Eliminating Unwanted Odors in Vehicles

GM Vehicle Care Odor Eliminator, GM P/N 12378554 (Canadian P/N 88901678), may control or eliminate odors in the interior and luggage compartment areas of GM vehicles. This non-toxic, biodegradable, odorless product has been shown to greatly reduce or remove the following types of odor

1. Objectionable smells of mold and mildew resulting from vehicle water leaks
2. Customer created odors, such as smoke

You may safely use GM Vehicle Care Odor Eliminator on fabrics, vinyl, leather, carpet, and sound deadening materials. You may also induce this product into HVAC modules and instrument panel ducts for the control of non-bacterial related odors.

This product may result in the permanent elimination of an odor and may be preferable to customers whose allergies make them sensitive to perfumes. This product may effectively remove odors when directly contacting the odor source. In cases such as water leaks, use this product with diagnostic procedures to first eliminate the primary cause of the odor. Then use further applications on the residual odor to permanently correct the vehicle condition.

How to Use this Product

1. Spray GM Vehicle Care Odor Eliminator directly or as an additive with carpet shampoo in steam cleaners.
2. Do not use on any interior surface that plain water would deteriorate, because this product will have the same effect. Also avoid letting this product come into contact with vinegar or any acidic substance. Acid-based products will hamper the effectiveness of GM Vehicle Care Odor Eliminator.
3. Instructions and cautions are printed on the bottle, but additional help is available. If you encounter a persistent or recurring odor, you may call to obtain additional information and usage suggestions. In the USA, call 1-800-955-8591. In Canada, call 1-800-977-4145.

Tools Required

J 38778 Door Trim Pad Clip Remover

Scheme 1

1. Using a J 38778 release the retainer clips from the rocker panel.
2. Slide the carpet retainer rearward from the hinge pillar.
3. Disconnect the front carpet retainer from the center pillar garnish molding.
4. Remove the front carpet retainer.
5. If the clips come out of the carpet retainers, turn the plastic retainers 90 degrees in the hole in order to secure.

Installation Procedure

1. Position the front upper retainer to the holes in the hinge pillar.
2. Align the front carpet retainer with the slots in the rocker panel.
3. Apply pressure along the entire length of the molding in order to secure the retainers.
4. Ensure the fit at the lower center pillar garnish molding is secure to the front carpet retainer.

J 38778 Door Trim Pad Clip Remover

Removal Procedure

1. Remove the rear seat cushion. Refer to «Seat Cushion Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
2. Using a J 38778 release the retainer clips from the rocker panel.
3. Lift the rear carpet retainer (1) at the center pillar base in order to release the retainer from the center pillar trim (4).
4. Tilt the carpet retainer inward and pull downward in order to release the lock pillar (2) tab from the carpet retainer (3).
5. Remove the rear carpet retainer.
6. If the carpet retainer clips come off of the retainers, turn the retainer clips 90 degrees in the slot in order to secure.

1. Position the rear carpet retainer (1) with the slots in the rocker.
2. Tilt the trim plate in order to align the notch (3) to the tab on the bottom of the lock pillar (2).
3. Ensure the rear carpet retainer is aligned at the lower lock pillar trim.
4. Position the retainers into the slots on the rocker panel.
5. Align the carpet retainer to the slot on the center trim pillar (4).
6. Press downward in order to engage the retainers into the slots in the rocker panel.
7. Install the rear seat cushion. Refer to «Seat Cushion Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.

Floor Carpet Drying

If the carpet or the pad or insulator is wet, use the following criteria for drying or for replacing the components

1. For a 1-piece carpet assembly bonded to a cotton or a fiber padding, replace the entire assembly.
2. For a 2-piece carpet assembly with a cotton or a fiber padding, replace the padding only. While the carpet is out of the vehicle, dry the carpet using the method described below.
3. For a 1-piece carpet assembly bonded to a foam padding or attached to a synthetic padding, dry the carpet using the method described below.
4. For a 2-piece carpet assembly with a synthetic padding, dry the assembly using the method described below.

Drying Method

1. If you observe puddles of liquid on the carpet face, use a wet vacuum to remove the excess moisture.
2. Blot the face of the carpet with a towel in order to absorb as much moisture as possible.
3. Point a fan at the affected area and air dry the carpet.

Carpet Replacement - Front

1. Remove the appropriate front seat. Refer to «Seat Replacement - Bucket»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
2. Remove the center console. Refer to «Console Replacement - Front Floor»(/cadillac/cts/i-2002-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
3. Remove the front carpet retainer. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
4. Remove the rear carpet retainer. Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
5. Remove the center pillar garnish molding. Refer to «Garnish Molding Replacement - Center Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
6. Remove the carpet (1,2).

1. Position the front floor carpet (1,2) into place over the front edge of the rear carpet.
2. Make sure the electrical connector (5) is carefully positioned under the front carpet piece.
3. Align the carpet to the dash panel, rocker panel, tunnel and seat attachment areas.
4. Tuck the carpet behind the tab on the HVAC duct.
5. Ensure all wrinkles are removed.
6. Install the center console. Refer to «Console Replacement - Front Floor»(/cadillac/cts/i-2002-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
7. Install the center pillar garnish molding. Refer to «Garnish Molding Replacement - Center Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
8. Install the front carpet retainer. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
9. Install the rear carpet retainer. Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
10. Install the front seat. Refer to «Seat Replacement - Bucket»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.

Carpet Replacement - Rear

J 38778 Door Trim Pad Clip Remover

1. Remove the front seats. Refer to «Seat Replacement - Bucket»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
2. Remove the center console. Refer to «Console Replacement - Front Floor»(/cadillac/cts/i-2002-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
3. Remove the rear seat cushion. Refer to «Seat Cushion Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
4. Remove the front carpet retainers. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
5. Remove the rear carpet retainers. Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
6. Remove the center pillar garnish moldings. Refer to «Garnish Molding Replacement - Center Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
7. Using a J 38778 disconnect the push-in retainers at the rear ducts.
8. Carefully lift the rear carpet in order to disengage the front floor ducts (4) from the rear floor duct assembly.
9. Remove the rear carpet (3) from the vehicle.
10. Using the J 38778 disconnect the push-in retainers from the air ducts to carpet.
11. Remove the air ducts from the carpeting.

1. Place the rear air distribution ducts to the carpet.
2. Install the push-in retainers in order to secure the air distribution ducts to the rear carpet.
3. Place the rear carpet (3) into the vehicle.
4. Ensure the electrical connectors are exposed above the rear carpeting.
5. Angle the front edge of the rear carpeting in order to attach the rear HVAC ducts to the front carpeting duct assembly (4).
6. Ensure the floor ducts are securely attached to the floor duct assembly.
7. Install new push-in retainers.
8. Press the rear carpet to the floorpan in order to remove any distortion from the carpet.
9. Install the center pillar garnish moldings. Refer to «Garnish Molding Replacement - Center Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
10. Install the rear carpet retainers. Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
11. Install the front carpet retainers. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
12. Install the center console. Refer to «Console Replacement - Front Floor»(/cadillac/cts/i-2002-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
13. Install the front seats. Refer to «Seat Replacement - Bucket»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
14. Install the rear seat cushion. Refer to «Seat Cushion Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.

1. Remove the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
2. Remove the sound barrier to the wheelhouse panel.
3. Remove the rear wheelhouse sound barrier from the vehicle.
4. Remove the rear shoulder belts. Refer to «Seat Belt Retractor Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/restraints-control-systems/#seat-belt-system) in Seat Belts.
5. Remove the center rear shoulder belt. Refer to «Seat Belt Retractor Replacement - Center Rear»(/cadillac/cts/i-2002-2007/remont/restraints-control-systems/#seat-belt-system) in Seat Belts.
6. Lift the rear floorpan sound barrier upward and pull outward in order to remove.

1. Position the sound barrier to the floorpan.
2. Position the sound barrier under the rear compartment trim.
3. Ensure the attachment areas are clear.
4. Route the sound barrier around the electrical harness.
5. Route the sound barrier under the primary weatherstrip on the outside edges.
6. Press firmly in all areas in order to secure the sound barrier to the floorpan.
7. Install the rear shoulder belts. Refer to «Seat Belt Retractor Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/restraints-control-systems/#seat-belt-system) in Seat Belts.
8. Install the center rear shoulder belt. Refer to «Seat Belt Retractor Replacement - Center Rear»(/cadillac/cts/i-2002-2007/remont/restraints-control-systems/#seat-belt-system) in Seat Belts.
9. Position the rear seat back sound barrier to the wheelhouse panel.
10. Install the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.

1. Remove the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
2. Remove the sound barrier (1) to the wheelhouse panel.
3. Lift the rear compartment front interior trim.
4. Remove the wheelhouse sound barrier from the vehicle.

1. Position the sound barrier (1) to the wheelhouse panel under the rear compartment front interior trim.
2. Install the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.

Headliner Replacement

J 38778 Door Trim Pad Clip Remover

1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 2»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) and «SIR Disabling and Enabling Zone 6»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the windshield pillar garnish moldings (2). Refer to «Garnish Molding Replacement - Windshield Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
3. Remove the front seats. Refer to «Seat Replacement - Bucket»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
4. Remove the center console. Refer to «Console Replacement - Front Floor»(/cadillac/cts/i-2002-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
5. Remove the front carpet retainers. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
6. Remove the rear carpet retainers (1). Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
7. Remove the center pillar garnish moldings (3). Refer to «Garnish Molding Replacement - Center Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
8. Remove the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
9. Remove the rear sail panels. Refer to «Sail Panel Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
10. Remove the rear assist handles. Refer to «Assist Handle Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
11. Disconnect the electrical connectors from the left rear quarter panel.
12. Disconnect the right rear quarter panel electrical connectors (3,4).
13. Disconnect the coaxial cable (1).
14. Remove the rear roof mounted dome lamp (1). Refer to «Dome Lamp Replacement»(/cadillac/cts/i-2002-2007/remont/exterior-lights/#lighting-systems-introduction-and-removal-installation) in Lighting Systems.
15. Remove the sunshades. Refer to «Sunshade Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
16. Ensure that the plastic retainer on each side is retrieved as the headliner is lowered.
17. Remove the fasteners for the sunshade rod retainers.
18. Remove the sunshade rod retainers.
19. Remove the fasteners for the overhead console. Refer to «Console Replacement - Overhead»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
20. Disconnect the electrical connectors at the inside rear view mirror attachment.
21. Disconnect the connector lead (3) for the antenna module from the front windshield (2).
22. Disconnect the connector lead (3) for the antenna module from the rear window (1).
23. Pull down at the attachments in order to detach the six glue bond spots on the cardboard roof insulator to headliner.
24. Using J 38778 disconnect the yellow plastic retainer (1) securing the headliner to the roof panel above the overhead console.
25. With the aid from an assistant, remove the headliner through the right front door.
26. Place the headliner upside down on a clean protected surface.
27. Disconnect the electrical connector (1) from the antenna module.
28. Disconnect the 2 coaxial cables (3,4).
29. Remove the antenna module from the bracket on the headliner.

1. Position the new headliner upside down, on a clean protected surface.
2. Transfer the antenna module (2) to the new headliner.
3. Attach the antenna module (2) to the bracket.
4. Connect the electrical connector (1).
5. Connect the 2 coaxial cables (3,4).
6. Ensure the antenna module ground strap is positioned properly to the headliner.
7. Install the rear dome lamp bezel (1) to the headliner.
8. Loosely install the fastener (3).
9. Install the side assist handle retainers.
10. Install the assist handles and loosely install the fasteners in the integral retainer clips in order to hold the handles into position.
11. Install the sunshades to the headliner.
12. Position the electrical harness between the headliner and retainer clip.
13. Install the metal retainer ring (2).
14. Loosely install the fasteners.
15. Connect the electrical connectors (1).
16. Install the sunshade rod retainers.
17. Install the overhead console to the headliner.
18. On the right side, install the bolt through the sunshade rod retainer and through the overhead console bracket.
19. Position the ground strap (1) onto the bolt (2).
20. Install the metal retainer clip over the bolt in order to hold the ground strap into position.
21. Install the left sunshade rod retainer.
22. Loosely install the fastener.
23. Ensure to install a new yellow plastic retainer to the bracket on the overhead console prior to assembly. The headliner is now ready for installation.
24. Ensure the electrical harnesses (3,4,6) are visible prior to installation.
25. With the aid from an assistant, position the headliner (7) to the cardboard roof insulator.
26. Position and align the yellow push-in retainer to the net hole located in roof panel above the overhead console.
27. Apply moderate hand pressure to the overhead console (1) in order to seat the push-in retainer.
28. Secure both side assist handles (9) in order to hold the headliner in place. Tighten the assist handle screws to 2 N.m (18 lb in).
29. Install the assist handle bezel covers.
30. Install the fastener (3) for the rear dome lamp (1). Tighten: Tighten the fastener to 10 N.m (88 lb in).
31. Secure the bezel cover (2).
32. Secure both sunshades. Tighten: Tighten the outer sunshade bezel fasteners to 2 N.m (18 lb in).
33. Secure the right side sunshade rod retainer. Tighten: Tighten the right side to 10 N.m (88 lb in).
34. Secure the left side sunshade rod retainer. Tighten: Tighten the left side to 2 N.m (18 lb in).
35. Position the sunshades to the headliner.
36. Connect the electrical connectors to the inside rearview mirror.
37. Connect the connector lead (3) for the antenna module to the front windshield (2).
38. Connect the connector lead (3) for the antenna module to the rear window (1).
39. Connect the right rear quarter electrical connectors (3,4).
40. Connect the coaxial cable (1).
41. Connect the left rear quarter electrical connectors.
42. Install the rear sail panels. Refer to «Sail Panel Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
43. Install the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
44. Install the center pillar garnish moldings (3). Refer to «Garnish Molding Replacement - Center Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
45. Install the rear carpet retainers (1). Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
46. Install the front carpet retainers. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
47. Install the center console. Refer to «Console Replacement - Front Floor»(/cadillac/cts/i-2002-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
48. Install the front seats. Refer to «Seat Replacement - Bucket»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
49. Install the windshield pillar garnish moldings (2). Refer to «Garnish Molding Replacement - Windshield Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
50. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 2»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) and «SIR Disabling and Enabling Zone 6»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

1. Remove the headliner. Refer to «Headliner Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim__headliner-replacement) .
2. Starting in one corner of the cardboard, pulling downward, cut the adhesive beads (1) using a sharp putty knife or equivalent.
3. Cut off the majority of the loose adhesive beads.
4. Remove the cardboard roof insulator.

1. Apply 6 mm (1/4 in) to 11 mm (1/2 in) high (2) beads of adhesive 15 mm (5/8 in) wide (1).
2. Apply the adhesive in the locations marked on the cardboard insulator (1).
3. Place the cardboard roof insulator to the inner roof panel.
4. Install the headliner. Refer to «Headliner Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim__headliner-replacement) .

1. Gently pry out the outer edge of the escutcheons (2) and push inward.
2. Slide the escutcheon toward the center of the assist handle (3).
3. Remove the 2 screws (1) that retain the assist handle to the roof panel.
4. Remove the assist handle.

1. Position the assist handle (3) to the headliner.
2. Install the two fasteners in order to retain the assist handle to the roof panel. Tighten: Tighten the 2 screws to 2 N.m (18 lb in).
3. Secure the assist handle escutheons (2) to the outer edges of the assist handle.
4. Snap the escutheons in place in order to secure.

1. Using your fingers, gently pull downward at the front edge of the overhead console (1).
2. Disconnect the electrical connectors.
3. Remove the overhead console.

Scheme 2

1. Connect the electrical connectors.
2. Install the overhead console into the headliner opening.
3. Ensure the locking tabs are properly positioned.
4. Press upward on the overhead console (1) to secure the locking tabs to the console bracket.

1. Detach the sunshade (1) from the sunshade rod retainer clip.
2. Remove the windshield pillar garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
3. Remove the fasteners from the outboard bezel (2).
4. The plastic retainer will fall out of the headliner (3) when the three fasteners are removed from the bezel.
5. Carefully reach inside the headliner until the electrical connector (1) is exposed.
6. Disconnect the electrical connector.
7. Remove the sunshade from the vehicle.

1. Position the sunshade to the headliner.
2. Push the electrical connector and the wiring through the hole in the headliner.
3. Connect the electrical connector (1).
4. Position the plastic retainer (2) over the top of the electrical harness.
5. Align the fasteners to the holes in the sunshade metal integral clip (2).
6. Install the fasteners that secure the bezel (2) to the headliner. Tighten: Tighten the fasteners to 2 N.m (18 lb in).
7. Install the windshield pillar garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
8. Secure the sunshade to the sunshade rod retainer.

1. Remove the windshield pillar garnish moldings. Refer to «Garnish Molding Replacement - Windshield Pillar»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
2. Detach the sunshades from the sunshade rod retainers.
3. Carefully pry open the sunshade rod retainer cover using a thin flat-bladed tool.
4. Ensure to include the ground strap upon re-assembly of the sunshade rod retainer, right side only.
5. Remove the fasteners.
6. Lower the front part of the headliner in order to access the ground strap (1).
7. Remove the right side sunshade bezel from the headliner.
8. Remove the left side sunshade bezel from the headliner.

Scheme 3

1. Position the bezel to the bottom side of the headliner.
2. Press the bezel upward into place.
3. Position the overhead console bracket (3) to the sunshade rod retainer.
4. Insert the bolt (1) through overhead console bracket (3) and the ground strap.
5. Install the serrated washer in order to hold the bolt in place prior to installation.
6. Position the bolt to the roof panel. Tighten: Tighten the right side sunshade rod retainer bolt (1) to 10 N.m (88 lb in).
7. Install the left side sunshade rod retainer fastener (4). Tighten: Tighten the fastener to 2 N.m (18 lb in).
8. Position both the sunshades to the sunshade rod retainers.

1. Open the door.
2. Remove the screw cover at the top of the garnish molding.
3. Remove the screw from the garnish molding.
4. Pull inward on the garnish molding (2) to release the top of the molding from the headliner (3).
5. Pull inward at the center of the garnish molding to release the center part of the garnish molding.
6. Remove the speaker. Refer to «Speaker Replacement - Front Upper»(/cadillac/cts/i-2002-2007/remont/entertainment-systems/#entertainment-system) in Entertainment.

1. Install the speaker. Refer to «Speaker Replacement - Front Upper»(/cadillac/cts/i-2002-2007/remont/entertainment-systems/#entertainment-system) in Entertainment.
2. Position the base of the garnish molding to the outside of the instrument panel pad.
3. Position the molding to the windshield pillar, aligning the tabs to the retention clips on the windshield pillar.
4. Push inward on the garnish molding (2) to secure the windshield pillar and headliner.
5. Install the fastener. Tighten: Tighten the fastener to 2 N.m (18 lb in).
6. Install the screw cover.

1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 2»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) and «SIR Disabling and Enabling Zone 6»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
2. Remove the front carpet retainers. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
3. Remove the rear carpet retainers. Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
4. Carefully pull outward at the bottom of the pillar trim in order to use the J 38778 in order to release the three lower retainer clips.
5. Pull outward on the upper portion of the pillar trim in order to release the sheet metal retainer clips from the lock pillar (1).
6. Slide the pillar trim inward and downward in order to release the top locking tab (2) from between the sheet metal and the headliner.
7. Remove the center pillar trim (3).
8. Replace the retainer clips if broken or damaged.

1. Place the metal retention clips to the lock pillar.
2. Secure the new plastic retainer clips (3) to the center pillar (2).
3. Position the top of the locking tab (2) to the slot in the sheet metal under the headliner.
4. Push upward in order to secure.
5. Position the upper trim locating tabs to the metal clips in the lock pillar (1).
6. Position the three plastic retainers to the holes in the lock pillar (1).
7. Push inward beginning at the top of the pillar and working downward to the floorpan in order to secure the center pillar trim (3).
8. Install the rear carpet retainers. Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
9. Install the front carpet retainers. Refer to «Carpet Retainer Replacement - Front»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
10. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 2»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) and «SIR Disabling and Enabling Zone 6»(/cadillac/cts/i-2002-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

J 38778 Door Trim Pad Clip Remover

1. Remove the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
2. Remove the rear sail panels. Refer to «Sail Panel Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
3. Remove the rear carpet retainers (1). Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
4. Using the J 38778 disengage the push-in retainers from the upper garnish molding.
5. Remove the body pillar upper garnish molding by pulling the panel from the locator holes.
6. Remove the garnish molding.
7. Transfer the shoulder belt comfort guide to the new garnish molding, if replacing.

1. Align the plastic retainers on the body pillar upper garnish molding with the holes in the body pillar.
2. Push the panel inward in order to secure the push-in retainers.
3. Install the rear carpet retainers (1). Refer to «Carpet Retainer Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
4. Install the rear sail panels. Refer to «Sail Panel Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
5. Install the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.

J 38778 Door Trim Pad Clip Remover

1. Remove the screw cover from the sail panel.
2. Remove the fastener.
3. Pull downward on the lower front portion of the sail panel in order to release the integral clip.
4. Release the sail panel plastic push-in retainer using the J 38778 , or equivalent.
5. Pull outward at the top in order to release the other integral clip.
6. Pull the sail panel from the C-pillar.
7. Remove the lower shoulder belt fastener.
8. Disengage the shoulder belt and escutheon from the sail panel.
9. Route the rear outboard shoulder belt from the sail panel.
10. Remove the shoulder belt from the sail panel.
11. Remove the sail panel.

1. Position the sail panel to the C-pillar.
2. Route the outboard shoulder belt and escutheon through the sail panel.
3. Straighten the belt, if needed, prior to securing the shoulder belt floorpan fastener. Refer to «Seat Belt Retractor Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/restraints-control-systems/#seat-belt-system) in Seat Belts.
4. Position the upper sail panel downward next to the end of the rear shelf trim panel.
5. Insert the upper metal integral clip (1) on the trim panel to the slot located in the headliner.
6. Insert the lower metal integral clip (2) to the sheet metal.
7. Position the plastic push-in retainer (3) to the hole in the sheet metal.
8. Press inward at the plastic retainer in order to secure.
9. Install the fastener with a magnetic-tipped screwdriver. Tighten: Tighten the screw to 2 N.m (18 lb in).
10. Secure the seat belt escutheon to the sail panel.
11. Install the screw cover to the sail panel.

1. Remove rear shelf trim panel. Refer to «Trim Panel Replacement - Rear Window Shelf»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the four fasteners securing the carrier assembly to the rear shelf.
3. Disengage the retainer securing the right side rear shelf carrier.
4. Disconnect the electrical connectors.
5. Remove the rear shelf carrier assembly (1).

1. Install rear shelf carrier assembly (1).
2. Ensure the retainer on the right side is fully seated into the rear shelf.
3. Connect the electrical connectors.
4. Install the rear shelf carrier fasteners. Tighten: Tighten the rear shelf carrier fasteners to 9 N.m (80 lb in).
5. Install the rear shelf trim panel. Refer to «Trim Panel Replacement - Rear Window Shelf»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .

`

1. Remove the rear seat cushion. Refer to «Seat Cushion Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
2. Remove the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
3. Remove both rear upper quarter sail panels. Refer to «Sail Panel Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
4. Disengage the center shoulder belt from the shoulder belt latch.
5. Disengage the shoulder belt escutheon from the rear shelf.
6. Lift the rear shelf upward to disengage the center shoulder belt from the rear shelf.
7. Disengage the 2 dual lock fasteners (1) at the rear edge of the shelf panel.
8. Lift upward and inward to remove the rear shelf panel (2).

1. Route the rear seat shelf panel (2) to the rear cross car beam at the dual lock fasteners (1).
2. Position the rear center shoulder belt through the rear shelf panel.
3. Ensure the shoulder belt is not twisted.
4. Lower the rear shelf panel over the child restraint tether anchors and apply pressure at both dual lock fasteners (1) to secure.
5. Secure the shoulder belt escutheon to the rear shelf panel.
6. Insert the escutheon rearward and snap the front downward in place to secure.
7. Install both rear upper quarter sail panels. Refer to «Sail Panel Replacement»(/cadillac/cts/i-2002-2007/remont/exteriorinterior-trim/#interior-trim) .
8. Install the rear seat back. Refer to «Seat Back Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.
9. Install the rear seat cushion. Refer to «Seat Cushion Replacement - Rear»(/cadillac/cts/i-2002-2007/remont/seats/#seat-system) in Seats.

Headliner Description

The modular headliner (8) is a one-piece composite substrate that is covered with a foam cloth facing.

Scheme 4

The electrical wiring harness (3, 4, 6) for the roof lighting (2, 5), the electrochromatic (UE1) inside rear view mirror (3),and the antenna module coaxial cable (6), attaches to the headliner by means of an adhesive glue bond.

The headliner is held up to the roof panel cardboard insulator by the use of six adhesive patches along with a single push-in plastic retainer located above the overhead console (2) The rear assist handles (7) fasteners, the front sunshades (1) fasteners and the rear courtesy lamp (5) fasteners also secure the headliner in place.

If the vehicle is equipped with a sunroof, there are four patches of Dual Lock(tm) material at the rear sides of the sunroof opening which add extra support for the headliner.

Special Tools

Special Tools Illustration Tool Number/ Description J 38778 Door Trim Pad Clip Remover

Scheme 5

See also:
• Seat Cushion Replacement - Rear
• SIR Caution
• Console Replacement - Front Floor
• Seat Belt Retractor Replacement - Rear
• SIR Disabling and Enabling Zone 2
• Dome Lamp Replacement
• Fastener Notice
• Speaker Replacement - Front Upper
• Carpet Retainer Replacement - Front
• Headliner Replacement
