Scheme 10
Scheme 11
Scheme 12
STOP ENGINE OIL WARNING LIGHT
Indicates low oil pressure. Does not indicate amount of oil in engine.
ANTI-LOCK BRAKE WARNING LIGHT
Will illuminate when parking brake is applied, and also if fluid is low in service brake system.
EGR WARNING LIGHT
Light indicates need for periodic maintenance service.
ALTERNATOR WARNING LIGHT
Comes on briefly during engine start as a bulb check. If it remains on or comes on while driving, it indicates a problem with the alternator system.
GATE OPEN WARNING LIGHT
Indicates rear lift gate is not closed.
SERVICE ENGINE SOON/CHECK ENGINE WARNING LIGHT
Indicates engine control system problem which may affect driveability or emissions.
LEVEL RIDE LIGHT
Indicates ride level system is operating.
SECURITY SYSTEM LIGHT
This light will stay lit until the ignition key is inserted into the ignition.
TRUNK LIGHT
Indicates the trunk lid is open.
WASHER FLUID LIGHT
Indicates low fluid level in windshield washer reservoir.
STOP ENGINE COOLANT TEMPERATURE LIGHT
Indicates excessive coolant temperature.
FASTEN BELTS LIGHT
Indicates lap belts are not fastened.
WAIT LIGHT (DIESEL)
Indicates need to wait for glow plugs to warm-up prior to starting diesel engines.
WATER IN FUEL LIGHT (DIESEL)
Indicates water in fuel system on diesel engine vehicles.
CHOKE LIGHT
Indicates choke operation, on some gasoline engine vehicles.
