Brake Pedal Position Sensor Calibration

Note. Brake system does not use a brake switch, stoplight switch or brakelight switch. System uses a Brake Pedal Position Sensor to control these functions.

Calibration Criteria

Note. Do not apply the brake pedal during the brake pedal position sensor calibration procedure. Any movement of the brake pedal during this procedure will cause the calibration procedure to fail. If this occurs, the brake pedal position sensor calibration must be repeated.

Brake pedal position sensor calibration must be performed after the brake pedal position sensor, body control module (BCM), or engine control module (ECM) have been serviced. The calibration procedure will set the brake pedal position sensor home value. This value is used by the BCM and ECM to determine the action of the driver applying the brake system and to provide this information to the vehicle subsystems via serial data.

Calibration Procedure

1. Apply the parking brake.
2. Ignition ON, engine OFF, place the transmission in the PARK position for automatic transmission or NEUTRAL position for manual transmission.
3. Install a scan tool.
4. Clear all DTCs before proceeding.
5. Navigate to the Configuration/Reset Functions menu of the BCM.
6. Select the Brake Pedal Position Sensor Learn procedure and follow the directions displayed on the screen.
7. Navigate to the Configuration/Reset Functions menu of the ECM.
8. Select the Learn Functions menu.
9. Select the Brake Pedal Position Sensor Learn procedure and follow the directions displayed on the screen.

Brake Pedal Position Sensor Replacement

Note. Brake system does not use a brake switch, stoplight switch or brakelight switch. System uses a Brake Pedal Position Sensor to control these functions.

Removal Procedure

1. Remove the left side front floor air outlet duct. Refer to «Floor Front Air Outlet Duct Replacement - Left Side (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , «Floor Front Air Outlet Duct Replacement - Left Side (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__floor-front-air-outlet-duct-replacement) .
2. Disconnect the brake pedal position sensor electrical connector.
3. Remove the brake pedal position sensor bolt (1).
4. Remove the brake pedal position sensor (1).

Installation Procedure

1. Install the brake pedal position sensor (1).
2. Install the brake pedal position sensor bolt (1) and tighten to 3 (27 lb in).
3. Install the left side front floor air outlet duct. Refer to «Floor Front Air Outlet Duct Replacement - Left Side (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , «Floor Front Air Outlet Duct Replacement - Left Side (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__floor-front-air-outlet-duct-replacement) .
4. Connect the brake pedal position sensor electrical connector.
5. Calibrate the brake pedal position sensor. Refer to «Brake Pedal Position Sensor Calibration»(/buick/encore/i-2012-2016/remont/exterior-lights/#lighting-system-repair-instructions__brake-pedal-position-sensor-calibration) .

Scheme 1

Headlamp Switch Replacement (Encore)

Scheme 2

Headlamp Switch Replacement (Trax)

Scheme 3

Hazard Warning Switch Replacement (Trax)

Scheme 4

Hazard Warning and Accessory Switch Replacement (Encore)

Scheme 5

Dome Lamp Bezel Replacement

Scheme 6

Center Reading Lamp Replacement

Scheme 7

Center Reading Lamp Bulb Replacement

Scheme 8

Center Reading and Courtesy Lamp Lens Replacement

Scheme 9

Instrument Panel Flood Lamp Replacement - Left Side (Encore)

Scheme 10

Instrument Panel Flood Lamp Replacement - Right Side (Encore)

Scheme 11

Windshield Header Courtesy Lamp Replacement

Scheme 12

Rear Seat Position Center Courtesy Lamp Replacement

Scheme 13

Sunshade Illuminated Mirror Lamp Bulb Replacement (Encore)

Scheme 14

Sunshade Illuminated Mirror Lamp Bulb Replacement (Trax)

Scheme 15

Sunshade Illuminated Mirror Lamp Lens Replacement (Encore)

Scheme 16

Sunshade Illuminated Mirror Lamp Lens Replacement (Trax)

Scheme 17

Dome Lamp Bulb Replacement

Scheme 18

Outside Rearview Mirror Turn Signal Lamp Replacement

Scheme 19

Headlamp Replacement

Scheme 20

Headlamp Bulb Replacement - Left Side (Trax High Beam)

Scheme 21

Headlamp Bulb Replacement - Left Side (Trax Low Beam)

Scheme 22

Headlamp Bulb Replacement - Right Side (High Beam)

Scheme 23

Headlamp Bulb Replacement - Right Side (Low Beam)

Scheme 24

Headlamp Bracket Replacement

Visual Aiming Preparation Procedure

Note. Some state and local laws specify requirements for headlamp aim. Comply with all of these laws when performing any headlamp aiming operations.

Headlamp aim should be checked

1. When a new headlamp capsule is installed.
2. If service or repairs to the front end area have, or may have, disturbed the headlamps or their mounting.

The aiming screen should meet the following criteria

1. The area will consist of a level surface large enough to allow for a vehicle and an additional 7.62 m (25 ft) measured from face of lamps to the front of the aiming screen.
2. The screen will be 1.52 m (5 ft) high x 3.66 m (12 ft) wide with a matte white surface well shaded from extraneous light, and properly adjusted to the floor on which the vehicle stands. Provisions should be made to align the aiming screen parallel with the vehicle.
3. The screen shall be provided with a fixed vertical centerline, two laterally adjustable vertical tapes, and one vertically adjustable horizontal tape.
4. If a regular commercial aiming screen is not available, the screen may consist of a vertical wall having a clear uninterrupted area approximately 1.83 m (6 ft) high and 3.66 m (12 ft) wide. The surface should be finished with a washable non-gloss white paint.
5. After the aiming screen has been set up in a permanent location, paint a reference line on the floor directly under the lens of the lamps to indicate the proper location of the headlamps when they are being aimed: Adjustable horizontal tape (1) Adjustable vertical pointer (2) Diagram of light screen (3) Distance between headlamps (4) Center line of screen (5) Horizontal center line of lamps (6) 7.62 m (25 ft) (7) Car axis (8) Horizontal center line ahead of left headlamp (9)

Prior to aiming the headlamps, the following steps must be taken

1. Remove any snow, ice or mud from the vehicle.
2. The vehicle must have a full tank of gas.
3. Stop all other work on the vehicle.
4. If any service has been performed on the vehicle, make sure that all of the components are back in their original place.
5. The vehicle must be on a level surface.
6. The vehicle left tires must be aligned with the reference line extending from the screen with the headlamps aligned with the reference line.
7. Do not load any cargo in the vehicle.
8. The vehicle must contain approximately 75 kg (165 lb) on the driver seat.
9. Inflate the tires to the proper pressure.
10. Simulate the vehicle loads if the intended use of the vehicle is for hauling heavy loads or towing a trailer.
11. Rock the vehicle in order to stabilize the suspension.
12. Turn on the headlamps to low beam and observe the left and the top edges of the high intensity zone on the screen. The edges of the high intensity zone should fall within the specifications.

Scheme 25

1. Open the hood.
2. Measure from the floor to the center of the headlamp bulb. Some headlamps have an aim dot marked on the headlamp lens.
3. At the screen, measure from the floor and place the horizontal tape at the measured distance.
4. Measure from the reference line on the floor to the left headlamp bulb centerline.
5. At the screen (1), measure from the reference line and place the vertical tape at the measured distance.
6. Measure from the reference line on the floor to the right headlamp bulb centerline.
7. At the screen, measure from the reference line and place the vertical tape (2) at the measured distance.
8. Turn ON the low beam headlamps. Block the light from projecting onto the screen from the passenger side headlamp.
9. Adjust the vertical aim screw ( as shown by the arrow ) of the headlamps to the specifications required by the state and the local authorities, or as shown in step number 8.
10. Repeat the aiming procedure for the passenger side headlamp while blocking the light from projecting onto the screen from the driver side headlamp.
11. Turn the headlamps OFF.
12. Close the hood.

Scheme 26

Front Fog Lamp Replacement (Trax)

Scheme 27

Front Fog Lamp Replacement (Encore)

Scheme 28

Front Fog Lamp Bulb Replacement (Trax)

Scheme 29

Front Fog Lamp Bulb Replacement (Encore)

Scheme 30

Front Fog Lamp Cover Replacement (Trax Except T3U)

Scheme 31

Front Fog Lamp Cover Replacement (Trax With T3U)

Scheme 32

Front Fog Lamp Cover Replacement (Encore)

Scheme 33

Front Fog Lamp Opening Cover Replacement (Encore)

Preparation Procedure

Note. Horizontal aim is not adjustable on this vehicle. Adjust the fog lamp as required using the adjusting screw above the projector lens on the outside of the front bumper fascia. Prior to aiming the fog lamps, perform the following steps

1. Completely assemble all of the components on the vehicle.
2. Place the vehicle on a level surface.
3. Stop all unnecessary operations or work that could affect the ride height of the vehicle.
4. Close the doors and verify that the luggage compartment is empty.
5. Stabilize the suspension by rocking the vehicle sideways.
6. Ensure that the fuel level is full.
7. Ensure that the tires are inflated to the proper pressure.
8. Ensure that the driver or a similar weight, approximately 75 kg (165 lb), is in the vehicle driver seat.

Aiming Procedure

1. Park the vehicle 7.6 m (25 ft) away from the target screen (a).
2. Measure the distance from the center of the fog lamp to the ground line (b).
3. Using this measurement, mark the horizontal centerline (1) of the fog lamp on the target screen directly in front of the vehicle.
4. Turn ON the fog lamps.
5. The top of the fog lamp beam image (2) on the target screen should be 102 mm (4 in) below the center of the fog lamp lens height (1).
6. Adjust the fog lamp as required using the adjusting screw above the projector lens on the outside of the front bumper fascia.
7. After the adjustments are made, turn OFF the fog lamps.

Scheme 34

Front Turn Signal Lamp Bulb Replacement (Left hand)

Scheme 35

Front Turn Signal Lamp Bulb Replacement (Right Hand)

Scheme 36

Parking and Turn Signal Lamp Bulb Replacement (Left Hand)

Scheme 37

Parking and Turn Signal Lamp Bulb Replacement (Right Hand)

Scheme 38

High Mount Stop Lamp Replacement

Scheme 39

Cargo Lamp Replacement

Scheme 40

Cargo Center Courtesy Lamp Bulb Replacement

Scheme 41

Backup Lamp Bulb Replacement (Trax)

Scheme 42

Backup Lamp Bulb Replacement (Encore)

Scheme 43

Rear License Plate Lamp Replacement

Scheme 44

Rear License Plate Lamp Bulb Replacement

Scheme 45

Rear License Plate Lamp Wiring Harness Replacement

Scheme 46

Tail Lamp Replacement (Trax)

Scheme 47

Tail Lamp Replacement (Encore)

Scheme 48

Stop and Tail Lamp Bulb Replacement (Trax)

Scheme 49

Stop and Tail Lamp Bulb Replacement (Encore)

Scheme 50

Rear Turn Signal Lamp Bulb Replacement (Trax)

Scheme 51

Rear Turn Signal Lamp Bulb Replacement (Encore)
