Feedback Carburetor Component Test Buick Regal II

System Performance Check Chart. Scheme 208

Diagnostic Circuit Check Chart. Scheme 209

ENGINE PERFORMANCE PROBLEM - ODOR, SURGE, FUEL ECONOMY OR EMISSION PROBLEM

1. If the "CHECK ENGINE" light is not on, normal checks that would be performed on cars without the system should be done first.
2. If the alternator or coolant light is on with the "CHECK ENGINE" light, they should be diagnosed first.
3. Inspect for poor connections at coolant sensor, mixture control solenoid, etc. Also check for poor or loose vacuum hoses and connections. Repair as necessary.
4. If there is an intermittent "CHECK ENGINE" light, but no trouble code is stored, check the following: Check for intermittent connection in circuit between ignition coil to ground. Check for arcing at spark plug wires or spark plugs. Check battery to ECM terminals "C" and "R". Check ECM Terminals "A" and "U" to engine ground. Check for loss of trouble code long-term memory: Grounding dwell lead for 10 seconds with "TEST" lead ungrounded should produce a Code 23 which should be retained after the engine is turned off and the ignition switch is turned to "RUN" position. If a Code 23 is not displayed, ECM is defective and must be replaced. Ensure that the EST wires are kept away from the spark plug wires, distributor housing, ignition coil and alternator. Wires from ECM Terminal No. 13 to distributor and the shield (if used) should have a good ground.
5. If the customer is complaining of stalling, rough idle, dieseling or improper idle speed, see IDLE SPEED CONTROL CHECK.
6. If the complaint is detonation (spark knock) check the following items: Check the ESC system. Refer to ESC SYSTEM CHECK. Check the MAP or Vacuum Sensor output. See CHART 7 - MAP & BARO OUTPUT CHECK or CHART 8 - VACUUM SENSOR CHECK. Check EGR system. Refer to EGR VALVE CHECK. Check TPS enrichment system operation. See TPS ENRICHMENT CHECK. Check HEI operation. Refer to appropriate IGNITION SYSTEM article in the ELECTRICAL section.
7. If the complaint is poor performance and/or poor fuel economy, check the following: Perform appropriate EST PERFORMANCE CHECK. Perform ESC SYSTEM CHECK.
8. If the customer is experiencing poor full throttle performance, refer to CRANKS, BUT WON'T RUN chart.
9. If the complaint is intermittent no starts, make the following checks: Check for incorrect pick-up coil or ignition coil. See CRANKS, BUT WON'T RUN chart. Check for intermittent ground connection on ECM.

ALL OTHER COMPLAINTS

For any other complaints, do the SYSTEM PERFORMANCE CHECK with engine warmed to normal operating temperature. Ensure all repairs have been made to vehicle before performing SYSTEM PERFORMANCE CHECK.

CHART 1 - Dwell Fixed Under 10° (Lean Exhaust Indication). Scheme 210

CHART 2 - Dwell Between 10°-50° Open Coolant/O2 Sensor Ckt. Scheme 211

CHART 3 - Fixed Dwell Over 50° (Rich Exhaust Indication). Scheme 212

CHART 4 - TPS Enrichment Check. Scheme 213

CHART 5 - "CHECK ENGINE" Light Inoperative. Scheme 214

CHART 6 - Won't Flash Code 12 (Remote Lamp Driver In Harness). Scheme 215

CHART 7 - Map & Baro Output Check. Scheme 216

CHART 8 - Vacuum Sensor Check. Scheme 217

Flow Chart - Canister Purge Valve Check. Scheme 218

Flow Chart - Canister Purge Valve Check. Scheme 219

Flow Chart - Divert Valve Check. Scheme 220

Flow Chart - Divert Valve Check (1 Of 2). Scheme 221

Flow Chart - Divert Valve Check (2 Of 2). Scheme 222

Flow Chart - Air Mgmt Sys Chk W/ Elec Air Cont & Elec Switch Valve. Scheme 223

Flow Chart - Air Mgmt Sys Chk W/ Elec Air Cont & Elec Switch Valve. Scheme 224

Flow Chart - EFE (Electrically Heated) Check (3.8L Turbo). Scheme 225

Flow Chart - EFE (Electrically Heated) Check (3.8L Turbo). Scheme 226

Flow Chart - EFE (Electrically Heated) Chk (Exc 3.8L Turbo). Scheme 227

Flow Chart - EFE (Electrically Heated) Chk (Exc 3.8L Turbo). Scheme 228

Flow Chart - EFE (Vacuum Servo) Check. Scheme 229

Flow Chart - EFE (Vacuum Servo) Check. Scheme 230

Flow Chart - EGR Valve Chk (3.8L VIN A/Cal, 4.1L & 5.0L VIN Y). Scheme 231

Flow Chart - EGR Valve Chk (3.8L VIN A/Cal, 4.1L & 5.0L VIN Y). Scheme 232

Flow Chart - Electric Diverter Valve Check (EDV) 3.8L VIN "A"/Calif., 5.0L VIN "H"/Calif. - "B" & "G" Series, & 5.7L Calif. Scheme 233

Flow Chart - Electric Diverter Valve Check (EDV) 3.8L VIN "A"/Calif., 5.0L VIN "H"/Calif. - "B" & "G" Series, & 5.7L Calif. Scheme 234

Flow Chart - Electronic Spark Control (ESC) System Check (Engine Knock, Poor Performance Or Poor Economy) - No Code 43. Scheme 235

Flow Chart - Electronic Spark Control (ESC) System Check (Engine Knock, Poor Performance Or Poor Economy) - No Code 43. Scheme 236

Flow Chart - Engine Cranks, But Won't Run (W/Integral Coil). Scheme 237

Flow Chart - Engine Cranks, But Won't Run (With Remote Coil). Scheme 238

Flow Chart - EST Performance Check (Exc. 5.0L VIN "Y" & "9"). Scheme 239

Flow Chart - EST Performance Check (Exc. 5.0L VIN "Y" & "9"). Scheme 240

Flow Chart - EST Performance Check (5.0L VIN "Y" & "9"). Scheme 241

Flow Chart - EST Performance Check (5.0L VIN "Y" & "9"). Scheme 242

Flow Chart - Idle Speed Control (ISC) Check. Scheme 243

Flow Chart - Idle Speed Control (ISC) Check. Scheme 244

Flow Chart - Pulsair Solenoid Check. Scheme 245

Flow Chart - Pulsair Solenoid Check. Scheme 246

Flow Chart - Pulse Width Modulated (PWM) EGR Check - 2.8L, 3.0L, 3.8L (Exc. 3.8L VIN "A" Calif.), 5.0L VIN "H" & 5.7L VIN "L". Scheme 247

Flow Chart - Pulse Width Modulated (PWM) EGR Check - 2.8L, 3.0L, 3.8L (Exc. 3.8L VIN "A" Calif.), 5.0L VIN "H" & 5.7L VIN "L". Scheme 248

Flow Chart - Torque Converter Clutch (TCC) Elec Diagnosis. Scheme 249

Flow Chart - Torque Converter Clutch (TCC) Elec Diagnosis (1 Of 2). Scheme 250

Flow Chart - Torque Converter Clutch (TCC) Elec Diagnosis (2 Of 2). Scheme 251
