Engine Mechanical - 2.0l - Repair Instructions - on Vehicle Buick Regal V

Mechanical 14 illustrations ~7649 words

Scheme 82

Scheme 82: Intake Manifold Cover Replacement
Scheme 82: Intake Manifold Cover Replacement
CalloutComponent Name
1Intake Manifold Cover Procedure Remove the oil cap before removing the intake manifold cover. The intake manifold cover needs to be pulled straight up to disconnect from the ball studs to prevent joysticking of the ball studs. Install the intake manifold cover straight down and ensure the oil fill tube is properly seated. Install the oil cap.

Intake Manifold Cover Replacement

Scheme 83

Scheme 83: Belt Idler Pulley Replacement
Scheme 83: Belt Idler Pulley Replacement
CalloutComponent Name
Preliminary Procedure Remove the drive belt. Refer to Drive Belt Replacement .
1Drive Belt Idler Pulley Fastener CAUTION: Refer to Fastener Caution . Tighten 20 N.m (16 lb ft)
2Drive Belt Idler Pulley Procedure Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Belt Idler Pulley Replacement

Scheme 84

Scheme 84: Drive Belt Replacement
Scheme 84: Drive Belt Replacement
CalloutComponent Name
Preliminary Procedure Remove the Engine Mount. Refer to Engine Mount Replacement
1Drive Belt Procedure Use the proper tool to rotate the drive belt tensioner. Remove the drive belt from the pulleys and tensioner.
2Drive Belt Tensioner Procedure Clean and inspect the drive belt surfaces of all the pulleys. Inspect the drive belt for correct alignment.

Drive Belt Replacement

Scheme 85

Scheme 85: Drive Belt Tensioner Replacement
Scheme 85: Drive Belt Tensioner Replacement
CalloutComponent Name
Preliminary Procedure Remove the Engine Mount Bracket. Refer to Engine Mount Bracket Replacement .
1Drive Belt Tensioner Fastener CAUTION: Refer to Fastener Caution . Tighten 45 N.m (33 lb ft)
2Drive Belt Tensioner Procedure Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Drive Belt Tensioner Replacement

Engine Mount Inspection

IMPORTANTBefore replacing any engine mount due to suspected fluid loss, verify that the source of the fluid is the engine mount, not the engine or accessories.
  1. Install a engine hoist to the lift brackets and raise the engine slightly putting pressure on the engine mounts.
  2. Observe the engine mount while slightly lifting the engine. Lifting the engine removes the weight from the engine mount and creates slight tension on the rubber.
  3. Replace the engine mount if the engine mount exhibits any of the following conditions: The hard rubber is covered with heat check cracks. The rubber is separated from the metal plate of the engine mount. The rubber is split through the center of the engine mount. The engine mount is leaking fluid, if applicable.
  4. For engine mount replacement, refer to «Engine Mount Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .

Scheme 86

Scheme 86: Engine Mount Bracket Replacement
Scheme 86: Engine Mount Bracket Replacement
CalloutComponent Name
Preliminary Procedure Prior to removing the engine mount, mark mount bolt to mount interfaces using spray paint or a marker for correct positioning during installation of the engine mount. Refer to Engine Mount Replacement .
1Engine Mount Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 100 N.m (74 lb ft)
2Engine Mount Bracket Procedure Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Engine Mount Bracket Replacement

Special Tools

  1. EN-28467-B Universal Engine Support Fixture
  2. EN-43405-1 Engine Support Feet (Passenger Side)
  3. EN-43405-2 Engine Support Feet (Drivers Side)

For equivalent regional tools, refer to Special Tools (LDK, LHU) .

Installation Procedure

  1. Remove the Intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) .
  2. Remove the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
  3. Assemble the EN-28467-B universal engine support fixture to the EN-43405-1 engine support feet (passenger side) and EN-43405-2 engine support feet (drivers side) and place across the engine compartment.
  4. From the EN-28467-B universal engine support fixture universal engine support fixture, install the radiator shelf tube J-28467-2A (1) on top of the strut tower tube J-28467-3 (2) above the engine front (right back) lift hook bracket.
  5. Install the round tube of the front support assembly J-28467-4A (3) through the large hole in the radiator shelf tube J-28467-2A.
  6. Locate the J-28467-4A front support assembly to the upper tie bar.
  7. Install the J-28467-9 7/16 inch x 2.0 inch quick-release pin (4) through the top hole in the J-28467-4A front support assembly.
  8. Install the J-28467-1A cross bracket assembly (1).
  9. Hand tighten the J-28467-1A cross bracket wing nuts (2).
  10. Install the J-28467-7A bolt hook through the J-28467-6A bracket.
  11. Install the J-28467-34 lift hook wing nut and washer to the J-28467-7A lift hook.
  12. Repeat the previous 2 steps in order to assemble 2 lift hooks and brackets.
  13. Install one of the lift hook and bracket assemblies (1) to the engine support fixture long bar (2).
  14. Install the other lift hook and bracket assembly (3) to the J-28467-2A radiator shelf tube (4) above the engine front lift bracket.
  15. Install the lift hook J-28467-7A through the engine rear lift bracket (2).
  16. Install the lift hook J-28467-7A through the engine front lift bracket.
  17. Hand tighten the lift hook wing nuts J-28467-34 in order to remove all slack from the engine support fixture assembly.

Powertrain Mount Balancing

Note. Follow the balance procedure steps listed below when no starting point has been established such as in a collision repair.

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/regal/v-2009-2013/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Loosen the front transaxle mount through bolt (1) until it is finger tight.
  3. Loosen the rear transaxle mount (1) through bolt until it is finger tight.
  4. Lower the vehicle.
  5. Position two floor jacks with wood blocks under the engine and transaxle in order to support the powertrain assembly.
  6. Loosen the transaxle adapter to transaxle bolts (1).
  7. Loosen the engine mount (1) to bracket bolts (2).
  8. Lower the floor jacks in order to allow a 1/4 inch (6 mm) gap between the upper engine mount and engine mount bracket, and also between the transmission and left transmission mount.
  9. Check that the front and rear mounts are centered (1) in the mount brackets, adjust if necessary.
  10. Tighten the left hand (transaxle side) mount bolts, starting with the bolt nearest to the center of the mount. See the appropriate transmission mount replacement procedure for the fastener tightening specifications.
  11. Tighten the right hand (engine side) mount bolts (1), starting with the bolt nearest to the center of the mount. See the appropriate engine mount replacement procedure for the fastener tightening specifications.
  12. Remove the floor jacks from under the oil pan and transmission.
  13. Raise the vehicle.
  14. Shake the powertrain from front to rear and allow the powertrain to settle.
  15. Tighten the rear transaxle mount through bolt (1). See the appropriate transmission mount replacement procedure for the fastener tightening specifications.
  16. Tighten the front transaxle mount through bolt (1). See the appropriate transmission mount replacement procedure for the fastener tightening specifications.
  17. Lower the vehicle.

Powertrain Mount Balancing - Lower

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/regal/v-2009-2013/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Loosen the front transaxle mount through bolt (1).
  3. Loosen the rear transaxle mount through bolt (1).
  4. Shake the powertrain from front to rear and allow the powertrain to settle.
  5. Tighten the rear transaxle mount through bolt (1). See the appropriate transmission mount replacement procedure for the fastener tightening specifications.
  6. Tighten the front transaxle mount through bolt (1). See the appropriate transmission mount replacement procedure for the fastener tightening specifications.
  7. Lower the vehicle.

Scheme 87

Scheme 87: Engine Mount Replacement
Scheme 87: Engine Mount Replacement
CalloutComponent Name
Preliminary Procedures Install engine support fixture. Refer to Engine Support Fixture . Prior to removing the mount, mark mount to bracket, mount to body interfaces and fasteners to mount interfaces using spray paint or a marker for correct positioning during installation.
1Engine Mount Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure If the front and/or rear lower mount through bolts were loosened or removed, perform the Powertrain Mount Balancing - Lower. If ALL powertrain mounts were replaced with new components, perform the Powertrain Mount Balancing. Refer to the appropriate engine service information. Tighten 50 N.m (37 lb ft) +60 degrees +15 degrees
2Engine Mount Fastener (Qty: 3) Tighten 62 N.m (46 lb ft)
3Engine Mount Procedure Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Engine Mount Replacement

Scheme 88

Scheme 88: Oil Level Indicator Tube Replacement
Scheme 88: Oil Level Indicator Tube Replacement
CalloutComponent Name
Preliminary Procedure Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement
1Oil level indicator tube fastener CAUTION: Refer to Fastener Caution . Tighten 10 N.m (89 lb in)
2Oil level indicator Procedure Remove the oil level indicator
3Oil level indicator tube Procedure Disconnect electrical connectors as needed. Remove the electrical wiring harness from the oil level indicator tube. Remove the oil level indicator tube from the oil pan. Inspect the O-rings for damage. Replace if damaged. Transfer parts as needed.
CAUTION
Refer to Fastener Caution .

Oil Level Indicator Tube Replacement

Removal Procedure

  1. Drain the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (GE 47716)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  3. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  4. Remove the catalytic converter. Refer to «Catalytic Converter Replacement (LDK or LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system) .
  5. Remove the turbocharger oil feed pipe bolts.
  6. Remove the turbocharger oil feed pipe gaskets.
  7. Remove the turbocharger oil feed pipe (1).
  8. Remove the turbocharger coolant return pipe bolts.
  9. Remove the turbocharger coolant return pipe gaskets.
  10. Remove the turbocharger coolant return pipe (1).
  11. Remove the turbocharger air cooler outlet pipe. Refer to «Charge Air Cooler Outlet Pipe Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  12. Remove the turbocharger coolant feed pipe bolts.
  13. Remove the turbocharger coolant feed pipe gaskets.
  14. Remove the turbocharger coolant feed pipe (1).
  15. Remove the turbocharger brace nuts.
  16. Remove the turbocharger brace (1).
  17. Remove the PCV hose fitting bolt at the turbocharger.
  18. Remove the PCV hose fitting from the turbocharger.
  19. Remove the turbocharger nuts (1).
  20. Remove the turbocharger (2) and the oil return pipe.
  21. Remove the turbocharger gasket (3).
  22. Remove the turbocharger oil return pipe bolts (3).
  23. Remove the turbocharger oil return pipe (2) from the turbocharger.
  24. Remove and discard the turbocharger oil return pipe gasket (1).
  25. Disconnect vacuum hose as needed.
  26. Disconnect coolant hoses as needed.
  27. Disconnect electrical connectors as needed.
  1. Install a new turbocharger oil return pipe gasket (1).
  2. Install the turbocharger oil return pipe (2) on the turbocharger.
  3. Install the turbocharger oil return pipe bolts (3) and tighten to 10 N.m (89 lb in).
  4. Attach the positive crankcase ventilation (PCV) hose and fitting with O-ring from the camshaft cover to the turbocharger.
  5. Install the PCV hose fitting bolt and tighten to 10 N.m (89 lb in).
  6. Lubricate the O-ring on the turbocharger oil return pipe with clean engine oil.
  7. Install a new turbocharger gasket (3).
  8. Install the turbocharger (2) with the oil return pipe.
  9. Install the turbocharger nuts (1). Tighten the turbocharger nuts to 30 N.m (22 lb ft). Tighten the turbocharger nuts a second time to 35 N.m (26 lb ft).
  10. Install the turbocharger brace (1).
  11. Install the turbocharger brace nuts and tighten to 50 N.m (37 lb ft).
  12. Install the catalytic converter. Refer to «Catalytic Converter Replacement (LDK or LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system) .
  13. Install the turbocharger coolant feed pipe (1).
  14. Install the turbocharger coolant feed pipe gaskets.
  15. Install the turbocharger coolant feed pipe bolts. Tighten the turbocharger coolant feed pipe bolts to 35 N.m (26 lb ft). Tighten the turbocharger coolant feed pipe mounting bolt to 10 N.m (89 lb in).
  16. Connect the PCV and hose assembly.
  17. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  18. Install the turbocharger oil feed pipe (1) on the engine block side.
  19. Install the turbocharger oil feed pipe gasket on the engine block side.
  20. Install the bolt and tighten to 40 N.m (30 lb ft).
  21. Install the turbocharger coolant return pipe (1).
  22. Install the turbocharger coolant return pipe gaskets.
  23. Install the turbocharger coolant return pipe bolts and tighten to 35 N.m (26 lb ft).
  24. Install the turbocharger oil feed pipe (1) onto the turbocharger.
  25. Install the turbocharger oil feed pipe gasket for the turbocharger side.
  26. Install the turbocharger oil feed pipe bolt and tighten to 40 N.m (30 lb ft).
  27. Install the catalytic converter. Refer to «Catalytic Converter Replacement (LDK or LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system) .
  28. Fill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (GE 47716)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  29. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  30. Replace the oil filter and fill the engine oil system. Refer to «Engine Oil and Oil Filter Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .

Scheme 89

Scheme 89: Turbocharger Oil Feed Pipe Replacement
Scheme 89: Turbocharger Oil Feed Pipe Replacement
CalloutComponent Name
Preliminary Procedures Remove the catalytic converter. Refer to Catalytic Converter Replacement (LDK or LHU) . Remove the turbocharger brace.
1Turbocharger Oil Feed Pipe Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Do not reuse gasket. A new Gasket must be used. Tighten 35 N.m (26 lb ft)
2Turbocharger Oil Feed Pipe Procedure Disconnect coolant hose's as needed. Disconnect electrical connectors as needed. Transfer parts as needed.
CAUTION
Refer to Fastener Caution .

Turbocharger Oil Feed Pipe Replacement

Scheme 90

Scheme 90: Turbocharger Oil Return Pipe Replacement
Scheme 90: Turbocharger Oil Return Pipe Replacement
CalloutComponent Name
Preliminary Procedure Remove the Turbocharger. Refer to Turbocharger Replacement . Remove the catalytic converter. Refer to Catalytic Converter Replacement (LDK or LHU) .
1Turbocharger Oil Return Pipe Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 10 N.m (89 lb in)
2Turbocharger Oil Return Pipe Procedure A new gasket should be used whenever the pipe is removed from the turbo or engine assembly Transfer components as necessary
CAUTION
Refer to Fastener Caution .

Turbocharger Oil Return Pipe Replacement

  1. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Drain the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (GE 47716)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  3. Release the charge air cooler outlet pipe. Refer to «Charge Air Cooler Outlet Pipe Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  4. Relief the fuel pressure. Refer to «Fuel Pressure Relief»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions__fuel-pressure-relief) .
  5. Disconnect the charger AIR bypass tube assembly from the intake manifold.
  6. Disconnect the charger AIR bypass tube with the retaining clip from the charger AIR bypass valve solenoid.
  7. Remove the charger AIR bypass valve tank assembly nut (2).
  8. Loosen the charger AIR bypass valve tank assembly bolt.
  9. Remove the charger AIR bypass valve tank assembly (1).
  10. Disconnect the remaining charger AIR bypass tubes at the turbocharger and vehicle.
  11. Remove the charger AIR bypass valve solenoid bolts.
  12. Remove the charger AIR bypass valve solenoid (1).
  13. Remove the high pressure fuel pump cover bolts.
  14. Remove the high pressure fuel pump cover (2).
  15. Remove the high pressure fuel pump noise insulator (1).
  16. Loosen and disconnect the fuel feed line tube nut (1).
  17. Remove the fuel feed line bolts.
  18. Remove the fuel feed line (2).
  19. Inspect the fuel feed line nut for damaged threads.
  20. Inspect the fuel feed line sealing bail for damage or debris.
  21. Replace the fuel feed line if any damage is found.
  22. Disconnect the rear knock sensor from the intake manifold brace.
  23. Remove the intake manifold brace bolt (1) and nut (3).
  24. Remove the intake manifold brace (2).
  25. Remove the intake manifold bolts and nuts (3).
  26. Remove the intake manifold (2).
  27. Remove the intake manifold gasket (1).
  28. Clean and Inspection intake manifold. Refer to «Intake Manifold Cleaning and Inspection (LDK, LHU)»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-off-vehicle__intake-manifold-cleaning-and-inspection-ldk) .
  29. Transfer parts as needed.
  30. Disconnect electrical connectors as needed.
  1. Install a NEW intake manifold gasket (1).
  2. Install the intake manifold (2).
  3. Install the intake manifold bolts and nuts (3) finger tight.
  4. Tighten the intake manifold bolts and nuts in sequence: Tighten the intake manifold bolts to 25 N.m (18 lb ft). Tighten the intake manifold nuts to 22 N.m (16 lb ft).
  5. Install the intake manifold brace (2).
  6. Install the intake manifold brace bolt (1) and nut (3) and tighten to 25 N.m (18 lb ft).
  7. Connect the rear knock sensor to the intake manifold brace.
  8. Lubricate the high pressure fuel pump fuel feed line connection threads with clean 5W30 engine oil.
  9. Install the fuel feed line (2).
  10. Install the fuel feed line bolts.
  11. Connect the low pressure fuel line nut (1) and tighten to 30 N.m (22 lb ft).
  12. Tighten the fuel feed line bolts to 10 N.m (89 lb in).
  13. Install the high pressure fuel pump noise insulator (1).
  14. Install the high pressure fuel pump cover (2).
  15. Install the high pressure fuel pump cover bolts and tighten to 10 N.m (89 lb in).
  16. Install the charger AIR bypass valve solenoid (1) with charger AIR bypass tube assemblies.
  17. Install the charger AIR bypass valve solenoid bolts and tighten to 10 N.m (89 lb in).
  18. Connect the charger AIR bypass tube assemblies and clips from the charger AIR bypass valve solenoid to the turbocharger and vehicle.
  19. Install the charger AIR bypass valve tank assembly (1).
  20. Tighten the charger AIR bypass valve tanks assembly bolt to 25 N.m (18 lb ft).
  21. Install the charger AIR bypass valve tank assembly nut (2) and tighten to 25 N.m (18 lb ft).
  22. Connect the appropriate charger AIR bypass tube assembly to the intake manifold.
  23. Connect the final charger AIR Bypass tube assembly from the charger AIR bypass valve tank assembly to the charger AIR bypass valve solenoid.
  24. Install the charge air cooler outlet pipe. Refer to «Charge Air Cooler Outlet Pipe Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  25. Fill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (GE 47716)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  26. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  1. EN-47981 Harmonic Balancer Holder
  2. EN-45059 Angle Meter

For equivalent regional tools, refer to Special Tools (LDK, LHU) .

  1. Remove the engine drive belt. Refer to «Drive Belt Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/regal/v-2009-2013/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Use the EN-47981 Harmonic Balancer Holder to prevent the crankshaft from rotating while loosening the crankshaft balancer bolt.
  4. Remove the crankshaft balancer bolt. Discard the bolt.
  5. Remove the balancer using a universal removal tool.
  1. Install the crankshaft balancer onto the crankshaft indexing keyway. Use care to properly align the keyway and the flats on the balancer with the oil pump drive.
  2. Install the crankshaft balancer using a universal balancer installer.
  3. Install a NEW crankshaft balancer bolt. Use the EN-47981 Harmonic Balancer Holder to prevent the crankshaft from rotating when tightening the bolt. Tighten the bolt to 100 N.m (74 lb ft) plus an additional 125 degreesusing the EN-45059 Angle Meter.
  4. Lower the vehicle.
  5. Install the engine drive belt. Refer to «Drive Belt Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .

EN-34115 Sprocket Bearing Installer

  1. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Using a flat-bladed tool, remove the oil seal from the front cover.
  1. Use the EN-34115 Sprocket Bearing Installer in order to install the oil seal to the front cover.
  2. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  1. Remove the drive belt tensioner. Refer to «Drive Belt Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  3. Remove the belt idler pulley. Refer to «Belt Idler Pulley Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle)
  4. Remove the engine front cover bolts.
  5. Remove the engine front cover to water pump bolt.
  6. Remove and discard the engine front cover gasket.
  7. Remove the crankshaft front cover oil seal with an appropriate tool.
  8. Remove and discard the friction washer.
  1. Install a NEW crankshaft front oil seal. Refer to «Crankshaft Front Oil Seal Installation (LDK, LHU)»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-off-vehicle__crankshaft-front-oil-seal-installation-ldk) .
  2. Install a NEW friction washer.
  3. Position and install a NEW engine front cover gasket to the dowel pins.
  4. Install the engine front cover bolts
  5. Install the long water pump bolt (1) Tighten Tighten the bolt to 25 N.m (18 lb ft).
  6. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) .
  7. Install the belt idler pulley. Refer to «Belt Idler Pulley Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle)
  8. Install the drive belt tensioner. Refer to «Drive Belt Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  1. EN-45027 Tensioner Tool
  2. EN-45059 Angle Meter
  1. Remove the number 1 cylinder spark plug. Refer to «Spark Plug Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
  2. Rotate the crankshaft in the engine rotational direction clockwise, until the number 1 piston is at top dead center (TDC) on the exhaust stroke.
  3. Remove the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  4. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  5. Remove the upper timing chain guide bolts and guide.
  6. Remove the timing chain tensioner.
  7. Install a 24 mm wrench on the hex on the exhaust camshaft in order to hold the camshaft.
  8. Remove and discard the exhaust camshaft actuator bolt (2).
  9. Remove the exhaust camshaft actuator (1, 3) from the camshaft and timing chain.
  10. Remove the timing chain tensioner guide bolt and guide.
  11. Remove the fixed timing chain guide access plug.
  12. Remove the fixed timing chain guide bolts and guide.
  13. Install a 24 mm wrench on the hex on the intake camshaft in order to hold the camshaft.
  14. Remove and discard the intake camshaft actuator bolt (2).
  15. Remove the intake camshaft actuator (3), and the timing chain through the top of the cylinder head.
  16. Remove the timing chain crankshaft sprocket.
  17. If replacing the balance shaft timing chain and sprocket, perform the following steps, if not proceed to step 10 in the installation procedure.
  18. Remove the balance shaft drive chain tensioner bolts and tensioner.
  19. Remove the adjustable balance shaft chain guide bolt and guide.
  20. Remove the small balance shaft drive chain guide bolts and guide.
  21. Remove the upper balance shaft drive chain guide bolts and guide.
  22. Remove the balance shaft drive chain (7).
  23. Remove the balance shaft drive sprocket.
  1. If replacing the balance shaft timing chain, perform the following steps, if not proceed to step 10.
  2. Install the balance shaft drive sprocket.
  3. Install the balance shaft drive chain (1) with the colored link lined up with the marks on the balance shaft sprockets and the balance shaft drive sprocket. There are 3 colored links on the chain. Two are chrome and 1 is copper. Use the following steps in order to line up the links with the sprockets. Place the copper link (5) so that it lines up with the timing mark (2) on the intake side balance shaft sprocket. Working clockwise around the chain, place the chrome link (4) in line with the timing mark (3) on the balance shaft drive sprocket. (approximately 6 o'clock position on the sprocket). Place the chain (7) on the water pump drive sprocket. The alignment is not critical. Align the last chrome link (6) with the timing mark (1) on the exhaust side balance shaft drive sprocket.
  4. Install the upper balance shaft drive chain guide and bolts and tighten to 15 N.m (11 lb ft).
  5. Install the small balance shaft drive chain guide and bolts and tighten to 15 N.m (11 lb ft).
  6. Install the adjustable balance shaft chain guide and bolt and tighten to 10 N.m (89 lb in).
  7. Reset the timing chain tensioner by performing the following steps: Rotate the tensioner plunger 90 degrees in its bore and compress the plunger. Rotate the tensioner back to the original 12 o'clock position and insert a paper clip through the hole in the plunger body and into the hose in the tensioner plunger.
  8. Install the balance shaft drive chain tensioner and bolts and tighten to 10 N.m (89 lb in).
  9. Remove the paper clip from the balance shaft drive chain tensioner.
  10. On 2.2L engines, ensure the intake camshaft notch is in the 10 o'clock position (2) and the exhaust camshaft notch is in the 7 o'clock position (1). The number 1 piston should be at TDC, crankshaft key at 12 o'clock.
  11. On 2.4L engines, ensure the intake camshaft notch is in the 5 o'clock position (2) and the exhaust camshaft notch is in the 7 o'clock position (1). The number 1 piston should be at TDC, crankshaft key at 12 o'clock.
  12. Install the timing chain drive sprocket to the crankshaft with the timing mark in the 5 o'clock position and the front of the sprocket facing out.
  13. Assemble the intake camshaft actuator into the timing chain with the timing mark lined up with the uniquely colored link (1).
  14. Lower the timing chain through the opening in the cylinder head. Use care to ensure that the chain goes around both sides of the cylinder block bosses (1, 2).
  15. Install the intake camshaft actuator onto the intake camshaft while aligning the dowel pin into the camshaft slot.
  16. Hand tighten the new intake camshaft actuator bolt.
  17. Route the timing chain around the crankshaft sprocket and line up the first matching colored link with the timing mark on the crankshaft sprocket, in approximately the 5 o'clock position.
  18. Rotate the crankshaft clockwise to remove all chain slack. Do not rotate the intake camshaft.
  19. Install the adjustable timing chain guide down through the opening in the cylinder head and install the adjustable timing chain bolt. Tighten the adjustable timing chain guide bolt to 10 N.m (89 lb in).
  20. Install the exhaust camshaft actuator into the timing chain with the timing mark lined up with the second matching colored link.
  21. Install the exhaust camshaft actuator onto the exhaust camshaft, aligning the dowel pin into the camshaft slot.
  22. Using a 23 mm open end wrench, rotate the exhaust camshaft approximately 45 degrees until the dowel pin in the camshaft actuator goes into the camshaft slot.
  23. When the actuator seats on the cam, tighten the new exhaust camshaft actuator bolt hand tight.
  24. Verify that all of the colored links and the appropriate timing marks are still aligned. If they are not aligned, repeat the portion of the procedure necessary to align the timing marks.
  25. Install the fixed timing chain guide and bolts. Tighten the fixed timing chain guide bolts to 10 N.m (89 lb in).
  26. Install the upper timing chain guide and bolts. Tighten the upper timing chain guide bolts to 10 N.m (89 lb in).
  27. Reset the timing chain tensioner by performing the following steps: Remove the snap ring. Remove the piston assembly from the body of the timing chain tensioner. Install the EN-45027-2 (2) into a vise. Install the notch end of the piston assembly into the J-45027-2 (2). Using the EN-45027-1 (1), turn the ratchet cylinder into the piston. Reinstall the piston assembly into the body of the tensioner. Install the snap ring.
  28. Inspect the timing chain tensioner seal for damage. If damaged, replace the seal.
  29. Inspect to ensure all dirt and debris is removed from the timing chain tensioner threaded hole in the cylinder head.
  30. Install the timing chain tensioner assembly. Tighten the timing chain tensioner to 75 N.m (55 lb ft).
  31. The timing chain tensioner is released by compressing it 2 mm (0.079 in), which will release the locking mechanism in the ratchet. To release the timing chain tensioner, use a suitable tool with a rubber tip on the end. Feed the tool down through the cam drive chest to rest on the cam chain. Then give a sharp jolt diagonally downwards to release the tensioner.
  32. Using a 23 mm wrench, engage the hex on the intake camshaft, and using a torque wrench, tighten the camshaft actuator bolt. Tighten the intake camshaft position actuator bolt to 30 N.m (22 lb ft) plus 100 degreesusing the EN-45059 meter.
  33. Using a 23 mm wrench, engage the hex on the exhaust camshaft, and using a torque wrench, tighten the camshaft actuator bolt. Tighten the exhaust camshaft position actuator bolt to 30 N.m (22 lb ft) plus 100 degreesusing the EN-45059 meter.
  34. Install the timing chain oiling nozzle. Tighten the timing chain oiling nozzle bolt to 10 N.m (89 lb in).
  35. Apply sealant compound to the thread of the timing chain guide bolt access hole plug. Refer to «Adhesives, Fluids, Lubricants, and Sealers»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-specifications__adhesives-fluids-lubricants-and-sealers) for the recommended sealant.
  36. Install the timing chain guide bolt access hole plug. Tighten the access hole plug to 90 N.m (66 lb ft).
  37. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  38. Install the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  39. Install the number 1 cylinder spark plug. Refer to «Spark Plug Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .

Scheme 91

Scheme 91: Camshaft Cover Replacement
Scheme 91: Camshaft Cover Replacement
CalloutComponent Name
Preliminary Procedures Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement . Remove the ignition coil. Refer to Ignition Coil Replacement . Remove the Charge air cooler inlet air tube. Refer to Charge Air Cooler Inlet Air Tube Replacement Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement Remove the positive crankcase ventilation hose from the turbocharger. Remove the camshaft position actuator sensor intake. Refer to Camshaft Position Actuator Solenoid Valve Replacement (Intake) , Camshaft Position Actuator Solenoid Valve Replacement (Exhaust) Remove the camshaft position actuator sensor exhaust. Refer to Camshaft Position Actuator Solenoid Valve Replacement (Intake) , Camshaft Position Actuator Solenoid Valve Replacement (Exhaust) Remove the Power Brake Booster Pump. Refer to Power Brake Booster Pump Replacement (2.0L)
1Camshaft Cover Fastener (Qty: 11) CAUTION: Refer to Fastener Caution . Procedure A new gasket should be used whenever the cover is removed from the engine assembly. Tighten 10 N.m (89 lb in)
2Camshaft Cover Procedure Disconnect any electrical connectors. Transfer parts as needed.
CAUTION
Refer to Fastener Caution .

Camshaft Cover Replacement

EN-49212 Camshaft Fixer

For equivalent regional tools, refer to Special Tools (LDK, LHU) .

  1. Remove the timing chain tensioner. Refer to «Timing Chain Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Rotate the crankshaft balancer mark (1) to the oil pump housing mark (2).
  3. Remove the camshaft position actuator - exhaust. Refer to «Camshaft Position Exhaust Actuator Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  4. If the adjustment is NOT correct, release the timing chain from camshaft position actuator - intake (1) and rotate counterclockwise the intake camshaft up to the fixing from the EN-49212-2 camshaft fixer (2).
  1. Install the timing chain to the camshaft position actuator - intake.
  2. Install the camshaft position actuator - exhaust. Refer to «Camshaft Position Exhaust Actuator Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) . Count the number of the end to end connectors of the camshaft timing chain between the mark on the intake camshaft drive pulley and the mark on the exhaust camshaft drive pulley. The timing chain must have 29 end to end connectors to guarantee a correct adjustment. During assembly it is necessary to tension the timing chain. Turn the camshaft in clockwise direction to install the exhaust camshaft drive pulley. Install the exhaust camshaft drive pulley and fixes with that fastener in the camshaft.
  3. Fix the exhaust camshaft with the EN-49212-1 camshaft fixer. When complete, check setup over again.
  4. Tighten the camshaft position actuator - intake to 30 N.m (22 lb ft) 100 degrees.
  5. Tighten the camshaft position actuator - exhaust to 30 N.m (22 lb ft) 100 degrees.
  6. Remove EN-49212 camshaft fixer.
  7. Install the timing chain tensioner. Refer to «Timing Chain Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .

J 45027 Tensioner Tool

  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
  2. Remove the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  3. Remove the timing chain tensioner.
  4. Remove the seal from the tensioner.
  1. Inspect the timing chain tensioner. If the timing chain tensioner, O-ring seal, or washer is damaged, replace the timing chain tensioner or O-ring seal as applicable.
  2. Measure the timing chain tensioner assembly from end to end. If the timing chain tensioner is to be replaced, a new tensioner should be supplied in the fully compressed non-active state. A tensioner in the compressed state will measure 72 mm (2.83 in) (a) from end to end. A tensioner in the active state will measure 85 mm (3.35 in) (a) from end to end.
  3. If the timing chain tensioner is not in the compressed state, perform the following steps: Remove the piston assembly from the body of the timing chain tensioner by pulling it out. Install the J 45027-2 (2) into a vise. Install the notch end of the piston assembly into the J 45027-2 (2). Using the J 45027-1 (1), turn the ratchet cylinder into the piston.
  4. Inspect the bore of the tensioner body for dirt, debris, and damage. If any damage appears, replace the tensioner. Clean dirt or debris out with a lint-free cloth.
  5. Install the compressed piston assembly back into the timing chain tensioner body until it stops at the bottom of the bore. Do not compress the piston assembly against the bottom of the bore. If the piston assembly is compressed against the bottom of the bore, it will activate the tensioner, which will then need to be reset again.
  6. At this point the tensioner should measure approximately 72 mm (2.83 in) (a) from end to end. If the tensioner does not read 72 mm (2.83 in) (a) from end to end, repeat steps 3-5.
  7. Inspect to ensure all dirt and debris is removed from the timing chain tensioner threaded hole in the cylinder head.
  8. Install the timing chain tensioner assembly. Tighten the timing chain tensioner to 75 N.m (55 lb ft).
  9. The timing chain tensioner is released by compressing the tensioner 2 mm (0.079 in) which will release the locking mechanism in the ratchet. To release the timing chain tensioner, use a suitable tool with a rubber tip on the end. Feed the tool down through the cam drive chest to rest on the cam chain. Then give a sharp jolt diagonally downwards to release the tensioner.
  10. Install the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  11. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
  1. Remove the camshaft position intake actuator. Refer to «Camshaft Position Intake Actuator Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Mark the bearing caps to ensure they are installed in the original position.
  3. Remove the bearing cap bolts.
  4. Remove the bearing caps.
  5. Remove the intake camshaft (1).
  6. Remove the camshaft roller followers.
  7. Remove the hydraulic element lash adjusters.
  1. Install the hydraulic element lash adjusters into their bores in the cylinder head. Install the camshaft caps and hand start the camshaft cap bolts.
  2. Install the camshaft caps.
  3. Tighten the camshaft cap bolts in increments of 3 turns until they are seated. Tighten the camshaft caps to 10 N.m (89 lb in).
  4. Apply a 3.5 mm bead of sealer to the cylinder head at the number 6 intake camshaft rear cap mating surface. Refer to «Adhesives, Fluids, Lubricants, and Sealers»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-specifications__adhesives-fluids-lubricants-and-sealers) for the recommended sealant.
  5. Install the number 6 intake camshaft rear cap. Tighten the cap bolts evenly to 5 N.m (44 lb in). Tighten the cap bolts evenly a final pass to 10 N.m (89 lb in).
  6. Remove all excess sealing material from the fuel pump roller lifter orifice (1), and ensure the orifice is free of debris.
  7. Remove all excess sealing material from the sealing surfaces.
  8. Install the rear cylinder head opening plate and bolts and tighten to 10 N.m (89 lb in).
  9. Install the camshaft position intake actuator. Refer to «Camshaft Position Intake Actuator Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  1. Remove the camshaft position exhaust actuator. Refer to «Camshaft Position Exhaust Actuator Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Mark the camshaft bearing caps to ensure they are installed in the same position.
  3. Remove the camshaft bearing cap bolts and cap.
  4. Remove the exhaust camshaft.
  5. Remove the valve rocker arms.
  6. Remove the hydraulic valve lash adjusters.
  1. Install the hydraulic valve lash adjusters into their bores in the cylinder head.
  2. Lubricate the hydraulic valve lash adjusters. Refer to «Adhesives, Fluids, Lubricants, and Sealers»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-specifications__adhesives-fluids-lubricants-and-sealers) .
  3. Lubricate the valve tips. Refer to «Adhesives, Fluids, Lubricants, and Sealers»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-specifications__adhesives-fluids-lubricants-and-sealers) .
  4. Position the rocker arms on the tip of the valve stem and on the valve lash adjuster. Lubricate the rocker arms. Refer to «Adhesives, Fluids, Lubricants, and Sealers»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-specifications__adhesives-fluids-lubricants-and-sealers) .
  5. Install the exhaust camshaft. Lubricate the camshaft. Refer to «Adhesives, Fluids, Lubricants, and Sealers»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-specifications__adhesives-fluids-lubricants-and-sealers) .
  6. Position the camshaft bearing caps. Install the bearing cap bolts hand tight.
  7. Tighten the bearing cap bolts in increments of 3 turns until they are seated. Tighten Tighten the bolts to 10 N.m (89 lb in).
  8. Install the camshaft position exhaust actuator. Refer to «Camshaft Position Exhaust Actuator Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  1. «EN-48749»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) Timing Chain Retention Tool Kit
  2. «EN-48953»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) Camshaft Actuator Locking Tool
  3. EN-45059 Angle Meter
  1. Remove the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Remove the spark plugs. Refer to «Spark Plug Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
  3. Rotate the crankshaft clockwise and install the camshaft actuator retainer «EN-48953»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1).
  4. Install the camshaft actuator retainer bolts and tighten to 10 N.m (89 lb in).
  5. Loosen, but DO NOT remove the intake camshaft actuator bolt.
  6. Remove the camshaft actuator locking tool, «EN-48953»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1).
  7. Clean the timing chain and gears with solvent.
  8. Mark the intake and exhaust camshaft actuators and the respective locations on the timing chain.
  9. Remove the upper timing chain guide bolts and guide.
  10. Remove the timing chain tensioner.
  11. Install the timing chain retention tool «EN-48749»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1) to the intake side of the timing chain.
  12. Install the timing chain retention tool «EN-48749»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1) to the exhaust side of the timing chain.
  13. Remove and discard the intake camshaft actuator bolt (2).
  14. Rotate the exhaust camshaft clockwise slightly to take the tension off of the timing chain on the intake actuator.
  15. Remove the intake camshaft actuator (3) from the camshaft while also removing the actuator from the timing chain.
  1. Install the timing chain onto the intake camshaft actuator.
  2. Align the intake camshaft actuator alignment mark made previously with the timing chain mark and install the actuator onto the camshaft rotating the exhaust camshaft clockwise, if required.
  3. Install a NEW intake camshaft actuator bolt (2) until snug.
  4. Remove the timing chain retention tool (1) from the intake side of the timing chain.
  5. Remove the timing chain retention tool (1) from the exhaust side of the timing chain.
  6. Reset and install the timing chain tensioner. Refer to «Timing Chain Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle)
  7. Install the camshaft actuator retainer (1) EN-48953 Camshaft Actuator Locking Tool.
  8. Install the camshaft actuator retainer bolts and tighten to 10 N.m (89 lb in).
  9. Tighten the NEW camshaft actuator bolt to 30 N.m (22 lb ft) plus an additional 100 degreesusing the EN-45059 Angle Meter.
  10. To release the tensioner apply a counterclockwise rotational torque to the crankshaft balancer bolt of 45 N.m (33 lb ft).
  11. Remove the camshaft actuator retainer «EN-48953»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1).
  12. Install the upper timing chain guide and bolts and tighten to 10 N.m (89 lb in).
  13. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
  14. Install the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  1. «EN-48749»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) Timing Chain Retention Tool Kit
  2. «EN-48953»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) Camshaft Actuator Locking Tool
  3. EN-45059 Angle Meter
  1. Remove the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Remove the spark plugs. Refer to «Spark Plug Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
  3. Rotate the crankshaft clockwise and install the camshaft actuator retainer «EN-48953»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1).
  4. Install the camshaft actuator retainer bolts and tighten to 10 N.m (89 lb in).
  5. Loosen, but do not remove the exhaust camshaft actuator bolt.
  6. Clean the timing chain and gears with solvent.
  7. Mark the intake and exhaust camshaft actuators and the respective locations on the timing chain.
  8. Remove the upper timing chain guide bolts and guide.
  9. Remove the timing chain tensioner.
  10. Install the timing chain retention tool «EN-48749»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1) to the exhaust side of the timing chain.
  11. Remove and discard the exhaust camshaft actuator bolt (2).
  12. Remove the exhaust camshaft actuator (3) from the camshaft while also removing the actuator from the timing chain.
  1. Install the timing chain onto the exhaust camshaft actuator.
  2. Align the exhaust camshaft actuator alignment mark made previously with the timing chain mark and install the actuator onto the camshaft.
  3. Install a NEW exhaust camshaft actuator bolt (2) until snug.
  4. Remove the timing chain retention tool «EN-48749»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1) from the exhaust side of the timing chain.
  5. Reset and install the timing chain tensioner. Refer to «Timing Chain Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  6. Install the intake camshaft actuator retainer (1).
  7. Install the camshaft actuator retainer bolts and tighten 10 N.m (89 lb in).
  8. Tighten the NEW camshaft actuator bolt to 30 N.m (22 lb ft) plus an additional 100 degreesusing the EN-45059 Angle meter.
  9. To release the tensioner apply a counterclockwise rotational torque to the crankshaft balancer bolt of 45 N.m (33 lb ft).
  10. Remove the camshaft actuator retainer «EN-48953»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-24l) (1).
  11. Install the upper timing chain guide and bolts and tighten to 10 N.m (89 lb in).
  12. Install the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  13. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
  1. EN-38188 Cylinder Head Broken Bolt Extractor Kit
  2. EN-45059 Angle Meter

For equivalent regional tools, refer to Special Tools (LDK, LHU) .

  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
  2. Drain the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (GE 47716)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  3. Remove the camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle)
  4. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  5. Remove the exhaust manifold. Refer to «Exhaust Manifold Replacement (LDK or LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system) .
  6. Remove the camshaft timing chain. Refer to «Camshaft Timing Chain, Sprocket, and Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  7. Remove the cylinder head bolts opposite to the block fastener sequence.
  8. Remove the cylinder head (1) and the cylinder head gasket (2) from the block.
  9. Clean all of the gasket surfaces. Refer to «Cylinder Head Cleaning and Inspection (LDK, LHU)»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-off-vehicle)
  1. Install the cylinder head gasket (1) to the cylinder block (2). On right side pay attention to the cylinder head lock pin (3).
  2. Ensure the number 1 cylinder is at top dead center (TDC). Setting up the crankshaft balancer mark (1) to the oil pump housing mark (2).
  3. Install the cylinder head.
  4. Install NEW cylinder head fasteners. Tighten the fastener in sequence to 30 N.m (22 lb ft). Tighten the fastener in additional 155 degreesin sequence using the EN-45059 angle meter.
  5. Install the front cylinder head fastener (1) and tighten to 35 N.m (26 lb ft).
  6. Install camshaft timing chain. Refer to «Camshaft Timing Chain, Sprocket, and Tensioner Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  7. Install the exhaust manifold. Refer to «Exhaust Manifold Replacement (LDK or LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system) .
  8. Install the intake manifold. Refer to «Intake Manifold Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  9. Install camshaft cover. Refer to «Camshaft Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle)
  10. Fill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (GE 47716)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  11. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .

Scheme 92

Scheme 92: Engine Oil Cooler Replacement
Scheme 92: Engine Oil Cooler Replacement
CalloutComponent Name
Primarily procedure Remove the Radiator Outlet Hose. Refer to Radiator Outlet Hose Replacement (LHU) . Remove the Radiator Surge Tank Inlet Hose. Refer to Radiator Surge Tank Inlet Hose Replacement (LEA) .
1Engine oil cooler fastener (Qty, 3) CAUTION: Refer to Fastener Caution . Tighten 22 N.m (16 lb ft)
2Engine oil cooler Procedure Disconnect electrical connector as needed. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Engine Oil Cooler Replacement

Scheme 93

Scheme 93: Oil Pan Replacement
Scheme 93: Oil Pan Replacement
CalloutComponent Name
Preliminary Procedure Drain the oil. Refer to Engine Oil and Oil Filter Replacement . Remove the oil level indicator Tube. Refer to Oil Level Indicator Tube Replacement . Remove the air conditioning compressor bracket. Refer to Air Conditioning Compressor Bracket Replacement . Remove the catalytic converter bracket. Refer to Catalytic Converter Brace Replacement (LDK OR LHU) .
1Oil Pan Fastener (Qty: 15) NOTE: The lower crankcase surface must be free of contamination prior to applying the sealer. Install and align the oil pan to block within 20 minutes of applying the sealer. The oil pan must be fastened to final torque specification within 60 minutes of applying the sealer. Procedure Before removing the oil pan note the location of the bolts. Ensure to clean and inspect the oil. Refer to Oil Pan Cleaning and Inspection (LDK, LHU) . Apply a 2.25 mm bead of sealer (1) on the level part of the flange next to the chamfer around the perimeter of the oil pan and the oil suction port opening. Refer to Adhesives, Fluids, Lubricants, and Sealers . Follow the tighten bolt sequence. Tighten 25 N.m (18 lb ft)
2Oil Pan Procedure Disconnect electrical connectors as needed. Transfer components as necessary.
NOTE
The lower crankcase surface must be free of contamination prior to applying the sealer. Install and align the oil pan to block within 20 minutes of applying the sealer. The oil pan must be fastened to final torque specification within 60 minutes of applying the sealer.

Oil Pan Replacement

Scheme 94

Scheme 94: Crankshaft Rear Oil Seal Replacement
Scheme 94: Crankshaft Rear Oil Seal Replacement
CalloutComponent Name
Preliminary Procedure Remove the flywheel. Refer to Engine Flywheel Replacement .
1Crankshaft Rear Oil Seal Procedure Use flat-bladed tool to remove the seal. Use the EN-42027 installer and install a NEW crankshaft real oil seal. Transfer components as necessary. Special Tools EN-42067 Rear Main Seal Installer For equivalent regional tools, refer to Special Tools (LDK, LHU) .

Crankshaft Rear Oil Seal Replacement

Scheme 95

Scheme 95: Engine Flywheel Replacement
Scheme 95: Engine Flywheel Replacement
CalloutComponent Name
Preliminary Procedure Remove the transmission. Refer to Transmission Replacement .
1Flywheel Fastener (Qty: 8) CAUTION: Refer to Fastener Caution . Procedure Install the EN-43653 Flywheel Holding Tool. Clean the thread adhesive from the flywheel bolt holes. Use a nylon bristle brush to clean the holes in the crankshaft. Ensure to use NEW bolt whenever removing the flywheel. Tighten 53 N.m (39 lb ft) plus an additional 25 degrees Special Tools EN-43653 Flywheel Holding Tool For equivalent regional tools, refer to Special Tools (LDK, LHU) .
2Flywheel Spacer
3Flywheel Procedure Clean and inspect the flywheel. Refer to Engine Flywheel Cleaning and Inspection . If the flywheel teeth are damaged, inspect the starter for proper operation. Replace the starter if you find excessive wear or damage to the starter drive. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Engine Flywheel Replacement

  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions__fuel-pressure-relief) .
  2. Recover the refrigerant from the air conditioning system. Refer to «Refrigerant Recovery and Recharging»(/buick/regal/v-2009-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging)
  3. Remove the front bumper fascia. Refer to «Front Bumper Fascia Replacement»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
  4. Remove the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  5. Disconnect the fuel feed pipe quick connect fitting at the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  6. Remove the fuel feed pipe clip from the fuel line bracket.
  7. Remove the transaxle shift cable clip from the fuel line bracket.
  8. Remove the battery tray. Refer to «Battery Tray Replacement»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
  9. Remove the vacuum brake booster hose from the intake manifold.
  10. Disconnect all necessary electrical connectors to remove engine from vehicle.
  11. Remove the coolant recovery inlet pipe clip from the fuel rail.
  12. Disconnect the coolant recovery inlet hose from the engine.
  13. Disconnect the radiator inlet hose from the engine. Refer to «Radiator Inlet Hose Replacement (LHU)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  14. Disconnect the radiator outlet hose from the engine. Refer to «Radiator Outlet Hose Replacement (LHU)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  15. Remove the heater inlet and outlet hoses from the thermostat housing.
  16. Remove the charge air cooler inlet air tube from the engine. Refer to «Charge Air Cooler Inlet Air Tube Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  17. Remove the charge air cooler outlet air tube from the engine. Refer to «Charge Air Cooler Outlet Pipe Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  18. Remove the coolant recovery reservoir/heater inlet hose (4) from the thermostat housing.
  19. Disconnect the transmission fluid cooler hose. Refer to «Transmission Fluid Cooler Hose Replacement»(/buick/regal/v-2009-2013/remont/automatic-trans/#automatic-transmission-af40-6)
  20. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/regal/v-2009-2013/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  21. Using spray paint, mark the location of the frame to body for correct alignment during installation.
  22. Drain the engine oil. Refer to «Engine Oil and Oil Filter Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  23. Disconnect the engine wiring harness electrical connector from the air conditioning (A/C) compressor.
  24. Remove the positive battery cable from the starter motor.
  25. Disconnect the generator electrical connectors.
  26. Lower the vehicle.
  27. Remove the transaxle shift cable from the range select lever.
  28. Release the shift control cable retaining clip and remove the cable from the shift control cable bracket.
  29. Using long tie straps, secure the radiator/condenser/fan assembly to the radiator support.
  30. Raise the vehicle.
  31. Remove the front wheels and tires. Refer to «Tire and Wheel Removal and Installation»(/buick/regal/v-2009-2013/remont/wheel-tire-system/#tires-and-wheels) .
  32. Drain the transaxle fluid.
  33. Remove the exhaust front pipe. Refer to «Exhaust Front Pipe Replacement (LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Front Pipe Replacement (LDK or LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system)
  34. Remove the intermediate to steering gear pinch bolt and disconnect the intermediate shaft from the steering gear. Discard the pinch bolt.
  35. Remove the left and right wheel drive shafts. Refer to «Front Wheel Drive Shaft Replacement - Left Side (GNA)»(/buick/regal/v-2009-2013/remont/axle-shafts/#wheel-drive-shafts) , and «Front Wheel Drive Shaft Replacement - Right Side (GNA)»(/buick/regal/v-2009-2013/remont/axle-shafts/#wheel-drive-shafts) .
  36. Lower the vehicle.
  37. Remove the engine mount to bracket bolts (1).
  38. Remove the transaxle mount to transaxle bolts.
  39. Raise the vehicle.
  40. Position a engine support table under the powertrain assembly.
  41. With the table positioned, fully raise the table to contact the powertrain assembly.
  42. Remove the frame to body bolts. Discard the bolts.
  43. Lower the engine table and raise the body on the hoist until the engine/transaxle and frame are free from the vehicle.
  44. Disconnect the engine wiring harness electrical connectors as necessary.
  45. Remove the starter motor bolts and starter.
  46. Remove the torque converter to flexplate bolts (1).
  47. Install a suitable lifting device to the engine.
  48. Remove the transaxle bolts (2) from the engine.
  49. Separate the engine from the transaxle (1).
  50. Install the engine to a suitable engine stand.
  1. Install a suitable lifting device to the engine.
  2. Using the lifting device, position and install the engine to the transaxle (1).
  3. Install the transaxle bolts (2) to the engine and tighten to 75 N.m (55 lb ft).
  4. Install the torque converter to flexplate bolts (1) and tighten to 60 N.m (44 lb ft).
  5. Remove the engine lifting device.
  6. Install the starter motor and bolts and tighten to 53 N.m (39 lb ft).
  7. Position the powertrain and support table under the vehicle.
  8. Raise the powertrain into position under the vehicle.
  9. With the table positioned, if required, lower the vehicle over the powertrain.
  10. Align the lower radiator pins with the frame. Ensure all hoses and electrical harnesses are correctly routed and free from the loading path of the powertrain.
  11. Install the NEW frame to body bolts and tighten to 155 N.m (114 lb ft).
  12. Lower the vehicle.
  13. Install the transaxle mount to transaxle bolts and tighten to 55 N.m (41 lb ft).
  14. Install the engine mount to bracket bolts (1) and tighten to 50 N.m (37 lb ft).
  15. Raise and support the vehicle.
  16. Install the left and right wheel drive shafts. Refer to «Front Wheel Drive Shaft Replacement - Left Side (GNA)»(/buick/regal/v-2009-2013/remont/axle-shafts/#wheel-drive-shafts) , and «Front Wheel Drive Shaft Replacement - Right Side (GNA)»(/buick/regal/v-2009-2013/remont/axle-shafts/#wheel-drive-shafts) .
  17. Position the intermediate shaft to the steering gear and install a NEW pinch bolt and tighten to 34 N.m (25 lb ft).
  18. Install the exhaust front pipe. Refer to «Exhaust Front Pipe Replacement (LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system) , «Exhaust Front Pipe Replacement (LDK or LHU)»(/buick/regal/v-2009-2013/remont/exhaust/#engine-exhaust-system)
  19. Install the front wheels and tires. Refer to «Tire and Wheel Removal and Installation»(/buick/regal/v-2009-2013/remont/wheel-tire-system/#tires-and-wheels) .
  20. Lower the vehicle.
  21. Unsecure and position the radiator/condenser/fan assembly.
  22. Install the charge air cooler inlet air tube to the engine and the air charge cooler. Refer to «Charge Air Cooler Inlet Air Tube Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  23. Install the charge air cooler outlet air tube to the engine and the air charge cooler. Refer to «Charge Air Cooler Outlet Pipe Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  24. Install the shift control cable to the shift control cable bracket and engage the shift control cable retaining clip.
  25. Install the transaxle shift cable to the range select lever.
  26. Raise and support the vehicle.
  27. Connect the generator electrical connectors.
  28. Install the positive battery cable to the starter motor, tighten to 9 N.m (80 lb in)
  29. Position the A/C compressor and install the bolts and tighten to 50 N.m (37 lb ft).
  30. Connect the engine wiring harness electrical connector to the A/C compressor.
  31. Lower the vehicle.
  32. Connect the engine wiring harness electrical connectors as necessary.
  33. Install the coolant recovery reservoir/heater inlet hose to the thermostat housing.
  34. Connect the radiator inlet hose to the engine. Refer to «Radiator Inlet Hose Replacement (LHU)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  35. Connect the radiator outlet hose to the engine. Refer to «Radiator Outlet Hose Replacement (LHU)»(/buick/regal/v-2009-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
  36. Install the heater inlet and outlet hoses to the thermostat housing.
  37. Position and install the coolant recovery inlet hose to the cylinder head.
  38. Install the coolant recovery inlet pipe clip to the fuel rail.
  39. Position and install the vacuum brake booster hose to the intake manifold.
  40. Install the battery tray. Refer to «Battery Tray Replacement»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
  41. Install the transaxle shift cable clip to the fuel line bracket.
  42. connect the transmission fluid cooler hose. Refer to «Transmission Fluid Cooler Hose Replacement»(/buick/regal/v-2009-2013/remont/automatic-trans/#automatic-transmission-af40-6)
  43. Install the fuel feed pipe clip to the fuel line bracket.
  44. Connect the fuel feed pipe quick connect fitting at the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions) .
  45. Install the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-20l-repair-instructions) .
  46. Fill the transaxle with fluid. Refer to «Transmission Fluid Level and Condition Check»(/buick/regal/v-2009-2013/remont/automatic-trans/#automatic-transmission-af40-6__transmission-fluid-level-and-condition-check) .
  47. Refill the engine with oil. Refer to «Engine Oil and Oil Filter Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  48. Recharge the air conditioning system. Refer to «Refrigerant Recovery and Recharging»(/buick/regal/v-2009-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging)
  49. Install the front bumper fascia. Refer to «Front Bumper Fascia Replacement»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bumpers-and-fascias) .
  50. Perform the CKP system variation learn procedure. Refer to «Crankshaft Position System Variation Learn»(/buick/regal/v-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-24l-repair-instructions__crankshaft-position-system-variation-learn) .
  51. Start the engine and allow the engine to run, inspect for leaks. Correct as necessary.

Special Tools

EN-44887 Oil Filter Wrench

For equivalent regional tools, refer to Special Tools (LDK, LHU) .

  1. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .
  2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/regal/v-2009-2013/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Place a drain pan under the oil drain plug.
  4. Remove the oil pan drain plug.
  5. Allow the oil to drain completely.
  6. Install the oil pan drain plug and tighten to 25 N.m (18 lb ft).
  7. Lower the vehicle.
  8. Use EN-44887 wrench to remove the oil filter cap (1).
  9. Remove the oil filter (2) from the cap and discard.
  10. Clean the oil filter housing in the engine block.
  1. Install a new oil filter (2) on the oil filter cap (1).
  2. Lubricate the oil filter cap O-ring with engine oil.
  3. Use the EN-44887 wrench to install the oil filter and cap. Tighten the oil filter cap until fully seated. DO NOT exceed 22 N.m (16 lb ft).
  4. Fill the engine with oil. Refer to «Fluid and Lubricant Recommendations»(/buick/regal/v-2009-2013/remont/lubrication-system/#maintenance-and-lubrication__fluid-and-lubricant-recommendations) .
  5. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(/buick/regal/v-2009-2013/remont/mechanical/#engine-mechanical-20l-repair-instructions-on-vehicle) .

See also:
• Fastener Caution
• Engine Mount Replacement
• Special Tools (LDK, LHU)
• Air Cleaner Assembly Replacement
• Lifting and Jacking the Vehicle
• Cooling System Draining and Filling (Static Fill)
• Air Cleaner Outlet Duct Replacement
• Catalytic Converter Replacement (LDK or LHU)
• Fuel Pressure Relief
• Intake Manifold Cleaning and Inspection (LDK, LHU)
• Crankshaft Front Oil Seal Installation (LDK, LHU)
• Adhesives, Fluids, Lubricants, and Sealers
• Power Brake Booster Pump Replacement (2.0L)
• Battery Negative Cable Disconnection and Connection
• Cylinder Head Cleaning and Inspection (LDK, LHU)
• Air Conditioning Compressor Bracket Replacement
• Oil Pan Cleaning and Inspection (LDK, LHU)
• Transmission Replacement
• Engine Flywheel Cleaning and Inspection
• Refrigerant Recovery and Recharging
• Front Bumper Fascia Replacement
• Transmission Fluid Cooler Hose Replacement
• Tire and Wheel Removal and Installation
• Front Wheel Drive Shaft Replacement - Left Side (GNA)
• Transmission Fluid Level and Condition Check
• Crankshaft Position System Variation Learn
• Fluid and Lubricant Recommendations
• Drive Belt Replacement

More articles — Engine
