Supplemental Inflatable Restraint System Deactivation Procedures Cadillac DeVille Concours I final

SPECIAL CARE DURING MECHANICAL REPAIRS

In some instances, it may be necessary to remove the steering column or instrument panel to access blower motor housing, heater assembly, evaporator assembly and other related A/C-heater system components. Observe specific manufacturer SERVICE PRECAUTIONS when working on vehicle with an air bag system.

Electrical sources should NEVER be allowed near inflator on back of air bag module. NEVER probe air bag system electrical wires with an analog volt-ohmmeter or test light. Always disable air bag system before servicing vehicle. See appropriate DISABLING & ACTIVATING AIR BAG SYSTEM procedure. Failure to disable system properly may result in accidental air bag deployment and possible personal injury.

If air bag system is not fully functional for any reason, DO NOT drive vehicle until system is repaired and functions properly. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally. If air bag system is not functional, park vehicle until system is repaired and functions properly.

CHRYSLER CORP.

All Chrysler vehicles are equipped with driver-side and passenger-side air bags. Unless specific models are mentioned, the following procedures apply to all models with an air bag system.

SYSTEM OPERATION CHECK

1. Ensure negative battery cable, or negative battery cable remote terminal, is disconnected and isolated. Connect Diagnostic Read-Out Box III (DRB-III) to 16-pin Data Link Connector (DLC) located left of steering column, at lower edge of instrument panel. Turn ignition switch to ON position and exit vehicle. Ensure latest version of correct DRB cartridge is being used.
2. After ensuring there is no one inside vehicle, connect negative battery cable or negative battery cable remote terminal. Using DRB, read and record active and any stored Diagnostic Trouble Codes (DTCs). If any DTCs are present, diagnose air bag system. Clear DTCs and recheck for DTCs. If a problem still exists DTC data will not clear.
3. Ignition switch should still be in ON position. Ensure no one is inside vehicle. From a position outside vehicle and away from air bag modules (in case of air bag deployment), turn ignition switch to OFF position for about 10 seconds, and then back to ON position. Observe AIR BAG indicator. It should come on for 6-8 seconds and then go out, indicating system is functioning properly.
4. If AIR BAG indicator fails to come on, comes on and stays on, or comes on while driving, a system malfunction exists. Perform air bag system self-diagnostics, and repair air bag system.

SERVICE PRECAUTIONS

Observe the following precautions when working with or near air bag systems

1. Disconnect and isolate negative battery cable before servicing vehicle. Allow system capacitor to discharge for 2 minutes before removing air bag components.
2. Disable air bag system before servicing any air bag system or steering column component. Failure to do this may result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-activating-air-bag-system) .
3. Always wear safety glasses when servicing or handling an air bag.
4. Air bag module must be stored in its original special container until used for service. It must be stored in a clean, dry place, away from sources of extreme heat, sparks and high electrical energy.
5. When placing a live air bag on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if accidentally deployed.
6. When a steering column has been removed from vehicle with an air bag module attached, never place column on the floor or any other surface with the steering wheel or air bag module face down.
7. After deployment, air bag surface may contain sodium hydroxide deposits, which irritate skin. Sodium hydroxide is a product of gas generant combustion. Always wear safety glasses, rubber gloves and a long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct disposal procedures.
8. When carrying a live air bag module, point trim cover away from your body to minimize injury in case of accidental deployment.
9. DO NOT disconnect or connect air bag module while battery is connected. Never disassemble air bag module. There are no serviceable parts within the module.
10. The air bag control module contains an impact sensor which enables the system to deploy air bags. Never strike the air bag control module. If air bag control module is accidentally dropped, module MUST be replaced.
11. Clockspring, air bag module, and seat belt pre-tensioner (if equipped) MUST be replaced if air bag is deployed.
12. On Caravan, Town & Country and Voyager, when driver-side air bag is deployed because of a collision, the complete steering column assembly, steering column clockspring, steering wheel, driver-side air bag cover/horn module, and lower steering coupler MUST be replaced.
13. On Dakota, Durango and Ram Van/Wagon, driver-side air bag module inflator assembly contains sodium azide and potassium nitrate. These materials are poisonous and extremely flammable; contact with acid, water, or heavy metals may produce harmful and irritating gases.
14. On Dakota and Ram Pickup, ALWAYS remove and replace the air bag control module and its mounting bracket as a unit. DO NOT transfer the module to another bracket.
15. On Ram Pickup, whenever passenger-side air bag module is removed and reinstalled, air distribution panel outlet barrels in passenger-side air bag door panel outlet housings MUST be replaced. Panel outlet barrels must be replaced with NEW barrels. Occupant injuries could result during air bag deployment if outlet barrels are not replaced.
16. On Ram Pickup, after air bag deployment, both air bag modules, clockspring, and the steering column assembly MUST be replaced. During air bag deployment, these components will be damaged or weakened, and are NOT intended to be reused.
17. Fasteners, screws and bolts used to fasten air bag components have a special coating and are specifically designed for air bag system. Use only original equipment fasteners.

DISABLING & ACTIVATING AIR BAG SYSTEM

1. Turn ignition off. On Avenger, Caravan, Dakota, Durango, Neon, Ram Pickup, Ram Van/Wagon, Sebring Coupe, Talon and Town & Country, disconnect and isolate negative battery cable.
2. On Breeze, Cirrus, Concorde, Intrepid, Sebring Convertible and Stratus, disconnect and isolate negative battery cable remote terminal. On Concorde and Intrepid battery remote cable is located on right strut tower. On Breeze, Cirrus, Sebring Convertible and Stratus, battery remote cable is located on left strut tower.
3. On all models, wait at least 2 MINUTES for system capacitor to discharge before servicing or working near air bag system components. To activate system, turn ignition off and reconnect negative battery cable or negative battery cable remote terminal. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__system-operation-check) .

FORD MOTOR CO.

All Ford vehicles are equipped with a dual air bag system. Unless specific models are mentioned, the following procedures apply to all models with an air bag system.

1. Turn ignition switch to RUN position. Observe AIR BAG indicator with air bags installed. If AIR BAG indicator comes on for approximately 6 seconds then goes out, air bag system is functioning properly and no fault codes exist.
2. If a fault code is detected in air bag system during system check, AIR BAG indicator will fail to light, stay on continuously or flash.
3. The AIR BAG indicator may not start flashing for approximately 30 seconds after ignition switch has been turned to RUN position. This time is required for diagnostic monitor to completely test air bag system.
4. If AIR BAG indicator is inoperative and a system fault exists, an audible tone of 5 sets of 5 beeps will be heard. If this occurs, air bag system service is required.

Observe the following precautions when working with air bag systems

1. Disable air bag system before servicing any air bag system or steering column components. Failure to do so may result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .
2. Because of critical system operating requirements, DO NOT service sensors, clockspring, air bag diagnostic monitor or air bag module. Servicing is made by replacement only.
3. Always wear gloves and safety glasses when servicing an air bag-equipped vehicle or handling an air bag.
4. When carrying a live air bag, point air bag and trim cover away from your body. This minimizes chance of injury in case of accidental deployment.
5. When placing a live air bag on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if it is accidentally deployed.
6. After deployment, air bag surface may contain deposits of sodium hydroxide, which may irritate skin. Always wear gloves and safety glasses when handling a deployed air bag. Wash hands using mild soap and water. Follow correct disposal procedures.
7. Air bag modules with discolored or damaged cover deployment doors must be replaced, not repainted.
8. Vehicle impact sensor orientation is critical for proper system operation. If vehicle is involved in a collision, inspect sensor mounting brackets for deformation. Ensure body structure in sensor mounting area is restored to its original condition. If damaged, the impact sensor must be replaced regardless of whether or not air bag is deployed.
9. Never probe connectors on air bag module. Doing so may cause air bag deployment and personal injury.
10. The instruction to DISCONNECT always refers to a component connector. DO NOT remove a component from vehicle when instructed to DISCONNECT.
11. Air bag simulators MUST be removed and the air bags reconnected when the air bag system is reactivated.
12. After any servicing, perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling System (Continental, Crown Victoria, Grand Marquis & Town Car)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Disconnect driver-side air bag module connector. Attach air bag simulator to air bag connector to simulate driver-side air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1)
3. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Disconnect passenger-side air bag connector. Install air bag simulator to air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. Connect negative battery cable.

Activating System

1. Disconnect negative battery cable. Wait at least one minute. Remove air bag simulators from driver-side and passenger-side air bag wiring harness connectors.
2. Connect driver-side air bag connector to air bag module. Install driver-side air bag module onto steering wheel. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .
3. Connect passenger-side air bag connector to air bag module. Install passenger-side air bag into instrument panel. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

Disabling System (Contour, Cougar, Mystique & Windstar)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Install air bag simulator to driver-side air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed.
3. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Install air bag simulator to passenger-side air bag module harness connector to simulate air bag. A trouble code will set if an incorrect air bag simulator is installed. Connect negative battery cable.

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy. Remove driver-side and passenger-side air bag simulators.
2. Install driver-side and passenger-side air bag modules. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

Disabling System (Escort, "F" Series Pickups & Tracer)

1. Disconnect negative battery cable. On "F" Series Pickups, remove battery-to-starter relay cable. Wait at least one minute. This time is required for back-up power supply in air bag Electronic Crash Sensor (ECS) module or diagnostic monitor to deplete its stored energy.
2. Remove driver-side air bag module from vehicle. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up.
3. Install air bag simulator to driver-side air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed.
4. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up.
5. Install air bag simulator to air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed. Connect negative battery cable.

1. Disconnect negative battery cable. On "F" Series Pickups, remove battery-to-starter relay cable. On all models, wait at least one minute. This time is required for back-up power supply in ECS or diagnostic monitor to deplete its stored energy. Remove air bag simulators.
2. Install driver-side air bag module and passenger-side air bag module. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling System ("E" Series Vans With One Battery)

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove driver-side air bag module from vehicle. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up. Install air bag simulator to driver-side air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed.
3. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up. Install air bag simulator to air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed. Connect negative battery cable.

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy. Remove air bag simulators.
2. Install driver-side air bag module and passenger-side air bag module. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling System ("E" Series Vans With Dual Batteries)

1. If vehicle is equipped with a diesel engine, go to next step. If vehicle is equipped with a gasoline engine, disconnect primary battery (engine compartment) negative battery cable. Disconnect auxiliary battery frame ground cable and isolate cable (located on right side frame rail). Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. If vehicle is equipped with a diesel engine, disconnect secondary battery positive cable terminal from primary battery positive terminal (engine compartment). Isolate secondary battery positive cable to ensure battery cable does not contact any ground surface. Disconnect primary battery negative cable. Disconnect primary battery-to-starter relay cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
3. On all models, remove driver-side air bag module from vehicle. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up. Install air bag simulator to driver-side air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed.
4. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up. Install air bag simulator to air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed. Connect battery cables in reverse order of disabling procedure.

1. Disconnect battery cables. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy. Remove air bag simulators.
2. Install driver-side air bag module and passenger-side air bag module. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect battery cables in reverse order of disabling procedure. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling System (Explorer, Expedition, Mountaineer, Navigator & Ranger)

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove driver-side air bag from vehicle. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Attach air bag simulator to air bag connector to simulate driver-side air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table.
3. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Attach air bag simulator to air bag connector to simulate passenger-side air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table.

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy. Remove air bag simulators.
2. Install driver-side and passenger-side air bag modules. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect positive battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling System (Mustang, Sable & Taurus)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove driver-side air bag module from vehicle. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up.
3. Install air bag simulator to air bag module harness connector to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed. If vehicle has a passenger-side air bag, go to next step. If vehicle has only a driver-side air bag, connect negative battery cable.
4. Remove passenger-side air bag module from instrument panel. See «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures). Position air bag module on bench with trim cover facing up. Install air bag simulator to air bag module harness connector(s) to simulate air bag. See «AIR BAG SIMULATOR APPLICATION»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) table. (Scheme 1) A trouble code will set if an incorrect air bag simulator is installed. Connect negative battery cable.

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy. Remove air bag simulators.
2. Install driver-side and passenger-side air bag modules. See «DRIVER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) and «PASSENGER-SIDE AIR BAG MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

Disabling System (Villager)

1. Disconnect negative battery cable. Wait at least 10 minutes. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove panel covering lower portion of steering column to access driver-side air bag module connector. Disconnect driver-side air bag connector from air bag module. Install Air Bag Simulator (T94P-50-A) to air bag module harness connector to simulate air bag.
3. Disconnect passenger-side air bag module connector. Connector is located behind glove box. Install Air Bag Simulator (T96P-50-A) to air bag module harness connector to simulate air bag. Connect negative battery cable.

1. Disconnect negative battery cable. Wait at least 10 minutes. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove air bag simulators. Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Scheme 1

AIR BAG SIMULATOR APPLICATION

Removal & Installation (Expedition, Explorer, "E" Series Vans, "F" Series Pickups, Mountaineer, Navigator & Ranger)

1. Disable air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Ensure front wheels are pointed straight-ahead. Remove back cover plugs (if equipped) and air bag module retaining bolts. Lift air bag module from steering wheel.
3. Disconnect horn connector. Disconnect air bag module connector. Remove driver-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
4. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect battery cable(s). Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Removal & Installation (Continental, Crown Victoria, Grand Marquis, Mustang, Sable, Taurus & Town Car)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove steering wheel spoke covers (if equipped). Remove back cover plugs and air bag module retaining bolts and washers. Lift air bag module from steering wheel.
3. Disconnect air bag module, horn, and speed control connectors (if equipped). Remove driver-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
4. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

Removal & Installation (Contour, Cougar & Mystique)

1. Disconnect negative battery cable. Disconnect positive battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove upper and lower steering column shroud from steering column. Rotate steering wheel to access driver-side air bag module retaining bolts. Remove driver-side air bag module. Disconnect driver-side air bag module connector and remove from vehicle. Position air bag module on bench with trim cover facing up.
3. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect positive battery cable. Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Removal & Installation (Escort & Tracer)

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in air bag Electronic Crash Sensor (ECS) module to deplete its stored energy.
2. Ensure front wheels are pointed straight-ahead. Remove air bag module retaining bolts. Lift air bag module from steering wheel. Disconnect air bag module connector. Remove driver-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
3. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Removal & Installation (Windstar)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove back cover plugs and air bag module retaining bolts. Lift air bag module from steering wheel. Disconnect air bag module and horn connectors. Remove driver-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
3. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

Removal & Installation (Continental, Crown Victoria, Grand Marquis & Town Car)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. On Crown Victoria and Grand Marquis, unsnap and remove upper instrument panel molding. On Town Car, open glove box door, release assist cable, press sides inward and lower glove box door to floor. On Continental, Crown Victoria and Grand Marquis, open glove box door, press sides inward and lower it to floor. On Continental and Town Car, disconnect passenger-side air bag module connector. On all models, remove passenger-side air bag module retaining bolts.
3. On Crown Victoria and Grand Marquis, disconnect passenger-side air bag module connector. On all models, push passenger-side air bag module from inside instrument panel. Remove passenger-side air bag module without handling edges of trim cover.
4. To install, reverse removal procedure. Ensure wiring harness is not pinched between air bag module and instrument panel. On Town Car, ensure trim cover retaining clips on back of air bag module are fully seated in slots. On all models, tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) .

1. Disconnect negative battery cable. Disconnect positive battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Push sides of glove box inward, and lower glove box to floor. Remove 4 screws, disconnect glove box light, and remove glove box upper cover. Remove A/C duct.
3. Through glove box opening, remove 2 passenger-side air bag module retaining nuts and 2 retaining bolts. Disconnect passenger-side air bag module connector. Remove passenger-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
4. To install, reverse removal procedure. Tighten mounting bolts and nuts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Removal & Installation ("E" Series Vans)

1. Disable air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove right lower instrument panel finish panel and panel reinforcement. Remove 3 passenger-side air bag module retaining nuts. Carefully slide a flat-blade screwdriver (3/8 x 4") under right bottom edge of passenger-side air bag door.
3. Lift upward and separate door from retaining clip. Using hands, lift door upward and separate door from remaining clips. Disconnect passenger-side air bag connector and remove passenger air bag module. Remove 6 offset air bag door retaining clips from instrument panel.
4. To install, reverse removal procedure. Tighten air bag mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Install 6 NEW offset retaining clips onto air bag module door. Activate air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Removal & Installation (Expedition, "F" Series Pickups & Navigator)

1. Disconnect negative battery cable. Disconnect positive battery cable (batter-to-starter relay cable on "F" series pickups). Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove instrument panel relay cover from top, right side of instrument panel. Remove 3 passenger-side air bag module retaining bolts. Disconnect passenger-side air bag module connector, located in relay cover opening.
3. Gently pull passenger-side air bag module from instrument panel. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Removal & Installation (Explorer & Mountaineer)

1. Disconnect negative battery cable. Disconnect battery-to-starter relay cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Open glove box. Push sides of glove box toward each other, and lower glove box to floor. Remove passenger-side air bag module retaining bolts. Push passenger-side air bag module from behind instrument panel.
3. Using both hands, gently pull passenger-side air bag module from instrument panel. Disconnect passenger-side air bag module connector, located on left side of air bag.
4. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

1. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in air bag Electronic Crash Sensor (ECS) module to deplete its stored energy.
2. Push in tabs on glove box door, and lower door. Remove 2 glove box hinge-to-instrument panel bolts. Remove glove box. Remove 4 passenger-side air bag module bolts. Pull passenger-side air bag module from instrument panel. Disconnect passenger-side air bag module connector. Remove passenger-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
3. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) .

Removal & Installation (Mustang & Ranger)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Push sides of glove box toward each other, and lower glove box to floor. Remove right side A/C duct (Mustang only). Remove passenger-side air bag module retaining bolts. Disconnect passenger-side air bag module connector, located on left side of air bag. Remove air bag connector from steel reinforcement.
3. Gently pull each corner of air bag cover to disengage cover-to-instrument panel attachments. Push passenger-side air bag module from behind instrument panel. Using both hands, pull passenger-side air bag module from instrument panel. DO NOT handle air bag module by edges of deployment doors.
4. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

Removal & Installation (Sable & Taurus)

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Air bag module trim cover is retained by snap-in tabs. Remove air bag module trim cover from instrument panel. Open glove box, press sides inward, and lower glove box to floor.
3. Through glove box opening, remove 2 air bag module retaining screws. Disconnect 2 air bag module connectors. Remove passenger-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
4. To install, reverse removal procedure. Tighten retaining screws to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

1. Record preset radio station frequencies. Disconnect negative battery cable. Wait at least one minute. This time is required for back-up power supply in diagnostic monitor to deplete its stored energy.
2. Remove instrument cluster trim panel and left instrument panel finish panel. Remove instrument panel finish panel retaining clips. Open glove box, press sides inward, and lower glove box to floor.
3. Remove 4 passenger-side air bag module front retaining bolts. Disconnect passenger-side air bag module connector located on left side of module. Remove passenger-side air bag module from vehicle. Position air bag module on bench with trim cover facing up.
4. To install, reverse removal procedure. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect positive battery cable. Connect negative battery cable. Perform «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) . Program radio station frequencies.

TORQUE SPECIFICATIONS

AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)

GENERAL MOTORS

The following models are equipped with a driver-side only air bag system: 3500 Series "G" Vans with Camper, Cutaway, or RV package. All other models are equipped with driver-side and passenger-side air bag systems.

Catera, DeVille, Montana, Prizm, Silhouette and Venture may be equipped with driver and front passenger side-impact air bags and seat belt pretensioners.

On "C" and "K" series pickups equipped with an air bag system, AIR BAG will be molded into the middle of the driver-side air bag cover and into the passenger-side air bag vinyl trim cover. There will also be an air bag warning light on the instrument panel which comes on during bulb check.

Catera

Turn ignition switch from OFF position to RUN position. If air bag system is operating normally, AIR BAG warning light will come on for 3-4 seconds and then go out. If AIR BAG warning light does not operate as specified a system malfunction is indicated.

All Other Models

1. On "C" and "K" series pickups equipped with a passenger-side air bag ON/OFF switch, ensure ON/OFF switch is in ON position.
2. On all models, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. If AIR BAG warning light operation is as specified, system is functioning normally.

On all models, the following AIR BAG warning light conditions indicate possible system failure

1. Light does not come on at all.
2. Light comes on while vehicle is driven.
3. Light flashes 7 times and remains on.
4. Light flashes 4 times during bulb check.
5. Light does not flash, but remains on when ignition is turned on.

Air bag system faults are often caused by a disconnected or loose electrical connector due to previous service on vehicle. Always check Yellow 2-pin connector(s) at base of steering column.

Observe the following service precautions when working with air bag systems

1. Disable air bag system before servicing any air bag system or steering column component. Failure to do this may result in accidental air bag deployment and possible personal injury. If vehicle is equipped with passenger-side air bag, both modules (driver and passenger) MUST be disabled. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .
2. After repairs, stay well away from air bag module(s) and turn ignition switch to RUN position. Ensure AIR BAG warning light is working properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .
3. Always wear safety glasses when servicing or handling an air bag.
4. Air bag module must be stored in its original special container until it is ready to be used for service. It must be stored in a clean, dry place, away from sources of extreme heat, sparks or high electrical energy.
5. When placing a live air bag module on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if it is accidentally deployed.
6. After deployment, air bag surface may contain deposits of sodium hydroxide, which can irritate skin. Always wear safety glasses, rubber gloves, and a long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct disposal procedures.
7. When carrying a live air bag module, point trim cover away from body to minimize injury in case of accidental deployment.
8. DO NOT carry seat belt pretensioner by wiring harness or connector. Seat belt pretensioner can be carried by piston tube. When handling a live seat belt pretensioner, DO NOT touch seat belt pretensioner in cable area between buckle and mounting bolt hole. DO NOT cover pretensioner piston tube opening with hands or point open end at yourself or others.
9. Coil assembly must be replaced whenever air bag is deployed. Replace SDM, driver-side air bag module or passenger-side air bag module if it has been dropped from a height greater than 3 feet.
10. Electrical sources should never be allowed near inflator on back of air bag module.
11. If water enters the vehicle's interior and soaks the carpet, the SDM or SDM harness connector may need to be replaced. Inspect the affected area and remove all the water. Repair the water damage, replace the SDM harness connector, and replace the SDM. Failure to do this may result in accidental air bag deployment and possible personal injury.
12. If air bag system is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally. If air bag system is not functional, park vehicle until repairs can be made.

Disabling & Activating System (Catera)

1. Turn steering wheel to place front wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove key. Wait one MINUTE. Disconnect negative battery cable and isolate.
2. To activate air bag system, ensure front wheels are in a straight-ahead position. Turn ignition switch to LOCK position and remove ignition key. Connect negative battery cable. Staying well away from air bag modules, turn ignition switch to ON position. Ensure AIR BAG warning light comes on for 3-4 seconds and then goes out. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling & Activating System (Corvette)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove key. Remove SDM fuse from instrument panel fuse block located on passenger-side floor board, behind carpet. Wait at least 10 MINUTES.
2. Remove sound insulator from under steering column. Remove Connector Position Assurance (CPA) clip, and disconnect driver-side air bag Yellow 2-pin connector located at base of steering column. Remove CPA clip, and disconnect passenger-side air bag Yellow 2-pin connector located near base of steering column.
3. To activate air bag system, connect Yellow 2-pin connectors. Install CPA clips. Install sound insulators. Install SDM fuse.
4. Staying well away from air bag module(s), turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling & Activating System (Cutlass & Malibu)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove ignition key. Remove AIR BAG fuse from left instrument panel wiring harness junction block located at end of instrument panel. Wait at least 10 MINUTES.
2. Remove Connector Position Assurance (CPA) clip from driver-side air bag module Yellow 2-pin connector located above left side instrument panel wiring harness junction block. Disconnect driver-side air bag module Yellow 2-pin connector.
3. Remove CPA clip from passenger-side Yellow 2-pin connector located above right side instrument panel wiring harness junction block. Disconnect passenger-side Yellow 2-pin connector.
4. To activate air bag system, ensure ignition switch is in LOCK position and ignition key is removed. Connect air bag module Yellow 2-pin connectors and install CPA clips. Install AIR BAG fuse in left side instrument panel wiring harness junction block.
5. Staying well away from air bag modules, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Note. When fuse is removed and ignition switch is in ON position, AIR BAG warning light will be on. This is a normal operation and does not indicate an SIR system malfunction.

Disabling & Activating System (DeVille, Eldorado & Seville)

Note. DeVille and Seville STS are equipped with side-impact air bags. Remove SIR fuse from trunk compartment fuse block. Remove front door trim panels, and disconnect side impact air bag module Yellow 2-pin connectors to deactivate side-impact air bags.

1. Turn steering wheel to place front wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove key. Remove SIR fuse from trunk compartment fuse block (behind carpet in left front corner of trunk). Wait at least 10 MINUTES.
2. Remove sound insulator from under steering column. Remove Connector Position Assurance (CPA) clip, and disconnect Yellow 2-pin connector located at base of steering column. Remove CPA clip, and disconnect Yellow 2-pin connector from passenger inflator module pigtail through trap door inside glove box.
3. To activate air bag system, connect Yellow 2-pin connectors. Install CPA clips. Install sound insulator. Install SIR fuse. Staying well away from air bag modules, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling & Activating System (Grand Prix)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove ignition key. Remove SIR fuse from fuse block (located behind glove box door). Wait at least 10 MINUTES.
2. Remove left side instrument panel insulator. Remove Connector Position Assurance (CPA) clip from driver-side air bag module Yellow 2-pin connector located at base of steering column. Disconnect driver-side air bag module Yellow 2-pin connector.
3. Remove CPA clip from passenger-side Yellow 2-pin connector located at right side of steering column. Disconnect passenger-side Yellow 2-pin connector.
4. To activate air bag system, ensure ignition switch is in LOCK position and ignition key is removed. Connect air bag module Yellow 2-pin connectors and install CPA clips. Install SIR fuse in fuse block.
5. Staying well away from air bag modules, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Note. When fuse is removed and ignition switch is in ON position, AIR BAG warning light will be on. This is a normal operation and does not indicate an SIR system malfunction.

Disabling & Activating System (Lumina & Monte Carlo)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove ignition key. Remove fuse No. 21 from instrument panel fuse block, located on end of instrument panel. Wait at least 10 MINUTES.
2. Remove sound insulator from under steering column. Remove Connector Position Assurance (CPA) clip, and disconnect driver-side air bag module Yellow 2-pin connector located at base of steering column.
3. Remove right side sound insulator from under instrument panel. Remove CPA clip from passenger-side Yellow 2-pin connector and disconnect passenger-side Yellow 2-pin connector located behind glove box.
4. To activate air bag system, ensure ignition switch is in LOCK position and ignition key is removed. Connect air bag module Yellow 2-pin connectors and install CPA clips. Install left and right sound insulators. Install fuse No. 21 into instrument panel fuse block.
5. Staying well away from air bag modules, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. See «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling & Activating System (Metro & Firefly (Canadian) & Tracker)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove key.
2. On Metro & Firefly (Canadian), remove AIR BAG fuse from junction block located under instrument panel, near base of steering column. On Tracker, remove AIR BAG fuse from air bag fuse block located near base of steering column. On all models, wait at least 10 MINUTES. Remove steering wheel side cover. Remove Connector Position Assurance (CPA) clip, release driver-side air bag module Yellow 2-pin connector lock and disconnect connector.
3. Open glove box, push right and left stoppers inward and lower glove box door. Remove Connector Position Assurance (CPA) clip, release passenger-side air bag module Yellow 2-pin connector lock and disconnect connector.
4. To activate air bag system, turn ignition switch to LOCK position and remove key. Connect and lock air bag module Yellow 2-pin connectors, and install CPA clips. To complete installation, reverse removal procedure. Install AIR BAG fuse. Staying well away from air bag modules, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times and stays off. If AIR BAG warning light does not operate as described, see «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Note. When fuse is removed and ignition switch is in ON position, AIR BAG warning light will be on. This is a normal operation and does not indicate an SIR system malfunction.

Note. Prizm is equipped with driver and front passenger air bags, and driver and front passenger side-impact air bags.

Disabling & Activating System (Montana, Silhouette & Venture)

Note. Montana, Silhouette and Venture are equipped with driver and front passenger air bags, driver and front passenger side-impact air bags, and seat belt pretensioners.

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove ignition key. Remove Supplemental Inflatable Restraint (SIR) fuse from instrument panel fuse block. Wait at least 10 MINUTES.
2. Remove left side sound insulator from under steering column. Remove Connector Position Assurance (CPA) clip, and disconnect Yellow 2-pin connector located at base of steering column.
3. Remove right side sound insulator from right side of instrument panel. Remove Connector Position Assurance (CPA) clip, and disconnect 2-pin connector from passenger inflator module pigtail.
4. Locate driver's side-impact air bag Yellow 2-pin connector and driver seat belt pretensioner Yellow 2-pin connector under driver's seat. Remove CPA from each connector and disconnect Yellow connectors.
5. Locate passenger's side-impact air bag Yellow 2-pin connector and front passenger seat belt pretensioner Yellow 2-pin connector under front passenger's seat. Remove CPA clip from each connector and disconnect Yellow connectors.
6. To activate air bag system, ensure ignition switch is in LOCK position and ignition key is removed. Connect air bag and seat belt pretensioner Yellow 2-pin connectors located under instrument panel and front seats. Install CPA clips. Install knee bolsters, sound insulators. Install SIR fuse.
7. Staying well away from both air bag modules, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. If AIR BAG warning light does not operate as described, see «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling & Activating System (Prizm)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove ignition key. Remove AIR BAG fuse from junction block located near base of steering column. Wait at least 10 MINUTES.
2. Locate driver-side air bag module coil behind steering wheel, release 2-pin connector lock and disconnect Yellow 2-pin connector. Remove right side kick panel. Remove 2 lower bolts and 3 upper screws from glove box. Remove glove box. Release passenger-side air bag module 2-pin connector lock and disconnect Yellow 2-pin connector.
3. Locate driver and front passenger side-impact air bag module Yellow 2-pin connectors under front seats. Release side-impact air bag 2-pin connector locks and disconnect Yellow 2-pin connectors.
4. To activate air bag system, ensure ignition switch is in LOCK position and ignition key is removed. Connect and lock driver and front passenger side-impact air bag Yellow 2-pin connectors located under front seats.
5. Connect and lock passenger air bag module Yellow 2-pin connector. Install glove box and tighten bolts and screws to 11 ft. lbs. (15 N.m). Connect Yellow 2-pin connector behind steering wheel and lock Yellow 2-pin connector.
6. Install AIR BAG fuse to junction block. Staying well away from air bag modules, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times and stays off. If AIR BAG warning light does not operate as described, see «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Note. When AIR BAG fuse is removed and ignition switch is in ON position, AIR BAG warning light will be on. This is a normal operation and does not indicate an SIR system malfunction.

Disabling & Activating System (Saturn)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove key.
2. Remove AIR BAG fuse from instrument panel junction block. Wait 10 MINUTES. Locate driver-side air bag module Yellow 2-pin connector near base of steering column. Remove Connector Position Assurance (CPA) clip, and disconnect Yellow 2-pin connector at base of steering column.
3. Passenger-side air bag module connector is located under upper instrument panel trim panel. To access connector, locate upper trim panel screw caps at center of instrument panel. Remove screw caps and upper trim panel screws.
4. Remove upper trim panel by lifting up on rear edge to release clips. Pull panel rearward out of clips at bottom of windshield. Remove upper trim panel insulator. When removing upper trim panel, DO NOT damage VIN plate and upper trim panel seal. Locate passenger-side air bag module Yellow 2-pin connector in center of instrument panel. Remove CPA clip, and disconnect Yellow 2-pin connector.
5. To activate air bag system, turn ignition switch to LOCK position and remove key. Connect Yellow 2-pin connectors, and install CPA clips. To complete installation, reverse removal procedure. Install AIR BAG fuse. Turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. If AIR BAG warning light does not operate as described, see «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling & Activating System (All Other Models)

1. Turn steering wheel to place wheels in straight-ahead position. Turn ignition switch to LOCK position, and remove ignition key. Remove AIR BAG fuse, AIR BAG 1C fuse, or Supplemental Inflatable Restraint (SIR) fuse from instrument panel fuse block (underhood junction block on Park Avenue). Wait at least 10 MINUTES.
2. Remove knee bolster, sound insulator, or trim panel (as necessary) from under steering column. Remove Connector Position Assurance (CPA) clip, and disconnect Yellow 2-pin connector located at base of steering column. (Scheme 2)or (Scheme 3). NOTE: On "C" & "K" Pickups, Cavalier, Century, Grand Prix, Intrigue, Regal, Sierra, Suburban and Sunfire, passenger-side air bag Yellow 2-pin connector is located near base of steering column.
3. On models with passenger-side air bag, remove knee bolster, trim panel, sound insulator, glove box or glove box door (as necessary) from right side of instrument panel. Remove CPA clip, and disconnect passenger-side Yellow 2-pin connector from passenger inflator module pigtail.
4. To activate air bag system, ensure ignition switch is in LOCK position and ignition key is removed. Connect air bag module Yellow 2-pin connectors. Install CPA clips. Install AIR BAG fuse, AIR BAG 1C fuse, or SIR fuse. Install knee bolsters, sound insulators, trim panels, glove box or glove box door (if removed).
5. Staying well away from air bag modules, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times and stays off. If AIR BAG warning light does not operate as described, see «SYSTEM OPERATION CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures).

Note. When fuse is removed and ignition switch is in ON position, AIR BAG warning light will be on. This is a normal operation and does not indicate an SIR system malfunction.

Scheme 2

Scheme 3

JEEP

All models are equipped with a with dual air bag system. Unless specific models are mentioned, the following procedures apply to all models with air bag system.

1. Ensure negative battery cable is disconnected and isolated. Connect Diagnostic Read-Out Box III (DRB-III) to 16-pin Data Link Connector (DLC) located left of steering column at lower edge of instrument panel. Turn ignition switch to ON position and exit vehicle. Ensure latest version of correct DRB cartridge is being used.
2. After ensuring there is no one inside vehicle, connect negative battery cable. Using DRB, read and record active and any stored Diagnostic Trouble Codes (DTCs). If any DTCs are present, diagnose air bag system. Clear DTCs and recheck for DTCs. If a problem still exists DTC data will not clear.
3. Ignition switch should still be in ON position. Ensure no one is inside vehicle. From a position outside vehicle and away from air bag modules (in case of air bag deployment), turn ignition switch to OFF position for about 10 seconds, and then back to ON position. Observe AIR BAG warning light. It should come on for 6-8 seconds and then go out, indicating system is functioning properly.
4. If AIR BAG warning light fails to come on, comes on and stays on, or comes on while driving, a system malfunction exists. Perform air bag system self-diagnostics, and repair air bag system.

Observe the following precautions when working with or near air bag systems

1. Disconnect and isolate negative battery cable before servicing vehicle. Allow system capacitor to discharge for 2 MINUTES before removing air bag components.
2. Disable air bag system before servicing any air bag system or steering column component. Failure to do this may result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/deville-concours/i-final-1999-1999/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures) .
3. Always wear safety glasses when servicing or handling an air bag.
4. Air bag module must be stored in its original special container until used for service. It must be stored in a clean, dry place, away from sources of extreme heat, sparks and high electrical energy.
5. When placing a live air bag on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if accidentally deployed.
6. When a steering column has an air bag module attached, never place column on the floor or any other surface with the steering wheel or air bag module face down.
7. The air bag module inflator assembly contains sodium azide and potassium nitrate. These materials are poisonous and extremely flammable; contact with acid, water, or heavy metals may produce harmful and irritating gases.
8. Passenger-side air bag contains argon gas pressurized to over 2500 psi (175.8 kg/cm 2 ). DO NOT attempt to dismantle air bag module or tamper with its inflator. DO NOT puncture, incinerate, or bring air bag into contact with electricity. DO NOT store air bag at temperatures exceeding 200°F (93°C).
9. After deployment, air bag surface may contain sodium hydroxide deposits, which irritate skin. Sodium hydroxide is a product of the gas generant combustion. Always wear safety glasses, rubber gloves and a long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct disposal procedures.
10. When carrying a live air bag module, point trim cover away from your body to minimize injury in case of accidental deployment.
11. The horn switch is integral with the air bag module trim cover. Failure to take the proper precautions could result in accidental, incomplete, or improper air bag deployment and possible personal injury.
12. DO NOT disconnect or connect air bag module while battery is connected. Never disassemble air bag module. There are no serviceable parts within the module.
13. On Wrangler, when both air bag door bracket "J" nuts are removed from the instrument panel armature, they must be replaced with 2 NEW "J" nuts. Ensure all fasteners for air bag door are installed. Failure to do this could result in incomplete, or improper air bag deployment and possible personal injury.
14. The air bag control module contains an impact sensor which enables the system to deploy the air bags. Never strike the air bag control module. If air bag control module is accidentally dropped, the module MUST be replaced.
15. Clockspring and air bag module MUST be replaced if air bag is deployed.
16. On Grand Cherokee and Wrangler, ALWAYS remove and replace air bag control module and its mounting bracket as a unit. DO NOT transfer the module to another bracket.
17. Fasteners, screws and bolts used to fasten air bag components have a special coating and are specifically designed for air bag system. Use only original equipment fasteners. On Grand Cherokee, if the passenger-side air bag module mounting screws cannot be tightened to the specified torque, replace screws with the OEM-approved over-sized screws.

Disabling & Activating System

To disable system, turn ignition switch to OFF position. Disconnect negative battery cable, and isolate battery cable end. Wait at least 2 MINUTES for system capacitor to discharge before servicing or working near air bag system components. To activate system, reconnect negative battery cable. See SYSTEM OPERATION CHECK .

See also:
• DISABLING & ACTIVATING AIR BAG SYSTEM
• SYSTEM OPERATION CHECK
• DISABLING & ACTIVATING AIR BAG SYSTEM
• TORQUE SPECIFICATIONS
• DISABLING SYSTEM ("E" SERIES VANS WITH DUAL BATTERIES)
