Remote Keyless Entry Systems Cadillac DeVille Concours I final

Door Locks & Anti-Theft Systems 3 illustrations ~3427 words

DESCRIPTION

Remote Keyless Entry (RKE) system, also known as Remote Function Actuator (RFA) system, allows driver to operate several features from outside vehicle. Main components of system are the transmitter and receiver module. Transmitter unit sends a radio signal to the receiver module in response to button presses by vehicle operator. Receiver module then interprets signals and relays information to appropriate module to provide requested function. RFA module identifies which transmitter is being used and sends class 2 data to memory seat module to adjusts seats and mirrors to their preset positions. Perimeter lighting can be enabled to illuminate using RKE transmitter when it is dark out.

OPERATION

Pressing unlock button once will unlock driver's door, turn on illuminated entry lights, and disarm theft system (if equipped). Pressing unlock button a second time within 4 seconds will unlock all doors. This function will be disabled if ignition is on.

Pressing lock button will lock all doors. Pressing trunk button will unlock trunk. This feature is disabled if transmission is not in Park and ignition is on. Pressing fuel door button will open fuel door.

COMPONENT LOCATION

ComponentLocation
Body Control Module (BCM) (1)(2) Front Of Trunk, Mounted On Electronics Bay Board
Data Link ConnectorUnder Left Side Of Instrument Panel, Near Steering Column
Remote Function Actuator (RFA) Module(2) Front Of Trunk, Mounted On Electronics Bay Board
Rear Junction Block(2) Front Of Trunk, Mounted On Electronics Bay Board
(1) BCM may also be referred to as Platform Zone Module (PZM). (2) (Scheme 34)
(1)BCM may also be referred to as Platform Zone Module (PZM).

KEYLESS ENTRY COMPONENT LOCATION

TRANSMITTER PROGRAMMING

Note. Transmitters are numbered on back for reference only (can be programmed in any order).

Programming order is important, first transmitter programmed should be No. 1 and second should be No. 2. Up to 4 transmitters can be programmed. Additional transmitters are available, but will be unmarked. To program transmitters, perform following procedures

  1. Connect scan tool.
  2. Select DIAGNOSTICS.
  3. Select BODY CODE.
  4. Select BODY STYLE CODE.
  5. Select OTHER.
  6. Select RFA.
  7. Select SPECIAL FUNCTIONS.
  8. Select F0 (PROGRAM KEY FOBS).
  9. Choose FOB number that you wish to program.
  10. Follow screen prompts to complete programming procedure.
  11. Press and hold LOCK and UNLOCK buttons on RKE transmitter being programmed, door locks should cycle within 15 seconds.
  12. Continue with next transmitter and repeat until all transmitters are programmed.
  13. Exit RKE transmitter programming procedure and disconnect scan tool.
  14. Cycle ignition and verify RKE transmitter operation.

TRANSMITTER PERSONALIZATION

Transmitters can be customized to have the following actions take place with a certain transmitter

  1. Perimeter lighting comes ON with remote unlock.
  2. Park lights come ON with remote unlock.
  3. Park lights come ON with remote lock.
  4. Horn sounds with remote lock.

To program personalization features for transmitters, perform following steps

  1. Connect scan tool.
  2. Select DIAGNOSTICS.
  3. Select BODY CODE.
  4. Select BODY STYLE CODE.
  5. Select OTHER.
  6. Select PERSONALIZATION.
  7. Select DRIVER INFORMATION.
  8. Choose driver.
  9. Select driver number key FOB options.
  10. Change functions to ACTIVE or INACTIVE as desired.
  11. Save options and exit.

SYNCHRONIZING TRANSMITTERS

When transmitters are out of synchronization, all buttons except fuel door release will be inoperative. Transmitters need to be synchronized if buttons have been pushed 256 times out of range of receiver, Remote Function Actuator (RFA) module is replaced or resynchronization procedure is performed outside range of receiver.

To synchronize transmitters after battery replacement, press and hold LOCK and UNLOCK buttons simultaneously for seven seconds. All doors lock and unlock to indicate synchronization is complete. Verify RKE system operation.

PRELIMINARY CHECKS

Ensure retained accessory power system operates correctly by checking if radio operates after ignition is turned off for 10 minutes or until door is opened. Check if door locks work from all door lock switches. Ensure theft deterrent arming and disarming functions correctly. See appropriate ANTI-THEFT SYSTEMS article. Check IGN SW fuse No. 20 (15-amp) in rear compartment fuse block and replace as necessary. Ensure all power and ground circuits are clean and tight. Perform REMOTE KEYLESS ENTRY (RKE) SYSTEM CHECK .

REMOTE KEYLESS ENTRY (RKE) SYSTEM CHECK

  1. Depress LOCK button on RKE transmitter. All doors should lock. If all doors do not lock, go to «DOOR LOCK INOPERATIVE WITH TRANSMITTER - ALL DOORS»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__door-lock-inoperative-with-transmitter) under SYSTEM TESTS.
  2. Depress UNLOCK on RKE transmitter once. Driver's door only should unlock. If driver's door does not unlock, go to «DOOR UNLOCK INOPERATIVE WITH TRANSMITTER - DRIVER'S DOOR»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__door-unlock-inoperative-with-transmitter) under SYSTEM TESTS.
  3. Depress UNLOCK on RKE transmitter twice within 5 seconds. All doors should unlock. If all doors do not unlock, go to «DOOR UNLOCK INOPERATIVE WITH TRANSMITTER - ALL DOORS»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__door-unlock-inoperative-with-transmitter) under SYSTEM TESTS.
  4. Depress fuel door release button on RKE transmitter with shift lever in park. Fuel door should release. If fuel door does not release, go to «FUEL DOOR RELEASE INOPERATIVE WITH TRANSMITTER»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__fuel-door-release-inoperative-with-transmitter) under SYSTEM TESTS.
  5. Depress TRUNK RELEASE button on RKE transmitter. Rear compartment lid should release. If trunk does not release, go to «TRUNK RELEASE INOPERATIVE WITH TRANSMITTER»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__trunk-release-inoperative-with-transmitter) under SYSTEM TESTS.
  6. Press any button on RKE transmitter. Any function pressed should actuate function. If system does not operate as specified, go to «REMOTE KEYLESS ENTRY SYSTEM INOPERATIVE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-system-inoperative) under SYSTEM TESTS.

Scan Tool

A scan tool can be used to retrieve and clear DTCs. The scan tool also has several features that can be used to help locate an intermittent condition. When scan tool is used for system tests, it will display values actually seen or commanded by various systems (i.e., BCM, PCM). To display DTCs, connect scan tool to Data Link Connector (DLC) and power up scan tool. Select appropriate system for DTCs to be displayed. Select DTC on scan tool to display system DTCs. After displaying all DTCs, go to REMOTE KEYLESS ENTRY SYSTEM DTCs table to diagnose and repair. To clear DTCs, see CLEARING DIAGNOSTIC TROUBLE CODES (DTCs) .

On-Board Diagnostics

DTCs can be displayed and erased on both digital and analog instrument clusters using the A/C-heater control panel. Turn ignition on. On digital instrument clusters, press and hold OFF and warmer (Red) buttons until all segments in the Driver's Information Center (DIC) light up. On analog instrument clusters, press and hold OFF and passenger warmer (up arrow) buttons until all segments in the Driver's Information Center (DIC) light up. On all models, after segments light up, the DIC will display DTCs in the following order

  1. PCM
  2. IPC
  3. ACM
  4. SDM
  5. TCS
  6. PZM
  7. IRC
  8. RFA
  9. CCP
  10. MSM
  11. MMM
  12. PHN

The RSS, CCP, MSM, MMM and PHN DTCs only appear if vehicle is equipped with those systems. Press the fan speed down (down arrow) button to select the appropriate system is selected. After displaying all DTCs, go to REMOTE KEYLESS ENTRY SYSTEM DTCs table to diagnose and repair. To clear DTCs, see CLEARING DIAGNOSTIC TROUBLE CODES (DTCs) .

DTC (1) (2)Description
B1000RFA Internal Fault (Self-Test Failed)
B1007EEPROM Write Error
B3108Transmitter Synchronization Failure
(1) Go to appropriate diagnosis and repair procedure under DIAGNOSTIC TESTS . (2) DTC will not turn on Malfunction Indicator Light (MIL).
(1)Go to appropriate diagnosis and repair procedure under DIAGNOSTIC TESTS .
(2)DTC will not turn on Malfunction Indicator Light (MIL).

REMOTE KEYLESS ENTRY SYSTEM DTCs

To retrieve DTCs, go to RETRIEVING DIAGNOSTIC TROUBLE CODES (DTCs) . After repairing DTCs, select appropriate system for clearing codes. Select DTC and CLEAR CODES on scan tool. When prompted, press YES button to clear DTCs.

To retrieve DTCs, go to RETRIEVING DIAGNOSTIC TROUBLE CODES (DTCs) . After repairing DTCs, press fan speed down (down arrow) button to select the appropriate system is selected. Press fan speed up (up arrow) button until appropriate system and CODES? is displayed. Press fan speed down (down arrow) button until appropriate system and CLEAR CODES? is displayed. Press fan speed up (up arrow) button to clear codes. Appropriate system and CODES CLEAR will be displayed.

REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK

  1. Connect scan tool to Data Link Connector (DLC). Turn ignition on. Attempt to establish communications with vehicle. If scan tool communicates with vehicle, go to next step. If scan tool does not communicate with vehicle, go to BODY CONTROL MODULES - DEVILLE & ELDORADO article.
  2. Attempt to communicate with Remote Function Actuator (RFA) module. If scan tool communicates with RFA module, go to next step. If scan tool does not communicate with RFA module, go to «REMOTE KEYLESS ENTRY SYSTEM INOPERATIVE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-system-inoperative) .
  3. Check for Diagnostic Trouble Codes (DTCs) in RFA module. If any current RKE DTCs are present, go to «REMOTE KEYLESS ENTRY SYSTEM DTCs»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) table. If no DTCs are set, go to «REMOTE KEYLESS ENTRY (RKE) SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-system-check) under TROUBLE SHOOTING.

Remote Function Actuator (RFA) module runs this internal self-test at power up. This test will only be run if DTC B1982 (battery voltage high) or B1983 (battery voltage low) is not present.

DTC B1000 will set and store in Remote Keyless Entry (RKE) current memory only if RFA module fails internal Read Only Memory (ROM) to Random Access Memory (RAM) write test. No driver warning message will be displayed for this DTC.

DTC B1000 will clear when RFA module receives a "passed test" message after power up self-test.

Testing

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Using scan tool, clear DTC B1000. Turn ignition off and back on again. Recheck for DTCs. If DTC B1000 is still present, go to next step. If DTC B1000 is no longer present, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  3. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.

Diagnostic Aids

DTC B1000 will stay in current memory until passed test message is received by Remote Function Actuator (RFA) module after power up self-test. If DTC will not clear, replace RFA module.

Remote Function Actuator (RFA) module performs internal tests on EEPROM each time RFA module writes to memory in EEPROM. RFA module reads back data from EEPROM that has been written to EEPROM. If data does not match after 3 consecutive write and verify attempts, RFA module will set DTC B1007 as current. No driver warning message will be displayed for this DTC.

DTC B1007 will clear when RFA successfully writes and reads from EEPROM. History DTCs will clear after 50 consecutive ignition cycles if malfunction is no longer present.

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Using scan tool, clear DTC B1007. Turn ignition off and back on again. Recheck for DTCs. If DTC B1007 is still present, go to next step. If DTC B1007 is no longer present, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  3. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.

EEPROM cannot be removed from Remote Function Actuator (RFA) module. DTC B1007 is an internal RKE malfunction, RFA module will need to be replaced if DTC B1007 is set as current.

Remote Function Actuator (RFA) module runs this test every time module processes a message from transmitters.

DTC B3108 will set and store in current memory if RFA module does not receive a transmission from transmitter. No driver warning message will be displayed for this DTC.

Under all fault conditions, DTC B3108 will clear when transmission is received by RFA module, using on-board clearing DTC feature or when scan tool is used to clear codes.

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Hold transmitter within operating range of vehicle. Press and hold lock and unlock buttons on transmitter for 8 seconds. Repeat for additional transmitters. Using scan tool, clear DTC B3108 from memory. Operate all functions using all transmitters. If DTC B3108 resets, go to next step. If DTC B3108 does not reset, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  3. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.

REMOTE KEYLESS ENTRY SYSTEM INOPERATIVE

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. If RKE system is inoperative from both transmitters, go to next step. If RKE system is inoperative from one transmitter, go to step 8.
  3. Turn ignition off. Disconnect Remote Function Actuator (RFA) module connector. (Scheme 34) Using DVOM, measure voltage between RFA module connector terminal No. 1 (Orange wire) and ground. If battery voltage is indicated, go to next step. If battery voltage is not indicated, go to step 5.
  4. Using DVOM, measure voltage between RFA module connector terminals No. 1 (Orange wire) and No. 4 (Black wire). If battery voltage is indicated, go to step 7. If battery voltage is not indicated, go to step 6.
  5. Repair open or short to ground in Orange wire between RFA module and rear fuse block. Recheck system operation.
  6. Repair open in Black/White wire between RFA module and ground. Recheck system operation.
  7. Replace RFA module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION. Recheck system operation.
  8. Replace transmitter battery in faulty transmitter. Recheck system operation. If RKE system is still inoperative, go to next step.
  9. Replace faulty transmitter. After replacement, transmitter must be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES. Recheck system operation.

DOOR LOCK INOPERATIVE WITH TRANSMITTER - ALL DOORS

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Verify door lock function by depressing door mounted door lock switch to lock position. If door locks operate to lock position, go to next step. If power door locks do not operate to lock position, go to POWER DOOR LOCKS - DEVILLE & ELDORADO article.
  3. If doors will not lock with all transmitters, go to next step. If doors will not lock with only one transmitter, go to step 5 .
  4. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.
  5. Replace faulty transmitter. After replacement, transmitter must be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES.

DOOR UNLOCK INOPERATIVE WITH TRANSMITTER - ALL DOORS

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Verify door unlock function by depressing door mounted door lock switch to unlock position. If door locks operate to unlock position, go to next step. If power door locks do not operate to unlock position, go to POWER DOOR LOCKS - DEVILLE & ELDORADO article.
  3. If doors will not unlock with all transmitters, go to next step. If doors will not unlock with only one transmitter, go to step 5 .
  4. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.
  5. Replace faulty transmitter. After replacement, transmitter must be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES.

DOOR UNLOCK INOPERATIVE WITH TRANSMITTER - DRIVER'S DOOR

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Verify door lock function by depressing door mounted door lock switch to unlock position. If driver's door lock operates to unlock position, go to next step. If driver's door lock does not operate to unlock position, go to POWER DOOR LOCKS - DEVILLE & ELDORADO article.
  3. If driver's door does not unlock with all transmitters, go to next step. If driver's door does not unlock with only one transmitter, go to step 5 .
  4. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.
  5. Replace faulty transmitter. After replacement, transmitter must be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES.

FUEL DOOR RELEASE INOPERATIVE WITH TRANSMITTER

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Depress instrument panel mounted fuel door release switch. If fuel door release functions properly, go to next step. If fuel door release functions do not function properly, see POWER TRUNK & FUEL DOOR RELEASE - DEVILLE & ELDORADO article.
  3. Check fuel door release function with second or known-good transmitter. If fuel door release functions properly, go to next step. If fuel door release functions do not function properly, go to step 5 .
  4. Replace faulty transmitter. After replacement, transmitter must be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES.
  5. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.

TRUNK RELEASE INOPERATIVE WITH TRANSMITTER

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Depress instrument panel mounted rear compartment lid release switch. If rear compartment lid release functions properly, go to next step. If rear compartment lid release functions do not function properly, see POWER TRUNK & FUEL DOOR RELEASE - DEVILLE & ELDORADO article.
  3. Check rear compartment release function with second or known-good transmitter. If rear compartment lid release functions properly, go to next step. If rear compartment lid release functions do not function properly, go to step 5 .
  4. Replace faulty transmitter. After replacement, transmitter must be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES.
  5. Replace Remote Function Actuator (RFA) module. See «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems) under REMOVAL & INSTALLATION.

TRANSMITTER TEST

  1. If remote keyless entry diagnostic system check was performed, go to next step. If remote keyless entry diagnostic system check was not performed, go to «REMOTE KEYLESS ENTRY (RKE) DIAGNOSTIC SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-diagnostic-system) under SELF-DIAGNOSTIC SYSTEM.
  2. Turn on Keyless Entry Tester (J-43241). (Scheme 33) Place transmitter on pad and press each button on transmitter. Ensure that transmitter is correct model for Remote Keyless Entry (RKE) system. Wrong transmitter will pass test, but will not work with vehicle. Tone should sound and Green light should light on keyless entry tester when each button is pressed. If keyless entry tester responds as specified, go to step 7. If keyless entry tester does not respond as specified, go to next step.
  3. If any buttons cause tone to sound and Green light to light on keyless entry tester, go to step 6. If no buttons cause tone to sound and Green light to light on keyless entry tester, go to next step.
  4. Replace transmitter battery. After replacement, transmitter will need to be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES. After replacement, go to next step.
  5. Place transmitter on keyless entry tester pad and press each button on transmitter. Tone should sound and Green light should light on keyless entry tester when each button is pressed. If keyless entry tester responds as specified, go to step 9. If keyless entry tester does not respond as specified, go to next step.
  6. Replace faulty transmitter. After replacement, transmitter must be programmed. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES. After replacement, go to step 11.
  7. Operate transmitter within range of vehicle. If RKE functions operate properly, go to step 12. If RKE functions do not operate properly, go to next step.
  8. Press PANIC button on transmitter. If vehicle responds properly (flashing lights, horn sounds), go to next step. If vehicle does not respond properly, go to step 11.
  9. Resynchronize transmitters. See «SYNCHRONIZING TRANSMITTERS»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__synchronizing-transmitters) under PROGRAMMING PROCEDURES. If all doors locked and unlocked, go to next step. If all doors did not lock and unlock, go to step 11.
  10. Operate transmitter within range of vehicle. If RKE functions operate properly, go to step 12. If RKE functions do not operate properly, go to «REMOTE KEYLESS ENTRY (RKE) SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-system-check) under TROUBLE SHOOTING.
  11. Reprogram all transmitters. See «TRANSMITTER PROGRAMMING»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__transmitter-programming) under PROGRAMMING PROCEDURES. If all doors locked and unlocked, go to next step. If all doors did not lock and unlock, go to «REMOTE KEYLESS ENTRY (RKE) SYSTEM CHECK»(/cadillac/deville-concours/i-final-1999-1999/remont/door-locks-anti-theft-systems/#remote-keyless-entry-systems__remote-keyless-entry-rke-system-check) under TROUBLE SHOOTING.
  12. Recheck system operation.

Scheme 33

Scheme 33
Scheme 33

Removal & Installation

Remove rear compartment front trim panel. Remove rear seatback. Remove rear electronics bay board. Disconnect Remote Function Actuator (RFA) module wiring harness connector. Remove RFA module from left side of electronics by board by pressing on locking tabs. (Scheme 34) To install, reverse removal procedure. Tighten nuts to 80 INCH lbs. (9 N.m).

Scheme 34

Scheme 34: Removal & Installation
Scheme 34: Removal & Installation

Remote Keyless Entry System Wiring Diagram (DeVille & Eldorado). Scheme 35

Scheme 35: Remote Keyless Entry System Wiring Diagram (DeVille & Eldorado)
Scheme 35: Remote Keyless Entry System Wiring Diagram (DeVille & Eldorado)
