Steering Wheel & Steering Column Buick LeSabre VIII

Ignition Switch/steering Lock 38 illustrations ~8998 words

FASTENER TIGHTENING SPECIFICATIONS

ApplicationSpecification
MetricEnglish
Column Support Bolts27 N.m20 lb ft
Cable Support Bracket Screws3 N.m26 lb in
Intermediate Shaft Pinch Bolt47 N.m35 lb ft
Intermediate Shaft Seal Screw2 N.m21 lb in
Multi-Function Switch Screws7 N.m62 lb in
Steering Column Trim Cover Lower3.5 N.m31 lb in
Steering Column Trim Cover Upper1.5 N.m13 lb in
Steering Column Wiring Harness Connector8 N.m71 lb in
Steering Wheel Nut41 N.m30 lb ft
Steering Wheel Rear Bezel Screws3 N.m26 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: STEERING COLUMN DISASSEMBLED VIEW
Scheme 1: STEERING COLUMN DISASSEMBLED VIEW

DIAGNOSTIC STARTING POINT - STEERING COLUMN

Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to SYMPTOMS - STEERING WHEEL AND COLUMN in order to identify the correct procedure for diagnosing the system and where the procedure is located.

SYMPTOMS - STEERING WHEEL AND COLUMN

Review the system description and operation in order to familiarize yourself with the system functions. Refer to STEERING WHEEL & COLUMN DESCRIPTION & OPERATION .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the steering wheel and column.
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Symptoms List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. «LOCK SYSTEM DOES NOT UNLOCK»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  2. «LOCK SYSTEM DOES NOT LOCK»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  3. «LOCK SYSTEM STICKS IN START»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  4. «KEY CANNOT BE REMOVED IN OFF LOCK POSITION»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  5. «HIGH LOCK EFFORT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  6. «NOISE IN STEERING COLUMN»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  7. «HIGH SHIFT EFFORT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  8. «LOOSENESS IN STEERING COLUMN»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)
  9. «STEERING COLUMN TILT FUNCTION INOPERATIVE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column)

Scheme 2

Scheme 2: LOCK SYSTEM DOES NOT UNLOCK
Scheme 2: LOCK SYSTEM DOES NOT UNLOCK

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: LOCK SYSTEM DOES NOT LOCK
Scheme 4: LOCK SYSTEM DOES NOT LOCK

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: LOCK SYSTEM STICKS IN START
Scheme 6: LOCK SYSTEM STICKS IN START

Scheme 7

Scheme 7: KEY CANNOT BE REMOVED IN OFF LOCK POSITION
Scheme 7: KEY CANNOT BE REMOVED IN OFF LOCK POSITION

Scheme 8

Scheme 8: HIGH LOCK EFFORT
Scheme 8: HIGH LOCK EFFORT

Scheme 9

Scheme 9: NOISE IN STEERING COLUMN
Scheme 9: NOISE IN STEERING COLUMN

Scheme 10

Scheme 10: HIGH SHIFT EFFORT
Scheme 10: HIGH SHIFT EFFORT

Scheme 11

Scheme 11: LOOSENESS IN STEERING COLUMN
Scheme 11: LOOSENESS IN STEERING COLUMN

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13: STEERING COLUMN TILT FUNCTION INOPERATIVE
Scheme 13: STEERING COLUMN TILT FUNCTION INOPERATIVE

STEERING COLUMN ACCIDENT DAMAGE INSPECTION - OFF VEHICLE

  1. Vehicles involved in accidents resulting in frame damage, major body or sheet metal damage, or where the steering column has been impacted, or where supplemental inflatable restraint systems deployed may also have a damaged or misaligned steering column.
  2. Check the capsules on the steering column bracket assembly. All capsules must be securely seated in the bracket slots and checked for any loose conditions when pushed or pulled by hand.
  3. Observe how the bracket is attached to the jacket assembly. If the capsules are not securely seated and the bracket is bolted to the jacket assembly, replace only the bracket. If the capsules are not securely seated and the bracket is welded to the jacket assembly, replace only the jacket assembly.
  4. Replace the jacket assembly if the measured dimensions are not within specifications.
  5. Check for tab (1) breakage on the bearing and adapter assembly.
  6. Visually inspect the steering shaft for sheared injected plastic. If the steering shaft shows sheared plastic, replace the steering shaft.
  7. Any frame damage that could cause a bent steering shaft must have the steering shaft runout checked. Using a dial indicator (1) at the lower end of the steering shaft, rotate the steering wheel. The runout must not exceed 1.60 mm (0.0625 in).

STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .

Removal Procedure

  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) . WARNING: Before servicing any electrical component, the ignition key must be in the OFF or LOCK position and all electrical loads must be OFF, unless instructed otherwise in these procedures. If a tool or equipment could easily come in contact with a live exposed electrical terminal, also disconnect the negative battery cable. Failure to follow these precautions may cause personal injury and/or damage to the vehicle or its components.
  2. Disconnect the negative battery cable. Refer to «BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE»(/buick/lesabre/viii-2000-2005/remont/body-electrical/#battery) .
  3. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  4. Remove the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) .
  5. Remove the tilt lever.
  6. Remove the lower steering column trim cover retaining screws.
  7. Disconnect the closeout shroud from the lower steering column trim cover.
  8. Remove the upper steering column trim cover retaining screw (3).
  9. Lift the upper steering column trim cover to gain access to the lock cylinder access hole.
  10. Using a bent tip awl, insert the tip into the ignition lock cylinder access hole.
  11. Turn the ignition lock cylinder to the START position.
  12. Using the bent tip awl push down on the ignition lock cylinder retaining pin.
  13. Release the ignition lock cylinder to the RUN position and remove the lock cylinder.
  14. Remove the upper trim cover.
  15. Disconnect the closeout shroud from the upper steering column trim cover.

Installation Procedure

  1. Connect the upper steering column trim cover to the closeout shroud.
  2. Install the upper steering column trim cover to the steering column. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the upper steering column trim cover retaining screw (3). Tighten the upper steering column trim cover retaining screw to 1.5 N.m (13 in lbs).
  4. Install the Ignition lock cylinder.
  5. Connect the lower steering column trim cover to the closeout shroud.
  6. Install the lower steering column trim cover retaining screws. Tighten the lower steering column trim cover retaining screws to 3.5 N.m (31 in lbs).
  7. Install the tilt lever.
  8. Install the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) .
  9. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  10. Connect the negative battery cable. Refer to «BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE»(/buick/lesabre/viii-2000-2005/remont/body-electrical/#battery) .
  11. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

IGNITION SWITCH REPLACEMENT - ON VEHICLE

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  3. Remove the wire harness assembly (4) out of the wire harness strap (5).
  4. Remove the wire harness straps (3) from the wire harness assembly.
  5. Remove the wire harness strap (2) from the upper tilt head assembly (1).
  6. Disconnect the ignition switch electrical connector.
  7. Remove the theft deterrent control module (2) from the lock module assembly.
  8. Remove the key alarm connector (1) from the lock module assembly (4).
  9. Remove the ignition switch retaining screws (3).
  10. Remove the ignition switch.

Scheme 14

Scheme 14: Installation Procedure
Scheme 14: Installation Procedure
  1. Install the ignition switch (2) to the steering column. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the ignition switch retaining screws (3). Tighten the ignition switch retaining screws to 7 N.m (62 in lbs).
  3. Install the key alarm connector (1) to the lock module assembly (4).
  4. Route the electrical harness and connect electrical connections.
  5. Install a new wire harness strap to the upper tilt head assembly (2).
  6. Install new wire harness straps to the wire harness assembly (3).
  7. Install the wire harness assembly into the wire harness strap (5).
  8. Install the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  9. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

IGNITION LOCK CYLINDER REPLACEMENT - ON VEHICLE

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) . WARNING: Before servicing any electrical component, the ignition key must be in the OFF or LOCK position and all electrical loads must be OFF, unless instructed otherwise in these procedures. If a tool or equipment could easily come in contact with a live exposed electrical terminal, also disconnect the negative battery cable. Failure to follow these precautions may cause personal injury and/or damage to the vehicle or its components.
  2. Disconnect the battery negative cable. Refer to «BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE»(/buick/lesabre/viii-2000-2005/remont/body-electrical/#battery) .
  3. Position the steering wheel half way between the upper and lower tilt stops (if necessary).
  4. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  5. Remove the tilt lever. Refer to «TILT LEVER REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  6. Remove the lower steering column trim cover retaining screws.
  7. Remove the lower steering column trim cover.
  8. Remove the upper steering column trim cover retaining screws (3).
  9. Lift the upper steering column trim cover to gain access to the lock cylinder access hole.
  10. Using a bent tip awl, insert the tip into the ignition lock cylinder access hole.
  11. Turn the ignition lock cylinder to the START position.
  12. Using the bent tip awl, push down on the ignition lock cylinder retaining pin.
  13. Release the ignition lock cylinder to the RUN position.
  14. Remove the ignition lock cylinder from the lock module assembly by pulling the ignition lock cylinder away from the steering column.
  1. Insert the ignition lock cylinder through the upper steering column trim cover.
  2. Install the ignition lock cylinder to the lock module assembly by doing the following: Align the positioning slot and locking tab slot on the lock module assembly to the positioning tab and locking tab on the ignition lock cylinder. Push the ignition lock cylinder into the lock module assembly until the locking tab locks against the locking tab. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the upper steering column trim cover retaining screws (3). Tighten the upper steering column trim cover retaining screw to 1.5 N.m (13 in lbs).
  4. Install the lower steering column trim cover to the closeout shroud.
  5. Install the lower steering column trim cover retaining screws. Tighten the lower steering column trim cover retaining screws to 3.5 N.m (31 in lbs).
  6. Install the tilt lever. Refer to «TILT LEVER REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  7. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  8. Connect the negative battery cable. Refer to «BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE»(/buick/lesabre/viii-2000-2005/remont/body-electrical/#battery) .
  9. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

LINEAR SHIFT ASSEMBLY REPLACEMENT - ON VEHICLE

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  3. Remove the shift lever from the linear shift assembly. Refer to «SHIFT LEVER REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__shift-lever-replacement-on-vehicle) .
  4. Disconnect the automatic transmission shift lock actuator from the linear shift assembly.
  5. Disconnect the transmission shift cable from the linear shift assembly.
  6. Disconnect the park lock cable assembly (1).
  7. Insert a small screwdriver into the slot on the lock module assembly and push against the parklock cable locking tab to remove the parklock cable.
  8. Remove the linear shift assembly retaining screws.
  9. Remove the linear shift assembly.
CAUTIONUse the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  1. Install the linear shift assembly and retaining screws. Tighten the linear shift assembly retaining screws to 10 N.m (89 in lbs).
  2. Connect the park lock cable assembly (1) to the lock module assembly.
  3. Connect the transmission shift cable to the linear shift assembly.
  4. Connect the automatic transmission shift lock actuator to the linear shift assembly.
  5. Adjust the automatic transmission shift lock. Refer to «AUTOMATIC TRANSMISSION SHIFT LOCK ACTUATOR REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/transmission-control-systems/#shift-interlock-systems) in Shift Lock Control.
  6. Install the shift lever. Refer to «SHIFT LEVER REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__shift-lever-replacement-on-vehicle) .
  7. Install the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  8. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

TURN SIGNAL CANCEL CAM & STEERING SHAFT UPPER BEARING SPRING REPLACEMENT - ON VEHICLE

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .

Note. Tools Required: Steering Column Lock Plate (J 23653-SIR).

  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the inflatable restraint steering wheel module coil. Refer to «SIR COIL ASSEMBLY»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system) .
  3. Install J 23653-SIR to the upper steering shaft.
  4. Using J 23653-SIR depress the lock plate and remove the retaining clip.
  5. Remove J 23653-SIR from the upper steering shaft.
  6. Remove the shaft lock shield assembly (1).
  7. Remove the turn signal cancel cam assembly (2).
  8. Remove the upper bearing spring (3).
  1. Install the upper bearing spring (3).
  2. Install the turn signal cancel cam assembly (2).
  3. Install the shaft lock shield assembly (1).
  4. Install a new bearing retainer.
  5. Using J 23653-SIR depress the shaft lock shield assembly.
  6. Push the bearing retainer into place.
  7. Remove the J 23653-SIR from the steering shaft.
  8. Install the inflatable restraint steering wheel module coil. Refer to «SIR COIL ASSEMBLY»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system) .
  9. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

MULTIFUNCTION, TURN SIGNAL, & HAZARD SWITCH REPLACEMENT - ON VEHICLE

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the steering column trim cover. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  3. Remove the multifunction switch retaining screws.
  4. Disconnect the multifunction switch electrical connections.
  5. Remove the multifunction switch.
  1. Install the multifunction switch to the steering column. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the multifunction switch retaining screws. Tighten the multifunction switch retaining screws to 7 N.m (62 in lbs).
  3. Route the electrical harness and connect electrical connections.
  4. Install the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  5. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

SHIFT LEVER REPLACEMENT - ON VEHICLE

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  3. Remove the shift lever retaining screw (3).
  4. Disconnect electrical connector from traction control harness if equipped and feed harness out of column. Observe the harness routing and location to assist in reassembly.
  5. Pull the shift lever (4) upward to remove it from the linear shift assembly.
  1. Push the shift lever downward to engage it into the linear shift assembly. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the shift lever retaining screw (3). Tighten the shift lever retaining screw to 1.5 N.m (13 in lbs).
  3. Feed the traction control harness back through the column. Use care to route the harness as previously observed.
  4. Install the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  5. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .
  1. Grasp the tilt lever.
  2. Pull the tilt lever straight out from steering column.
  1. Align the tilt lever into the steering column.
  2. Slide the tilt lever handle into the steering column until it locks into position.

STEERING WHEEL CONTROL SWITCH ASSEMBLY REPLACEMENT

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  3. Remove the steering wheel rear bezel retaining screws (1).
  4. Remove the steering wheel rear bezel (2).
  5. Insert a small, blunt ended tool into the access hole in the back of the steering wheel in order to push the switch out of the steering wheel.
  6. Disconnect the electrical connector.

Scheme 15

Scheme 15: Installation Procedure
Scheme 15: Installation Procedure
  1. Connect the electrical connector.
  2. Align the switch to the switch opening in the steering wheel.
  3. Snap the switch into the steering wheel.
  4. Install the steering wheel rear bezel (2). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Install the steering wheel rear bezel retaining screws (1). Tighten the steering wheel rear bezel retaining screws to 3 N.m (26 in lbs).
  6. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  7. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

STEERING WHEEL REPLACEMENT

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .

Note. Tools Required: Steering Wheel Puller Legs (J 42578) and Steering Wheel Puller (J 1859-A).

  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the Inflatable Restraint Steering Wheel Module. Refer to «AIR BAG MODULES»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system) .
  3. Disconnect the steering wheel electrical connector.
  4. Remove the weight block from the steering wheel base if equipped.
  5. Remove the steering wheel retaining nut.
  6. Note the mark on the steering shaft and the steering wheel in order to ensure proper alignment during installation.
  7. Install J 42578 and J 1859-A to the steering wheel.
  8. Using J 42578 and J 1859-A remove the steering wheel.
  9. Remove the J 42578 and J 1859-A from the steering wheel.
  1. Route the steering wheel wiring through the steering wheel.
  2. Align the mark on the steering wheel with the mark on the steering shaft.
  3. Install the steering wheel. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  4. Install the steering wheel retaining nut. Tighten the steering wheel retaining nut to 41 N.m (30 ft lbs).
  5. Install the weight block if equipped.
  6. Connect the steering wheel electrical connector.
  7. Install the Inflatable Restraint Steering Wheel Module. Refer to «AIR BAG MODULES»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system) .
  8. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

INTERMEDIATE STEERING SHAFT REPLACEMENT

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .

Note. Tools Required: Steering Column Lock Pin (J 42640).

  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) . CAUTION: The wheels of the vehicle must be straight ahead and the steering column in the LOCK position before disconnecting the steering column or intermediate shaft from the steering gear. Failure to do so will cause the SIR coil assembly to become uncentered, which may cause damage to the coil assembly.
  2. Insert the J 42640 into the steering column access hole in order to lock the steering column. This will maintain correct orientation.
  3. Remove the pinch bolt at the steering gear stub shaft.
  4. Remove the left IP sound insulator. Refer to «CLOSEOUT/INSULATOR PANEL REPLACEMENT-LEFT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) in Instrument Panel, Gauges and Console.
  5. Reposition the intermediate shaft seal (dust seal) in order to gain access to the upper intermediate shaft pinch bolt (2).
  6. Remove the pinch bolt (2).
  7. Disconnect the intermediate shaft (1) from the steering column.
  8. Remove the intermediate steering shaft (1).
  1. Position the intermediate steering shaft (1). Insert the shaft fully into the pinch bolt pot joint on the steering column. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Bottom out the lower pinch pot joint on the steering gear. Tighten the pinch bolt (2) to 47 N.m (35 ft lbs).
  3. Reposition the seal as needed.
  4. Install the left IP sound insulator. Refer to «CLOSEOUT/INSULATOR PANEL REPLACEMENT-LEFT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) in Instrument Panel, Gauges and Console.
  5. Remove the J 42640 from the steering column.
  6. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

TILT SPRING REPLACEMENT - STEERING COLUMN

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  3. Remove the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) in Instrument Panel, Gauges and Console.
  4. Remove the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  5. Use the tilt lever to tilt the column in the UP position.
  6. Remove the tilt spring (1).
  1. Lubricate tilt spring guide with synthetic grease.
  2. Install the tilt spring guide into the tilt spring.
  3. Install the tilt spring (1).
  4. Install the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-trim-covers-replacement) .
  5. Install the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) in Instrument Panel, Gauges and Console.
  6. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-wheel-replacement) .
  7. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

STEERING COLUMN REPLACEMENT

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .
CAUTIONThe wheels of the vehicle must be straight ahead and the steering column in the LOCK position before disconnecting the steering column or intermediate shaft from the steering gear. Failure to do so will cause the SIR coil assembly to become uncentered, which may cause damage to the coil assembly.
CAUTIONOnce the steering column is removed from the car, the column is extremely susceptible to damage. Dropping the column on its end could collapse the steering shaft or loosen the plastic injections which maintain column rigidity. Leaning on the column could cause the jacket to bend or deform. Any of the above damage could impair the column's collapsible design. If it is necessary to remove the steering wheel, use only the specified steering wheel puller. Under no conditions should the end of the shaft be hammered upon as hammering could loosen plastic injections which maintain column rigidity.

Note. Tools Required: Steering Column Lock Pin (J 42640).

  1. Disable the SIR system. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Insert J 42640 into the steering column access hole in order to lock the steering column. This will maintain the correct orientation.
  3. Raise and support the vehicle.
  4. Remove the lower pinch bolt from the intermediate shaft.
  5. Remove the intermediate shaft from the steering gear.
  6. Lower the vehicle.
  7. Remove the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) in Instrument Panel, Gages and Console.
  8. Disconnect the steering column wiring harness connector from the main body wiring harness.
  9. Disconnect the shift lever cable from the linear shift assembly.
  10. Remove the shift cable retaining clip.
  11. Press the shift cable tabs (1) together and remove the shift cable (2) from the steering column. CAUTION: The steering column should never be supported only by the lower support bracket. Damage to the lower support could result. NOTE: Stabilize the studs in order to remove the nuts securing the steering column to the instrument panel.
  12. Support the column.
  13. Position a 13 mm crowfoot wrench onto one of the nuts which secures the steering column to the I/P.
  14. While holding the stud in position with a #7 inverted TORX® socket, remove the nut.
  15. Repeat the above steps for each nut. NOTE: Discard the clips at the upper steering column support, if equipped. These clips are for assembly plant usage only.
  16. Remove the steering column from the vehicle.
  17. Transfer any necessary components.
CAUTIONIn order to ensure the intended function of the steering column in a vehicle during a crash and in order to avoid personal injury to the driver, perform the following: Tighten the steering column lower fasteners before you tighten the steering column upper fasteners. Failure to do this can damage the steering column. Tighten the steering column fasteners to the specified torque. Overtightening the upper steering column fasteners could affect the steering column collapse.
CAUTIONIf a service replacement steering column is being installed, do not remove the anti-rotation pin until after the steering column has been connected to the steering gear. Removing the anti-rotation pin before the steering column is connected to the steering gear may damage the SIR coil assembly.
CAUTIONThe steering column should never be supported only by the lower support bracket. Damage to the lower support could result.
  1. Install the steering column to the vehicle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. NOTE: When installing the steering column, install the fasteners needed for completing each step of the installation. DO NOT tighten the fasteners until the procedure tells you to do so. In order to ensure that the column absorbs energy correctly, use only the specified screws, bolts, and nuts. Tighten the components to the specified torque.
  2. Support and install the steering column mounting nuts. Tighten the nuts to 27 N.m (20 ft lbs).
  3. Connect the steering column wiring harness connector to the main body wiring harness.
  4. Install the transmission shift cable (2) to the steering column.
  5. Install the transmission shift cable retaining clip.
  6. Install the shift cable to the linear shift assembly.
  7. Install the knee bolster and the bracket. Refer to «KNEE BOLSTER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) in Instrument Panel, Gages and Console.
  8. Raise the vehicle.
  9. Install the intermediate shaft to the steering gear.
  10. Install the lower pinch bolt to the intermediate shaft. Tighten the bolt to 47 N.m (35 ft lbs).
  11. Install the tire and wheel.
  12. Lower the vehicle.
  13. Enable the SIR system. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .
  14. Remove J 42640 from the steering column.
  15. Inspect the steering for proper operation.

Scheme 16

Scheme 16: STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE
Scheme 16: STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE
  1. Check the steering column for accident damage. Refer to «STEERING COLUMN ACCIDENT DAMAGE INSPECTION - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-accident-damage-inspection) .
  2. Remove the tilt lever (2) from the trim covers (1).
  3. Remove 2 pan head tapping screws (2) from the lower trim cover (1).
  4. Unsnap the closeout trim cover from the lower trim cover (1).
  5. Remove the lower trim cover (1).
  6. Slide the shift lever seal up the shift lever.
  7. Remove 1 TORX® head screw (3) from the upper trim cover (1).
  8. Remove the upper trim cover (1) with the closeout trim cover (2).
  9. Remove the closeout trim cover (2) from the upper trim cover (1).
  10. Remove the trim cover protector (1) from the lower trim cover (2).

Scheme 17

Scheme 17: STEERING COLUMN TRIM COVERS - ASSEMBLE - OFF VEHICLE
Scheme 17: STEERING COLUMN TRIM COVERS - ASSEMBLE - OFF VEHICLE

Scheme 18

Scheme 18
Scheme 18
  1. Install the trim cover protector (1) to the lower trim cover (2).
  2. Install the closeout trim cover (2) onto the upper trim cover (1). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the upper trim cover (1) with the closeout trim cover (2) and secure by using 1 TORX® head screw (3). Tighten the screw to 1.5 N.m (13 in lbs).
  4. Slide the shift lever seal down the shift lever and secure into the upper trim cover.
  5. Install the lower trim cover (1).
  6. Make sure the shift lever seal is properly aligned in the upper and lower trim covers.
  7. Install 2 pan head tapping screws (2). Tighten the screws to 3.5 N.m (31 in lbs).
  8. Install the tilt lever (2) into the trim covers (1).

SHIFT LEVER - DISASSEMBLE - OFF VEHICLE

  1. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Remove the wire harness straps.
  3. Remove the wire harness assembly from the wire restraint clip (1).
  4. Disconnect the shift lever connector.
  5. Remove the shift lever screw (3).
  6. Remove the shift lever assembly (4).
  7. Remove the shift lever seal (2) from the shift lever assembly (4).

SHIFT LEVER - ASSEMBLE - OFF VEHICLE

  1. Install the shift lever seal (2) onto the shift lever assembly (4). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the shift lever assembly (4) and secure it with the shift lever screw (3). Tighten the screw to 1.5 N.m (13 in lbs).
  3. Reconnect the shift lever connector.
  4. Install the wire harness assembly into the wire restraint clip (1).
  5. Install the wire harness straps.
  6. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL - DISASSEMBLE - OFF VEHICLE

Note. Before performing the following procedures, check the fused jumper assembly for burned 2 amp fuses.

  1. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Remove the wire harness straps. Remove the wire harness assembly from the wire restraint clip (1).
  3. Remove the black inflatable restraint steering wheel module coil connector from the fused jumper assembly connector.
  4. Remove the retaining ring (1).
  5. Remove the inflatable restraint steering wheel module coil (2).
  6. Remove the wave washer (3).

Scheme 19

Scheme 19: INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL - ASSEMBLE - OFF VEHICLE
Scheme 19: INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL - ASSEMBLE - OFF VEHICLE
  1. Install the wave washer (1).
  2. A new inflatable restraint steering wheel module coil will be precentered. Do not remove the orange tab until installation is complete. Do not depress the tab (1) on the back of the inflatable restraint steering wheel module coil.
  3. If reusing the original inflatable restraint steering wheel module coil, it must be centered first. Refer to «INFLATABLE RESTRAINT COIL CENTERING OFF VEHICLE (COLUMN SHIFT & FLOOR SHIFT)»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__inflatable-restraint-coil-centering-off-vehicle) .
  4. Align the inflatable restraint steering wheel module coil (2) with the horn tower sticking through the shaft lock shield assembly (1). NOTE: The retaining ring (1) must seat securely on the groove of the shaft assembly (2).
  5. Install the retaining ring (1).
  6. Install the black inflatable restraint steering wheel module coil connector to the fused jumper assembly connector.
  7. Install the 4 wire harness straps.
  8. Install the wire harness assembly into the wire restraint clip (1).
  9. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

WINDSHIELD WIPER/WASHER SWITCH

TURN SIGNAL & MULTIFUNCTION SWITCH ASSEMBLY - DISASSEMBLE - OFF VEHICLE

  1. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Remove the wire harness straps. Remove the wire harness assembly from the wire restraint clip (1).
  3. Disconnect the connectors of the turn signal and multifunction switch assembly.
  4. Remove 2 pan head tapping screws from the turn signal and multifunction switch assembly.
  5. Remove the turn signal and multifunction switch assembly.

TURN SIGNAL & MULTIFUNCTION SWITCH ASSEMBLY - ASSEMBLE - OFF VEHICLE

  1. Install the turn signal and multifunction switch assembly. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. NOTE: The electrical contact on the turn signal and multifunction switch assembly must rest on the turn signal cancel cam assembly.
  2. Screw the 2 pan head tapping screws (1) and (3) into the turn signal and multifunction switch assembly (2). Tighten the top pan head tapping screw (1) to 3 N.m (30 in lbs). Tighten the side pan head tapping screw (3) to 7 N.m (62 in lbs).
  3. Reconnect the connectors of the turn signal and multifunction switch assembly.
  4. Install the wire harness straps.
  5. Install the wire harness assembly into the wire restraint clip (1).
  6. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

IGNITION & KEY ALARM SWITCH ASSEMBLY - DISASSEMBLE - OFF VEHICLE

  1. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Disconnect the coded key controller connector.
  3. Disconnect the fused jumper assembly connector.
  4. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly out of the bulk head connector (1).
  5. Slide the coded key controller (2) from the electronic lock module assembly (1).
  6. Remove the key alarm connector (1) from the electronic lock module assembly (4).
  7. Remove the 2 tapping screws (3) from the ignition and key alarm switch assembly (2).

IGNITION & KEY ALARM SWITCH ASSEMBLY - ASSEMBLE - OFF VEHICLE

CAUTIONUse the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  1. Install the ignition and key alarm switch assembly (2) and secure by using 2 tapping screws (3). Tighten the screws to 7 N.m (62 in lbs).
  2. Install the ignition and key alarm connector (1) onto the electronic lock module assembly (4).
  3. Connect the coded key controller.
  4. Connect the fused jumper assembly connector.
  5. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly onto the bulk head connector (1).
  6. Install the coded key controller (2) onto the electronic lock module assembly (1).
  7. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL - DISASSEMBLE - OFF VEHICLE

  1. Disconnect the automatic transmission shift lock control connector.
  2. Use a screwdriver to pry the automatic transmission shift lock control from the steering column support assembly.
  3. Remove the automatic transmission shift lock control from the steering column.

Scheme 20

Scheme 20: AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL - ASSEMBLE - OFF VEHICLE
Scheme 20: AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL - ASSEMBLE - OFF VEHICLE
  1. Install the automatic transmission shift lock control. Put the column in the NEUTRAL position.
  2. Adjust the automatic transmission shift lock control. Pull the tab (1) out on the block side (2) of the automatic transmission shift lock control. Shift the column into the NEUTRAL position. Press on the adjuster block (2) to compress the internal adjuster spring to disengage the adjuster teeth. Slide the adjuster block (2) as far away from the solenoid as possible. Shift the column into the PARK position. Lock in place by pushing the tab (1) back in.
  3. Inspect the automatic transmission shift lock control. The automatic transmission shift lock control must lock the gear shift lever when it is put into the PARK position. When the column is installed in the vehicle you will not be able to shift the gear shift lever out of the PARK position without pressing on the brake pedal. The solenoid will be energized. Readjust if needed.
  4. Reconnect the automatic transmission shift lock control connector.

LINEAR SHIFT ASSEMBLY - DISASSEMBLE - OFF VEHICLE

  1. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Remove the automatic transmission shift lock control assembly. Refer to «AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__automatic-transmission-shift-lock-control) .
  3. The lock cylinder should be in the OFF-LOCK position.
  4. Disconnect the park lock cable assembly (1).
  5. Insert a small screwdriver into the slot on the electronic lock module assembly and push against the locking tab to remove.
  6. Remove the 3 flat head 6 lobed socket tap screws from the linear shift assembly.
  7. Remove the linear shift assembly from the steering column.

LINEAR SHIFT ASSEMBLY - ASSEMBLE - OFF VEHICLE

Note. Tools Required: Park Lock Cable Pliers (J 41396).

CAUTIONUse the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.

Scheme 21

Scheme 21
Scheme 21
  1. Install the linear shift assembly and secure using the 3 flat head 6 lobed socket tap screws. Tighten the 3 flat head 6 lobed socket tap screws to 10 N.m (89 in lbs).
  2. Connect the park lock cable assembly (1).
  3. The lock cylinder should be in the OFF-LOCK position.
  4. The locking tab at the end of the park lock cable assembly (1) must be installed into the electronic lock module assembly.
  5. Adjust the park lock cable assembly. Use the gear shift lever to put the column in the PARK position. Put the ignition switch in the OFF-LOCK position. Remove the key. Unlock the adjuster ring on the park lock cable assembly with J 41396. Pull on the cable until the park lock latch contacts the gear shift lever. Release the cable. Lock the adjuster ring securely in place on the park lock cable assembly with J 41396.
  6. Inspect the park lock cable assembly. Put the lock cylinder in the OFF-LOCK position. The gear shift lever should not be able to shift out of the PARK position. Turn the key to the run position and put the gear shift lever in the NEUTRAL position. With the gear shift lever in the NEUTRAL position the lock cylinder should not be able to go into the OFF-LOCK position. Put the gear shift lever in the PARK position. Put the lock cylinder in the OFF-LOCK position and then remove the key.
  7. Install the automatic transmission shift lock control assembly. Refer to «AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  8. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

Scheme 22

Scheme 22: TILT SPRING - DISASSEMBLE - OFF VEHICLE
Scheme 22: TILT SPRING - DISASSEMBLE - OFF VEHICLE
  1. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  2. Use the tilt lever to tilt the column in the UP position. WARNING: The tilt spring and the spring guide are under pressure. The tilt spring and the spring guide may become a projectile. Secure the spring with locking pliers during removal. Secure the spring with locking pliers during installation. Bodily injury may result during removal and installation of the tilt spring and the spring guide. Always use caution during removal and installation of the tilt spring and the spring guide.
  3. Remove the tilt spring (1). Pry the tilt spring up until a bulge occurs and most of the tilt spring tension is removed. Secure the tilt spring and continue prying until the tilt spring disengages from the post on the steering column support assembly (2) and the steering column tilt head assembly (3).
  4. Remove the spring guide (1) from the tilt spring (2).

Scheme 23

Scheme 23: TILT SPRING - ASSEMBLE - OFF VEHICLE
Scheme 23: TILT SPRING - ASSEMBLE - OFF VEHICLE
  1. Lubricate spring guide with synthetic grease. Install the spring guide into the tilt spring. WARNING: The tilt spring and the spring guide are under pressure. The tilt spring and the spring guide may become a projectile. Secure the spring with locking pliers during removal. Secure the spring with locking pliers during Installation. Bodily Injury may result during removal and Installation of the tilt spring and the spring guide. Always use caution during removal and Installation of the tilt spring and the spring guide.
  2. Install the tilt spring (1). Install the tilt spring (1) to the post on the steering column support assembly (2). Secure the tilt spring (1).
  3. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

ELECTRONIC COLUMN LOCK MODULE - DISASSEMBLE - OFF VEHICLE

  1. Remove the ignition and key alarm switch assembly. Refer to «IGNITION & KEY ALARM SWITCH ASSEMBLY - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__ignition-key-alarm-switch-assembly) .
  2. Remove the steering column tilt head components. Refer to «STEERING COLUMN TILT HEAD HOUSING - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-tilt-head-housing) .
  3. Remove the park lock cable assembly (1) from the electronic lock module assembly in the following way: Place the steering column lock cylinder set into the OFF position. Place the shift lever clevis into the PARK position. Use a small blade to push against the locking tab on the end of the park lock cable assembly (1). Disconnect the park lock cable assembly (1) from the electronic lock module assembly.
  4. Remove the 3 TORX® screws (2) from the electronic lock module assembly (1).
  5. Remove the electronic lock module assembly (2) from the steering column tilt head assembly.

ELECTRONIC COLUMN LOCK MODULE - ASSEMBLE - OFF VEHICLE

Note. Tools Required: Park Lock Cable Pliers (J 41396).

Scheme 24

Scheme 24: ELECTRONIC COLUMN LOCK MODULE - ASSEMBLE - OFF VEHICLE
Scheme 24: ELECTRONIC COLUMN LOCK MODULE - ASSEMBLE - OFF VEHICLE
  1. Align the electronic lock module assembly (2) with the steering column tilt head assembly. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Screw the 3 TORX® screws (1) into the electronic lock module assembly (1). Tighten the 3 TORX® screws to 7 N.m (62 in lbs).
  3. Place steering column lock cylinder set into the OFF position.
  4. Place the shift lever clevis into the PARK position.
  5. Press the locking tab on the end of the park lock cable assembly (1) into the slot in the electronic lock module assembly.
  6. Adjust the park lock cable assembly. Use the gear shift lever to put the column in the PARK position. Put the ignition switch in the OFF-LOCK position. Remove the key. Unlock the adjuster ring on the park lock cable assembly with J 41396. Pull on the cable until the park lock latch contacts the gear shift lever. Release the cable. Lock the adjuster ring securely in place on the park lock cable assembly with J 41396.
  7. Inspect the park lock cable assembly. Put the lock cylinder in the OFF-LOCK position. The gear shift lever should not be able to shift out of the PARK position. Turn the key to the run position and put the gear shift lever in the NEUTRAL position. With the gear shift lever in the NEUTRAL position the lock cylinder should not be able to go into the OFF-LOCK position. Put the gear shift lever in the PARK position. Put the lock cylinder in the OFF-LOCK position and then remove the key. Install the coded key controller and the ignition and key alarm switch assembly only. Refer to «IGNITION & KEY ALARM SWITCH ASSEMBLY - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__ignition-key-alarm-switch-assembly) . Install the steering column tilt head components. Refer to «STEERING COLUMN TILT HEAD HOUSING - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-tilt-head-housing) .

STEERING COLUMN TILT HEAD HOUSING - DISASSEMBLE - OFF VEHICLE

Note. Tools Required: Steering Column Lock Plate Compressor (J 23653-SIR) and Steering Column Lock Plate Compressor Adapter (J 42137).

  1. Remove the inflatable restraint steering wheel module coil. Refer to «INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__inflatable-restraint-steering-wheel-module-coil) .
  2. Remove the bearing retainer using J 23653-SIR and J 42137 and dispose of it.
  3. Remove J 23653-SIR and J 42137 from the steering shaft assembly.
  4. Remove the shaft lock shield assembly (1).
  5. Remove the turn signal cancel cam assembly (2).
  6. Remove the upper bearing spring (3).
  7. Remove the upper bearing inner race seat (4).
  8. Remove the inner race (5).

STEERING COLUMN TILT HEAD HOUSING - ASSEMBLE - OFF VEHICLE

Note. Tools Required: Steering Column Lock Plate Compressor (J 23653-SIR) and Steering Column Lock Plate Compressor Adapter (J 42137).

  1. Install the inner race (4).
  2. Install the upper bearing inner race seat (3).
  3. Install the upper bearing spring (2).
  4. Lubricate the turn signal cancel cam assembly (1) with lithium grease.
  5. Install the turn signal cancel cam assembly (1).
  6. Install the shaft lock shield assembly.
  7. Install the new bearing retainer using J 23653-SIR and J 42137.
  8. Remove J 23653-SIR and J 42137 from the steering shaft assembly.
  9. Install the inflatable restraint steering wheel module coil. Refer to «INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .

TURN SIGNAL SWITCH HOUSING - DISASSEMBLE - OFF VEHICLE

  1. Remove the lock module assembly. Refer to «ELECTRONIC COLUMN LOCK MODULE - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__electronic-column-lock-module-disassemble) .
  2. Remove the turn signal and multifunction switch assembly only. Refer to «TURN SIGNAL & MULTIFUNCTION SWITCH ASSEMBLY - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__turn-signal-multifunction-switch-assembly) .
  3. Slide the turn signal switch housing off of the steering column shaft assembly.

TURN SIGNAL SWITCH HOUSING - ASSEMBLE - OFF VEHICLE

  1. Install the lock module assembly only. Refer to «ELECTRONIC COLUMN LOCK MODULE - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__electronic-column-lock-module-assemble) . NOTE: The switch mounting bracket must be pressed firmly against the steering column tilt head in order for the screws from the turn signal and multifunction switch assembly screws to line up.
  2. Slide the turn signal switch housing onto the steering column shaft assembly.
  3. Install the turn signal and multifunction switch assembly only. Refer to «TURN SIGNAL & MULTIFUNCTION SWITCH ASSEMBLY - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__turn-signal-multifunction-switch-assembly) .
  4. Install the steering column tilt head components. Refer to «STEERING COLUMN TILT HEAD HOUSING - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__steering-column-tilt-head-housing) .

STEERING SHAFT, LOWER BEARING, & JACKET - DISASSEMBLE OFF VEHICLE (COLUMN SHIFT)

Note. Tools Required: Pivot Pin Remover (J 21854-01).

WARNINGThis vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment. Personal injury. Unnecessary SIR system repairs. In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING SYSTEM .

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. Disable the inflatable restraint steering wheel module. Refer to «DISABLING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) .
  2. Remove the turn signal switch housing. Refer to «TURN SIGNAL SWITCH HOUSING - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__turn-signal-switch-housing-disassemble) .
  3. Remove the tilt spring only. Refer to «TILT SPRING - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  4. Remove the linear shift assembly and the automatic transmission shift lock control only. Refer to «LINEAR SHIFT ASSEMBLY - DISASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__linear-shift-assembly-disassemble) .
  5. Remove 2 pivot pins (1) from the steering column support assembly using J 21854-01.
  6. If the sensor assembly is present, perform the following steps. Remove the boot (5). Remove the steering shaft seal (4). Remove the sensor retainer (3). Remove the sensor locator (2). Remove the sensor steer assembly (1).
  7. If you do not have a sensor assembly, perform the following: Remove the boot (4). Remove the steering shaft seal (3). Remove the sensor retainer (2). Remove the boot seal (1).
  8. Remove the 3 flat head screws.
  9. Remove the cable support bracket.
  10. Remove the tilt head assembly (1) from the steering column support assembly (2) with the steering shaft (3) still attached.
  11. Remove the tilt head assembly (1) from the steering shaft assembly (2). NOTE: Mark the race and upper shaft (1) and the lower steering shaft (2) to ensure proper assembly. Failure to assemble properly will cause the steering wheel to be tuned 180 degrees.
  12. Tilt the upper shaft assembly 90 degrees to the steering shaft assembly and disengage.

Scheme 28

Scheme 28: STEERING SHAFT, LOWER BEARING, & JACKET ASSEMBLE OFF VEHICLE (COLUMN SHIFT)
Scheme 28: STEERING SHAFT, LOWER BEARING, & JACKET ASSEMBLE OFF VEHICLE (COLUMN SHIFT)

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31
  1. Apply lithium grease to the race and upper shaft assembly.
  2. Align the marks on the race and upper shaft assembly with the lower shaft assembly marks you made from the disassemble procedure.
  3. Install the lower shaft assembly to the race and upper shaft assembly.
  4. Install the cable support bracket. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Lubricate the 3 flat head screws with LOCTITE®. Install the 3 flat head screws. Tighten the screws to 10 N.m (89 in lbs).
  6. If no sensor assembly is present, perform the following steps: Install the boot seal (1). Install the sensor retainer (2). Install the steering shaft seal (3). Install the boot (4).
  7. If a sensor assembly is present, perform the following steps: Install the sensor steer assembly (1). The sensor steer assembly must be aligned to the 9 o'clock position. Install the sensor locator (2). Install the sensor retainer (3). Install the steering shaft seal (4). Install the boot (5).
  8. Install the steering shaft assembly (2) into the steering column tilt head assembly (1).
  9. Install the tilt head assembly (1) and the steering shaft (3) into the steering column jacket assembly (2). NOTE: Replace the steering column support assembly if the steering column support assembly has been staked 3 times.
  10. Lubricate the pivot pins with synthetic grease. Install the 2 pivot pins onto the steering column support assembly. Stake the pins in 3 places. WARNING: Improper routing of the wire harness assembly may damage the inflatable restraint steering wheel module coil. This may result in a malfunction of the coil, which may cause personal injury.
  11. Install the linear shift assembly and the automatic transmission shift lock control only. Refer to «LINEAR SHIFT ASSEMBLY - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__linear-shift-assembly-assemble) .
  12. Install the tilt spring assembly only. Refer to «TILT SPRING - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column) .
  13. Install the turn signal switch housing. Refer to «TURN SIGNAL SWITCH HOUSING - ASSEMBLE - OFF VEHICLE»(/buick/lesabre/viii-2000-2005/remont/ignition-switchsteering-lock/#steering-wheel-steering-column__turn-signal-switch-housing-assemble) .
  14. Enable the inflatable restraint steering wheel module. Refer to «ACTIVATING SYSTEM»(/buick/lesabre/viii-2000-2005/remont/airbag/#supplemental-inflatable-restraint-system__activating-system) .

INFLATABLE RESTRAINT COIL CENTERING OFF VEHICLE (COLUMN SHIFT & FLOOR SHIFT)

CAUTIONThe new SIR coil assembly will be centered. Improper alignment of the SIR coil assembly may damage the unit, causing an inflatable restraint malfunction.

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Verify the following before centering the inflatable restraint steering wheel module coil: The wheels on the vehicle are straight ahead. The block tooth (1) of the steering shaft assembly is in the 12 o'clock position. The ignition switch is in the LOCK position.
  2. If the front (5) of the inflatable restraint steering wheel module coil has a centering window (4), and on the back side (2) a spring service lock (1), perform the following steps: Hold the inflatable restraint steering wheel module coil with the face up. While depressing the spring service lock, rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counterclockwise, until the centering window appears yellow and both arrows (3) line up. Release spring service lock between the locking tab. The inflatable restraint steering wheel module coil is now centered. Align the centered inflatable restraint steering wheel module coil with the horn tower and slide onto the steering shaft assembly.
  3. If the front (4) of the inflatable restraint steering wheel module coil has a centering window (3) and no spring service lock on the back side (1), perform the following steps: Hold the inflatable restraint steering wheel module coil with the face up. Rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counterclockwise until the centering window appears yellow and both arrows (2) line up. This is the CENTER position. While holding the coil hub in the CENTER position, align the inflatable restraint steering wheel module coil with the horn tower and slide onto the steering shaft assembly.
  4. If no centering window is present on the front side (3) of the inflatable restraint steering wheel module coil, but a spring service lock (1) is on the back side (2), perform the following steps: Hold the inflatable restraint steering wheel module coil with the back side up. While depressing the spring service lock, rotate the coil hub in the direction of the arrow (4) until the coil ribbon stops. Still pressing the spring service lock, rotate the coil hub in the opposite direction 2 1/2 revolutions. Release the spring service lock between locking tabs. The inflatable restraint steering wheel module coil is now centered. Align the centered inflatable restraint steering wheel module coil with the horn tower and slide onto the steering shaft assembly.
  5. For no centering window on the front side (2) of the inflatable restraint steering wheel module coil and no spring service lock on the back side (1), perform the following steps: Hold the inflatable restraint steering wheel module coil with the face up. Rotate the coil hub in the direction of the arrow until the coil ribbon stops. Rotate the coil hub, slowly, counterclockwise, for 2 1/2 revolutions. This is the CENTER position. While maintaining the coil hub in the CENTER position, align the centered inflatable restraint steering wheel module coil with the horn tower and slide onto the steering shaft assembly.

STEERING WHEEL & COLUMN DESCRIPTION & OPERATION

The steering wheel and column has 4 primary functions

  1. Vehicle steering.
  2. Vehicle security.
  3. Driver convenience.
  4. Driver safety.

Vehicle Steering

The steering wheel is the first link between the driver and the vehicle. The steering wheel is fastened to a steering shaft within the column. At the lower end of the column, the intermediate: shaft connects the column to the steering gear.

Vehicle Security - Some Vehicle Models

Theft deterrent components are mounted and designed into the steering column. The following components allow the column to be locked in order to minimize theft

  1. The ignition switch.
  2. The steering column lock.
  3. The ignition cylinder.

Driver Convenience

The steering wheel and column may also have driver controls attached for convenience and comfort. The following controls may be mounted on or near the steering wheel or column.

  1. The turn signal switch.
  2. The hazard switch.
  3. The headlamp dimmer switch.
  4. The wiper/washer switch.
  5. The horn pad/cruise control switch.
  6. The redundant radio/entertainment system controls.
  7. The tilt or tilt/telescoping functions.
  8. The navigation/OnStar® features.
  9. The HVAC controls.

Driver Safety

The energy-absorbing steering column compresses in the event of a front-end collision, which reduces the chance of injury to the driver. The mounting capsules break away from the mounting bracket in the event of an accident.

Scheme 37

Scheme 37: SPECIAL TOOLS & EQUIPMENT
Scheme 37: SPECIAL TOOLS & EQUIPMENT

Scheme 38

Scheme 38
Scheme 38

See also:
• DISABLING SYSTEM
• BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE
• KNEE BOLSTER REPLACEMENT
• ACTIVATING SYSTEM
• AUTOMATIC TRANSMISSION SHIFT LOCK ACTUATOR REPLACEMENT
• SIR COIL ASSEMBLY
• SYMPTOMS - STEERING WHEEL AND COLUMN
• STEERING WHEEL & COLUMN DESCRIPTION & OPERATION
• LOCK SYSTEM DOES NOT UNLOCK
• STEERING WHEEL REPLACEMENT
• STEERING COLUMN TRIM COVERS REPLACEMENT - ON VEHICLE
• SHIFT LEVER REPLACEMENT - ON VEHICLE
• STEERING COLUMN ACCIDENT DAMAGE INSPECTION - OFF VEHICLE
• INFLATABLE RESTRAINT COIL CENTERING OFF VEHICLE (COLUMN SHIFT & FLOOR SHIFT)
• TURN SIGNAL & MULTIFUNCTION SWITCH ASSEMBLY - DISASSEMBLE - OFF VEHICLE
• AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL - DISASSEMBLE - OFF VEHICLE
• IGNITION & KEY ALARM SWITCH ASSEMBLY - DISASSEMBLE - OFF VEHICLE
• STEERING COLUMN TILT HEAD HOUSING - DISASSEMBLE - OFF VEHICLE
• INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL - DISASSEMBLE - OFF VEHICLE
• ELECTRONIC COLUMN LOCK MODULE - DISASSEMBLE - OFF VEHICLE
• ELECTRONIC COLUMN LOCK MODULE - ASSEMBLE - OFF VEHICLE
• TURN SIGNAL SWITCH HOUSING - DISASSEMBLE - OFF VEHICLE
• LINEAR SHIFT ASSEMBLY - DISASSEMBLE - OFF VEHICLE
• LINEAR SHIFT ASSEMBLY - ASSEMBLE - OFF VEHICLE
• TURN SIGNAL SWITCH HOUSING - ASSEMBLE - OFF VEHICLE
