DESCRIPTION
One mirror control switch adjusts both left (driver side) and right (passenger side) mirrors. Mirror select switch setting determines whether left or right mirror is adjusted.
OPERATION
Each power mirror assembly contains 2 reversible motors: an up/down motor and a left/right motor. Mirror control switch reverses polarity of motor circuit to change direction of mirror movement. Each motor contains a self-resetting circuit breaker, which opens when mirror reaches its mechanical limit of travel.
TESTING
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION Section before disconnecting battery. |
Before performing following tests, ensure circuit ground, circuit harness wiring and circuit fuse are okay. Also, ensure all circuit connections are clean and tight.
LEFT MIRROR UP/DOWN POSITIONS DO NOT OPERATE (LEFT/RIGHT POSITIONS OPERATE NORMALLY)
- Place mirror select switch in left position. Toggle mirror position switch between up and down positions. With mirror control switch connector still connected, using test light, backprobe between terminal "C" (Light Green wire) and terminal "D" (Yellow wire) of mirror control switch connector.
- If test light does not light, check for poor connections at Light Green wire terminal and Yellow wire terminal of mirror control switch connector. If connections are okay, replace mirror control switch.
- If test light comes on, toggle mirror position switch between up and down positions. With left outside mirror drive unit connector still connected, using test light, backprobe between terminal "C" (Light Green wire) and terminal "D" (Yellow wire) of left outside mirror drive unit connector.
- If test light does not light, check for open in Light Green wire or Yellow wire between mirror control switch and left outside mirror drive unit. Repair or replace as necessary.
- If test light comes on, check for poor connections at Light Green wire terminal and Yellow wire terminal of left outside mirror drive unit connector. If connections are okay, replace left outside mirror drive unit.
LEFT MIRROR LEFT/RIGHT POSITIONS DO NOT OPERATE (UP/DOWN POSITIONS OPERATE NORMALLY)
- Place mirror select switch in left position. Toggle mirror position switch between left and right positions. With mirror control switch connector still connected, using test light, backprobe between terminal "B" (White wire) and terminal "C" (Light Green wire) of mirror control switch connector.
- If test light does not light, check for poor connections at White wire terminal and Light Green wire terminal of mirror control switch connector. If connections are okay, replace mirror control switch.
- If test light comes on, toggle mirror position switch between left and right positions. With left outside mirror drive unit connector still connected, using test light, backprobe between terminal "B" (White wire) and terminal "A" (Light Blue wire) of left outside mirror drive unit connector.
- If test light does not light, check for open in White wire or Light Blue wire between mirror control switch and left outside mirror drive unit. Repair or replace as necessary.
- If test light comes on, check for poor connections at White wire terminal and Light Blue wire terminal of left outside mirror drive unit connector. If connections are okay, replace left outside mirror drive unit.
LEFT MIRROR DOES NOT OPERATE IN EITHER UP/DOWN OR LEFT/RIGHT POSITIONS
- Place mirror select switch in left position. Toggle mirror position switch between up and down positions. With outside mirror control switch connector still connected, using test light, backprobe between terminal "C" (Light Green wire) and terminal "D" (Yellow wire) of mirror control switch connector.
- If test light does not light, check for poor connections at Light Green wire terminal and Yellow wire terminal of mirror control switch connector. If connections are okay, replace mirror control switch.
- If test light comes on, toggle mirror position switch between up and down positions. With left outside mirror drive unit connector still connected, using test light, backprobe between terminal "C" (Light Green wire) and terminal "D" (Yellow wire) of left outside mirror drive unit connector.
- If test light does not light, check for open in Light Green wire between mirror control switch and left outside mirror drive unit. Repair or replace as necessary.
- If test light comes on, check for poor connections at Light Green wire terminal and Yellow wire terminal of left outside mirror drive unit connector. If connections are okay, replace left outside mirror drive unit.
RIGHT MIRROR UP/DOWN POSITIONS DO NOT OPERATE (LEFT/RIGHT POSITIONS OPERATE NORMALLY)
- Place mirror select switch in right position. Toggle mirror position switch between up and down positions. With mirror control switch connector still connected, using test light, backprobe between terminal "E" (Yellow wire) and terminal "F" (Light Blue wire) of mirror control switch connector.
- If test light does not light, check for poor connections at Yellow wire terminal and Light Blue wire terminal of mirror control switch connector. If connections are okay, replace mirror control switch.
- If test light comes on, toggle mirror position switch between up and down positions. With right outside mirror drive unit connector still connected, using test light, backprobe between terminal "D" (Yellow wire) and terminal "C" (Light Green wire) of right outside mirror drive unit connector.
- If test light does not light, check for open in Yellow wire or Light Green wire between mirror control switch and right outside mirror drive unit. Repair or replace as necessary.
- If test light comes on, check for poor connections at Yellow wire terminal and Light Green wire terminal of right outside mirror drive unit connector. If connections are okay, replace right outside mirror drive unit.
RIGHT MIRROR LEFT/RIGHT POSITIONS DO NOT OPERATE (UP/DOWN POSITIONS OPERATE NORMALLY)
- Place mirror select switch in right position. Toggle mirror position switch between left and right positions. With mirror control switch connector still connected, using test light, backprobe between terminal "F" (Light Blue wire) and terminal "G" (White wire) of mirror control switch connector.
- If test light does not light, check for poor connections at Light Blue wire terminal and White wire terminal of mirror control switch connector. If connections are okay, replace mirror control switch.
- If test light comes on, toggle mirror position switch between left and right positions. With right outside mirror drive unit connector still connected, using test light, backprobe between terminal "A" (Light Blue wire) and terminal "B" (White wire) of right outside mirror drive unit connector.
- If test light does not light, check for open in Light Blue wire or White wire between mirror control switch and right outside mirror drive unit. Repair or replace as necessary.
- If test light comes on, check for poor connections at Light Blue wire terminal and White wire terminal of right outside mirror drive unit connector. If connections are okay, replace right outside mirror drive unit.
RIGHT MIRROR DOES NOT OPERATE IN EITHER UP/DOWN OR LEFT/RIGHT POSITIONS
- Place mirror select switch in right position. Toggle mirror position switch between up and down positions. With mirror control switch connector still connected, using test light, backprobe between terminal "E" (Yellow wire) and terminal "F" (Light Blue wire) of mirror control switch connector.
- If test light does not light, check for poor connections at Yellow wire terminal and Light Blue wire terminal of mirror control switch connector. If connections are okay, replace mirror control switch.
- If test light comes on, toggle mirror position switch between up and down positions. With right outside mirror drive unit connector still connected, using test light, backprobe between terminal "C" (Light Green wire) and terminal "D" (Yellow wire) of right outside mirror drive unit connector.
- If test light does not light, check for open in Light Blue wire between mirror control switch and right outside mirror drive unit. Repair or replace as necessary.
- If test light comes on, check for poor connections at Light Green wire terminal and Yellow wire terminal of right outside mirror drive unit connector. If connections are okay, replace right outside mirror drive unit.
BOTH MIRRORS DO NOT OPERATE
- Disconnect mirror control switch connector. Connect test light between Orange wire terminal of mirror control switch connector and ground.
- If test light does not light, check Orange wire. Repair or replace as necessary. If test light comes on, connect test light between Orange wire terminal and Black wire terminal of mirror control switch connector.
- If test light does not light, check Black wire. Repair or replace as necessary. If test light comes on, replace mirror control switch.
REMOVAL & INSTALLATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION Section before disconnecting battery. |
| CAUTION | On some models, momentary actuation of power window switch can cause window to move directly to fully open position. When working inside door, leave ignition off whenever possible. |
Insert flat tool between switch plate and trim panel, and disengage spring clip. If switch plate is attached to trim panel with screws, remove screws. Disconnect outside mirror control switch electrical connector. To install, reverse removal procedure.
Removal
Disconnect negative battery cable. Pull mirror and backing plate assembly out of mirror housing. (Scheme 1) Remove jack screws from mirror backing plate. If equipped with left outside mirror defogger, cut wires at splice location.
Installation
If equipped with left outside mirror defogger, splice wires together at splice location. Snap jack screws into NEW mirror backing plate. Align jack screws to drive unit, and align drive unit swivel to pivot points on mirror backing plate. Push mirror and backing plate assembly into housing until assembly clicks into place.
Scheme 1
Cover door to avoid damage to painted surface. Tape mirror, then break mirror glass. Remove broken glass from mirror frame. Wipe inside of mirror frame clean.
Remove paper backing from replacement mirror glass. Center mirror glass in mirror frame, and firmly press into place.
Remove outside mirror face. See OUTSIDE MIRROR FACE. (Scheme 1) Remove screws attaching outside mirror drive unit to mirror housing. Disconnect electrical connector. To install, reverse removal procedure.
Remove door trim panel. Remove water deflector (if necessary). Remove speaker (if necessary). Remove support brackets (if equipped). Disconnect electrical connector. Remove outside mirror assembly attaching nuts. Remove outside mirror assembly. To install, reverse removal procedure.
Power Mirror Wiring Diagram. Scheme 2
Automatic Mirror Wiring Diagram. Scheme 3
