Note. On vehicles with electronic chassis controls, ensure all systems are functional before adjusting riding height or wheel alignment.
Before adjusting alignment, check riding height. Check riding height with vehicle on level floor and tires properly inflated. Tire inflation specifications can be found on door pillar, side wall of tire, sun visor or glove box. Bounce vehicle several times and allow suspension to settle.
Visually inspect vehicle for signs of abnormal height from front to rear or side to side. Remove extra heavy items from passenger and luggage compartments. If riding height is not within specifications, check, repair or replace suspension components. See appropriate RIDING HEIGHT SPECIFICATIONS table. (Scheme 3)
Note. For vehicles not listed, riding height between left and right side of vehicle should vary less than 1" (25.4 mm).
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Century |
| Coupe & Sedan |
| P185-75R14 | 9.45 (240) | 9.72 (247) |
| P195-75R14 | 9.65 (245) | 9.97 (253) |
| Wagon |
| P185-75R14 | 9.25 (235) | 9.45 (240) |
| P195-75R14 | 9.49 (241) | 9.69 (246) |
| Cutlass Ciera |
| P185-75R14 | 9.25 (235) | 9.49 (241) |
| P195-70R14 | 9.13 (232) | 9.41 (239) |
| P195-75R14 (3) | 9.47 (241) | 9.72 (247) |
| P195-75R14 (4) | 9.49 (241) | 9.72 (247) |
| Cutlass Cruiser |
| P185-75R14 | 9.25 (235) | 9.45 (240) |
| P195-70R14 | 9.13 (232) | 9.33 (237) |
| P195-75R14 | 9.49 (241) | 9.33 (237) |
| (1) Location "A" measured 19.9" (505 mm) from center of front axle. (2) Location "B" measured 18.1" (459 mm) from center of rear axle. (3) Soft-Ride suspension (FE1). (4) Sport suspension (FE3). |
| (1) | Location "A" measured 19.9" (505 mm) from center of front axle. |
| (2) | Location "B" measured 18.1" (459 mm) from center of rear axle. |
| (3) | Soft-Ride suspension (FE1). |
| (4) | Sport suspension (FE3). |
RIDING HEIGHT SPECIFICATIONS ("A" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Caprice Roadmaster | 9.9 (252) | 10.4 (264) |
| (1) Location "A" measured 31.9" (810 mm) from center of front axle. (2) Location "B" measured 24.2" (615 mm) from center of rear axle. |
| (1) | Location "A" measured 31.9" (810 mm) from center of front axle. |
| (2) | Location "B" measured 24.2" (615 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("B" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| DeVille, Fleetwood,Ninety-Eight & Park Avenue | 9.0-9.8 (228-248) | 9.05-9.85 (230-250) |
| (1) Location "A" measured 23.5" (600 mm) from center of front axle. (2) Location "B" measured 23.5" (600 mm) from center of rear axle. |
| (1) | Location "A" measured 23.5" (600 mm) from center of front axle. |
| (2) | Location "B" measured 23.5" (600 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("C" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Fleetwood | 9.93 (252) | 10.40 (264) |
| (1) Location "A" measured 31.9" (810 mm) from center of front axle. (2) Location "B" measured 24.2" (615 mm) from center of rear axle. |
| (1) | Location "A" measured 31.9" (810 mm) from center of front axle. |
| (2) | Location "B" measured 24.2" (615 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("D" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Eldorado | 8.78 (223) | 8.70 (221) |
| Riviera | 8.62 (219) | 8.74 (222) |
| (1) Location "A" measured 22.8" (580 mm) from center of front axle. (2) Location "B" measured 22.2" (563 mm) from center of rear axle. |
| (1) | Location "A" measured 22.8" (580 mm) from center of front axle. |
| (2) | Location "B" measured 22.2" (563 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("E" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Camaro & Firebird | 8.03 (204) | 8.2 (208) |
| (1) Location "A" measured 32.6" (828 mm) from center of front axle. (2) Location "B" measured 17.2" (438 mm) from center of rear axle. |
| (1) | Location "A" measured 32.6" (828 mm) from center of front axle. |
| (2) | Location "B" measured 17.2" (438 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("F" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Bonneville, Eighty-Eight & LeSabre | 9.0-9.8 (229-249) | 9.30-10.06 (236-256) |
| (1) Location "A" measured 23.5" (600 mm) from center of front axle. (2) Location "B" measured 23.5" (600 mm) from center of rear axle. |
| (1) | Location "A" measured 23.5" (600 mm) from center of front axle. |
| (2) | Location "B" measured 23.5" (600 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("H" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Cavalier Wagon | 9.53 (242) | 9.65 (245) |
| All Others | 9.26 (235) | 9.13 (232) |
| (1) Location "A" measured 21.9" (557 mm) from center of front axle. (2) Location "B" measured 21.7" (554 mm) from center of rear axle. |
| (1) | Location "A" measured 21.9" (557 mm) from center of front axle. |
| (2) | Location "B" measured 21.7" (554 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("J" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Seville | 9.49 (241) | 9.49 (241) |
| (1) Location "A" measured 22.8" (580 mm) from center of front axle. (2) Location "B" measured 22.2" (563 mm) from center of rear axle. |
| (1) | Location "A" measured 22.8" (580 mm) from center of front axle. |
| (2) | Location "B" measured 22.2" (563 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("K" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Beretta & Corsica |
| 4-Dr. Sedan | 9.53 (242) | 9.88 (251) |
| All Others |
| P185-75R14 | 9.40 (239) | 9.76 (248) |
| P195-70R14 | 9.40 (239) | 9.76 (248) |
| P205-55VR16 | 9.00 (229) | 9.37 (238) |
| P205-60R15 | 9.53 (242) | 9.88 (251) |
| P205-70R14 | 9.40 (239) | 9.76 (248) |
| (1) Location "A" measured 31.5" (800 mm) from center of front axle. (2) Location "B" measured 21.4" (560 mm) from center of rear axle. |
| (1) | Location "A" measured 31.5" (800 mm) from center of front axle. |
| (2) | Location "B" measured 21.4" (560 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("L" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Achieva, Grand Am & Skylark | 9.30 (237) | 9.40 (240) |
| (1) Location "A" measured 31.5" (800 mm) from center of front axle. (2) Location "B" measured 21.4" (560 mm) from center of rear axle. |
| (1) | Location "A" measured 31.5" (800 mm) from center of front axle. |
| (2) | Location "B" measured 21.4" (560 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("N" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Cutlass Supreme, Grand Prix, Lumina & Regal | 9.80 (249) | 9.80 (249) |
| (1) Location "A" measured 23.8" (605 mm) from center of front axle. (2) Location "B" measured 20.7" (525 mm) from center of rear axle. |
| (1) | Location "A" measured 23.8" (605 mm) from center of front axle. |
| (2) | Location "B" measured 20.7" (525 mm) from center of rear axle. |
RIDING HEIGHT SPECIFICATIONS ("W" BODY)
| Application | (1) Front "A": In. (mm) | (2) Rear "B": In. (mm) |
|---|
| Corvette |
| Convertible | 7.88 (200.3) | 7.85 (199.6) |
| Coupe (3) | 7.60 (193.2) | 7.59 (192.8) |
| Coupe (4) | 7.51 (190.9) | 7.52 (191.2) |
| ZR1 | 7.60 (193.1) | 7.85 (199.6) |
| (1) Location "A" measured 25.6" (652 mm) from center of front axle. (2) Location "B" measured 19.1" (486 mm) from center of rear axle. (3) Soft Ride suspension (FE1). (4) Heavy-duty suspension (FE7). |
| (1) | Location "A" measured 25.6" (652 mm) from center of front axle. |
| (2) | Location "B" measured 19.1" (486 mm) from center of rear axle. |
| (3) | Soft Ride suspension (FE1). |
| (4) | Heavy-duty suspension (FE7). |
RIDING HEIGHT SPECIFICATIONS ("Y" BODY)
Riding Height Measuring Points. Scheme 3
