Steering Wheel & Steering Column Buick Rendezvous I

Ignition Switch/steering Lock 8 illustrations ~4544 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Anchor Cable Nut (at Console Support Bracket)10 N.m89 lb in
Intermediate Steering Shaft Bolt48 N.m35 lb ft
Intermediate Steering Shaft bolt at Gear20 N.m15 lb ft
Intermediate Steering Shaft Seal Bolts3 N.m27 lb in
Linear Shift Assembly Screw10 N.m89 lb in
Shift Lever Set Screw7 N.m62 lb in
Steering Column Bolts (at Instrument Panel Lower Bracket)24 N.m18 lb ft
Steering Column Support Bolts (Internal)17 N.m13 lb ft
Steering Column Nuts (at Instrument Panel Upper Bracket)24 N.m18 lb ft
Steering Column Tilt Lever Bolt10 N.m89 lb in
Steering Wheel Nut *41 N.m30 lb ft
Steering Wheel Rear Bezel Screws3 N.m27 lb in
Trim Cover Screws, Upper3.5 N.m31 lb in
Trim Cover Screws, Lower1.5 N.m13 lb in
Multifunction Switch Screws3 N.m26 lb in
* This is a prevailing torque type fastener. This fastener may be reused ONLY if: The fastener and its counterpart are clean and free from rust The fastener develops a specified amount of torque (drag) against its counterpart prior to the fastener seating. Refer to the appropriate service procedure for the prevailing toque value. If the fastener does not meet these criteria, REPLACE the fastener.

Fastener Tightening Specifications

Scheme 1

Scheme 1: Column/Ignition Lock Schematics
Scheme 1: Column/Ignition Lock Schematics

Scheme 2

Scheme 2: Steering Column Disassembled View (Aztek/250)
Scheme 2: Steering Column Disassembled View (Aztek/250)
CalloutComponent Name
1Upper Trim Cover
2Upper Bearing
3Upper Bearing Seat
4Steering Shaft Upper Bearing Spring
5Inflatable Restraint Steering Wheel Module Coil
6Bearing Retainer
7Steering Wheel Nut
8Trim Cover Protector
9Sleeve
10Cover, Housing Trim Extension
11Lower Trim Cover Screws
12Lower Trim Cover
13Tilt Lever
14Tilt Lever Spring
15Tilt Lever Bolt
16Tilt Lever Spring
17Lower Trim Cover Screw
18Lower Tilt Head Mounting Bolts
19Lower Tilt Head
20Tilt Head Pivot Pins
21Steering Column Jacket Assembly
22Adapter and Bearing Assembly
23Lower Bearing Seat
24Lower Bearing Retainer
25Wire Harness Retainer
26Wire Harness Assembly
27Shaft Assembly
28Multifunction Switch
29Tilt Head Springs
30Multifunction Switch Screws
31Trim Cover Screw
32Actuator, Automatic Transmission Shift Lock Control
33Ignition Switch
34Ignition Key Alarm Switch
35Upper Tilt Head
36Theft Deterrent Module

Scheme 3

Scheme 3: Steering Column Disassembled View (Rendezvous/257)
Scheme 3: Steering Column Disassembled View (Rendezvous/257)
CalloutComponent Name
1Upper Trim Cover
2Upper Bearing
3Upper Bearing Seat
4Steering Shaft Upper Bearing Spring
5Bearing Retainer
6Inflatable Restraint Steering Wheel Module Coil
7Steering Wheel Nut
8Trim Cover Protector
9Sleeve
10Cover, Housing Trim Extension
11Lower Trim Cover Screws
12Lower Trim Cover
13Tilt Lever
14Tilt Lever Spring
15Tilt Lever Bolt
16Tilt Lever Spring
17Lower Trim Cover Screw
18Lower Tilt Head Mounting Bolts
19Lower Tilt Head
20Tilt Head Pivot Pins
21Steering Column Jacket Assembly
22Adapter and Bearing Assembly
23Lower Bearing Seat
24Lower Bearing Retainer
25Wire Harness Retainer
26Wire Harness Assembly
27Shaft Assembly
28Multifunction Switch
29Tilt Head Springs
30Multifunction Switch Screws
31Trim Cover Screw
32Ignition Switch
33Ignition Key Alarm
34Upper Tilt Head
35Theft Deterrent Module
36Control Assembly
37Shift Lever Pivot Pin
38Pivot Pin Bolt
39Lower Shift Lever Bushing
40Upper Shift Lever Bushing
41Steering Column Boot
42Shift Lever
43Shift Lever Screw
44Shift Lever Pin
45Shift Lever Spring

Scheme 4

Scheme 4: Steering Wheel and Column Component Views
Scheme 4: Steering Wheel and Column Component Views
CalloutComponent Name
1Body Control Module (BCM) C2
2Body Control Module (BCM) C1
3Body Control Module (BCM) C0
4Automatic Transmission Floor Shift Control
5Fuse Block - Center Console C2
6Fuse Block - Center Console C1

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Inflatable Restraint Steering Wheel Module
2Wire Harness Assembly
3Multifunction Switch
4Ignition Lock Cylinder Control Actuator
5Ignition Switch
6Theft Deterrent Module

Steering Wheel and Column Connector End Views

Ignition Lock Cylinder Control Actuator Connector End Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU 1134 Ignition Lock Cylinder Control Actuator Signal B BLK 1450 Ground

Diagnostic Starting Point - Steering Column

Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Steering Wheel and Column in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Symptoms - Steering Wheel and Column

Review the system description and operation in order to familiarize yourself with the system functions. Refer to Steering Wheel and Column Description and Operation .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the steering wheel and column.
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Symptoms List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. «Lock System Does Not Unlock»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__lock-system-does-not-unlock)
  2. «Lock System Does Not Lock»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__lock-system-does-not-lock)
  3. «Lock System Sticks in Start»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__lock-system-sticks-in-start)
  4. «Key Cannot Be Removed in the Off Lock Position»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__key-cannot-be-removed-in-the)
  5. «High Lock Effort»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__high-lock-effort)
  6. «Noise in Steering Column»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__noise-in-steering-column)
  7. «Steering Column Tilt Function Inoperative»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-tilt-function-inoperative)

Steering Column Tilt Function Inoperative

StepActionYesNo
1Did you review the Steering Wheel and Column - Tilt Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Steering Wheel and Column
2Verify that the steering column tilt function is inoperative. Does the steering column tilt function operate normally?System OKGo to Step 3
3Verify that the shoe is not seized on the pivot pin. Is the shoe seized on the pivot pin?Go to Step 9Go to Step 4
4Inspect the shoe grooves for dirt, burrs, or rust. Are the shoe grooves free of dirt, burrs, and rust?Go to Step 9Go to Step 5
5Inspect weak or broken shoe lock spring. Is the shoe lock spring weak or broken?Go to Step 9Go to Step 6
6Inspect the pivot pins for binding. Are the pivot pins binding?Go to Step 9Go to Step 7
7Inspect for a weak or broken wheel tilt spring. Is the wheel tilt spring weak or broken?Go to Step 9Go to Step 8
8Inspect the steering column wiring harness for tightness. Is the steering column wiring harness too tight?Go to Step 10Go to Step 3
9Replace the steering column. Refer to Steering Column Replacement . Is the repair complete?Go to Step 11
10Reroute the steering column wiring harness to the correct location. Is the steering column wiring harness routed properly?Go to Step 11
11Operate the steering column tilt function in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Steering Column Tilt Function Inoperative

Circuit Description

If the vehicle is equipped with a floor mounted console gearshift, an ignition lock cylinder control actuator system is used in the steering column. The purpose of the system is to prevent the ignition lock cylinder from being turned to the lock position while the transmission is in gear, this also prevents the steering wheel from being locked. The system consists of an ignition lock cylinder actuator and a park position switch. The actuator contains a pin that is spring loaded out, to prevent the ignition lock cylinder from being turned to the lock position when the gearshift is not in Park. The park position switch is located in the floor mounted gearshift assembly, as part of the automatic transmission shift lock control switch. The switch is closed with the gearshift in PARK, and open in all other positions.

System Operation

When the gearshift is in the PARK position, the park position switch is closed. This applies voltage to the ignition lock cylinder actuator and the pin retracts, allowing the ignition lock cylinder to be turned to the LOCK position. When the gearshift is not in PARK, the park position switch is open. No voltage is applied to the ignition lock cylinder actuator and the spring loaded pin remains in the out position, preventing the ignition lock cylinder from being turned to LOCK. If vehicle power is lost while the ignition lock cylinder is not in the LOCK position, the system will prevent the operator from turning the ignition key to the lock position or removing the key. If the vehicle has lost power, pushing the ignition lock cylinder release button on the underside of the ignition lock cylinder will override the system and allow the key to be removed.

StepActionYesNo
Schematic Reference: Column/Ignition Lock Schematics Connector End View Reference: Steering Wheel and Column Connector End Views
1Verify the fault is present. Does the system operate normally?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 2
2Does the automatic transaxle shift lever operate normally?Go to Step 3Go to Diagnostic Starting Point - Automatic Transmission Shift Lock Control in Shift Lock Control
3Push the ignition lock cylinder control actuator release button which is on the underside of the ignition lock cylinder. Turn the key to the LOCK position and remove the key. Were you able to turn the key to the LOCK position and remove the key?Go to Step 4Go to Lock System Does Not Lock
4Turn OFF the ignition. Disconnect the ignition lock cylinder control actuator. Connect a test lamp between the battery positive voltage and ground circuits of the ignition lock cylinder control actuator. Turn ON the ignition, with the engine OFF. Cycle the gear shift from Park to Drive. Does the test lamp turn ON and OFF with each cycle?Go to Step 11Go to Step 5
5Does the test lamp remain illuminated with each cycle?Go to Step 8Go to Step 6
6Connect a test lamp between the ground circuit of the ignition lock cylinder control actuator and B+ voltage? Does the test lamp illuminate?Go to Step 7Go to Step 9
7Test the control circuit of the ignition lock cylinder control actuator for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 14Go to Step 10
8Test the control circuit of the ignition lock cylinder control actuator for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 14Go to Step 10
9Repair the open in the ground circuit of the ignition lock cylinder control actuator. Refer to Wiring Repairs in Wiring Systems. Did you complete the repair?Go to Step 14
10Inspect for poor connections at the automatic transmission shift lock actuator. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 14Go to Step 12
11Inspect for poor connections at the ignition lock cylinder control actuator. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 14Go to Step 13
12Replace the automatic transmission shift lock actuator. Refer to Floor Shift Control Replacement in Automatic Transaxle - 4T65-E. Did you complete the replacement?Go to Step 14
13Replace the ignition lock cylinder control actuator. Refer to Park Pawl Actuator Replacement (Aztek) . Did you complete the replacement?Go to Step 14
14Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2

Ignition Can/Cannot Be Turned Off with Transmission in Any Gear

Lock System Does Not Unlock

StepActionYesNo
DEFINITION: The lock system does not allow the key to rotate out of the OFF position.
1Did you review the Ignition Lock System Description and perform the necessary inspections?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system does not unlock. Does the lock system operate normally?System OKGo to Step 3
3Inspect for an incorrect, a worn, or a damaged key. Is the key incorrect, worn, or damaged?Go to Step 8Go to Step 4
4Inspect for a faulty lock cylinder. Is the lock cylinder damaged?Go to Step 9Go to Step 5
5Inspect the automatic transmission shift lock control adjustment. Is the automatic transmission shift lock control adjusted incorrectly?Go to Step 10Go to Step 6
6Inspect the lock module assembly for damage. Is the lock module assembly damaged?Go to Step 11Go to Step 7
7Inspect the ignition switch assembly for damage. Is the ignition switch assembly damaged?Go to Step 12Go to Step 3
8Replace the key. Refer to Key and Lock Cylinder Coding in General Information. Did you complete the repair?Go to Step 13
9Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 13
10Adjust the automatic transmission shift lock control. Did you complete the repair?Go to Step 13
11Replace the steering column. Refer to Steering Column Replacement . Did you complete the repair?Go to Step 13
12Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 13
13Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Lock System Does Not Unlock

Lock System Does Not Lock

StepActionYesNo
DEFINITION: The lock system will not allow the key to be turned to the OFF lock position.
1Did you review the ignition lock system description and perform the necessary inspections?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system does not lock. Does the lock system operate normally?System OKGo to Step 3
3Inspect for an incorrect, worn, or damaged key. Is the key incorrect, worn, or damaged?Go to Step 9Go to Step 4
4Inspect for a faulty lock cylinder. Is the lock cylinder or release button damaged?Go to Step 10Go to Step 5
5Inspect the shift linkage adjustment. Is the shift linkage adjusted incorrectly?Go to Step 11Go to Step 6
6Inspect the automatic transmission shift lock control for damage. Is the automatic shift lock control damaged?Go to Step 12Go to Step 7
7Inspect the ignition switch for damage. Is the ignition switch damaged?Go to Step 13Go to Step 8
8Inspect the park lock for damage and cycle manual override. Is the park lock damaged?Go to Step 14Go to Step 3
9Replace the key. Refer to Key and Lock Cylinder Coding in General Information. Did you complete the repair?Go to Step 15
10Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 15
11Adjust the shift linkage. Did you complete the repair?Go to Step 15
12Replace the automatic transmission shift lock control. Did you complete the repair?Go to Step 15
13Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 15
14Replace the park lock. Refer to Park Pawl Actuator Replacement (Aztek) . Did you complete the repair?Go to Step 15
15Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Lock System Does Not Lock

Lock System Sticks in Start

StepActionYesNo
1Did you review the Ignition Lock System Description and perform the necessary inspections?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system sticks in the START position. Does the lock system operate normally?System OKGo to Step 3
3Inspect the lock module assembly for damage. Is the lock module assembly damaged?Go to Step 6Go to Step 4
4Inspect the lock cylinder for damage. Is the lock cylinder damaged?Go to Step 7Go to Step 5
5Inspect the ignition switch for damage. Is the ignition switch damaged?Go to Step 8Go to Step 3
6Replace steering column. Refer to Steering Column Replacement . Did you complete the repair?Go to Step 9
7Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 9
8Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 9
9Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Lock System Sticks in Start

Key Cannot Be Removed in the Off Lock Position

StepActionYesNo
1Did you review the Ignition Lock System Description and perform the necessary inspections?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the key cannot be removed from the lock cylinder in the OFF position. Does the lock system operate normally?System OKGo to Step 3
3Inspect for an incorrect, a worn, or a damaged key. Is the key incorrect, worn, or damaged?Go to Step 5Go to Step 4
4Inspect for a faulty lock cylinder or release button. Is the lock cylinder or release button damaged?Go to Step 6Go to Step 3
5Replace the key. Refer to Key and Lock Cylinder Coding in General Information. Did you complete the repair?Go to Step 7
6Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 7
7Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Key Cannot Be Removed in the Off Lock Position

High Lock Effort

StepActionYesNo
1Did you review the Ignition Lock System Description and perform the necessary inspections?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system has a high lock effort. Does the lock system operate normally?System OKGo to Step 3
3Inspect for an incorrect, a worn, or a damaged key. Is the key incorrect, worn, or damaged?Go to Step 7Go to Step 4
4Inspect for a faulty lock cylinder. Is the lock cylinder damaged?Go to Step 8Go to Step 5
5Inspect the lock module assembly for damage. Is the lock module assembly damaged?Go to Step 9Go to Step 6
6Inspect the ignition switch assembly for damage. Is the ignition switch assembly damaged?Go to Step 10Go to Step 7
7Replace the key. Refer to Key and Lock Cylinder Coding in General Information. Did you complete the repair?Go to Step 11
8Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 11
9Replace the steering column. Refer to Steering Column Replacement . Did you complete the repair?Go to Step 11
10Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 11
11Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

High Lock Effort

Noise in Steering Column

StepActionYesNo
1Did you review the Steering Wheel and Column Description and perform the necessary inspections?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that noise is present in the steering column during operation. Is noise present in the steering column during operation?Go to Step 3System OK
3Inspect the steering column components for looseness. Is the steering column components loose?Go to Step 8Go to Step 4
4Inspect the SIR/SRS coil for noise. Is the SIR/SRS coil noisy?Go to Step 9Go to Step 5
5Inspect the horn contact ring for lubrication. Does the horn contact ring need to be lubricated?Go to Step 10Go to Step 6
6Inspect the intermediate shaft bearing for the following conditions: Damage Lubrication Wear Proper seating Are the bearings in need of repair or replacement?Go to Step 13Go to Step 8
7Inspect the steering column coupling for looseness. Is the steering column coupling loose?Go to Step 12Go to Step 3
8Tighten the steering column components to specifications. Refer to Fastener Tightening Specifications . Did you complete the repair?Go to Step 13
9Replace the SIR coil. Refer to Inflatable Restraint Steering Wheel Module Coil Replacement in SIR. Did you complete the repair?Go to Step 13
10Lubricate the horn contact ring. Did you complete the repair?Go to Step 13
11Replace the intermediate shaft as necessary. Did you complete the repair?Go to Step 13
12Tighten the steering column coupling to specifications. Refer to Fastener Tightening Specifications . Did you complete the repair?Go to Step 13
13Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Noise in Steering Column

Removal Procedure

  1. Turn the ignition OFF and remove the key from the ignition lock cylinder in order to lock the steering column.
  2. Remove the left closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  3. Disconnect the intermediate shaft seal from the steering column.
  4. Remove the intermediate shaft to steering column pinch bolt.
  5. Disconnect the intermediate shaft from the steering column. Refer to «Intermediate Steering Shaft Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  6. Collapse the intermediate shaft in order to gain clearance.
  7. Cut three 1-inch slits in the insulation over the seal bolts in order to access the seal bolts.
  8. Remove the intermediate shaft seal bolts.
  9. Remove the intermediate shaft seal from the inside of the vehicle.
  10. If the lower intermediate shaft seal remains, then remove the seal from the intermediate shaft through the inside of the vehicle.

Installation Procedure

  1. Collapse the lower intermediate shaft seal into the upper intermediate shaft seal.
  2. Install the intermediate shaft seal over the intermediate shaft from inside the vehicle.
  3. Connect the intermediate shaft to the steering column. Refer to «Intermediate Steering Shaft Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  4. Install the upper intermediate shaft pinch bolt. Tighten: Tighten the intermediate shaft seal bolts to 48 N.m (35 lb ft).
  5. Install the intermediate shaft seal bolts. Tighten: Tighten the intermediate shaft seal bolts to 3 N.m (27 lb in).
  6. Connect the intermediate shaft seal to the steering column.
  7. Install the left closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  8. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/rendezvous/i-2001-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
  9. Connect the lower intermediate shaft seal to the steering gear.
  10. Lower the vehicle.

Note. The steering column must be in the LOCK position before disconnecting the following components: The steering column The steering shaft coupling The intermediate shaft The lower steering shaft After disconnecting these components, do not move the front tires and wheels. Failure to follow these procedures may cause improper alignment of some components during installation and result in possible damage to the SIR coil.

  1. Turn the ignition OFF, with the wheel in a straight forward position.
  2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/rendezvous/i-2001-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
  3. Remove the left front tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/buick/rendezvous/i-2001-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
  4. Push the intermediate shaft lower seal up into the intermediate shaft upper seal in order to access to the intermediate shaft lower bolt.
  5. Remove the intermediate shaft lower pinch bolt.
  6. Push the intermediate steering shaft (1) up in order to remove the intermediate steering shaft from the steering gear (2).
  7. Lower the vehicle.
  8. Remove the left closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  9. Pull the intermediate steering shaft seal down off of the steering column in order to access the intermediate steering shaft upper bolt.
  10. Remove the intermediate shaft to steering column pinch bolt.
  11. Disconnect the intermediate shaft from the steering column.
  12. Remove the intermediate steering shaft through the inside of the vehicle.
  1. Install the intermediate steering shaft (1) through the intermediate steering shaft seal.
  2. Install the intermediate steering shaft (1) to the steering column.
  3. Install the intermediate steering shaft upper pinch bolt. Tighten: Tighten the intermediate steering shaft upper bolt to 48 N.m (35 lb ft).
  4. Install the intermediate steering shaft to the steering column.
  5. Install the left closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  6. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/rendezvous/i-2001-2007/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
  7. Connect the intermediate shaft (1) to the steering gear (2).
  8. Connect the intermediate steering shaft lower pinch bolt. Tighten: Tighten the intermediate steering shaft lower bolt to 48 N.m (35 lb ft).
  9. Connect the intermediate steering shaft seal to the steering gear. Take care in aligning the seal the shaft clearance.
  10. Install the left front tire and wheel. Refer to «Tire and Wheel Removal and Installation»(/buick/rendezvous/i-2001-2007/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
  11. Lower the vehicle.

Inspection Procedure

  1. Inspect the capsules on the steering column bracket assembly. Verify that the capsules are seated securely in the bracket slots and inspect the capsules for any loose conditions when pushed or pulled by hand. If the capsules are not secure, perform one of the following procedures: If the bracket is bolted to the jacket assembly, replace the bracket. If the bracket is welded to the jacket assembly, replace the jacket assembly.
  2. Inspect the jacket assembly for collapse by measuring the distance from the lower edge of the upper jacket to a defined point on the lower jacket. If measured dimensions (A), are not within specifications (100 mm), install a steering column.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the knee bolster trim panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  3. Remove the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  4. Remove the tilt lever close out plate.
  5. Remove the trim cover screws (1) from the lower steering column.
  6. Tilt the lower trim cover (2) down and slide the lower trim cover rearward in order to disengage the locking tabs.
  7. Remove the upper trim cover screws.
  8. Remove the ignition lock cylinder. Refer to «Ignition Lock Cylinder Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  9. Remove the upper trim cover (2) from the steering column.
  1. Install the upper trim cover to the steering column.
  2. Install the lock cylinder. Refer to «Ignition Lock Cylinder Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  3. Install the upper trim cover screws to the steering column. Tighten: Tighten the screws to 1.5 N.m (13 lb in).
  4. Match the tab slots on the lower trim cover with the locking tabs on the upper trim cover.
  5. Tilt the lower trim cover up and slide the lower trim cover until the locking tabs snap into the tab slots.
  6. Install the screws (1) to the lower trim cover (2). Tighten: Tighten the screws to 3.5 N.m (31 lb in).
  7. Install the tilt lever close out plate.
  8. Install the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  9. Install the knee bolster trim panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  10. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  3. Pull the theft deterrent control module (2) away from the lock cylinder housing (1).
  4. Depress the 2 white spring loaded retainers on the ignition switch.
  5. Slide the ignition switch downward away from the ignition lock cylinder case.
  6. Disconnect the electrical connector from the ignition switch.
  1. Connect the electrical connector to the ignition switch.
  2. Slide the ignition switch into the ignition lock cylinder case.
  3. Push the theft deterrent module (2), onto the lock cylinder housing (1).
  4. Install the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  5. Enable the SIR System. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Disconnect the battery negative cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LA1)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) or «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  2. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  3. Remove the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  4. Remove the tilt lever close out plate.
  5. Remove the retaining screw from the lower steering column trim covers.
  6. Tilt the trim cover down and slide rearward in order to disengage the locking tabs. Remove the lower steering column trim covers.
  7. Remove the retaining screws from the upper steering column trim cover.
  8. Lift the trim cover in order to gain access to the lock cylinder access hole (1).
  9. Insert the Snap-On A173A bent-tip awl (1) or equivalent, with a 2.5 mm (3/32 in) tip, and 20 mm (3/4 in) in length, into the access hole of the.
  10. Turn the ignition lock cylinder to START.
  11. Use the bent tip in order to push down on the ignition lock cylinder retainer.
  12. Release the ignition lock cylinder to the RUN position.
  13. Remove the ignition lock cylinder from the lock cylinder case.
  1. Insert the ignition lock cylinder through the trim cover in the upper steering column.
  2. Align the lock cylinder retaining tab and the position tab with the slots in the lock housing.
  3. Completely push the lock cylinder into the lock housing.
  4. Install the retaining screws to the upper steering trim cover. Tighten: Tighten the screws to 3.5 N.m (31 lb in).
  5. Match the tab slots on the lower trim cover with the locking tabs on the upper trim cover.
  6. Tilt the lower trim cover up and slide the lower trim cover until the locking tabs snap into the tab slots.
  7. Install the lower trim cover screws to the steering column. Tighten: Tighten the screws to 1.5 N.m (13 lb in).
  8. Install the tilt lever close out plate.
  9. Install the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  10. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  11. Connect the battery negative cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LA1)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) or «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  1. Remove the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Remove the tie straps from the park pawl actuator harness.
  3. Remove the park pawl actuator by rotating counterclockwise.
  4. Disconnect the electrical connector.
  1. Connect the electrical connector.
  2. Install the park pawl actuator by rotating clockwise.
  3. Install the tie straps onto the park pawl actuator harness.
  4. Install the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  3. Disconnect the electrical connectors from the multifunction switch.
  4. Remove the wiring harness (1) from the steering column harness strap (2).
  5. Disconnect the multifunction switch electrical connectors from the steering column wiring harness.
  6. Remove the multifunction switch retaining screws (1).
  7. Remove the multifunction switch (2) from the steering column.
  8. Remove the SIR coil from the steering column shaft. Refer to «Inflatable Restraint Steering Wheel Module Coil Replacement»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Install the multifunction switch (2) to the steering column tilt head. Verify that the electrical contact of the turn signal switch rests on the horn ring.
  2. Install the multifunction switch screws (1). Tighten: Tighten the screws to 3 N.m (26 lb in).
  3. Install 2 electrical connectors (2) of the multifunction switch into the bulkhead connector.
  4. Connect the multifunction switch connector to the SIR coil connector.
  5. Attach the wire harness (1) to the steering column with new wire harness straps.
  6. Install the wire harness (1) to the wire harness strap.
  7. Install the SIR coil to the steering column shaft. Refer to «Inflatable Restraint Steering Wheel Module Coil Replacement»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  8. Install the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  9. Enable the SIR. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Position the shift lever boot out of the way (2).
  2. Remove the retaining screw (3) from the lever.
  3. Remove the lever (1).
  1. Insert the shift lever (1) into the shift lever housing.
  2. Install the shift lever retaining screw (3). Tighten: Tighten the screw to 7 N.m (62 lb in).
  3. Position the shift lever boot (2).
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the lower trim cover. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  3. Remove the tilt lever spring.
  4. Remove the retaining bolt from the tilt lever.
  5. Remove the tilt lever.
  1. Install the tilt lever.
  2. Install the retaining bolt to the tilt lever. Tighten: Tighten the bolt to 10 N.m (89 lb in).
  3. Install the tilt lever spring.
  4. Install the lower trim cover. Refer to «Steering Column Trim Covers Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  5. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Steering Wheel Control Switch Assembly Replacement

CAUTIONRefer to SIR Caution in Cautions and Notices.
  1. Disable the SIR System. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  3. Remove the retaining screws (2, 3) from the steering wheel rear bezel.
  4. Remove the steering wheel rear bezel (1).
  5. Disconnect the electrical connector.
  6. Insert a small, blunt-ended tool into the access hole in the back of the steering wheel. Push the switch out of the steering wheel.
  1. Connect the electrical connector.
  2. Align the switch to the opening in the steering wheel.
  3. Push the switch into the steering wheel.
  4. Install the steering wheel rear bezel (1).
  5. Install the retaining screws (2, 3) to the steering wheel rear bezel. Tighten: Tighten the screws to 3 N.m (27 lb in).
  6. Install the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  7. Enable the SIR System. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Steering Wheel Replacement

Tools Required

  1. J 1859-A Steering Wheel Puller. See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. J 42578 Steering Wheel Puller Legs. See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the inflator module. Refer to «Inflatable Restraint Steering Wheel Module Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) or «Inflatable Restraint Steering Wheel Module Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  3. Disconnect the steering wheel control electrical connector.
  4. Remove the steering wheel nut.
  5. Install J 42578 and J 1859-A to the steering wheel. See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  6. Use J 42578 and J 1859-A in order to remove the steering wheel. See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  7. Remove J 42578 and J 1859-A from the steering wheel. See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  8. Remove the controls and the control harness from the steering wheel.
  1. Install the controls and the control harness to the steering wheel.
  2. Install the wiring through the steering wheel.
  3. Install the steering wheel.
  4. Connect the steering wheel control electrical connector.
  5. Install the steering wheel nut. Tighten: Tighten the nut to 41 N.m (30 lb ft).
  6. Install the inflator module. Refer to «Inflatable Restraint Steering Wheel Module Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) or «Inflatable Restraint Steering Wheel Module Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  7. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

Tools Required

J 42640 Steering Column Anti-Rotation Pin

  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Install J 42640 to the steering column.
  3. Remove the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  4. Remove the knee bolster trim panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  5. Push the top of the intermediate shaft seal down in order to access to the upper retaining bolt.
  6. Remove the upper retaining bolt and nut.
  7. Disconnect the steering column electrical connectors.
  8. Column Shift Only. Disconnect the shift cable from the control assembly and the steering column.
  9. Remove the upper mounting nuts.
  10. Remove the lower mounting bolts.
  11. Remove the anchor cable from the bracket.
  12. Remove the steering column from the vehicle.
  1. Install the steering column to the vehicle.
  2. Install the steering column to the intermediate shaft.
  3. Install the anchor cable to the bracket stud.
  4. Install the steering column nuts. Finger tighten the nuts.
  5. Install the steering column bolts.
  6. Tighten the fasteners in the following order: Tighten: Tighten the bolts to 24 N.m (18 lb ft). Tighten the nuts to 24 N.m (18 lb ft).
  7. Install the upper intermediate shaft bolt. Tighten: Tighten the bolt to 48 N.m (35 lb ft).
  8. Install the intermediate shaft seal to the steering column.
  9. Column Shift Only. Install the shift cable to the control assembly and the steering column.
  10. Connect the steering column electrical connectors.
  11. Install the knee bolster trim panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  12. Install the steering wheel. Refer to «Steering Wheel Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  13. Remove J 42640 from the steering column.
  14. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
  15. Program the theft deterrent system. Refer to «Programming Theft Deterrent System Components»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#theft-deterrent-system) in Theft Deterrent.
  1. Remove the knee bolster. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
  2. Remove the steering column upper nut.
  3. Remove the center console. Refer to «Console Replacement - Front Floor (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Console Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
  4. Remove the anchor cable nut from the center console bracket.
  5. Remove the anchor cable.
  1. Properly route the steering column anchor cable.
  2. Install the anchor cable to the center console bracket stud.
  3. Install the anchor cable nut to the center console bracket stud. Tighten: Tighten the nut to 10 N.m (89 lb in).
  4. Install the steering column anchor cable end to the steering column stud.
  5. Install the steering column nut. Refer to «Steering Column Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  6. Install the center console. Refer to «Console Replacement - Front Floor (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Console Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
  7. Install the knee bolster. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
  1. Remove the steering column. Refer to «Steering Column Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Disconnect all the electrical connectors.
  3. Remove all the wire harness straps (2).
  4. Remove the wire harness from the steering column.
  1. Install the wire harness to the steering column.
  2. Replace all the tie straps (2).
  3. Connect all the electrical connectors.
  4. Install the steering column. Refer to «Steering Column Replacement»(/buick/rendezvous/i-2001-2007/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

Inflatable Restraint Steering Wheel Module Coil Centering

Note. The new SIR coil assembly will be centered. Improper alignment of the SIR coil assembly may damage the unit, causing an inflatable restraint malfunction.

Scheme 6

Scheme 6: Inflatable Restraint Steering Wheel Module Coil Centering
Scheme 6: Inflatable Restraint Steering Wheel Module Coil Centering
  1. Verify the following conditions before centering the SIR coil: The wheels on the vehicle are pointed straight ahead. The block tooth (1) of the steering shaft is in the 12 o'clock position. The ignition switch is in the LOCK position, or J 42640 is installed in the upper tilt head.
  2. If the front (5) of the SIR coil has a centering window (4), and the back side (2) has a spring service lock (1), perform the following steps: Hold the coil with the face up. While depressing the spring service lock, rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counter clockwise, until the centering window appears yellow and both arrows (3) line up. Release the spring service lock between the locking tab. The SIR coil is now centered. Align the centered SIR coil with the horn tower and slide the coil onto the steering shaft.
  3. If the front (4) of the SIR coil has a centering window (3) and the back side (1) does NOT have a spring service lock, perform the following steps: Hold the coil with the face up. Rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counter clockwise until the centering window appears yellow and both arrows (2) line up. This is center position. While holding the coil hub in center position, align the SIR coil assembly with the horn tower and slide onto the steering shaft.
  4. If the front side (3) of the SIR coil does NOT have a centering window, but the back side (2) has a spring service lock (1), perform the following steps: Hold the SIR coil with the back side up. While depressing the spring service lock, rotate the coil hub counter clockwise until the coil ribbon stops. Still pressing the spring service lock, rotate the coil hub in the opposite direction 2.5 revolutions. Release the spring service lock between locking tabs. The SIR coil is now centered. Align the centered SIR coil with the horn tower and slide onto the steering shaft.
  5. If the front side (3) of the SIR coil does NOT have a centering window, and the back side (2) does NOT have a spring service lock (1), perform the following steps: Hold the coil with the face up. Rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub, slowly, counter clockwise, for 2.5 revolutions. This is center position. While maintaining the coil hub in center position, align the centered SIR coil with the horn tower and slide onto the steering shaft.

Steering Wheel and Column Description and Operation

The steering wheel and column has 4 primary functions

  1. Vehicle steering
  2. Vehicle security
  3. Driver convenience
  4. Driver safety

Vehicle Steering

The steering wheel is the first link between the driver and the vehicle. The steering wheel is fastened to a steering shaft within the column. At the lower end of the column, the intermediate shaft connects the column to the steering gear.

Vehicle Security, found on Some Vehicle Models

Theft deterrent components are mounted and designed into the steering column. The following components allow the column to be locked in order to minimize theft

  1. The ignition switch
  2. The steering column lock
  3. The ignition cylinder

Driver Convenience

The steering wheel and column may also have driver controls attached for convenience and comfort. The following controls may be mounted on or near the steering wheel or column.

  1. The turn signal switch
  2. The hazard switch
  3. The headlamp dimmer switch
  4. The wiper/washer switch
  5. The horn pad/cruise control switch
  6. The redundant radio/entertainment system controls
  7. The tilt or tilt/telescoping functions
  8. The navigation/OnStar® features
  9. The HVAC controls

Driver Safety

The energy-absorbing steering column compresses in the event of a front-end collision, which reduces the chance of injury to the driver. The mounting capsules break away from the mounting bracket in the event of an accident.

Ignition Lock Cylinder Control Actuator

If the vehicle is equipped with a floor mounted console gear shift, it has a ignition lock cylinder control actuator system in the steering column. The ignition lock cylinder control actuator's purpose is to prevent the ignition key from being turned to the OFF position when the transmission is in gear and the vehicle may still be moving. The column ignition lock system consists of a ignition lock cylinder control actuator, and a park position switch that is located in the A/T shift lock control switch. The ignition lock cylinder control actuator contains a pin that is spring loaded out to mechanically prevent the ignition key cylinder from being turned to the lock position when the vehicle transmission is not in the Park position. If vehicle power is lost, and/or the transmission is not in the Park position the operator will not be able to turn the ignition key to the lock position and will not be able to remove the ignition key from the column.

Special Tools

Special Tools Illustration Tool Number/Description J 1859-A Steering Wheel Puller J 42578 Steering Wheel Puller Legs J 42640 Anti-Rotation Pin

Scheme 7

Scheme 7: Special Tools
Scheme 7: Special Tools

Scheme 8

Scheme 8
Scheme 8

See also:
• Testing for Intermittent Conditions and Poor Connections
• Diagnostic Starting Point - Automatic Transmission Shift Lock Control
• Circuit Testing
• Wiring Repairs
• Connector Repairs
• Floor Shift Control Replacement
• Key and Lock Cylinder Coding
• Inflatable Restraint Steering Wheel Module Coil Replacement
• Closeout/Insulator Panel Replacement - Left
• Fastener Notice
• Lifting and Jacking the Vehicle
• Tire and Wheel Removal and Installation
• Battery Negative Cable Disconnect/Connect Procedure (LA1)
• SIR Caution
• Programming Theft Deterrent System Components
• Symptoms - Steering Wheel and Column
• Steering Wheel and Column Description and Operation
• Lock System Does Not Unlock
• Lock System Does Not Lock
• Lock System Sticks in Start
• Key Cannot Be Removed in the Off Lock Position
• High Lock Effort
• Noise in Steering Column
• Steering Column Tilt Function Inoperative
• Steering Column Replacement
• Steering Wheel and Column Connector End Views
• Fastener Tightening Specifications
• Steering Wheel Replacement
