Seat Belt System Buick Encore I

Restraints Control Systems 10 illustrations ~5803 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Driver or Passenger Seat Belt Buckle Fastener4533 lb ft
Front Seat Belt Guide Adjuster Bolt4533 lb ft
Rear Seat Belt Buckle Nut4030 lb ft
Rear Seat Center Belt Nut4030 lb ft
Rear Seat Center Seat Belt Retractor Nut4533 lb ft
Rear Seat Shoulder Belt Anchor Bolt4533 lb ft
Rear Seat Shoulder Belt Guide Adjuster Nut4533 lb ft
Rear Seat Shoulder Belt Retractor Bolt4533 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Switches and Indicator

Scheme 2

Scheme 2: Switches, Sensor, and Indicator

Note. If the vehicle has been in a collision, refer to Repairs and Inspections Required After a Collision for additional information.

Perform the following inspection from the driver seat

  1. Turn the ignition switch to the ON position. Verify proper operation of the seat belt reminder lamp with the belt buckled and with the belt unbuckled.
  2. Inspect the shoulder belt guide in order to ensure that the following conditions are met: The shoulder belt guide swivels freely. The seat belt webbing is seated flat in the guide slot. The seat belt webbing does not bind.
  3. Verify that the seat belt buckle faces inboard and is accessible.
  4. Verify that the seat belt retractor units are securely attached.
  5. Verify that the seat belt anchor bolts are secure.
  6. Fully extend the seat belt webbing. Verify that the seat belt webbing does not have any twists or tears.
  7. Allow the seat belt webbing to retract. Verify that the seat belt webbing returns freely and completely back into the retractor. If the seat belt webbing will not retract, refer to «Seat Belt Does Not Retract»(/buick/encore/i-2012-2016/remont/restraints-control-systems/#seat-belt-system__seat-belt-does-not-retract) .
  8. Snap the seat belt latch plate into the buckle.
  9. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  10. Push the button on the buckle: Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Perform the following inspection procedure from the passenger seat.

  1. Verify the automatic locking retractor (ALR) feature operates properly by performing the following checks: Pull the seat belt all the way out of the retractor until it stops. Slowly allow the belt to retract partially, while listening for a ratcheting sound. Sharply tug on the belt ensuring that the retractor lock sets and does not allow the belt to be pulled from the retractor. After performing steps 1.1 through 1.3 ensure the belt fully retracts.
  2. Repeat the inspection procedure steps 2 through 10 from the passengers seat.

Perform the following steps in order to inspect the left and right rear seat belts

  1. Inspect the shoulder belt guide in order to ensure that the following conditions are met: The seat belt webbing is seated flat in the guide slot. The seat belt webbing does not bind.
  2. Verify that the seat belt buckle is accessible.
  3. Verify that the seat belt retractor units are securely attached.
  4. Verify that the seat belt anchor bolts are secure.
  5. Fully extend the seat belt webbing. Verify that the seat belt webbing does not have any twists or tears.
  6. Allow the seat belt webbing to retract. Verify that the seat belt webbing returns freely and completely back into the retractor.
  7. Snap the seat belt latch plate into the buckle.
  8. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  9. Push the button on the buckle: Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Emergency Locking Retractors

WARNINGPerform this test in an area clear of other vehicles or obstructions. Do not conduct this test on the open road. A large, empty parking lot is suitable. Failure to observe this precaution may result in damage to the vehicle and possible personal injury.

Scheme 3

Scheme 3
  1. Fasten the seat belts, an assistant is needed when the retractor under test is not part of the driver seat belt.
  2. Accelerate the vehicle slowly to 16 km/h (10 mph) and apply the brakes firmly.
  3. Verify that the seat belt locks when braking firmly.
  4. If the belt does not lock, proceed with the following steps: Remove the seat belt retractor assembly. Tilt the seat belt retractor slowly. Ensure that the seat belt webbing can be pulled from the retractor at an inclination of 15 degrees forward or less, from the retractors mounted position. Ensure the retractor cannot be pulled from the retractor at an inclination of 45 degrees forward or more. If a seat belt retractor does not operate as described, replace the retractor assembly.

Diagnostic Code Index

DTCDescription
DTC B0072 or B0073DTC B0072 Driver Seat Belt Switch Circuit DTC B0073 Passenger Seat Belt Switch Circuit
DTC B059ADTC B059A 01 Passenger Seat Belt Indicator Circuit Short to Battery DTC B059A 02 Passenger Seat Belt Indicator Circuit Short to Ground DTC B059A 04 Passenger Seat Belt Indicator Circuit Open

DIAGNOSTIC CODE INDEX

Diagnostic Instructions

  1. Perform the «Diagnostic System Check - Vehicle»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category

DTC Descriptors

For symptom byte information refer to Symptom Byte List .

Diagnostic Fault Information

CircuitShort to GroundHigh ResistanceOpenShort to VoltageSignal Performance
Driver Seat Belt Switch SignalB0072 02, B0072 0BB0072 04, B0072 06, B0072 0CB0072 04, B0072 06B0072 01, B0072 05B0072 08
Passenger Seat Belt Switch SignalB0073 02, B0073 0BB0073 04, B0073 06, B0073 0CB0073 04, B0073 06B0073 01, B0073 05B0073 08

Circuit/System Description

The inflatable restraint seat belt buckle switch is within the seat belt buckle and provides an input to the inflatable restraint sensing and diagnostic module (SDM). The inflatable restraint sensing and diagnostic module supplies a low reference circuit and a seat belt switch signal circuit to determine a buckled or unbuckled condition. The inflatable restraint sensing and diagnostic module monitors the seat belt switch circuits and if a fault is detected a DTC will be set.

Conditions for Running the DTC

Ignition voltage is between 9-16 V.

Conditions for Setting the DTC

B0072 01 or B0073 01

The seat belt switch circuit is shorted to voltage.

B0072 02 or B0073 02

The seat belt switch circuit is shorted to ground.

B0072 04 or B0073 03

The seat belt switch circuit is open.

B0072 05 or B0073 05

The seat belt switch circuit is shorted to voltage or open.

B0072 06 or B0073 06

The seat belt switch circuit is shorted to ground or open.

B0072 08 or B0073 08

The seat belt switch signal is invalid.

B0072 0B or B0073 0B

The seat belt switch signal is above threshold.

B0072 0C or B0073 0C

The seat belt switch signal is below threshold.

Action Taken When the DTC Sets

The inflatable restraint sensing and diagnostic module will store a DTC and illuminate the air bag indicator in the instrument cluster.

Conditions for Clearing the DTC

The condition for setting the DTC no longer exists.

Reference Information

Schematic Reference

Connector End View Reference

WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - ENCORE WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - TRAX

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
  2. «Testing for Intermittent Conditions and Poor Connections»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
  3. «Wiring Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)
  4. «Connector Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

  1. Ignition ON.
  2. Verify the appropriate scan tool Seat Belt Status parameter changes between Buckled and Unbuckled when the seat belt is buckled and unbuckled. If the parameter does not change Refer to Circuit/System Testing. If the parameter changes
  3. All OK.

Circuit/System Testing

Note. When removing connectors inspect for damage or corrosion. Damage or corrosion in the following requires repair or replacement of the affected component/connector. B153D Seat Belt Buckle-Driver B153P Seat Belt Buckle-Passenger K36 Inflatable Restraint Sensing and Diagnostic Module

  1. Ignition OFF. Scan tool disconnected. Disconnect the harness connector at the appropriate B153 Seat Belt Buckle. It may take up to 2 min for all vehicle systems to power down.
  2. Test for less than 5 ohms between the low reference circuit terminal 2 and ground. If 5 ohms or greater Ignition OFF, disconnect the harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for less than 2 ohms in the low reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If less than 5 ohms
  3. Ignition ON.
  4. Verify the appropriate scan tool Seat Belt Status parameter is Buckled. If not Buckled Ignition OFF, disconnect the harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for infinite resistance between the signal circuit terminal 1 and ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If Buckled
  5. Install a 3 A fused jumper wire between the signal circuit terminal 1 and the low reference circuit terminal 2.
  6. Verify the appropriate scan tool Seat Belt Status parameter is Unbuckled. If not Unbuckled Ignition OFF, disconnect the harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module, ignition ON. Test for less than 1 V between the signal circuit and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V Test for less than 2 ohms in the signal circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If Unbuckled
  7. Test or replace the B153 Seat Belt Buckle.

Component Testing

  1. Ignition OFF. Scan tool disconnected. Disconnect the harness connector at the appropriate B153 Seat Belt Buckle. It may take up to 2 min for all vehicle systems to power down.
  2. Test for infinite resistance between the signal terminal 1 and the low reference terminal 2. If less than infinite resistance Replace the B153 Seat Belt Buckle. If infinite resistance
  3. Insert the seat belt into the buckle.
  4. Test for less than 5 ohms between the signal terminal 1 and the low reference terminal 2. If 5 ohms or greater Replace the B153 Seat Belt Buckle. If less than 5 ohms
  5. All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Front Seat Belt Buckle Replacement»(/buick/encore/i-2012-2016/remont/restraints-control-systems/#seat-belt-system)
  2. «Control Module References»(/buick/encore/i-2012-2016/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for inflatable restraint sensing and diagnostic module replacement, programming, and setup.
  1. Perform the «Diagnostic System Check - Vehicle»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category
CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
Passenger Seat Belt Indicator ControlB059A 02B059A 04B059A 01

The Inflatable Restraint Sensing and Diagnostic Module (SDM) monitors the passenger seat status and the passenger seat belt buckle switch and provides an output to the passenger seat belt indicator. When the Inflatable Restraint Sensing and Diagnostic Module detects the passenger seat is occupied and the seat belt is not fastened, the Inflatable Restraint Sensing and Diagnostic Module supplies a pulse width modulated signal to control the passenger seat belt indicator circuit. The Inflatable Restraint Sensing and Diagnostic Module monitors the passenger seat belt indicator circuits and if a fault is detected a DTC will be set.

Ignition voltage is between 9-16 V.

B059A 01

The passenger seat belt indicator circuit is shorted to voltage.

B059A 02

The passenger seat belt indicator circuit is shorted to ground.

B059A 04

The passenger seat belt indicator circuit is open.

The Inflatable Restraint Sensing and Diagnostic Module will store the DTC.

The condition for setting the DTC no longer exists.

Schematic Reference

Connector End View Reference

WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - ENCORE WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - TRAX

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
  2. «Testing for Intermittent Conditions and Poor Connections»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
  3. «Wiring Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)
  4. «Connector Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)

Scan Tool Reference

Control Module References for scan tool information

Note. When removing connectors inspect for damage or corrosion. Damage or corrosion in the following requires repair or replacement of the affected component/connector. P14 Passenger Air Bag Disable Indicator K36 Inflatable Restraint Sensing and Diagnostic Module

  1. Ignition OFF, disconnect the harness connector at the P14 Passenger Air Bag Disable Indicator.
  2. Test for less than 10 ohms between the ground circuit terminal 1 and ground. If 10 ohms or greater Ignition OFF. Test for less than 2 ohms in the ground circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, repair the open/high resistance in the ground connection. If less than 10 ohms
  3. Connect a test lamp between the control circuit terminal 4 and ground, ignition ON.
  4. Verify the test lamp turns OFF and ON when the passenger seat belt is buckled and unbuckled. If the test lamp is always on Ignition OFF, disconnect the harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module, ignition ON. Test for less than 1 V between the signal circuit and ground. If 1V or greater, repair the short to voltage on the circuit. If less than 1V, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If the test lamp is always off Disconnect the harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for infinite resistance between the seat belt switch signal circuit terminal 45 and ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance Test for less than 2 ohms in each control circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If test lamp turns on and off while changing between the commanded states
  5. Test or replace the P14 Passenger Air Bag Disable Indicator.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Instrument Panel Airbag Arming Status Display Replacement (Trax)»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system) , «Instrument Panel Airbag Arming Status Display Replacement (Encore)»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system) for passenger air bag disable indicator replacement
  2. «Control Module References»(/buick/encore/i-2012-2016/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for Inflatable Restraint Sensing and Diagnostic Module replacement, programming, and setup

Symptoms - Seat Belts

Note. Review the seat belt system description and operation in order to familiarize yourself with the system and how it functions. Refer to Seat Belt System Description and Operation .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the seat belt system. Refer to «Checking Aftermarket Accessories»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories) .
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to the following symptom diagnostic procedure in order to diagnose the symptom

Seat Belt Does Not Retract

  1. Grab the seat belt webbing and slowly and firmly extract 15-25 mm (5/8-1 in) of webbing from the seat belt.
  2. Release the seat belt and allow the webbing to slowly retract back into the retractor.
  3. Check to see if the seat belt is released. If the seat belt is not released, repeat steps 1 and 2, two times more.
  4. If the retractor does not release after repeating the steps, replace with a new retractor.
  1. Perform the «Diagnostic System Check - Vehicle»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
Driver Seat Belt Switch Signal122
Driver Seat Belt Switch Low Reference2
1. Indicator will remain ON with seat belt buckled. 2. Indicator will illuminate only for the bulb check.

The driver seat belt switch is a 2-wire switch wired to the Inflatable Restraint Sensing and Diagnostic Module (SDM) using a signal circuit and a low reference circuit. When the seat belt is unbuckled the switch is closed, and when the seat belt is buckled the switch is open. The Inflatable Restraint Sensing and Diagnostic Module sends the status of the driver seat belt via serial data to the instrument cluster. After receiving the message, the instrument cluster controls the illumination of the driver seat belt indicator.

Schematic Reference

Connector End View Reference

WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - ENCORE WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - TRAX

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
  2. «Connector Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

  1. Verify the driver seat belt indicator turns ON and OFF when commanding the instrument cluster all indicators ON and OFF with a scan tool. If the driver seat belt indicator does not turn ON and OFF as commanded . Replace the P16 Instrument Cluster. If the driver seat belt indicator does turn ON and OFF as commanded
  2. Verify the scan tool Diver Seat Belt Switch parameter changes between Buckled and Unbuckled when buckling and unbuckling the driver seat belt. If the parameter does not change Refer to Circuit/System Testing. If the parameter changes
  3. All OK.

Note. When removing connectors inspect for damage or corrosion. Damage or corrosion in the following requires repair or replacement of the affected component/connector. B153D Seat Belt Buckle-Driver Seat belt switch harness connector K36 Inflatable Restraint Sensing and Diagnostic Module Inflatable Restraint Sensing and Diagnostic Module wiring harness connector

  1. Ignition OFF and all vehicle systems OFF, disconnect the harness connector at the B153D Seat Belt Buckle-Driver. It may take up to 2 minutes for all vehicle systems to power down.
  2. Test for less than 5 ohms between the low reference circuit terminal 2 and ground. If 5 ohms or greater Disconnect the X2 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for less than 2 ohms in each low reference circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If less than 5 ohms
  3. Ignition ON.
  4. Verify the scan tool Driver Seat Belt Status parameter is Buckled. If not Buckled Ignition OFF, disconnect the X2 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for infinite resistance between the seat belt switch signal circuit terminal 1 and ground. If less than infinite resistance, repair the short to ground on the circuit. If infinite resistance, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If Buckled
  5. Install a 3 A fused jumper wire between the signal circuit terminal 1 and the low reference circuit terminal 2.
  6. Verify the scan tool Driver Seat Belt Status parameter is Unbuckled. If Unbuckled Ignition OFF, disconnect the X2 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module, ignition ON. Test for less than 1 V between the signal circuit and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V Test for less than 2 ohms in each circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If Unbuckled
  7. Test or replace the B153D Seat Belt Buckle-Driver.
  1. Ignition OFF, disconnect the harness connector at the B153D Seat Belt Buckle-Driver, buckle the driver seat belt.
  2. Test for infinite resistance between the signal circuit terminal 1 and the low reference terminal 2. If not infinite resistance Replace the B153D Seat Belt Buckle-Driver. If infinite resistance
  3. Unbuckle the driver seat belt.
  4. Test for less than 1 ohms between the signal circuit terminal 1 and the low reference terminal 2. If 1 ohms or greater Replace the B153D Seat Belt Buckle-Driver. If less than 1 ohms
  5. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Front Seat Belt Buckle Replacement»(/buick/encore/i-2012-2016/remont/restraints-control-systems/#seat-belt-system)
  2. «Control Module References»(/buick/encore/i-2012-2016/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for Inflatable Restraint Sensing and Diagnostic Module or instrument cluster replacement, programming and setup
  1. Perform the «Diagnostic System Check - Vehicle»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/buick/encore/i-2012-2016/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
Passenger Seat Belt Switch Signal122
Passenger Seat Belt Indicator Control334
Passenger Seat Belt Switch Low Reference2
Ground3
1. Indicator will remain ON with seat belt buckled. 2. Indicator will illuminate only for the bulb check. 3. Indicator will not illuminate. 4. Indicator always ON.

When an individual is sitting in the passenger seat the passenger presence sensor detects the individual. A signal to the Inflatable Restraint Sensing and Diagnostic Module indicates a person is in the passenger seat. The Inflatable Restraint Sensing and Diagnostic Module will turn the passenger seat belt indicator. The passenger seat belt switch is a 2-wire switch wired to the Inflatable Restraint Sensing and Diagnostic Module using a signal circuit and a low reference circuit. When the seat belt is unbuckled the switch is closed, and when the seat belt is buckled the switch is open. The Inflatable Restraint Sensing and Diagnostic Module sends the status of the passenger seat belt via a hard wire to the passenger air bag disable indicator. After receiving the message, the passenger air bag disable indicator controls the illumination of the passenger seat belt indicator.

Diagnostic Aids

Objects on the passenger seat can cause the passenger seat belt reminder to be commanded on. Depending on the sensing technology used, a conductive object (computers, MP3 players, cell phones, diagnostic scan tool, wires, a hand, etc.) placed on the passenger seat may cause the Passenger Presence Detection Module to command the passenger air bag indicator ON and/or command the passenger seat belt indicator ON. The fasten seat belt chime will also sound.

Schematic Reference

Connector End View Reference

WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - ENCORE WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - TRAX

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
  2. «Connector Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the passenger seat belt indicator turns ON and OFF when commanding the Passenger Seat Belt Reminder Indicator with a scan tool. If the passenger seat belt indicator does not turn ON and OFF Refer to Seat Belt Indicator Malfunction in Circuit/System Testing. If the passenger seat belt indicator turns ON and OFF
  3. Verify the scan tool Passenger Seat Belt Status parameter changes between Buckled and Unbuckled when buckling and unbuckling the seat belt. If the parameter does not change between Buckled and Unbuckled when buckling and unbuckling the seat belt Refer to Seat Belt Switch Malfunction in Circuit/System Testing. If the parameter changes between Buckled and Unbuckled when buckling and unbuckling the seat belt
  4. All OK.

Passenger Seat Belt Switch Malfunction

  1. Ignition OFF. Disconnect the harness connector at the B153P Seat Belt Buckle-Passenger.
  2. Test for less than 5 ohms between the low reference circuit terminal 2 and ground. If 5 ohms or greater Disconnect the X2 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for less than 2 ohms in each control circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If less than 5 ohms
  3. Ignition ON.
  4. Verify the scan tool Passenger Seat Belt Status parameter listed below is Buckled. If not Buckled Disconnect the X2 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for infinite resistance between the seat belt switch signal circuit terminal 1 and ground. If less than infinite resistance, repair the short to ground on the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If Buckled
  5. Install a 3 A fused jumper wire between the signal circuit terminal 1 and the low reference circuit terminal 2.
  6. Verify the scan tool Passenger Seat Belt Status parameter is Unbuckled. If not Unbuckled Ignition OFF. Disconnect the X2 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Ignition ON. Test for less than 1 V between the signal circuit and ground. If 1 V or greater, repair the short to voltage on the circuit. Test for less than 2 ohms in each circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If Unbuckled
  7. Test or replace the B153P Seat Belt Buckle-Passenger.

Passenger Seat Belt Indicator Malfunction

  1. Ignition OFF and all vehicle systems OFF, disconnect the harness connector at the P14 Passenger Air Bag Disable Indicator.
  2. Test for less than 10 ohms between the ground circuit terminal 4 and ground. If 10 ohms or greater Ignition OFF. Test for less than 2 ohms in the ground circuit end to end. If 2 ohms or greater, repair the open/high resistance in the circuit. If less than 2 ohms, repair the open/high resistance in the ground connection. If less than 10 ohms
  3. Ignition ON. With a scan tool, command the Passenger Seat Belt Reminder Indicator OFF.
  4. Test for less than 11 V between the control circuit terminal 6 and ground. If 11 V or greater Ignition OFF. Disconnect the X1 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Ignition ON. Test for less than 1 V between the control circuit terminal 6 and ground. If 1 V or greater, repair the short to voltage on the circuit. If less than 1 V, replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If less than 11 V
  5. With a scan tool, command the Passenger Seat Belt Reminder Indicator ON.
  6. Test for greater than 4 V between the control circuit terminal 6 and ground. If 4 V or less Ignition OFF. Disconnect the X 1 harness connector at the K36 Inflatable Restraint Sensing and Diagnostic Module. Test for infinite resistance between the control circuit terminal 6 and ground. If less than infinite resistance, repair the short to ground on the circuit. Test for less than 2 ohms between the control circuit terminal 6 and ground. If 2 ohms or greater repair the open/high resistance in the circuit. If less than 2 ohms replace the K36 Inflatable Restraint Sensing and Diagnostic Module. If greater than 4 V
  7. Replace the P14 Passenger Air Bag Disable Indicator.
  1. Ignition OFF. Disconnect the harness connector at the B153P Seat Belt Buckle-Passenger. Buckle the B153P Seat Belt Buckle-Passenger.
  2. Test for infinite resistance between the signal circuit terminal 1 and the low reference terminal 2 at the B153P Seat Belt Buckle-Passenger. If less than infinite resistance Replace the B153P Seat Belt Buckle-Passenger. If infinite resistance
  3. Unbuckle the B153P Seat Belt Buckle-Passenger.
  4. Test for less than 1 ohms between the signal circuit terminal 1 and the low reference terminal 2 at the B153P Seat Belt Buckle-Passenger. If 1 ohms or greater Replace the B153P Seat Belt Buckle-Passenger. If less than 1 ohms
  5. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Front Seat Belt Buckle Replacement»(/buick/encore/i-2012-2016/remont/restraints-control-systems/#seat-belt-system)
  2. «Instrument Panel Airbag Arming Status Display Replacement (Trax)»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system) , «Instrument Panel Airbag Arming Status Display Replacement (Encore)»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system)
  3. «Control Module References»(/buick/encore/i-2012-2016/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for Inflatable Restraint Sensing and Diagnostic Module and Instrument Cluster replacement, programming and setup

Seat Belt Service Precautions

  1. Do not bleach or dye the seat belt webbing. Use only the following items in order to clean the seat belt webbing: A mild soap and water solution A soft brush or cloth
  2. Keep sharp edges and damaging objects away from the seat belts. Avoid bending or damaging any part of the seat belt buckle or the latch plate. Replace any seat belts which are cut or damaged in any way.
  3. Use only the correct seat belt anchor bolts/screws and tighten the anchor bolts/screws to the correct torque value. Refer to «Fastener Tightening Specifications»(/buick/encore/i-2012-2016/remont/restraints-control-systems/#seat-belt-system__fastener-tightening-specifications) . When installing seat belt anchor bolts, start the bolt by hand to ensure that the bolt is threaded straight.
  4. Some seat belts and retractors require service as a set, with service replacement parts only. Do not attempt to repair to individual components that require service as a set.
  5. Verify that the replacement part number is correct for the vehicle at that seating position. Do not substitute a seat belt from a different seating position.

Repairs and Inspections Required After a Collision

WARNINGRestraint systems can be damaged in a collision. To help avoid injury and ensure that all parts in need of replacement are replaced: Replace any seat belt system that was in use during the collision serious enough to deploy any automatic restraint device such as air bags and seat belt pretensioners. This not only includes seat belt systems in use by people of adult size, but seat belt systems used to secure child restraints, infant carriers and booster seats, including LATCH system and top tether anchorages. Replace any seat belt system that has torn, worn, or damaged components. This not only includes adult seat belt systems, but built-in child restraints and LATCH system components, if any. Replace any seat belt system if you observe the words "REPLACE" or "CAUTION", or if a yellow tag is visible. Do not replace a seat belt if only the child seat caution label is visible. Replace any seat belt system if you are doubtful about its condition. This not only includes adult seat belt systems, but built-in child restraints, LATCH system components, and any restraint system used to secure infant carriers, child restraints, and booster seats. Do NOT replace single seat belt system components in vehicles that have been in a collision as described above. Always replace the entire seat belt system with the buckle, guide and retractor assembly, which includes the latch and webbing material.

After a minor collision where no automatic restraint device was deployed, seat belt system replacement may not be necessary, unless some of the parts are torn, worn, or damaged.

Scheme 4

Scheme 4: Front Seat Belt Buckle Replacement
CalloutComponent Name
Preliminary Procedures Remove the front seat. Refer to Driver or Passenger Seat Removal and Installation .
1Driver or Passenger Seat Belt Buckle Fastener CAUTION: Refer to Fastener Caution . Tighten 45 N.m (33 lb ft)
2Driver or Passenger Seat Belt Buckle Assembly Procedure Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Front Seat Belt Buckle Replacement

Scheme 5

Scheme 5: Rear Seat Belt Buckle Replacement
CalloutComponent Name
1Rear Seat Belt Buckle Nut CAUTION: Refer to Fastener Caution . Procedure Pull on the lower release straps to disengage the seat cushion so it can be folded into the up position to gain access to the nut. Tighten 45 (33 lb ft)
2Rear Seat Belt Buckle Assembly Procedure Disconnect the electrical, if equipped.
CAUTION
Refer to Fastener Caution .

Rear Seat Belt Buckle Replacement

Scheme 6

Scheme 6: Rear Seat Center Shoulder Belt Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear seat center belt. Refer to Rear Seat Center Belt Replacement . Remove the rear seat back cushion cover and pad. Refer to Rear Seat Back Cushion Cover and Pad Replacement (40%) , Rear Seat Back Cushion Cover and Pad Replacement (60%) .
1Rear Center Seat Belt Retractor Nut. CAUTION: Refer to Fastener Caution . Tighten 45 (33 lb ft)
2Rear Seat Center Belt Retractor Assembly
CAUTION
Refer to Fastener Caution .

Rear Seat Center Shoulder Belt Replacement

Scheme 7

Scheme 7: Rear Seat Center Belt Replacement
CalloutComponent Name
1Rear Seat Center Belt Nut CAUTION: Refer to Fastener Caution . Procedure Pull on the lower release straps to disengage the seat cushion so it can be folded into the up position to gain access to the nut. Tighten 40 (30 lb ft)
2Rear Seat Center Belt Assembly Procedure Disconnect the electrical, if equipped.
CAUTION
Refer to Fastener Caution .

Rear Seat Center Belt Replacement

Scheme 8

Scheme 8: Front Seat Belt Guide Adjuster Replacement
CalloutComponent Name
Preliminary Procedures Remove the center pillar upper trim panel. Refer to Center Pillar Upper Trim Panel Replacement (Encore) , Center Pillar Upper Trim Panel Replacement (Trax) Remove the front seat belt retractor upper fastener only. Refer to Front Seat Belt Retractor Replacement (With A69) .
1Front Seat Shoulder Belt Guide Adjuster Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 45 (33 lb ft)
2Front Seat Shoulder Belt Guide Adjuster
CAUTION
Refer to Fastener Caution .

Front Seat Belt Guide Adjuster Replacement

Scheme 9

Scheme 9: Rear Seat Belt Retractor Replacement
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the rear seat cushion. Refer to Rear Seat Cushion Removal and Installation . Remove the quarter lower rear trim panel. Refer to Quarter Lower Rear Trim Panel Replacement .
1Rear Seat Shoulder Belt Anchor Bolt CAUTION: Refer to Fastener Caution . Tighten 45 (33 lb ft)
2Rear Seat Shoulder Belt Retractor Bolt NOTE: When the seat belt retractor is replaced with a new one, there is no thread in the nut welded to the retractor. This is normal as the bolt will make the thread in the welded nut when the bolt is tightened. Tighten 45 (33 lb ft)
3Rear Seat Shoulder Belt Guide Adjuster Bolt Tighten 45 (33 lb ft)
4Rear Seat Shoulder Belt Retractor Assembly
CAUTION
Refer to Fastener Caution .
NOTE
When the seat belt retractor is replaced with a new one, there is no thread in the nut welded to the retractor. This is normal as the bolt will make the thread in the welded nut when the bolt is tightened.

Rear Seat Belt Retractor Replacement

Scheme 10

Scheme 10: Seat Belt with P14 Block Diagram
CalloutComponent Name
HWHard-Wired
HWHard-Wired
HWHard-Wired
DASerial Data
DASerial Data
HWHard-Wired
DASerial Data
B153DB153D Seat Belt Buckle - Driver
B153PB153P Seat Belt Buckle - Passenger
K36K36 Inflatable Restraint Sensing and Diagnostic Module
A11A11 Radio
P16P16 Instrument Cluster
B60B60 Passenger Presence Sensor
K85Passenger Presence Module
P14P14 Passenger Air Bag Disabled Indicator

Restraint System

Note. If the vehicle has been in a collision, refer to Repairs and Inspections Required After a Collision

The vehicle has front and rear seat belts that are the primary means of occupant restraint. Seat belts help to keep the occupants inside the passenger compartment and to gradually reduce the impact forces during the following events

  1. Frontal impact type crashes
  2. Rear impact type crashes
  3. Side impact type crashes
  4. Roll-over type crashes

All seat belt retractors have emergency locks. The retractors remain unlocked during normal operation and under normal driving conditions. The retractors remain unlocked during normal conditions in order to allow free movement of the upper body of each occupant. A pendulum locks the seat belt webbing into position. The pendulum causes a locking bar to engage a cog on the spool of the retractor mechanism when the following conditions occur

  1. A rapid extraction of the seat belt webbing from the retractor
  2. An abrupt change in vehicle speed
  3. An abrupt change in vehicle direction
  4. Operation of the vehicle on a steep upgrade
  5. Operation of the vehicle on a downgrade

The seat belts have an automatic locking (cinch) feature. The cinch feature is activated when the seat belt webbing is completely extended from the retractor. The cinch feature prevents the webbing from extending beyond the position from which it is allowed to retract. Use of the cinch feature is recommended for securing a child seat. The cinch feature may be cancelled by allowing the webbing to wind back completely into the retractor. After the cinch feature is cancelled, the webbing is unlocked. After the cinch feature is cancelled, the webbing will extend from the retractor. This vehicle is also equipped with a supplemental inflatable restraint (SIR) system. Refer to Supplemental Inflatable Restraint System Description and Operation

The front seat belt system includes a driver and passenger seat belt pretensioner retractor. Both front seat belt pretensioners includes a seat belt switch in the seat buckle which controls a reminder lamp and a tone alarm.

Note. The front passenger seat is equipped with a passenger presence detection sensor, which detects an occupant. If the passenger presence detection sensor detects an empty front passenger seat, then the passenger fasten safety belt indicator will be disabled.

  1. When the driver seat belt is buckled and the ignition switch is turned ON, the following events will occur: The tone alarm will not operate. The reminder lamp will not operate.
  2. When the passenger seat belt is buckled with an occupant sitting in the passenger front seat, then the ignition switch is turned ON, the following events will occur: The tone alarm will not operate. The reminder lamp, which is located within the Passenger Air Bag Disable Indicator, will not be turned ON.
  3. When the driver seat belt is not buckled and the ignition switch is in the ON position, the following events will occur: The tone alarm will operate for 4-8 seconds and then go OFF. The fasten safety belt indicator will turn ON for 20 seconds, until the driver seat belt is buckled.
  4. When the passenger seat belt is not buckled with an occupant sitting in the passenger front seat, then the ignition switch is turned ON, the following events will occur: The tone alarm will operate for 4-8 seconds and then go OFF. The reminder lamp, which is located within the Passenger Air Bag Disable Indicator, will be turned ON.

The Rear Seat Belt System includes the following components

  1. The rear seat belt retractor is located at the wheelhouse panel and attached to the floor panel by the rear seat shoulder belt retractor bracket.
  2. The rear seat belt buckles and the center seat belt buckle are attached to each seat.

Child Seat Restraint System

WARNINGA child in a rear-facing child restraint can be seriously injured if the right-front passengers air bag inflates. This is because the back of a rear-facing child restraint would be very close to the inflating air bag. NEVER use a rear-facing child restraint in this vehicle. If a forward-facing child restraint is suitable for your child, ALWAYS move the front passenger seat as far back as it will go and then install the child restraint. Be sure the child restraint position does not conflict with any additional requirements provided by the manufacturer. For more information, refer to the vehicle owners manual and the instruction that came with the child restraint.

A child in a rear-facing child restraint can be seriously injured if the right-front passengers air bag inflates. This is because the back of a rear-facing child restraint would be very close to the inflating air bag. NEVER use a rear-facing child restraint in this vehicle. If a forward-facing child restraint is suitable for your child, ALWAYS move the front passenger seat as far back as it will go and then install the child restraint. Be sure the child restraint position does not conflict with any additional requirements provided by the manufacturer. For more information, refer to the vehicle owners manual and the instruction that came with the child restraint.

The child seat may only be used in a forward facing seating location. The child seat should be installed and secured according to the manufacturer's directions. If the child seat has a top strap, the seat will need to be anchored. Passengers should not be allowed to sit at locations where the seat belts are being used to secure the child seat.

All vehicles are equipped with a dual-mode type retractor with emergency and automatic locking features. The automatic locking feature is for restraint of a child seat. The child seat can be secured by pulling the seat belt all the way out to lock it. Then tighten the seat belt around the child seat.

If a child seat is to be used in the second seat position, a special dealer-installed anchor must be used in order to anchor the child seat top strap. This only applies to the seats designed with the top strap provision and for the vehicles sold in Canada. In order to ensure the correct top strap angle, the child seat is only to be used at the seating position for which the top strap anchor is installed.

Fasten Safety Belt Indicators

There are two fasten safety belt indicators for this vehicle. The driver fasten safety belt reminder is displayed in the instrument cluster, and the passenger fasten safety belt reminder is displayed in the passenger air bag disable indicator. The fasten safety belt indicator may only be ON during RUN. The fasten safety belt indicator illuminates under the following conditions

  1. During the bulb check
  2. The inflatable restraint sensing and diagnostic module (SDM) sends the status of the driver seat belt to the instrument cluster via serial data. The passenger seat belt status is sent to the passenger air bag disable indicator via a hardwire. If any of the seat belts are unfastened, the instrument cluster will send a message requesting a chime sound to be turned ON after a bulb check.

See also:
Diagnostic System Check - Vehicle
Strategy Based Diagnosis
Diagnostic Procedure Instructions
Symptom Byte List
WIRING SYSTEMS AND POWER MANAGEMENT - COMPONENT CONNECTOR END VIEWS - INDEX - ENCORE
Supplemental Inflatable Restraint System Description and Operation
Circuit Testing
Testing for Intermittent Conditions and Poor Connections
Wiring Repairs
Connector Repairs
Control Module References
Diagnostic Repair Verification
Checking Aftermarket Accessories
Driver or Passenger Seat Removal and Installation
Fastener Caution
Center Pillar Upper Trim Panel Replacement (Encore)
SIR Disabling and Enabling
Repairs and Inspections Required After a Collision
Seat Belt Does Not Retract
DTC B0072 or B0073
Fastener Tightening Specifications
