Wheel Alignment Specifications & Procedures Buick Skylark VI

Wheel Alignment 2 illustrations ~147 words

PRE-ALIGNMENT CHECKS

Note. Prior to performing wheel alignment, perform preliminary visual and mechanical inspection of wheels, tires and suspension components. See ALIGNMENT THEORY/OPERATION article in the WHEEL ALIGNMENT section.

TOE-IN (FRONT & REAR)

Loosen jam nut on inner tie rod. Adjust toe to specification by turning inner tie tie rod. DO NOT twist boots (if equipped). Tighten nuts to 45 ft. lbs. (61 N.m). (Scheme 2)

Toe-In (Front & Rear). Scheme 2

Scheme 2: Toe-In (Front & Rear)

CAMBER (REAR)

  1. Remove rear auxiliary spring and strut assembly. See appropriate article in the SUSPENSION section.
  2. File a lateral hole (oblong) on: lower strut-to-knuckle attaching hole, lower strut attaching hole, and lower stabilizer bracket-to-strut attaching hole. (Scheme 3)
  3. Install strut assembly and adjust camber to proper specifications. Tighten strut-to-knuckle nuts to 136 ft. lbs. (184 N.m).

Camber (Rear). Scheme 3

Scheme 3: Camber (Rear)
ApplicationSpecification
Camber in Degrees
Fraction0 +/- 13/16
Decimal0 +/- .80
Caster in Degrees
Fraction2 5/16 +/- 1
Decimal2.30 +/- 1
Toe-In in Inches
Fraction3/64 +/- 3/32
Decimal.05 +/- .10
Toe-In in Degrees
Fraction3/32 +/- 13/64
Decimal.10 +/- .20

WHEEL ALIGNMENT SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Skylark100 (136)

WHEEL LUG NUT TORQUE SPECIFICATIONS
