Seat System Buick Rendezvous I

Seats 6 illustrations ~12582 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Armrest Mounting Bolt21 N.m15 lb ft
Footrest Bolt43 N.m32 lb ft
Front Seat Adjuster Bolt43 N.m32 lb ft
Front Seat Cushion Trim Panel Center Screw2 N.m18 lb in
Front Seat Cushion Trim Panel Front Screw2 N.m18 lb in
Front Seat Cushion Trim Panel Rear Screw2 N.m18 lb in
Front Seat Track Cover Screw2 N.m18 lb in
Left Front Seat Back Recliner Hinge Bolt40 N.m30 lb ft
Lumbar Control Screw10 N.m89 lb in
Rear Adjuster Bolt10 N.m89 lb in
Rear Seat Cushion Trim Cover Screw2 N.m18 lb in
Rear Seat Cushion Trim Panel Screw2 N.m18 lb in
Recliner Seat Back Bolt30 N.m22 lb ft
Right Front Seat Back Recliner Hinge Bolt40 N.m30 lb ft
Seat Anchor Nuts50 N.m37 lb ft
Seat Back Recliner Screw2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Driver Seat Schematics
Scheme 1: Driver Seat Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Passenger Seat Schematics
Scheme 3: Passenger Seat Schematics

Scheme 4

Scheme 4: Power Seat Systems Component Views
Scheme 4: Power Seat Systems Component Views
CalloutComponent Name
1Seat Belt Switch
2Heated Seat Element - Cushion Cover Connector (KA1)
3Heated Seat Back Element Connector (KA1)
4Manual Lumbar Adjuster
5Seat Adjuster Switch (AG1/AG2)
6Manual Seat Recliner Lever
7Seat Postion Sensor Front Vertical - Driver (A43)
8Seat Postion Sensor Horizontal - Driver (A43)
9Seat Postion Sensor Rear Vertical - Driver (A43)
10Memory Seat and Mirror Module (A43)

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Seat Adjuster Switch-Front Passenger

I/P Switch Assembly C2 Connector End Connector Part Information 12047976 8-Way F Metri-Pack 280 Series (BLU) Pin Wire Color Circuit No. Function A GRY 8 Instrument Panel Lamp Supply Voltage - 1 B BLK 150 Ground C LT GRN 911 Rear Defog Relay Coil Supply Voltage D LT BLU 1462 Driver Heated Seat Switch Signal E LT BLU/BLK 1505 Front Passenger Heated Seat Switch Signal F-H - - Not Used

Memory Seat and Mirror Module C1 (A43) Connector End Connector Part Information 12020557 3-Way F Metri-Pack 480 Series (BLK) Pin Wire Color Circuit No. Function A - - Not Used B BLK 550 Ground C ORN 1140 Battery Positive Voltage

Memory Seat and Mirror Module C2 (A43) Connector End Connector Part Information 12064998 8-Way F Metri-Pack 280 Series (BLK) Pin Wire Color Circuit No. Function A GRY 286 Driver Seat Front Vertical Motor Up Control B WHT 287 Driver Seat Front Vertical Motor Down Control C LT BLU 283 Driver Seat Rear Vertical Motor Down Control D YEL 282 Driver Seat Rear Vertical Motor Up Control E LT GRN 284 Driver Seat Horizontal Motor Rearward Control F TAN 285 Driver Seat Horizontal Motor Forward Control G-H - - Not Used

Memory Seat and Mirror Module C3 (A43) Connector End Connector Part Information 12110206 24-Way F Micro-Pack 100 Series (LT BLU) Pin Wire Color Circuit No. Function A1 - - Not Used A2 DK BLU 672 5-Volt Reference A3 GRY 786 Driver Mirror Horizontal Position Sensor Signal A4 DK GRN 784 Driver Mirror Vertical Position Sensor Signal A5 LT BLU/BLK 785 Passenger Mirror Horizontal Position Sensor Signal A6 BRN 787 Passenger Mirror Vertical Position Sensor Signal A7 ORN 917 5-Volt Reference A8 BLK 918 Low Reference A9 - - Not Used A10 LT GRN 921 Driver Seat Horizontal Position Sensor Signal A11 TAN 920 Driver Seat Rear Vertical Position Sensor Signal A12 BRN/WHT 919 Driver Seat Front Vertical Position Sensor Signal B1 - - Not Used B2 BRN 673 Low Reference B3 - - Not Used B4 RED/WHT 881 Passenger Mirror Motor Right Control B5 GRY 90 Passenger Mirror Motor Left Control B6 PPL/WHT 889 Passenger Mirror Motor Down Control B7-B9 - - Not Used B10 WHT 81 Driver Mirror Motor Right Control B11 LT BLU 82 Driver Mirror Motor Left Control B12 LT GRN 89 Driver Mirror Motor Down Control

Memory Seat and Mirror Module C4 (A43) Connector End Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function A1 - - Not Used A2 PPL 616 Memory 2 Switch Signal A3 WHT 615 Memory 1 Switch Signal A4-A5 - - Not Used A6 LT GRN 911 Driver Seat Horizontal Rearward Switch Signal A7 TAN 912 Driver Seat Horizontal Forward Switch Signal A8 LT BLU 910 Driver Seat Rear Vertical Down Switch Signal A9 YEL 909 Driver Seat Rear Vertical Up Switch Signal A10 WHT 950 Driver Seat Front Vertical Down Switch Signal A11 GRY 913 Driver Seat Front Vertical Up Switch Signal A12 - - Not Used B1 BRN/WHT 1048 Class 2 Serial Data B2-B3 - - Not Used B4 TAN/WHT 915 Mirror Switch Supply Voltage B5 ORN 908 Driver Seat Switch Supply Voltage B6 - - Not Used B7 RED/WHT 1513 Passenger Mirror Switch Right Signal B8 WHT 1512 Driver Mirror Switch Right Signal B9 PPL/WHT 1515 Passenger Mirror Switch Down Signal B10 LT GRN 1514 Driver Mirror Switch Down Signal B11 YEL 1496 Mirror Motor Left/Up Control B12 - - Not Used

Memory Seat and Mirror Switch (A43) Connector End Connector Part Information 12047785 4-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A WHT 615 Memory 1 Switch Signal B PPL 616 Memory 2 Switch Signal C BLK 550 Ground D GRY 8 Instrument Panel Lamp Supply Voltage

Seat Adjuster Motor Assembly Connector End - Driver Connector Part Information 12064752 6-Way F Metri-Pack 280 Series (BLK) Pin Wire Color Circuit No. Function A TAN 285 Driver Seat Horizontal Motor Forward Control B LT GRN 284 Driver Seat Horizontal Motor Rearward Control C GRY 286 Driver Seat Front Vertical Motor Up Control D WHT 287 Driver Seat Front Vertical Motor Down Control E YEL 282 Driver Seat Rear Vertical Motor Up Control F LT BLU 283 Driver Seat Rear Vertical Motor Down Control

Seat Adjuster Motor Assembly Connector End - Front Passenger Connector Part Information 12064752 6-Way F Metri-Pack 280 Series (BLK) Pin Wire Color Circuit No. Function A TAN 285 Driver Seat Horizontal Motor Forward Control B LT GRN 284 Driver Seat Horizontal Motor Rearward Control C DK GRN 286 Driver Seat Front Vertical Motor Up Control D DK BLU 287 Driver Seat Front Vertical Motor Down Control E YEL 282 Driver Seat Rear Vertical Motor Up Control F LT BLU 283 Driver Seat Rear Vertical Motor Down Control

Seat Adjuster Switch Connector End - Driver (w/o A43) Connector Part Information 15326928 8-Way M 280 GT (BLK) Pin Wire Color Circuit No. Function A ORN 1140 Battery Positive Voltage B YEL 282 Driver Seat Rear Vertical Up Switch Signal C LT BLU 283 Driver Seat Rear Vertical Down Switch Signal D LT GRN 284 Driver Seat Horizontal Rearward Switch Signal E TAN 285 Driver Seat Horizontal Forward Switch Signal F DK GRN 286 Driver Seat Front Vertical Up Switch Signal G DK BLU 287 Driver Seat Front Vertical Down Switch Signal H BLK 550 Ground

Seat Adjuster Switch Connector End - Driver (A43) Connector Part Information 15326928 8-Way M 280 GT (BLK) Pin Wire Color Circuit No. Function A ORN 908 Battery Positive Voltage B YEL 909 Driver Seat Rear Vertical Up Switch Signal C LT BLU 910 Driver Seat Rear Vertical Down Switch Signal D LT GRN 911 Driver Seat Horizontal Rearward Switch Signal E TAN 912 Driver Seat Horizontal Forward Switch Signal F GRY 913 Driver Seat Front Vertical Up Switch Signal G WHT 950 Driver Seat Front Vertical Down Switch Signal H - - Not Used

Seat Front Vertical Motor Position Sensor Connector End - Driver Connector Part Information 104257-2 3-Way F Amp (BLK) Pin Wire Color Circuit No. Function A BLK - 5 Volt Reference B GRN/WHT - Front Vertical Seat Motor Position Sensor Signal C ORN - Low Reference

Seat Horizontal Motor Position Sensor Connector End - Driver Connector Part Information 104257-2 3-Way F Amp (BLK) Pin Wire Color Circuit No. Function A BLK - 5 Volt Reference B LT GRN - Horizontal Seat Motor Position Sensor Signal C ORN - Low Reference

Seat Rear Vertical Motor Position Sensor Connector End - Driver Connector Part Information 104257-2 3-Way F Amp (BLK) Pin Wire Color Circuit No. Function A BLK - 5 Volt Reference B TAN - Front Vertical Seat Motor Position Sensor Signal C ORN - Low Reference

Seat Adjuster Switch Connector End - Front Passenger Connector Part Information 15326928 8-Way M 280 GT (BLK) Pin Wire Color Circuit No. Function A ORN 1140 Battery Positive Voltage B YEL 282 Driver Seat Rear Vertical Motor Down C LT BLU 283 Driver Seat Rear Vertical Motor Up D LT GRN 284 Driver Seat Horizontal Motor Rearward E TAN 285 Driver Seat Horizontal Motor Forward F DK GRN 286 Driver Seat Front Vertical Motor Up G DK BLU 287 Driver Seat Front Vertical Motor Down H BLK 550 Ground

Diagnostic Starting Point - Seats

Begin all memory seat system diagnosis with the Diagnostic System Check - Power Seat Systems . The Diagnostic System Check will provide the following information

  1. The identification of the control module(s) which command the system.
  2. The ability of the control module(s) to communicate through the serial data circuit.
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status.

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Begin power seat system and heated seat system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Seats in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Test Description

The numbers below refer to the step numbers on the diagnostic table.

  1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
  2. 4: Determine if any DTCs are present which may be the cause of the condition.
  3. 5: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
  4. 6: Determine if an internal memory malfunction exists.
  5. 7: Determine if the ignition voltage monitored by the powertrain control module is within acceptable limits.
StepActionYesNo
1Install a scan tool. Does the scan tool power up?Go to Step 2Go to Scan Tool Does Not Power Up in Data Link Communications
2Turn ON the ignition, with the engine OFF. Attempt to establish communication with the following systems: Powertrain control module Memory seat module Does the scan tool communicate with these systems?Go to Step 4Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications
3IMPORTANT: The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode. Access the Class 2 Power Mode in the Diagnostic Circuit Check on the scan tool. Rotate the ignition switch through all positions while observing the ignition switch power mode parameter. Does the ignition switch parameter reading match the ignition switch position for all switch positions?Go to Step 4Go to Power Mode Mismatch in Body Control System
4Select the display DTCs function. Does the scan tool display any DTCs?Go to Step 5Go to Symptoms - Seats
5Does the scan tool display any DTCs which begin with a "U"?Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link CommunicationsGo to Step 6
6Does the scan tool display DTC B1000?Go to Diagnostic Trouble Code (DTC) List in Body Control SystemGo to Step 7
7Does the scan tool display DTC P0560?Go to Diagnostic Trouble Code (DTC) List in Engine ElectricalGo to Diagnostic Trouble Code (DTC) List
IMPORTANT
The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode.

Diagnostic System Check - Power Seat Systems

Scan Tool Output Controls

Scan Tool Output ControlAdditional Menu Selection(s)Description
Front Up/DownOutput ControlOperates the front of the driver seat up or down.
Seat Forward/RearwardOutput ControlOperates the driver seat forward or backward.
Rear Up/DownOutput ControlOperates the rear of the driver seat up or down.

Scan Tool Output Controls

Scan Tool Data List

Scan Tool ParameterData ListUnits DisplayedTypical Data Value
Battery VoltageInput/OutputVoltsVaries
Driver IdentificationInput/OutputDriver 1/Driver 2Varies
Exit Front Vertical ValueMemory Data0.0-5.0 VoltsVaries
Exit Horizontal ValueMemory Data0.0-5.0 VoltsVaries
Exit Rear Vertical ValueMemory Data0.0-5.0 VoltsVaries
Front Vertical MotorInput/OutputInactive/Up/DownInactive
Front Vertical Position SwitchInput/OutputInactive/Up/DownVaries
Front Vertical PositionSensor Data0.0-5.0 VoltsVaries
Horizontal MotorInput/OutputInactive/Forward/BackInactive
Horizontal Position SwitchInput/OutputInactive/Forward/BackInactive
Memory SwitchInput/OutputMemory 1/Memory 2/Easy Exit/InactiveInactive
Mem 1 Front Vertical ValueMemory Data0.0-5.0 VoltsVaries
Mem 2 Front Vertical ValueMemory Data0.0-5.0 VoltsVaries
Mem 1 Horizontal ValueMemory Data0.0-5.0 VoltsVaries
Mem 2 Horizontal ValueMemory Data0.0-5.0 VoltsVaries
Mem 1 Rear Vertical ValueMemory Data0.0-5.0 VoltsVaries
Mem 2 Rear Vertical ValueMemory Data0.0-5.0 VoltsVaries
PRNDL StateInput/OutputPark/Neutral/ Reverse/Over Drive/Drive/Second/FirstPark
Rear Vertical MotorInput/OutputInactive/Up/DownInactive
Rear Vertical Position SwitchInput/OutputInactive/Up/DownVaries
Rear Vertical PositionSensor Data0.0-5.0 VoltsVaries
Seat Horizontal PositionSensor Data0.0-5.0 VoltsVaries
System Power ModeInput/OutputRun/Accessory/RAP/Off AwakeOn
8 Digit GM Part NumberModule InformationAlpha/NumericVaries

Scan Tool Data List

Diagnostic Trouble Code (DTC) List

DTCDiagnostic ProcedureModule(s)
B1735DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820Memory Seat Module
B1740DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820Memory Seat Module
B1745DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820Memory Seat Module
B1750DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820Memory Seat Module
B1755DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820Memory Seat Module
B1760DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820Memory Seat Module
B1770DTC B1770, B1775, B1780, B1785, B1790, B1805, or B2415Memory Seat Module
B1775DTC B1770, B1775, B1780, B1785, B1790, B1805, or B2415Memory Seat Module
B1780DTC B1770, B1775, B1780, B1785, B1790, B1805, or B2415Memory Seat Module
B2355DTC B1825, B1850, B2355, B2365, or B2375Memory Seat Module
B2365DTC B1825, B1850, B2355, B2365, or B2375Memory Seat Module
B2375DTC B1825, B1850, B2355, B2365, or B2375Memory Seat Module
B2755DTC B2755 or B2760Memory Seat Module
B2760DTC B2755 or B2760Memory Seat Module

Diagnostic Trouble Code (DTC) List

Circuit Description

The seat adjuster switch is supplied a 12-volt reference circuit by the memory seat module. When a seat adjuster switch is pressed the signal circuit is closed to the 12-volt reference circuit. Closing the signal circuit to the 12-volt reference circuit pulls the signal circuit high indicating to the memory seat module the switch status is active.

Conditions for Running the DTC

The system voltage must be between 9-16 volts.

Conditions for Setting the DTC

A seat adjuster switch input to the memory seat module is active for more than 30 seconds.

Action Taken When the DTC Sets

  1. The memory seat module will ignore the switch input for which a current status DTC is set.
  2. When the fault is no longer present a history status DTC will be stored, and switch operation will be restored.

Conditions for Clearing the DTC

  1. The DTC will be current for as long as the fault is present.
  2. When the fault is no longer present the DTC will be a history status code.
  3. The history DTC will be cleared after 100 error free ignition cycles, or by using the scan tool clearing DTCs feature.

The numbers below refer to the step numbers on the diagnostic table.

  1. 3: This step tests the seat adjuster switch for an internal fault.
  2. 4: When the seat adjuster switch is disconnected the faulty switch signal circuit will be isolated.
StepActionYesNo
Schematic Reference: Driver Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views
1Did you perform the Power Seat Systems Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Power Seat Systems
2Install a scan tool. Verify that the DTC is current. Is the DTC current?Go to Step 3Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems
3Disconnect the seat adjuster switch connector. With a scan tool, observe the current DTCs. Is the DTC current?Go to Step 4Go to Step 5
4Test the switch signal circuit indicated in the previous step for a short to voltage. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 6
5Inspect and repair any damage to the seat adjuster switch connector and terminals which may cause the condition. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 7
6Inspect and repair any damage to the memory seat module connector and terminals which may cause the condition. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 8
7Replace the seat adjuster switch. Refer to Seat Switch Replacement - Power . Did you complete the replacement?Go to Step 9
8Replace the memory seat module. Refer to Memory Seat Control Module Replacement . Did you complete the replacement?Go to Step 9
9Use the scan tool in order to clear the DTCs. Operate the system within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset?Go to Step 2System OK

DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820

The seat adjuster motors are controlled by the memory seat module through the adjuster motor control circuits. The memory seat module also monitors current flow through the adjuster motor control circuits. In an inactive state the control circuits are closed to ground within the memory seat module. In an active state the appropriate adjuster motor control circuit is switched to battery voltage within the memory seat module. The direction of the adjuster motor rotation is determined by which of the control circuits is switched to battery voltage while the other remains grounded.

The system voltage must be between 9-16 volts.

The adjuster motor control circuit current monitored by the memory seat module is high, low, or open.

  1. The memory seat module will disable the seat adjuster motor for which a current status DTC is set.
  2. When the fault is no longer present a history status DTC will be stored, and adjuster motor operation will be restored.
  1. The DTC will be current for as long as the fault is present.
  2. When the fault is no longer present the DTC will be a history status code.
  3. The history DTC will be cleared after 100 error free ignition cycles, or by using the scan tool clearing DTCs feature.

The numbers below refer to the step numbers on the diagnostic table.

  1. 2: Verify that the DTC is current or history by attempting to operate the seat adjuster motor for which the code is set.
  2. 3: Tests the adjuster motor supply circuits for proper operation.
StepActionYesNo
Schematic Reference: Driver Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views
1Did you perform the Power Seat Systems Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Power Seat Systems
2Install a scan tool. With a scan tool, operate the seat adjuster motor through the full range of adjustment in both directions. Does the seat adjuster motor operate through the full range of adjustment?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Disconnect the seat adjuster motor assembly connector. Connect a test lamp between the affected adjuster motor control circuit terminals in the seat harness connector. With a scan tool, command the adjuster motor active in both directions. Does the test lamp turn ON and OFF with each command?Go to Step 5Go to Step 4
4Test and repair the adjuster motor control circuits for the following conditions: Short to ground Open or high resistance Short to voltage Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 6
5Inspect for poor connections at the adjuster motor assembly connector. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 7
6Inspect for poor connections at the harness connector of the memory seat module. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 8
7Replace the seat adjuster motor assembly. Refer to Seat Adjuster Replacement - Front . Did you complete the replacement?Go to Step 9
8Replace the memory seat module. Refer to Memory Seat Control Module Replacement . Did you complete the replacement?Go to Step 9
9Use the scan tool in order to clear the DTCs. Operate the system in order to verify the repair. Does the DTC reset?Go to Step 2System OK

DTC B1770, B1775, B1780, B1785, B1790, B1805, or B2415

The seat adjuster motors are equipped with potentiometer type position sensors used by the memory seat module to determine the seat position. The motor position sensors are supplied with 5-volt reference and ground circuits from the memory seat module. The position sensor signal circuits are referenced from ground within the memory seat module. The signal voltages monitored by the memory seat module range from 0.24-4.75 volts and are determined by the wiper locations on the resistors within the position sensors. The position sensor circuit voltage levels are used by the memory seat module to determine the position of the seat when storing or recalling memory position settings.

The system voltage must be between 9-16 volts.

The memory seat module detects the position sensor signal circuit under 0.24 volts or over 4.75 volts.

Memory functions will be disabled as long as the fault is current.

  1. The DTC will be current for as long as the fault is present.
  2. When the fault is no longer present the DTC will be a history status code.
  3. The history DTC will be cleared after 100 error free ignition cycles, or by using the scan tool clearing DTCs feature.
StepActionValuesYesNo
Schematic Reference: Driver Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views
1Did you perform the Power Seat Systems Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Power Seat Systems
2Install a scan tool. With the scan tool, observe the Position Sensor parameter in the memory seat module data list. Does the scan tool indicate that the Position Sensor parameter is within the specified range?0.2-4.7 VGo to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Disconnect the position sensor connector. Measure the voltage between the 5-volt reference circuit of the position sensor and a good ground. Does the voltage measure within the specified range?4.7-5 VGo to Step 5Go to Step 4
4Test the 5-volt reference circuit of the position sensor for the following conditions: Open or high resistance Short to ground Short to voltage Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 9
5Connect a 3-amp fused jumper wire between the 5-volt reference circuit of the position sensor and the signal circuit of the position sensor. With a scan tool, observe the Position Sensor parameter. Does the scan tool indicate that the Position Sensor parameter is within the specified range?4.7-5 VGo to Step 7Go to Step 6
6Test the signal circuit of the position sensor for the following conditions: Open or high resistance Short to ground Short to voltage Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 9
7Test the low reference circuit of the position sensor for an open or high resistance. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 8
8Inspect for poor connections at the harness connector of the position sensor. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 10
9Inspect for poor connections at the harness connector of the memory seat module. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 11
10Replace the seat position sensor. Refer to Seat Adjuster Replacement - Front . Did you complete the replacement?Go to Step 12
11Replace the memory seat module. Refer to Memory Seat Control Module Replacement . Did you complete the replacement?Go to Step 12
12Use the scan tool in order to clear the DTCs. Operate the system within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset?Go to Step 2System OK

DTC B1825, B1850, B2355, B2365, or B2375

The memory select switch signal circuits are supplied 12 volts through a resistor and monitored within the memory seat module. When a memory select switch is pressed, the signal circuit is closed to ground and the signal circuit voltage is pulled low.

The system voltage must be between 9-16 volts.

A memory select switch input to the memory seat module is active for more than 30 seconds.

  1. The memory seat module will ignore the switch input for which a current status DTC is set.
  2. When the fault is no longer present a history status DTC will be stored, and switch operation will be restored.
  1. The DTC will be current for as long as the fault is present.
  2. When the fault is no longer present the DTC will be a history status code.
  3. The history DTC will be cleared after 100 error free ignition cycles, or by using the scan tool clearing DTCs feature.

The numbers below refer to the step numbers on the diagnostic table.

  1. 2: Verify that the DTC is current or history by monitoring the switch status for which the code is set.
  2. 3: Tests the memory select switch for an internal fault.
StepActionYesNo
Schematic Reference: Driver Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views
1Did you perform the Power Seat System Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Power Seat Systems
2Install a scan tool. With a scan tool, observe the Memory Select Switch parameter in the memory seat module data list. Does the scan tool display inactive?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Disconnect the memory select switch connector. With a scan tool, observe the Memory Select Switch parameter. Does the scan tool display inactive?Go to Step 5Go to Step 4
4Test the switch signal circuit for a short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 6
5Inspect and repair any damage to the memory select switch connector and terminals which may cause the condition. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 7
6Inspect and repair any damage to the memory seat module connector and terminals which may cause the condition. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 8
7Replace the memory select switch. Refer to Memory Seat Switch Replacement (Rendezvous) . Did you complete the replacement?Go to Step 9
8Replace the memory seat module. Refer to Memory Seat Control Module Replacement . Did you complete the replacement?Go to Step 9
9Use the scan tool in order to clear the DTCs. Operate the system in order to verify the repair. Does the DTC reset?Go to Step 2System OK

DTC B2755 or B2760

Symptoms - Seats

IMPORTANTThe following steps must be completed before using the symptom tables.
  1. When diagnosing a memory seat system condition perform the «Diagnostic System Check - Power Seat Systems»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) before using the symptom tables in order to verify that all of the following are true: There are no DTCs set. The control module(s) can communicate via the serial data link.
  2. Refer to the system description and operation from the following list in order to familiarize yourself with the system functions: «Power Seats System Description and Operation»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) «Heated Seats Description and Operation»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) «Memory Seats Description and Operation»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system)

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the power seat systems. Refer to «Checking Aftermarket Accessories»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__checking-aftermarket-accessories) in Wiring Systems.
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
  3. Inspect the seat adjuster track for conditions which may cause binding or objects within the seat adjustment range which may obstruct movement or interfere with wiring.

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. «Power Seat Inoperative (w/Memory)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system__power-seat-inoperative-wmemory) or «Power Seat Inoperative (w/o Memory)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system__power-seat-inoperative-wo-memory)
  2. «Memory Seat Feature Inoperative»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system__memory-seat-feature-inoperative)
  3. «Heated Seat Always On»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system__heated-seat-always-on)
  4. «Heated Seat Inoperative»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system__heated-seat-inoperative)

Power Seat Inoperative (w/Memory)

StepActionYesNo
Schematic Reference: Driver Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views DEFINITION: One or more of the memory seat functions are inoperative and no DTCs are set.
1Did you perform the Power Seat Systems Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Power Seat Systems
2Attempt to operate all of the memory seat adjustments through their full range. Do all of the memory seat functions operate properly?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Install a scan tool. Display the memory seat module Input/Output data list. Disconnect the seat adjuster switch connector. Connect a test lamp from the adjuster switch 12-volt reference circuit terminal in the harness connector to ground. Does the test lamp illuminate?Go to Step 4Go to Step 5
4Connect a fused jumper wire from the 12-volt reference circuit terminal to the inoperative switch signal circuit terminal in the adjuster switch harness connector. Does the scan tool indicate the appropriate switch status as active?Go to Step 7Go to Step 6
5Test the adjuster switch 12-volt reference circuit for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 8
6Test the inoperative switch signal circuit for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 8
7Inspect for poor connections at the seat adjuster switch. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 9
8Inspect for poor connections at the memory seat module. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 10
9Replace the seat adjuster switch. Refer to Memory Seat Switch Replacement (Rendezvous) . Is the repair complete?Go to Step 11
10Replace the memory seat module. Refer to Memory Seat Control Module Replacement . Is the repair complete?Go to Step 11
11Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Power Seat Inoperative (w/Memory)

Power Seat Inoperative (w/o Memory)

StepActionYesNo
Schematic Reference: Driver Seat Schematics , Passenger Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views DEFINITION: One or more of the driver or passenger power seat functions are inoperative.
1Did you review the Power Seat System Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Seats
2Attempt to operate all of the seat adjuster motors through their full range of adjustment. Do all of the power seat adjuster motors operate properly?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Are all of the power seat functions inoperative?Go to Step 4Go to Step 6
4Test the battery positive voltage supply circuit to the seat adjuster switch for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 5
5Test the seat adjuster switch ground circuit for an open or high resistance. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 6
6Disconnect the inoperative adjuster motor connector. Connect a test lamp across the inoperative adjuster motor control circuit terminals. Press the inoperative seat adjuster switch in both directions. Does the test lamp illuminate when the switch is pressed in both directions?Go to Step 8Go to Step 7
7Disconnect the power seat switch connector. Test the inoperative adjuster motor control circuits for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 10
8Inspect for poor connections at the seat adjuster motor assembly. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 9
9Replace the seat adjuster motor assembly. Refer to Seat Adjuster Replacement - Front . Did you complete the replacement?Go to Step 12
10Inspect for poor connections at the seat adjuster switch. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 12Go to Step 11
11Replace the power seat switch. Refer to Seat Switch Replacement - Power . Is the repair complete?Go to Step 12
12Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2

Power Seat Inoperative (w/o Memory)

Memory Seat Feature Inoperative

StepActionYesNo
Schematic Reference: Driver Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views
1Did you perform the Power Seat Systems Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Power Seat Systems
2Attempt to set and recall Memory 1, Memory 2, and Exit seat positions. Do the memory seat recall functions operate properly?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Install a scan tool. Disconnect the memory select switch connector. Connect a fused jumper wire from the memory 1 switch signal circuit terminal in the harness connector to ground. Observe the Memory Switch parameter in the memory seat module Input/Output data list. Does the scan tool indicate the Memory 1 switch is active?Go to Step 4Go to Step 5
4Connect a fused jumper wire from the memory 2 switch signal circuit terminal in the harness connector to ground. Observe the Memory Switch parameter in the memory seat module Input/Output data list. Does the scan tool indicate the Memory 2 switch is active?Go to Step 7Go to Step 6
5Test the memory 1 switch signal circuit for an open or high resistance. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 8
6Test the memory 2 switch signal circuit for an open or high resistance. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 8
7Inspect for poor connections at the memory select switch connector. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 9
8Inspect for poor connections at the memory seat module connector. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 11Go to Step 10
9Replace the memory select switch. Refer to Memory Seat Switch Replacement (Rendezvous) . Is the repair complete?Go to Step 11
10Replace the memory seat module. Refer to Memory Seat Control Module Replacement . Is the repair complete?Go to Step 11
11Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Memory Seat Feature Inoperative

Heated Seat Always On

StepActionYesNo
Schematic Reference: Driver Seat Schematics , Passenger Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views DEFINITION: The driver or passenger seat heaters are on when the heated seat switches are turned off.
1Did you review the Heated Seat System Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Seats
2Disconnect the heated seat cushion 4-way connector. Connect a test lamp from the heated seat switch signal circuit terminal to ground. Turn ON the ignition. Turn the heated seat switch OFF. Does the test lamp illuminate?Go to Step 3Go to Step 5
3Test the heated seat switch signal circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 6Go to Step 4
4Replace the heated seat switch. Is the repair complete?Go to Step 6
5Replace the seat cushion heater element. Refer to Seat Cushion Heater Element Replacement - Front (Aztek) . Is the repair complete?Go to Step 6
6Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2

Heated Seat Always On

Heated Seat Inoperative

StepActionValuesYesNo
Schematic Reference: Driver Seat Schematics , Passenger Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views DEFINITION: The driver or passenger heated seat is inoperative.
1Did you review the Heated Seat System Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Seats
2Turn ON the ignition. Turn the heated seat switch ON. Does the heated seat operate properly?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Does the heated seat switch indicator illuminate when the switch is turned ON?Go to Step 6Go to Step 4
4Test the heated seat switch ignition voltage supply circuit for an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 5
5Test the heated seat switch ground circuit for an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 11
6Disconnect the heated seat cushion 4-way connector. Connect a test lamp from the heated seat switch signal circuit terminal in the harness connector to ground. Turn ON the ignition. Turn the heated seat switch ON. Does the test lamp illuminate?Go to Step 7Go to Step 10
7Test the heated seat battery positive voltage supply circuit for an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 8
8Test the heated seat ground circuit for an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 9
9Disconnect the heated seat back element connector. Measure the resistance of the heated seat back element. Refer to Circuit Testing in Wiring Systems. Is the resistance within the specified values?0.5-2 ohmsGo to Step 15Go to Step 13
10Test the heated seat switch signal circuit for an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 11
11Inspect for poor connections at the heated seat switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 12
12Replace the heated seat switch. Is the repair complete?Go to Step 17
13Inspect for poor connections at the heated seat back element connector. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 14
14Replace the heated seat back element. Refer to Seat Back Heater Element Replacement - Front . Is the repair complete?Go to Step 17
15Inspect for poor connections at the heated seat cushion 4 way connector. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 16
16Replace the heated seat cushion element. Refer to Seat Cushion Heater Element Replacement - Front (Aztek) . Is the repair complete?Go to Step 17
17Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Heated Seat Inoperative

Scheme 6

Scheme 6: Removal Procedure
Scheme 6: Removal Procedure
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 7»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) or «SIR Disabling and Enabling Zone 9»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling-zone-9) .
  2. Position the front bucket seat to the mid-position with the back in the full up position.
  3. Remove the nuts from the front seat adjuster at the floor pan.
  4. Disconnect the electrical connectors from the seat.
  5. Remove the seat from the vehicle.

Installation Procedure

  1. Install the front seat to the studs on the floor pan.
  2. Connect the seat electrical connectors.
  3. Install the nuts to the seat floor pan studs. Tighten: Tighten the front bucket seat adjuster-to-floor pan nuts to 50 N.m (37 lb ft). Inspect the front bucket seat for proper operation and adjustment.
  4. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 7»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) or «SIR Disabling and Enabling Zone 9»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling-zone-9) .

Removal Procedure

  1. Remove the front bucket seat from the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the front seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the front seat cushion cover from the front seat cushion. Refer to «Seat Cushion Cover Replacement - Front (Aztek)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the front seat cushion from the front seat frame.
  1. Install the front seat cushion cover to the front seat cushion. Refer to «Seat Cushion Cover Replacement - Front (Aztek)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Install the front seat cushion to the front seat frame.
  3. Install the front seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the front bucket seat to the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front bucket seat from the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the front seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the front seat adjuster. Refer to «Seat Adjuster Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Disconnect the electrical connector for the heated seat, if equipped.
  5. Remove the J-hook retainers on the front of the front seat cushion cover.
  6. Remove the J-hook retainers on the sides of the front seat cushion cover.
  7. Remove the J-hook retainers on the rear of the front seat cushion cover.
  8. Remove the hook and the loop retainers securing the seat cushion cover to the cushion.
  9. Remove the hog rings from the front seat cushion cover.
  10. Remove the front seat cushion cover from the front seat cushion.
  1. Install the seat cushion cover onto the front seat cushion.
  2. Install the hog rings from the front seat cushion cover.
  3. Install the J-hook retainer on the front of the front seat cushion cover.
  4. Install the J-hook retainers on the sides of the front seat cushion cover.
  5. Install the J-hook retainer on the rear of the front seat cushion cover.
  6. Install the hook and the loop retainers securing the seat cushion cover to the cushion, by pressing in place until fully seated.
  7. Install the front seat adjuster. Refer to «Seat Adjuster Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  8. Connect the electrical connector for the heated seat, if equipped.
  9. Install the front seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  10. Install the front bucket seat to the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front bucket seat from the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the front seat adjuster. Refer to «Seat Adjuster Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the front seat back from the front seat. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the front seat cushion cover from the front seat cushion. Refer to «Seat Cushion Cover Replacement - Front (Aztek)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Remove the front seat cushion from the front seat frame. Refer to «Seat Cushion Replacement - Front (Aztek)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  6. Disconnect all required wiring harnesses from the front seat cushion frame.
  1. Connect all required wiring harnesses to the front seat cushion frame.
  2. Install the front seat cushion to the front seat cushion frame. Refer to «Seat Cushion Replacement - Front (Aztek)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Install the front seat cushion cover to the front seat cushion. Refer to «Seat Cushion Cover Replacement - Front (Aztek)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the front seat adjuster. Refer to «Seat Adjuster Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Install the front seat back to the front seat. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  6. Install the front bucket seat to the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front seat lumbar control knob by pulling off.
  2. Remove the front seat back recliner handle. Refer to «Seat Back Recliner Handle Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Place the front bucket seat to the most rearward position.
  4. Remove the screw from the rear of the front seat cushion trim panel.
  5. Place the front bucket seat to the most forward position.
  6. Remove the screw from the front of the front seat cushion trim panel.
  7. Remove the screw from the center of the front seat cushion trim panel.
  8. Remove the front seat cushion trim panel from the front seat.
  9. Remove the power seat switch from the front seat cushion trim panel, if equipped.
  10. Remove the front seat cushion trim panel from the vehicle.
  1. Install the power seat switch to the front seat cushion trim panel, if equipped.
  2. Align the center screw mounting point to the seat frame.
  3. Install the front seat cushion trim panel to the front seat.
  4. Install the center screw to the front seat cushion trim panel. Tighten: Tighten the front seat cushion trim panel center screw to 43 N.m (32 lb ft).
  5. Place the front bucket seat to the most forward position.
  6. Install the front screw to the front seat cushion trim panel. Tighten: Tighten the front seat cushion trim panel front screw to 43 N.m (32 lb ft).
  7. Place the front bucket seat to the most rearward position.
  8. Install the rear screw to the front seat cushion trim panel. Tighten: Tighten the front seat cushion trim panel rear screw to 43 N.m (32 lb ft).
  9. Install the front seat lumbar control knob, pressing into place until fully seated.
  10. Install the front seat back recliner handle. Refer to «Seat Back Recliner Handle Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the screw from the rear of the front seat cushion trim panel.
  3. Remove the screw from the front of the front seat cushion trim panel.
  4. Remove the screw from the center of the front seat cushion trim panel.
  5. Remove the front seat cushion trim panel from the front bucket seat.
  1. Install the front seat cushion trim panel from the front bucket seat.
  2. Install the screw to the center of the front seat cushion trim panel. Tighten: Tighten the front seat cushion trim panel center screw to 43 N.m (32 lb ft).
  3. Install the screw to the front of the front seat cushion trim panel. Tighten: Tighten the front seat cushion trim panel front screw to 43 N.m (32 lb ft).
  4. Install the screw to the rear of the front seat cushion trim panel. Tighten: Tighten the front seat cushion trim panel rear screw to 43 N.m (32 lb ft).
  5. Install the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the outer trim panel from the front seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the inner trim panel from the front seat cushion. Refer to «Seat Cushion Inner Trim Panel Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the cable ends from the seat back recliner hinge.
  5. Disconnect the electrical connector harness for the side air bag from the front seat frame.
  6. Disconnect the electrical connector for the side air bag from the front seat frame.
  7. Disconnect the heated seat electrical connector.
  8. Remove the left front bolts from the seat back recliner hinge.
  9. Remove the right front bolts from the seat back recliner hinge.
  10. Remove the back from the seat cushion frame. Set the back face down on the front seat cushion.
  11. Remove the heated seat wiring harness and the side air bag wire harness. Remove the wiring harnesses through the front seat cushion and frame area.
  12. Remove the seat back from the seat cushion.
  1. Install the front seat back onto the front seat cushion.
  2. Install the wiring harnesses to the heated seat and to the side air bag through the front seat cushion and frame area.
  3. Install the back to the seat cushion frame.
  4. Install the left front bolts to the seat back recliner hinge. Tighten: Tighten the bolts to 40 N.m (30 lb ft).
  5. Install the right front bolts to the seat back recliner hinge. Tighten: Tighten the bolts to 40 N.m (30 lb ft).
  6. Install the recliner cable ends to the seat back recliner hinge.
  7. Install the outer trim panel to the front seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  8. Install the inner trim panel to the front seat cushion. Refer to «Seat Cushion Inner Trim Panel Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  9. Inspect the seat back for proper operation.
  10. Install the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the front seat back from the front seat. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the front seat headrest. Refer to «Head Restraint Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the front seat armrest. Refer to «Armrest Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Separate the J-hook retainer at the bottom of the seat back cover.
  6. Position the front seat back cover end flaps for access.
  7. Remove the side air bag from the front right and/or left seat. For the right front seat side air bag, refer to «Inflatable Restraint Side Impact Module Replacement - RH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement) in Seats. For the left front seat side air bag, refer to «Inflatable Restraint Side Impact Module Replacement - LH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement) in Seats.
  8. Separate the seat back cover from the front retainer at the side impact airbag.
  9. Separate the seat back cover from the rear retainer at the side impact airbag.
  10. Separate the hook and the loop retainers securing the front seat back cover to the pad.
  11. Remove the front seat back cover from the seat back, by pulling the seat back cover up and over the pad.
  12. Remove the hog rings from the front seat back cover to the pad.
  13. Remove the front seat back cover from the pad.
  1. Install the front seat back cover with alignment mark to the alignment mark on the pad.
  2. Install the hog rings to the front seat back cover to the pad.
  3. Install the seat back cover over the pad while alining the hook and the loop retainers.
  4. Install the hook and the loop retainers, securing the front seat back cover to the pad.
  5. Install the seat back cover to the front retainer at the side impact airbag.
  6. Install the seat back cover to the rear retainer at the side impact airbag.
  7. Install the side air bag to the front right and/or left seat. For the right front seat side air bag, refer to «Inflatable Restraint Side Impact Module Replacement - RH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement) in Seats. For the left front seat side air bag, refer to «Inflatable Restraint Side Impact Module Replacement - LH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement) in Seats.
  8. Install and adjust the seat back cover to the side air bag retainer, by pressing in and pulling down on the seat back cover.
  9. Reposition the front seat back cover end flap.
  10. Install the J-hook retainer at the bottom of the seat back cover.
  11. Install the front seat back to the front seat. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  12. Install the front seat headrest. Refer to «Head Restraint Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  13. Install the front seat armrest. Refer to «Armrest Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  14. Install the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front seat back cover. Refer to «Seat Back Cover Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the front seat back pad from the front seat back frame.
  1. Install the front seat back pad to the front seat back frame.
  2. Install the front seat back cover. Refer to «Seat Back Cover Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the front seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the front seat back cushion cover. Refer to «Seat Back Cover Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the front seat back pad from the front seat back frame. Refer to «Seat Back Pad Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Remove the front seat lumbar from the front seat back, if required. Refer to «Lumbar Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Install the front seat lumbar to the front seat back, if required. Refer to «Lumbar Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Install the front seat back pad to the front seat back frame. Refer to «Seat Back Pad Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Install the front seat back cushion cover. Refer to «Seat Back Cover Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the front seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Install the front seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .

Seat Back Recliner Mechanism Replacement - Front

The front seat back recliner mechanism is part of the front seat cushion frame and cannot be serviced separately, for replacement of the recliner mechanism, refer to Seat Cushion Frame Replacement - Front (Aztek) .

  1. Remove the screw from the seat back recliner handle.
  2. Remove the seat back recliner handle from the seat back recliner handle shaft.
  1. Position the seat back recliner handle to the seat back recliner handle shaft.
  2. Install the seat back recliner handle to the seat back recliner handle shaft pressing on until properly seated.
  3. Install the screw to the seat back recliner handle. Tighten: Tighten the seat back recliner screw to 2 N.m (18 lb in).
  1. Remove the front seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the front seat back cover. Refer to «Seat Back Cover Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the front seat back pad. Refer to «Seat Back Pad Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the lumbar control cable from the lumbar control.
  5. Remove the lumbar support from the front seat back by compressing the lumbar support push-in retainers.
  6. Remove the lumbar support from the front seat back.
  1. Install the lumbar support to the mounting holes in the front seat back.
  2. Install the lumbar support to the front seat back, pressing into place until fully seated.
  3. Install the lumbar support cable to the lumbar support control.
  4. Install the lumbar support cable to the lumbar support control.
  5. Install the front seat back pad. Refer to «Seat Back Pad Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  6. Install the front seat back cover. Refer to «Seat Back Cover Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  7. Install the front seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the lumbar support knob by pulling off the lumbar control shaft.
  2. Remove the lumbar support knob from the vehicle.
  1. Install the knob to the lumbar control shaft.
  2. Install the lumbar support knob by pressing into place until fully seated
  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the outer trim panel. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the lumbar control cable from the lumbar control.
  4. Remove the screws from the lumbar control.
  5. Remove the lumbar control from the seat cushion frame.
  1. Install the lumbar control to the seat cushion frame.
  2. Install the screws to the lumbar control. Tighten: Tighten the screws to 10 N.m (89 lb in).
  3. Install the lumbar control cable to the lumbar control.
  4. Install the outer trim panel. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Install the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the inner cushion trim cover. Refer to «Seat Cushion Inner Trim Panel Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the outer cushion trim cover. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the front seat belt buckle. Refer to the following procedures in Seat Belts: «Seat Belt Buckle Replacement - Left Front»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system) «Seat Belt Buckle Replacement - Right Front»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system)
  5. Disconnect the electrical connectors from the front seat adjuster motors.
  6. Remove the bolts from the seat adjuster.
  7. Remove the adjuster from the seat cushion frame.
  8. Remove the handle from the seat adjuster.
  1. Install the front seat adjuster to the seat cushion frame.
  2. Install the seat back recliner cable to the recessed space on the right and on the left sides of the seat cushion frame.
  3. Install the bolts to the front seat adjuster. Tighten: Tighten the bolts to 43 N.m (32 lb ft).
  4. Install the handle to the front seat adjuster.
  5. Connect the electrical connectors to the front seat adjuster motors.
  6. Install the front seat belt buckle. Refer to the following procedures in Seat Belts: «Seat Belt Buckle Replacement - Left Front»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system) «Seat Belt Buckle Replacement - Right Front»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system)
  7. Install the inner cushion trim cover. Refer to «Seat Cushion Inner Trim Panel Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  8. Install the outer cushion trim cover. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  9. Install the bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  10. If the vehicle is equipped with memory seats, calibrate the seat. Refer to «Memory Seat Calibration Procedure»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system__memory-seat-calibration-procedure) .
  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the screws from the front seat track covers.
  3. Remove the track covers from the front seat.
  1. Install the track covers to the front seat.
  2. Install the screws to the front seat track covers. Tighten: Tighten the screws to 2 N.m (18 lb in).
  3. Install the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the outer trim panel from the front seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Use a small flat-bladed tool to release the retainers which hold the power seat switch to the outer trim panel.
  3. Remove the power seat switch from the outer trim panel.
  4. Remove the power seat switch harness from the front seat support.
  5. Disconnect the electrical connector from the power seat switch.
  6. Remove the power seat switch.
  1. Connect the electrical connector to the power seat switch.
  2. Install the power seat switch to the outer trim panel, pressing the switch into place until fully seated.
  3. Connect the power seat switch harness to the front seat support.
  4. Install the outer trim panel to the front seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Use a flat-bladed tool to pry the memory seat switch panel from the door trim panel.
  2. Disconnect the electrical connectors from the memory seat switch panel.
  1. Connect the electrical connectors to the memory seat switch panel
  2. Install the memory seat switch panel to the door trim panel and press into place until fully seated.
  1. Disable the SIR. Refer to «SIR Disabling and Enabling Zone 7»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Adjust the front seat assembly up and forward in order to access the fasteners (1) at the rear of the front seat cushion assembly.
  3. Remove the fasteners.
  4. Adjust the front seat assembly to the rear of the vehicle.
  5. Angle the front seat cushion (1) up, in order to access the assembly fasteners (2).
  6. Remove the fasteners.
  7. Lift the front seat cushion assembly (1) away from the seat riser.
  8. Disconnect the electrical connector.
  9. Using a flat-bladed tool, release the module from the bracket.
  10. Remove the memory seat module from the seat frame.
  1. Install the memory seat module to the seat frame.
  2. Press the module into the bracket until the module is firmly seated.
  3. Connect the electrical connector to the memory seat module.
  4. Install the seat cushion assembly (1) to the seat riser.
  5. Install the fasteners (2) to the seat cushion assembly (1).
  6. Adjust the front seat assembly up and forward in order to access the fasteners (1).
  7. Install the fasteners (1) to the seat cushion assembly. Tighten: Tighten the fasteners to 9 N.m (80 lb in).
  8. Angle the front seat cushion up, in order to access the assembly fasteners. Tighten: Tighten the fasteners to 9 N.m (80 lb in).
  9. Enable the SIR. Refer to «SIR Disabling and Enabling Zone 7»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  10. Calibrate the seat. Refer to «Memory Seat Calibration Procedure»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system__memory-seat-calibration-procedure) .

Memory Seat Calibration Procedure

The memory seat module uses position sensor inputs to establish soft stop locations for the adjuster motors several millimeters ahead of the physical limits of the adjuster assembly. After replacing a memory seat module or adjuster components, it may be necessary to reset the adjuster motor soft stop locations. When the repair procedure has been completed, operate the seat adjuster switch in every direction until the seat adjuster reaches its mechanical hard stop by repeatedly pressing and releasing the switch as necessary.

  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the back from the front seat. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the headrest. Refer to «Head Restraint Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the armrest. Refer to «Armrest Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Separate the J-hook retainer at the bottom of the seat back cover.
  6. Position the cover end flaps for access.
  7. Remove the side air bag from the front seat. Refer to one of the following procedures: «Inflatable Restraint Side Impact Module Replacement - RH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement) «Inflatable Restraint Side Impact Module Replacement - LH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement)
  8. Separate the seat back cover from the front retainer at the side impact airbag.
  9. Separate the seat back cover from the rear retainer at the side impact airbag.
  10. Separate the hook and the loop retainers securing the seat back cover to the pad.
  11. Remove the seat back cover by pulling the cover up and over the pad.
  12. Remove the hog rings which secures the cover to the pad.
  13. Remove the cover from the pad.
  14. If the cushion is damaged, replace the cushion.
  15. Remove the seat back heater element.
  1. Install the seat back heater element.
  2. Install the front seat back cover. Align the marks on the cover and the pad.
  3. Install the hog rings from the cover to the pad.
  4. Install the cover over the pad while aligning the hook and the loop retainers.
  5. Install the hook and the loop retainers, securing the cover to the pad.
  6. Install the cover to the front retainer at the side impact airbag.
  7. Install the cover to the rear retainer at the side impact airbag.
  8. Install the side air bag to the front seat. Refer to one of the following procedures: «Inflatable Restraint Side Impact Module Replacement - RH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement) «Inflatable Restraint Side Impact Module Replacement - LH»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__inflatable-restraint-side-impact-module-replacement)
  9. Install and adjust the cover to the side air bag retainer, by pressing in and pulling down on the cover.
  10. Reposition the end flap to the seat back cover.
  11. Install the J-hook retainer at the bottom of the seat back cover.
  12. Install the back to the front seat. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  13. Install the headrest. Refer to «Head Restraint Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  14. Install the armrest. Refer to «Armrest Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  15. Install the bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the front bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the seat adjuster. Refer to «Seat Adjuster Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Disconnect the electrical connector for the heated seat, if equipped.
  5. Remove the J-hook retainers at the front of the seat cushion cover.
  6. Remove the J-hook retainers on the sides of the cover.
  7. Remove the J-hook retainers at the rear of the cover.
  8. Remove the hook and the loop retainers securing the cover to the cushion.
  9. Remove the hog rings from the cover.
  10. Remove the cover from the front seat cushion.
  11. If the cushion is damaged, replace the cushion.
  12. Remove the seat cushion heater element.
  1. Install the seat cushion heater element.
  2. Install the cover onto the front seat cushion.
  3. Install the hog rings to the front seat cushion cover.
  4. Install the J-hook retainer on the front of the cover.
  5. Install the J-hook retainers on the sides of the cover.
  6. Install the J-hook retainer on the rear of the cover.
  7. Install the hook and the loop retainers securing the cover to the cushion, by pressing in place until fully seated.
  8. Install the seat adjuster. Refer to «Seat Adjuster Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  9. Connect the electrical connector for the heated seat, if equipped.
  10. Install the seat back. Refer to «Seat Back Replacement - Front»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  11. Install the bucket seat. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .

Tool Required

J 42372 Head Rest Removal Tool. See Special Tools and Equipment .

Head restraints are the double-post type that are adjustable either up or down. Only the solid type head restraints have serviceable trim covers. Use J 42372 in order to remove the head restraints. See Special Tools and Equipment .

  1. Raise the head restraint to the full up position.
  2. Push the head restraint down just far enough in order to center the locking clip in between the detents (3) on the posts.
  3. Insert the J 42372 down the detent side of both posts (3) slightly off center of the detents. See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Push the head rest removal tool over and down to the detent making sure to keep constant pressure on the tool to grab and move the clip away from the detent.
  5. Push down on both of the tools on both sides and lift the head restraint out. It may be necessary to have help pulling on the head rest or pushing on the tool.
  1. Push the head restraint to a full down position in order to install the head restraint posts (1) into the guides (4).
  2. Raise the head restraint in order to ensure that the restraint stops at the detent (3).
  3. Return the head restraint to its original position.
  1. Remove the headrest from the front seat. Refer to «Head Restraint Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Place the front seat back to the full upright position.
  3. Remove the J-hook retainer at the bottom of the seat back cover.
  4. Remove enough of the front seat cover to enlarge the opening for access to the front seat frame.
  5. Reach carefully inside the front seat back between the seat back cover and the seat back pad and squeeze the bottom of the headrest retainer together, while pulling the headrest retainer upwards from the seat back frame.
  6. Remove the headrest retainer from the front seat back frame.
  1. Install the guide to the seat back frame, pressing in until fully seated into the front seat frame.
  2. Install the front seat cover to the front seat back.
  3. Install the J-hook retainer at the bottom edge of the front seat back cover.
  4. Install the headrest to the front seat. Refer to «Head Restraint Replacement - Front Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Place the front seat back to the original position.
  1. Remove the armrest bolt trim cap using a small flat-bladed tool.
  2. Remove the bolt from the armrest.
  3. Remove the armrest from the front bucket seat.
  1. Position the bolt into the mounting point of the armrest.
  2. Position the armrest to the front bucker seat.
  3. Tighten the armrest mounting bolt. Tighten: Tighten the armrest mounting bolt to 4.5 N.m (40 lb in).
  4. install the armrest bolt trim cap pressing into place until fully seated.
  5. Inspect the armrest for proper movement.
  1. Place the seat back fully forward.
  2. Pull the release strap on the back side of the seat adjuster or pull the release handle on the side of the rear seat in order to release the adjuster from the floor.
  3. Lift the rear of the rear seat fully upwards and forward.
  4. Lift the rear seat from the anchor plate.
  5. Remove the rear sear from the vehicle.
  1. Place the rear seat to the anchor plates.
  2. Install the front seat adjuster latches into the anchor plate. Ensure that the latch is hooked on both pins.
  3. Tilt the rear seat assembly down and latch the seat adjuster into the floor.
  4. Install the rear seat to its original position.
  1. Place the rear bucket seat back fully forward.
  2. Pull the release strap on the back side of the rear seat adjuster or pull the release handle on the side of the rear seat in order to release the adjuster from the floor.
  3. Lift the rear of the seat fully upwards and forward.
  4. Lift the rear seat from the anchor plate.
  5. Remove the rear sear from the vehicle.
  1. Place the rear seat to the anchor plates.
  2. Install the front seat adjuster latches into the anchor plate. Ensure that the latch is hooked on both pins.
  3. Tilt the rear seat assembly down and latch the rear seat adjusters into the floor.
  4. Place the rear seat to the original position.
  1. Remove the rear bucket seat from the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear screw from the rear seat cushion trim cover.
  3. Remove the front screw from the rear seat cushion trim cover.
  4. Remove the rear seat belt buckle. Refer to «Seat Belt Buckle Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system) or «Seat Belt Buckle Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system) .
  5. Remove the rear seat cushion trim cover from the rear seat.
  1. Position the rear seat cushion trim cover to the rear seat.
  2. Install the upper retainer clip to the seat frame, pressing into place until fully seated.
  3. Install the rear screw to the seat cushion trim cover. Tighten: Tighten the rear seat cushion trim cover screw to 40 N.m (30 lb ft).
  4. Install the front screw from the rear seat cushion trim cover. Tighten: Tighten the rear seat cushion trim cover screw to 40 N.m (30 lb ft).
  5. Install the rear seat belt buckle. Refer to «Seat Belt Buckle Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system) or «Seat Belt Buckle Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system) .
  6. Install the rear bucket seat to the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear bucket seat from the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear screw from the rear seat cushion trim cover.
  3. Remove the rear seat recliner handle.
  4. Remove the rear seat cushion trim cover from the rear seat.
  1. Position the rear seat cushion trim cover from the rear seat.
  2. Install the upper retainer clip to the seat frame, pressing into place until fully seated.
  3. Install the rear screw to the seat cushion trim cover. Tighten: Tighten the rear seat cushion trim cover screw to 2 N.m (18 lb in).
  4. Install the rear seat recliner handle.
  5. Install the rear bucket seat to the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the screw from the rear seat cushion trim panel.
  2. Remove the rear seat cushion trim panel by lifting up to release the retainer from the recliner hinge.
  1. Install the retainer slot on the rear seat cushion trim panel to tab on the recliner hinge.
  2. Install the rear seat cushion trim panel by sliding down until the retainer slot is fully seated on the recliner hinge tab.
  3. Install the screw to the rear seat cushion trim panel. Tighten: Tighten the rear seat cushion trim panel screw to 2 N.m (18 lb in).
  1. Remove the rear bucket seat from the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat cushion cover from the rear seat cushion. Refer to «Seat Cushion Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the rear seat cushion from the rear seat frame.
  1. Install the rear seat cushion to the rear seat frame.
  2. Install the rear seat cushion cover to the rear seat cushion. Refer to «Seat Cushion Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Install the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the rear bucket seat to the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear split bench seat from the vehicle. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat cushion cover from the rear seat cushion. Refer to «Seat Cushion Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the rear seat cushion from the rear seat frame.
  1. Install the rear seat cushion to the rear seat frame.
  2. Install the rear seat cushion cover to the rear seat cushion. Refer to «Seat Cushion Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Install the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the rear split bench seat to the vehicle. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear bucket seat from the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat adjuster. Refer to «Seat Adjuster Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the J-hook retainers on the front of the rear seat cushion cover.
  5. Remove the J-hook retainers on the sides of the rear seat cushion cover.
  6. Remove the J-hook retainers on the rear of the rear seat cushion cover.
  7. Remove the hook and the loop retainers securing the seat cushion cover to the cushion.
  8. Remove the hog rings from the rear seat cushion cover.
  9. Remove the rear seat cushion cover from the rear seat cushion.
  1. Install the seat cushion cover onto the rear seat cushion.
  2. Install the hog rings from the rear seat cushion cover.
  3. Install the J-hook retainer on the front of the rear seat cushion cover.
  4. Install the J-hook retainers on the sides of the rear seat cushion cover.
  5. Install the J-hook retainer on the rear of the rear seat cushion cover.
  6. Install the hook and the loop retainers securing the seat cushion cover to the cushion, by pressing in place until fully seated.
  7. Install the rear seat adjuster. Refer to «Seat Adjuster Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  8. Install the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  9. Install the rear bucket seat to the vehicle. Refer to «Seat Replacement - Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear split bench seat from the vehicle. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat adjuster. Refer to «Seat Adjuster Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the J-hook retainers on the rear center of the rear seat cushion cover.
  5. Remove the J-hook retainers on the left rear edge of the rear seat cushion cover.
  6. Remove the J-hook retainers on the left side of the rear seat cushion cover.
  7. Remove the J-hook retainers on the right side of the rear seat cushion cover.
  8. Remove the hog rings from the rear seat belt area.
  9. Remove the hog rings from the rear seat cushion cover.
  10. Remove the rear seat cushion cover from the bottom of the rear seat cushion.
  11. Remove the hog rings from the rear seat cushion cover.
  12. Remove the rear seat cushion cover from the rear seat cushion.
  1. Place the rear seat cushion cover to the rear seat cushion.
  2. Install the rear seat cushion cover to the rear seat cushion with hog rings.
  3. Install the rear seat cushion cover to the rear seat cushion.
  4. Install the hog rings to the rear seat cushion cover.
  5. Install the hog rings to the rear seat belt area.
  6. Install the J-hook retainers on the rear center of the rear seat cushion cover.
  7. Install the J-hook retainers on the left rear edge of the rear seat cushion cover.
  8. Install the J-hook retainers on the left side of the rear seat cushion cover.
  9. Install the J-hook retainers on the right side of the rear seat cushion cover.
  10. Install the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  11. Install the rear seat adjuster. Refer to «Seat Adjuster Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  12. Install the rear split bench seat to the vehicle. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear bucket seat from the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the seat back from the rear seat. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat adjuster. Refer to «Seat Adjuster Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the cushion cover and the rear seat cushion. Refer to «Seat Cushion Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Remove the rear seat cushion from the rear seat frame. Refer to «Seat Cushion Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Install the rear seat cushion to the rear seat cushion frame. Refer to «Seat Cushion Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Install the rear seat cushion cover to the rear seat cushion. Refer to «Seat Cushion Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Install the rear seat back to the rear seat. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the rear seat adjuster. Refer to «Seat Adjuster Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Install the rear bucket seat to the vehicle. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the back trim panel from the rear seat. Refer to «Trim Panel Replacement - Rear Seat Back»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the outer trim panel from the rear seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the lower J-hook retainer and pull back the cushion cover to expose the recliner hinge and the center pivot point.
  5. Remove the upper bolts from the seat back recliner hinge.
  6. Remove the seat back from the inner pivot point by lifting up the outer end of the seat back. Use a quick upward twist to disengage the pivot stud from the pivot socket.
  1. Place the rear seat back pivot stud to the rear seat pivot point.
  2. Install the seat back to the pivot point. Press the seat back into the socket until fully seated.
  3. Install the bolts to the seat back recliner hinges. Tighten: Tighten the bolts to 40 N.m (30 lb ft).
  4. Install the lower J-hook retainer.
  5. Install the trim panel to the seat back. Refer to «Trim Panel Replacement - Rear Seat Back»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  6. Install the outer trim panel to the seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  7. Inspect the seat back for proper operation.
  8. Install the split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear bucket seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the outer trim panel from the rear seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the inner trim panel from the rear seat cushion. Refer to «Seat Cushion Inner Panel Replacement - Rear»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the bolts from the seat back recliner hinges.
  5. Remove the seat back from the seat cushion.
  1. Place the rear seat back to the rear seat cushion frame.
  2. Install the bolts to the seat back recliner hinges. Tighten: Tighten the bolts to 40 N.m (30 lb ft).
  3. Install the outer trim panel to the rear seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the inner trim panel to the rear seat cushion. Refer to «Seat Cushion Inner Panel Replacement - Rear»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Inspect the seat back for proper operation.
  6. Install the rear bucket seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the outer trim panel from the seat cushions. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Move the seat back cover and the pad away in order to expose the seat back recliner bolts.
  4. Remove the bolts from the seat back recliner.
  5. Remove the recliner from the seat.
  6. If required, remove the trim cover from the seat back recliner inner side.
  1. If required, install the trim cover to the inner side of the seat back recliner.
  2. Install the seat back recliner to the seat.
  3. Install the bolts to the seat back recliner. Tighten: Tighten the bolts to 40 N.m (30 lb ft).
  4. Move the cover and the pad over the seat back recliner bolts.
  5. Install the outer trim panel to the seat cushions. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  6. Install the split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear bucket seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the outer trim panel from the rear seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the inner trim panel from the rear seat cushion. Refer to «Seat Cushion Inner Panel Replacement - Rear»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Disconnect the cable retainer from the seat back recliner, pushing up on the retainer.
  5. Remove the cable from the seat back recliner.
  6. Move away the seat back cover and pad in order to expose the seat back recliner bolts.
  7. Remove the bolts from the seat back recliner.
  8. Remove the recliner from the seat.
  1. Install the seat back recliner to the seat.
  2. Install the recliner seat back bolts. Tighten: Tighten the bolts to 40 N.m (30 lb ft).
  3. Move the seat back cover and pad over the seat back recliner bolts.
  4. Install the cable to the seat back recliner.
  5. Install the cable retainer to the seat back recliner, pushing down on the retainer until fully seated.
  6. Install the outer trim panel to the rear seat cushion. Refer to «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Cushion Outer Trim Panel Replacement - Rear Seat (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  7. Install the inner trim panel to the rear seat cushion. Refer to «Seat Cushion Inner Panel Replacement - Rear»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  8. Install the rear bucket seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear bucket seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat back cushion cover. Refer to «Seat Back Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the rear seat back pad from the rear seat back frame. Refer to «Seat Back Pad Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Pad Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Install the rear seat back pad to the rear seat back frame. Refer to «Seat Back Pad Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Pad Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Install the rear seat back cushion cover. Refer to «Seat Back Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Install the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the rear seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat back cushion cover. Refer to «Seat Back Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the rear seat back pad from the rear seat back frame. Refer to «Seat Back Pad Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Pad Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Install the rear seat back pad to the rear seat back frame. Refer to «Seat Back Pad Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Pad Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Install the rear seat back cushion cover. Refer to «Seat Back Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Install the rear seat back. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Install the split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the center of the push-pin retainer from the rear seat back trim panel using a small flat-bladed tool.
  2. Remove the push-pin retainer from the seat back trim panel.
  3. Remove the seat back trim panel from the rear seat back.
  1. Place the seat back trim panel to the rear seat back.
  2. Install the outer portion of the push-pin retainer to the seat back trim panel.
  3. Install the push-pin retainer pressing into place until fully seated.
  1. Remove the rear bucket seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back trim panel. Refer to «Trim Panel Replacement - Rear Seat Back»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat back from the front seat. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the rear seat headrest. Refer to «Head Restraint Replacement - Rear Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Remove the J-hook retainer at the bottom of the seat back cover.
  6. Pull out the rear seat back cover end flaps.
  7. Remove the hook and the loop retainers securing the rear seat back cover to the pad.
  8. Remove the rear seat back cover from the seat back, by pulling the seat back cover up and over the pad.
  9. Remove the hog rings from the rear seat back cover to the pad.
  10. Remove the rear seat back cover from the pad.
  1. Install the rear seat back cover alignment mark to the alignment mark on the pad.
  2. Install the hog rings to the rear seat back cover to the pad.
  3. Install the seat back cover over the pad and alining the hook and the loop retainers.
  4. Install the hook and the loop retainers, securing the rear seat back cover to the pad.
  5. Install the rear seat back cover end flap.
  6. Install the J-hook retainer at the bottom of the seat back cover.
  7. Install the rear seat back to the rear seat. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  8. Install the rear seat headrest. Refer to «Head Restraint Replacement - Rear Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  9. Install the rear seat back trim panel. Refer to «Trim Panel Replacement - Rear Seat Back»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  10. Install the rear bucket seat. Refer to «Seat Replacement - Rear Bucket»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear seat back trim panel. Refer to «Trim Panel Replacement - Rear Seat Back»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  3. Remove the rear seat back from the rear seat. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Remove the rear seat headrest. Refer to «Head Restraint Replacement - Rear Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Remove the J-hook retainer at the bottom of the seat back cover.
  6. Pull out the rear seat back cover end flaps.
  7. Remove the hog rings from the rear seat back cover to the pad.
  8. Remove the hook and the loop retainers securing the rear seat back cover to the pad.
  9. Remove the rear seat back cover from the seat back, by pulling the seat back cover up and over the pad.
  10. Remove the rear seat back cover from the pad.
  1. Install the rear seat back cover to the pad.
  2. Install the rear seat back cover to the seat back, by pulling the seat back cover down and over the pad.
  3. Install the hog rings to the rear seat back cover to the pad.
  4. Install the J-hook retainer at the bottom of the seat back cover.
  5. Install the hook and the loop retainers securing the rear seat back cover to the pad.
  6. Install the rear seat back trim panel.
  7. Install the rear seat back to the rear seat. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  8. Install the rear seat headrest. Refer to «Head Restraint Replacement - Rear Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  9. Install the rear seat back trim panel. Refer to «Trim Panel Replacement - Rear Seat Back»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  10. Install the rear split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear seat back cover. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system)
  2. Remove the rear seat back pad from the rear seat back frame.
  1. Install the rear seat back pad to the rear seat back frame.
  2. Install the rear seat back cover. Refer to «Seat Back Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system)
  1. Remove the rear seat back cover. Refer to «Seat Back Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the hog rings from the rear seat back pad.
  3. Remove the rear seat back pad from the rear seat back frame.
  1. Install the rear seat back pad to the rear seat back frame.
  2. Install the hog rings to the rear seat back pad.
  3. Install the rear seat back cover. Refer to «Seat Back Cover Replacement - Rear (Bucket)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) or «Seat Back Cover Replacement - Rear (Split Bench)»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .

J 42372 Head Rest Removal Tool. See Special Tools and Equipment .

Head restraints are the double-post type that are adjustable up or down. Only the solid-type head restraints have serviceable trim covers.

Use J 42372 in order to remove the head restraints. See Special Tools and Equipment . The rear seat head restraint has only 1 locking post.

  1. Raise the head restraint to a full up position.
  2. Push the head restraint down just far enough in order to center the locking clip (4) in the guide between the detents on the posts (3).
  3. Insert J 42372 down the detent side of the post (3). See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  4. Hold the tool down, and at the same time, lift the head restraint upward in order to disengage the detent (3) from the guide (4).
  5. Lift the restraint out.
  1. Install the head restraint posts (1) into the guides.
  2. Push the head restraint to a full down position.
  3. Raise the head restraint in order to ensure that the restraint stops at the detent (3).
  4. Return the head restraint to its original position.
  1. Remove the headrest from the rear seat. Refer to «Head Restraint Replacement - Rear Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Place the rear seat back to the full upright position.
  3. Remove the J-hook retainer at the bottom of the seat back cover.
  4. Remove the rear seat cover to enlarge the opening for access to the rear seat frame.
  5. Reach carefully inside the rear seat back between the seat back cover and the seat back pad and squeeze the bottom of the headrest retainer together, while pulling the headrest retainer upwards from the seat back frame.
  6. Remove the headrest retainer from the rear seat back frame.
  1. Install the guide to the seat back frame, pressing in until fully seated into the rear seat frame.
  2. Install the rear seat cover to the rear seat back.
  3. Install the J-hook retainer at the bottom edge of the rear seat back cover.
  4. Install the headrest to the rear seat. Refer to «Head Restraint Replacement - Rear Seat»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  5. Place the rear seat back to the original position.
  1. Remove the rear split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  2. Remove the rear split bench seat release handle and bezel.
  3. Remove the bolts from the rear seat adjuster.
  4. Remove the rear seat adjuster from the rear seat cushion frame.
  1. Install the rear seat adjuster to the rear seat cushion frame.
  2. Install the bolts to the rear seat adjuster. Tighten: Tighten the rear adjuster bolts to 10 N.m (89 lb in).
  3. Install the rear split bench seat release handle and bezel.
  4. Install the rear split bench seat. Refer to «Seat Replacement - Rear 50-50 Split»(/buick/rendezvous/i-2001-2007/remont/seats/#seat-system) .
  1. Remove the rear storage compartment. Refer to «Storage Compartment Replacement - Rear (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  2. Roll the second row seats forward.
  3. Remove the front anchor nuts from the rear No. 2 seat.
  4. Remove the seat.
  1. Install the rear seat to the mounting studs.
  2. Install the front anchor nuts to the mounting studs on the rear seat. Tighten: Tighten the nuts to 50 N.m (37 lb ft)
  3. Move the second row seat to the original position.
  4. Install the storage compartment. Refer to «Storage Compartment Replacement - Rear (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

The power seat system consists of the following components

  1. The driver seat adjuster switch
  2. The passenger seat adjuster switch
  3. The driver seat adjuster motor assembly
  4. The passenger seat adjuster motor assembly
  5. The PWR/HEATED SEAT PSD 30A circuit breaker

Driver and Passenger Power Seat Operation

The seat adjuster motors are controlled by the seat adjuster switches. Battery positive voltage and ground is supplied to the switch assemblies. All of the switches are closed to ground when in an inactive state. When an adjuster switch is pressed one of the adjuster motor supply circuits is supplied battery positive voltage, and ground is provided through the supply circuit to the inactive switch. The adjuster motors are reversible and the direction of the adjuster motor rotation is determined by which of the supply circuits is closed to battery positive voltage and which remains grounded.

The heated seats system consists of the following components

  1. The heated seat switch
  2. The driver heated seat relay module
  3. The passenger heated seat relay module
  4. The driver heated seat thermistor
  5. The passenger heated seat thermistor
  6. The driver back cushion heater element
  7. The driver seat cushion heater element
  8. The passenger back cushion heater element
  9. The passenger seat cushion heater element
  10. The HVAC/DIC/DRL/HEATED SEAT 10A fuse
  11. The PWR/HEATED SEAT PSD 30A circuit breaker

The heated seats are controlled by the following components

  1. Headed seat switches
  2. Heated seat relay modules

Heated Seat Operation

The driver and front passenger seats are heated using electric heater elements with approximately 1 ohm of resistance each and are located in the lower seat cushions and seat backs. Voltage to the heater elements is controlled by the heated seat relay modules using inputs from the heated seat switches and the heated seat thermistors. The heated seat relay modules and thermistors are part of the lower seat cushion heater element assemblies. Ignition voltage is supplied to the heated seat switch assembly and is used to supply a signal voltage to the relay module and to illuminate the heated seat indicator during heated seat operation.

Battery voltage is supplied to the relay module through a PTC device located in the seat harness which provides extra circuit protection. During heated seat operation the relay module switches the battery voltage supply circuit to the heater element supply circuit. The seat cushion and back heater elements are wired in series and always operate simultaneously. The seat temperature is regulated by the relay module using an input from the thermistor located in the seat cushion. The thermistor is a temperature sensitive variable resistor and the relay module determines the seat cushion temperature by monitoring the signal voltage supplied to the thermistor. When the desired seat temperature has been reached the relay module will open and close the supply voltage to the heater elements as necessary in order to maintain the seat temperature.

The memory seat system consists of the following components

  1. The seat adjuster switch
  2. The memory seat module
  3. The driver seat adjuster motor assembly
  4. The PWR/HEATED SEAT PSD 30A circuit breaker

The memory seat system is controlled by the following components

  1. Seat adjuster switch
  2. Memory seat module

The seat adjuster motors are controlled by the memory seat module through the adjuster motor supply circuits. Adjuster motor operation occurs when the memory seat module switches one of the adjuster motor supply circuits to battery positive voltage and the other to ground. The adjuster motors are reversible and the direction of the adjuster motor rotation is determined by which of the adjuster motor supply circuits is switched to battery positive voltage and which is grounded.

The seat adjuster switch is supplied with a 12-volt reference circuit by the memory seat module. When a seat adjuster switch is pressed the signal circuit is closed to the 12-volt reference. Closing the switch signal circuit to the reference voltage pulls the signal circuit high indicating to the memory seat module the switch status is active. The memory seat module also uses the serial data circuit for diagnostic purposes and to send and receive messages which affect the memory seat system operation.

The seat adjuster motors are equipped with position sensors. The position sensors are supplied with a 5-volt reference circuit and low reference circuit from the memory seat module. Whenever a memory seat module function is active the memory seat module receives a signal from each position sensor which varies from 0 to 5 volts depending on the seat position. The memory seat module uses the position sensor signal voltages to determine the seat position when storing or recalling seat position settings.

Special Tools

Special Tools Illustration Tool Number/Description J 42372 Head Rest Removal Tool

See also:
• Scan Tool Does Not Power Up
• Power Mode Mismatch
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List
• Testing for Intermittent Conditions and Poor Connections
• Circuit Testing
• Wiring Repairs
• Connector Repairs
• Checking Aftermarket Accessories
• SIR Disabling and Enabling Zone 7
• SIR Disabling and Enabling Zone 9
• Inflatable Restraint Side Impact Module Replacement - RH
• Seat Belt Buckle Replacement - Left Front
• Fastener Notice
• SIR Caution
• Storage Compartment Replacement - Rear (Rendezvous)
• Diagnostic System Check - Power Seat Systems
• Symptoms - Seats
• Diagnostic Trouble Code (DTC) List
• Power Seat Inoperative (w/Memory)
• Power Seat Inoperative (w/o Memory)
• Memory Seat Feature Inoperative
• Heated Seat Always On
• Heated Seat Inoperative
• Memory Seat Calibration Procedure
