Supplemental Inflatable Restraint System - Deactivation Procedures Cadillac CTS I

SPECIAL CARE DURING MECHANICAL REPAIRS

In some instances, it may be necessary to remove the steering column or instrument panel to access electrical components. Observe specific manufacturer SERVICE PRECAUTIONS when working on a vehicle with an air bag system.

Electrical power sources should NEVER be allowed to contact the inflator on the back of the air bag module. NEVER probe air bag system electrical wires with an analog volt-ohmmeter or test light. Always disable air bag system before servicing vehicle. See appropriate DISABLING & ACTIVATING AIR BAG SYSTEM procedure. Failure to disable system properly may result in accidental air bag deployment and possible personal injury.

If air bag system is not fully functional for any reason, DO NOT drive vehicle until system is repaired and functions properly. DO NOT remove bulbs, modules, sensors, or other air bag components which will prevent air bag system from operating as designed. If air bag system is not functional, park vehicle until system is repaired and functions properly.

SYSTEM OPERATION CHECK

PICKUPS WITH PASSENGER AIR BAG

Turn ignition switch from OFF to ON position. Turn passenger air bag switch to OFF position, then back to ON position. With ON/OFF switch in ON position, AIR BAG warning light should flash 7 times, then turn off.

The following AIR BAG warning light conditions indicate possible SIR system faults

1. Light does not illuminate at all.
2. Light remains illuminated when ignition is turned on.
3. Light illuminates while vehicle is driven.

ALL MODELS EXCEPT PICKUPS WITH PASSENGER AIR BAG

Turn ignition switch from OFF to ON or RUN position. AIR BAG warning light should flash 7 times (6-10 times on DeVille) and then turn off.

The following AIR BAG warning light conditions indicate possible SIR system faults

1. Light does not illuminate at all.
2. Light remains illuminated when ignition is turned on.
3. Light illuminates while vehicle is driven.

SIR system faults are usually due to a disconnected/loose electrical connector caused by previous service on vehicle. Always check all Yellow SIR connectors for loose connections or damage.

If all connectors are okay, and AIR BAG warning light is still not operating properly, diagnose SIR system. Repair air bag system as necessary.

VEHICLES WITH PASSENGER PRESENCE SYSTEM

PASSENGER AIR BAG ON/OFF indicators located on the rear view mirror are used to notify the driver when the Passenger Presence System (PPS) has enabled or disabled the instrument panel inflator module. The PPS air bag indicators will also inform the driver of any PPS malfunctions. When the ignition is turned on, the PPS module is supplied with ignition 1 voltage and commands both PASSENGER AIR BAG ON/OFF indicators ON for 5 seconds. The PPS module conducts tests on the PPS components and circuits while both ON/OFF indicators are ON. If no malfunctions are detected, the PPS module will turn the PASSENGER AIR BAG indicator ON or OFF depending on the status of the PPS. If a malfunction is detected, the PPS module will store a Diagnostic Trouble Code (DTC), default the PPS to the OFF state and communicate with the SDM that a DTC has been set. When the SDM detects that the PPS has set a DTC, the SDM will set either DTC B0092 or B0098 and request the Instrument Panel Cluster (IPC) to turn the AIR BAG indicator located on the IPC ON. This is done to notify the driver of any PPS malfunctions. The presence of a SIR system malfunction could result in non-deployment of the air bags. The AIR BAG indicator will remain ON until the malfunction has been repaired.

Note. When the following conditions apply: Air Bag lamp is on. Passenger Air Bag indicator always reads off. DTC B0092 is reported. The cause of this condition may be a shorted Passenger Presence System (PPS) sensor wire. The PPS sensor harness is located under the front passenger seat. This harness may be pinched between the seat frame and the track/riser.

SERVICE PRECAUTIONS

Observe the following service precautions when working with air bag systems

1. Disable appropriate air bag system zone or zones before servicing any air bag system or steering column component. Failure to do this may result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-activating-air-bag-system) .
2. Sensing and Diagnostic Module (SDM) maintains a reserve energy supply. Deployment power is available for as long as one minute after disconnecting battery power. Servicing vehicle before this time limit is reached may cause accidental air bag deployment and possible personal injury.
3. After repairs, stay well away from air bag inflator module(s), and turn ignition switch to ON position. Ensure AIR BAG warning light is working properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__system-operation-check) .
4. Use only new, original equipment replacement parts. DO NOT use salvaged parts for SIR system repairs.
5. DO NOT expose air bag inflator modules to temperatures above 150°F (65°C).
6. Always wear safety glasses when servicing or handling an air bag.
7. Air bag module must be stored in its original special container until it is ready to be used for service. It must be stored in a clean, dry place, away from sources of extreme heat, sparks or high electrical energy.
8. When placing a live air bag module on a bench or other surface, always face air bag and trim cover upward, away from surface. This will reduce motion of module if it is accidentally deployed.
9. After deployment, air bag surface may contain deposits of sodium hydroxide which can irritate skin. Always wear safety glasses, rubber gloves and a long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct disposal procedures.
10. When carrying a live air bag module, point trim cover away from your body to minimize injury in case of accidental deployment. DO NOT carry live air bag module by wiring harness or connector.
11. DO NOT carry seat belt pretensioner by wiring harness or connector. Seat belt pretensioner can be carried by piston tube. When handling a live seat belt pretensioner, DO NOT touch seat belt pretensioner in cable area between buckle and mounting bolt hole. DO NOT cover pretensioner piston tube opening with hands or point open end at yourself or others.
12. Coil assembly must be replaced whenever air bag is deployed. Replace SDM, driver air bag module, passenger air bag module, side air bag module, side air bag sensor or front air bag sensor if any component has been dropped from a height of 3 feet or more.
13. DO NOT attempt to repair SDM, air bag inflator modules, air bag sensors or steering wheel coil assembly. Service all components by replacement only.
14. Electrical sources should never be allowed near inflator on back of air bag module.
15. Avoid touching SDM terminals to prevent electrostatic discharge damage.
16. If water enters the vehicle's interior and soaks the carpet up to level of SDM, inspect the affected area and remove all evidence of water. Repair water damage, replace SDM, and replace harness connector. Failure to do this may result in accidental air bag deployment and possible personal injury.
17. If air bag system is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally. If air bag system is not functional, park vehicle until repairs can be made.

DISABLING & ACTIVATING AIR BAG SYSTEM

Note. When AIR BAG or SIR fuse is removed, and ignition is in ON position, AIR BAG warning light will illuminate. This is normal operation and does not indicate SIR system malfunction.

SUPPLEMENTAL INFLATABLE RESTRAINT DISABLING & ENABLING ZONES

Note. Not all zones are used by all vehicles.

The Supplemental Inflatable Restraint (SIR) system has been divided into disabling and enabling zones. When performing service on or near SIR components or SIR wiring, it may be necessary to disable the SIR components in that zone. It may be necessary to disable more than one zone depending on the location of other SIR components and the area being serviced. (Scheme 1) Identify the specific zone or zones in which service will be performed and disable and enable selected zone or zones.

Scheme 1

ALERO, GRAND AM & MALIBU

Note. When AIR BAG fuse is removed and the ignition is in ON position, the AIR BAG warning lamp will illuminate. This is a normal operation and does not indicate an SIR system malfunction.

Disabling System

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch.
2. Remove AIR BAG fuse from junction block/fuse panel at far left end of instrument panel. (Scheme 2) Wait one minute. Zone 3 - To disable driver side air bag module and coil located in SIR Zone 3, remove Connector Position Assurance (CPA) clip. (Scheme 1) Disconnect driver 2-pin Yellow SIR connector located above fuse block. (Scheme 2) Zone 5 - To disable passenger side air bag module located in SIR Zone 5, remove access panel from junction block/fuse panel at far right end of instrument panel. (Scheme 1) Remove passenger air bag CPA clip and disconnect 2-pin Yellow SIR connector located above fuse block. (Scheme 3) Zone 9 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, remove CPA clip. (Scheme 1) Disconnect driver side 2-pin Yellow SIR connector located above fuse block. (Scheme 2)and (Scheme 3). Remove passenger air bag CPA clip and disconnect 2-pin Yellow SIR connector located above fuse block.

Scheme 2

Scheme 3

Activating System

1. Ensure key is out of ignition switch and AIR BAG fuse is still removed. Connect Yellow SIR connectors previously disconnected to vehicle harness and install CPA clips. Install AIR BAG fuse. Install access panels.
2. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch.
2. Remove AIR BAG fuse from instrument panel fuse block. Fuse block is under lower left side of instrument panel, on firewall. Wait at least one minute. Zone 1 - To disable inflatable restraint front end discriminating sensor located in SIR Zone 1, raise and support the vehicle. (Scheme 1) Remove Connector Position Assurance (CPA) clip from inflatable restraint front end discriminating sensor connector located on the frame crossmember. Disconnect inflatable restraint front end discriminating sensor connector. Zone 3 - To disable driver side air bag module and coil located in SIR Zone 3, remove sound insulator and knee bolster from lower left side of instrument panel. (Scheme 1) Remove CPA clip from driver 2-pin Yellow SIR connector located left of the steering column near the knee bolster. Disconnect driver 2-pin Yellow SIR connector located near the knee bolster. (Scheme 4) Zone 5 - To disable passenger side air bag module located in SIR Zone 5, remove passenger knee bolster from right side of instrument panel. (Scheme 1) Remove the CPA clip from the passenger side air bag module 2-pin Yellow SIR connector located behind instrument panel support. Disconnect passenger side air bag module 2-pin Yellow connector. (Scheme 5) Zone 7 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 7, remove sound insulator and knee bolster from lower left side of instrument panel. (Scheme 1) Remove CPA clip from driver 2-pin Yellow SIR connector located left of the steering column near the knee bolster. Disconnect driver 2-pin Yellow SIR connector located near the knee bolster. (Scheme 4) Remove passenger knee bolster from right side of instrument panel. Remove passenger air bag CPA clip and disconnect 2-pin Yellow SIR connector located behind instrument panel support. (Scheme 5)

Scheme 4

Scheme 5

1. Remove key from ignition switch. Ensure AIR BAG fuse is still removed from fuse block. Connect passenger air bag Yellow 2-pin connector. Install CPA clip. Connect driver air bag Yellow 2-pin connector. Install CPA clip. To complete installation, reverse removal procedure.
2. Install AIR BAG fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch.
2. Remove SIR fuse from fuse block. On Aurora, Bonneville and LeSabre, fuse is in rear fuse block beneath rear seat cushion, on driver's side. On Park Avenue, fuse is in underhood fuse block. Wait one minute. NOTE: Park Avenue does not have any SIR components in SIR Zone 1. Zone 1 - On Aurora, Bonneville and LeSabre, to disable inflatable restraint front end discriminating sensor located in SIR Zone 1, open front hood. Locate front end sensor sometimes referred to as Electronic Frontal Sensor (EFS). Remove Connector Position Assurance (CPA) clip from EFS. Remove EFS connector from the EFS. Zones 2 & 6 - To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove appropriate center pillar trim panel. Remove front and rear carpet retainers and then center pillar trim panel. Remove inflatable restraint SIS CPA clip from the SIS and then remove SIS Yellow connector. (Scheme 6) Zone 3 - To disable inflatable restraint steering wheel module and coil located in SIR Zone 3, remove sound insulator panel from under left side of instrument panel. Remove CPA clip, and disconnect driver 2-pin Yellow SIR connector at base of steering column. (Scheme 7) Zone 5 - To disable passenger air bag module located in SIR Zone 5, remove right insulator panel from under right side of instrument panel. Remove passenger air bag CPA clip from the vehicle harness Yellow connector located under instrument panel and disconnect 2-pin Yellow SIR connector from vehicle harness. (Scheme 8) Zone 7 - To disable driver's seat side air bag module located in SIR Zone 7, remove CPA clip from driver's seat side air bag module Yellow 2-pin connector located under driver's seat. (Scheme 9) Disconnect vehicle harness Yellow connector from side air bag module Yellow connector. NOTE: Park Avenue does not have any SIR components in SIR Zone 8. Inflatable restraint Sensing and Diagnostic Module (SDM) is located in SIR Zone 9. Zone 8 - On Aurora, Bonneville and LeSabre, to disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable SIR Zones 1, 2, 3 5, 6, 7 and 9. Remove CPA clip from Yellow connectors and disconnect vehicle harness SIR Yellow connectors. Zone 9 (Except Park Avenue) - On Aurora, Bonneville and LeSabre, to disable passenger's seat side air bag module located in SIR Zone 9, remove CPA clip from passenger's seat side air bag module Yellow 2-pin connector located under passenger's seat. (Scheme 9) Disconnect vehicle harness Yellow connector from side air bag module Yellow connector. Zone 9 (Park Avenue) - On Park Avenue, inflatable restraint Sensing and Diagnostic Module (SDM) and passenger's seat side air bag module are located in SIR Zone 9. To disable passenger's seat side air bag module, remove CPA clip from passenger's seat side air bag module Yellow 2-pin connector located under passenger's seat. (Scheme 9) Disconnect vehicle harness Yellow connector from side air bag module Yellow connector. To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable passenger's seat side air bag module and SIR Zones 2, 3, 5, 6 and 7. Remove CPA clip from Yellow connectors and disconnect vehicle harness SIR Yellow connectors.

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

AVALANCHE, ESCALADE, ESCALADE ESV, ESCALADE EXT, SIERRA, SILVERADO, SUBURBAN, TAHOE, YUKON & YUKON XL

Note. When AIR BAG or SIR fuse is removed, and ignition is in ON position, AIR BAG warning light will illuminate. This is normal operation and does not indicate SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove AIR BAG fuse from instrument panel fuse block. Fuse block is located at far left end of instrument panel. Wait one minute. CAUTION: Vehicle is equipped with 2 inflatable restraint front end sensors. When performing this procedure ensure both front end sensors are disabled. Zone 1 - To disable, inflatable restraint front end sensors located in SIR Zone 1, raise and support vehicle. Remove Connector Position Assurance (CPA) clips from both front end sensor connectors located on the frame crossmember. Disconnect both front end sensor connectors. Zones 2 & 6 - To disable left or right front door inflatable restraint Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove the front door handle bezel. Remove the window handle, if equipped. Release the upper extension by pulling outward in order to release upper retainer clip. Remove upper extension from door trim panel by lifting up and out. Remove the manual lock lever from the trim panel using a flat-bladed tool. Remove the trim panel screws. Disconnect the electrical connectors and remove trim panel from door. Carefully slide door trim panel up in order to release retainers from the door. Remove CPA clip from side air bag sensor Yellow 2-pin connector located near bottom of door. (Scheme 10) Disconnect side air bag sensor Yellow 2-pin connector. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove CPA clip from steering wheel module Yellow 4-pin connector located left of steering column near knee bolster. (Scheme 11) Disconnect steering wheel module Yellow 4-pin connector. Zone 5 - To disable passenger air bag module located in SIR Zone 5, open glove box. Push in on glove box sides to fully open glove box. Remove CPA clip. Disconnect passenger air bag 4-pin Yellow SIR connector located behind glove box attached to main instrument panel support. (Scheme 12) Zone 7 - To disable inflatable restraint Sensing and Diagnostic Module (SDM), inflatable restraint side air bag module, and inflatable restraint Seat Position Switch (SPS) located in SIR Zone 7, remove CPA clip from driver air bag module Yellow 4-pin connector. Disconnect driver air bag module Yellow 4-pin connector. Remove CPA clip from passenger air bag module Yellow 4-pin connector. Disconnect passenger air bag module Yellow 4-pin connector. Remove CPA clip from the right front side air bag module Yellow 2-pin connector located under passenger seat. Disconnect right front side air bag module Yellow 2-pin connector. Remove CPA clip from left front side air bag module Yellow 2-pin connector located under driver seat. Disconnect left front side air bag module Yellow 2-pin connector. (Scheme 13)Zone 9 - To disable inflatable restraint Passenger Presence System (PPS), inflatable restraint side air bag module, inflatable restraint Seat Position Switch (SPS), and inflatable restraint seat belt tension retractor sensor located in SIR Zone 9, remove CPA clip from right side air bag module Yellow 2-pin connector located under passenger seat. Disconnect right side air bag module Yellow 2-pin connector. (Scheme 13)

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

AVEO

Note. When AIR BAG fuse is removed and the ignition is in ON position, the AIR BAG warning lamp will illuminate. This is a normal operation and does not indicate an SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch.
2. Remove AIR BAG fuse from fuse block located on the far left side of dash. Zone 2 Or 6 - Remove center pillar trim. Remove the Connector Position Assurance (CPA) clip from the seat belt pretensioner connector. Disconnect the seat belt pretensioner connector from the vehicle harness. Remove the CPA clip from the side Air Bag sensor. Disconnect the side air bag sensor connector. (Scheme 14) Zone 3 - Remove the lower steering column trim panel and knee bolster. Remove CPA clip from Yellow connector and disconnect Yellow connector. Zone 5 - Remove the glove box. (Scheme 15) Remove the CPA clip and the Yellow 2-pin connector from the inflatable restraint I/P module and disconnect the connector. (Scheme 16) Zones 7 & 9 - Remove the CPA clip (1) from the side impact module connector located under driver or passenger seat. Disconnect the side air impact connector. (Scheme 17) Zone 8 - Disconnect SIR connectors in zones 2, 3, 5, 6, 7 & 9.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Ensure key is out of ignition switch and AIR BAG fuse is still removed. Connect Yellow SIR connectors previously disconnected to vehicle harness and install CPA clips. Install AIR BAG fuse. Install access panels.
2. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal process.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove console accessory wiring junction block access hole cover. Remove SIR (10-amp) fuse from fuse block. Fuse block is behind access cover on right side of center console. Wait one minute. Zone 1 - To disable restraint Electronic Front End Sensor (EFS) located in SIR Zone 1, remove grille. Remove retainers that hold upper front bumper fascia to radiator support. Pull fascia from radiator support to gain access to sensor. Remove Orange CPA clip from Yellow sensor harness connector. Disconnect harness connector from sensor. Zones 2 Or 6 - To disable driver/left Side Impact Sensor (SIS) located in SIR Zone 2 or passenger/right Side Impact Sensor (SIS) located in SIR Zone 6, remove front and rear door sill plates from appropriate zone. Remove center pillar lower trim. Remove CPA clip from Yellow 2-pin harness connector on inflatable restraint side air bag sensor. (Scheme 18) Disconnect wiring harness connector from side air bag sensor. Zone 3 - To disable driver side air bag module and coil located in SIR Zone 3, remove sound insulator panel from under left side of dash. Remove CPA clip. Disconnect driver air bag 2-pin Yellow SIR connector at base of steering column. (Scheme 19) Zone 5 - To disable passenger air bag module located in SIR Zone 5, remove sound insulator panel from under right side of dash. Remove CPA clip from passenger air bag module connector located behind right side insulator panel. Disconnect passenger air bag 2-pin Yellow SIR connector. (Scheme 54) Zone 7 Or 9 - To disable driver seat side air bag module located in SIR Zone 7 or passenger seat side air bag module located in SIR Zone 9, remove CPA clip from driver side or passenger side air bag 2-pin Yellow SIR connector. Disconnect Yellow SIR connector from vehicle harness located under driver seat or passenger seat. (Scheme 20) Zone 9 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3, 5, 7 and passenger seat side air bag module located in SIR Zone 9. Disconnect Yellow component connectors.

Scheme 18

Scheme 19

Scheme 20

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

BLAZER, CANYON, COLORADO, JIMMY, S10 PICKUP & SONOMA

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove SIR fuse from instrument panel fuse block. Fuse block is located behind access cover on far left end of instrument panel. Wait one minute. Zone 1 - To disable inflatable restraint front end discriminating sensors located in SIR Zone 1, raise and support the vehicle. Remove Connector Position Assurance (CPA) clip from both inflatable restraint front end discriminating sensor connectors located on frame crossmember. Disconnect inflatable restraint front end discriminating sensor connectors. Zone 2 Or 6 (Colorado & Canyon) - Remove trim panel from door and remove the Connector Position Assurance (CPA) clip (3) from the side impact sensor Yellow 2-pin connector (5) located near the middle of the door. Disconnect the side impact sensor Yellow 2-pin connector (5) located near the middle of the door. (Scheme 10) Remove the garnish trim panel from rear corner. Remove the CPA clip from the seat belt pretensioner-left connector. Disconnect the seat belt pretensioner-left connector from the vehicle harness connector. (Scheme 22) Disconnect the roof rail module connector (1) from the vehicle harness. (Scheme 23) Zone 3 - To disable driver side air bag module and coil located in SIR Zone 3, remove left side knee bolster. Remove CPA clip and disconnect driver air bag 2-pin Yellow SIR connector at base of steering column. (Scheme 21) Zone 5 - To disable passenger side air bag module located in SIR Zone 5, open glove box, lift stop, and allow door to fully open. Remove CPA clip and disconnect passenger air bag 2-pin Yellow SIR connector. Connector is located behind instrument panel support, in left side of glove box opening. Zone 8 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 1, 3 & 5. Disconnect Yellow component connectors.

Scheme 21

Scheme 22

Scheme 23

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

BRAVADA, ENVOY, ENVOY XUV, TRAILBLAZER, & RAINIER

Note. When AIR BAG or SIR fuse is removed, and ignition is in ON position, AIR BAG warning light will illuminate. This is normal operation and does not indicate SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove SIR fuse from underhood fuse block. Fuse block is located in the underhood fuse block. Wait one minute. CAUTION: Vehicle is equipped with 2 inflatable restraint electronic front end sensors. When performing this procedure ensure both front end sensors are disabled. Zone 1 - To disable inflatable restraint Electronic Front Sensors (EFS) located in SIR Zone 1, remove the grille. Remove headlamp wire harness from the retaining clip and raise wire harness to gain access to the front end sensor. Loosen sensor retaining bolts and remove sensor assembly from the frame. (Scheme 24) Position sensor assembly above the front bumper. Remove sensor retaining bolts and protective cover. Remove Connector Position Assurance (CPA) clip from the sensor electrical connector and disconnect sensor electrical connector. Zones 2 & 6 - To disable left or right front door inflatable restraint Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove accessory switch panel. Remove 2 trim panel retaining bolts. Release 9 trim panel fasteners from door and remove trim panel from the door. Remove CPA clip from side air bag sensor Yellow 2-pin connector located near the bottom of door. (Scheme 10) Disconnect side air bag sensor Yellow 2-pin connector located near the bottom of door. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove left instrument panel closeout/insulator panel. Remove 4 trim panel retaining screws, release trim panel retaining clips and remove trim panel. Remove CPA clip from driver air bag module Yellow 4-pin connector located left of steering column, near knee bolster. (Scheme 25) Disconnect driver air bag module Yellow 4-pin connector. Zone 5 - To disable passenger air bag module located in SIR Zone 5, access passenger air bag module Yellow 4-pin connector through glove box. Remove CPA clip from instrument panel module Yellow 4-pin connector located behind instrument panel support. Disconnect instrument panel module Yellow 4-pin connector located behind instrument panel support. (Scheme 26)Zone 7 - To disable inflatable restraint side air bag module located in SIR Zone 7, remove CPA clip from left side air bag module Yellow 2-pin connector located under driver seat. Disconnect left side air bag module Yellow 2-pin connector located under driver seat. see scheme 27Zone 8 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 3, 5, 7 and 9. Disconnect Yellow component connectors. Zone 9 - To disable inflatable restraint side air bag module located in SIR Zone 9, remove CPA clip from right side air bag module Yellow 2-pin connector located under passenger seat. Disconnect right side air bag module Yellow 2-pin connector located under passenger seat. see scheme 27

Scheme 24

Scheme 25

Scheme 26

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK or OFF position and remove key. Remove AIR BAG fuse from fuse block. Fuse block is located behind cover on far left end of instrument panel. Wait at least one minute. Zone 1 - To disable Electronic Front end Sensor (EFS) located in SIR Zone 2, remove hood close out filler panel. Remove Connector Position Assurance (CPA) clip from EFS connector. Disconnect EFS connector from EFS. Zones 2 Or 6 (Coupe) - To disable Side Impact Sensor (SIS) located in SIR Zone 2 (left) or 6 (right), remove door trim panel of suspect sensor. Remove enough water deflector to access the side air bag sensor. Remove side air bag sensor from door. (Scheme 28) Remove Connector Position Assurance (CPA) clip from SIS connector and disconnect SIS connector. Zones 2 Or 6 (Sedan) - To disable Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove center pillar upper trim. Remove inflatable restraint side air bag sensor from center pillar. (Scheme 29) Remove CPA clip from SIS connector and disconnect SIS connector. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove CPA clip from driver air bag module in-line Yellow 2-pin connector. Connector is located under the instrument panel, left of the steering column. (Scheme 30) Disconnect driver air bag module Yellow 2-pin connector. Zone 5 - To disable passenger air bag module located in SIR Zone 5, remove CPA clip from the passenger air bag module in-line Yellow 2-pin connector located under the instrument panel, left of the steering column. (Scheme 30) Disconnect the inflatable restraint instrument panel module in-line connector. Zone 7 Or 9 - To disable driver seat with left side air bag module located in SIR Zone 7 or passenger seat with right side air bag module located in SIR Zone 9, remove CPA clip from inflatable restraint side air bag module connector located under seat. (Scheme 31) Disconnect side air bag module connector. Zone 9 - To disable Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3, 5, 7 and 9. Disconnect Yellow component connectors.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position and remove key. Remove fuse block access door on far right end of instrument panel. Remove AIR BAG (or SIR) fuse. Wait one minute. Zone 2 (Century & Regal Only) - To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zone 2, remove front and rear door jam carpet retainer. Remove door jam weatherstrip from center pillar pinch weld flange to expose the lower trim panel. Starting at the base, grasp trim panel firmly with both hands and pull panel away from center pillar. Remove seat belt from the slot in the lower trim panel. Remove the center pillar lower trim. Loosen 2 SIS mounting screws and remove SIS from center pillar. Remove Connector Position Assurance (CPA) clip from SIS connector. Disconnect SIS connector. Zone 3 - To disable, driver air bag module and coil located in SIR Zone 3, remove sound insulator panel from under lower left side of instrument panel. Remove CPA clip, and disconnect driver air bag module Yellow 2-pin connector at base of steering column. (Scheme 32) Disconnect steering wheel module coil connector. Zone 5 - To disable passenger side air bag module, located in SIR Zone 5, remove left insulator panel. Remove CPA clip from passenger 2-pin Yellow connector. Disconnect passenger 2-pin Yellow SIR connector located to right of steering column. (Scheme 33) Zone 7 (Century & Regal Only) - To disable driver seat side air bag, located in SIR Zone 7, remove CPA clip from driver side air bag module 2-pin Yellow connector located under driver seat. Disconnect side air bag module 2-pin Yellow connector. Zone 9 (Century & Regal Only) - To disable Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 2, 3 and 5. Disconnect Yellow component connectors. Zone 9 (Grand Prix Only) - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3 and 5. Remove CPA clip from SDM wiring harness connector. Disconnect SDM wiring harness connector from SDM.

Scheme 32

Scheme 33

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

CLASSIC

Note. With the AIR BAG Fuse removed and the ignition ON, the AIR BAG warning lamp illuminates. This is a normal operation and does not indicate an SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key from ignition switch. Remove the AIR BAG Fuse from the left side I/P wiring harness junction block (3) located on the far left side of the dash. (Scheme 34) Zone 3 - Remove the Connector Position Assurance (CPA) clip from the inflatable restraint steering wheel module coil connector (1) located above the wiring harness junction block. Disconnect the steering wheel module coil connector (1). (Scheme 34) Zone 5 - Remove the Connector Position Assurance (CPA) clip (2) from the inflatable restraint connector (1) located above the wiring harness junction block. Disconnect the SIR connector (1). (Scheme 34) Zone 9 - To disable Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disconnect zones 3 & 5.

Scheme 34

To activate AIR BAG system, reverse disabling procedure. Staying well away from both air bags, turn ON the ignition. Ensure the AIR BAG indicator will flash seven times and then AIR BAG indicator turns OFF.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key. Remove SDM fuse (No. 16) from interior fuse block under front floor kick-up panel (passenger side). Wait one minute. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, carefully pry instrument panel courtesy light from left lower closeout panel. Remove push-on retaining nut from steering column bracket stud. Release left lower closeout panel push-in retainers from instrument panel lower support beam. Insert courtesy light up through closeout panel opening. Lower and remove closeout panel. Release notch in right forward edge of closeout panel from tab on accelerator pedal bracket. Remove left sound insulator. Remove CPA clip from driver air bag module coil connector located at base of steering column. (Scheme 35) Disconnect steering wheel module coil connector located at base of steering column. Zone 4 - To disable Sensing and Diagnostic Module (SDM) located in SIR Zone 4, remove left sound insulator. Remove CPA clip from inflatable restraint steering wheel module coil connector located at base of steering column. Disconnect driver air bag module coil connector located at base of steering column. Remove CPA clip from passenger air bag module connector located near base of the steering column. Disconnect passenger air bag module connector. Zone 5 - To disable passenger air bag module located in SIR Zone 5, remove left sound insulator. Remove CPA clip from passenger air bag module connector located at base of steering column. (Scheme 33) Disconnect passenger air bag module connector located at the base of the steering column.

Scheme 35

Remove key from ignition switch. Ensure SDM fuse (No. 16) is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key from ignition switch. Remove rear seat cushion. Locate rear fuse block under rear seat cushion. Remove SIR fuse from rear fuse block. Wait one minute. Zone 1 - To disable inflatable restraint front end sensor located in SIR Zone 1, open front hood. Locate front end sensor sometimes referred to as Electronic Frontal Sensor (EFS). (Scheme 36) Remove Connector Position Assurance (CPA) clip from the EFS connector. Remove EFS connector from EFS. Zones 2 Or 6 - To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zone 2 (left) or Zone 6 (right), remove appropriate center pillar trim panel. Pull out on center pillar garnish molding to disengage retainer clips. Remove front and rear carpet retainer. Remove center pillar garnish molding. Remove appropriate side air bag sensor CPA clip from SIS. (Scheme 37) Remove SIS connector from SIS. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove driver side sound insulator. Remove CPA clip and disconnect Yellow 2-pin SIR connector at base of steering column. (Scheme 38) Zone 5 - To disable passenger air bag module located in SIR Zone 5, remove right sound insulator from bottom of instrument panel. Remove CPA clip from passenger air bag module Yellow connector located below instrument panel. see scheme 40 Disconnect passenger air bag module Yellow connector from vehicle harness Yellow connector. Zones 7 Or 9 - To disable seat side air bag module and seat belt pretensioner located in SIR Zone 7 (left) or Zone 9 (right), move front seats fully forward. Remove both CPA clips from appropriate side air bag module and pretensioner Yellow connector located under driver or passenger seat. (Scheme 39) Disconnect Yellow connector from appropriate side air bag module and pretensioner Yellow harness connector. Zone 8 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 3, 5, 7 and 9. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors. Zones 10 Or 12 - To disable rear inflatable restraint side air bag module located in SIR Zone 10 (left) or Zone 12 (right), remove rear seat back. Remove CPA clip from rear side air bag module Yellow connector. Disconnect side air bag module Yellow connector from vehicle harness Yellow connector. (Scheme 40)

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 6-10 times, and then turns off. To complete installation, reverse removal procedures.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key from ignition switch. Remove AIR BAG fuse from instrument panel fuse block. Fuse block is located on lower left side of instrument panel, above hood release. Wait one minute. Zone 1 - To disable inflatable restraint front end sensor located in SIR Zone 1, raise and support vehicle. Remove Connector Position Assurance (CPA) clip from front end sensor connector (2) located on frame crossmember. Disconnect the front end sensor connector (1). (Scheme 41)Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove CPA clip from driver air bag module 4-pin Yellow connector. (Scheme 42) Disconnect driver air bag module 4-pin Yellow connector located left of steering column, near knee bolster. Zone 5 - To disable passenger air bag module located in SIR Zone 5, remove passenger-side lower trim panel and knee bolster. Remove CPA clip, and disconnect passenger air bag 4-pin Yellow SIR connector located behind instrument panel support. (Scheme 43) Zone 7 - To disable inflatable restraint Sensing and Diagnostic Module (SDM), inflatable restraint seat belt pretensioner and inflatable restraint Seat Position Switch (SPS) located in SIR Zone 7, disable Zones 3 and 5. Remove CPA clip from right seat belt pretensioner Yellow 2-pin connector located under passenger seat. (Scheme 44) Disconnect right seat belt pretensioner Yellow 2-pin connector. Remove CPA clip from left seat belt pretensioner Yellow 2-pin connector located under driver seat. Disconnect left seat belt pretensioner Yellow 2-pin connector. Zone 9 - To disable inflatable restraint seat belt pretensioner and inflatable restraint Seat Position Switch (SPS) located in SIR Zone 9, remove CPA clip from right seat belt pretensioner Yellow 2-pin connector located under passenger seat. Disconnect right seat belt pretensioner Yellow 2-pin connector.

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

GTO

Note. With the SIR fuse removed and the ignition switch in the ON position, the AIR BAG warning indicator illuminates. This is normal operation, and does not indicate an SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn the steering wheel so that the vehicle's wheels are pointing straight ahead. Turn the ignition switch to the OFF position. Zone 3 - Locate and remove the SIR fuse from the Instrument Panel (I/P) fuse panel (1), which is located near the base of the steering column. (Scheme 45) Disconnect the battery negative cable. Remove the upper steering column trim cover. Release the inflatable restraint steering wheel module coil connector locking mechanism (3). Disconnect the inflatable restraint steering wheel module coil connector (1). (Scheme 46) Zone 5 - Open and remove the I/P compartment door. Release then unlock the I/P module connector (2). Disconnect the I/P module connector (2). (Scheme 47) Zone 8 - To disable zone 8, zones 3 and 5 must be disconnected.

Scheme 45

Scheme 46

Scheme 47

To activate, remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component SIR connectors to vehicle harness and install connector lock mechanisms. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. The AIR BAG indicator will flash then turn OFF.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position and remove key from ignition switch. Remove SDM fuse from fuse block at far left end of instrument panel. Fuse block is under access cover. Wait one minute. Zone 1 - To disable inflatable restraint Electronic Front End Sensor (EFS) located in SIR Zone 1, remove radiator upper air baffle and deflector. Remove Orange CPA clip from Yellow sensor harness connector. Disconnect sensor harness connector from sensor. (Scheme 48) Zone 2 (Impala) - To disable Side Impact Sensor (SIS) located in SIR Zone 2, remove front carpet retainer. Pull up carpet retaining leg of quarter lower trim panel. Pull center pillar lower trim panel out to disengage push-in retaining clips. Slide panel down, then out from under the upper trim panel. Remove seat belt from slot in center lower trim panel. Remove center lower trim panel from center pillar. Remove left SIS from center pillar. (Scheme 49) Remove CPA clip from SIS connector. Disconnect SIS connector from SIS. CAUTION: Vehicle has energy-absorbing foam blocks for side air bag protection located in door. To help avoid personal injury in a collision, foam blocks that are damaged, or removed during repairs must be replaced. Failure to replace foam blocks that are removed can violate federal law. Zone 2 (Monte Carlo) - To disable left Side Impact Sensor (SIS) located in SIR Zone 2, remove left door trim panel. Remove water deflector as required. Remove inner energy absorber pad. Loosen the top clip from the outer energy absorber pad and pull the pad away from outer door panel. Remove sensor fasteners. Remove left side air bag sensor from mounting bracket on door air bag beam. (Scheme 50) Remove CPA clip from SIS connector. Disconnect SIS connector from SIS. CAUTION: Vehicle has energy-absorbing foam pads for side air bag protection located in door. To help avoid personal injury in a collision, foam pads that are damaged, or removed during repairs must be replaced. Failure to replace foam pads that are removed can violate federal law. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove left insulator panel. Remove CPA clip from driver air bag Yellow connector located at base of steering column. (Scheme 32) Disconnect driver air bag Yellow air bag connector. Zone 5 - To disable passenger air bag module, located in SIR Zone 5, remove access hole cover from far right end of instrument panel. (Scheme 51) Unclip passenger air bag Yellow connector from metal rail. Remove CPA clip and disconnect passenger air bag Yellow air bag connector. Zone 7 - To disable driver seat left side air bag module located in SIR Zone 7, move driver seat as far forward as possible. Remove CPA clip from side air bag module connector located under the driver seat. Disconnect side air bag module connector. Zone 9 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3, 5 and 7. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Remove key from ignition switch. Ensure SDM fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn steering wheel to place wheels in straight-ahead position. Remove key from ignition switch. Remove SDM (air bag) fuse from instrument panel fuse block. Fuse block is at far right end of instrument panel. Wait at least one minute. Zone 1 - To disable Electronic Front End Sensors (EFS) located in SIR Zone 1, remove CPA clips from both electronic front end sensor connectors. Disconnect both EFS connectors from EFS. (Scheme 24) Zones 2 Or 6 - To disable Side Impact Sensors (SIS) located in SIR Zone 2 (left) or Zone 6 (right), remove seat belt retractor and center pillar trim cover. Loosen side air bag sensor fasteners. (Scheme 52) Remove side air bag sensor from center pillar. Remove CPA clip from side air bag sensor Yellow 2-pin harness connector. Disconnect side air bag sensor wiring harness connector. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove left side sound insulator from under steering column. Remove CPA clip from driver air bag module Yellow 2-pin connector. Disconnect Yellow 2-pin connector located at base of steering column. (Scheme 53) Zone 5 - To disable passenger air bag Module located in SIR Zone 5, remove sound insulator panel from under right side of dash. Remove CPA clip from passenger air bag module connector located behind right side insulator panel. Disconnect passenger air bag 2-pin Yellow SIR connector. (Scheme 54) Zone 7 - To disable inflatable restraint side air bag module and seat belt pretensioner located in SIR Zone 7, move driver seat fully forward. Locate driver seat side air bag and seat belt pretensioner Yellow 2-pin connectors, located under driver's seat. Remove CPA clip and disconnect both connectors. (Scheme 55) Zone 9 - To disable inflatable restraint side air bag module, seat belt pretensioner, and Sensing and Diagnostic Module (SDM) located in SIR Zone 9, remove left insulator panel. Remove CPA clips from driver air bag module coil connector located at the base of steering column. Disconnect driver air bag module coil connector. Remove right insulator panel. Remove CPA clips from passenger air bag module connector located behind right insulator panel. Disconnect passenger air bag module connector. Remove CPA clips from left and right side air bag modules located under driver and passenger seats. Disconnect side air bag module connectors. Remove CPA clips from left and right seat belt pretensioner connectors located under driver and passenger seats. Disconnect seat belt pretensioner connectors.

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Remove key from ignition switch. Ensure SDM fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key from ignition switch. Remove rear seat cushion. Locate rear fuse block under rear seat cushion. Remove SIR fuse from rear fuse block. Wait one minute. Zones 2 Or 6 - To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zone 2 (left) or Zone 6 (right), remove appropriate center pillar trim panel. Pull out on center pillar garnish molding to disengage retainer clips. Remove front and rear carpet retainer. Remove center pillar garnish molding. Remove appropriate side air bag sensor CPA clip from SIS. (Scheme 37) Remove SIS connector from SIS. Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove driver side sound insulator. Remove CPA clip and disconnect Yellow 2-pin SIR connector at base of steering column. (Scheme 38) Zone 5 - To disable passenger air bag module located in SIR Zone 5, remove right sound insulator from bottom of instrument panel. Remove CPA clip from passenger air bag module Yellow connector located below instrument panel. see scheme 40 Disconnect passenger air bag module Yellow connector from vehicle harness Yellow connector. Zone 7 - To disable seat side air bag module and seat belt pretensioner located in SIR Zone 7, move driver seat fully forward. Working under driver seat, remove both CPA clips from driver side air bag module and pretensioner Yellow connector. (Scheme 39) Disconnect Yellow connector from driver side air bag module and pretensioner Yellow connector. Disconnect Yellow connector from vehicle harness. Zone 9 - To disable passenger side air bag module and pretensioner located in SIR Zone 9, move passenger seat fully forward. Working under passenger seat, remove both CPA clips from passenger side air bag module and pretensioner Yellow connector. (Scheme 39) Disconnect Yellow connector from passenger side air bag module and pretensioner Yellow connector. Disconnect Yellow connector from vehicle harness. Zone 9 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 2, 3, 5, 6, 7 and passenger side air bag module and pretensioner located in SIR Zone 9. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 6-10 times, and then turns off. To complete installation, reverse removal procedures.

SRX

Note. With the SIR fuse removed and the ignition switch in the ON position, the AIR BAG warning indicator illuminates. This is normal operation, and does not indicate an SIR system malfunction. Locate and remove the SIR fuse from the right rear fuse center.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch. Zone 1 - Open front hood, and locate both front end sensors (3 and 4). Remove both Connector Position Assurance (CPA) clips (1 and 6) from left and right front end sensor connectors (2 and 5) and disconnect both connectors from left and right front end sensors. (Scheme 56) Zones 2 Or 6 - Remove the left carpet retainer trim in order to lift carpet and push side trim away to expose roof rail air bag connector. Remove the Connector Position Assurance (CPA) clip from the roof rail module Yellow connector. Disconnect the left roof rail module connector (2) from the roof rail module (1). Remove the center pillar trim panel. Remove the SIS CPA clip from the left SIS connector (2). Remove the SIS connector (2) from the SIS (3). (Scheme 57)and (Scheme 58). Zones 3 Or 5 - Remove the driver or passenger sound insulator from the instrument panel. Remove the Connector Position Assurance (CPA) clip from the steering wheel module coil, or I/P module Yellow connector (1). Disconnect the steering wheel module coil or I/P module Yellow connector (1) from the vehicle harness Yellow connector (3). (Scheme 59) Zones 7 Or 9 - Remove both Connector Position Assurance (CPA) clips from the driver or passenger side impact module and seat belt pretensioner Yellow connector (1) which is located under the front of driver or passenger seat. Disconnect the LF or RF side impact module and pretensioner Yellow connector (1) from the vehicle harness Yellow connector. (Scheme 60) Zone 8 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8. Disconnect SIR components in all other zones.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. Ensure key is out of ignition switch and AIR BAG fuse is still removed. Connect Yellow SIR connectors previously disconnected to vehicle harness and install CPA clips. Install AIR BAG fuse. Install access panels.
2. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/cadillac/cts/i-2002-2007/remont/restraints/#supplemental-inflatable-restraint-system-deactivation-procedures__service-precautions). Ensure front wheels are in straight-ahead position. Remove key. Remove AIR BAG fuse from in-line fuse holder located near base of steering column. (Scheme 61) Zone 3 - To disable driver air bag module and coil located in SIR Zone 3, remove steering column opening trim plate. Remove Connector Position Assurance (CPA) clip, release lock tab, and disconnect driver air bag Yellow 2-pin connector. (Scheme 61) Zone 5 - To disable passenger air bag module located in SIR Zone 5, open glove box. Push inward on left and right-side stoppers and rotate glove box downward. Remove CPA clip, and disconnect Yellow 2-pin passenger-side air bag connector. (Scheme 62) Zone 8 - To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 3 and 5. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Scheme 61

Scheme 62

Remove key from ignition switch. Ensure SDM fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

XLR

Note. With the SIR fuse removed and the ignition in the ON position, the AIR BAG warning indicator illuminates. This is normal operation, and does not indicate an SIR system malfunction. Locate and remove Sir Fuse by removing kick panel.

1. Zone 1 - Open front hood, and remove the air cleaner assembly. Locate both right and left front end sensors also known as the Electronic Frontal Sensor (EFS) remove both right and left Connector Position Assurance (CPA) clips from right and left EFS connector. Remove both EFS connectors from the EFS.
2. Zone 2 Or 6 - Open door and remove the door trim panel. Locate Side Impact Sensor (SIS). Remove the CPA clip from SIS connector. Remove the SIS connector from the SIS.
3. Zone 3 - Remove the left/driver sound insulator from the I/P. Remove the CPA clip from the vehicle harness Yellow connector. Disconnect the steering wheel module coil Yellow connector from the vehicle harness Yellow connector. (Scheme 63)
4. Zone 4 - Remove the driver and passenger sound insulator from the I/P. Locate the I/P module and steering wheel module coil Yellow connector just under console and remove the CPA clip from the vehicle harness Yellow connector. Disconnect the I/P module and steering wheel module coil Yellow connector from the vehicle harness Yellow connector. Remove both CPA clips from the driver and passenger side impact module and pretensioner Yellow connector which is located under the driver seat. Disconnect the vehicle harness Yellow connector from the side impact module and pretensioner Yellow connectors.
5. Zone 5 - Remove the right/passenger sound insulator from the I/P. Locate the I/P module Yellow connector just right of console and remove the CPA clip from the vehicle harness Yellow connector. Disconnect the I/P module Yellow connector from the vehicle harness Yellow connector.
6. Zone 7 & 9 - Remove both CPA clips from the front seat of appropriate Side Impact Module and Pretensioner Yellow connector which is located under the seat. Disconnect the vehicle harness Yellow connector (2) from the Side Impact Module and Pretensioner Yellow connector.

Scheme 63

Ensure key is out of ignition switch and AIR BAG fuse is still removed. Connect Yellow SIR connectors previously disconnected to vehicle harness and install CPA clips. Install AIR BAG fuse. Install access panels. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off.
