Interior lights — Courtesy lamps circuit Buick LeSabre VIII

Components on these wiring diagrams 31

Click a component to highlight it on every diagram it appears on.

• Class 2 Serial Data Line
• Courtesy Lamp Ground
• Door, Behind Trim Panel
• Driver Door Courtesy Lamp
• Front Passenger Door Courtesy Lamp
• Front Passenger Foot Well Courtesy Lamp
• Ground
• I/P Compartment Switch/ Lamp
• Inadvertent Power Input
• Int Lp Relay
• Left Foot Well Courtesy Lamp
• Left Front Door Lock Actuator
• Left Front Reading Courtesy Lamp
• Left Rear Door Courtesy Lamp
• Left Rear Door Lock Actuator
• Left Rear Door Module
• Left Rear Reading Courtesy Lamp
• Left Vanity Mirror
• Overhead Console
• Rear Compartment Courtesy Lamp
• Rear Compartment Lid Release Actuator
• Rear Integration Module
• Right Front Door Lock Actuator
• Right Front Door Module Simple Bus Interface
• Right Front Reading Courtesy Lamp
• Right Rear Door Courtesy Lamp
• Right Rear Door Lock Actuator
• Right Rear Door Module
• Right Rear Reading Courtesy Lamp
• Right Vanity Mirror
• Simple Bus Interface
