BELT ADJUSTMENT
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
| Application | (1) Tension - Lbs. (kg) |
|---|
| Serpentine Belt (2) |
| 2.0L (VIN H) | 225 (102) |
| 2.2L (VIN 4) |
| "A" Body | 50-70 (23-32) |
| All Others | 64-77 (29-35) |
| 2.3L (VIN A, D & 3) | 51 (23) |
| 3.1L (VIN T) | 51-71 (23-32) |
| 3.3L (VIN N) | 66 (30) |
| 3.4L (VIN S & X) | (3) |
| 3.8L (VIN L & 1) | (3) |
| 4.3L (VIN Z) | (3) |
| 5.0L (VIN E) | (3) |
| 5.7L (VIN P & 7) | (3) |
| "V" Belt |
| 2.3L (VIN A) |
| Power Steering | 110 (50) |
| (1) Specifications are for new belts only. (2) Serpentine belts have automatic tensioner. If tension is not as specified, check belt length and tensioner range. Replace as necessary. (3) Information is not available from manufacturer. |
| (1) | Specifications are for new belts only. |
| (2) | Serpentine belts have automatic tensioner. If tension is not as specified, check belt length and tensioner range. Replace as necessary. |
| (3) | Information is not available from manufacturer. |
Scheme 1
Scheme 2
Scheme 3
Scheme 3: Serpentine Belt Routing (2.0L)
Scheme 4
Scheme 4: Serpentine Belt Routing (2.2L & 2.5L)
Scheme 5
Scheme 6
Scheme 6: Serpentine Belt Routing (2.3L)
Scheme 7
Scheme 7: Serpentine Belt Routing (3.1L)
Scheme 8
Scheme 8: Serpentine Belt Routing (3.3L & 3.8L)
Scheme 9
Scheme 9: Serpentine Belt Routing (3.4L Camaro & Firebird)
Scheme 10
Scheme 10: Serpentine Belt Routing (3.4L Exc. Camaro/Firebird)
Scheme 11
Scheme 11: Serpentine Belt Routing (4.3L, 5.0L & 5.7L Except Corvette)
Scheme 12
Scheme 12: Serpentine Belt Routing (5.7L Corvette)
