Collision Repair Buick Regal V

Fastener Tightening Specifications

Fastener Tightening Specifications

Point to Point Measurements

Point-to-point measurements are for reference only. All measurements are given in millimeters. Use these measurements for diagnosing and estimating. Point-to-point measurements are duplicated with tram bar pointers set at equal lengths. All the marks, holes, slots, and fasteners are measured to the center. All dimensions are symmetrical unless otherwise specified

Scheme 51

Scheme 52

Scheme 53

Structure Identification

Number Description Material Procedure 1 Front Compartment Upper Side Rail Mild Steel Front Compartment Upper Side Rail Replacement 2 Front Wheelhouse Mild Steel Front Wheelhouse Panel Replacement Front Wheelhouse Front Panel Replacement 3 Outer Bodyside Panel Mild Steel Quarter Outer Panel Sectioning Center Pillar Sectioning - Outer 4 Roof Outer Panel Mild Steel Roof Outer Panel Replacement 5 Rear Compartment Panel Mild Steel Rear Floor Panel Sectioning 6 Rear End Panel Mild Steel Body Rear End Panel Replacement 7 Rear Inner Wheelhouse Mild Steel Rear Wheelhouse Inner Panel Replacement 8 Rear Inner Wheelhouse High Strength Low Alloy Steel Underbody Rear Side Rail Replacement 9 Rear Inner Wheelhouse Ultra High Strength Steel Not Serviced 10 Rear Inner Wheelhouse Mild Steel Rear Side Door Outer Panel Replacement 11 Rear Inner Wheelhouse Mild Steel Front Side Door Outer Panel Replacement 12 Rear Inner Wheelhouse Ultra High Strength Steel Not Serviced 13 Rear Inner Wheelhouse Ultra High Strength Steel Center Pillar Reinforcement Replacement 14 Rear Inner Wheelhouse Ultra High Strength Dual Phase Steel Rocker Inner Panel Reinforcement Replacement 15 Rear Inner Wheelhouse Dual Phase Steel Underbody Outer Front Side Rail Replacement 16 Rear Inner Wheelhouse High Strength Low Alloy Steel Mild Steel Front Hinge Pillar Body Sectioning Body Hinge Pillar Lower Reinforcement Replacement

Overlap/Backing Plate Sectioning (Welding)

1. Fit the service panel to the vehicle to ensure a proper fit.
2. Measure and mark a line at the sail panel 120 mm (4 3/4 in) from the back glass opening and 70 mm (2 3/4 in) rearward from the rocker panel locating hole edge of the service panel.
3. Cut along the line to trim the service panel.
4. Fabricate a 50 mm (2 in) backer plate so that the panel will fit behind the sectioning joint at the sail panel.
5. Fabricate a 100 mm (4 in) backer plate for the rocker panel.
6. Drill 8 mm (5/16 in) plug weld holes as necessary in the locations noted from the original panel.
7. Bevel the sail panel and service panel edges at the sectioned area to approximately 10 degrees.
8. Grind a 50 mm (2 in) area of the outer surface on the vehicle to remove any corrosion, E-coat, primers, coatings and galvanizing that may be present.
9. At the section area on the service panel, grind a 50 mm (2 in) area of the back side to remove any corrosion, E-coat, primers, coatings and galvanizing that may be present.
10. Drill plug weld holes approximately 13 mm (1/2 in) from the edge of the cuts the sectioning areas of the service panel and the original panel.
11. Prepare all mating surfaces as necessary.
12. Apply GM-approved weld-thru coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
13. Position and clamp or screw the backer plate with half of the backer plate exposed at the sectioning joint.
14. Position the service panel to overlap the backer plate and 1 1/2 times the thickness up to the original panel.
15. Check for proper fit and alignment to the vehicle. Clamp the panels together.
16. Plug weld the backer plate accordingly.
17. Stitch weld along the entire sectioning joint, make 25 mm (1 in) welds along the seam with 25 mm (1 in) gaps between them.
18. Complete the stitch weld.
19. Clean and prepare all welded surfaces of the entire sectioning joint.
20. Apply a lightweight body filler to the backer plate area.

Removal Procedure

1. Disable the SIR System. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components.
4. Remove the 4 front bumper energy absorber fastener (1).
5. Locate and mark all factory welds.
6. Drill all factory welds.
7. Remove the front bumper energy absorber.

Scheme 54

1. Position the front bumper energy absorber on the vehicle. CAUTION: Refer to «Fastener Caution»(/buick/regal/v-2009-2013/remont/oem-general-information/#dangers-warnings-and-cautions__fastener-caution) . NOTE: Use only the original front bumper energy absorber fastener. Replace fastener if damaged.
2. Install the 4 front bumper energy absorber fasteners (1) and tighten to the front compartment front inner side rail 115 N.m (85 lb ft).
3. Drill two holes (1) 6 mm (0.24 in)along the edges of the front bumper energy absorber.
4. Drill two holes (1) 6 mm (0.24 in)along the edges of the front bumper energy absorber.
5. Install the 2 front end upper tie bar fasteners (1) and tighten to the front compartment front inner side rail 22 N.m (16 lb ft).
6. Install the 2 front end upper tie bar fasteners (1) and tighten to the front compartment front inner side rail 22 N.m (16 lb ft).
7. Paint the repaired area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
8. Install all related panels and components.
9. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
10. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR System. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Inspect the high voltage system. Refer to «HIGH VOLTAGE SYSTEM INSPECTION»(/buick/regal/v-2009-2013/remont/body-electrical/#hybridev-energy-storage-system__high-voltage-system-inspection)
3. Disable the high voltage system. Refer to «HIGH VOLTAGE DISABLING»(/buick/regal/v-2009-2013/remont/body-electrical/#hybridev-energy-storage-system__high-voltage-disabling)
4. Remove all related panels and components.
5. Position the front bumper energy absorber on the vehicle. CAUTION: Refer to «Fastener Caution»(/buick/regal/v-2009-2013/remont/oem-general-information/#dangers-warnings-and-cautions__fastener-caution) . NOTE: Use only the original front bumper energy absorber fastener. Replace fastener if damaged.
6. Install the 4 front bumper energy absorber fasteners (1) and tighten to the front compartment front inner side rail 115 N.m (85 lb ft).
7. Drill two holes (1) 6 mm (0.24 in)along the edges of the front bumper energy absorber.
8. Drill two holes (1) 6 mm (0.24 in)along the edges of the front bumper energy absorber.
9. Install the 2 front end upper tie bar fasteners (1) and tighten to the front compartment front inner side rail 22 N.m (16 lb ft).
10. Install the 2 front end upper tie bar fasteners (1) and tighten to the front compartment front inner side rail 22 N.m (16 lb ft).
11. Paint the repaired area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
12. Install all related panels and components.
13. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
14. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 55

1. Disable the SIR System. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling)
2. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid)
3. Remove all related panels and components
4. Visually inspect the damage. Repair as much of the damage as possible
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Locate and mark all the necessary factory welds of the front wheelhouse front panel (1).
7. Drill all factory welds. Note the number and location of welds for installation of the service assembly
8. Remove the front wheelhouse front panel

Scheme 56

Scheme 57

Scheme 58

1. Drill 8 mm (5/16 in) for plug welding along the edges of the front wheelhouse front panel as noted from the original panel (1).
2. Clean and prepare the attaching surfaces for welding.
3. Position the front wheelhouse front panel on the vehicle (1)
4. Verify the fit of the front wheelhouse front panel
5. Clamp the front wheelhouse front panel into position
6. Plug weld accordingly (1).
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
8. Paint the repaired area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
9. Install all related panels and components.
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
4. Repair as much of the damage as possible.
5. Locate, mark, and drill out all factory welds (1). Note the number and location of welds for installation of the service assembly.
6. Remove the front wheelhouse from the vehicle.

Installation Procedure

1. Drill 8 mm (5/16 in) plug weld holes as necessary on service part, in the locations noted from the original assembly (1).
2. Clean and prepare the mating surfaces for welding, as necessary.
3. Apply GM-approved weld-thru coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
4. Position the service front wheelhouse to the vehicle using 3-dimensional measuring equipment (1). Clamp the front wheelhouse in place.
5. When the service assembly is correctly positioned, plug weld accordingly (1).
6. Measure frequently to ensure proper fit and alignment.
7. Clean and prepare all welded surfaces.
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
9. Paint the repaired area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
10. Install all related panels and components.
11. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
12. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 59

Scheme 60

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: Do not damage any inner panels or reinforcements
6. Locate and drill out all factory welds. Note the number and location of the welds for installation of the front upper rail (1)
7. Remove the damaged front upper rail (1).

Scheme 61

Note. If you cannot determine the location of the original plug weld holes, space the plug weld holes every 40 mm (11/2 in) apart.

1. Drill 8 mm (5/16 in) plug weld holes in the service part as necessary in the locations noted from the original panel (1).
2. Prepare all mating surfaces as necessary
3. Apply 3M Weld-Thru Coating P/N 05916 or equivalent to all mating surfaces
4. Position the front upper rail on the vehicle using 3-dimensional measuring equipment. Clamp the rail in place (1).
5. Plug weld accordingly (1).
6. Clean and prepare all welded surfaces
7. Install all related panels and components
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
9. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 62

Scheme 63

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove the front compartment upper side rail. Refer to «Front Compartment Upper Side Rail Replacement»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
4. Remove the headlamp mount panel
5. Remove the front wheelhouse. Refer to «Front Wheelhouse Panel Replacement»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
6. Visually inspect the damage. Repair as much of the damage as possible
7. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: Record the number and location of the factory welds for installation of the front compartment front half rail.
8. Locate and drill out all the necessary factory welds (1).
9. Remove the damaged front compartment front half rail (1).

Scheme 64

Scheme 65

Scheme 66

1. Drill out necessary factory welds on the full service assembly (1) where the front compartment front half rail attaches (2), to the full rail service assembly NOTE: If the location of the original plug weld holes cannot be determined, space the plug weld holes every 40 mm (11/2 in) apart.
2. Drill 8 mm (5/16 in) plug weld holes in the service part (1) as necessary in the locations noted from the original panel.
3. Prepare all matting surfaces for welding as necessary
4. Apply GM-approved Weld-Thru Coating or equivalent to all matting surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Clean and prepare the attaching surfaces for welding.
6. Position the front compartment front half rail on the vehicle (1).
7. Verify the fit of the front compartment front half rail
8. Clamp the front compartment front half rail into position
9. Plug weld accordingly (1).
10. Clean and prepare all of the welded surfaces
11. Install all of the related panels and components
12. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
13. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
14. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
15. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Underbody Outer Front SIde Rail Replacement

Scheme 67

Scheme 68

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: Record the number and location of the factory welds for installation of the front compartment front half rail. NOTE: Note the number and location of the factory welds for installation of the outer rail
6. Locate and drill out all the necessary factory welds (1).
7. Remove the outer rail from the vehicle (1).

Note. If the location of the original plug weld holes can not be determined, space the plug weld holes every 40 mm (11/2 in) apart

1. Drill 8 mm (5/16 in) plug weld holes in the service part as necessary in the locations noted from the original panel (1).
2. Prepare all mating surfaces as necessary
3. Apply GM-approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
4. Position the outer rail to the vehicle using 3-dimensional measuring equipment. Clamp the outer rail in place (1).
5. Plug weld accordingly (1).
6. Clean and prepare all of the welded surfaces
7. Install all of the related panels and components
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
9. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Sectioning should be performed only in the recommended areas. Failure to do so may compromise the structural integrity of the vehicle.

The body side outer panels are available in one-piece side frames. You can perform any one of these replacement procedures separately or in any combination, depending upon the extent of damage to the vehicle. Sectioning must take place in specified areas only. Stay away from the door and window opening radius areas. Perform sectioning only in straight areas of the openings.

Scheme 69

Scheme 70

Scheme 71

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. On the "A" Pillar Measure down 120 mm from the door wiring conduit hole lower edge (1). Mark this cut location on the front hinge pillar (2). Mark a cut location in the straight area on the rocker panel (3).
7. Cut the front hinge pillar body where sectioning is to be performed (1).
8. Locate and mark all the necessary factory welds of the front hinge pillar body
9. Drill out all factory welds (1).
10. Remove the damaged front hinge pillar body

Scheme 72

Scheme 73

Scheme 74

Scheme 75

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1).
2. Drill 8 mm (5/16 in) plug weld holes along the sectioning area in the service part, and at the locations noted from the original panel and along sectioned joint (1).
3. Prepare all matting surfaces as necessary.
4. Apply 3M Weld-Thru Coating P/N 05916 or equivalent to all matting surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Position the outer front pillar to the vehicle using 3-dimensional measuring equipment (1). Clamp the pillar in place
6. Plug weld accordingly (1).
7. To create a solid weld with minimum heat distortion, make a 25 mm (1 in) stitch welds along the seam with 25 mm (1 in) gaps between them. Then go back and complete the stitch weld (2).
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
9. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
10. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
11. Install all of the related panels and components
12. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
13. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Sectioning should be performed only in the recommended areas. Failure to do so may compromise the structural integrity of the vehicle

The body side outer panels are available in one-piece side frames. You can perform any one of these replacement procedures separately or in any combination, depending upon the extent of damage to the vehicle. Sectioning must take place in specified areas only. Stay away from the door and window opening radius areas. Perform sectioning only in straight areas of the openings.

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. On the "A" Pillar Measure down 300 mm from the roof edge (1). Mark this cut location on the front hinge pillar (2). Mark a cut location in the straight area on the rocker panel (3).
7. Cut the front hinge pillar body where sectioning is to be performed (1).
8. Locate and mark all the necessary factory welds of the front hinge pillar body NOTE: Record the number and location of welds for installation of the service assembly
9. Drill out all factory welds (1) The Upper Outer Rail will need to be removed to locate 4 hidden welds on Hinge Pillar Reinforcement
10. Remove the damaged front hinge pillar body (1).

Scheme 80

Scheme 81

Scheme 82

Scheme 83

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1).
2. Drill 8 mm (5/16 in) plug weld holes in the service part (1), as necessary, in the corresponding locations noted on the original panel and along sectioned joint.
3. Prepare all mating surfaces as necessary.
4. Apply GM approved Weld-Thru Coating or equivalent to all matting surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Position the outer front pillar to the vehicle using 3-dimensional measuring equipment (1). Clamp the pillar in place
6. Plug weld accordingly (1).
7. To create a solid weld with minimum heat distortion, make 25 mm (1 in) stitch welds along the seam with 25 mm (1 in) gaps between them. Then go back and complete the stitch weld (1).
8. Clean and prepare all of the welded surfaces
9. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
10. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
11. Install all of the related panels and components
12. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
13. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 84

Scheme 85

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components
3. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Section body side outer-hinge pillar area. Refer to «Front Hinge Pillar Body Sectioning»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
6. Locate and mark all the necessary factory welds of the body hinge pillar lower reinforcement (1).
7. Drill all factory welds. Note the number and location of welds for installation of the service assembly
8. Remove the damaged body hinge pillar lower reinforcement (1).

Scheme 86

Scheme 87

1. Prepare all mating surfaces as necessary
2. Drill 8 mm (5/16 in)for plug welding along the edges of the body hinge pillar lower reinforcement (1) as noted from the original panel.
3. Clean and prepare the attaching surfaces for welding
4. Position the body hinge pillar lower reinforcement (1) on the vehicle
5. Verify the fit of the body hinge pillar lower reinforcement
6. Clamp the body hinge pillar lower reinforcement into position
7. Plug weld the body hinge pillar lower reinforcement (1) accordingly
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
9. Install the bodyside outer hinge pillar section. Refer to «Front Hinge Pillar Body Sectioning»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
10. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
11. Install all of the related panels and components
12. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Use care when cutting to protect adjacent panels. Cut inboard of the side frame structure

Scheme 88

Scheme 89

Scheme 90

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Locate and mark all factory welds in the front and rear window openings.
7. Drill all factory welds (1). Note the number and location of welds for installation of the service assembly.
8. On the side rail area of the roof use a cut off wheel or equivalent to cut the panel 30 mm inboard of the roof edge (1).
9. Remove the center portion of the panel
10. To separate the remaining portion of the panel use a cut off wheel or equivalent to grind out the MIG braze joint (1).
11. Remove the remaining portion of the original panel

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

1. Dry fit the service panel to the vehicle
2. Clamp the panel into position in the rear window opening (1). Adjust the bow of the roof front to rear. Clamp in place in the windshield opening area (2).
3. With the service panel clamped in position drill a 3.2 mm (1/8 in) hole in each corner of the panel in the front and rear window openings (1).
4. Remove the service panel from the vehicle
5. Prepare the roof rail area of the vehicle with a Rol-lock abrasive wheel or equivalent (1).
6. Clean and prepare the front and rear window attaching surfaces for welding. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
7. Prepare the roof side rail bond areas. Refer to adhesive manufacturers preparation instructions
8. Apply Fusor super flexible anti-flutter foam fast set (1), or equivalent, to the roof bows in the locations noted from the original panel
9. Apply a 12 mm (1/2 in) bead of metal panel bonding adhesive Metal Panel Bonding to the left and right roof rails (1).
10. With the help of a second person lower the service panel straight down onto the vehicle NOTE: This step will insure the proper location and contour to the vehicle
11. Insert an awl or equivalent tool into the four holes drilled in the window openings in step 3 (1).
12. Clamp the roof in place in the front and rear window openings
13. Clean up the excess urethane from the surface.
14. Install 25 mm (1 in) wide ratchet strap or equivalent across the roof inboard of the bond area (1). Apply light even pressure to the bond area
15. Allow adhesive to completely cure per manufacturers instructions. Remove the ratchet straps.
16. Plug weld accordingly (1). Weld the four holes used for alignment
17. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
18. Use a high quality seam sealer to fill the gap between the outer roof panel and the body side roof rail. Follow the manufacturers instructions
19. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
20. Install all of the related panels and components
21. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
22. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 99

Scheme 100

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components WARNING: Refer to «Approved Equipment for Collision Repair Warning»(/buick/regal/v-2009-2013/remont/oem-general-information/#dangers-warnings-and-cautions__approved-equipment-for-collision-repair-warning) . NOTE: Failure to replace any damaged reinforcement as described could compromise the structural integrity of the vehicle
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: The inner reinforcement is a high strength steel and cannot be sectioned or altered
5. Drill out factory welds (1). NOTE: Note the number and location of the factory welds for installation of reinforcements
6. After the body side outer panel is removed to gain access to rocker, the center pillar reinforcement must be removed (1).

Note. If the location of the original plug weld holes cannot be determined, space the plug weld holes every 40 mm (1 1/2 in) apart

Scheme 101

1. Prepare the mating surfaces as necessary
2. Apply GM approved weld-thru coating or equivalent. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
3. Position the rocker reinforcement in place, use 3-dimensional measuring equipment, clamp in place
4. Plug weld accordingly (1).
5. Clean and prepare all of the welded surfaces.
6. Install all of the related panels and components.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
8. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
9. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
10. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Create cut lines on the rocker outer panel (1). To avoid cutting into hidden reinforcements within the center pillar panel, measure 115 mm down from bottom of electrical conduit hole (2), mark a cut line (3). To avoid a cutting into a sound deadener baffle within the lock pillar panel, measure 350 mm up from the bottom of the rocker panel (4), mark a cut line (5).
7. Perform additional sectioning procedures as needed depending on damage to vehicle. Refer to «Quarter Outer Panel Sectioning»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) , «Front Hinge Pillar Body Sectioning (Lower)»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) , «Front Hinge Pillar Body Sectioning (Upper)»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) or «Center Pillar Sectioning - Outer»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) NOTE: Do not damage any inner panels or reinforcements
8. Cut the rocker outer panel (1) where sectioning is to be performed
9. Locate and mark all the necessary factory welds of the rocker outer panel (1).
10. Drill all factory welds
11. Remove the damaged rocker outer panel (1).

1. From the service part (1), cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 inch) at each joint location
2. Prepare all mating surfaces as necessary
3. Drill 8 mm (5/16 in) plug weld holes in the service part (1), as necessary, in the corresponding locations noted on the original panel and along sectioned joint
4. Clean and prepare the attaching surfaces for welding
5. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Position the rocker outer panel section (1) to the vehicle using 3-dimensional measuring equipment. Clamp the pillar in place.
7. Plug weld the rocker outer panel (1) accordingly.
8. To create a solid weld with minimum heat distortion, make 25 mm (1 in) stitch welds along the seam with 25 mm (1 in) gaps between them. Then go back and complete the stitch weld
9. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
10. Paint the repair area.
11. Install all of the related panels and components
12. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
13. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 102

Scheme 103

Scheme 104

Scheme 105

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Locate and drill out the necessary factory welds of the body lock pillar upper reinforcement (1). Do not drill out the welds above the roof line. With the body lock pillar upper reinforcement still attached above the roof line, pry the lower portion of the reinforcement away from the body side inner panel
7. From inside of vehicle, cut body side inner panel where sectioning is to be performed (1).
8. Locate and drill out all necessary welds of the body side inner panel (1)
9. Remove the damaged body side inner panel (1).

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1).
2. Drill 8 mm (5/16 in) plug weld holes in the service part (1), as necessary, in the corresponding locations noted on the original panel and along sectioned joint.
3. Prepare all matting surfaces for welding, as necessary.
4. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Position the body side inner panel (1) to the vehicle using 3-dimensional measuring equipment. Clamp the panel in place
6. Plug weld accordingly (1).
7. To create a solid weld with minimum heat distortion, make 25 mm (1 in) stitch welds along the seam with 25 mm (1 in) gaps between them. Then go back and complete the stitch weld (1).
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
9. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
10. Install all of the related panels and components
11. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
12. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 111

Scheme 112

Scheme 113

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
6. Measure 70 mm rearward from the rear edge of the #5 bar (1). Mark the cut location (2). NOTE: Do not damage any adjacent panels or components when cutting or drilling out spot welds. Record the number and location of welds for installation of the service part.
7. Drill out all factory welds (1).
8. Cut the rear floor panel accordingly (1).

Scheme 114

Note. The service part is supplied precut at the proper location for sectioning. The service part will overlap the original floor panel by approximately 50 mm at the cut location. Two rows of evenly staggered plug welds will provide the necessary weld strength for this procedure

Scheme 115

Scheme 116

1. Create 2 rows of plug welds in the service part as follows. For the 1st row, measure 13 mm from the front edge of the service part (1). Mark a straight line across the width of the service part (2). For the 2nd row, measure 25 mm from the 1st row. Mark a straight line across the width of the service part (3).
2. Drill 8 mm (5/16 in) plug weld holes, every 40 mm along the 1st marked row. Locating the first hole 20 mm (1) from the left edge of the service part
3. Drill 8 mm (5/16 in) plug weld holes, every 40 mm along the 2nd marked row (3). Locate first hole 40 mm (2) from the left edge of the service part
4. Prepare all matting surfaces for welding, as necessary.
5. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Position the rear floor pan to the vehicle using 3-dimensional measuring equipment. Clamp the part in place.
7. Plug weld accordingly (1).
8. Clean and prepare all welded surfaces for painting
9. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
10. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
11. Install all of the related panels and components
12. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
13. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 117

Scheme 118

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: Note the number and location of the factory welds for installation of the rear inner wheelhouse.
6. Locate and drill out all the necessary factory welds (1).
7. Remove the rear inner wheelhouse (1).

Scheme 119

Note. If the location of the original plug weld holes can not be determined, space the plug weld holes every 40 mm (11/2 in) apart.

1. Drill 8 mm (5/16 in) plug weld holes in the service part as necessary in the locations noted from the original panel (1).
2. Prepare all mating surfaces for welding as necessary
3. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
4. Position the rear inner wheelhouse to the vehicle. Clamp the part in place (1).
5. Plug weld accordingly
6. Clean and prepare all of the welded surfaces
7. Install all of the related panels and components
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
9. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. The quarter panel is serviced as a body side service assembly. The assembly includes the full body side, including the rear lower quarter panel, the tail lamp pocket, and the gutter assembly. Removal of the quarter panel requires removal of the rear window. A special sectioning procedure has been developed for improved serviceability

Scheme 120

Scheme 121

Scheme 122

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Note the location and remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Section the sail panel and the rocker panel At the sail panel, measure from the back glass opening down 85 mm. Scribe a line. This is the cut location (1). Scribe a line on the rocker panel on the flat area between the holes where the molding attaches to the rocker panel. From the third hole rearward, measure 55 mm forward. This is the cut location (2).
7. Locate and drill out all factory welds. Note the number and location of welds for installation of the quarter panel (1). NOTE: Do not damage any other panel or reinforcements when cutting at the marked locations
8. Cut the panel at the marked locations (1).
9. Remove the lower quarter panel (1).

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1, 2).
2. Drill 8 mm (5/16 in) plug weld holes as necessary in locations noted from the original quarter panel (1). NOTE: If the location of the original plug weld holes can not be determined, or if structural weld-thru adhesive is present, space the plug weld holes every 40 mm (1 1/2 in) apart.
3. Prepare all mating surfaces for welding, as necessary.
4. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Position the new service panel and clamp in place (1).
6. Perform the sectioning procedure
7. Plug weld accordingly (1).
8. To create a solid weld with the minimum heat distortion, make a 25 mm (1 in) stitch weld along the seam with gaps of 25 mm (1 in) gaps between them. Go back and complete the stitch weld
9. Clean and prepare all welded surfaces
10. Pre-flange wheel housing. Using flat faced body hammer, bend over the flanged edge 45 degrees (1), at the same time holding a hard rubber block against it. Use structural adhesive in the area (2).
11. Bend the wheel arch (3).
12. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
13. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
14. Install all of the related panels and components
15. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
16. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Remove the inner and outer quarter panel to access the welds from the rail to the inner rocker panel area. Refer to «Quarter Outer Panel Sectioning»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) .
7. Remove the filler rocker reinforcement inner panel
8. Remove the shock reinforcement wheel house extension (1).
9. Locate and drill out all the necessary factory welds under the inner rocker reinforcement (1).
10. Locate and drill out all necessary factory welds to remove the five bar (1).
11. Remove the rear rail (1).

Note. If the location of the original plug weld holes cannot be determined, space the plug weld holes every 40 mm (11/2 in) apart.

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

1. Drill 8 mm (5/16 in) plug weld holes in the service part as necessary in the locations noted from the original panel (1).
2. Prepare all mating surfaces for welding as necessary.
3. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: The service part includes a rear wheelhouse extension
4. Position the rear rail to the vehicle using 3-dimensional measuring equipment. Clamp the rail in place (1).
5. Plug weld accordingly (1).
6. Install the five bar (1).
7. Install the rear rocker inner panel reinforcement (1).
8. Install the quarter panel.
9. Install the inner panel.
10. Install all of the related panels and components.
11. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
12. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
13. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
14. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Before beginning the repair, refer to Metal Panel Bonding for proper adhesive applicator preparations and general information

Scheme 138

Scheme 139

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
3. Remove all related panels and components
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: Note the number and location of the factory welds for installation of the rear end panel.
6. Locate and drill out all the necessary factory welds (1).
7. Remove the rear end panel (1).

Scheme 140

Note. If the location of the original plug weld holes can not be determined, space the plug weld holes every 40 mm (11/2 in) apart

Scheme 141

Scheme 142

1. Drill 8 mm (5/16 in) plug weld holes in the service part as necessary in the locations noted from the original panel (1).
2. Clean and prepare all matting surfaces as necessary (2). NOTE: Remove excess weld and sealer
3. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: The service part includes a rear wheelhouse extension
4. Position the rear end panel on the vehicle. Use 3-dimensional measuring equipment to inspect the panel (1).
5. 5. Clamp the panel in place.
6. Plug weld accordingly (1).
7. 7. Clean and prepare all of the welded surfaces.
8. Install all of the related panels and components
9. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
10. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
11. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
12. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components
3. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Locate and mark all factory welds
6. Drill all factory welds lower of the center pillar inner panel (1). Note the number and location of welds for installation of the service assembly
7. Drill all factory welds upper of the center pillar inner panel (1). Note the number and location of welds for installation of the service assembly
8. Remove the damaged center pillar inner panel (1).

1. Drill 8 mm (5/16 in)for plug welding along the edges of the center pillar inner panel (1) as noted from the original panel
2. Clean and prepare the attaching surfaces for welding
3. Position the center pillar inner panel (1) on the vehicle
4. Verify the fit of the panel
5. Clamp the center pillar inner panel into position
6. Plug weld accordingly center pillar inner panel (1) upper and lower
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
8. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
9. Install all of the related panels and components
10. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Section in specified areas only. Sectioning outside of these areas may compromise the structural integrity of the vehicle. The door frame can be replaced at factory seams, but requires the removal of the windshield and the roof. The sectioning procedures have been developed as a more cost-effective alternative to complete replacement. The specific area to be sectioned is determined by the extent of the damage to the vehicle

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components
3. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Remove body side center pillar section. Refer to «Center Pillar Sectioning - Outer»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
6. Locate and mark all the necessary factory welds of the center pillar reinforcement (1).
7. Drill all factory welds. Note the number and location of welds for installation of the service assembly
8. Remove the damaged center pillar reinforcement (1).

1. Prepare all matting surfaces as necessary
2. Align the center pillar reinforcement
3. Drill 8 mm (5/16 in)for plug welding along the edges of the center pillar reinforcement (1) as noted from the original panel
4. Clean and prepare the attaching surfaces for welding
5. Position the center pillar reinforcement (1) on the vehicle using 3-dimensional measuring equipment
6. Verify the fit of the center pillar reinforcement
7. Clamp the center pillar reinforcement into position
8. Plug weld the center pillar reinforcement (1) accordingly
9. Complete body side center pillar sectioning. Refer to «Center Pillar Sectioning - Outer»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
10. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
11. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
12. Install all of the related panels and components
13. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Sectioning should be performed only in the recommended areas. Failure to do so may compromise the structural integrity of the vehicle

Note. This procedure was developed to allow full access for the replacement of the center reinforcement pillar replacement since sectioning is not endorsed or recommended to the reinforcement due to the ultra high strength steel Ultra High Strength Steel

Scheme 143

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components
3. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
4. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
5. Remove the weatherstrip, observe the flange in the center pillar area. There will be a 3-metal stack-up. The center layer is the center pillar inner reinforcement (1).
6. Measure 13 mm (1/2 in)from the forward and rearward edges of the center pillar inner reinforcement and mark a vertical line (1).
7. Measure down 25 mm (1 in) from the upper edge of the body side outer panel and mark a horizontal line (1). This is the cut line
8. Cut access window (1) in the center pillar outer.
9. Perform additional sectioning procedures as needed depending on damage to vehicle. Refer to «Quarter Outer Panel Sectioning»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) , «Rocker Outer Panel Sectioning»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) , or «Front Hinge Pillar Body Sectioning (Upper)»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair) or «Front Hinge Pillar Body Sectioning (Lower)»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
10. Locate and drill out all factory welds (1). Note the number and location of welds for installation of the service part.
11. Remove the damaged center pillar outer panel section (1).

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in)at each joint location (1).
2. Drill 8 mm (5/16 in)plug weld holes in the service part (1), as necessary, in the corresponding locations noted on the original panel and along sectioned joint
3. Prepare all mating surfaces for welding, as necessary.
4. Apply GM approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Position the outer center pillar (1) to the vehicle using 3-dimensional measuring equipment. Clamp the pillar in place.
6. Plug weld accordingly (1).
7. To create a solid weld with minimum heat distortion, make a 25 mm (1 in)stitch weld along the seam with gaps of 25 mm (1 in)gaps between them. Go back and complete the stitch weld (1).
8. Clean and prepare all of the welded surfaces.
9. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
10. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
11. Install all of the related panels and components
12. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 144

1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
2. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
3. Remove the door from the vehicle. Refer to «FRONT SIDE DOOR REPLACEMENT»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bolted-exterior-body-panels-and-closures)
4. Remove all related panels and components
5. Locate and drill out all factory welds. Note the number and location of welds at the upper window frame and mirror locations (1).
6. Grind the edges of the door outer panel to separate the outer door panel from the door shell (1). WARNING: Inspection of the door guard beam for damage must be performed before replacement of the door outer panel. If damage to the door guard beam is found the door must be replaced. Failure to do so may compromise the structural integrity of the vehicle and may cause personal injury if the vehicle is involved in a collision.
7. Remove the outer door panel (1).
8. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
9. Straighten the edges of the door shell (1).

1. Using a grinding disk grind the surface of the door shell mating flanges to bare steel (1).
2. Scuff the opposing mating surfaces of the door outer panel to remove the gloss of the E-Coat (1).
3. Drill 8 mm (5/16 in) plug weld holes as necessary in the locations noted from the original panel (1). NOTE: If the location of the original plug-weld holes can not be determined, space plug weld holes every 40 mm (1 in) apart
4. Clean the mating surfaces NOTE: Do not allow the adhesive to totally cure off the vehicle, as proper alignment of the door outer panel to the door shell will be difficult
5. Apply a 3-6 mm (1/8-1/4 in) bead of metal panel bonding adhesive to both of the mating surfaces (1).
6. Using a small acid brush, spread a coat of adhesive to cover all the bare metal surfaces to ensure corrosion protection. NOTE: Do NOT pull the panels apart after joined together. Slide the panels against each other to realign the panels.
7. Apply a 9-13 mm (3/8-1/2 in) bead of metal panel bonding adhesive to the mating surface of the service panel.
8. Install the door outer panel to the door shell (1).
9. Clamp the door outer panel into position as required.
10. Using a hammer re-hem the hem flanges around the door shell. Continue to hammer in stages along the hem flanges (1).
11. Using lacquer thinner remove the excess adhesive from the door panel area.
12. Install the door to the vehicle. Inspect the door outer panel for proper alignment. Adjust the alignment as required. Refer to «FRONT SIDE DOOR REPLACEMENT»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bolted-exterior-body-panels-and-closures)
13. Metal-inert gas (MIG) weld the door outer panel to the door frame in the locations noted at the upper door frame (1).
14. Clean and prepare all welded surfaces
15. Apply Fusor super flexible anti-flutter foam - fast set, Fusor P/N 121/124 or equivalent in 4-5 evenly spaced locations between the door outer panel and the inner safety beam and the upper belt reinforcement (1).
16. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
17. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
18. Install all of the related panels and components
19. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
20. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .

Note. Before beginning the repair, refer to Metal Panel Bonding for proper adhesive applicator preparations and general information

Scheme 145

1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .
2. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
3. Remove the door from the vehicle. Refer to «FRONT SIDE DOOR REPLACEMENT»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bolted-exterior-body-panels-and-closures) or to «REAR SIDE DOOR REPLACEMENT»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bolted-exterior-body-panels-and-closures)
4. Locate and drill out all factory welds. Note the number and location of welds (1).
5. Grind the edges of the door outer panel to separate the outer door panel from the door shell (1). WARNING: Inspection of the door guard beam for damage must be performed before replacement of the door outer panel. If damage to the door guard beam is found the door must be replaced. Failure to do so may compromise the structural integrity of the vehicle and may cause personal injury if the vehicle is involved in a collision.
6. Remove the outer door panel (1).
7. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Straighten the edges of the door shell (1).

1. Using a grinding disk grind the surface of the door shell mating flanges to bare steel (1).
2. Scuff the opposing mating surfaces of the door outer panel to remove the gloss of the E-Coat (1).
3. Drill 8 mm (5/16 in) plug weld holes as necessary in the locations noted from the original panel (1). NOTE: If the location of the original plug welds can not be determined, space the plug weld holes every 40 mm (1 in) apart.
4. Clean the mating surfaces. NOTE: The adhesive has a 40-50 minute working time. Do not allow the adhesive to totally cure off the vehicle, as proper alignment of the door outer panel to the door shell will be difficult.
5. Apply a 3-6 mm (1/8 to 1/4 in) bead of metal panel bonding adhesive to both of the mating surfaces (1).
6. Using a small acid brush, spread a coat of adhesive to cover all the bare metal surfaces to ensure corrosion protection NOTE: Do NOT pull the panels apart after joined together. Slide the panels against each other to realign the panels.
7. Apply a 9-13 mm (3/8-1/2 in) bead of metal panel bonding adhesive to the mating surface of the service panel
8. Install the door outer panel to the door shell
9. Clamp the door outer panel into position as required.
10. Using a hammer re-hem the hem flanges around the door shell . Continue to hammer in stages along the hem flanges (1).
11. Using lacquer thinner remove the excess adhesive from the door panel area
12. Install the door to the vehicle check the door outer panel for proper alignment, adjust the alignment as required
13. Metal-inert gas (MIG) weld the door outer panel to the door frame in the locations noted at the upper door frame (1).
14. Clean and prepare all welded surfaces.
15. Apply Fusor super flexible anti-flutter foam-fast set, Fusor P/N 121/124 or equivalent in 4-5 evenly spaced locations between the door outer panel and the inner safety beam and the upper belt reinforcement (1).
16. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
17. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
18. Install all of the related panels and components
19. Install the door to the vehicle. Refer to «FRONT SIDE DOOR REPLACEMENT»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bolted-exterior-body-panels-and-closures) or to «REAR SIDE DOOR REPLACEMENT»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#bolted-exterior-body-panels-and-closures)
20. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
21. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/regal/v-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-non-hybrid) .

Scheme 146

Scheme 147

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components
3. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body»(/buick/regal/v-2009-2013/remont/exterior-body-panels/#collision-repair)
4. Note the location and remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) NOTE: To remove the rear rail-rear section, the number five bar extension (1) will have to be removed to gain access to the rail spot welds NOTE: Do not damage any inner panels or reinforcements. In areas where structural adhesive is present, heat the area to assist with removing the components.
5. Locate and drill out all factory welds (1). Note the number and location of the welds for installation of the rear rail - rear section.
6. Remove the damaged rear rail - rear section (1).

Note. If the location of the original plug weld holes cannot be determined, space the plug weld holes every 40 mm (1 1/2 in) apart. Some panels may have structural weld-thru adhesive. It is necessary to replace the weld-thru adhesive with an additional spot weld between each factory spot weld.

1. Prepare all mating surfaces as necessary
2. Apply GM-approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
3. Position the rear rail-rear section (1) to the vehicle using 3-dimensional measuring equipment. Clamp the rear rail lower into place.
4. Plug weld accordingly (1).
5. Clean and prepare all welded surfaces.
6. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «ANTI-CORROSION TREATMENT AND REPAIR»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
7. Paint the repair area. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(/buick/regal/v-2009-2013/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
8. Install all of the related panels and components
9. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Dual Phase Steel

This information provides repair recommendations and general guidelines for steel classified as Dual Phase Steel (Dual Phase Steel with a tensile strength up to and including 800 MPa), also known as DP.

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Note. The use of heat to repair damage is not recommended for this classification of steel.

Recommended Repairs

1. Cold repairs can be performed on this type of steel, unless the damage includes kinks. If the damage includes kinks, the part should be replaced.
2. Sectioning or partial replacement of this type of steel is recommended only at approved locations, in a specific sectioning procedure.
3. This type of steel can be used as a sleeve, or backer plate, when recommended in a specific sectioning procedure.
4. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
5. MIG plug welding and MIG stitch welding can be used on this type of steel.
6. MIG Brazing can be used on this type of steel.

High Strength Low Alloy Steel

This information provides repair recommendations and general guidelines for steel classified as High Strength Low Alloy Steel, also known as HSLA. This type of steel normally has a tensile strength range from 300-700 MPa.

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Recommended Repairs

1. Cold repairs can be performed on this type of steel, unless the damage includes kinks. If the damage includes kinks, the part should be replaced.
2. Controlled use of heat can be used to repair damage, if the heat does not exceed 650°C (1200°F). The heat should be applied a maximum of 2 times, for up to 90 seconds.
3. Sectioning or partial replacement of this type of steel is recommended only at approved locations, in a specific sectioning procedure.
4. This type of steel can be used as a sleeve, or backer plate, during sectioning procedures.
5. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
6. MIG plug welding and MIG stitch welding can be used on this type of steel.
7. MIG Brazing can be used on this type of steel.

Metal Panel Bonding

This is intended to provide general guidelines for adhesive bonding of exterior panels as an alternative to Metal-Inert Gas (MIG) welding. Panel bonding may be seen as an alternative to MIG welding to provide full panel replacement in regards to collision repair procedures. The benefits of panel bonding is

1. No heat or burn damage when additional welding is not required
2. Corrosion protection
3. Can act as a sealant
4. Improved process for complicated shapes (wheelhouse area)

The General Motors specification for metal bonding adhesives is GM 6449G. The scope of this specification is intended to provide the performance guidelines of structural adhesive systems used to repair (metallic) automotive bodies in the aftermarket. These types of adhesives are intended for use when bonding replacement body panels as an option to welding as the attachment means. GM information outlines the use of room temperature cure acrylic adhesives that contain glass bead technology.

Bonding procedures in general are applicable only to a factory seams type approach.

Sectioning or partial paneling of full panels is not supported by General Motors unless specifically documented in a Service Bulletin or Manual.

Applicable components for this technology are EXTERIOR PANELS ONLY, including door skins, tail panels, roof outer panels and quarter panels.

Adhesives currently meeting the performance requirements include General Motors materials and products manufactured by Lord Adhesives. At this time, ONLY the adhesive products listed below meet this guideline

Metal Panel Bonding

Mild Steel

This information provides repair recommendations and general guidelines for steel classified as Mild Steel. This type of steel normally has a tensile strength less than 270 MPa. This includes the common steel names of

1. Mild Steel
2. Bake Hardenable Steel (BH)
3. Solid Solution Strengthened Steel

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Recommended Repairs

1. Cold repairs can be performed on this type of steel, unless the damage includes kinks. If the damage includes kinks, the part should be replaced.
2. Controlled use of heat can be used to repair damage, if the heat does not exceed 650°C (1200°F). The heat should be applied a maximum of 2 times, for up to 90 seconds.
3. Sectioning or partial replacement of this type of steel is recommended only at approved locations, in a specific sectioning procedure.
4. This type of steel can be used as a sleeve, or backer plate, when recommended in a specific sectioning procedure.
5. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable
6. MIG plug welding and MIG stitch welding can be used on this type of steel.
7. MIG Brazing can be used on this type of steel.

Ultra High Strength Dual Phase Steel

This information provides repair recommendations and general guidelines for steel classified as Ultra High Strength Dual Phase Steel (Dual Phase Steel with a tensile strength greater than 800 MPa), also known as DPX.

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Note. Repair of this type of steel is not recommended. This type of steel should be replaced at factory joints only. Sectioning or partial replacement is not recommended. The use of heat to repair damage is not recommended for this type of steel. Stitch Welding is not recommended for this type of steel. This classification of steel can not be used as a backing reinforcement or a sleeve for a sectioning joint, unless a specific procedure is available.

Recommended Repairs

1. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
2. MIG plug welding can be used to replace factory spot welds.
3. MIG Brazing can be used to replace factory spot welds.

Ultra High Strength Steel

This information provides repair recommendations and general guidelines for steel classified as Ultra High Strength Steel, also know as UHSS. This type of steel normally has a tensile strength greater than 700 MPa.

This includes the common steel names of

1. Ultra High Strength Steel (UHSS)
2. Martensitic Steel (MS)
3. Press Hardened Steel (PHS)
4. Boron Steel

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Note. Repair of this type of steel is not recommended. This type of steel should be replaced only, at factory joints. Sectioning or partial replacement is not recommended. The use of heat to repair damage is not recommended for this type of steel. Stitch Welding is not recommended for this type of steel. This type of steel can not be used as a backing reinforcement or a sleeve for a sectioning joint.

Recommended Repairs

1. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
2. MIG plug welding can be used to replace factory spot welds.
3. MIG Brazing can be used to replace factory spot welds.

See also:
• ANTI-CORROSION TREATMENT AND REPAIR
• Approved Equipment for Collision Repair Warning
• Glass and Sheet Metal Handling Warning
• SIR Disabling and Enabling
• Battery Negative Cable Disconnection and Connection
• Fastener Caution
• BASECOAT/CLEARCOAT PAINT SYSTEMS
• HIGH VOLTAGE SYSTEM INSPECTION
• HIGH VOLTAGE DISABLING
• COLLISION SECTIONING WARNING
• FRONT SIDE DOOR REPLACEMENT
• Dimensions - Body
• Metal Panel Bonding
