Instrument Panel Trim and Console Trim Cadillac CTS II

Exterior/interior Trim 51 illustrations ~522 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Front Floor Console Armrest Screw2.5 N.m22 lb in
Front Floor Console Compartment Door Hinge Screw2.5 N.m22 lb in
Front Floor Console Compartment Door Latch Screw2.5 N.m22 lb in
Front Floor Console Compartment Door Lower Latch Screw2.5 N.m22 lb in
Front Floor Console Compartment Screw2.5 N.m22 lb in
Front Floor Console Cupholder Screw2.5 N.m22 lb in
Front Floor Console Lower Armrest Retainer Screw2.5 N.m22 lb in
Front Floor Console Lower Armrest Retainer Screw2.5 N.m22 lb in
Front Floor Console Rear Compartment Screw2.5 N.m22 lb in
Front Floor Console Screw2.5 N.m22 lb in
Front Floor Console Trim Plate Screw2.5 N.m22 lb in
Front Floor Console Upper Closeout Screw2.5 N.m22 lb in
Front Floor Console Upper Closeout Screw2.5 N.m22 lb in
Front Floor Console Upper Closeout Screw2.5 N.m22 lb in
Instrument Panel Carrier to Body Bolts25 N.m18 lb ft
Instrument Panel Carrier to Body Nuts25 N.m18 lb ft
Instrument Panel Carrier to HVAC Module Screw2.5 N.m22 lb in
Instrument Panel Center Compartment Screws1 N.m9 lb in
Instrument Panel Cluster Trim Plate Cover Screw2 N.m18 lb in
Instrument Panel Compartment Bolts2.5 N.m22 lb in
Instrument Panel Compartment Door Latch Screw2.5 N.m22 lb in
Instrument Panel Compartment Screws2.5 N.m22 lb in
Instrument Panel Drivers Knee Bolster Bracket Bolt9 N.m80 lb in
Instrument Panel Inflatable Restraint Bolt10 N.m89 lb in
Instrument Panel Insulator Screw2 N.m18 lb in
Instrument Panel Lower Trim Panel Bolt2.5 N.m22 lb in
Instrument Panel Upper Trim Panel Screw2.5 N.m22 lb in
Parking Brake Lever Bracket Reinforcement Screws2.5 N.m22 lb in

Scheme 69

Scheme 69: Instrument Panel Insulator Replacement - Right Side (Left Hand Drive)
Scheme 69: Instrument Panel Insulator Replacement - Right Side (Left Hand Drive)
CalloutComponent Name
1Instrument Panel Insulator Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Insulator Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel insulator assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 70

Scheme 70: Instrument Panel Insulator Replacement - Right Side (Right Hand Drive)
Scheme 70: Instrument Panel Insulator Replacement - Right Side (Right Hand Drive)
CalloutComponent Name
1Instrument Panel Insulator Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Insulator Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel insulator assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 71

Scheme 71: Instrument Panel Insulator Replacement - Left Side (Left Hand Drive)
Scheme 71: Instrument Panel Insulator Replacement - Left Side (Left Hand Drive)
CalloutComponent Name
1Instrument Panel Insulator Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Insulator Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel insulator assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 72

Scheme 72: Instrument Panel Insulator Replacement - Left Side (Right Hand Drive)
Scheme 72: Instrument Panel Insulator Replacement - Left Side (Right Hand Drive)
CalloutComponent Name
1Instrument Panel Insulator Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Insulator Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel insulator assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 73

Scheme 73: Driver Knee Bolster Replacement (Left Hand Drive)
Scheme 73: Driver Knee Bolster Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the left instrument panel insulator. Refer to Instrument Panel Insulator Replacement - Left Side (Left Hand Drive) . Remove the left instrument panel side trim panel. Refer to Instrument Panel Side Trim Panel Replacement .
1Instrument Panel Driver Knee Bolster Assembly Procedure: Grasp the knee bolster assembly and pull rearward in order to release the retainer clips securing the knee bolster assembly to the instrument panel.

Scheme 74

Scheme 74: Driver Knee Bolster Replacement (Right Hand Drive)
Scheme 74: Driver Knee Bolster Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the left instrument panel insulator. Refer to Instrument Panel Insulator Replacement - Left Side (Right Hand Drive) . Remove the left instrument panel side trim panel. Refer to Instrument Panel Side Trim Panel Replacement .
1Instrument Panel Driver Knee Bolster Assembly Procedure: Grasp the knee bolster assembly and pull rearward in order to release the retainer clips securing the knee bolster assembly to the instrument panel.

Scheme 75

Scheme 75: Driver Knee Bolster Bracket Replacement (Left Hand Drive)
Scheme 75: Driver Knee Bolster Bracket Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure: Remove the instrument panel driver knee bolster assembly. Refer to Driver Knee Bolster Replacement (Left Hand Drive)
1Instrument Panel Driver Knee Bolster Bracket Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Driver Knee Bolster Bracket
CAUTION
Refer to Fastener Caution .

Scheme 76

Scheme 76: Driver Knee Bolster Bracket Replacement (Right Hand Drive)
Scheme 76: Driver Knee Bolster Bracket Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure: Remove the instrument panel driver knee bolster assembly. Refer to Driver Knee Bolster Replacement (Right Hand Drive)
1Instrument Panel Driver Knee Bolster Bracket Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Driver Knee Bolster Bracket
CAUTION
Refer to Fastener Caution .

Scheme 77

Scheme 77: Instrument Panel Trim Plate Applique Replacement - Right Side (Left Hand Drive)
Scheme 77: Instrument Panel Trim Plate Applique Replacement - Right Side (Left Hand Drive)
CalloutComponent Name
1Instrument Panel Trim Plate Applique Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Procedure Use a flat bladed plastic trim tool in order to release the seven retaining clips securing the trim plate applique to the instrument panel. Starting at the upper inboard corner, release the first retainer clip securing the applique to the instrument panel, then work outward releasing the remaining six retaining clips.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 78

Scheme 78: Instrument Panel Trim Plate Applique Replacement - Right Side (Right Hand Drive )
Scheme 78: Instrument Panel Trim Plate Applique Replacement - Right Side (Right Hand Drive )
CalloutComponent Name
1Instrument Panel Trim Plate Applique Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. Procedure: Use a flat bladed plastic trim tool in order to release the retaining clips securing the trim plate applique to the instrument panel.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.

Scheme 79

Scheme 79: Instrument Panel Trim Plate Applique Replacement - Left Side (Left Hand Drive)
Scheme 79: Instrument Panel Trim Plate Applique Replacement - Left Side (Left Hand Drive)
CalloutComponent Name
1Instrument Panel Trim Plate Applique Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. Procedure: Use a flat bladed plastic trim tool in order to release the retaining clips securing the trim plate applique to the instrument panel.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.

Scheme 80

Scheme 80: Instrument Panel Trim Plate Applique Replacement - Left Side (Right Hand Drive)
Scheme 80: Instrument Panel Trim Plate Applique Replacement - Left Side (Right Hand Drive)
CalloutComponent Name
1Instrument Panel Trim Plate Applique Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Procedure Use a flat bladed plastic trim tool in order to release the seven retaining clips securing the trim plate applique to the instrument panel. Starting at the upper inboard corner, release the first retainer clip securing the applique to the instrument panel, then work outward releasing the remaining six retaining clips.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 81

Scheme 81: Instrument Panel Trim Plate Applique Replacement - Center (Left Hand Drive)
Scheme 81: Instrument Panel Trim Plate Applique Replacement - Center (Left Hand Drive)
CalloutComponent Name
1Instrument Panel Trim Plate Applique Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. Procedure: Use a flat bladed plastic trim tool in order to release the retaining clips securing the trim plate applique to the instrument panel.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.

Scheme 82

Scheme 82: Instrument Panel Trim Plate Applique Replacement - Center (Right Hand Drive)
Scheme 82: Instrument Panel Trim Plate Applique Replacement - Center (Right Hand Drive)
CalloutComponent Name
1Instrument Panel Trim Plate Applique Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. Procedure: Use a flat bladed plastic trim tool in order to release the retaining clips securing the trim plate applique to the instrument panel.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.

Scheme 83

Scheme 83: Instrument Panel Side Trim Panel Replacement
Scheme 83: Instrument Panel Side Trim Panel Replacement
CalloutComponent Name
1Instrument Panel Side Trim Panel Assembly Procedure: Use a flat bladed plastic trim tool in order to release the retaining clips securing the side trim panel to the instrument panel.

Scheme 84

Scheme 84: Instrument Panel Upper Trim Panel Replacement (Left Hand Drive)
Scheme 84: Instrument Panel Upper Trim Panel Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel assembly. Refer to Instrument Panel Lower Trim Panel Replacement (Left Hand Drive) . Remove the instrument panel inflatable restraint module. Refer to Instrument Panel Inflatable Restraint Module Replacement .
1Instrument Panel Upper Trim Panel Screw (Qty: 37) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Upper Trim Panel Tie-Down Screw (Qty: 1) Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Upper Trim Panel Procedure Grasp the upper trim panel and pull upward disengaging the retainer clips securing the upper trim panel to the lower trim panel. When replacing the instrument panel upper trim panel assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 85

Scheme 85: Instrument Panel Upper Trim Panel Replacement (Right Hand Drive)
Scheme 85: Instrument Panel Upper Trim Panel Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel assembly. Refer to Instrument Panel Lower Trim Panel Replacement (Right Hand Drive) . Remove the instrument panel inflatable restraint module. Refer to Instrument Panel Inflatable Restraint Module Replacement .
1Instrument Panel Upper Trim Panel Screw (Qty: 37) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Upper Trim Panel Tie-Down Screw (Qty: 1) Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Upper Trim Panel Procedure Grasp the upper trim panel and pull upward disengaging the retainer clips securing the upper trim panel to the lower trim panel. When replacing the instrument panel upper trim panel assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 86

Scheme 86: Instrument Panel Cluster Trim Plate Cover Replacement (Left Hand Drive)
Scheme 86: Instrument Panel Cluster Trim Plate Cover Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure: Remove the windshield defroster grill assembly. Refer to Windshield Defroster Nozzle Grille Replacement (Left Hand Drive) .
1Instrument Panel Cluster Trim Plate Cover Screw (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Cluster Trim Plate Cover Assembly
CAUTION
Refer to Fastener Caution .

Scheme 87

Scheme 87: Instrument Panel Cluster Trim Plate Cover Replacement (Right Hand Drive)
Scheme 87: Instrument Panel Cluster Trim Plate Cover Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure: Remove the windshield defroster grill assembly. Refer to Windshield Defroster Nozzle Grille Replacement (Right Hand Drive) .
1Instrument Panel Cluster Trim Plate Cover Screw (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Cluster Trim Plate Cover Assembly
CAUTION
Refer to Fastener Caution .

Scheme 88

Scheme 88: Instrument Panel Lower Trim Panel Replacement (Left Hand Drive)
Scheme 88: Instrument Panel Lower Trim Panel Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the front floor console assembly. Refer to Front Floor Console Replacement (Left Hand Drive) . Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the radio front speakers. Refer to Radio Front Speaker Replacement . Remove the radio. Refer to Radio Replacement . Remove the radio, video, audio disc player, and navigation information display assembly, if equipped. Refer to Radio, Video, Audio Disc Player, and Navigation Information Display Replacement . Remove the left and right instrument panel insulators. Refer to Instrument Panel Insulator Replacement - Left Side (Left Hand Drive) and Instrument Panel Insulator Replacement - Right Side (Left Hand Drive) . Remove the steering column assembly. Refer to Steering Column Replacement . Remove the instrument panel cluster assembly. Refer to Instrument Cluster Replacement (Left Hand Drive) or Instrument Cluster Replacement (Right Hand Drive) . Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement (Left Hand Drive) . Remove the right, left, and center instrument panel trim panel appliques. Refer to Instrument Panel Trim Plate Applique Replacement - Right Side (Left Hand Drive) and Instrument Panel Trim Plate Applique Replacement - Left Side (Left Hand Drive) and Instrument Panel Trim Plate Applique Replacement - Center (Left Hand Drive) . Remove the right and left instrument panel flood lamp assemblies. Refer to Instrument Panel Flood Lamp Replacement - Left Side . Remove the left and right instrument panel air outlet deflector assemblies. Refer to Instrument Panel Outer Air Outlet Deflector Replacement - Left Side . Prior to removal of the instrument panel lower trim panel assembly, note the routing of the instrument panel wiring harness and connector locations to ensure proper reinstallation.
1Instrument Panel Inflatable Restraint Bolt (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten: 10 N.m (89 lb in)
2Parking Brake Lever Bracket Reinforcement Screw (Qty: 3) Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Lower Trim Panel Bolt/Screws (Qty: 16) Tighten: 2.5 N.m (22 lb in)
4Instrument Panel Lower Trim Panel Assembly Procedure Disconnect the instrument panel wiring harness from the instrument panel lower trim panel assembly and position out of the way. When replacing the instrument panel lower trim panel assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 89

Scheme 89: Instrument Panel Lower Trim Panel Replacement (Right Hand Drive)
Scheme 89: Instrument Panel Lower Trim Panel Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the front floor console assembly. Refer to Front Floor Console Replacement (Right Hand Drive) . Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the radio front speakers. Refer to Radio Front Speaker Replacement . Remove the radio. Refer to Radio Replacement . Remove the radio, video, audio disc player, and navigation information display assembly, if equipped. Refer to Radio, Video, Audio Disc Player, and Navigation Information Display Replacement . Remove the left and right instrument panel insulators. Refer to Instrument Panel Insulator Replacement - Left Side (Right Hand Drive) and Instrument Panel Insulator Replacement - Right Side (Right Hand Drive) . Remove the steering column assembly. Refer to Steering Column Replacement . Remove the instrument panel cluster assembly. Refer to Instrument Cluster Replacement (Right Hand Drive) . Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement (Right Hand Drive) . Remove the right, left, and center instrument panel trim panel appliques. Refer to Instrument Panel Trim Plate Applique Replacement - Right Side (Right Hand Drive ) and Instrument Panel Trim Plate Applique Replacement - Left Side (Right Hand Drive) and Instrument Panel Trim Plate Applique Replacement - Center (Right Hand Drive) . Remove the right and left instrument panel flood lamp assemblies. Refer to Instrument Panel Flood Lamp Replacement - Left Side and Instrument Panel Flood Lamp Replacement - Right Side . Remove the left and right instrument panel air outlet deflector assemblies. Refer to Instrument Panel Outer Air Outlet Deflector Replacement - Left Side and Instrument Panel Outer Air Outlet Deflector Replacement - Right Side . Prior to removal of the instrument panel lower trim panel assembly, note the routing of the instrument panel wiring harness and connector locations to ensure proper reinstallation.
1Instrument Panel Inflatable Restraint Bolt (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten: 10 N.m (89 lb in)
2Parking Brake Lever Bracket Reinforcement Screw (Qty: 3) Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Lower Trim Panel Bolt/Screws (Qty: 16) Tighten: 2.5 N.m (22 lb in)
4Instrument Panel Lower Trim Panel Assembly Procedure Disconnect the instrument panel wiring harness from the instrument panel lower trim panel assembly and position out of the way. When replacing the instrument panel lower trim panel assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 90

Scheme 90: Instrument Panel Center Compartment Replacement
Scheme 90: Instrument Panel Center Compartment Replacement
CalloutComponent Name
1AM/FM Stereo, Clock, and CD Player Radio Control Assembly Refer to Radio Control Assembly Replacement (with Navigation Display) or Radio Control Assembly Replacement (without Navigation Display) .
2Instrument Panel Center Compartment Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 1 N.m (9 lb in)
3Instrument Panel Center Compartment Assembly
CAUTION
Refer to Fastener Caution .

Scheme 91

Scheme 91: Instrument Panel Compartment Replacement (Left Hand Drive)
Scheme 91: Instrument Panel Compartment Replacement (Left Hand Drive)
CalloutComponent Name
1Instrument Panel Compartment Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Compartment Bolt (Qty: 4) Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Compartment Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel compartment assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 92

Scheme 92: Instrument Panel Compartment Replacement (Right Hand Drive)
Scheme 92: Instrument Panel Compartment Replacement (Right Hand Drive)
CalloutComponent Name
1Instrument Panel Compartment Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Compartment Bolt (Qty: 4) Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Compartment Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel compartment assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 93

Scheme 93: Instrument Panel Compartment Door Latch Replacement
Scheme 93: Instrument Panel Compartment Door Latch Replacement
CalloutComponent Name
1Instrument Panel Compartment Assembly Refer to Instrument Panel Compartment Replacement (Left Hand Drive) or Instrument Panel Compartment Replacement (Right Hand Drive) .
2Instrument Panel Compartment Door Latch Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Compartment Door Latch Assembly
CAUTION
Refer to Fastener Caution .

Scheme 94

Scheme 94: Instrument Panel Compartment Door Latch Trim Cover Replacement
Scheme 94: Instrument Panel Compartment Door Latch Trim Cover Replacement
CalloutComponent Name
Preliminary Procedure: Remove the instrument compartment assembly. Refer to Instrument Panel Compartment Replacement (Left Hand Drive) or Instrument Panel Compartment Replacement (Right Hand Drive) .
1Instrument Panel Compartment Door Latch Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Compartment Door Latch Assembly
3Instrument Panel Compartment Door Latch Trim Procedure: Unsnap the instrument panel compartment door latch trim from the latch assembly.
CAUTION
Refer to Fastener Caution .

Removal Procedure

  1. Remove the instrument panel compartment latch. Refer to «Instrument Panel Compartment Door Latch Replacement»(/cadillac/cts/ii-2007-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Remove the instrument panel compartment door latch trim cover from the latch assembly. Refer to «Instrument Panel Compartment Door Latch Trim Cover Replacement»(/cadillac/cts/ii-2007-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  3. Position the instrument panel compartment latch fork bolt in the up position.
  4. Insert the key into the instrument panel compartment lock cylinder.
  5. Rotate the instrument panel compartment lock cylinder clockwise to the 3 o'clock position with the key.
  6. With the key in position, apply a light load and depress the retainer tumbler through the poke hole at the right hand side of the instrument panel compartment latch.
  7. Rotate the key until the instrument panel compartment lock cylinder rotates to about the 5 o'clock position. This will line up the notch at the rear of the instrument panel compartment lock cylinder with the tab in the instrument panel compartment latch housing.
  8. Remove the instrument panel compartment lock cylinder from the instrument panel compartment latch by pulling on the key.

Installation Procedure

  1. Position the instrument panel compartment latch fork bolt in the up position.
  2. Grasp the instrument panel compartment lock cylinder. Depress the rear-most, light-colored tumbler that is flush with the instrument panel compartment lock cylinder surface.
  3. Insert the key. All the tumblers will now stay depressed.
  4. Insert the instrument panel compartment lock cylinder, with the key inserted, into the instrument panel compartment latch housing. Ensure that the front projection pin is at the appropriate 8 o'clock position. The instrument panel compartment lock cylinder will drop into place.
  5. Rotate the key counterclockwise until the key stops.
  6. Remove the key, the tumblers will now release. The instrument panel compartment lock cylinder is now locked into the instrument panel compartment latch housing.
  7. Install the instrument panel compartment door latch trim cover. Refer to «Instrument Panel Compartment Door Latch Trim Cover Replacement»(/cadillac/cts/ii-2007-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  8. Install the instrument panel compartment latch. Refer to «Instrument Panel Compartment Door Latch Replacement»(/cadillac/cts/ii-2007-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Scheme 95

Scheme 95: Windshield Defroster Nozzle Grille Replacement (Left Hand Drive)
Scheme 95: Windshield Defroster Nozzle Grille Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure: Remove the windshield side garnish moldings. Refer to Windshield Side Garnish Molding Replacement .
1Windshield Defroster Nozzle Grille Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Procedure Use a flat bladed plastic trim tool in order to release the ten retaining clips securing the windshield defroster nozzle grille to the instrument panel. Disconnect the electrical connections. When replacing the windshield defroster nozzle grille assembly, transfer all necessary components.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 96

Scheme 96: Windshield Defroster Nozzle Grille Replacement (Right Hand Drive)
Scheme 96: Windshield Defroster Nozzle Grille Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure: Remove the windshield side garnish moldings. Refer to Windshield Side Garnish Molding Replacement .
1Windshield Defroster Nozzle Grille Assembly CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Procedure Use a flat bladed plastic trim tool in order to release the ten retaining clips securing the windshield defroster nozzle grille to the instrument panel. Disconnect the electrical connections. When replacing the windshield defroster nozzle grille assembly, transfer all necessary components.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 97

Scheme 97: Instrument Panel Upper Trim Cover Replacement (Left Hand Drive)
Scheme 97: Instrument Panel Upper Trim Cover Replacement (Left Hand Drive)
CalloutComponent Name
1Instrument Panel Upper Cover Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the cover to the instrument panel.

Scheme 98

Scheme 98: Instrument Panel Upper Trim Cover Replacement (Right Hand Drive)
Scheme 98: Instrument Panel Upper Trim Cover Replacement (Right Hand Drive)
CalloutComponent Name
1Instrument Panel Upper Cover Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the cover to the instrument panel.

Scheme 99

Scheme 99: Instrument Panel Carrier Bracket Replacement
Scheme 99: Instrument Panel Carrier Bracket Replacement
CalloutComponent Name
Preliminary Procedure: Remove the instrument panel lower trim panel assembly. Refer to Instrument Panel Lower Trim Panel Replacement (Left Hand Drive) or Instrument Panel Lower Trim Panel Replacement (Right Hand Drive) .
1Instrument Panel Carrier Bracket to Carrier Bolt/Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Carrier Bracket to Body Bolt (Qty: 4) Tighten: 25 N.m (19 lb ft)
3Instrument Panel Carrier Bracket
CAUTION
Refer to Fastener Caution .

Scheme 100

Scheme 100: Instrument Panel Carrier Replacement (Left Hand Drive)
Scheme 100: Instrument Panel Carrier Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel assembly. Refer to Instrument Panel Lower Trim Panel Replacement (Left Hand Drive) . Remove the instrument panel carrier bracket assembly. Refer to Instrument Panel Carrier Bracket Replacement . Remove the center air distribution duct assembly. Refer to Air Distributor Center Duct Replacement . Remove the right and left air distribution ducts. Refer to Air Distributor Duct Replacement - Right Side and Air Distributor Duct Replacement - Left Side . Remove the right and left side widow defroster outlet duct assemblies. Refer to Side Window Defogger Outlet Duct Replacement - Right Side and Side Window Defogger Outlet Duct Replacement - Left Side . Remove the parking brake lever pedal assembly. Refer to Parking Brake Lever Pedal Assembly Replacement . If vehicle is equipped with a manual transmission, remove the clutch pedal assembly. Refer to Clutch Pedal Replacement . Prior to removal of the instrument panel carrier assembly, note the routing of the instrument panel wiring harness and connector locations to ensure proper reinstallation.
1Instrument Panel Carrier to HVAC Module Screw (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Carrier to Body Bolt (Qty: 2) Tighten: 25 N.m (19 lb ft)
3Instrument Panel Carrier to Body Nut (Qty: 8) Tighten: 25 N.m (19 lb ft)
4Brake Pedal Bracket to Cowl Nut (Qty: 4) Tighten: 25 N.m (19 lb ft)
5Instrument Panel Carrier Assembly Procedure Disconnect the instrument panel wiring harness from the instrument panel carrier assembly and position out of the way. Prior to removing the carrier assembly from the car, adequately support the HVAC module in order to prevent damage. When replacing the instrument panel carrier assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 101

Scheme 101: Instrument Panel Carrier Replacement (Right Hand Drive)
Scheme 101: Instrument Panel Carrier Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel assembly. Refer to Instrument Panel Lower Trim Panel Replacement (Right Hand Drive) . Remove the instrument panel carrier bracket assembly. Refer to Instrument Panel Carrier Bracket Replacement . Remove the center air distribution duct assembly. Refer to Air Distributor Center Duct Replacement . Remove the right and left air distribution ducts. Refer to Air Distributor Duct Replacement - Right Side and Air Distributor Duct Replacement - Left Side . Remove the right and left side widow defroster outlet duct assemblies. Refer to Side Window Defogger Outlet Duct Replacement - Right Side and Side Window Defogger Outlet Duct Replacement - Left Side . Remove the parking brake lever pedal assembly. Refer to Parking Brake Lever Pedal Assembly Replacement . If vehicle is equipped with a manual transmission, remove the clutch pedal assembly. Refer to Clutch Pedal Replacement . Prior to removal of the instrument panel carrier assembly, note the routing of the instrument panel wiring harness and connector locations to ensure proper reinstallation.
1Instrument Panel Carrier to HVAC Module Screw (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Carrier to Body Bolt (Qty: 2) Tighten: 25 N.m (19 lb ft)
3Instrument Panel Carrier to Body Nut (Qty: 8) Tighten: 25 N.m (19 lb ft)
4Brake Pedal Bracket to Cowl Nut (Qty: 4) Tighten: 25 N.m (19 lb ft)
5Instrument Panel Carrier Assembly Procedure Disconnect the instrument panel wiring harness from the instrument panel carrier assembly and position out of the way. Prior to removing the carrier assembly from the car, adequately support the HVAC module in order to prevent damage. When replacing the instrument panel carrier assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 102

Scheme 102: Front Floor Console Cup Holder Replacement
Scheme 102: Front Floor Console Cup Holder Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console compartment. Refer to Front Floor Console Compartment Replacement .
1Front Floor Console Cupholder Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Cupholder Assembly
CAUTION
Refer to Fastener Caution .

Scheme 103

Scheme 103: Front Floor Console Compartment Replacement
Scheme 103: Front Floor Console Compartment Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement .
1Front Floor Console Compartment Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Compartment Assembly Procedure Disconnect the electrical connections. When replacing the front floor console compartment, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 104

Scheme 104: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Automatic Tra
Scheme 104: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Automatic Tra
CalloutComponent Name
CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Preliminary Procedure Remove the right and left front floor console appliques. Refer to Front Floor Console Applique Replacement . Remove the transmission control boot. Refer to Transmission Control Lever Boot Replacement .
1Front Floor Console Transmission Shifter Trim Plate Assembly Procedure Use a flat bladed plastic trim tool in order to release the retaining clips securing the front floor console transmission shift plate to the console assembly. Disconnect the electrical connections. When replacing the front floor console transmission shift plate assembly, transfer all necessary components.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 105

Scheme 105: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Manual Transm
Scheme 105: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Manual Transm
CalloutComponent Name
CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Preliminary Procedure: Remove the right and left front floor console appliques. Refer to Front Floor Console Applique Replacement .
1Front Floor Console Transmission Opening Trim Plate Assembly Procedure Use a flat bladed trim tool and release the retainers securing the front floor console transmission opening trim plate to the console assembly. Disconnect the electrical connections. Firmly grasp the shift control knob and pull straight up using enough force to release the retainer clip securing the shift control knob and boot assembly to the shift lever. When replacing the front floor console transmission opening trim plate, transfer all necessary components. Tip: Detaching the shift control knob from the shift lever may require a large amount of physical effort. The front floor console transmission opening trim plate and the shift control knob and boot assembly must be removed as an assembly and separated outside the vehicle.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 106

Scheme 106: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Automatic Tr
Scheme 106: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Automatic Tr
CalloutComponent Name
CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Preliminary Procedure Remove the right and left front floor console appliques. Refer to Front Floor Console Applique Replacement . Remove the transmission control boot. Refer to Transmission Control Lever Boot Replacement .
1Front Floor Console Transmission Shifter Trim Plate Assembly Procedure Use a flat bladed plastic trim tool in order to release the retaining clips securing the front floor console transmission shift plate to the console assembly. Disconnect the electrical connections. When replacing the front floor console transmission shift plate assembly, transfer all necessary components.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 107

Scheme 107: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Manual Trans
Scheme 107: Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Manual Trans
CalloutComponent Name
CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Preliminary Procedure: Remove the right and left front floor console appliques. Refer to Front Floor Console Applique Replacement .
1Front Floor Console Transmission Opening Trim Plate Assembly Procedure Use a flat bladed trim tool and release the retainers securing the front floor console transmission opening trim plate to the console assembly. Disconnect the electrical connections. Firmly grasp the shift control knob and pull straight up using enough force to release the retainer clip securing the shift control knob and boot assembly to the shift lever. When replacing the front floor console transmission opening trim plate, transfer all necessary components. Tip: Detaching the shift control knob from the shift lever may require a large amount of physical effort. The front floor console transmission opening trim plate and the shift control knob and boot assembly must be removed as an assembly and separated outside the vehicle.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 108

Scheme 108: Front Floor Console Rear Compartment Replacement
Scheme 108: Front Floor Console Rear Compartment Replacement
CalloutComponent Name
1Front Floor Console Rear Cover Refer to Front Floor Console Rear Cover Replacement .
2Front Floor Console Rear Compartment Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Rear Compartment Assembly
CAUTION
Refer to Fastener Caution .

Scheme 109

Scheme 109: Front Floor Console Replacement (Left Hand Drive)
Scheme 109: Front Floor Console Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the left and right front floor console appliques. Refer to Front Floor Console Applique Replacement . Remove the front floor console transmission shifter trim plate assembly. Refer to Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Automatic Trans) or Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Manual Transmission) .
1Front Floor Console Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Screw (Qty: 2) Procedure Move the front seats to the full rear position. Pull the carpet way from the console assembly to expose the front lower console screws. Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Screw (Qty: 2) Procedure Move the front seats to the full forward position. Pull the carpet way from the console assembly to expose the rear lower console screws. Tighten: 2.5 N.m (22 lb in)
4Front Floor Console Armrest Assembly Procedure Disconnect the electrical connections. When replacing the front floor console assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 110

Scheme 110: Front Floor Console Replacement (Right Hand Drive)
Scheme 110: Front Floor Console Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the left and right front floor console appliques. Refer to Front Floor Console Applique Replacement . Remove the front floor console transmission shifter trim plate assembly. Refer to Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Automatic Trans) or Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Manual Transmission) .
1Front Floor Console Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Screw (Qty: 2) Procedure Move the front seats to the full rear position. Pull the carpet way from the console assembly to expose the front lower console screws. Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Screw (Qty: 2) Procedure Move the front seats to the full forward position. Pull the carpet way from the console assembly to expose the rear lower console screws. Tighten: 2.5 N.m (22 lb in)
4Front Floor Console Armrest Assembly Procedure Disconnect the electrical connections. When replacing the front floor console assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 111

Scheme 111: Front Floor Console Armrest Latch Replacement - Upper
Scheme 111: Front Floor Console Armrest Latch Replacement - Upper
CalloutComponent Name
1Front Floor Console Upper Closeout Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure: Grasp the front floor console upper closeout panel and pull it apart from the upper armrest assembly. Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Compartment Door Latch Screw (Qty: 2) Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Compartment Door Upper Latch Assembly
CAUTION
Refer to Fastener Caution .

Scheme 112

Scheme 112: Front Floor Console Armrest Latch Replacement - Lower
Scheme 112: Front Floor Console Armrest Latch Replacement - Lower
CalloutComponent Name
Preliminary Procedure: Remove the front floor console armrest assembly. Refer to Front Floor Console Armrest Replacement .
1Front Floor Console Lower Armrest Retainer Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure: Grasp the front floor console lower armrest retainer and pull it apart from the armrest upper compartment bin assembly. Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Compartment Door Lower Latch Screw (Qty: 2) Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Compartment Door Lower Latch Assembly
CAUTION
Refer to Fastener Caution .

Scheme 113

Scheme 113: Front Floor Console Armrest Replacement
Scheme 113: Front Floor Console Armrest Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement .
1Front Floor Console Armrest Bolt/Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Armrest Assembly
CAUTION
Refer to Fastener Caution .

Scheme 114

Scheme 114: Front Floor Console Armrest Hinge Replacement
Scheme 114: Front Floor Console Armrest Hinge Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console armrest assembly. Refer to Front Floor Console Armrest Replacement .
1Front Floor Console Lower Armrest Retainer Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure: Grasp the front floor console lower armrest retainer and pull it apart from the armrest upper compartment bin assembly. Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Upper Closeout Screw (Qty: 2) Procedure: Grasp the front floor console upper closeout panel and pull it apart from the upper armrest assembly. Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Compartment Door Hinge Screw (Qty 3) Tighten: 2.5 N.m (22 lb in)
4Front Floor Console Compartment Door Hinge Cover
5Front Floor Console Compartment Door Hinge Assembly
CAUTION
Refer to Fastener Caution .

Scheme 115

Scheme 115: Front Floor Console Trim Plate Replacement
Scheme 115: Front Floor Console Trim Plate Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console transmission shifter trim plate. Refer to Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Automatic Trans) or Front Floor Console Transmission Shift Opening Trim Plate Replacement (Left Hand Drive Manual Transmission) or Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Automatic Trans) or Front Floor Console Transmission Shift Opening Trim Plate Replacement (Right Hand Drive Manual Transmission) .
1Front Floor Console Trim Plate Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Trim Plate Assembly Procedure: Use a flat-bladed plastic trim tool in order to release the retaining clips securing the front floor console trim plate to the console assembly.
CAUTION
Refer to Fastener Caution .

Scheme 116

Scheme 116: Front Floor Console Applique Replacement
Scheme 116: Front Floor Console Applique Replacement
CalloutComponent Name
1Front Floor Console Applique CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim. CAUTION: Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel. Procedure Use a flat bladed plastic trim tool in order to release the three retaining clips securing the front floor console applique to the console assembly. Insert the flat bladed plastic trim tool approximately one inch from the lower rear corner along the lower edge of the trim releasing the first retainer clip, then work forward toward the front of the vehicle releasing the remaining retainer clips.
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.
CAUTION
Be sure to follow the service procedure when removing the trim panel. Failure to follow service procedure may cause damage to the trim panel.

Scheme 117

Scheme 117: Front Floor Console Rear Cover Replacement
Scheme 117: Front Floor Console Rear Cover Replacement
CalloutComponent Name
1Front Floor Console Rear Cover Assembly Procedure Use a flat bladed plastic trim tool in order to release the retaining clips securing the front floor console rear cover to the console assembly. Pull the console rear cover out away from the console assembly enough to excess the mode actuator cable, disconnect the cable from the console rear cover. Disconnect the electrical connections. When replacing the front floor console rear cover, transfer all necessary components.

Scheme 118

Scheme 118: Roof Console Replacement
Scheme 118: Roof Console Replacement
CalloutComponent Name
1Front Roof Console Assembly Procedure Grasp the overhead console and pull downward disengaging the retainer clips securing it to the vehicle. Disconnect the electrical connections. When replacing the front roof console assembly, transfer all necessary components.

Scheme 119

Scheme 119: Roof Rear Console Replacement
Scheme 119: Roof Rear Console Replacement
CalloutComponent Name
1Rear Roof Console Assembly Procedure Grasp the overhead console and pull downward disengaging the retainer clips securing it to the vehicle. Disconnect the electrical connections. When replacing the rear roof console assembly, transfer all necessary components.

More articles — Body & Frame
