite to 5 ohms or less, go to step 15 .
13. Check sun roof switch connector for poor terminal contact. Check for open or short to ground in Orange wire between sun roof switch and sun roof control module. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . If terminal contact and Orange wire circuit is okay, replace sun roof switch. Recheck system operation.
14. Close sun roof. Connect fused jumper between sun roof control module connector C1 terminals "C" (Pink wire) and "B" (Light Green wire). With first jumper in place, connect second fused jumper between connector C1 terminal "A" (Dark Green wire) and "D" (Black wire). If sun roof motor runs, go to step 16 . If motor does not run go to step 17 .
15. Check for short to ground in Red wire between sun roof actuator and sun roof control module. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . If circuit is okay, replace sun roof actuator. See «SUN ROOF ACTUATOR»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__sun-roof-actuator) under REMOVAL & INSTALLATION.
16. Check for poor terminal contact in sun roof control module connectors C1 and C2. If terminal contact okay, replace sun roof control module. Recheck system operation.
17. Check sun roof control module connectors C1 and C2 for poor terminal contact. Check for open or short to ground in Light Green wire between sun roof control module and sun roof actuator. Check for open in Dark Green wire between sun roof control module and sun roof actuator. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . If terminal contact and wire circuits are okay, replace sun roof actuator. Recheck system operation.

SUN ROOF DOES OPEN TO VENT POSITION

1. Turn ignition off. Disconnect sun roof control module connector C2. Turn ignition switch to RUN position. Close sun roof. Using DVOM, measure resistance between connector C2 terminals No. 8 (Red wire) and No. 1 (Yellow wire). If resistance is less than 5 ohms, go to next step. If resistance is 5 ohms or greater, go to step 3 .
2. Open sun roof, measure resistance between connector C2 terminals No. 1 (Yellow wire) and No. 8 (Red wire). If resistance is infinite, go to step 4 . If resistance is not infinite, go to step 5 .
3. Check sun roof control module connector C2 for poor terminal contact. Check for open or short to ground in Orange wire between sun roof control module and sun roof actuator. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . If terminal contact and Orange wire circuit are okay, replace sun roof actuator. Recheck system operation.
4. Measure resistance between connector C2 terminal No. 8 (Red wire) and ground. If resistance is infinite, go to step 6 . If resistance is not infinite, go to step 7 .
5. Replace sun roof actuator. See «SUN ROOF ACTUATOR»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__sun-roof-actuator) under REMOVAL & INSTALLATION. Recheck system operation.
6. Check sun roof control module connector C2 for poor terminal contact. If terminal contact is okay, replace sun roof control module. Recheck system operation.
7. Check for short to ground in Red wire between sun roof control module and sun roof actuator. See «WIRING DIAGRAMS»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . If Red wire circuit is okay, replace sun roof actuator. See «SUN ROOF ACTUATOR»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__sun-roof-actuator) under REMOVAL & INSTALLATION. Recheck system operation.

REMOVAL & INSTALLATION

Fully open sun roof. Push pins out of deflector arm bracket far enough to remove springs. (Scheme 18) Note position of springs for installation. Remove springs and raise lifter arms to vertical position. Remove pins completely. Lift out deflector assembly. To install, reverse removal procedure.

Scheme 18

Lower headliner to gain access to drain hose connections. See HEADLINER . Remove clamp and drain hose from spout. Remove interior moldings to access drain hose retaining clips. Remove tape and hose from retainers. To install, reverse removal procedure. Ensure clearance is maintained between clamps and headliner.

Removal & Installation (DeVille)

1. Remove rear vanity mirrors if equipped. Open rear vanity mirrors and insert small, flat-bladed screwdriver into slots to disengage clips. Pull down and rearward and disconnect electrical connector to remove.
2. Remove rear seat cushion and rear seat back. Remove anchor bolts at end of seat belt shoulder straps. Pull outward to disengage 2 upper and one lower fastener for rear quarter trim panels. Pull off seat belt opening trim from trim panels and feed opening trim and seat belts through opening in quarter trim panels. Remove quarter trim panels from vehicle. Disconnect electrical connectors located at the rear quarters.
3. Open front doors and remove windshield garnish trim panels by firmly pulling outward to disengage clips. Pull outward on top and middle of "B" pillar trim panel to disengage clips. Pull upward to remove from sill plate. Release clip from slot at top of panel. Remove shoulder belt through slot and remove trim panel.
4. Remove all passenger assist straps. Remove rear courtesy light assemblies. Remove sun visors and rear view mirror assembly. Remove overhead console. See «SUN ROOF SWITCH»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . Move front seats to full forward position and recline fully.
5. Pull downward and disengage rear headliner clip. Pull downward on the front of the headliner where auxiliary sun visors are located to disengage clips. Release the hook and loop straps attaching headliner to top of door openings. Ask for assistance and carefully remove headliner through passenger's front door.
6. To install, reverse removal procedure. Torque rear shoulder belt anchor bolts to 30 ft lbs. (41 Nm).

Removal & Installation (Eldorado)

1. Remove rear seat cushion and rear seat back. Remove sill plates from lower edge or door openings. Slide covers down on passenger assist straps and remove screws. Remove anchor bolts at end of rear seat belt shoulder straps. Firmly pull rear quarter panels inward to release retainers. Feed seat belt through opening and remove quarter trim panels. Disconnect electrical connectors located at the rear quarters.
2. Open front doors and remove windshield garnish trim panels by firmly pulling outward to disengage clips. Remove front shoulder belt opening trim from headliner. Remove overhead courtesy lamps and sun visors. Remove overhead console. See «SUN ROOF SWITCH»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system) . Remove auxiliary sun visors supports.
3. Pull downward and disengage rear headliner clip. Pull downward on front of headliner where auxiliary sun visors are located to disengage clips. Release hook and loop straps attaching headliner to top of door openings. Ask for assistance and carefully remove headliner through passenger's front door.
4. To install, reverse removal procedure. Torque rear shoulder belt anchor bolts to 30 ft lbs. (41 Nm).

1. Open sun roof to VENT position. Open sunshade fully. Remove 3 screws from shield ring and slide shield ring rearward to expose screws. Remove 3 glass panel screws and remove glass panel. Slide shield and sunshade forward half way across opening.
2. Lift rear of shield to clear sunshade stops, then push rearward. Push sunshade fully forward, rotate sunshade to disengage guides from track and lift out sunshade. To install, reverse removal procedure. Adjust glass panel as needed. See «GLASS PANEL FORE/AFT ADJUSTMENT»(/cadillac/deville-concours/i-final-1999-1999/remont/sun-rooft-topconvertible-top/#power-sunroof-system__glass-panel-foreaft-adjustment) under ADJUSTMENTS. Tighten screws to 27 INCH lbs. (3 N.m).

Remove glass panel. See GLASS PANEL & SUNSHADE . Open sun roof until lift pin is clear. Remove cover plates. Close sun roof until openings in track are exposed. Remove lifter arms by sliding to rear and lifting out at openings in track. Cycle trolley forward, without engaging cable from transmission. Pull trough and shield assembly forward, and then lift out at opening in track. To install, reverse removal procedure. Ensure machined screws are installed in same position removed from. Tighten screws to 27 INCH lbs. (3 N.m).

SUN ROOF ACTUATOR

Note. Actuator must be synchronized if removed from vehicle. See TRACK & MOTOR SYNCHRONIZATION under ADJUSTMENTS.

Lower reart of headliner. See HEADLINER. Remove 2 screws attaching actuator assembly to roof. Disconnect electrical harness connector. See. (Scheme 19) Remove actuator assembly. To install, reverse removal procedure.

Using masking tape and paper, cover roof panel adjacent to sun roof opening to prevent damage to finish. Fully open sun roof. Remove 12 screws, leaving 4 machined fine-thread screws retaining track cover rails. Close sun roof. Remove motor cover. Remove motor. See SUN ROOF ACTUATOR . Remove sun roof assembly by lifting up and away from vehicle. To install, reverse removal procedure. Ensure tracks engage clips at rear of roof opening.

Lower rear of headliner to gain access to module. See HEADLINER. (Scheme 19) Depress tab on side of sun roof control module and remove from bracket. Disconnect electrical connector. To install, reverse removal procedure.

Scheme 19

Using small screwdriver, remove trim panel positioned around sun roof switch. Pull down on overhead center console to release retaining clips. Disconnect electrical connectors and remove overhead console. Gently pry locking tabs retaining sun roof switch. Remove switch from console. To install, reverse removal installation.

Using small screwdriver, gently pry open overhead console trim plate. Remove fastener retaining console to headliner. Gently pull rearward on overhead center console to release locking tabs. Disconnect electrical connectors and remove overhead console. Gently pry locking tabs retaining sun roof switch. Remove switch from console. To install, reverse removal installation.

Power Sun Roof System Wiring Diagram (DeVille & Eldorado). Scheme 20
