Note. Component Connector end views are sorted in alpha/Numeric sequence based upon connector ID (Code), NOT component name.
E5AB Tail/Stop Lamp - Right
| Connector Part Information Harness Type: Right Tail Lamp OEM Connector: 43645-0300 Service Connector: Service by Harness - See Part Catalog Description: 3-Way F Micro-Fit Series (BK) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | BK | 550 | Ground | |
| 2 | 0.5 | BN | 7541 | Right Rear Stop Lamp Supply Voltage | |
| 3 | 0.5 | L-BU/RD | 309 | Right Park Lamp Supply Voltage | |
E5AB Tail/Stop Lamp - Right
E5B Backup Lamp - Right
| Connector Part Information Harness Type: Right Tail Lamp OEM Connector: 16530675 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (L-GY) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 0.8 | L-GN | 24 | Backup Lamp Supply Voltage | |
| B | 0.8 | BK | 550 | Ground | |
E7L License Plate Lamp - Left
| Connector Part Information Harness Type: License Lamp OEM Connector: 13698133 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F Lamp Socket Wedge, Sealed (BK) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GN/YE | 6846 | Rear License Lamp Supply Voltage | |
| 2 | 0.35 | BK | 2550 | Ground | |
E7L License Plate Lamp - Left
E7R License Plate Lamp - Right
| Connector Part Information Harness Type: License Lamp OEM Connector: 13698133 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F Lamp Socket Wedge, Sealed (BK) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GN/YE | 6846 | Rear License Lamp Supply Voltage | |
| 2 | 0.35 | BK | 2550 | Ground | |
E7R License Plate Lamp - Right
E8D Door Courtesy Lamp - Driver
| Connector Part Information Harness Type: Door Trim OEM Connector: 19115613 Service Connector: 19179373 Description: 2-Way F 1.5/0.64 Series (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 19115613 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 157 | Interior Lamp Control | |
| 2 | 0.35 | BK | 850 | Ground | |
E8D Door Courtesy Lamp - Driver
E8J Instrument Panel Courtesy Lamp - Left
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595207 Service Connector: 13584097 Description: 2-Way F 0.64 Series (BK) | Terminal Part Information Terminated Lead: 13575790 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 157 | Interior Lamp Control | |
| 2 | 0.35 | BK | 1550 | Ground | |
E8J Instrument Panel Courtesy Lamp - Left
E8K Instrument Panel Courtesy Lamp - Right
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595207 Service Connector: 13584097 Description: 2-Way F 0.64 Series (BK) | Terminal Part Information Terminated Lead: 13575790 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 157 | Interior Lamp Control | |
| 2 | 0.35 | BK | 1550 | Ground | |
E8K Instrument Panel Courtesy Lamp - Right
E8LR Door Courtesy Lamp - Left Rear
| Connector Part Information Harness Type: Door Trim OEM Connector: 19115613 Service Connector: 19179373 Description: 2-Way F 1.5/0.64 Series (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 19115613 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 157 | Interior Lamp Control | |
| 2 | 0.35 | BK | 850 | Ground | |
E8LR Door Courtesy Lamp - Left Rear
E8P Door Courtesy Lamp - Passenger
| Connector Part Information Harness Type: Door Trim OEM Connector: 19115613 Service Connector: 19179373 Description: 2-Way F 1.5/0.64 Series (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 19115613 Release Tool: Not Available Diagnostic Test Probe :Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 157 | Interior Lamp Control | |
| 2 | 0.35 | BK | 850 | Ground | |
E8P Door Courtesy Lamp - Passenger
E8RR Door Courtesy Lamp - Right Rear
| Connector Part Information Harness Type: Door Trim OEM Connector: 19115613 Service Connector: 19179373 Description: 2-Way F 1.5/0.64 Series (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 19115613 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 157 | Interior Lamp Control | |
| 2 | 0.35 | BK | 850 | Ground | |
E8RR Door Courtesy Lamp - Right Rear
E8S Rear Compartment Courtesy Lamp
| Connector Part Information Harness Type: Body OEM Connector: 13595207 Service Connector: 13584097 Description: 2-Way F 0.64 Series (BK) | Terminal Part Information Terminated Lead: 13575790 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | L-GN/GY | 737 | Trunk Lamp Control | |
| 2 | 0.5 | BK | 2550 | Ground | |
E8S Rear Compartment Courtesy Lamp
E14A Seat Heating Element - Driver Back (KA1)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 24414864 Service Connector: 19167758 Description: 2-Way F 1.2 Timer Series (NA) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 19167758 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 1.0 | GN/BK | 2424 | Driver Heated Back Element Low Reference | |
| 2 | 1.0 | BU/BN | 2078 | Driver Heated Seat Element Low Reference | |
E14A Seat Heating Element - Driver Back (KA1)
E14B Seat Heating Element - Driver Cushion (KA1)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 12790202 Service Connector: Service by Harness - See Part Catalog Description: 8-Way M 1.6 Micro Timer Series (BK) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 1.0 | RD/WH | 2077 | Driver Heated Seat Element Supply Voltage | |
| 2 | 0.8 | BU/BN | 2078 | Driver Heated Seat Element Low Reference | |
| 3 | 0.5 | GN/PU | 2080 | Driver Heated Seat NTC Low Reference | |
| 4 | 0.5 | PK | 2079 | Driver Heated Seat NTC Signal | |
| 5-8 | | | | Not Used | |
E14B Seat Heating Element - Driver Cushion (KA1)
E14C Seat Heating Element - Passenger Back (KA1)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 24414864 Service Connector: 19167758 Description: 2-Way F 1.2 Timer Series (NA) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 19167758 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 1.0 | WH | 2433 | Passenger Heated Back Element Low Reference | |
| 2 | 1.0 | BU/BN | 2480 | Passenger Heated Seat Element Low Reference | |
E14C Seat Heating Element - Passenger Back (KA1)
E14D Seat Heating Element - Passenger Cushion (KA1)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 12790202 Service Connector: Service by Harness - See Part Catalog Description: 8-Way M 1.6 Micro Timer Series (BK) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 1.0 | WH/OG | 2479 | Passenger Heated Seat Element Supply Voltage | |
| 2 | 1.0 | BU/BN | 2480 | Passenger Heated Seat Element Low Reference | |
| 3 | 0.5 | GY/BK | 2434 | Passenger Heated Seat NTC Signal | |
| 4 | 0.5 | BK/RD | 2435 | Passenger Heated Seat NTC Low Reference | |
| 5-8 | | | | Not Used | |
E14D Seat Heating Element - Passenger Cushion (KA1)
E18 Rear Defogger Grid X1
| Connector Part Information Harness Type: PigTail OEM Connector: 13129191 Service Connector: 88988738 Description: 1-Way F (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 88988738 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 3.0 | BK | 293 | Rear Defog Element Supply Voltage | |
E18 Rear Defogger Grid X1
E18 Rear Defogger Grid X2
| Connector Part Information Harness Type: PigTail OEM Connector: 13129191 Service Connector: 88988738 Description: 1-Way F (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 88988738 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 3.0 BK | BK | 650 | Ground | |
E18 Rear Defogger Grid X2
E27 Instrument Panel Compartment Lamp
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13595207 Service Connector: 13584097 Description: 2-Way F 0.64 Series (BK) | Terminal Part Information Terminated Lead: 13575790 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | WH/BN | 6815 | Inadvertent Power Control | |
| 2 | 0.35 | BK | 1550 | Ground | |
E27 Instrument Panel Compartment Lamp
E28 Center Console Compartment Lamp
| Connector Part Information Harness Type: Console OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK) | Terminal Part Information Terminated Lead: 13575464 Release Tool: J-318125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 15326030/5 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 0.35 | WH/BN | 6815 | Inadvertent Power Control | |
| B | 0.35 | BK | 1550 | Ground | |
E28 Center Console Compartment Lamp
E29LF Fog Lamp - Left Front (T3U)
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 12124819 Service Connector: 13584255 Description: 2-Way F Metri-Pack 280 Series, Sealed (BK) | Terminal Part Information Terminated Lead: 13575418 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 12077411/2 Core/Insulation Crimp: 2/5 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 0.5 | BN/VT | 2234 | Front Fog Lamp Supply Voltage | |
| B | 0.5 | BK | 1050 | Ground | |
E29LF Fog Lamp - Left Front (T3U)
E29RF Fog Lamp - Right Front (T3U)
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 12124819 Service Connector: 13584255 Description: 2-Way F Metri-Pack 280 Series, Sealed (BK) | Terminal Part Information Terminated Lead: 13575418 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 12077411/2 Core/Insulation Crimp: 2/5 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 0.5 | BN/VT | 2234 | Front Fog Lamp Supply Voltage | |
| B | 0.5 | BK | 1150 | Ground | |
E29RF Fog Lamp - Right Front (T3U)
E31L Sunshade Mirror Lamp - Left
| Connector Part Information Harness Type: Headliner OEM Connector: 12047663 Service Connector: 13584278 Description: 2-Way M Metri-Pack 150 Series (BK) | Terminal Part Information Terminated Lead: 13575462 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 0.35 | WH/BN | 6815 | Inadvertent Power Control | |
| B | 0.35 | BK | 2550 | Ground | |
E31L Sunshade Mirror Lamp - Left
E31R Sunshade Mirror Lamp - Right
| Connector Part Information Harness Type: Headliner OEM Connector: 12047663 Service Connector: 13584278 Description: 2-Way M Metri-Pack 150 Series (BK) | Terminal Part Information Terminated Lead: 13575462 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 0.35 | WH/BN | 6815 | Inadvertent Power Control | |
| B | 0.35 | BK | 2550 | Ground | |
E31R Sunshade Mirror Lamp - Right
E37B Dome/Reading Lamps - 2nd Row
| Connector Part Information Harness Type: Headliner OEM Connector: 13641551 Service Connector: 13576538 Description: 6-Way F 1.5 Series (BK) | Terminal Part Information Terminated Lead: 13575790 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | WH/BN | 6815 | Inadvertent Power Control | |
| 2 | 0.35 | GY | 157 | Interior Lamp Control | |
| 3 | 0.35 | YE | 6817 | LED Backlight Dimming Control | |
| 4-5 | | | | Not Used | |
| 6 | 0.35 | BK | 2550 | Ground | |
E37B Dome/Reading Lamps - 2nd Row
E37F Dome/Reading Lamps - Front
| Connector Part Information Harness Type: Headliner OEM Connector: 13641551 Service Connector: 13576538 Description: 6-Way F 1.5 Series (BK) | Terminal Part Information Terminated Lead: 13575790 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 8240-0127/22 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | WH/BN | 6815 | Inadvertent Power Control | |
| 2 | 0.35 | GY | 157 | Interior Lamp Control | |
| 3 | 0.35 | YE | 6817 | LED Backlight Dimming Control | |
| 4 | 0.35 | GY/L-GN | 328 | Interior Lamp Defeat Switch Signal | |
| 5 | 0.35 | GY | 156 | Courtesy Lamp Switch Signal | |
| 6 | 0.35 | BK | 2550 | Ground | |
E37F Dome/Reading Lamps - Front
F101 Passenger Instrument Panel Air Bag X1
| Connector Part Information Harness Type: SIR Jumper OEM Connector: 19153417 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | YE | 3025 | Passenger IP Module Stage 1 High Control | |
| 2 | 0.35 | OG | 3024 | Passenger IP Module Stage 1 Low Control | |
F101 Passenger Instrument Panel Air Bag X1
F101 Passenger Instrument Panel Air Bag X2
| Connector Part Information Harness Type: SIR Jumper OEM Connector: 19153418 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 3027 | Passenger IP Module Stage 2 High Control | |
| 2 | 0.35 | PU | 3026 | Passenger IP Module Stage 2 Low Control | |
F101 Passenger Instrument Panel Air Bag X2
F101 Passenger Instrument Panel Air Bag X3
| Harness Type: SIR Jumper OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 1-Way F Spade Terminal Terminal Part Information Terminated Lead: Not Available Diagnostic Test Probe: Not Available Release Tool: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: N/A | |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | BN | 1550 | Ground | |
F101 Passenger Instrument Panel Air Bag X3
Scheme 249
Scheme 249: F102 Hybrid/EV Battery Pack Cable Cover (HP6)
| Connector Part Information Harness Type: Bas Plus OEM Connector: 13707327 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F M/P 150 HVIL (BK) | Terminal Part Information Terminated Lead: 13575725 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 12129484/19 Core/Insulation Crimp: E/C |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 0.35 | PU | 5087 | High Voltage Interlock Loop Signal (1) | |
| B | 0.35 | TN | 5088 | High Voltage Interlock Loop Low Reference (1) | |
F102 Hybrid/EV Battery Pack Cable Cover (HP6)
F105L Roof Rail Air Bag - Left
| Connector Part Information Harness Type: Body OEM Connector: 13680738 Service Connector: 13585619 Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Connector Assembly - Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | OG/L-GN | 5019 | Left Front Head Curtain Module High Control | |
| 2 | 0.35 | VT/OG | 5020 | Left Front Head Curtain Module Low Control | |
F105L Roof Rail Air Bag - Left
F105R Roof Rail Air Bag - Right
| Connector Part Information Harness Type: Body OEM Connector: 13680736 Service Connector: 13585620 Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 13585620 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | OG/GY | 5021 | Right Front Head Curtain Module High Control | |
| 2 | 0.35 | WH/OG | 5022 | Right Front Head Curtain Module Low Control | |
F105R Roof Rail Air Bag - Right
F106LF Seat Air Bag - Left Front
| Connector Part Information Harness Type: Driver Seat OEM Connector: PPI0001142 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE/OG) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | BN | 2137 | Left Front Side Impact Module High Control | |
| 2 | 0.35 | YE/BK | 2138 | Left Front Side Impact Module Low Control | |
F106LF Seat Air Bag - Left Front
F106LR Seat Air Bag - Left Rear (AW7)
| Connector Part Information Harness Type: Left Rear SIR Jumper OEM Connector: 13680736 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | BN/WH | 5223 | Left Rear Side Impact SIR Inflator Supply Voltage | |
| 2 | 0.5 | OG/BK | 5224 | Left Rear Side Impact SIR Inflator Control | |
F106LR Seat Air Bag - Left Rear (AW7)
F106RF Seat Air Bag - Right Front
| Connector Part Information Harness Type: Passenger Seat OEM Connector: PPI0001142 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE/OG) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | YE/BK | 2135 | Right Front Side Impact Module High Control | |
| 2 | 0.35 | BN | 2136 | Right Front Side Impact Module Low Control | |
F106RF Seat Air Bag - Right Front
F106RR Seat Air Bag - Right Rear (AW7)
| Connector Part Information Harness Type: Right Rear SIR Jumper OEM Connector: 13680736 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | OG/D-GN | 5225 | Right Rear Side Impact SIR Inflator Supply Voltage | |
| 2 | 0.5 | TN/WH | 5226 | Right Rear Side Impact SIR Inflator Control | |
F106RR Seat Air Bag - Right Rear (AW7)
F107 Steering Wheel Air Bag X1
| Connector Part Information Harness Type: Steering Wheel OEM Connector: 19153416 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | TN | 3021 | Steering Wheel Module Stage 1 High Control | |
| 2 | 0.35 | BN | 3020 | Steering Wheel Module Stage 1 Low Control | |
F107 Steering Wheel Air Bag X1
F107 Steering Wheel Air Bag X2
| Connector Part Information Harness Type: Steering Wheel OEM Connector: 19153416 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | WH | 3023 | Steering Wheel Module Stage 2 High Control | |
| 2 | 0.35 | PK | 3022 | Steering Wheel Module Stage 2 Low Control | |
F107 Steering Wheel Air Bag X2
F112D Seat Belt Retractor Pretensioner - Driver
| Connector Part Information Harness Type: Body OEM Connector: 13680737 Service Connector: 19180245 Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 19180245 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | BN/OG | 2118 | Driver Seat Belt Pretensioner High Control | |
| 2 | 0.35 | OG/YE | 2119 | Driver Seat Belt Pretensioner Low Control | |
F112D Seat Belt Retractor Pretensioner - Driver
F112P Seat Belt Retractor Pretensioner - Passenger
| Connector Part Information Harness Type: Body OEM Connector: 13843234 Service Connector: 13585621 Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 13585621 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | OG/GY | 2116 | Passenger Seat Belt Pretensioner High Control | |
| 2 | 0.35 | D-BU/OG | 2117 | Passenger Seat Belt Pretensioner Low Control | |
F112P Seat Belt Retractor Pretensioner - Passenger
F113D Seat Belt Anchor Pretensioner - Driver
| Connector Part Information Harness Type: Driver Seat OEM Connector: PPI0001721 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | OG/GN | 7203 | Left Front Seat Belt Pretensioner Stage 2 High Control | |
| 2 | 0.35 | TN/WH | 7206 | Left Front Seat Belt Pretensioner Stage 2 Low Control | |
F113D Seat Belt Anchor Pretensioner - Driver
F113P Seat Belt Anchor Pretensioner - Passenger
| Connector Part Information Harness Type: Passenger Seat OEM Connector: PPI0001721 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (YE) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | OG/GN | 7204 | Right Front Seat Belt Pretensioner Stage 2 High Control | |
| 2 | 0.35 | TN/WH | 7205 | Right Front Seat Belt Pretensioner Stage 2 Low Control | |
F113P Seat Belt Anchor Pretensioner - Passenger
Scheme 250
Scheme 250: G5 Transmission Fluid Pump - Auxilliary (HP6)
| Connector Part Information Harness Type: Engine OEM Connector: 10757672 Service Connector: 13585624 Description: 2-Way F 2.8 Series, Sealed (BK) | Terminal Part Information Terminated Lead: 13579988 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 54001400/NA Core/Insulation Crimp: 2/D |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 1.5 | L-GN/WH | 2968 | Transmission Auxiliary Oil Pump Control | |
| 2 | 1.5 | BK | 2650 | Ground | |
G5 Transmission Fluid Pump - Auxilliary (HP6)
G10L Cooling Fan Motor - Left
| Connector Part Information Harness Type: Cooling Fan OEM Connector: 15454358 Service Connector: 88987983 Description: 2-Way F 630 GT (BK) | Terminal Part Information Terminated Lead: 13327187 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 15476168/5 Core/Insulation Crimp: F/3 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 2.5 | BK | 1250 | Ground | |
| B | 2.5 | GY | 532 | Cooling Fan Motor Supply Voltage (2) | |
G10L Cooling Fan Motor - Left
G10R Cooling Fan Motor - Right
| Connector Part Information Harness Type: Cooling Fan OEM Connector: 15454358 Service Connector: 88987983 Description: 2-Way F 630 GT (BK) | Terminal Part Information Terminated Lead: 13327187 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 15476168/5 Core/Insulation Crimp: F/3 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 2.5 | YE | 5358 | Cooling Fan Motor Supply Voltage (3) | |
| B | 2.5 | WH/D-BU | 409 | Cooling Fan Motor Supply Voltage (1) | |
G10R Cooling Fan Motor - Right
G13 Generator X1 (LFX)
| Connector Part Information Harness Type: Engine OEM Connector: 12186308 Service Connector: 13585849 Description: 2-Way F Junior Power Timer Series, Sealed (BK) | Terminal Part Information Terminated Lead: 13327154 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | BN | 25 | Charge Indicator Control | |
| 2 | 0.5 | GY | 23 | Generator Field Duty Cycle Signal | |
G13 Generator X2
| Terminal Part Information Harness Type: Battery Cable Terminal: 12146361 Core/Insulation Crimp: N/A Description: Ring Terminal | |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| B+ | 32.0 | RD | 2 | Battery Positive Voltage | |
Scheme 251
Scheme 251: G14 Hybrid/EV Battery Pack Cooling Fan (HP6)
| Connector Part Information Harness Type: Body OEM Connector: 15469987 Service Connector: 13577529 Description: 5-Way F (BK) | Terminal Part Information Pins: 1, 5 Terminated Lead: Service by Connector Assembly - 13577529 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 2-4 Terminated Lead: 13582329 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 964280-2/15 Core/Insulation Crimp: E/2 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.75 | BK | 2350 | Ground | |
| 2 | 0.35 | D-BU/VT | 5599 | Fan Speed Signal (2) | |
| 3 | 0.35 | YE/L-GN | 5598 | Fan Speed Signal (1) | |
| 4 | 0.35 | BN/WH | 6277 | Fan Speed Sensor Supply Voltage | |
| 5 | 0.75 | RD/YE | 1442 | Battery Positive Voltage | |
G14 Hybrid/EV Battery Pack Cooling Fan (HP6)
G17 Heater Coolant Pump (HP6)
| Connector Part Information Harness Type: Engine OEM Connector: 13663390 Service Connector: 13574937 Description: 3-Way F 1.2 MLK Series, Sealed (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 13574937 Release Tool: J-38125-21 Diagnostic Test Probe: J-35616-16 (L-GN) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | BK | 2650 | Ground | |
| 2 | 0.5 | YE/D-BU | 5126 | After Boil Heater Pump Supply Voltage | |
| 3 | | | | Not Used | |
G17 Heater Coolant Pump (HP6)
G18 High Pressure Fuel Pump
| Connector Part Information Harness Type: Engine OEM Connector: 15339756 Service Connector: 88988963 Description: 2-Way F Kompakt 2.8 Series Sealed (BK) | Terminal Part Information Terminated Lead: 13576381 Release Tool: J-38125-561 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | VT/BK | 7300 | High Pressure Fuel Pump Actuator Low Control | |
| 2 | 0.5 | YE | 7301 | High Pressure Fuel Pump Actuator High Control | |
G18 High Pressure Fuel Pump
G21 Secondary Air Injection Pump (LUK)
| Connector Part Information Harness Type: Engine OEM Connector: 15326677 Service Connector: 88953351 Description: 2-Way F GT 280 Series, Sealed (BK) | Terminal Part Information Terminated Lead: 13575402 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15392777/23 Core/Insulation Crimp: B/5 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| A | 4.0 | BN/YE | 78 | Air Injection Reaction Pump Supply Voltage | |
| B | 4.0 | BK | 2650 | Ground | |
G21 Secondary Air Injection Pump (LUK)
G24 Windshield Washer Pump
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 10863916 Service Connector: 13576532 Description: 2-Way F 2.8 Series, Sealed (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 13576532 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 1-968857-3/7 Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | GY/VT | 228 | Windshield Washer Pump Control | |
| 2 | 0.5 | BK | 1150 | Ground | |
G24 Windshield Washer Pump
G43 Starter/Generator Coolant Pump (HP6)
| Connector Part Information Harness Type: Engine OEM Connector: 13663390 Service Connector: 13574937 Description: 3-Way F 1.2 MLK Series, Sealed (BK) | Terminal Part Information Terminated Lead: Service by Connector Assembly - 13574937 Release Tool: J-38125-21 Diagnostic Test Probe: J-35616-16 (L-GN) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | BK | 2650 | Ground | |
| 2 | 0.5 | VT/WH | 2022 | Coolant Pump Control | |
| 3 | | | | Not Used | |
G43 Starter/Generator Coolant Pump (HP6)
K8 Blower Motor Control Module X1
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13520671 Service Connector: 88988512 Description: 6-Way F GT 150 6.3 Series (BK) | Terminal Part Information Pin: 3 Terminated Lead: Service by Connector Assembly - 88988512 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 5-6 Terminated Lead: Service by Connector Assembly - 88988512 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 7116-4121-02/10 Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1-2 | | | | Not Used | |
| 3 | 0.13 | D-BU | 754 | Blower Motor Speed Control | |
| 4 | | | | Not Used | |
| 5 | 2.5 | BK | 1850 | Ground | |
| 6 | 2.5 | RD/YE | 542 | Battery Positive Voltage | |
K8 Blower Motor Control Module X1
K8 Blower Motor Control Module X2
| Connector Part Information Harness Type: HVAC OEM Connector: 15226103 Service Connector: 88988507 Description: 2-Way F Receptacle 6.3 Series (L-GY) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 4.0 | RD | 65 | Blower Motor Supply Voltage | |
| 2 | 4.0 | BK | 5987 | Front Blower Motor Low Reference | |
K8 Blower Motor Control Module X2
K9 Body Control Module X1
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13631051 Service Connector: 13576639 Description: 26-Way F 64 Series (NA) | Terminal Part Information Pins: 1-4 Terminated Lead: 13327199 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: SNAC-A061T-M2.8/20 Core/Insulation Crimp: E/A Pins: 5, 8-9, 11, 16-17, 19-22 Terminated Lead: Service by Connector Assembly - 13576639 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 14, 26 Terminated Lead: 13575870 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.75 | BK | 1650 | Ground | |
| 2 | 0.5 | RD/BK | 2540 | Battery Positive Voltage | |
| 3 | 0.5 | RD/BK | 2140 | Battery Positive Voltage | |
| 4 | 0.5 | RD/BN | 2240 | Battery Positive Voltage | |
| 5 | 0.13 | WH | 6816 | Indicator Dimming Control | |
| 6-7 | | | | Not Used | |
| 8 | 0.13 | BN | 5720 | Ignition Mode Switch Accessory LED Signal | BTM |
| 9 | 0.13 | WH | 7555 | Lighting Control Switch Signal | |
| 10 | | | | Not Used | |
| 11 | 0.13 | L-GN | 306 | Headlamp Switch Headlamps Off Signal Control | |
| 12-13 | | | | Not Used | |
| 14 | 0.35 | GY/L-GN | 328 | Interior Lamp Defeat Switch Signal | |
| 15 | | | | Not Used | |
| 16 | 0.13 | WH | 103 | Headlamp Switch On Signal | |
| 17 | 0.13 | GY | 7543 | Hazard LED Dimming Signal | |
| 18 | | | | Not Used | |
| 19 | 0.13 | BK | 5360 | Brake Apply Sensor Low Reference | |
| 20 | 0.13 | D-BU | 5719 | Ignition Mode Switch Start LED Signal | BTM |
| 21 | 0.13 | GY | 728 | Security Indicator Control | |
| 22 | 0.13 | L-GN | 13 | Headlamp Switch Park Lamp Signal | |
| 23-25 | | | | Not Used | |
| 26 | 0.35 | YE/L-GN | 3274 | Remote Function Actuator Transmit Signal | |
K9 Body Control Module X1
K9 Body Control Module X2
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13631046 Service Connector: 13576637 Description: 27-Way F 64 Series (BU) | Terminal Part Information Pins: 1-3 Terminated Lead: 13327199 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: SNAC-A061T-M2.8/20 Core/Insulation Crimp: E/A Pin: 4 Terminated Lead: 13327199 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: SNAC-A061T-M2.8/20 Core/Insulation Crimp: C/A Pins: 7, 10-11, 13-15, 17, 19 Terminated Lead: Service by Connector Assembly - 13631046 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 8, 16, 21-27 Terminated Lead: 13575870 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | RD/WH | 2740 | Battery Positive Voltage | |
| 2 | 0.75 | BK | 1650 | Ground | |
| 3 | 0.5 | RD | 2940 | Battery Positive Voltage | |
| 4 | 1.5 | RD/VT | 4040 | Battery Positive Voltage | |
| 5-6 | | | | Not Used | |
| 7 | 0.13 | D-BU/YE | 5361 | Brake Apply Sensor Signal | |
| 8 | 0.35 | YE | 6817 | LED Backlight Dimming Control | |
| 9 | | | | Not Used | |
| 10 | 0.13 | WH | 278 | Ambient Light Sensor Signal | |
| 11 | 0.13 | PU | 5526 | Tap Up/Tap Down Switch Signal | |
| 12 | | | | Not Used | |
| 13 | 0.13 | WH | 5359 | Brake Apply Sensor Supply Voltage | |
| 14 | 0.13 | D-BU | 1788 | Traction Control Switch Signal 1 | |
| 15 | 0.13 | BN | 781 | Driver Door Lock Switch Unlock Signal | |
| 16 | 0.13 | GY | 3273 | Remote Function Actuator Return | |
| 17 | 0.13 | D-BU | 5723 | Ignition Mode Switch Mode Voltage | BTM |
| 18 | | | | Not Used | |
| 19 | 0.13 | BN | 780 | Driver Door Lock Switch Lock Signal | |
| 20 | | | | Not Used | |
| 21 | 0.35 | L-GN/GY | 6135 | Linear Interconnect Network Bus 4 | |
| 22 | 0.35 | GN | 5060 | Low Speed GMLAN Serial Data | |
| 23 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 24 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 25 | 0.35 | GY/WH | 3272 | Remote Function Actuator Supply Voltage | |
| 26 | 0.35 | L-GN/WH | 111 | Hazard Switch Signal | |
| 27 | 0.35 | D-BU/WH | 3275 | Remote Function Actuator Receive Signal | |
K9 Body Control Module X2
K9 Body Control Module X3
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 13631047 Service Connector: 13576643 Description: 25-Way F 64 Series (L-GN) | Terminal Part Information Pins: 1, 3, 5-6 (without BTM), 8-13, 15, 17-18, 20, 22, 24-25 Terminated Lead: Service by Connector Assembly - 13576643 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 2, 5-6 (BTM), 7 Terminated Lead: 13575870 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.13 | L-GN | 3277 | Vehicle Anti-Theft System Immobilizer Return | |
| 2 | 0.35 | GN/PU | 7533 | Linear Interconnect Network Bus 11 | |
| 3 | 0.13 | GY | 3276 | Vehicle Anti-Theft System Immobilizer Supply Voltage | |
| 4 | 0.35 | YE | 7556 | Lighting Control Switch Reference | |
| 5 | 0.35 | VT/YE | 4 | Accessory Voltage | BTM |
| 0.13 PU | PU | 4 | Accessory Voltage | Without BTM |
| 6 | 0.35 | VT/BK | 3 | Run/Crank Ignition 1 Voltage | BTM |
| 0.13 | PU | 3 | Run/Crank Ignition 1 Voltage | Without BTM |
| 7 | 0.35 | VT/YE | 143 | Accessory Voltage | Without BTM |
| 8 | 0.13 | L-GN | 6818 | Steering Wheel Resistor Ladder Signal #1 | |
| 9 | 0.13 | BN | 1884 | Cruise Control Set/Coast/Resume/Accelerate Switch Signal | |
| 10 | 0.13 | BK | 6009 | Windshield Wiper Switch Low Reference | |
| 11 | 0.13 | WH | 524 | Headlamp Dimmer Switch High Beam Signal | |
| 12 | 0.13 | WH | 663 | Hazard Switch Left Turn Signal | |
| 13 | 0.13 | YE | 1714 | Windshield Wiper Switch Low Signal | |
| 14 | | | | Not Used | |
| 15 | 0.13 | WH | 1020 | Off/Run/Crank Voltage | Without BTM |
| 16 | | | | Not Used | |
| 17 | 0.13 | YE | 307 | Headlamp Switch Flash To Pass Signal | |
| 18 | 0.13 | L-GN | 3287 | Horn Switch Signal | |
| 19 | | | | Not Used | |
| 20 | 0.13 | GY | 1715 | Windshield Wiper Switch High Signal | |
| 21 | | | | Not Used | |
| 22 | 0.13 | WH | 1073 | Ignition Key Resistor Signal | Without BTM |
| 23 | | | | Not Used | |
| 24 | 0.13 | PU | 664 | Hazard Switch Right Turn Signal | |
| 25 | 0.13 | WH | 94 | Windshield Washer Switch Signal | |
K9 Body Control Module X3
K9 Body Control Module X4
| Connector Part Information Harness Type: Body OEM Connector: 13631048 Service Connector: 13576640 Description: 26-Way F 64 Series (BK) | Terminal Part Information Pins: 1-4 Terminated Lead: 13327199 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: SNAC-A061T-M2.8/20 Core/Insulation Crimp: E/A Pins: 5-7, 13-18, 20-24, 26 Terminated Lead: 13575870 Release Tool: J38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J Pins: 11-12 Terminated Lead: 13579954 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.75 | D-BU/BN | 7539 | Right Front DRL Supply Voltage | T4F |
| 0.75 | YE | 312 | Right Headlamp Low Beam Supply Voltage | T4A |
| 2 | 0.75 | GY/D-BU | 7538 | Left Front DRL Supply Voltage | T4F |
| 0.75 | YE | 712 | Left Headlamp Low Beam Supply Voltage | T4A |
| 3 | 0.5 | L-GN/VT | 1315 | Right Front Turn Signal Lamp Supply Voltage | |
| 4 | 0.5 | D-BU/VT | 1335 | Right Rear Turn Signal Lamp Supply Voltage | |
| 5 | 0.5 | GY/BN | 309 | Right Park Lamp Supply Voltage | |
| 6 | 0.5 | VT/GY | 709 | Left Park Lamp Supply Voltage | |
| 7 | 0.5 | GY/YE | 7542 | Left Rear Stop Lamp Supply Voltage | |
| 8-10 | | | | Not Used | |
| 11 | 0.13 | PU | 5065 | CHMSL Supply Voltage | |
| 12 | 0.13 | GY | 755 | RAP Relay Coil Control | |
| 13 | 0.35 | L-GN/RD | 6846 | Rear License Lamp Supply Voltage | |
| 14 | 0.35 | BN/GY | 2268 | Windshield Washer Relay Control | |
| 15 | 0.35 | L-GN/VT | 5199 | Run/Crank Relay Coil Control | |
| 16 | 0.35 | GY | 91 | Windshield Wiper Motor Relay Coil Supply Voltage | |
| 17 | 0.35 | BN/L-GN | 196 | Windshield Wiper Motor Park Switch Signal | |
| 18 | 0.35 | WH/YE | 5075 | Current Sensor Signal | |
| 19 | | | | Not Used | |
| 20 | 0.35 | RD/YE | 2340 | Battery Positive Voltage | |
| 21 | 0.35 | D-BU/VT | 5076 | Current Sensor Supply Voltage | |
| 22 | 0.35 | VT/YE | 5985 | Accessory Wakeup Serial Data | |
| 23 | 0.35 | WH/D-BU | 5986 | Serial Data Communication Enable | |
| 24 | 0.35 | BN/L-GN | 109 | Hood Ajar Switch Signal | |
| 25 | | | | Not Used | |
| 26 | 0.5 | BK | 150 | Ground | |
K9 Body Control Module X4
K9 Body Control Module X5
| Connector Part Information Harness Type: Body OEM Connector: 13631049 Service Connector: 13576641 Description: 26-Way F 64 Series (BN) | Terminal Part Information Pins: 1-4 Terminated Lead: 13327199 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: SNAC-A061T-M2.8/20 Core/Insulation Crimp: E/A Pins: 6-7, 10, 12-13, 14 (UVD), 16, 18-19, 24 Terminated Lead: 13575870 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J Pins: 11, 14 (U80 except UVD) Terminated Lead: 13582342 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A031T-0.64/Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | D-BU/WH | 1334 | Left Rear Turn Signal Lamp Supply Voltage | |
| 2 | 0.5 | D-BU/WH | 1314 | Left Front Turn Signal Lamp Supply Voltage | |
| 3 | 0.75 | RD/L-GN | 3840 | Battery Positive Voltage | |
| 4 | 0.5 | RD/WH | 3440 | Battery Positive Voltage | |
| 5 | | | | Not Used | |
| 6 | 0.35 | BK/VT | 5077 | Current Sensor Low Reference | |
| 7 | 0.5 | WH/YE | 7541 | Right Rear Stop Lamp Supply Voltage | |
| 8-9 | | | | Not Used | |
| 10 | 0.35 | BN/WH | 1317 | Fog Lamp Relay Control | T3U |
| 11 | 0.13 | GY | 6188 | Lift Glass/Trunk Motor Release Control | |
| 12 | 0.35 | WH/D-BU | 6311 | Cruise/ETC/TCC Brake Signal | |
| 13 | 0.35 | BN/YE | 1970 | Headlamp Low Beam Relay Control | T4F |
| 14 | 0.13 | BN | 5486 | Run Relay Coil Control | U80 except UVD |
| 0.35 | BN/VT | 5486 | Run Relay Coil Control | UVD |
| 15 | | | | Not Used | |
| 16 | 0.35 | VT/YE | 3267 | Child Security Lock Relay Control | |
| 17 | | | | Not Used | |
| 18 | 0.35 | BN/VT | 1969 | Headlamp High Beam Relay Control | |
| 19 | 0.35 | BN/WH | 28 | Horn Relay Control | |
| 20-23 | | | | Not Used | |
| 24 | 0.35 | WH/VT | 860 | Front Windshield Wiper Switch High Signal | |
| 25-26 | | | | Not Used | |
K9 Body Control Module X5
K9 Body Control Module X6
| Connector Part Information Harness Type: Body OEM Connector: 13631052 Service Connector: 13576638 Description: 27-Way F 64 Series (PK) | Terminal Part Information Pin: 1-4 Terminated Lead: 13327199 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: SNAC-A061T-M2.8/20 Core/Insulation Crimp: Pin: 1 - E/A Core/Insulation Crimp: Pins: 2-4 - C/A Pins: 5, 7, 9-10, 16, 24-25 Terminated Lead: 13575870 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J Pin: 15 Terminated Lead: Service by Connector Assembly - 13576638 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.75 | GY | 5911 | Door Lock Actuator Lock Control 2 | |
| 2 | 1.5 | GY/L-GN | 3271 | Door Lock Control (2) | |
| 3 | 1.5 | BK | 2150 | Ground | |
| 4 | 1.5 | BN/YE | 294 | Door Lock Actuator Unlock Control | |
| 5 | 0.35 | VT/GY | 1303 | Lift Gate Ajar Switch Signal (1) | |
| 6 | | | | Not Used | |
| 7 | 0.35 | WH/YE | 7557 | LED Ambient Lighting Control 1 | |
| 8 | | | | Not Used | |
| 9 | 0.35 | L-GN/D-BU | 6133 | Linear Interconnect Network Bus 2 | |
| 10 | 0.35 | L-GN/YE | 6134 | Linear Interconnect Network Bus 3 | |
| 11-14 | | | | Not Used | |
| 15 | 0.13 | YE | 5797 | Rear Closure Handle Switch Open Signal | |
| 16 | 0.35 | L-GN/BN | 6132 | Linear Interconnect Network Bus 1 | C3U |
| 17-23 | | | | Not Used | |
| 24 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 25 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 26-27 | | | | Not Used | |
K9 Body Control Module X6
K9 Body Control Module X7
| Connector Part Information Harness Type: Body OEM Connector: 13576642 Service Connector: 13576642 Description: 26-Way F 64 Series (GY) | Terminal Part Information Pins: 1-3 Terminated Lead: 13327199 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: SNAC-A061T-M2.8/20 Core/Insulation Crimp: E/A Pins: 7-9 Terminated Lead: 13575870 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SNAC3-A021T-M0.64/20 Core/Insulation Crimp: J/J Pins: 5-6, 12-13, 17-19 Terminated Lead: Service by Connector Assembly - 13576642 Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | GY | 157 | Interior Lamp Control | |
| 2 | 0.5 | WH/BN | 6815 | Inadvertent Power Control | |
| 3 | 0.5 | L-GN/WH | 24 | Backup Lamp Supply Voltage | |
| 4 | | | | Not Used | |
| 5 | 0.13 | WH | 694 | Driver Door Lock Actuator Unlock Control | ATH |
| 6 | 0.13 | PU | 7553 | Park Lock Solenoid Control | |
| 7 | 0.5 | L-GN/GY | 737 | Trunk Lamp Control | |
| 8 | 0.35 | GY/L-GN | 5996 | Driver Outside Rear View Mirror Puddle Lamp Supply Voltage | DLG or DLL |
| 9 | 0.35 | YE | 6817 | LED Backlight Dimming Control | |
| 10-11 | | | | Not Used | |
| 12 | 0.13 | BN | 3269 | Child Security Lock Motor Status Signal Left Rear | |
| 13 | 0.13 | WH | 5905 | Key Capture/Column Lock Shift Position Signal | BTM |
| 14-16 | | | | Not Used | |
| 17 | 0.13 | D-BU | 195 | Door Lock Control | ATH |
| 18 | 0.13 | GY | 3268 | Child Security Lock Motor Status Signal Right Rear | |
| 19 | 0.13 | GY | 156 | Courtesy Lamp Switch Signal | |
| 20-26 | | | | Not Used | |
K16 Battery Energy Control Module X1 (HP6)
| Connector Part Information Harness Type: Bas Plus OEM Connector: 13667565 Service Connector: Service by Harness - See Part Catalog Description: 22-Way F Kaizen 0.64 Series (BK) | Terminal Part Information Terminated Lead: 13575864 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SAIT-A03GF-M064/27 Core/Insulation Crimp: P/P |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | PK | 5076 | Current Sensor Supply Voltage | |
| 2 | 0.35 | WH | 5075 | Current Sensor Signal | |
| 3-4 | | | | Not Used | |
| 5 | 0.35 | GY | 6435 | CAN Bus Low #2 Serial Data | |
| 6 | 0.35 | PK/BK | 6434 | CAN Bus High #2 Serial Data | |
| 7 | 0.35 | TN/WH | 6433 | CAN Bus High Serial Data | |
| 8 | 0.35 | L-GN/BK | 6432 | CAN Bus Low Serial Data | |
| 9 | 0.35 | PK | 3 | Run/Crank Ignition 1 Voltage | |
| 10 | 0.35 | RD/BK | 202 | Battery Positive Voltage | |
| 11 | 0.35 | RD | 1 | Unfused Battery Positive Voltage | |
| 12 | 0.35 | BN | 5077 | Current Sensor Low Reference | |
| 13-19 | | | | Not Used | |
| 20 | 0.35 | D-BU | 5985 | Accessory Wakeup Serial Data | |
| 21-22 | | | | Not Used | |
K16 Battery Energy Control Module X1 (HP6)
K16 Battery Energy Control Module X2 (HP6)
| Connector Part Information Harness Type: BAS Plus OEM Connector: AIT2PB-10A-2AK Service Connector: 13577390 Description: 10-Way F Kaizen 0.64 Series (BK) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | WH | 5409 | Battery Module Temperature Signal (5) | |
| 2 | 0.35 | GN | 5408 | Battery Module Temperature Signal (4) | |
| 3 | 0.35 | GY | 5406 | Battery Module Temperature Signal (2) | |
| 4 | 0.35 | RD | 5405 | Battery Module Temperature Signal (1) | |
| 5 | | | | Not Used | |
| 6 | 0.35 | WH/OG | 5597 | Inlet Air Temperature Sensor Low Reference | |
| 7 | 0.35 | BN/GN | 5597 | Inlet Air Temperature Sensor Low Reference | |
| 8 | 0.35 | GY/OG | 5597 | Inlet Air Temperature Sensor Low Reference | |
| 9 | 0.35 | BK/RD | 5597 | Inlet Air Temperature Sensor Low Reference | |
| 10 | | | | Not Used | |
K16 Battery Energy Control Module X2 (HP6)
Scheme 252
Scheme 252: K16 Battery Energy Control Module X3 (HP6)
| Connector Part Information Harness Type: BAS Plus OEM Connector: AIT2PB-10A-2BK Service Connector: Service by Harness - See Part Catalog Description: 10-Way F Kaizen 0.64 Series (GY) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | GY | 5411 | Battery Module Temperature Signal (7) | |
| 2 | 0.35 | RD | 5407 | Battery Module Temperature Signal (3) | |
| 3 | | | | Not Used | |
| 4 | 0.35 | GN | 5410 | Battery Module Temperature Signal (6) | |
| 5 | | | | Not Used | |
| 6 | 0.35 | OG/GY | 5597 | Inlet Air Temperature Sensor Low Reference | |
| 7 | 0.35 | BN/GN | 5597 | Inlet Air Temperature Sensor Low Reference | |
| 8 | | | | Not Used | |
| 9 | 0.35 | BN/GN | 5597 | Inlet Air Temperature Sensor Low Reference | |
| 10 | | | | Not Used | |
K16 Battery Energy Control Module X3 (HP6)
Scheme 253
Scheme 253: K16 Battery Energy Control Module X4 (HP6)
| Connector Part Information Harness Type: BAS Plus OEM Connector: AIT2GPB-18-2AD Service Connector: Service by Harness - See Part Catalog Description: 18-Way F (OG) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | BU | | Cell Voltage 32 (-) | |
| 2 | 0.5 | BU | | Cell Voltage 31 (+) | |
| 3 | 0.5 | BU | | Cell Voltage 29 (+) | |
| 4 | 0.5 | BU | | Cell Voltage 27 (+) | |
| 5 | 0.5 | BU | | Cell Voltage 25 (+) | |
| 6 | 0.5 | BU | | Cell Voltage 23 (+) | |
| 7 | 0.5 | BU | | Cell Voltage 21 (+) | |
| 8 | 0.5 | BU | | Cell Voltage 19 (+) | |
| 9 | 0.5 | BU | | Cell Voltage 17 (+) | |
| 10 | 0.5 | BU | | Voltage routed from cell 32 (-) | |
| 11 | 0.5 | BU | | Cell Voltage 32 (+) | |
| 12 | 0.5 | BU | | Cell Voltage 30 (+) | |
| 13 | 0.5 | BU | | Cell Voltage 28 (+) | |
| 14 | 0.5 | BU | | Cell Voltage 26 (+) | |
| 15 | 0.5 | BU | | Cell Voltage 24 (+) | |
| 16 | 0.5 | BU | | Cell Voltage 22 (+) | |
| 17 | 0.5 | BU | | Cell Voltage 20 (+) | |
| 18 | 0.5 | BU | | Cell Voltage 18 (+) | |
K16 Battery Energy Control Module X4 (HP6)
Scheme 254
Scheme 254: K16 Battery Energy Control Module X5 (HP6)
| Connector Part Information Harness Type: BAS Plus OEM Connector: AIT2GPB-18-2BD Service Connector: Service by Harness - See Part Catalog Description: 18-Way F (OG) | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | BU | | Cell Voltage 16 (-) | |
| 2 | 0.5 | BU | | Cell Voltage 15 (+) | |
| 3 | 0.5 | BU | | Cell Voltage 13 (+) | |
| 4 | 0.5 | BU | | Cell Voltage 11 (+) | |
| 5 | 0.5 | BU | | Cell Voltage 9 (+) | |
| 6 | 0.5 | BU | | Cell Voltage 7 (+) | |
| 7 | 0.5 | BU | | Cell Voltage 5 (+) | |
| 8 | 0.5 | BU | | Cell Voltage 3 (+) | |
| 9 | 0.5 | BU | | Cell Voltage 1 (+) | |
| 10 | 0.5 | BU | | Cell Voltage 16 (+) | |
| 11 | 0.5 | BU | | Cell Voltage 14 (+) | |
| 12 | 0.5 | BU | | Cell Voltage 12 (+) | |
| 13 | 0.5 | BU | | Cell Voltage 10 (+) | |
| 14 | 0.5 | BU | | Cell Voltage 8 (+) | |
| 15 | 0.5 | BU | | Cell Voltage 6 (+) | |
| 16 | 0.5 | BU | | Cell Voltage 4 (+) | |
| 17 | 0.5 | BU | | Cell Voltage 2 (+) | |
| 18 | 0.5 | BU | | Voltage routed from cell 1 (+) | |
K16 Battery Energy Control Module X5 (HP6)
K17 Electronic Brake Control Module
| Connector Part Information Harness Type: Body OEM Connector: 13626344 Service Connector: 13576554 Description: 38-Way F Mixed Series (BK) | Terminal Part Information Pins: 1, 13 Terminated Lead: 13575437 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 1241818-1/4 Core/Insulation Crimp: B/G Pins: 3-4, 7, 10-11, 14, 27-28, 33, 35-36 Terminated Lead: 13578883 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Pins: 5-6, 15-18, 20-22, 26, 29 Terminated Lead: 13582340 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Pins: 25, 38 Terminated Lead: Service by Harness - See Part Catalog Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-964273-1/15 Core/Insulation Crimp: E/1 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 4.0 | RD/YE | 442 | Battery Positive Voltage | |
| 2 | | | | Not Used | |
| 3 | 0.35 | YE | 872 | Wheel Speed Sensor Signal Right Front | |
| 4 | 0.35 | BK/YE | 833 | Wheel Speed Sensor Low Reference Right Front | |
| 5 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 6 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 7 | 0.35 | GY | 1903 | AAS Wheel Speed Sensor Signal Left Front | UYS |
| 8-9 | | | | Not Used | |
| 10 | 0.35 | BK/VT | 883 | Wheel Speed Sensor Low Reference Right Rear | |
| 11 | 0.35 | VT | 882 | Wheel Speed Sensor Signal Right Rear | |
| 12 | | | | Not Used | |
| 13 | 4.0 | BK | 1450 | Ground | |
| 14 | 0.35 | D-GN/BN | 2087 | Combined Vehicle Inertial Sensor Supply Voltage | |
| 15 | 0.5 | YE/RD | 6031 | 5-Volt Reference | |
| 16 | 0.5 | BK/YE | 6032 | Low Reference | |
| 17 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 18 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 19 | | | | Not Used | |
| 20 | 0.5 | WH | 6106 | High Speed GMLAN Serial Data (-) (2) | |
| 21 | 0.5 | BU/YE | 6105 | High Speed GMLAN Serial Data (+) (2) | |
| 22 | 0.5 | YE/VT | 6030 | Brake Vacuum Sensor Signal | |
| 23-24 | | | | Not Used | |
| 25 | 1.5 | RD/GY | 1042 | Battery Positive Voltage | |
| 26 | 0.5 | BN | 6305 | Brake Vacuum Switch Signal | |
| 27 | 0.35 | GY | 830 | Wheel Speed Sensor Signal Left Front | |
| 28 | 0.35 | BK/GY | 873 | Left Front Wheel Speed Sensor Low Reference | |
| 29 | 0.5 | L-GN/GY | 333 | Brake Fluid Level Sensor Signal | |
| 30-32 | | | | Not Used | |
| 33 | 0.35 | WH/D-BU | 5986 | Serial Data Communication Enable | |
| 34 | | | | Not Used | |
| 35 | 0.35 | BK/D-BU | 885 | Wheel Speed Sensor Low Reference Left Rear | |
| 36 | 0.35 | D-BU | 884 | Wheel Speed Sensor Signal Left Rear | |
| 37 | | | | Not Used | |
| 38 | 1.5 | BK | 1450 | Ground | |
K17 Electronic Brake Control Module
K18 Compass Module (without UE1)
| Connector Part Information Harness Type: Body OEM Connector: 13541539 Service Connector: 13585622 Description: 4-Way F AIT II Series (BK) | Terminal Part Information Pin: 1 Terminated Lead: 13579943 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 2, 3 Terminated Lead: Pins: 2: 13327119 Terminated Lead: Pins: 3: 13575867 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.13 | BN | 5486 | Run Relay Coil Control | |
| 2 | 0.75 | BK | 2350 | Ground | |
| 3 | 0.35 | L-GN/D-BU | 6133 | Linear Interconnect Network Bus 2 | |
| 4 | | | | Not Used | |
K18 Compass Module (without UE1)
K19 Suspension Control Module (F45)
| Connector Part Information Harness Type: Body OEM Connector: 13548598 Service Connector: 13576557 Description: 32-Way F 0.64 Micro Quadlok Series (BU) | Terminal Part Information Pins: 18 Terminated Lead: 13575587 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 928999-5/15 Core/Insulation Crimp: J/J Pins: 1-16, 20, 22-25, 28-31 Terminated Lead: 13575737 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 928999-5/15 Core/Insulation Crimp: Pins: 1-10, 12-16, 20 - H/H Core/Insulation Crimp: Pins: 11, 22-25, 28-31 - J/J |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | RD/GY | 1740 | Battery Positive Voltage | |
| 2 | 0.35 | L-GN/GY | 1119 | Right Rear Damping Servo Control | |
| 3 | 0.35 | BN/L-GN | 1118 | Right Rear Damping Servo Supply Voltage | |
| 4 | 0.35 | D-BU/GY | 1114 | Left Rear Damping Servo Supply Voltage | |
| 5 | 0.35 | L-GN/VT | 1115 | Left Rear Damping Servo Control | |
| 6 | 0.35 | WH/D-BU | 5986 | Serial Data Communication Enable | |
| 7 | 0.35 | WH/YE | 3256 | Rear Accelerometer Signal | |
| 8 | 0.35 | WH/VT | 3259 | Left Front Accelerometer Signal | |
| 9 | 0.35 | WH/BN | 3253 | Right Front Accelerometer Signal | |
| 10 | 0.35 | WH | 1100 | Left Front Wheel Damping Accelerometer Signal | |
| 11 | 0.5 | WH | 1106 | Right Front Wheel Damping Accelerometer Signal | |
| 12 | 0.35 | YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference | |
| 13 | 0.35 | GY/D-BU | 1113 | Left Front Damping Servo Control | |
| 14 | 0.35 | BN/WH | 1107 | Left Front Damping Servo Supply Voltage | |
| 15 | 0.35 | BN/D-BU | 1116 | Right Front Damping Servo Supply Voltage | |
| 16 | 0.35 | GY/WH | 1117 | Right Front Damping Servo Control | |
| 17 | | | | Not Used | |
| 18 | 0.75 | BK | 2350 | Ground | |
| 19 | | | | Not Used | |
| 20 | 0.35/ | BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference | |
| 21 | | | | Not Used | |
| 22 | 0.35 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 23 | 0.35 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 24 | 0.35 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 25 | 0.35 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 26-27 | | | | Not Used | |
| 28 | 0.35 | BU/YE | 6105 | High Speed GMLAN Serial Data (+) (2) | |
| 29 | 0.35 | BU/YE | 6105 | High Speed GMLAN Serial Data (+) (2) | |
| 30 | 0.35 | WH | 6106 | High Speed GMLAN Serial Data (-) (2) | |
| 31 | 0.35 | WH | 6106 | High Speed GMLAN Serial Data (-) (2) | |
| 32 | | | | Not Used | |
K19 Suspension Control Module (F45)
K20 Engine Control Module X1 (LFX)
| Connector Part Information Harness Type: Engine OEM Connector: 13611938 Service Connector: 13574782 Description: 73-Way F Sealed (BK with BU cover) | Terminal Part Information Pins: 4-6, 9-10, 14-15, 21-22, 25-27, 30, 32-34, 38-40, 42, 44, 46-48, 51-53, 57, 59, 62-63, 66-67-68, 70, 72 Terminated Lead: 13575575 Release Tool: J-38125-213 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 33467-0005/23 Core/Insulation Crimp: J/J Pin: 73 Terminated Lead: 13576392 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 7116-4152-02/9 Core/Insulation Crimp: A/5 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1-3 | | | | Not Used | |
| 4 | 0.5 | YE/WH | 3200 | Barometric Pressure Sensor Signal | |
| 5 | 0.5 | WH/RD | 3201 | 5V Reference 1 | |
| 6 | 0.5 | L-GN | 380 | A/C Refrigerant Pressure Sensor Signal | |
| 7-8 | | | | Not Used | |
| 9 | 0.5 | D-BU/WH | 890 | Fuel Tank Pressure Sensor Signal | |
| 10 | 0.5 | YE/RD | 2709 | Fuel Tank Pressure Sensor 5-Volt Reference 1 | |
| 11-13 | | | | Not Used | |
| 14 | 0.5 | WH/RD | 1164 | Accelerator Pedal Position 5-Volt Reference 4 (1) | |
| 15 | 0.5 | YE/WH | 1161 | Accelerator Pedal Position Signal (1) | |
| 16-20 | | | | Not Used | |
| 21 | 0.5 | BN/RD | 2700 | 5-Volt Reference 1 | |
| 22 | 0.5 | BK/BN | 5514 | A/C Refrigerant Pressure Sensor Low Reference | |
| 23-24 | | | | Not Available | |
| 25 | 0.5 | D-BU/L-GN | 1936 | Primary Fuel Level Sensor Signal | |
| 26 | 0.5 | BK/L-GN | 6281 | Fuel Level Sensor Low Reference | |
| 27 | 0.5 | D-BU/WH | 1937 | Secondary Fuel Level Sensor Signal | |
| 28-29 | | | | Not Used | |
| 30 | 0.5 | BK/D-BU | 1271 | Accelerator Pedal Position Low Reference (1) | |
| 31 | | | | Not Used | |
| 32 | 0.5 | WH/GY | 459 | A/C Compressor Clutch Relay Control | |
| 33 | 0.5 | BN/RD | 1274 | Accelerator Pedal Position 5-Volt Reference 3 (2) | |
| 34 | 0.5 | L-GN/WH | 1162 | Accelerator Pedal Position Signal (2) | |
| 35-37 | | | | Not Used | |
| 38 | 0.5 | WH | 1579 | Fuel Temperature/Composition Signal | |
| 39 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 40 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 41 | | | | Not Used | |
| 42 | 0.5 | BN/YE | 473 | High Speed Cooling Fan Relay Control | |
| 43 | | | | Not Used | |
| 44 | 0.5 | L-GN/GY | 465 | Fuel Pump Primary Relay Control | |
| 45 | | | | Not Used | |
| 46 | 0.5 | BN/WH | 419 | Check Engine Indicator Control | |
| 47 | 0.5 | WH/RD | 5381 | Brake Position Sensor 5 Volt Reference | |
| 48 | 0.5 | WH | 5380 | Brake Position Sensor Signal | |
| 49-50 | | | | Not Used | |
| 51 | 0.5 | VT/L-GN | 439 | Run/Crank Ignition 1 Voltage | |
| 52 | 0.5 | RD/BN | 440 | Battery Positive Voltage | |
| 53 | 0.5 | BK/VT | 1272 | Accelerator Pedal Position Low Reference (2) | |
| 54-56 | | | | Not Used | |
| 57 | 0.5 | WH/D-BU | 6311 | Cruise/ETC/TCC Brake Signal | |
| 58 | | | | Not Used | |
| 59 | 0.5 | L-GN/VT | 335 | Low Speed Cooling Fan Relay Control | |
| 60-61 | | | | Not Used | |
| 62 | 0.5 | VT/D-BU | 5291 | Powertrain Main Relay Fused Supply (2) | |
| 63 | 0.5 | VT/GY | 6386 | Starter Enable Relay (PPEI 3) Control | |
| 64-65 | | | | Not Used | |
| 66 | 0.5 | WH | 1310 | EVAP Canister Vent Solenoid Control | |
| 67 | 0.5 | VT/D-BU | 5292 | Powertrain Main Relay Fused Supply (3) | |
| 68 | 0.5 | BK/BN | 5382 | Brake Position Sensor Low Reference | |
| 69 | | | | Not Used | |
| 70 | 0.5 | VT/YE | 5985 | Accessory Wakeup Serial Data | |
| 71 | | | | Not Used | |
| 72 | 0.75 | YE | 5991 | Powertrain Relay Coil Control | |
| 73 | 2.5 | VT/D-BU | 5290 | Ignition 1 Voltage | |
K20 Engine Control Module X1 (LFX)
K20 Engine Control Module X1 (LUK)
| Connector Part Information Harness Type: Engine OEM Connector: 13611938 Service Connector: 13574782 Description: 73-Way F 0.64 2.8 Series, Sealed (BK with BU Terminal Position Assurance Lock) | Terminal Part Information Pins: 6, 9-10, 14-15, 21-22, 25-26, 30, 32-34, 36-37, 39-40, 42, 44, 46, 51-53, 55-57, 59, 62-63, 66, 70, 72 Terminated Lead: 13575575 Release Tool: J-38125-213 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 33467-0005/23 Core/Insulation Crimp: J/J Pin: 62 Terminated Lead: 13575575 Release Tool: J-38125-213 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 33467-0005/23 Core/Insulation Crimp: K/K Pin: 73 Terminated Lead: 13579750 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 1326030-6/17 Core/Insulation Crimp: C/A |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1-5 | | | | Not Used | |
| 6 | 0.5 | L-GN | 380 | A/C Refrigerant Pressure Sensor Signal | |
| 7-8 | | | | Not Used | |
| 9 | 0.5 | D-BU/WH | 890 | Fuel Tank Pressure Sensor Signal | |
| 10 | 0.5 | YE/RD | 2709 | Fuel Tank Pressure Sensor 5-Volt Reference 1 | |
| 11-13 | | | | Not Used | |
| 14 | 0.5 | WH/RD | 1164 | Accelerator Pedal Position 5-Volt Reference 4 (1) | |
| 15 | 0.5 | YE/WH | 1161 | Accelerator Pedal Position Signal (1) | |
| 16-20 | | | | Not Used | |
| 21 | 0.5 | BN/RD | 2700 | 5-Volt Reference 1 | |
| 22 | 0.5 | BK/BN | 5514 | A/C Refrigerant Pressure Sensor Low Reference | |
| 23-24 | | | | Not Used | |
| 25 | 0.5 | D-BU/L-GN | 1936 | Primary Fuel Level Sensor Signal | |
| 26 | 0.5 | BK/L-GN | 6281 | Fuel Level Sensor Low Reference | |
| 27-29 | | | | Not Used | |
| 30 | 0.5 | BK/D-BU | 1271 | Accelerator Pedal Position Low Reference (1) | |
| 31 | | | | Not Used | |
| 32 | 0.5 | WH/GY | 459 | A/C Compressor Clutch Relay Control | |
| 33 | 0.5 | BN/RD | 1274 | Accelerator Pedal Position 5-Volt Reference 3 (2) | |
| 34 | 0.5 | L-GN/WH | 1162 | Accelerator Pedal Position Signal (2) | |
| 35 | | | | Not Used | |
| 36 | 0.5 | D-BU/GY | 7493 | High Speed GMLAN Serial Data (+) (3) | |
| 37 | 0.5 | WH | 7494 | High Speed GMLAN Serial Data (-) (3) | |
| 38 | | | | Not Used | |
| 39 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 40 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 41 | | | | Not Used | |
| 42 | 0.5 | BN/YE | 473 | High Speed Cooling Fan Relay Control | |
| 43 | | | | Not Used | |
| 44 | 0.5 | L-GN/GY | 465 | Fuel Pump Primary Relay Control | |
| 45 | | | | Not Used | |
| 46 | 0.5 | BN/WH | 419 | Check Engine Indicator Control | |
| 47-50 | | | | Not Used | |
| 51 | 0.5 | VT/L-GN | 439 | Run/Crank Ignition 1 Voltage | |
| 52 | 0.5 | RD/BN | 440 | Battery Positive Voltage | |
| 53 | 0.5 | BK/VT | 1272 | Accelerator Pedal Position Low Reference (2) | |
| 54 | | | | Not Used | |
| 55 | 0.5 | L-GN/D-BU | 436 | Air Injection Reaction Pump Relay Coil Control | NU6 |
| 56 | 0.5 | D-BU/BK | 421 | Air Injection Reaction Solenoid Relay Coil Control | NU6 |
| 57 | 0.5 | WH/D-BU | 6311 | Cruise/ETC/TCC Brake Signal | |
| 58 | | | | Not Used | |
| 59 | 0.5 | L-GN/VT | 335 | Low Speed Cooling Fan Relay Control | |
| 60-61 | | | | Not Used | |
| 62 | 0.75 | VT/D-BU | 5291 | Powertrain Main Relay Fused Supply (2) | |
| 63 | 0.5 | VT/GY | 6386 | Starter Enable Relay (PPEI 3) Control | |
| 64-65 | | | | Not Used | |
| 66 | 0.5 | WH | 1310 | EVAP Canister Vent Solenoid Control | |
| 67-69 | | | | Not Used | |
| 70 | 0.5 | VT/YE | 5985 | Accessory Wakeup Serial Data | |
| 71 | | | | Not Used | |
| 72 | 0.5 | YE | 5991 | Powertrain Relay Coil Control | |
| 73 | 1.0 | VT/D-BU | 5290 | Ignition 1 Voltage | |
K20 Engine Control Module X1 (LUK)
K20 Engine Control Module X2 (LFX)
| Connector Part Information Harness Type: Engine OEM Connector: 15499466 Service Connector: 88988931 Description: 73-Way F MX123 Series, Sealed (BK with BK Terminal Position Assurance Lock) | Terminal Part Information Pin: 3, 10-13, 15-16, 18-19, 26-29, 32, 34, 36-37, 41-44, 49, 51-58, 61-63, 69-70 Terminated Lead: 13575575 Release Tool: J-38125-213 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 33467-0005/23 Core/Insulation Crimp: J/J Pin: 73 Terminated Lead: 13576392 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 7116-4152-02/9 Core/Insulation Crimp: A/5 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1-2 | | | | Not Used | |
| 3 | 0.5 | BK/L-GN | 2919 | Sensor Low Reference | |
| 4-9 | | | | Not Used | |
| 10 | 0.5 | VT/GY | 3110 | Heated Oxygen Sensor High Signal Bank 1 Sensor (1) | |
| 11 | 0.5 | VT/WH | 3210 | Heated Oxygen Sensor High Signal Bank 2 Sensor (1) | |
| 12 | 0.5 | VT/D-BU | 3120 | Heated Oxygen Sensor High Signal Bank 1 Sensor (2) | |
| 13 | 0.5 | VT/L-GN | 3220 | Heated Oxygen Sensor High Signal Bank 2 Sensor (2) | |
| 14 | | | | Not Used | |
| 15 | 0.5 | GY/D-BU | 7564 | Humidity Sensor Signal | |
| 16 | 0.5 | BN/WH | 582 | Throttle Actuator Control Close | |
| 17 | | | | Not Used | |
| 18 | 0.5 | BN/RD | 2917 | Fuel Rail Pressure Sensor (5) Volt Reference | |
| 19 | 0.5 | D-D-BU/WH | 2918 | Fuel Rail Pressure Sensor Signal | |
| 20-25 | | | | Not Used | |
| 26 | 0.5 | WH/BK | 3111 | Heated Oxygen Sensor Low Signal Bank 1 Sensor (1) | |
| 27 | 0.5 | YE/WH | 3211 | Heated Oxygen Sensor Low Signal Bank 2 Sensor (1) | |
| 28 | 0.5 | WH/YE | 3121 | Heated Oxygen Sensor Low Signal Bank 1 Sensor (2) | |
| 29 | 0.5 | YE/D-BU | 3221 | Heated Oxygen Sensor Low Signal Bank 2 Sensor (2) | |
| 30-31 | | | | Not Used | |
| 32 | 0.5 | YE | 581 | Throttle Actuator Control Open | |
| 33 | | | | Not Used | |
| 34 | 0.5 | BN/RD | 2701 | Throttle Position Sensor 5-Volt Reference 4 | |
| 35 | | | | Not Used | |
| 36 | 0.5 | VT/GY | 496 | Knock Sensor Signal (1) | |
| 37 | 0.5 | WH/GY | 1876 | Knock Sensor Signal (2) | |
| 38-40 | | | | Not Available | |
| 41 | 0.5 | GY/WH | 3113 | Heated Oxygen Sensor Heater Low Control Bank 1 Sensor (1) | |
| 42 | 0.5 | GY/WH | 3122 | Heated Oxygen Sensor Heater Low Control Bank 1 Sensor (2) | |
| 43 | 0.5 | L-GN/WH | 432 | Manifold Absolute Pressure Sensor Signal | |
| 44 | 0.5 | GY/RD | 2704 | Manifold Absolute Pressure Sensor 5-Volt Reference 3 | |
| 45-46 | | | | Not Used | |
| 47 | 0.5 | WH/RD | 5381 | Brake Position Sensor Low Reference | |
| 48 | 0.5 | WH | 5380 | Brake Position Sensor Signal | |
| 49 | 0.5 | WH/D-BU | 6289 | Induction Air Temperature Sensor Signal | |
| 50 | | | | Not Used | |
| 51 | 0.5 | L-GN/D-BU | 428 | EVAP Canister Purge Solenoid Control | |
| 52 | 0.5 | L-GN/WH | 492 | Mass Air Flow Sensor Signal | |
| 53 | 0.5 | BN | 25 | Charge Indicator Control | |
| 54 | 0.5 | BK/BN | 2752 | Throttle Position Sensor Low Reference | |
| 55 | 0.5 | GY | 23 | Generator Field Duty Cycle Signal | |
| 56 | 0.5 | BK/YE | 1716 | Knock Sensor Low Reference (1) | |
| 57 | 0.5 | BK/GY | 2303 | Knock Sensor Low Reference (2) | |
| 58 | 0.5 | WH/GY | 1786 | Transmission Park/Neutral Signal (1) | |
| 59-60 | | | | Not Used | |
| 61 | 0.5 | L-GN/YE | 3212 | Heated Oxygen Sensor Heater Low Control Bank 2 Sensor (1) | |
| 62 | 0.5 | WH/BN | 3223 | Heated Oxygen Sensor Heater Low Control Bank 2 Sensor (2) | |
| 63 | 0.5 | BK/L-GN | 469 | Manifold Absolute Pressure Sensor Low Reference | |
| 64-67 | | | | Not Used | |
| 68 | 0.5 | BK/BN | 5382 | Brake Position Sensor 5 Volt Reference | |
| 69 | 0.5 | BK/VT | 2760 | Intake Air Temperature Sensor Low Reference | |
| 70 | 0.5 | D-BU/WH | 3630 | Throttle Position Sensor (SENT1) Signal | |
| 71-72 | | | | Not Available | |
| 73 | 2.5 | BK/WH | 451 | Signal Ground | |
K20 Engine Control Module X2 (LFX)
K20 Engine Control Module X2 (LUK)
| Connector Part Information Harness Type: Engine OEM Connector: 15499466 Service Connector: 88988931 Description: 73-Way F MX123 Series, Sealed (BK with BK Terminal Position Assurance Lock) | Terminal Part Information Pins: 1-3, 10, 12, 16-19, 26, 28, 32, 34, 41-44, 47, 49, 51-52, 54, 56, 58, 63, 69-70 Terminated Lead: 13575575 Release Tool: J-38125-213 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 33467-0005/23 Core/Insulation Crimp: J/J Pin: 73 Terminated Lead: Service by Connector Assembly - 88988931 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 1326030-6/17 Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.5 | WH/BN | 6331 | Air Injection Reaction Pump Pressure Sensor Signal | NU6 |
| 2 | 0.5 | WH/BN | 6452 | Air Injection Reaction Pump Sensor Supply Voltage | NU6 |
| 3 | 0.5 | BK/D-BU | 808 | Sensor Low Reference | |
| 4-9 | | | | Not Used | |
| 10 | 0.5 | VT/GY | 3110 | Heated Oxygen Sensor High Signal Bank 1 Sensor (1) | |
| 11 | | | | Not Used | |
| 12 | 0.5 | VT/D-BU | 3120 | Heated Oxygen Sensor High Signal Bank 1 Sensor (2) | |
| 13-15 | | | | Not Used | |
| 16 | 0.5 | BN/WH | 582 | Throttle Actuator Control Close | |
| 17 | 0.5 | BK/D-BU | 6785 | Air Injection Reaction Control Valve #1 Low Reference | NU6 |
| 18 | 0.5 | GY/RD | 598 | 5-Volt Reference 1 | |
| 19 | 0.5 | D-BU/WH | 2918 | Fuel Rail Pressure Sensor Signal | |
| 20-25 | | | | Not Used | |
| 26 | 0.5 | WH/BK | 3111 | Heated Oxygen Sensor Low Signal Bank 1 Sensor (1) | |
| 27 | | | | Not Used | |
| 28 | 0.5 | WH/YE | 3121 | Heated Oxygen Sensor Low Signal Bank 1 Sensor (2) | |
| 29-31 | | | | Not Used | |
| 32 | 0.5 | YE | 581 | Throttle Actuator Control Open | |
| 33 | | | | Not Used | |
| 34 | 0.5 | BN/RD | 2701 | Throttle Position Sensor 5-Volt Reference 4 | |
| 35 | | | | Not Used | |
| 36 | 0.5 | VT/GY | 496 | Knock Sensor Signal (1) | |
| 37-40 | | | | Not Used | |
| 41 | 0.5 | GY/WH | 3113 | Heated Oxygen Sensor Heater Low Control Bank 1 Sensor (1) | |
| 42 | 0.5 | GY/WH | 3122 | Heated Oxygen Sensor Heater Low Control Bank 1 Sensor (2) | |
| 43 | 0.5 | L-GN/WH | 432 | Manifold Absolute Pressure Sensor Signal | |
| 44 | 0.5 | GY/RD | 2704 | Manifold Absolute Pressure Sensor 5-Volt Reference 3 | |
| 45-46 | | | | Not Used | |
| 47 | 0.5 | GY | 5127 | After Boil Heater Relay Control | |
| 48 | | | | Not Used | |
| 49 | 0.5 | WH/D-BU | 6289 | Induction Air Temperature Sensor Signal | |
| 50 | | | | Not Used | |
| 51 | 0.5 | L-GN/D-BU | 428 | EVAP Canister Purge Solenoid Control | |
| 52 | 0.5 | L-GN/WH | 492 | Mass Air Flow Sensor Signal | |
| 53 | | | | Not Used | |
| 54 | 0.5 | BK/BN | 2752 | Throttle Position Sensor Low Reference | |
| 55 | | | | Not Used | |
| 56 | 0.5 | BK/YE | 1716 | Knock Sensor Low Reference (1) | |
| 57 | | | | Not Used | |
| 58 | 0.5 | WH/GY | 1786 | Transmission Park/Neutral Signal (1) | |
| 59-62 | | | | Not Used | |
| 63 | 0.5 | BK/L-GN | 469 | Manifold Absolute Pressure Sensor Low Reference | |
| 64-68 | | | | Not Used | |
| 69 | 0.5 | BK/VT | 2760 | Intake Air Temperature Sensor Low Reference | |
| 70 | 0.5 | BN/L-GN | 3630 | Throttle Position Sensor (SENT1) Signal | |
| 70-72 | | | | Not Used | |
| 73 | 1.5 | BK/WH | 451 | Signal Ground | |
K20 Engine Control Module X2 (LUK)
K20 Engine Control Module X3 (LFX)
| Connector Part Information Harness Type: Engine OEM Connector: 13705684 Service Connector: 88988372 Description: 73-Way F MX123 34566 Series (GY with BK Case) | Terminal Part Information Pin: 8-10, 13-16, 23-42, 46-48, 50-62, 66-68, 70-72 Terminated Lead: 13575575 Release Tool: J-38125-213 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 33467-0005/23 Core/Insulation Crimp: J/J Pin: 73 Terminated Lead: 13576392 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 7116-4152-02/9 Core/Insulation Crimp: A/5 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1-7 | | | | Not Available | |
| 8 | 0.5 | D-BU | 410 | Engine Coolant Temperature Sensor Signal | |
| 9 | 0.5 | YE/D-BU | 231 | Oil Pressure Switch Signal | |
| 10 | 0.5 | VT/D-BU | 6270 | Crankshaft 60X Sensor Voltage | |
| 11-12 | | | | Not Available | |
| 13 | 0.5 | BN/D-BU | 2126 | Ignition Control (6) | |
| 14 | 0.5 | D-BU/GY | 2125 | Ignition Control (5) | |
| 15 | 0.5 | BK/GY | 2130 | Ignition Control Low Reference Bank 2 | |
| 16 | 0.5 | YE | 7301 | High Pressure Fuel Pump Actuator High - Control | |
| 17-22 | | | | Not Available | |
| 23 | | | | Not Used | |
| 24 | 0.5 | BK/BN | 2761 | Coolant Temperature Sensor Low Reference | |
| 25 | 0.5 | BK/VT | 6272 | Crankshaft 60X Sensor Low Reference | |
| 26 | 0.5 | L-GN | 6271 | Crankshaft 60X Sensor Signal | |
| 27 | 0.5 | YE/D-BU | 2124 | Ignition Control (4) | |
| 28 | 0.5 | L-GN/D-BU | 2123 | Ignition Control (3) | |
| 29 | 0.5 | D-BU/WH | 2122 | Ignition Control (2) | |
| 30 | 0.5 | D-BU/VT | 2121 | Ignition Control (1) | |
| 31 | 0.5 | BK/D-BU | 2129 | Ignition Control Low Reference Bank 1 | |
| 32 | 0.5 | VT/BK | 7300 | High Pressure Fuel Pump Actuator Low - Control | |
| 33 | 0.5 | YE/VT | 5275 | Camshaft Position Intake Sensor (1) | |
| 34 | 0.5 | GY/D-BU | 5300 | 5-Volt Reference 1 | |
| 35 | 0.5 | VT/BK | 5273 | Camshaft Position Exhaust Sensor (1) | |
| 36 | 0.5 | YE | 5276 | Camshaft Position Intake Sensor (2) | |
| 37 | 0.5 | WH/D-BU | 5302 | Camshaft Position Intake Sensor 5-Volt Reference 1 | |
| 38 | 0.5 | VT/D-BU | 5274 | Camshaft Position Exhaust Sensor (2) | |
| 39 | 0.5 | VT/BN | 5284 | Camshaft Phaser Intake Solenoid (1) | |
| 40 | 0.5 | GY/D-BU | 5282 | Camshaft Phaser Exhaust Solenoid (1) | |
| 41 | 0.5 | L-GN | 5272 | Camshaft Phaser Intake Solenoid (2) | |
| 42 | 0.5 | L-GN/BN | 5283 | Camshaft Phaser Exhaust Solenoid (2) | |
| 43-45 | | | | Not Available | |
| 46 | 0.5 | GY/D-BU | 4804 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 4 | |
| 47 | 0.5 | WH/L-GN | 4805 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 5 | |
| 48 | 0.5 | D-BU | 4802 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 2 | |
| 49 | | | | Not Available | |
| 50 | 0.5 | L-GN | 4803 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 3 | |
| 51 | 0.5 | VT/L-GN | 4806 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 6 | |
| 52 | 0.5 | BN | 4801 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 1 | |
| 53 | 0.5 | BK/L-GN | 5301 | Camshaft Position Intake Sensor Low Reference (1) | |
| 54 | 0.5 | GY/YE | 5297 | 5-Volt Reference 1 | |
| 55 | 0.5 | BK/GY | 5296 | Camshaft Position Exhaust Sensor Low Reference (1) | |
| 56 | 0.5 | BK/VT | 5303 | Camshaft Position Intake Sensor Low Reference (2) | |
| 57 | 0.5 | L-GN/BN | 5298 | Camshaft Position Exhaust Sensor 5-Volt Reference 1 | |
| 58 | 0.5 | BK/BN | 5299 | Camshaft Position Exhaust Sensor Low Reference (2) | |
| 59 | 0.5 | BK/BN | 6753 | Cam Phaser W Return Low Reference | |
| 60 | 0.5 | BK/VT | 6754 | Cam Phaser X Return Low Reference | |
| 61 | 0.5 | BK/D-BU | 6755 | Cam Phaser Y Return Low Reference | |
| 62 | 0.5 | BK/GY | 6756 | Cam Phaser Z Return Low Reference | |
| 63-65 | | | | Not Available | |
| 66 | 0.5 | D-BU/WH | 4904 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 4 | |
| 67 | 0.5 | L-GN/WH | 4905 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 5 | |
| 68 | 0.5 | D-BU/GY | 4902 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 2 | |
| 69 | | | | Not Available | |
| 70 | 0.5 | L-GN/GY | 4903 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 3 | |
| 71 | 0.5 | VT/GY | 4906 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 6 | |
| 72 | 0.5 | BN/WH | 4901 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 1 | |
| 73 | 2.5 | BK/WH | 451 | Signal Ground | |
K20 Engine Control Module X3 (LFX)
K20 Engine Control Module X3 (LUK)
| Connector Part Information Harness Type: Engine OEM Connector: 13705642 Service Connector: 88988372 Description: 73-Way F Sealed (BK with GY Terminal Position Assurance Lock) | Terminal Part Information 8-10, 16, 24-35, 39-40, 46, 48, 50, 52-55, 59-60, 66, 68, 70, 72 Terminated Lead: 13575575 Release Tool: J-38125-213 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 33467-0005/23 Core/Insulation Crimp: J/J Pin: 73 Terminated Lead: Service by Connector Assembly - 88988372 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 1326030-6/17 Core/Insulation Crimp: Not Available |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1-7 | | | | Not Available | |
| 8 | 0.5 | D-BU | 410 | Engine Coolant Temperature Sensor Signal | |
| 9 | 0.5 | YE/D-BU | 231 | Oil Pressure Switch Signal | |
| 10 | 0.5 | VT/D-BU | 2867 | 5-Volt Reference 2 | |
| 11-15 | | | | Not Available | |
| 16 | 0.5 | YE | 7301 | High Pressure Fuel Pump Actuator High - Control | |
| 17-23 | | | | Not Available | |
| 24 | 0.5 | BK/BN | 2761 | Coolant Temperature Sensor Low Reference | |
| 25 | 0.5 | BK/VT | 574 | Crankshaft Position Sensor Low Reference (1) | |
| 26 | 0.5 | L-GN | 573 | Crankshaft Position Sensor Signal (1) | |
| 27 | 0.5 | D-BU/WH | 2122 | Ignition Control (2) | |
| 28 | 0.5 | YE/D-BU | 2124 | Ignition Control (4) | |
| 29 | 0.5 | L-GN/D-BU | 2123 | Ignition Control (3) | |
| 30 | 0.5 | D-BU/VT | 2121 | Ignition Control (1) | |
| 31 | 0.5 | BK/D-BU | 2129 | Ignition Control Low Reference Bank 1 | |
| 32 | 0.5 | VT/BK | 7300 | High Pressure Fuel Pump Actuator Low - Control | |
| 33 | 0.5 | YE/VT | 5275 | Camshaft Position Intake Sensor (1) | |
| 34 | 0.5 | GY/D-BU | 5300 | 5-Volt Reference 1 | |
| 35 | 0.5 | VT/BK | 5273 | Camshaft Position Exhaust Sensor (1) | |
| 36-38 | | | | Not Available | |
| 39 | 0.5 | VT/BN | 5284 | Camshaft Phaser Intake Solenoid (1) | |
| 40 | 0.5 | GY/D-BU | 5282 | Camshaft Phaser Exhaust Solenoid (1) | |
| 41-45 | | | | Not Available | |
| 46 | 0.5 | D-BU | 4802 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 2 | |
| 47 | | | | Not Available | |
| 48 | 0.5 | L-GN | 4803 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 3 | |
| 49 | | | | Not Available | |
| 50 | 0.5 | GY/D-BU | 4804 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 4 | |
| 51 | | | | Not Available | |
| 52 | 0.5 | BN | 4801 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 1 | |
| 53 | 0.5 | BK/L-GN | 5301 | Camshaft Position Intake Sensor Low Reference (1) | |
| 54 | 0.5 | GY/YE | 5297 | 5-Volt Reference 1 | |
| 55 | 0.5 | BK/GY | 5296 | Camshaft Position Exhaust Sensor Low Reference (1) | |
| 56-58 | | | | Not Available | |
| 59 | 0.5 | BK/BN | 6753 | Cam Phaser W Return Low Reference | |
| 60 | 0.5 | BK/VT | 6754 | Cam Phaser X Return Low Reference | |
| 61-65 | | | | Not Available | |
| 66 | 0.5 | D-BU/GY | 4902 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 2 | |
| 67 | | | | Not Available | |
| 68 | 0.5 | L-GN/GY | 4903 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 3 | |
| 69 | | | | Not Available | |
| 70 | 0.5 | D-BU/WH | 4904 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 4 | |
| 71 | | | | Not Available | |
| 72 | 0.5 | BN/WH | 4901 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 1 | |
| 73 | 1.5 | BK/WH | 451 | Signal Ground | |
K20 Engine Control Module X3 (LUK)
K26 Headlamp Control Module (T4F)
| Connector Part Information Harness Type: Body OEM Connector: 13783351 Service Connector: 13579578 Description: 16-Way F Micro HVT Series (BN) | Terminal Part Information Terminated Lead: 13575550 Release Tool: J-38125-559 Diagnostic Test Probe: J-35616-16 (L-GN) Terminal/Tray: 15445905/23 Core/Insulation Crimp: J/J |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 0.35 | WH/D-BU | 5986 | Serial Data Communication Enable | |
| 2-5 | | | | Not Used | |
| 6 | 0.5 | BK | 850 | Ground | |
| 7 | | | | Not Used | |
| 8 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 9 | 0.35 | RD/YE | 740 | Battery Positive Voltage | |
| 10-12 | | | | Not Used | |
| 13 | 0.35 | GN/PU | 7528 | Linear Interconnect Network Bus 6 | |
| 14-15 | | | | Not Used | |
| 16 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
K26 Headlamp Control Module (T4F)
K27 Fuel Pump Control Module (LFX)
| Connector Part Information Harness Type: Body OEM Connector: 13570966 Service Connector: 89047377 Description: 47-Way F ASG Series (BK) | Terminal Part Information Pins: 1, 16, 32, 47 Terminated Lead: Service by Connector Assembly - 89047377 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Pins: 5, 10, 13, 15, 17, 36 Terminated Lead: 13575263 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Pins: 6-7, 21-22, 44 Terminated Lead: 13575264 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 |
| Pin | Size | Color | Circuit | Function | Option |
|---|
| 1 | 1.5 | BK | 2650 | Ground | |
| 2-4 | | | | Not Available | |
| 5 | 0.35 | BK/YE | 7447 | Fuel Line Pressure Sensor Low Reference | |
| 6 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 7 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 8-9 | | | | Not Available | |
| 10 | 0.35 | D-BU/WH | 7446 | Fuel Line Pressure Sensor Signal | |
| 11-12 | | | | Not Available | |
| 13 | 0.35 | L-GN/GY | 465 | Fuel Pump Primary Relay Control | |
| 14 | | | | Not Available | |
| 15 | 0.35 | VT/BK | 2139 | Run/Crank Ignition 1 Voltage | |
| 16 | 2.5 | BK/L-GN | 1580 | Fuel Pump Low Reference | |
| 17 | 0.35 | WH/D-BU | 5986 | Serial Data Communication Enable | |
| 18-20 | | | | Not Available | |
| 21 | 0.5 | WH | 2501 | High Speed GMLAN Serial Data (-) (1) | |
| 22 | 0.5 | D-BU | 2500 | High Speed GMLAN Serial Data (+) (1) | |
| 23-31 | | | | Not Available | |
| 32 | 2.5 | RD/VT | 2640 | Battery Positive Voltage | |
| 33-35 | | | | Not Available | |
| 36 | 0.35 | BN/RD | 7445 | Fuel Line Pressure Sensor 5V Reference | |
| 37-43 | | | | Not Available | |
| 44 | 0.5 | D-BU | 7443 | Fuel System Control Module Shield Extension | |
| 45-46 | | | | Not Available | |
| 47 | 2.5 | GY | 120 | Fuel Pump Supply Voltage | |
K27 Fuel Pump Control Module (LFX)
