Automatic Transmission - 6t70 - Diagnostic Information and Procedures Buick LaCrosse II

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

Circuit/System Description

The transmission control module (TCM) within the control solenoid valve assembly continuously monitors the system voltage on the ignition voltage circuit. Lower than normal voltage may be inadequate to operate the transmission control solenoids properly. Improper solenoid operation may cause erratic transmission operation, which may result in internal damage. These DTCs detect high or low TCM voltage for an extended period.

Conditions for Running the DTC

P0562

1. Ignition voltage was greater than 5.0 volts and has not dropped below 2.0 volts.
2. Engine speed is greater than 1, 200 RPM.

P0563

Ignition voltage was greater than 5.0 volts and has not dropped below 2.0 volts.

P2534

1. Engine is running.
2. Normal CAN communication is enabled.

Conditions for Setting the DTC

P0562

TCM detects ignition voltage is 11 volts or less for 4 seconds in a period of 12 seconds.

P0563

TCM detects ignition voltage is 18 volts or greater for 10 seconds.

P2534

The TCM detects ignition voltage between 2.0 volts and 5.0 volts for 7 seconds or greater with the engine running.

Action Taken When the DTC Sets

P0562 and P0563

DTCs P0562 and P0563 are Type C DTCs.

P2534

1. DTC P2534 is a Type A DTC.
2. TCM turns the high side driver OFF.
3. TCM commands maximum line pressure.
4. TCM freezes transmission adaptive functions.
5. TCM commands the torque converter clutch (TCC) OFF.
6. TCM limits the transmission to Reverse and fifth gear operation.
7. TCM inhibits Tap Up/Down function.
8. TCM inhibits manual shifting of forward gears.
9. TCM requests a reduced engine torque.

Conditions for Clearing the DTC

1. DTCs P0562 and P0563 are Type C DTCs.
2. DTC P2534 is a Type A DTC.

Diagnostic Aids

1. Observe the driver information center (DIC) messaging that would indicate the electrical system requires service.
2. Running the engine with a battery charger attached may cause DTC P0563 to set.
3. Inspect for the following conditions: Loose or damaged terminals at the generator Loose or worn generator drive belt

Reference Information

Schematic Reference

Automatic Transmission Controls Schematics

Connector End View Reference

1. «COMPONENT CONNECTOR END VIEWS - INDEX»(/buick/lacrosse/ii-2009-2013/remont/body-electrical/#wiring-systems-and-power-management-component-connector-end-views-index)
2. «Inline Harness Connector End Views»(/buick/lacrosse/ii-2009-2013/remont/body-electrical/#wiring-systems-and-power-management-inline-harness-connector-end-views)

Description and Operation

Transmission General Description

Electrical Information Reference

1. «Circuit Testing»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

DTC Type Reference

Powertrain Diagnostic Trouble Code (DTC) Type Definitions

Scan Tool Reference

Control Module References for scan tool information

Special Tools

DT-47825-20 Adapter Harness

For equivalent regional tools, refer to Special Tools .

Circuit/System Verification

1. Test for 12.6-15 volts between the battery terminals with the engine running, accessories OFF. If not between 12.6-15 volts Refer to «Charging System Test»(/buick/lacrosse/ii-2009-2013/remont/charging-system/#battery-charging-system-and-starting-system-except-hybrid) . IF between 12.6-15 volts
2. Verify the scan tool TCM Ignition Voltage parameter is between 12.6-15.0 volts. If not between 12.6-15 volts Refer to Circuit/System Testing Below If between 12.6-15 volts
3. After performing the above steps, verify that the DTC does not reset by operating the vehicle within the Conditions for Running the DTC. You may also operate the vehicle within the conditions you observe from the Freeze Frame/Failure Records data. If the vehicle passes the Circuit/System Verification procedure, then STOP. Do not perform the Circuit/System Testing or Component Testing as this may result in an unnecessary part replacement. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) .

Circuit/System Testing

Note. You must perform the Circuit/System Verification first.

1. Ignition OFF, and all vehicle systems OFF, disconnect the X1 20-way harness connector at the transmission.
2. Connect the DT-47825-20 adapter harness to the vehicle wire harness X1 20-way transmission connector.
3. Test for less than 5 ohms between the ground circuit terminal 1 and ground at the transmission case. If 5 ohms or greater Test for less than 2 ohms in the ground circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, repair the open/high resistance in the ground connection. If less than 5 ohms
4. Ignition ON.
5. Verify that a test lamp illuminates between the B+ circuit terminal 10 and ground. If the test lamp does not illuminate and the circuit fuse is good Ignition OFF. Test for less than 2 ohms in the B+ circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, verify the fuse is not open and there is voltage at the fuse. If the test lamp does not illuminate and circuit fuse is open Ignition OFF. Test the B+ circuit for a short to ground. If B+ circuit has a short to ground, repair the short to ground on the circuit. If B+ circuit does not have a short to ground, replace the fuse. If the test lamp illuminates
6. Verify that a test lamp illuminates between the ignition circuit terminal 13 and ground. If the test lamp does not illuminate and the circuit fuse is good Ignition OFF. Test for less than 2 ohms in the ignition circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, verify the fuse is not open and there is voltage at the fuse. If the test lamp does not illuminate and the circuit fuse is open Ignition OFF. Test the ignition circuit for a short to ground. If ignition circuit has a short to ground, repair the short to ground on the circuit. If ignition circuit does not have a short to ground, replace the fuse. If the test lamp illuminates
7. Replace the Q8 control solenoid valve assembly.

Repair Instructions

Note. Perform the Reset Transmission Adapts following all transmission related repairs. Before replacing the TCM, perform the Control Solenoid Valve and Transmission Control Module Assembly Inspection .

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for control solenoid valve assembly replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Typical Scan Tool Data

Brake Pedal Position Sensor

The brake pedal position (BPP) sensor is part of the engine brake pedal override feature. The engine control module (ECM) continuously monitors the vehicle speed and the position of the brake pedal. These two main inputs, along with other ECM inputs are used to determine if the vehicle is decelerating at the proper speed and rate with the brake pedal applied. When the engine brake pedal override system is active, the ECM reduces engine torque to assist in reducing vehicle speed.

The BPP sensor is a three wire sensor, connected to a 5 V reference circuit, a low reference circuit, and a signal circuit. The ECM supplies 5 V to the BPP sensor, and also provides a sensor ground path on the low reference circuit. The BPP sensor sends a voltage signal to the ECM on the signal circuit. The voltage on the signal circuit will vary from a voltage greater than 0.25 V when the brake pedal is released to a voltage less than 4.75 V when the brake pedal is fully applied.

Ignition voltage is greater than 10 V.

P057C

BPP sensor voltage is less than 0.25 V for 1 second.

P057D

BPP sensor voltage is greater than 4.75 V for 1 second.

1. DTCs P057C and P057D are type B DTCs
2. Engine torque is reduced to 50 percent of available engine torque.
3. Brake torque management is active at 25 kpa (3.7 PSI) of brake apply pressure.

P057C and P057D are type B DTCs.

Schematic Reference

1. «Automatic Transmission Controls Schematics»(/buick/lacrosse/ii-2009-2013/remont/automatic-trans/#automatic-transmission-6t70-wiring-schematic-diagrams)
2. «Engine Controls Schematics (LFX)»(/buick/lacrosse/ii-2009-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-wiring-schematic-diagrams)
3. «Exterior Lights Schematics»(/buick/lacrosse/ii-2009-2013/remont/exterior-lights/#lighting-system-wiring-schematic-diagrams)

Connector End View Reference

1. «COMPONENT CONNECTOR END VIEWS - INDEX»(/buick/lacrosse/ii-2009-2013/remont/body-electrical/#wiring-systems-and-power-management-component-connector-end-views-index)
2. «Inline Harness Connector End Views»(/buick/lacrosse/ii-2009-2013/remont/body-electrical/#wiring-systems-and-power-management-inline-harness-connector-end-views)

Description and Operation

Transmission General Description

Electrical Information Reference

1. «Circuit Testing»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/lacrosse/ii-2009-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

DTC Type Reference

Powertrain Diagnostic Trouble Code (DTC) Type Definitions

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, engine OFF, transmission in PARK, service brake pedal released.
2. Verify DTC P0651 is not set. If DTC is set Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-trouble-code-dtc-list) . If DTC is not set
3. Verify the scan tool Brake Pedal Position Sensor parameter in the ECM Automatic Transmission Data list displays greater than.25 V. If.25 V or less Refer to Circuit/System Testing below. If greater than.25 V
4. Verify the scan tool Brake Pedal Position Sensor parameter changes as the brake pedal is applied and displays less than 4.75 V when the brake pedal is fully applied. If 4.75 V or greater, or the parameter does not change Refer to Circuit/System Testing below. If less than 4.75 V and parameter changes
5. Verify the scan tool Brake Pedal Position Sensor Learned Home Position parameter is within 0.1 V of the Brake Pedal Position Sensor parameter when the brake pedal is fully released. If difference is greater than 0.1 V Command the «Brake Pedal Position Sensor Learn»(/buick/lacrosse/ii-2009-2013/remont/automatic-trans/#automatic-transmission-6t70-diagnostic-information-and-procedures__brake-pedal-position-sensor-learn) with a scan tool. If difference is 0.1 V or less
6. Verify the scan tool Brake Pedal Position Sensor parameter transitions smoothly without any spikes or dropouts when slowly applying and releasing the brake. If parameter does not transition smoothly or has spikes or dropouts Refer to Circuit/System Testing below. If parameter transitions smoothly and there are no spikes or dropouts
7. Operate the vehicle within the Conditions for Running the DTC. You may also operate the vehicle within the conditions that you observed from the Freeze Frame/Failure Records data.
8. Verify the DTC does not set. If the DTC sets Refer to Circuit/System Testing below. If the DTC does not set
9. All OK.

Note. You must perform the Circuit/System Verification first.

1. Ignition OFF and all vehicle systems OFF, disconnect the harness connector from the B22 Brake Pedal Position Sensor. It may take up to 2 minutes for all vehicle systems to power down.
2. Test for less than 10 ohms between the low reference circuit terminal 5 and ground. If 10 ohms or greater Ignition OFF and all systems OFF, disconnect the harness connector at the K20 Engine Control Module. Test for less than 2 ohms in the low reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K20 Engine Control Module. If less than 10 ohms
3. Ignition ON.
4. Test for 4.8-5.2 V between the 5 V reference circuit terminal 6 and ground. If less than 4.8 V Ignition OFF, disconnect the harness connector at the K20 Engine Control Module. Test for infinite resistance between the 5 V reference circuit terminal 6 and ground If less than infinite resistance, repair the short to ground on the circuit If infinite resistance Test for less than 2 ohms in the 5 V reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K20 Engine Control Module. If greater than 5.2 V Ignition OFF, disconnect the harness connector at the K20 Engine Control Module, ignition ON. Test for less than 1 V between the 5 V reference circuit terminal 6 and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V, replace the K20 Engine Control Module. If between 4.8-5.2V
5. Verify the scan tool Brake Pedal Position Sensor parameter is less than.25 V. If parameter is.25 V or greater Ignition OFF, disconnect the harness connector at the K20 Engine Control Module, ignition ON. Test for less than.25 V between the signal circuit terminal 4 and ground. If.25 V or greater, repair the short to voltage on the circuit. If less than.25 V, replace the K20 Engine Control Module If less than.25 V
6. Install a 3 A fused jumper wire between the signal circuit terminal 4 and the 5 V reference circuit terminal 6.
7. Verify the scan tool Brake Pedal Position Sensor parameter is 4.8 V or greater. If less than 4.8 V Ignition OFF, disconnect the harness connector at the K20 Engine Control Module. Test for infinite resistance between the signal circuit terminal 4 and ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K20 Engine Control Module.
8. Replace the B22 Brake Pedal Position Sensor.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Brake Pedal Position Sensor Replacement»(/buick/lacrosse/ii-2009-2013/remont/exterior-lights/#lighting-system-repair-instructions__brake-pedal-position-sensor-replacement)
2. Perform the «Brake Pedal Position Sensor Learn»(/buick/lacrosse/ii-2009-2013/remont/automatic-trans/#automatic-transmission-6t70-diagnostic-information-and-procedures__brake-pedal-position-sensor-learn) following the replacement of the ECM or BPP sensor, or any repair that effects the BPP sensor alignment.

Control Module References for engine control module replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/lacrosse/ii-2009-2013/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
