| Assembly Line Diagnostic Link Connector | Attached To Instrument Panel Carrier, Right Of Steering Column. (Scheme 1) |
| Diagnostic Energy Reserve Module | Driver Side Of Instrument Panel, Above Convenience Center. (Scheme 2) |
| Electronic A/C Control Assembly (C68) | Center Of Instrument Panel. (Scheme 3) |
| Electronic Brake Control Module | Driver Side Of Engine Compartment, On Inner Fender Panel. (Scheme 2) |
| Engine Control Module | Attached To Base Of Passenger Side "A" Pillar. (Scheme 4) |
| Power Steering Control Module | Left Of Steering Column, Above Fuse Block |
| Power Steering Solenoid Actuator | Attached To Power Steering Actuator |
| C200 (56 Terminals) | Body Harness To Instrument Panel Harness, Bolted Above Accelerator Pedal. (Scheme 1) |
| C204 (37 Terminals) | Body Harness To Engine Harness, Behind Passenger Side Of Instrument Panel Between Blower Motor & Instrument Panel Compartment. (Scheme 4) |
| G104 | Passenger Rear Cylinder Head, Below Exhaust Manifold. (Scheme 5) |
| P100 | Passenger Side Of Instrument Panel, Forward Of Blower Motor. (Scheme 6) |
| P101 | Passenger Side Of Instrument Panel, Right Of ECM. (Scheme 7) |
| S109 | Engine Harness, Near A/C Pressure Cycling Switch Connector Breakout |
| S240 | Body Harness, Near Turn/Hazard Switch Connector Breakout |
| S250 | Engine Harness, In C204 Branch Near Connector |
| S252 | Body Harness, In ALDL Branch Near Connector |
| S265 | Body Harness, Near P102 In Passenger Compartment |
| S266 | Body Harness, Near Turn/Hazard Switch Connector Breakout |
