Interior lights — Instrument illumination circuit Buick Riviera VIII

Components on these wiring diagrams 27

Click a component to highlight it on every diagram it appears on.

• Ashtray Lamp
• Courtesy Lamps Switch
• Courtesy Lights Circuit
• Dim Enable Input
• Dimmer Module
• Engine Compartment Lamp
• Headlamp Switch
• Heater And A/C Control Assembly Trip Odometer Reset Switch
• I/P Fuse Block
• Illumination Lamp
• Instrument — Cluster
• Int Lp
• Lamp Control Module
• Left Door Switch Flood Lamp Left Door Handle Flood Lamp
• Panel Dimming Control
• Parade Dimming Control
• Park Lamp Switch
• Park Lamp Switch Input
• Park Lamps Control
• Passenger Climate Control Assembly
• Passenger Climate Control Assembly Hvac Programmer
• Right Door Switch Flood Lamp Right Door Handle Flood Lamp
• Right Rear Power Distribution Center
• Sir Coil Assembly
• Steering Wheel Control
• Vf Dim Input LED Dim Input
• Vf Dim Output
