Front Suspension System Cadillac CTS I

Fastener Tightening Specifications

Fastener Tightening Specifications

Removal Procedure

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Disconnect the ABS sensor wiring harness from the stabilizer shaft links.
4. Remove the stabilizer shaft link to stabilizer shaft retaining nuts.
5. Disconnect the stabilizer shaft links from the stabilizer shaft.
6. Remove the stabilizer shaft mounting bolts (1) and brackets (2).
7. Remove the stabilizer shaft from the vehicle.
8. Remove the stabilizer shaft insulators (3) from the stabilizer shaft.

Installation Procedure

1. Install the stabilizer shaft insulators (3) to the stabilizer shaft. Install the insulator to the stabilizer shaft with the slit facing rearward.
2. Install the stabilizer shaft to the vehicle.
3. Install the stabilizer shaft brackets (2) and mounting bolts (1).
4. Connect the stabilizer shaft links to the stabilizer shaft.
5. Install the stabilizer shaft link retaining nuts. Tighten: Tighten the link nuts to 50 N.m (37 lb ft). Tighten the bracket bolts to 60 N.m (44 lb ft).
6. Connect the ABS sensor wiring harness to the stabilizer links.
7. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
8. Lower the vehicle.

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Disconnect the ABS sensor wiring harness from the stabilizer shaft link.
4. Remove the stabilizer shaft link retaining nuts.
5. Remove the stabilizer shaft link.

1. Install the stabilizer shaft link.
2. Install the stabilizer shaft link retaining nuts. Tighten: Tighten the nuts to 50 N.m (37 lb ft).
3. Connect the ABS sensor wiring harness to the stabilizer shaft link.
4. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
5. Lower the vehicle.

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the stabilizer shaft mounting bolts (1) and bracket (2).
3. Remove the stabilizer shaft insulators from the stabilizer shaft.

1. Install the stabilizer shaft insulators (3) to the stabilizer shaft with the slit facing rearward.
2. Install the stabilizer shaft bracket (2) and mounting bolts (1). Tighten: Tighten the bolts to 60 N.m (44 lb ft).
3. Lower the vehicle.

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Remove the brake rotor. Refer to «Brake Rotor Replacement - Front»(/cadillac/cts/i-2002-2007/remont/mechanical-hydraulic/#disc-brake-system__brake-rotor-replacement-front) in Disc Brakes.
4. Disconnect the ABS electrical connector.
5. Remove the electrical connector from the splash shield.
6. Remove the wheel bearing/hub mounting bolts.
7. Remove the wheel bearing/hub.

1. Install the wheel bearing/hub.
2. Install the wheel bearing/hub bolts. Tighten: Tighten the bolts to 135 N.m (100 lb ft).
3. Connect the ABS electrical connector.
4. Install the brake rotor. Refer to «Brake Rotor Replacement - Front»(/cadillac/cts/i-2002-2007/remont/mechanical-hydraulic/#disc-brake-system__brake-rotor-replacement-front) in Disc Brakes.
5. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
6. Lower the vehicle.

Steering Knuckle Replacement

Tools Required

1. J 24319-B Universal Steering Linkage Puller
2. J 43631 Ball Joint Remover. See «Special Tools and Equipment»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Remove the wheel bearing/hub. Refer to «Wheel Bearing/Hub Replacement - Front»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .
4. Remove the outer tie rod to steering knuckle retaining nut.
5. Using J 24319-B disconnect the tie rod from the steering knuckle.
6. Remove the lower stabilizer shaft link retaining nut.
7. Remove the stabilizer shaft link from the lower control arm.
8. Remove the upper control arm to steering knuckle pinch bolt.
9. Separate the upper control arm from steering knuckle.
10. Remove the lower ball joint retaining nut and discard.
11. Using J 43631 disconnect the lower ball joint from the steering knuckle. See «Special Tools and Equipment»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .
12. Remove the steering knuckle from the lower ball joint stud.

1. Install the steering knuckle to the lower ball joint stud.
2. Install a new lower ball joint retaining nut.
3. Tighten the nut in the following order: Tighten: Tighten the nut to 20 N.m (15 lb ft). Tighten the nut to an additional 210 degree turn.
4. Install the upper control arm to steering knuckle.
5. Install the upper control arm to steering knuckle pinch bolt and nut. Tighten: Tighten the nut to 60 N.m (44 lb ft).
6. Connect the stabilizer shaft link to the lower control arm.
7. Install the stabilizer shaft link retaining nut. Tighten: Tighten the nut to 50 N.m (37 lb ft).
8. Connect the outer tie rod to the steering knuckle.
9. Install the outer tie rod retaining nut. Tighten: Tighten the nut to 75 N.m (55 lb ft).
10. Install the wheel bearing/hub. Refer to «Wheel Bearing/Hub Replacement - Front»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .
11. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
12. Lower the vehicle.

Lower Control Arm Replacement

Tools Required

1. J 24319-B Universal Steering Linkage Puller
2. J 43631 Ball Joint Remover. See «Special Tools and Equipment»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Remove the stabilizer shaft link lower retaining nut.
4. Remove the stabilizer shaft link from the lower control arm.
5. Remove the shock assembly lower retaining bolts (1).
6. Remove the outer tie rod to the steering knuckle retaining nut.
7. Using J 24319-B disconnect the outer tie rod from the steering knuckle.
8. Remove the ABS wire harness from the lower control arm.
9. Remove the lower control arm mounting nuts.
10. Remove the lower control arm mounting bolts.
11. Lower and support the lower arm control to gain access to the lower ball joint.
12. Remove the lower ball joint retaining nut and discard.
13. Using J 43631 separate the lower ball joint from the steering knuckle. See «Special Tools and Equipment»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .
14. Remove the lower control arm from the vehicle.

1. Install the lower control arm to the vehicle.
2. Install the lower control arm mounting bolts.
3. Adjust the lower control arm to Z height. Refer to «Trim Height Specifications»(/cadillac/cts/i-2002-2007/remont/suspension-front/#suspension-system-general-diagnosis__trim-height-specifications) in Suspension General Diagnosis.
4. Install the lower control arm mounting nuts. Tighten: Tighten the nuts to 135 N.m (100 lb ft).
5. Install the ABS wire harness to the lower control arm.
6. Connect the lower ball joint to the steering knuckle.
7. Install a new lower ball joint retaining nut.
8. Tighten the lower ball joint retaining nut in the following order: Tighten: Tighten the nut to 20 N.m (15 lb ft). Tighten the nut to an additional 210 degree turn.
9. Connect the outer tie rod to the steering knuckle.
10. Install the outer tie rod retaining nut. Tighten: Tighten the nut to 75 N.m (55 lb ft).
11. Install the shock module lower retaining bolts (1). Tighten: Tighten the bolts to 25 N.m (18 lb ft).
12. Install the stabilizer shaft link to the lower control arm.
13. Install the stabilizer shaft link retaining nut. Tighten: Tighten the nut to 50 N.m (37 lb ft).
14. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
15. Lower the vehicle.
16. Align the front end. Refer to «Measuring Wheel Alignment»(/cadillac/cts/i-2002-2007/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures__measuring-wheel-alignment) in Wheel Alignment.

Tools Required

J 43631 Ball Joint Remover. See Special Tools and Equipment .

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Remove the brake rotor. Refer to «Brake Rotor Replacement - Front»(/cadillac/cts/i-2002-2007/remont/mechanical-hydraulic/#disc-brake-system__brake-rotor-replacement-front) in Disc Brakes.
4. Using J 43631 remove the wheel stud at the inner most notch. See «Special Tools and Equipment»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .

1. Install the new stud from the back side of the hub.
2. Install flat washers on the wheel stud.
3. With the flat side of a wheel nut against the washers, tighten the wheel nut until the wheel stud head seats against the wheel hub flange.
4. Install the brake rotor. Refer to «Brake Rotor Replacement - Front»(/cadillac/cts/i-2002-2007/remont/mechanical-hydraulic/#disc-brake-system__brake-rotor-replacement-front) in Disc Brakes.
5. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
6. Lower the vehicle.

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Remove the upper control arm to steering knuckle pinch bolt and nut.
4. Disconnect the upper ball joint from the steering knuckle.
5. Remove the shock module lower mounting bolts (1).
6. Lower the vehicle.
7. Remove the air conditioning line retaining nut from the shock tower.
8. Position the air conditioning line bracket a side.
9. Remove the shock module upper mounting bolts.
10. Remove the shock module from the vehicle.

1. Install the shock module to the vehicle.
2. Install the shock module upper mounting bolts. Tighten: Tighten the bolts to 112 N.m (83 lb ft).
3. Position the air conditioning line bracket to the stud.
4. Install the air conditioning line retaining nut to stud. Tighten: Tighten the nut to 9 N.m (80 lb in).
5. Raise the vehicle.
6. Install the shock module lower mounting bolts (1). Tighten: Tighten the bolts to 25 N.m (18 lb ft).
7. Connect the upper ball joint to the steering knuckle.
8. Install the upper control arm to steering knuckle pinch bolt and nut. Tighten: Tighten the bolt to 60 N.m (44 lb ft).
9. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
10. Lower the vehicle.

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/cts/i-2002-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
2. Remove the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
3. Remove the shock module from the vehicle. Refer to «Shock Module Replacement»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .
4. Install the shock module into the spring compressor.
5. Mark the upper control arm assembly and insulator for proper installation.
6. Turn the spring compressor forcing screw (1) until the coil spring (2) is compressed.
7. Remove the shock absorber upper retaining nut.
8. Remove the shock absorber from the shock module.
9. Loosen the compressor forcing screw until the upper mounting plate and coil spring may be removed.
10. Remove the upper control arm bracket assembly, insulator and coil spring from the spring compressor.

1. Install the coil spring, insulator, upper control arm bracket assembly, and shock absorber to the spring compressor aligning all marks made in disassembly procedure.
2. Turn the spring compressor forcing screw (1) until the coil spring is compressed.
3. Install the shock absorber retaining nut. Tighten: Tighten the nut to 25 N.m (18 lb ft).
4. Remove the shock module from the spring compressor.
5. Install the shock module to the vehicle. Refer to «Shock Module Replacement»(/cadillac/cts/i-2002-2007/remont/suspension-front/#front-suspension-system) .
6. Install the tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/cadillac/cts/i-2002-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
7. Lower the vehicle.

Shock Absorber Disposal

1. Make an indentation 50 mm (2 in) from the top (2) of the tube using a centerpunch.
2. Make an indentation 25 mm (1.0 in) from the bottom (4) of the tube (3) using a centerpunch.
3. Clamp the shock absorber in a vise horizontally with the shock absorber rod (1) completely extended.
4. Drill a hole in the shock absorber at the centerpunch (4) using a 5 mm (3/16 in) drill bit. Gas or a gas/oil mixture will exhaust when the drill bit penetrates the shock absorber. Use shop towels in order to contain the escaping oil.
5. Drill a second hole in the shock absorber at the centerpunch (2) using a 5 mm (3/16 in) drill bit. Oil will exhaust when the drill bit penetrates the shock absorber. Use shop towels in order to contain the escaping oil.
6. Remove the shock absorber from the vise. Hold the shock absorber over a drain pan horizontally with the holes down. Move the rod (1) in and out of the tube (3) to completely drain the oil from the shock absorber.

General Description

The front suspension has 2 primary purposes

1. Isolate the driver from irregularities in the road surface.
2. Define the ride and handling characteristics of the vehicle.

The front suspension absorbs the impact of the tires travelling over irregular road surfaces and dissipates this energy throughout the suspension system. This process isolates the vehicle occupants from the road surface. The rate at which the suspension dissipates the energy and the amount of energy that is absorbed is how the suspension defines the vehicle's ride characteristics. Ride characteristics are designed into the suspension system and are not adjustable. The ride characteristics are mentioned in this description in order to aid in the understanding of the functions of the suspension system. The suspension system must allow for the vertical movement of the tire and wheel assembly as the vehicle travels over irregular road surfaces while maintaining the tire's horizontal relationship to the road.

This requires that the steering knuckle be suspended between an upper and a lower control arm. The lower control arm attaches from the steering knuckle at the outermost point of the control arm. The attachment is through a ball and socket type joint. The innermost end of the control arm attached at 2 points to the vehicle frame, through semi-rigid bushings. The upper control arm attaches to the upper control arm bracket and is part of the front shock module assembly that bolts to the body. Between the upper control arm bracket assembly and the seat on the shock, isolated by insulators under compression, is a coil spring.

This up and down motion of the steering knuckle as the vehicle travels over bumps is absorbed predominantly by the coil spring. The vertical movement of the steering knuckle as the vehicle travels over irregular road surfaces will tend to compress the spring and spring tension will lead the spring to return to the original, at-rest state. This action isolates the vehicle from the road surface. The lower control arms are allowed to pivot at the vehicle frame in a vertical fashion. The upper control arms are allowed to pivot on the upper control arm bracket. The ball joint allows the steering knuckle to maintain the perpendicular relationship to the road surface.

A shock absorber is used in conjunction with this system in order to dampen out the oscillations of the coil spring. A shock absorber is a basic hydraulic cylinder. The shock is filled with oil and has a moveable shaft that connects to a piston inside the shock absorber. Valves inside the shock absorber offer resistance to oil flow and consequently inhibit rapid movement of the piston and shaft. Each end of the shock absorber is connected in such a fashion to utilize this recoil action of a spring alone.

Front suspensions systems utilize a stabilizer shaft. The stabilizer bar connects between the left and right lower control arm assemblies through the stabilizer link and stabilizer shaft insulators. This bar controls the amount of independent movement of the suspension when the vehicle turns. Limiting the independent movement defines the vehicle's handling characteristics on turns.

Special Tools

Special Tools Illustration Tool Number/ Description J 24319-B Universal Steering Linkage Puller J 43631 Ball Joint Remover

Scheme 1

Scheme 2
