Battery, Charging System and Starting System (Hybrid (hp6)) Buick LaCrosse II

Battery Usage

Battery Usage

Scheme 11

Scheme 12

Diagnostic Code Index

DIAGNOSTIC CODE INDEX

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Circuit/System Description

The vehicle control modules or sensors monitor the system voltage to verify the system voltage is within the normal operating range.

Conditions for Running the DTC

The engine is running.

Conditions for Setting the DTC

The control module or sensor detects a system voltage of less than approximately 9 V or greater than 18 V for approximately 5 seconds.

Action Taken When the DTC Sets

1. A driver information center message and/or warning indicator may be displayed.
2. The control module may be temporarily disabled.
3. For P0562 set in the starter/generator control module, the starter/generator control module is turned off and high voltage contactor opens for remainder of ignition cycle

Conditions for Clearing the DTC

1. The system voltage returns to normal operating range.
2. For P0562 set in the starter/generator control module, the system voltage is at normal operating range on the next ignition cycle.

Diagnostic Aids

1. A high or low voltage DTC set or voltage value in multiple modules/sensors indicates a concern in the charging system.
2. A possible cause of this DTC could be overcharging with a battery charger or jump starting.

Reference Information

Schematic Reference

Control Module References

Connector End View Reference

1. «COMPONENT CONNECTOR END VIEWS - INDEX»(/buick/lacrosse/ii-2009-2013/remont/body-electrical/#wiring-systems-and-power-management-component-connector-end-views-index)
2. «Inline Harness Connector End Views»(/buick/lacrosse/ii-2009-2013/remont/body-electrical/#wiring-systems-and-power-management-inline-harness-connector-end-views)

Description and Operation

Charging System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

DTC Type Reference

Powertrain Diagnostic Trouble Code (DTC) Type Definitions

Scan Tool Reference

Control Module References for scan tool information

Special Tools

1. DT 47825-10 Adapter Harness
2. DT 47825-20 Adapter Harness
3. DT 48616-10 Adapter Harness

For equivalent regional tools, refer to Special Tools .

Circuit/System Verification

1. Ignition OFF, measure and record the battery voltage at the battery terminals. The battery voltage should stabilize between 12.4 and 12.8 V within a few minutes of turning the ignition OFF. If not within the specified range, refer to «Battery Inspection/Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) .
2. Engine running, accessories OFF, measure and record the battery voltage at the battery terminals. The voltage should be at least 1 V greater than the voltage measured in step 1 but less than 15 V. If not within the specified range, refer to «Charging System Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) .
3. Observe the appropriate module scan tool B+ and ignition voltage parameters. The voltage readings should be within 1 V of the battery voltage.

Circuit/System Testing

Note. Use the schematic to identify the following: Control modules the vehicle is equipped with The control modules ground, B+, and ignition circuit terminal IDs and connectors

1. Ignition OFF, disconnect the harness connectors at the appropriate control module.
2. For the transmission control module only, connect the appropriate adapter harness to the transmission connector.
3. Ignition OFF, scan tool disconnected, open and close the driver door and wait 1 minute. Test for less than 10 ohms between each ground circuit terminal and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
4. If equipped, test for greater than 9 V between each B+ circuit terminal and ground. If less than the specified range, test the B+ circuit for a short to ground or an open/high resistance.
5. If equipped, ignition ON, test for greater than 9 V between each ignition circuit terminal and ground. If less than the specified range, test the ignition circuit for a short to ground or an open/high resistance.
6. If all circuits test normal, replace the appropriate control module.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for control module replacement, programming and setup

Symptoms - Engine Electrical

The following steps must be completed before using the symptom diagnostic procedures

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) before using the symptom diagnostic procedures in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system descriptions and operations in order to familiarize yourself with the system functions. Refer to one of the following system operations: «Battery Description and Operation»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid__battery-description-and-operation) «Charging System Description and Operation»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) «Electrical Power Management Description and Operation»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid)

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the starting and charging systems. Refer to «Checking Aftermarket Accessories»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories) .
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Battery Inspection/Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-hybrid-hp6)
2. «Battery Charging»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-hybrid-hp6)
3. «Battery Electrical Drain/Parasitic Load Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid)
4. «Charging System Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-hybrid-hp6)

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Note. The battery test using the regionally available battery tester requires correct connections to the battery terminals. Ensure that battery tester clamps are connected directly to either the battery post or the battery cable terminal. Do not connect clamps to battery cable fasteners. Failure to obtain the correct connections during the test may result in a failed test on a good battery. Use the Out of Vehicle test for each battery when testing a vehicle with dual batteries.

Follow these instructions in order to avoid an incorrect diagnosis because of connections

1. If testing the vehicle with the battery cables still connected, wiggle the battery tester clips on the terminal. This may cut through any coating or through any oxidation that may be present on the terminal.
2. If correct connections to the battery terminals in the vehicle are in doubt, perform the following steps: Disconnect the negative battery cable. Disconnect the positive battery cable. Follow the instructions for testing a removed battery.
3. If the tester displays a REPLACE BATTERY or BAD CELL-REPLACE result for a battery tested in the vehicle with the battery cables connected, perform the following steps: Disconnect the negative battery cable. Disconnect the positive battery cable. NOTE: Always write the test code displayed by the tester on the repair order for any warranty purposes. The number is a unique code that describes the test data for a particular battery at a particular time. The test code may occasionally repeat when you retest the same battery. More often, each test will result in a different code. Use the test code from the second, or Out of Vehicle test. Follow the instructions for testing a removed battery. Replace the battery only if the second test shows a REPLACE BATTERY or BAD CELL-REPLACE result. Use the test code from the second test for any warranty purposes.

Schematic Reference

Starting and Charging Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Starting System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Special Tools

Battery Tester, for regionally available devices, refer to Special Tools .

1. Verify the C1 battery case is not cracked, broken, or damaged, which may be indicated by battery acid leakage. If there is any apparent damage Replace the C1 battery. If there is no damage
2. Verify the cold cranking amperage and amperage hour rating of the C1 battery. Refer to the manufacturer specifications on the battery label. If the C1 battery does not meet or exceed specifications Replace the C1 Battery. If the C1 Battery meets or exceeds specifications
3. Verify that the battery cables are clean and tight. The battery terminal bolts should be torqued as specified in «Fastener Tightening Specifications»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid__fastener-tightening-specifications) . If the battery cables need to be cleaned or tightened Clean as required and tighten as specified. If the battery cables are clean and tight
4. Install the battery tester and follow directions supplied by the tester.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Battery Replacement

Note. This procedure pertains to charging the 12V battery only. There is no procedure to charge the Hybrid/EV Battery Pack outside of the vehicle.

Special Tools

EL 42000 Battery Tester

For equivalent regional tools, refer to Special Tools

Note. For best results, use an automatic taper-rate battery charger with a voltage capability of 16 volts. The charging area should be well ventilated. Do not charge a battery that appears to be frozen. Allow the battery to warm to room temperature and test it using the EL 42000 before charging.

Battery State of Charge

Note. Using voltage to determine the batteries state of charge (SOC) is only accurate after the battery has been at rest for 24 hours. This is enough time for the acid in each cell to equalize. If the battery has been charged or discharged in the past 24 hours, the battery SOC will only be an estimate.

The maintenance-free batteries SOC is estimated by reading the voltage of the battery across the battery terminals. Because the voltage is affected by current flow into or out of the battery, the engine must be stopped and all electrical loads turned OFF, including parasitic loads, when checking the voltage. The voltage can also be affected if the battery has just been charged or discharged, so it is important to consider what has happened to the battery in the time just before testing. Use the following procedure to determine the battery's state of charge

1. Be sure all electrical loads are turned OFF.
2. Determine whether the battery has been used in a vehicle or charged within the past 12 hours. If the answer is no, the terminal voltage will be stabilized and no action is necessary before reading the voltage. Skip to step 3. If the answer is yes, terminal voltage will not be stabilized and you should wait 12 hours since the last time the battery was used.
3. Estimate the battery temperature by determining the average temperature to which the battery has been exposed for the past 12 hours.
4. Measure the battery voltage at the battery terminals. Refer to the following table to determine the state of charge according to the estimated battery temperature

Battery Charging

Use the state of charge information as follows

1. A battery with a state of charge that is below 65 percent must always be recharged before returning it to service or continuing storage.
2. A battery with a state of charge that is 65 percent or greater is generally considered to be charged enough in order to be returned to normal service or in order to continue storage. However, if the battery is being used in slow traffic or with short drive times, or if the temperature is very hot or very cold, the battery should be fully charged, to at least 90 percent, before returning it to service or continuing storage.

Charging Time Required

The time required to charge a battery will vary depending upon the following factors

1. The battery charger capacity-The higher the charger's amperage, the less time it will take to charge the battery.
2. The SOC of the battery-A completely discharged battery requires more than twice as much charging time as a half charged battery. In a discharged battery with a voltage below 11 volts, the battery has a very high internal resistance and may only accept a very low current at first. Later, as the charging current causes the acid content to increase in the electrolyte, the charging current will increase. Extremely discharged batteries may not activate the reversed voltage protection in some chargers. Refer to the manufacturers instructions for operating this circuitry.
3. The temperature of the battery-The colder the battery is, the more time it takes to recharge the battery. The charging current accepted by a cold battery is very low at first. As the battery warms, the charging current will increase.

Charging Procedure

Use the following procedure to charge the battery

1. Turn OFF the charger.
2. Ensure that all of the battery terminal connections are clean and tight.
3. Connect the charger positive lead to the battery positive terminal on the battery or fuse block - underhood.
4. Connect the negative charger lead to a solid engine ground or to a ground stud in the engine compartment that is connected directly to the battery negative terminal, but away from the battery. If the negative battery cable is disconnected and a terminal adapter is being used, connect directly to the battery terminal.
5. Turn ON the charger and set to the highest setting for normal charging.
6. Inspect the battery every half hour after starting the battery charger. Charge the battery until the taper-rate charger indicates that the battery is fully charged. Estimate the battery temperature by feeling the side of the battery. If it feels hot to the touch or its temperature is over 45°C (125°F), discontinue charging and allow the battery to cool before resuming charging.
7. After charging, test the battery. Refer to «Battery Inspection/Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) .

12 V Battery

The following procedure is for the 12 V battery only.

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Components most likely to cause a parasitic draw on the vehicles battery are switches, relays, and control modules. After the ignition is turned OFF the control modules will begin to go to sleep (shut OFF). All control modules do not go to sleep at the same time, some may take up to 30 min or longer after turning the ignition off before going to sleep, like the HVAC and body control modules. Others such as the ON Star and keyless entry control modules may periodically wake up then go back to sleep. These are all normal conditions.

1. Rule out any possible aftermarket equipment causing an unacceptable parasitic current drain. Aftermarket accessories installed into the courtesy lamp circuit can cause the inadvertent power timer in the body control module (BCM) to keep resetting. This may cause the BCM to remain awake and cause a current drain on the battery.
2. Rule out customer driving habits such as regular short trips that do not allow enough time to properly charge the battery. Refer to «Battery Description and Operation»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid__battery-description-and-operation) .
3. Verify that the battery and charging system are in proper working order. Refer to «Battery Charging»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) , and «Charging System Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) .
4. A battery discharging for no apparent reason while the vehicle is parked can be caused by an intermittent draw, such as a module waking up, or a continuous draw, such as a dome light or stuck relay.
5. Some systems and modules such as OnStar®, and regulated voltage control, if equipped, are designed to wake up, perform a task, and go back asleep at regular intervals. Refer to «Body Control System Description and Operation»(/buick/lacrosse/ii-2009-2013/remont/communication-devices/#data-communications-system__body-control-system-description-and-operation) for the system or modules description and operation.
6. An engine off natural vacuum evaporative test can occur if the engine control module (ECM) determines the drive cycle has met the appropriate criteria immediately after key off. The ECM will stay awake and the vent solenoid will stay energized for as long as 45 min. The typical current draw for this is about 1 A.
7. Digital OnStar generator 6 and later vehicle communication interface module do not "wake up" every 10 min for the first 48 h as the generator 5 and prior. Generator 6 and later vehicle communication interface module current draw is very low, less than 40 mA, so the OnStar system is left in that state for up to the first 48 h. Parasitic draw of up to 40 mA with an occasional spike as high as 80 mA through the vehicle communication interface module for the first 48 h is normal.
8. Some automatic climate control systems can remain in a semi awake state for up to three hours, actual draw amounts vary by vehicle platform but are typically not greater than 50 mA.
9. An extremely low mA current level is consumed by the remote keyless entry receiver for monitoring purposes, actual system wake up only occurs when the fobs for the vehicle are used. When other devices on the same remote keyless entry operating frequency are activated, such as the 4 tire pressure monitoring sensors and other vehicle FOBs in the vicinity, the remote keyless entry receiver will have a 100 mA spike. These spikes are normal and occur too briefly to have a significant effect on battery drain. Competing signals may cause remote keyless entry performance issues such as jamming but should not cause excessive battery draw.
10. If an excessive current draw is not present during initial testing, continue periodic testing over a 1-2 hour period to see if the current draw increases and stays above an unacceptable level.
11. The battery run down time will vary depending on the batteries reserve capacity. If the reserve capacity is higher, then the battery run down time may be longer. If the reserve capacity is lower, then the battery run down time may be shorter. The graph below indicates roughly how many days a 690 cold cranking amperage battery with a 110 min. reserve capacity starting at 80 percent state of charge will last with a constant current draw until it reaches 50 percent state of charge. Differences in battery reserve capacity and temperature will affect the results.

Schematic Reference

Control Module References

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Electrical Information Reference

1. «Circuit Testing»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Testing for Intermittent Conditions and Poor Connections»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
3. «Connector Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
4. «Wiring Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Special Tools

EL 38758 Parasitic Draw Test Switch

For equivalent regional tools, refer to Special Tools .

Note. Most vehicle systems will go to sleep within 30 min but it can take up to 2 h before all systems power down allowing the parasitic draw test to pass. An occasional increase in the parasitic draw is normal as long as it returns within 1 s. Closing the door latches/ajar switch while leaving the doors open is recommended, this allows the vehicle systems to perform in a "doors closed" mode while allowing vehicle interior access that may be needed to complete the diagnostic steps. Locking doors will arm the vehicle content theft deterrent system if equipped. Failure to arm the system may cause a theft system fault to not be present during testing. There are many things that can prevent the vehicle from completely going to sleep and passing the parasitic draw test. Make sure all the conditions listed below are met before performing the parasitic current draw test. Ignition OFF Key out of the ignition switch - when not equipped with keyless access and start Retained Accessory Power OFF - open and close the driver door after ignition OFF Scan tool not communicating with a vehicle control module - in some cases it may need to be disconnected from the DLC All access doors closed Headlamps OFF - auto headlamps disabled Any delay lighting OFF If equipped with an under hood lamp disable it HVAC after blow OFF Any accessory that can work with ignition OFF inactive or OFF Wait up to 2 min or longer, after all other listed conditions are met

Using an Inductive Pickup Probe

1. Connect an inductive pickup probe to the negative battery cable that can read down to 1 mA.
2. Ignition OFF, as the vehicle systems shut down test for less than 30 mA of parasitic current drain. If greater than the specified range, refer to Circuit/System Testing below.

Using the EL 38758 Parasitic Draw Test Switch

1. Ignition OFF, disconnect the battery negative cable from the battery. Refer to «Battery Negative Cable Disconnection and Connection»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) .
2. Turn the EL 38758 switch knob to the OFF position.
3. Install the male end of the EL 38758 switch to the battery ground terminal.
4. Install the battery negative cable to the female end of the EL 38758 switch.
5. Turn the EL 38758 switch knob to the ON position.
6. Road test the vehicle and activate all of the accessories such as the radio and air conditioning.
7. Ignition OFF, connect a 10 A fused jumper wire to the test switch tool terminals.
8. Turn the EL 38758 switch knob to the OFF position. The current now flows through the jumper wire.
9. Check the fuse in the jumper wire. The fuse should be OK. Failed: If the jumper wire fuse is blown, refer to Circuit/System Testing below. Passed
10. Turn the EL 38758 switch knob to the ON position. Remove the fused jumper wire.
11. Connect a DMM set to the 10 A DC scale between the test switch tool terminals.
12. Turn the EL 38758 switch knob to the OFF position. The current now flows through the DMM.
13. As the vehicle systems shut down test for less than 30 mA of parasitic current drain. If greater than the specified range, refer to Circuit/System Testing below.

Note. Removing or installing a fuse, relay, or connector, to determine the area causing high parasitic draw may wake up control modules. You must wait for the control modules to go back to sleep before retesting. It is best to install any removed or disconnected components after the diagnosis is completed. Fuses for power mode master components such as the BCM should be removed last to avoid misdiagnosis. If a scan tool is connected to the DLC, either disconnect it or subtract the scan tool current draw from the DMM reading to get the actual vehicle parasitic current draw.

If the vehicle has an unacceptable amount of parasitic current draw, remove each fuse one at a time until the current draw falls to an acceptable level. A drop of more than 10-20 mA, when disabling a single system or circuit, is an indication of an overly high current draw that could be causing the battery drain. Refer to Power Distribution Schematics to diagnose exactly which circuit of the suspect system is causing the high parasitic drain. The following is a list of common components that could cause a high current draw

1. Stuck switch
2. Stuck relay
3. Control module

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for control module replacement, programming and setup

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The starter/generator control module supplies the energy that flows between the high voltage (110 volt) direct current (DC) and low voltage (14 volt) DC to charge the 12 volt battery and power accessories. For more information about the starter/generator control module functions, refer to Drive Motor Battery System Description .

Schematic Reference

Starting and Charging Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Charging System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Engine running, observe the charge indicator on the instrument cluster or message in the driver information center display. The charge indicator on the instrument cluster should be turned OFF and the driver information center display should not display any charging system message.

1. Ignition ON, verify that no G13 Generator or B18 battery current sensor DTCs are set that would cause a charging system concern. If DTCs are set, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-trouble-code-dtc-list)
2. Ignition OFF, measure the voltage across the battery terminals. The voltage should read 12.0 V or greater at room temperature. If not within the specified value, refer to «Battery Inspection/Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid)
3. Engine ON, increase engine speed to 2, 500 RPM. Verify the battery voltage is between 12.6-15.0 V. If not within specified range, replace the K59 Starter/Generator Control Module.
4. Engine ON, increase engine speed to 2, 500 RPM. Turn ON all vehicle accessories. Verify the battery voltage is between 12.6-15.0 V. If not within specified range, replace the K59 Starter/Generator Control Module.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Starter Generator Replacement

The following information is for the 12 V battery only.

For information about charging the high voltage drive motor batteries, refer to Drive Motor Battery System Description .

Electrical Power Management (EPM) Overview

The electrical power management (EPM) system is designed to monitor and control the charging system and send diagnostic messages to alert the driver of possible problems. This EPM system primarily utilizes existing on-board computer capability to maximize the effectiveness of the charging system, manage the load, improve battery state-of-charge and life, and minimize the system's impact on fuel economy. The EPM system performs 3 functions

1. It monitors the battery voltage and estimates the battery condition.
2. It takes corrective actions by adjusting the regulated voltage.
3. It performs diagnostics and driver notification.

The battery condition is estimated during ignition off and during ignition on. During ignition off the state-of-charge (SOC) of the battery is determined by measuring the open-circuit voltage. The SOC is a function of the acid concentration and the internal resistance of the battery, and is estimated by reading the battery open circuit voltage when the battery has been at rest for several hours.

The SOC can be used as a diagnostic tool to tell the customer or the dealer the condition of the battery. Throughout ignition-on, the algorithm continuously estimates SOC based on adjusted net amp hours, battery capacity, initial SOC, and temperature.

While running, the battery degree of discharge is primarily determined by a battery current sensor, which is integrated to obtain net amp hours.

In addition, the EPM function is designed to perform regulated voltage control (RVC) to improve battery SOC, battery life, and fuel economy. This is accomplished by using knowledge of the battery SOC and temperature to set the charging voltage to an optimum battery voltage level for recharging without detriment to battery life.

Charging System Components

Starter/Generator Control Module

The starter/generator control module is a serviceable GMLAN device located in the luggage compartment. It is connected to the vehicle's 12 and 110-volt DC power circuits, and it is also joined to the starter/generator by 3-phase AC cables. The starter/generator control module is air-cooled. The hybrid/EV battery pack cooling fan draws air in through ports in the rear package shelf, flows across the Hybid/EV battery pack and cooling fins of the starter/generator control module, then blows the air out of the vehicle through ports in the luggage compartment. The starter/generator control module performs three main functions

1. As the power inverter for the starter-generator, the starter/generator control module converts 110-volt DC power into 3-phase AC power to drive the starter-generator as a motor.
2. The power inverter also rectifies 110-volt AC output power from the starter/generator into the 110-volt DC power used to charge the 110-volt generator battery.
3. An auxiliary power module contained within the starter/generator control module converts 110-volt DC power into the 12-volt DC power which is used for 12-volt vehicle loads and to charge the underhood 12-volt battery. A serviceable 200 amp fuse located in the auxiliary fuse block protects the vehicle's 12-volt electrical system from excessive current. The starter/generator control module controls the starter/generator, transmission auxiliary oil pump, hill-hold solenoids, and the auxiliary coolant pump. The pumps and solenoids are driven by 12-volt pulse width modulated (PWM) power through vehicle wiring harnesses.

Body Control Module (BCM)

The body control module (BCM) is a GMLAN device. It communicates with the engine control module (ECM) and the instrument panel cluster (IPC) for electrical power management (EPM) operation. The BCM determines the desired voltage set point and monitors a battery current sensor, the battery positive voltage circuit, and estimated battery temperature to determine battery state of charge (SOC).

Battery Current Sensor

The battery current sensor is a serviceable component that is connected to the negative battery cable at the battery. The battery current sensor is a 3-wire hall effect current sensor. The battery current sensor monitors the battery current. It directly inputs to the BCM. It creates a 5-V pulse width modulation (PWM) signal of 128 Hz with a duty cycle of 0-100 percent. Normal duty cycle is between 5-95 percent. Between 0-5 percent and 95-100 percent are for diagnostic purposes.

Engine Control Module (ECM)

The ECM receives control decisions based on messages from the BCM.

Instrument Panel Cluster (IPC)

The IPC provides a means of customer notification in case of a failure and a voltmeter. There are 2 means of notification, a charge indicator and a driver information center (DIC) message of SERVICE BATTERY CHARGING SYSTEM.

Charging System Operation

The purpose of the charging system is to maintain the battery charge and vehicle loads. There are 6 modes of operation and they include

1. Battery Sulfation Mode
2. Normal Mode
3. Fuel Economy Mode
4. Headlamp Mode
5. Voltage Reduction Mode
6. Plant Assembly Mode

Battery Sulfation Mode

The BCM will enter this mode when the interpreted charging system voltage is less than 13.2 V for 30 minutes. When this condition exists the BCM will enter Normal Mode for 5 minutes. The BCM will then determine which mode to enter depending on voltage requirements.

Normal Mode

The BCM will enter Normal Mode when ever one of the following conditions are met.

1. The wipers are ON for more than 3 seconds.
2. GMLAN Climate Control Voltage Boost Mode Request is true, as sensed by the HVAC control head. High speed cooling fan, rear defogger and HVAC high speed blower operation can cause the BCM to enter the Charge Mode.
3. The estimated battery temperature is less than 0°C (32°F).
4. Vehicle Speed is greater than 145 km/h (90 mph)
5. Current Sensor Fault Exists
6. System Voltage was determined to be below 12.56 V
7. Tow/Haul Mode is enabled

When any one of these conditions is met, the system will set targeted generator output voltage to a charging voltage between 13.9-15.5 V, depending on the battery state of charge and estimated battery temperature.

Fuel Economy Mode

The BCM will enter Fuel Economy Mode when the ambient air temperature is at least 0°C (32°F) but less than or equal to 80°C (176°F), the calculated battery current is greater than -8 amps but less than 5 amps, and the battery state of charge (SOC) is greater than or equal to 85 percent. Its targeted set-point voltage is the open circuit voltage of the battery and can be between 12.6-13.2 V. The BCM will exit this mode and enter Normal Mode when any of the conditions described above are present.

Headlamp Mode

The BCM will enter Headlamp Mode when ever the high or low beam headlamps are ON. Voltage will be regulated between 13.9-14.5 V

Voltage Reduction Mode

The BCM will enter Voltage Reduction Mode when the calculated battery temperature is above 0°C (32°F) and the calculated battery current is greater than -7 A but less than 1 A. Its targeted set-point voltage is 12.9-13.2 V. The BCM will exit this mode once the criteria are met for Normal Mode. Engages Start Up Mode When the engine is started the BCM sets a targeted set-point voltage of 14.3 V for 30 seconds.

Plant Assembly Mode

The BCM will increase charging voltage for the first 500 miles of operation in an effort to ensure that the 12 V battery is fully charged when the vehicle is delivered to the customer.

Instrument Panel Cluster (IPC) Operation

Charge Indicator Operation

The instrument panel cluster (IPC) illuminates the charge indicator and displays a warning message in the driver information center (DIC) when the one or more of the following occurs

1. The engine control module (ECM) detects system voltage less than 11 V or greater than 16 V. The IPC receives a GMLAN message from the ECM requesting illumination.
2. The BCM determines that the system voltage is less than 11 V or greater than 16 V.
3. The IPC receives a GMLAN message from the body control module (BCM) indicating there is a system voltage range concern.
4. The IPC performs the displays test at the start of each ignition cycle. The indicator illuminates for approximately 3 seconds.
5. The ignition is ON, with the engine OFF.

SERVICE BATTERY CHARGING SYSTEM

The BCM and the ECM will send a GMLAN message to the DIC for the SERVICE BATTERY CHARGING SYSTEM message to be displayed. It is displayed whenever the charge indicator is commanded ON due to a failure.

12-V Starting System

The following information is for the 12 V starter motor only. The 12 V starter motor is used for initial starting of the engine.

The high voltage starter/generator is used to start the engine once the vehicle is in autostop/autostart mode. For information about charging the high voltage starting system, refer to Starter Generator Description and Operation.

12-V Starting System Components

The starter motors are non-repairable starter motors. They have pole pieces that are arranged around the armature. Both solenoid windings are energized. The pull-in winding circuit is completed to the ground through the starter motor. The windings work together magnetically to pull and hold in the plunger. The plunger moves the shift lever. This action causes the starter drive assembly to rotate on the armature shaft spline as it engages with the flywheel ring gear on the engine. Moving at the same time, the plunger also closes the solenoid switch contacts in the starter solenoid. Full battery voltage is applied directly to the starter motor and it cranks the engine.

As soon as the solenoid switch contacts close, current stops flowing thorough the pull-in winding because battery voltage is applied to both ends of the windings. The hold-in winding remains energized. Its magnetic field is strong enough to hold the plunger, shift lever, starter drive assembly, and solenoid switch contacts in place to continue cranking the engine. When the engine starts, pinion overrun protects the armature from excessive speed until the switch is opened.

When the ignition switch is released from the START position, the START relay opens and battery voltage is removed from the starter solenoid S terminal. Current flows from the motor contacts through both windings to the ground at the end of the hold-in winding. However, the direction of the current flow through the pull-in winding is now opposite the direction of the current flow when the winding was first energized.

The magnetic fields of the pull-in and hold-in windings now oppose one another. This action of the windings, along with the help of the return spring, causes the starter drive assembly to disengage and the solenoid switch contacts to open simultaneously. As soon as the contacts open, the starter circuit is turned off.

Circuit Description (Key Start)

When the ignition switch is placed in the Start position, a discrete signal is supplied to the body control module (BCM) notifying it that the ignition is in the Start position. The BCM then sends a message to the engine control module (ECM) notifying it that CRANK has been requested. The ECM verifies that the transmission is in Park or Neutral. If it is, the ECM then supplies 12 V to the control circuit of the crank relay. When this occurs, battery positive voltage is supplied through the switch side of the crank relay to the S terminal of the starter solenoid.

Special Tools

Illustration Tool Number/Description EL 38758 EL 50074 J 38758 Parasitic Draw Test Switch EL 50313 EL 42000 EL 50076 J 42000 Battery Tester EL-48900 HEV Safety Kit

Scheme 13

Scheme 14

Scheme 15

See also:
• Diagnostic System Check - Vehicle
• Strategy Based Diagnosis
• Diagnostic Procedure Instructions
• Control Module References
• COMPONENT CONNECTOR END VIEWS - INDEX
• Inline Harness Connector End Views
• Charging System Description and Operation
• Circuit Testing
• Connector Repairs
• Testing for Intermittent Conditions and Poor Connections
• Wiring Repairs
• Special Tools
• Diagnostic Repair Verification
• Battery Description and Operation
• Checking Aftermarket Accessories
• Battery Disconnect Warning
• Starting System Description and Operation
• Fastener Tightening Specifications
• Fastener Caution
• Body Control System Description and Operation
• Power Distribution Schematics
• Drive Motor Battery System Description
• Diagnostic Trouble Code (DTC) List - Vehicle
• Starter Generator Replacement
• DTC B1325, B1330, B1420, B1424, B1517, C0800, C0895, C0899, C0900, C12E1, C12E2, P0560, P0562, or P0563
