Master Electrical Component List (Encore)
| Code | Name | Option | Location | Locator View | Connector End View |
|---|---|---|---|---|---|
| A3L | Sunshade - Left | D6I | In the passenger compartment, at the top left of the windshield | A3L Sunshade - Left | |
| A3R | Sunshade - Right | D6I | In the passenger compartment, at the top right of the windshield | A3R Sunshade - Right | |
| A7 | Fuel Pump and Level Sensor Assembly | LUV | Underneath the vehicle, inside the fuel tank | Fuel Tank Components | A7 Fuel Pump And Level Sensor Assembly |
| A9A | Outside Rearview Mirror - Driver | DLS | Outside the vehicle, at the front of the driver door | Driver Door Components (with panel) | A9A Outside Rearview Mirror - Driver |
| A9B | Outside Rearview Mirror - Passenger | DLS | Outside the vehicle, at the front of the passenger door | Passenger Door Components (without panel) | A9B Outside Rearview Mirror - Passenger |
| A10 | Inside Rearview Mirror | Inside passenger compartment. On windshield close to the top in center. | A10 Inside Rearview Mirror | ||
| A11 | Radio | In the passenger compartment, in the center of the instrument panel | A11 Radio X1 A11 Radio X2 | ||
| A22 | Radio Controls | In the passenger compartment, in the center of the instrument panel | Front of Instrument Panel (Buick) | ||
| A23D | Door Latch Assembly - Driver | Inside the driver door, at the rear of the door | Driver Door Components (with panel) Driver Door Components (without panel) | A23D Door Latch Assembly - Driver | |
| A23LR | Door Latch Assembly - Left Rear | Inside the left rear door, at the rear of the door | Passenger Door Components (without panel) Passenger Door Components (with panel) | A23LR Door Latch Assembly - Left Rear | |
| A23P | Door Latch Assembly - Passenger | Inside the passenger door, at the rear of the door | Passenger Door Components (without panel) Passenger Door Components (with panel) | A23P Door Latch Assembly - Passenger | |
| A23RR | Door Latch Assembly - Right Rear | Inside the right rear door, at the rear of the door | Right Rear Door (without panel) Right Rear Door (with panel) | A23RR Door Latch Assembly - Right Rear | |
| A26 | HVAC Controls | Inside Passenger Compartment. In center of dash. | A26 HVAC Controls | ||
| B1 | A/C Refrigerant Pressure Sensor | In the engine compartment, above the A/C compressor, in the air conditioning compressor and condenser hose, on the pressure side | B1 A/C Refrigerant Pressure Sensor | ||
| B5LF | Wheel Speed Sensor - Left Front | Outside the vehicle, in the left front steering knuckle | Wheel Components | B5LF Wheel Speed Sensor - Left Front | |
| B5LR | Wheel Speed Sensor - Left Rear | Outside the vehicle, in the left rear drum brake spacer | Wheel Components | B5LR Wheel Speed Sensor - Left Rear | |
| B5RF | Wheel Speed Sensor - Right Front | Outside the vehicle, in the right front steering knuckle | Wheel Components | B5RF Wheel Speed Sensor - Right Front | |
| B5RR | Wheel Speed Sensor - Right Rear | Outside the vehicle, in the right rear drum brake spacer | Wheel Components | B5RR Wheel Speed Sensor - Right Rear | |
| B7D | Air Temperature Sensor - Duct Left Lower | CJ2 | HVAC Components (1 of 2) | B7D Air Temperature Sensor - Duct Left Lower | |
| B7E | Air Temperature Sensor - Duct Right Lower | CJ2 | HVAC Components (1 of 2) | B7E Air Temperature Sensor - Duct Right Lower | |
| B7H | Air Temperature Sensor - Duct Left Upper | CJ2 | HVAC Components (1 of 2) | B7H Air Temperature Sensor - Duct Left Upper | |
| B7J | Air Temperature Sensor - Duct Right Upper | CJ2 | HVAC Components (1 of 2) | B7J Air Temperature Sensor - Duct Right Upper | |
| B9 | Ambient Air Temperature Sensor | Outside the vehicle, behind the lower grille insert, on the passenger side | Front of Vehicle Components | B9 Ambient Air Temperature Sensor | |
| B10B | Ambient Light/ Sunload Sensor | In Passenger Compartment. On top Do Instrument Panel. | Front of Instrument Panel (Buick) | B10 AMBIENT LIGHT SENSOR | |
| B12A | Transmission Fluid Pressure Switch | Internal to the Automatic Transmission assembly | |||
| B13 | Transmission Fluid Temperature Sensor | Internal to the Automatic Transmission assembly | |||
| B14A | Transmission Output Shaft Speed Sensor | In the engine compartment, internal to the automatic transmission assembly | COMPONENT LOCATION | B14A Transmission Output Shaft Speed Sensor | |
| B14C | Transmission Input Shaft Speed Sensor | In the engine compartment, internal to the automatic transmission assembly | COMPONENT LOCATION | B14C Transmission Input Shaft Speed Sensor (MH8 or MHB) | |
| B15 | Transmission Internal Mode Switch | In the engine compartment, internal to the automatic transmission assembly | COMPONENT LOCATION | B15 Transmission Internal Mode Switch | |
| B18 | Battery Current Sensor | In the left front of the engine compartment, in front of the battery, on the negative battery cable | B18 Battery Current Sensor | ||
| B20 | Brake Fluid Level Switch | At the rear of the engine compartment, driver's side, on the brake master cylinder | Left of Engine Compartment Components | B20 Brake Fluid Level Switch | |
| B22 | Brake Pedal Position Sensor | In the passenger compartment, under the driver side of the instrument panel, above the brake pedal | |||
| B23E | Camshaft Position Sensor - Exhaust | In the engine compartment, on the upper right front corner of the cylinder head | B23E Camshaft Position Sensor - Exhaust | ||
| B23F | Camshaft Position Sensor - Intake | In the engine compartment, on the upper right rear corner of the cylinder head | B23F Camshaft Position Sensor - Intake | ||
| B24 | Cellular Phone Microphone | UE1 or UNM | In the front of the passenger compartment, in the center, behind the dome lamp bezel | B24 Cellular Phone Microphone | |
| B26 | Crankshaft Position Sensor | In the engine compartment, on the lower left side of the engine, below the starter | B26 Crankshaft Position Sensor | ||
| B34 | Engine Coolant Temperature Sensor | In the right front of the engine compartment, in the bottom right of the radiator | B34A ENGINE COOLANT TEMPERATURE SENSOR 1 | ||
| B37 | B37 Engine Oil Pressure Switch | In the engine compartment, on the left side of the engine | B37B Engine Oil Pressure Sensor | ||
| B39 | A/C Evaporator Temperature Sensor | In the passenger compartment, in the HVAC assembly, on the left side, near the evaporator | B39 A/C EVAPORATOR TEMPERATURE SENSOR | ||
| B46A | Fuel Level Sensor - Primary | Underneath the vehicle, inside the fuel tank, internal to A7 Fuel Pump and Level Sensor Assembly | |||
| B46B | Fuel Level Sensor - Secondary | F46 | Under the vehicle, inside the fuel tank, part of the fuel pump and level sensor assembly | Fuel Tank Components | B46B Fuel Level Sensor - Secondary |
| B47 | Fuel Pressure Sensor | FHA | In the engine compartment, on top of the engine towards the right rear, at the end of the fuel rail | ||
| B52A | Heated Oxygen Sensor 1 | In the engine compartment, in front of the engine, in the exhaust manifold | Left Front of Engine Components (LUJ/LUV) | B52A HEATED OXYGEN SENSOR 1 | |
| B52B | Heated Oxygen Sensor 2 | In the engine compartment, behind the engine, in the exhaust pipe | B52B Heated Oxygen Sensor 2 | ||
| B55 | Hood Ajar Switch | In the front of the engine compartment, by the hood latch assembly | Front of Engine Compartment Components | B55 Hood Ajar Switch | |
| B59L | Front Impact Sensor - Left | In the front of the engine compartment, in the center, above the radiator | |||
| B59R | Front Impact Sensor - Right | In the front of the engine compartment, in the center, above the radiator | |||
| B60 | Passenger Presence Sensor | In the passenger compartment, under the passenger seat | B60 Passenger Presence Sensor | ||
| B63LF | Side Impact Sensor - Left Front | In the passenger compartment, In Left front door. Close to where wires for left front door enter door. | B63LF SIDE IMPACT SENSOR - LEFT FRONT | ||
| B63LR | Side Impact Sensor - Left Rear | In the passenger compartment, at the bottom of the left C-pillar, behind the trim panel | |||
| B63RF | Side Impact Sensor - Right Front | In the passenger compartment, In right front door. Close to where wires for right front door enter door. | B63RF SIDE IMPACT SENSOR - RIGHT FRONT | ||
| B63RR | Side Impact Sensor - Right Rear | In the passenger compartment, at the bottom of the right C-pillar, behind the trim panel | |||
| B68 | Knock Sensor | In the engine compartment, on the back of the engine block, below the intake manifold | B68 Knock Sensor | ||
| B74 | Mainfold Absolute Pressure Sensor | In the engine compartment, towards the left rear of the engine, on the side of the intake manifold | B74 Manifold Absolute Pressure Sensor | ||
| B75C | Multifunction Intake Air Sensor | LUJ | In the engine compartment, attached to the air intake tube | Left Front of Engine Components (LUJ/LUV) | B75C Multifunction Intake Air Sensor (LUJ) |
| B77LF | Radio Volume Compensator Interior Noise Microphone - Left Front | In Headliner, at the front of the vehicle. | |||
| B77RF | Radio Volume Compensator Interior Noise Microphone - Right Front | In Headliner, at the front of the vehicle. | |||
| B77R | Radio Volume Compensator Interior Noise Microphone - Rear | In Headliner, at the Middle to rear of the vehicle. | |||
| B78A | Front Object Sensor - Left Outer | UD5 | Outside the front of the vehicle, behind the Front fascia, left outer position | Front of Vehicle Components | B78A FRONT OBJECT SENSOR - LEFT OUTER |
| B78B | Front Object Sensor - Right Outer | UD5 | Outside the front of the vehicle, behind the front fascia, right outer position | Front of Vehicle Components | B78B FRONT OBJECT SENSOR - RIGHT OUTER |
| B78C | Front Object Sensor - Left Middle | UD5 | Outside the front of the vehicle, behind the front fascia, left middle position | Front of Vehicle Components | B78C FRONT OBJECT SENSOR - LEFT MIDDLE |
| B78D | Front Object Sensor - Right Middle | UD5 | Outside the Front of the vehicle, behind the front fascia, right middle position | Front of Vehicle Components | B78D FRONT OBJECT SENSOR - RIGHT MIDDLE |
| B78E | Rear Object Sensor - Left Middle | UD5 | Outside the rear of the vehicle, behind the rear fascia, left middle position | Rear of Vehicle Components | B78E REAR OBJECT SENSOR - LEFT MIDDLE |
| B78F | Rear Object Sensor - Right Middle | UD5 | Outside the rear of the vehicle, behind the rear fascia, right middle position | Rear of Vehicle Components | B78F REAR OBJECT SENSOR - RIGHT MIDDLE |
| B78G | Rear Object Sensor - Left Outer | UD5 | Outside the rear of the vehicle, behind the rear fascia, left outer position | Rear of Vehicle Components | B78G REAR OBJECT SENSOR - LEFT OUTER |
| B78H | Rear Object Sensor - Right Outer | UD5 | Outside the rear of the vehicle, behind the rear fascia, right outer position | Rear of Vehicle Components | B78H REAR OBJECT SENSOR - RIGHT OUTER |
| B80 | Park Brake Switch | In the passenger compartment, under the center console, at the base of the park brake handle | B80 Park Brake Switch | ||
| B81B | Park Position Switch | M97 | Internal to S3 Transmission Shift Lever | ||
| B87 | Rearview Camera | UVC | At rear of vehicle. on Outside of vehicle, above license plate, Between license plate lamp. | Rear of Vehicle Components | B87 Rearview Camera (UVC) |
| B88D | Seat Belt Switch -Driver | In Seat Belt Buckle- Driver | B88D Seat Belt Switch - Driver | ||
| B88P | Seat Belt Switch - Passenger | In Seat Belt Buckle- Passenger | B88P Seat Belt Switch - Passenger | ||
| B99 | Steering Wheel Angle Sensor | Inside the vehicle, on the steering collumn, behind the steering wheel air bag coil | Steering Column Components | B99 Steering Wheel Angle Sensor | |
| B10B | B10B Ambient Light / Sunload Sensor | In the passenger compartment, On instrument panel.l | B104 Sunload Sensor | ||
| B107 | Accelerator Pedal Position Sensor | In the passenger compartment, under the driver side of the instrument panel, above the accelerator pedal | B107 Accelerator Pedal Position Sensor | ||
| B111B | Turbocharger Boost/Intake Air Temperature Sensor | In the engine compartment, In the intake tube before the Throttle Body. | Left Front of Engine Components (LUJ/LUV) | ||
| B150 | Fuel Tank Pressure Sensor | LUV | Under Car, On the fuel tank harness. Between Fuel tank and bottom of car. | B150 Fuel Tank Pressure Sensor | |
| B153D | Seat Belt Buckle - Driver | In the passenger compartment, between the driver seat and the center console | B153D Seat Belt Buckle - Driver | ||
| B153P | Seat Belt Buckle - Passenger | In the passenger compartment, between the passenger seat and the center console | |||
| B160 | Windshield Temperature and Inside of Moisture Sensor | CJ2 | In the front passenger compartment, next to the inside rearview mirror | B160 Windshield Temperature And Inside Moisture Sensor | |
| B203 | Engine Coolant Radiator Temperature Sensor | In the engine compartment, Near the Radator | |||
| B200 | Rain Sensor Module | CE1 | Headliner Components (With Sunroof) | ||
| B218L | Side Object Sensor Module - Left | UFT | |||
| B218R | Side Object Sensor Module - Right | UFT | |||
| B272 | Child Security Lock Switch | NCG | Front of Instrument Panel (AT) | B272 Child Security Lock Switch | |
| C1 | Battery | In the front left corner of the engine compartment | |||
| C3 | Telematics Communication Interface Control Module Battery | In passenger compartment, behind dash on passenger side. | |||
| E1G | Accent Lamp - Left Instrument Panel | Inside passenger compartment on left side of Instrument panel | E1G ACCENT LAMP - LEFT INSTRUMENT PANEL (C93) | ||
| E1H | Accent Lamp - Right Instrument Panel | Inside passenger compartment on right side of Instrument panel | E1H ACCENT LAMP - RIGHT INSTRUMENT PANEL (C93) | ||
| E1W | Accent Lamp - Instrument panel | Inside passenger compartment on center of Instrument panel | E1W ACCENT LAMP - INSTRUMENT PANEL (C93) | ||
| E2LF | Side Marker Lamp - Left Front | Front of Vehicle Components | |||
| E2RF | Side Marker Lamp - Right Front | Front of Vehicle Components | |||
| E2LR | Side Marker Lamp - Left Rear | Inside Tail Lamp Assembly - Left | E2LR Side Marker Lamp - Left Rear | ||
| E2RR | Side Marker Lamp - Right Rear | Inside Tail Lamp Assembly - Right | E2RR Side Marker Lamp - Right Rear | ||
| E4E | Headlamp - Left High Beam | Inside Headlamp - Left | E4E Head Lamp - Left High Beam | ||
| E4F | Headlamp - Right High Beam | Inside Headlamp - Right | E4F Head Lamp - Right High Beam | ||
| E4G | Headlamp - Left Low Beam | Inside Headlamp - Left | E4G Head Lamp - Left Low Beam | ||
| E4H | Headlamp - Right Low Beam | Inside Headlamp - Right | E4H Head Lamp - Right Low Beam | ||
| E4J | Park Lamp - Left Front | Inside Headlamp - Left | |||
| E4K | Park Lamp - Right Front | Inside Headlamp - Right | |||
| E4LF | Turn Signal Lamp - Left Front | On the vehicle exterior, on the left front corner | |||
| E4LR | Turn Signal Lamp - Left Rear | In the Tail Lamp Assembly - Left | |||
| E4RF | Turn Signal Lamp - Right Front | On the vehicle exterior, on the right front corner | |||
| E4RR | Turn Signal Lamp - Right Rear | In the Tail Lamp Assembly - Right | |||
| E5A | Backup Lamp - Left | In rear of vehicle, In Tail Lamp Assembly - Left | E5A Backup Lamp - Left | ||
| E5AA | Tail/Stop Lamp - Left | In rear of vehicle, In Tail Lamp Assembly - Left | |||
| E5B | Backup Lamp - Right | In rear of vehicle, In Tail Lamp Assembly - Right | E5B Backup Lamp - Right | ||
| E5AB | Tail/Stop Lamp - Right | In rear of vehicle, In Tail Lamp Assembly - Right | |||
| E5E | Tail Lamp - Left | At the rear of the vehicle, internal to E42L Tail Lamp Assembly - Left | |||
| E5F | Tail Lamp - Right | At the rear of the vehicle, internal to E42R Tail Lamp Assembly - Right | |||
| E6 | Center High Mounted Stop Lamp | In the rear of the passenger compartment, at the top of the liftgate glass | Rear of Vehicle Components | E6 Center High Mounted Stop Lamp | |
| E7L | License Plate Lamp - Left | Outside of the liftgate, left of center, above the license plate | Rear of Vehicle Components | E7L License Plate Lamp - Left | |
| E7R | License Plate Lamp - Right | Outside of the liftgate, right of center, above the license plate | Rear of Vehicle Components | E7R License Plate Lamp - Right | |
| E8S | Rear Compartment Courtesy Lamp | In the rear compartment, on the left side | Left Side of Passenger Compartment Components (2 of 2) | E8S Rear Compartment Courtesy Lamp | |
| E13LA | Headlamp Assembly - Left | Outside, left front corner of the vehicle | Front of Vehicle Components | E13LA Headlamp Assembly - Left | |
| E13RA | Headlamp Assembly - Right | Outside, right front corner of the vehicle | Front of Vehicle Components | E13RA Headlamp Assembly - Right | |
| E14A | Seat Heating Element - Driver Back | KA1 | In the passenger compartment, under the driver seat cushion cover | ||
| E14B | Seat Heating Element - Driver Cushion | KA1 | In the passenger compartment, under the driver seat cushion cover | E14B SEAT HEATING ELEMENT - DRIVER CUSHION | |
| E14C | Seat Heating Element - Passenger Back | KA1 | In the passenger compartment, under the passenger seat cushion cover | ||
| E14D | Seat Heating Element - Passenger Cushion | KA1 | In the passenger compartment, under the passenger seat cushion cover | E14D Seat Heating Element - Passenger Cushion | |
| E15 | Steering Wheel Heater | UVD | In the passenger compartment, In steering wheel Column. | ||
| E17D | Outside Rearview Mirror Glass - Driver | UFT | |||
| E17P | Outside Rearview Mirror Glass - Passenger | UFT | |||
| E18 | Rear Defogger Grid | In the passenger compartment, on the inside of the liftgate window | Rear of Vehicle Components | E18 Rear Defogger Grid X1 E18 Rear Defogger Grid X2 | |
| E27 | Instrument Panel Compartment Lamp | T3U | In the passenger compartment, On the Instrument Panel | E27 Instrument Panel Compartment Lamp | |
| E29LF | Fog Lamp - Left Front | T3U | Outside, left front, lower corner of the vehicle, in the front fascia | Front of Vehicle/Engine Compartment Component Views | E29LF Fog Lamp - Left Front (T3U) |
| E29RF | Fog Lamp - Right Front | T3U | Outside, right front, lower corner of the vehicle, in the front fascia | Front of Vehicle/Engine Compartment Component Views | E29RF Fog Lamp - Right Front (T3U) |
| E32 | Cigarette Lighter Receptacle | Inside passenger compartment, In center of dash. Below HVAC controls. | E32 Cigarette Lighter Receptacle | ||
| E36AH | Dome Lamp | Inside passenger compartment, In headliner over second row seats. | |||
| E37A | Dome/Reading Lamps | In the passenger compartment, front and center of the headliner, between the sun visors | Left Side of Passenger Compartment Components (2 of 2) | E37A Dome/Reading Lamps | |
| E41 | Engine Coolant Thermostat Heater | In the engine compartment, towards the right front of the engine, in the water outlet assembly | E41 Engine Coolant Thermostat Heater | ||
| E42L | Tail Lamp Assembly - Left | Outside, left rear corner of the vehicle | Rear of Vehicle Components | ||
| E42R | Tail Lamp Assembly - Right | Outside, right rear corner of the vehicle | Rear of Vehicle Components | ||
| F101 | Passenger Instrument Panel Air Bag | In the passenger compartment, in the instrument panel, in front of the passenger seat | |||
| F105L | Roof Rail Air Bag - Left | AY0/AYF | In the passenger compartment, on the left roof rail, behind the trim panel | Left Side of Passenger Compartment Components (2 of 2) | F105L Roof Rail Air Bag - Left |
| F105R | Roof Rail Air Bag - Right | AY0/AYF | In the passenger compartment, on the right roof rail, behind the trim panel | Front of Vehicle Components | F105R Roof Rail Air Bag - Right |
| F106D | F106D Seat Side Air Bag - Driver | In the passenger compartment, In the Driver Seat | Driver Seat Components (Power) | F106D Seat Side Air Bag - Driver | |
| F106P | F106P Seat Side Air Bag - Passenger | In the passenger compartment, In the Passenger Seat | Passenger Seat Components (Power) | ||
| F106LR | Seat Side Air Bag - Left Rear | AYF | In the passenger compartment, In the Left side of the roof over the Left rear door | ||
| F106RR | Seat Side Air Bag - Right Rear | AYF | In the passenger compartment, In the Right side of the roof over the right rear door | ||
| F107 | Steering Wheel Air Bag | In the passenger compartment, on the center of the steering wheel | |||
| F112D | Seat Belt Retractor Pretensioner - Driver | In the passenger compartment, at the base of the driver side B-pillar, part of the driver seat belt retractor | Front of Vehicle Components | ||
| F112P | Seat Belt Retractor Pretensioner - Passenger | In the passenger compartment, at the base of the passenger side B-pillar, part of the passenger seat belt retractor | Front of Vehicle Components | ||
| F114D | Knee Airbag - Driver | AYF | In the passenger compartment, In passenger area of the dash on the drivers side | ||
| F114P | Knee Airbag - Passenger | AYF | In the passenger compartment, In the knee area of the dash on the passenger side. | ||
| F113D | Seat Belt Anchor Pretensioner - Driver | In the passenger compartment, between the center console and the driver seat, at the base of the driver seat belt buckle | |||
| F113P | Seat Belt Anchor Pretensioner - Passenger | In the passenger compartment, between the center console and the passenger seat, at the base of the passenger seat belt buckle | |||
| F122 | A/C Compressor Temperature Switch | Internal to G1 A/C Compressor | |||
| G1 | A/C Compressor | For Locator View or Connector End View, see Q2 A/C Compressor Clutch | |||
| G10 | Cooling Fan Motor | In the front center of the engine compartment, mounted to the back of the radiator | |||
| G12 | Fuel Pump | Under Vehicle. At rear of vehicle, in fuel tank. | |||
| G13 | Generator | In the engine compartment, on the lower right rear side of the engine | G13 Generator X1 | ||
| G24 | Windshield Washer Pump | Outside the left front corner of the vehicle, behind the front fascia, in the bottom of the washer solvent reservoir | Front of Engine Compartment Components | G24 Windshield Washer Pump | |
| K8 | Blower Motor Control Module | In the passenger compartment, behind the instrument panel. | HVAC Components (1 of 2) | K8 Blower Motor Control Module X1 | |
| K9 | Body Control Module | In the passenger compartment, behind the left side of the instrument panel | Rear of Instrument Panel Components (2 of 2) | K9 Body Control Module X1 K9 Body Control Module X2 K9 Body Control Module X3 K9 Body Control Module X4 K9 Body Control Module X5 K9 Body Control Module X6 K9 Body Control Module X7 | |
| K17 | Electronic Brake Control Module | At the rear of the engine compartment, driver's side, to the left of the brake master cylinder | Left of Engine Compartment Components | K17 Electronic Brake Control Module | |
| K20 | Engine Control Module | In the left front of the engine compartment, on the right side of the battery | K20 Engine Control Module X1 (LUJ) K20 Engine Control Module X1 (2H0 with MH8/MHB) K20 Engine Control Module X1 (2H0 with MFH/M7Y/MZ4) K20 Engine Control Module X2 (LUJ) K20 Engine Control Module X2 (2H0 with MH8/MHB) K20 Engine Control Module X2 (2H0 with MFH/M7Y/MZ4) K20 Engine Control Module X3 (LUJ) K20 Engine Control Module X3 (2H0 with MH8/MHB) | ||
| K32 | Steering Wheel Heating Control Module | UVD | Inside of passenger compartment. | ||
| K33 | HVAC Control Module | In the passenger compartment, in the center of the instrument panel, under the radio | HVAC Components (1 of 2) | K33 HVAC Control Module X2 (C67/CJ2) K33 HVAC Control Module X1 (CJ2) K33 HVAC Control Module X3 (CJ2/C67) | |
| K35 | Ignition Coil Module | In the engine compartment, mounted to the top of the engine | K35 Ignition Coil Module | ||
| K36 | Inflatable Restraint Sensing and Diagnostic Module | In the passenger compartment, under the instrument panel, in front of the center console | Rear of Instrument Panel Components (1 of 2) Rear of Instrument Panel Components (2 of 2) | K36 INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE X1 K36 Inflatable Restraint Sensing And Diagnostic Module X2 | |
| K38 | Chassis Control Module | FHA | Under Vehicle Near Fuel tank. | K38 Chassis Control Module | |
| K40 | Seat Memory Control Module | AAG/KA1 | Inside of the passenger compartment. Under bottom of Driver seat. | K40 SEAT MEMORY CONTROL MODULE X1 K40 SEAT MEMORY CONTROL MODULE X2 K40 SEAT MEMORY CONTROL MODULE X3 K40 SEAT MEMORY CONTROL MODULE X4 K40 SEAT MEMORY CONTROL MODULE X5 | |
| K41 | Front and Rear Parking Assist Control Module | UD5 | Inside of the passenger compartment. | Front of Vehicle Components | K41 Front And Rear Parking Assist Control Module X1 K41 Front And Rear Parking Assist Control Module X2 K41 Front And Rear Parking Assist Control Module X3 |
| K43 | Power Steering Control Module | In the passenger compartment, under the instrument panel, part of the steering column, near the base | Steering Column Components | K43 POWER STEERING CONTROL MODULE | |
| K47 | Rear Differential Clutch Control Module | F46 | In the rear of the vehicle. Under Vehicle on rear axle | K47 Rear Differential Clutch Control Module X1 | |
| K61 | Sunroof Control Module | CF5 | In the passenger compartment, above the headliner, at the front of the sunroof | K61 Sunroof Control Module | |
| K71 | Transmission Control Module | In Side the Automatic Transmission Assembly | |||
| K73 | Telematics Communication Interface Control Module | UE1 | In the passenger compartment, behind the instrument panel, in front of the passenger seat | K73 Telematics Communication Interface Control Module | |
| K77 | Remote Control Door Lock Receiver | In the passenger compartment, under the instrument panel center upper molding | Left Side of Passenger Compartment Components (2 of 2) | K77 Remote Control Door Lock Receiver | |
| K85 | K85 Passenger Presence Module | Passenger Seat Components (Power) | K85 Passenger Presence Module | ||
| K89 | Immobilizer Control Module | In the passenger compartment, on the right side of the steering column, around the ignition lock cylinder | Steering Column Components | K89 Immobilizer Control Module | |
| K109 | Frontview Camera Module | UFL | In the passenger compartment, in headliner by rearview mirror | K109 FRONTVIEW CAMERA MODULE | |
| M6L | Air Temperature Door Actuator - Left | HVAC Components (2 of 2) | M6L Air Temperature Door Actuator - Left | ||
| M6R | Air Temperature Door Actuator - Right | CJ2 | HVAC Components (1 of 2) | M6R Air Temperature Door Actuator - Right | |
| M7 | Transmission Shift Lock Control Solenoid Actuator | Inside the Transmission Shift lever | |||
| M8 | Blower Motor | In passenger compartment, Behind Dash. On passenger side of vehicle. | M8 BLOWER MOTOR | ||
| M9 | Brake Booster Pump Motor | At the rear of the engine compartment, driver's side, below the master cylinder | |||
| M30 | Liftgate Latch | Inside the bottom center of the liftgate | Liftgate Components | M30 Liftgate Latch | |
| M32 | Differential Clutch Pump | F46 | |||
| M37 | Mode Door Actuator | HVAC Components (2 of 2) | |||
| M45 | Rear Wiper Motor | Inside the center of the liftgate, at the bottom of the liftgate glass | Liftgate Components | M45 Rear Wiper Motor | |
| M46 | Air Recirculation Door Actuator | HVAC Components (1 of 2) | |||
| M50D | Seat Front Vertical Motor - Driver | Inside passenger compartment. In front driver seat | |||
| M50P | Seat Front Vertical Motor - Passegner | Inside passenger compartment. In front passenger seat | |||
| M51D | Seat Horizontal Motor - Driver | Inside passenger compartment. In front driver seat | |||
| M51P | Seat Horizontal Motor - Passenger | Passenger Seat Components (Power) | M51P Seat Horizontal Motor - Passenger | ||
| M53D | Seat Lumbar Support Motor - Driver | AR9 | In the passenger compartment, in the driver seat back | Driver Seat Components (Power) | |
| M53P | Seat Lumbar Support Motor - Passenger | AR9 | In the passenger compartment, in the front passenger seat back | Passenger Seat Components (Power) | |
| M55D | Seat Rear Vertical Motor - Driver | Inside passenger compartment. In front driver seat | |||
| M55P | Seat Rear Vertical Motor - Passenger | Passenger Seat Components (Power) | M55P Seat Rear Vertical Motor - Passenger | ||
| M64 | Starter Motor | In the engine compartment, on the lower left rear of the engine | M64 Starter Motor X1 M64 Starter Motor X1 | ||
| M74D | Window Motor - Driver | Inside driver door. | Driver Door Components (without panel) | M74D Window Motor - Driver | |
| M74P | Window Motor - Passenger | Inside passenger door | Passenger Door Components (with panel) | M74P Window Motor - Passenger | |
| M74LR | Window Motor - Left Rear | A33 | Inside the left rear door, below the window | Left Rear Door (without panel) | M74LR Window Motor - Left Rear |
| M74RR | Window Motor - Right Rear | A33 | Inside the right rear door, below the window | Right Rear Door (without panel) | M74RR Window Motor - Right Rear |
| M75 | Windshield Wiper Motor | In the left rear of the engine compartment, at the base of the windshield, under the air inlet grille | Left of Engine Compartment Components | M75 Windshield Wiper Motor | |
| M93 | Key Capture Solenoid Actuator | M97 | |||
| M97 | Fuel Door Lock Actuator | N08 | On the right side of the vehicle, just inside the fuel door, towards the rear | M97 Fuel Door Lock Actuator | |
| P2 | Transmission Shift Lever Position Indicator | In the passenger compartment, on the center console, next to the automatic transmission shift lever | P2 Transmission Shift Lever Position Indicator | ||
| P9 | Driver Information Center Display | In the passenger compartment, part of the instrument cluster assembly | P9 Driver Information Center Display | ||
| P12A | Horn | Outside the left front corner of the vehicle, behind the front fascia | Front of Engine Compartment Components | P12A Horn - High Note | |
| P12B | Horn | Outside the left front corner of the vehicle, behind the front fascia | Front of Engine Compartment Components | P12B Horn - Low Note | |
| P16 | Instrument Cluster | In the passenger compartment, on the upper part of the instrument panel, in front of the driver seat | P16 Instrument Cluster | ||
| P17 | Info Display Module | In the passenger compartment, on the upper part of the instrument panel, in middle of instrument panel | P17 INFO DISPLAY MODULE | ||
| P19AC | Speaker - Subwoofer | In the passenger compartment, At rear of vehicle. Right rear of trunk. | |||
| P19AG | Speaker - Left Front Door | In the passenger compartment, at the lower front of the left front door | Driver Door Components (without panel) | P19AG Speaker - Left Front Door | |
| P19AH | Speaker - Right Front Door | In the passenger compartment, at the lower front of the right front door | Passenger Door Components (with panel) | P19AH Speaker - Right Front Door | |
| P19AL | Speaker - Left Rear Door | In the passenger compartment, at the lower front of the left rear door | Left Rear Door (without panel) | P19AL Speaker - Left Rear Door | |
| P19AM | Speaker - Right Rear Door | In the passenger compartment, at the lower front of the right rear door | Right Rear Door (without panel) | P19AM Speaker - Right Rear Door | |
| P19H | Speaker - Left Front Tweeter | In the passenger compartment, at the base of the left windshield side garnish molding | P19H Speaker - Left Front Tweeter | ||
| P19V | Speaker - Right Front Tweeter | In the passenger compartment, at the base of the right windshield side garnish molding | P19V Speaker - Right Front Tweeter | ||
| P34D | Side Object Detection Indicator - Driver | UFT | |||
| P34P | Side Object Detection Indicator - Passenger | UFT | |||
| Q2 | A/C Compressor Clutch | C60 | In the engine compartment, on the lower right front of the engine, part of the A/C compressor | Q2 A/C Compressor Clutch | |
| Q5 | Brake Pressure Modulator | Part of the Electronic Brake Control Module | |||
| Q6E | Camshaft Position Actuator Solenoid Valve - Exhaust | In the engine compartment, on the upper, right front of the engine | Q6E Camshaft Position Actuator Solenoid Valve - Exhaust | ||
| Q6F | Camshaft Position Actuator Solenoid Valve - Intake | In the engine compartment, on the upper, right rear of the engine | Q6F Camshaft Position Actuator Solenoid Valve - Intake | ||
| Q8 | Control Solenoid Valve Assembly | In the engine compartment, inside the automatic transmission assembly | |||
| Q12 | Evaporative Emission Purge Solenoid Valve | In the engine compartment, towards the rear of the engine, on top of the intake manifold, near the fuel rail | Q12 Evaporative Emission Purge Solenoid Valve | ||
| Q13 | Evaporative Emission Purge Solenoid Valve | LUV | In the engine compartment, towards the rear of the engine | Q12 Evaporative Emission Purge Solenoid Valve | |
| Q17A | Fuel Injector 1 | In the engine compartment, top right of the engine, above cylinder 1 | Q17A Fuel Injector 1 | ||
| Q17B | Fuel Injector 2 | In the engine compartment, top center of the engine, above cylinder 2 | Q17B Fuel Injector 2 | ||
| Q17C | Fuel Injector 3 | In the engine compartment, top center of the engine, above cylinder 3 | Q17C Fuel Injector 3 | ||
| Q17D | Fuel Injector 4 | In the engine compartment, top left of the engine, above cylinder 4 | Q17D Fuel Injector 4 | ||
| Q23 | Line Pressure Control Solenoid Valve | MH8 or MHB | Inside the Automatic Transmission assembly | ||
| Q27B | Pressure Control Solenoid Valve 2 | Inside Automatic Transmission Assembly | |||
| Q27C | Pressure Control Solenoid Valve 3 | Inside Automatic Transmission Assembly | |||
| Q27D | Pressure Control Solenoid Valve 4 | Inside Automatic Transmission Assembly | |||
| Q27E | Pressure Control Solenoid Valve 5 | Inside Automatic Transmission Assembly | |||
| Q28 | Rear Drive Clutch | F46 | Under rear of Vehicle, Inside Rear axle Housing | ||
| Q32A | Shift Solenoid Valve 1 | Inside Automatic Transmission Assembly | |||
| Q38 | Throttle Body | In the engine compartment, on the right rear of the engine, on the intake manifold | Q38 Throttle Body | ||
| Q39A | Torque Converter Clutch Pressure Control Solenoid Valve | Inside Automatic Transmission Assembly | |||
| Q40 | Turbocharger Bypass Solenoid Valve | LUJ | In the engine compartment on the intake tube coming out to the Turbo | Q40 Turbocharger Bypass Solenoid Valve | |
| Q42 | Turbocharger Wastegate Solenoid Valve | LUJ | In the engine compartment, at the upper right front of engine | Q42 Turbocharger Wastegate Solenoid Valve | |
| Q49 | Rear Differential Clutch Solenoid Valve | F46 | Under Vehicle, above rear axle | ||
| R10 | Cooling Fan Resistor | In the passenger compartment, behind the lower left side of the instrument panel | R10 Cooling Fan Resistor (LUJ/LUV) | ||
| S2 | Transmission Manual Shift Switch | In the passenger compartment, at the front of the center console. inside Transmission Shift Lever. | |||
| S3 | Transmission Shift Lever | In the passenger compartment, at the front of the center console | S3 Transmission Shift Lever | ||
| S13D | Door Lock Switch - Driver | In the passenger compartment, on the driver door. | Driver Door Components (with panel) | S13D Door Lock Switch - Driver | |
| S13P | Door Lock Switch - Passenger | In the passenger compartment, on the passenger door. | Passenger Door Components (with panel) | S13P Door Lock Switch - Passenger | |
| S30 | Headlamp Switch | In the passenger compartment, on the left side of the instrument panel, between the steering column, and the driver door | S30 Headlamp Switch | ||
| S33 | Horn Switch | In the passenger compartment, on the center of the steering wheel | S33 Horn Switch | ||
| S39 | Ignition Switch | In the passenger compartment, on the right side of the steering column | Steering Column Components | S39 Ignition Switch | |
| S46B | Liftgate Unlatch Switch | Outside the rear of the vehicle, on the center of the liftgate, between the license plate lamps | Liftgate Components | S46B Liftgate Unlatch Switch | |
| S47D | Seat Memory Switch - Driver | AAG | In the passenger compartment, in the driver side seat | ||
| S48C | Multifunction Switch 1 - Instrument Panel | In the passenger compartment, at the bottom of the center stack | |||
| S48D | Multifunction Switch 2 - Instrument Panel | UD5/UFL | In the passenger compartment, at the bottom of the center stack | Front of Instrument Panel (AT) | |
| S51 | Telematics Button Assembly | UE1 | In the passenger compartment, In Rear View mirror. | ||
| S52 | Outside Rearview Mirror Switch | In the passenger compartment, on the front of the driver door arm rest, in front of the window switch | Driver Door Components (with panel) | S52 Outside Rearview Mirror Switch | |
| S64D | Seat Adjuster Switch - Driver | In the passenger compartment, On side of the driver seat | S64D Seat Adjuster Switch - Driver | ||
| S64P | Seat Adjuster Switch - Passenger | In the passenger compartment, On side of the passenger seat | |||
| S65D | Seat Lumbar Support Switch - Driver | In the passenger compartment, On side of the driver seat | S65D Seat Lumbar Support Switch - Driver | ||
| S65P | Seat Lumbar Support Switch - Passegner | In the passenger compartment, On side of the passenger seat | |||
| S70L | Steering Wheel Controls Switch - Left | In the passenger compartment, on the steering wheel, on the left side | |||
| S70R | Steering Wheel Controls Switch - Right | In the passenger compartment, on the front of the steering wheel, right of center | |||
| S72 | Sunroof Switch | CF5 | In the passenger compartment, in the front center of the headliner, in the dome lamp bezel | S72 Sunroof Switch | |
| S78 | S78 Turn Signal / Multifunction Switch | In the passenger compartment, mounted to the left side of the steering column | Steering Column Components | S78 Turn Signal/Multifunction Switch | |
| S79D | Window Switch - Driver | In the passenger compartment, on the driver door arm rest | Driver Door Components (with panel) | S79D Window Switch - Driver (A55+A33) | |
| S79LR | Window Switch - Left Rear | In the passenger compartment, on the left rear door arm rest | Left Rear Door (with panel) | S79LR Window Switch - Left Rear | |
| S79P | Window Switch - Passenger | In the passenger compartment, on the passenger door arm rest | Passenger Door Components (with panel) | S79P WINDOW SWITCH - PASSENGER (A66) | |
| S79RR | Window Switch - Right Rear | In the passenger compartment, on the right rear door arm rest | Right Rear Door (with panel) | S79RR Window Switch - Right Rear | |
| S82 | Windshield Wiper/Washer Switch | In the passenger compartment, on steering column. On the right side. | S88 Sunroof Tilt Switch | ||
| S88 | Sunroof Tilt Switch | CF5 | In the passenger compartment, in the headliner just above the rearview mirror | S88 Sunroof Tilt Switch | |
| T3 | Audio Amplifier | Inside passenger compartment. In rear of vehicle. By rear wheel well. | T3 Audio Amplifier X1 T3 Audio Amplifier X2 T3 Audio Amplifier X3 | ||
| T4G | Cellular Phone, Navigation, and Digital Radio Antenna | UE1 | |||
| T4M | Radio Antenna | Outside the vehicle, at the center, rear of the roof | |||
| T4S | Wireless Communication Antenna - Bluetooth | UE1 | In side of Passenger compartment, part of the Telematics Communication Interface Control Module | ||
| T6 | Power Inverter Module | KI6 | Left Side of Passenger Compartment Components (2 of 2) | T6 Power Inverter Module | |
| T12 | Automotic Transmission Assembly | In the engine compartment, mounted to the left side of the engine | T12 Automatic Transmission Assembly X1 | ||
| X50A | Fuse Block - Underhood | In the left front corner of the engine compartment, left of the battery | Left of Engine Compartment Components | X50A FUSE BLOCK - UNDERHOOD X1 (BUICK, NORTH AMERICA) X50A FUSE BLOCK - UNDERHOOD X2 (BUICK, NORTH AMERICA) X50A FUSE BLOCK - UNDERHOOD X3 (BUICK, NORTH AMERICA) | |
| X50D | Fuse Block - Battery | In the engine compartment, on top of the battery | Left of Engine Compartment Components | X50D Fuse Block - Battery X1 X50D Fuse Block - Battery X3 X50D Fuse Block - Battery X5 | |
| X51A | Fuse Block - Instrument Panel | In the passenger compartment, under the left side of the instrument panel | Rear of Instrument Panel Components (1 of 2) | ||
| X53A | Fuse Block - Rear Body | In the passenger compartment, In the rear of the vehicle. | Left Side of Passenger Compartment Components (2 of 2) | X53A Fuse Block - Rear Body, Wire Entry | |
| X70A | Relay Block - Underhood | In the engine compartment. Near the battery. | X70A Relay Block - Underhood, Wire Entry | ||
| X81 | Accessory Power Receptacle - 110V AC | Accessory Power Receptacle - 110V AC | In the passenger compartment, in the center console. | ||
| X83 | Auxiliary Audio Input | In the passenger compartment, on the passenger side of the instrument panel, inside the upper storage compartment, on the left side | |||
| X84 | Data Link Connector | In the passenger compartment, under the driver side of the instrument panel | Rear of Instrument Panel Components (1 of 2) | X84 Data Link Connector | |
| X85 | Steering Wheel Air Bag Coil | In the passenger compartment, on the steering column, under the steering wheel | Steering Column Components | X85 Steering Wheel Air Bag Coil X1 X85 Steering Wheel Air Bag Coil X2 X85 Steering Wheel Air Bag Coil X3 | |
| X105 | Forward Lamp Harness to Ambient Temperature Sensor Jumper Harness (2 cavities) | Outside the vehicle, behind the font fascia, near the ambient temperature sensor | Forward Lamp Harness Routing - Outside | X105 FORWARD LAMP HARNESS TO BODY HARNESS | |
| X112 | Body Harness to Engine Harness | In engine compartment Left side of engine | ENGINE HARNESS ROUTING (LUJ) | X112 Engine Harness To Body Harness | |
| X123 | Forward Lamp Harness to front fascia harness | In the engine compartment, Near the front fascia | Forward Lamp Harness Routing - Outside | X123 Front Fascia Harness To Forward Lamp Harness | |
| X200 | Body Harness to Instrument Panel Harness (18 cavities) | In the right front of the passenger compartment, below the instrument panel, behind the passenger kick panel | INSTRUMENT PANEL HARNESS ROUTING | X200 Body Harness To Instrument Panel Harness (Left) | |
| X202 | Body Harness to Instrument Panel Harness (58 cavities) | In the left front of the passenger compartment, below the instrument panel, behind the passenger kick panel | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | X202 Body Harness To Instrument Panel Harness (Right) | |
| X207 | Instrument Panel Harness to Passenger Air Bag Jumper Harness (5 cavities) | Behind the passenger side of the instrument panel, near the passenger air bag | |||
| X231 | Body Harness to Center Console Harness | KI6 | In the passenger compartment, between Instrument panel and center console | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | X231 Body Harness To Center Console Harness |
| X301 | Body Harness to Driver Seat Harness (20 cavities) | In the passenger compartment, under the front of the driver seat | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | X301 Body Harness To Driver Seat Harness | |
| X302 | Body Harness to Passenger Seat Harness (20 cavities) | In the passenger compartment, under the front of the passenger seat | INSTRUMENT PANEL HARNESS ROUTING | X302 Body Harness To Passenger Seat Harness | |
| X350 | Body Harness | Inside passenger compartment, at rear of vehicle Near right rear strut tower. | INSTRUMENT PANEL HARNESS ROUTING | X350 Body Harness To Fuel Tank Harness | |
| X400 | Body Harness | Inside passenger compartment, at rear of vehicle Near right rear strut tower. | INSTRUMENT PANEL HARNESS ROUTING | X400 Rear Fascia Harness To Body Harness (Right) | |
| X405 | Left Tail Lamp Harness to Body Harness (6 cavities) | Inside the left rear corner of the rear compartment | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | BODY HARNESS ROUTING - LEFT REAR OF PASSENGER COMPARTMENT | |
| X406 | Right Tail Lamp Harness to Body Harness (6 cavities) | Inside the right rear corner of the rear compartment | INSTRUMENT PANEL HARNESS ROUTING | BODY HARNESS ROUTING - RIGHT REAR OF PASSENGER COMPARTMENT | |
| X409 | Body Harness to All Wheel Drive Harness | F46 | Under vehicle at rear axle. | Rear Differential Harness Routing | X409 Body Harness To All Wheel Drive Harness |
| X500 | Driver Door Harness to Body Harness (30 cavities) | At the front of the driver door, between the door and the body | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | X500 Driver Door Harness To Body Harness | |
| X600 | Passenger Door Harness to Body Harness (30 cavities) | At the front of the passenger door, between the door and the body | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | X600 Passenger Door Harness To Body Harness | |
| X700 | Left Rear Door Harness to Body Harness (18 cavities) | At the front of the left rear door, between the door and the body | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | X700 Left Rear Door Harness To Body Harness | |
| X800 | Right Rear Door Harness to Body Harness (18 cavities) | At the front of the right rear door, between the door and the body | Right Rear Door Harness Routing | X800 Right Rear Door Harness To Body Harness | |
| X900 | Body Harness to Liftgate Harness | In the upper, left rear corner of the luggage compartment | Headliner Harness Routing (Without Sunroof) | X900 Liftgate Harness To Body Harness | |
| X901 | Body Harness to Liftgate Harness | In the liftgate, left of center, behind the liftgate trim | X901 Liftgate Harness To Liftgate Extension Harness | ||
| X902 | Liftgate Extension Harness to License Lamp Harness | On the inside of the Liftgate, on the left side | X902 Liftgate Extension Harness To License Lamp Harness | ||
| G100 | Forward Lamp Harness | In the engine compartment, on the left side, on the frame rail | G100 | ||
| G101 | Forward Lamp Harness | In the engine compartment, on the right side, on the frame rail | G101 | ||
| G102 | Body Harness | In the left side of the engine compartment, on the inner fender well | G102 | ||
| G103 | Engine Harness | In the left front of the engine compartment, below the battery | G103 | ||
| G104 | Engine Harness | In the left front of the engine compartment, below the battery | G104 (LFF Engine) | ||
| G105 | Engine Harness | In the left side of the engine compartment, on the frame rail, behind X101 | |||
| G106 | Engine Harness | ||||
| G107 | Engine Harness | In the left front of the engine compartment, below the battery | |||
| G200 | HVAC Harness | C32 | In the passenger compartment, behind the instrument panel | G200, G301, and G302 | |
| G201 | Body Harness | In the left front of the passenger compartment, under the instrument panel, behind the driver kick panel, just above the base of the left A-pillar | G201, G203, G303, and G305 | ||
| G202 | HVAC Harness | In the passenger compartment, behind the instrument panel | G103 | ||
| G203 | HVAC Harness | In the passenger compartment, behind the instrument panel | G201, G203, G303, and G305 | ||
| G301 | Instrument Panel Harness | In the passenger compartment, under the center console, near G300 and G302 | G200, G301, and G302 | ||
| G302 | Instrument Panel Harness | In the passenger compartment, under the center console, near G300 and G301 | G200, G301, and G302 | ||
| G303 | Body Harness | In the left front of the passenger compartment, at the base of the left A-pillar | G201, G203, G303, and G305 | ||
| G304 | Body Harness | In the right front of the passenger compartment, near the base of the right A-pillar | G304 | ||
| G305 | Body Harness | NJ1 | In the left front of the passenger compartment, at the base of the left A-pillar, above G303 | G201, G203, G303, and G305 | |
| G401 | Body Harness | In the right of the luggage compartment, on top of the right rear wheel well | G401 | ||
| G402 | Body Harness | ||||
| G404 | Body Harness | In the left of the luggage compartmen, on top of the left rear wheel well | G402 and G404 | ||
| J101 | Engine Harness | LUJ | In engine compartment Below K20 Engine Control Module | ENGINE HARNESS ROUTING - RIGHT FRONT (LFF) | |
| J102 | Engine Harness | LFF | In engine compartment on top of the engine near the ignition coils | ||
| J103 | Engine Harness | LFF | In engine compartment on top of the engine near the ignition coils | ||
| J111 | Engine Harness | In engine compartment | |||
| J114 | Body Harness | In the left rear of the engine compartment, approximately 14.5 cm (5.71 in) left of the breakout to the brake fluid level switch | Headliner Harness Routing (With Sunroof) | ||
| J117 | Engine Harness | ||||
| J118 | Engine Harness | On the rear left side of the engine, approximately 4.5 cm (1.77 in) into the breakout leading to the engine control module connectors | Rear Differential Harness Routing | ||
| J124 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp | |||
| J125 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp | |||
| J126 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp. By X100 | |||
| J129 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp | |||
| J137 | Body Harness | Left front fender. Under brake booster. | ENGINE HARNESS ROUTING (LUJ) | ||
| J138 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp. By X100 | |||
| J140 | Body Harness | In the left rear of the engine compartment, approximately 4.5 cm (1.77 in) left of J114 | Headliner Harness Routing (With Sunroof) | ||
| J142 | Body Harness | In the left side of the engine compartment, Under brake booster | Headliner Harness Routing (With Sunroof) | ||
| J165 | Front Facia | Below left Headlamp above bumper | License Lamp Harness Routing | ||
| J166 | Front Facia | Below left Headlamp above bumper | License Lamp Harness Routing | ||
| J175 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp. By X100 | |||
| J201 | Body Harness | On left side of passenger compartment under dash. Under kick panel | Headliner Harness Routing (Without Sunroof) | ||
| J202 | Instrument Panel Harness | On left side of passenger compartment under dash. Under kick panel | |||
| J203 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J207 | Instrument Panel Harness | In center of passenger compartment Near K33 HVAC | |||
| J211 | Instrument Panel Harness | In center of passenger compartment Near A11 Radio X1 | |||
| J212 | Instrument Panel Harness | On left side of passenger compartment Near S30 Headlamp Switch | |||
| J213 | Instrument Panel Harness | In center of passenger compartment Near K33 HVAC | |||
| J214 | Instrument Panel Harness | In center of passenger compartment Near K33 HVAC | Headliner Harness Routing (Without Sunroof) | ||
| J215 | Instrument Panel Harness | In center of passenger compartment Near K33 HVAC | |||
| J216 | Instrument Panel Harness | On left side of passenger compartment under dash. | |||
| J223 | Body Harness | Under dash on left side. | Headliner Harness Routing (Without Sunroof) | ||
| J225 | Body Harness | On the left side of the instrument panel, under kick panel | Headliner Harness Routing (Without Sunroof) | ||
| J226 | Body Harness | On the left side of the instrument panel, approximately 10.5 cm (4.13 cm) below the breakout to the X114 | Headliner Harness Routing (Without Sunroof) | ||
| J227 | Instrument Panel Harness | In center of passenger compartment behind dash. Close to A5 Driver Information Center | |||
| J228 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J229 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J230 | Body Harness | On the left side of the instrument panel, under kick panel | Headliner Harness Routing (Without Sunroof) | ||
| J231 | Body Harness | On the right side of the passenger compartment Under kick panel Close to brake out for G304 | Headliner Harness Routing (Without Sunroof) | ||
| J232 | Body Harness | On the right side of the passenger compartment Under kick panel Close to brake out for G304 | Headliner Harness Routing (Without Sunroof) | ||
| J233 | Body Harness | On the right side of the passenger compartment Under kick panel | Headliner Harness Routing (Without Sunroof) | ||
| J247 | Instrument Panel Harness | On left side of passenger compartment under dash. Near breakout for the steering column. | |||
| J249 | Instrument Panel Harness | On Center side of passenger compartment under dash. | |||
| J255 | Instrument Panel Harness | On Right side of passenger compartment under dash. | |||
| J256 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J260 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J267 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J281 | Instrument Panel Harness | UE1 | Instrument Panel Harness Routing | ||
| J282 | Instrument Panel Harness | UE1 | |||
| J290 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J291 | Body Harness | Body Harness Routing - Right Front of Passenger Compartment | |||
| J313 | Body Harness | In the passenger compartment, On left side in the rear behind C pillar panel | Headliner Harness Routing (Without Sunroof) | ||
| J314 | Body Harness | On the left side of the passenger compartment, Under left front seat | INSTRUMENT PANEL HARNESS ROUTING | ||
| J317 | Body Harness | Body Harness Routing - Center of Passenger Compartment | |||
| J318 | Body Harness | On the right side of the passenger compartment, Under right front seat | INSTRUMENT PANEL HARNESS ROUTING | ||
| J321 | Body Harness | In the passenger compartment, under the center console. At the rear of center console | Headliner Harness Routing (Without Sunroof) | ||
| J325 | Headliner Harness | Headliner Harness Routing (Without Sunroof) Headliner Harness Routing (With Sunroof) | |||
| J326 | Body Harness | In the passenger compartment, under the left front seat. | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | ||
| J327 | Body Harness | In the passenger compartment, under the left front seat. | |||
| J328 | Body Harness | In the passenger compartment, under the Left seat | Headliner Harness Routing (Without Sunroof) | ||
| J329 | Body Harness | In the passenger compartment, Under right front seat | Headliner Harness Routing (Without Sunroof) | ||
| J330 | Body Harness | Body Harness Routing - Left Front of Passenger Compartment | |||
| J331 | Body Harness | Body Harness Routing - Left Front of Passenger Compartment | |||
| J333 | Body Harness | Body Harness Routing - Right Front of Passenger Compartment | |||
| J334 | Body Harness | On the right side of the passenger compartment, Rear of vehicle near taillight. | Headliner Harness Routing (Without Sunroof) | ||
| J335 | Body Harness | On the right side of the passenger compartment, Back by the X53A Fuse block rear body. | |||
| J336 | Body Harness | Body Harness Routing - Left Rear of Passenger Compartment | |||
| J339 | Body Harness | On the left side of the passenger compartment, Behind Dash on A piller | Headliner Harness Routing (Without Sunroof) | ||
| J345 | Body Harness | On the left side of the passenger compartment, Under Rear door trim. | Headliner Harness Routing (Without Sunroof) | ||
| J346 | Body Harness | On the left side of the passenger compartment, In rear of vehicle close to strut tower | Headliner Harness Routing (Without Sunroof) | ||
| J347 | Body Harness | Body Harness Routing - Right Front of Passenger Compartment | |||
| J348 | Headliner Harness | Headliner Harness Routing (With Sunroof) | |||
| J349 | Driver Seat Harness | Body Harness Routing - Left Front of Passenger Compartment | |||
| J353 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J355 | Body Harness | On the left side of the passenger compartment, Near breakout for X200. | |||
| J362 | Body Harness | On the left side of the passenger compartment, In rear of vehicle | |||
| J387 | Body Harness | Body Harness Routing - Right Rear of Passenger Compartment | |||
| J400 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J401 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J405 | Body Harness | On the left side of the passenger compartment, In rear of vehicle top of c piller | Headliner Harness Routing (Without Sunroof) | ||
| J411 | Body Harness | On the left side of the passenger compartment, In rear of vehicle close to the top of c piller | Headliner Harness Routing (Without Sunroof) | ||
| J412 | Body Harness | On the left side of the passenger compartment, In rear of vehicle close to the top of c piller | Headliner Harness Routing (Without Sunroof) | ||
| J421 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J422 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J423 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J424 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J446 | Body Harness | Body Harness Routing - Left Rear of Passenger Compartment | |||
| J450 | Body Harness | Body Harness Routing - Left Rear of Passenger Compartment | |||
| J504 | Driver Door | Behind the driver door trim panel after breakout for outside mirror. | |||
| J505 | Driver Door | Driver Door Harness Routing | |||
| J506 | Driver Door | Behind the driver door trim panel after breakout for outside mirror. | |||
| J507 | Driver Door | Behind the driver door trim panel after breakout for outside mirror. | |||
| J601 | Driver Door | Behind the Passenger door trim panel, approximately 8 cm into the breakout to the window switch | |||
| J605 | Passenger Door Harness | Passenger Door Harness Routing | |||
| J606 | Driver Door | Behind the Passenger door trim panel Close the the breakout for the outside Rearview Mirror - Passenger | |||
| J702 | Driver Door | Behind the left rear door trim panel, approximately 8 cm into the breakout to the window switch | |||
| J801 | Driver Door | Behind the right rear door trim panel, approximately 8 cm into the breakout to the window switch | |||
| J900 | Liftgate | Inside the liftgate, approximately 4 cm (1.57 in) left of the breakout to X901 | |||
| J902 | License Plate Lamp | On the outside of the liftgate, under the license lamp trim cover, approximately 24 cm (9.45 in) from the right license plate lamp | |||
| J903 | License Plate Lamp | On the outside of the liftgate, under the license lamp trim cover, approximately 29 cm (11.4 in) from the right license plate lamp | |||
| J905 | Liftgate | Inside the liftgate. Close the to the breakout for the M30 Liftgate Latch. | |||
| J990 | Liftgate Harness | Liftgate Harness Routing | |||
| J991 | Liftgate Harness | Liftgate Harness Routing | |||
| JX203 | Instrument Panel Harness | Behind the instrument panel, near breakout to A11 radio X1 connector | |||
| JX404 | Body Harness | On the left side of luggage compartment, near breakout to X53A fuse block |
Master Electrical Component List (Encore)
Master Electrical Component List (Trax)
| Code | Name | Option | Location | Locator View | Connector End View |
|---|---|---|---|---|---|
| A3L | Sunshade - Left | D6I | In the passenger compartment, at the top left of the windshield | A3L SUNSHADE - LEFT | |
| A3R | Sunshade - Right | D6I | In the passenger compartment, at the top right of the windshield | A3R SUNSHADE - RIGHT | |
| A7 | Fuel Pump and Level Sensor Assembly | Underneath the vehicle, inside the fuel tank | Fuel Tank Components | A7 FUEL PUMP AND LEVEL SENSOR ASSEMBLY | |
| A9A | Outside Rearview Mirror - Driver | Outside the vehicle, at the front of the driver door | A9A OUTSIDE REARVIEW MIRROR - DRIVER | ||
| A9B | Outside Rearview Mirror - Passenger | Outside the vehicle, at the front of the passenger door | A9B OUTSIDE REARVIEW MIRROR - PASSENGER | ||
| A10 | Inside Rearview Mirror | DD8/UE1 | Inside passenger compartment. On windshield close to the top in center. | A10 INSIDE REARVIEW MIRROR | |
| A11 | Radio | In the passenger compartment, in the center of the instrument panel | A11 RADIO X1 A11 RADIO X2 | ||
| A23D | Door Latch Assembly - Driver | Inside the driver door, at the rear of the door | A23D DOOR LATCH ASSEMBLY - DRIVER | ||
| A23LR | Door Latch Assembly - Left Rear | Inside the left rear door, at the rear of the door | A23LR DOOR LATCH ASSEMBLY - LEFT REAR | ||
| A23P | Door Latch Assembly - Passenger | Inside the passenger door, at the rear of the door | A23P DOOR LATCH ASSEMBLY - PASSENGER | ||
| A23RR | Door Latch Assembly - Right Rear | Inside the right rear door, at the rear of the door | A23RR DOOR LATCH ASSEMBLY - RIGHT REAR | ||
| B1 | A/C Refrigerant Pressure Sensor | C60 | In the engine compartment, above the A/C compressor, in the air conditioning compressor and condenser hose, on the pressure side | B1 A/C REFRIGERANT PRESSURE SENSOR | |
| B5LF | Wheel Speed Sensor - Left Front | Outside the vehicle, in the left front steering knuckle | Wheel Components | B5LF WHEEL SPEED SENSOR - LEFT FRONT | |
| B5LR | Wheel Speed Sensor - Left Rear | Outside the vehicle, in the left rear drum brake spacer | Wheel Components | B5LR WHEEL SPEED SENSOR - LEFT REAR | |
| B5RF | Wheel Speed Sensor - Right Front | Outside the vehicle, in the right front steering knuckle | Wheel Components | B5RF WHEEL SPEED SENSOR - RIGHT FRONT | |
| B5RR | Wheel Speed Sensor - Right Rear | Outside the vehicle, in the right rear drum brake spacer | Wheel Components | B5RR WHEEL SPEED SENSOR - RIGHT REAR | |
| B9 | Ambient Air Temperature Sensor | Outside the vehicle, behind the lower grille insert, on the passenger side | Front of Vehicle Components | B9 AMBIENT AIR TEMPERATURE SENSOR | |
| B10B | Ambient Light / Sunload Sensor | In Passenger Compartment. On top Do Instrument Panel. | B10 AMBIENT LIGHT SENSOR | ||
| B12A | Transmission Fluid Pressure Switch | MH8 or MHB | In Transmission | ||
| B13 | Transmission Fluid Temperature Sensor | MH8 or MHB | In Transmission | ||
| B14A | Transmission Output Shaft Speed Sensor | MH8 or MHB | In the engine compartment, internal to the automatic transmission assembly | COMPONENT LOCATION | B14A TRANSMISSION OUTPUT SHAFT SPEED SENSOR |
| B14C | Transmission Input Shaft Speed Sensor | MH8 or MHB | In the engine compartment, internal to the automatic transmission assembly | COMPONENT LOCATION | B14C TRANSMISSION INPUT SHAFT SPEED SENSOR (MH8 OR MHB) |
| B15 | Transmission Internal Mode Switch | MH8 or MHB | In the engine compartment, internal to the automatic transmission assembly | COMPONENT LOCATION | B15 TRANSMISSION INTERNAL MODE SWITCH |
| B16 | Backup Lamp Switch | M4P or MR5 | In the engine compartment, on the front of the transmission | B16 BACKUP LAMP SWITCH | |
| B18 | Battery Current Sensor | In the left front of the engine compartment, in front of the battery, on the negative battery cable | B18 BATTERY CURRENT SENSOR | ||
| B19B | Brake Booster Vacuum Sensor | In the rear of the engine compartment, drivers side, on the brake booster | Left of Engine Compartment Components | B19B BRAKE BOOSTER VACUUM SENSOR | |
| B19C | Brake Booster Vacuum Switch | J41 | At the rear of the engine compartment, driver's side, on the brake booster | B19C BRAKE BOOSTER VACUUM SWITCH (J41) | |
| B20 | Brake Fluid Level Switch | At the rear of the engine compartment, driver's side, on the brake master cylinder | Left of Engine Compartment Components | B20 BRAKE FLUID LEVEL SWITCH | |
| B22 | Brake Pedal Position Sensor | In the passenger compartment, under the driver side of the instrument panel, above the brake pedal | B22 BRAKE PEDAL POSITION SENSOR (MH8/MHB) B22 BRAKE PEDAL POSITION SENSOR (M4P/MR5) | ||
| B23E | Camshaft Position Sensor - Exhaust | In the engine compartment, on the upper right front corner of the cylinder head | B23E CAMSHAFT POSITION SENSOR - EXHAUST | ||
| B23F | Camshaft Position Sensor - Intake | In the engine compartment, on the upper right rear corner of the cylinder head | B23F CAMSHAFT POSITION SENSOR - INTAKE | ||
| B24 | Cellular Phone Microphone | In the front of the passenger compartment, in the center, behind the dome lamp bezel | B24 CELLULAR PHONE MICROPHONE | ||
| B25 | Clutch Pedal Position Switch | M4P | In the passenger compartment, under the driver side of the instrument panel, above the clutch pedal | B25B Clutch Pedal Position Sensor (MR5) | |
| B25B | Clutch Pedal Position Sensor | MR5 | B25B Clutch Pedal Position Sensor (MR5) | ||
| B26 | Crankshaft Position Sensor | In the engine compartment, on the lower left side of the engine, below the starter | B26 Crankshaft Position Sensor | ||
| B34 | Engine Coolant Temperature Sensor | Left Front of Engine Components (LUJ/LUV) | B34 Engine Coolant Temperature Sensor | ||
| B37 | Engine Oil Pressure Switch | In the engine compartment, on the left side of the engine | B37 Engine Oil Pressure Switch | ||
| B39 | A/C Evaporator Temperature Sensor | C60 | In the passenger compartment, in the HVAC assembly, on the left side, near the evaporator | B39 A/C Evaporator Temperature Sensor (C60) | |
| B46A | Fuel Level Sensor - Primary | Underneath the vehicle, inside the fuel tank, internal to A7 Fuel Pump and Level Sensor Assembly | |||
| B46B | Fuel Level Sensor - Secondary | F46 | Under the vehicle, inside the fuel tank, part of the fuel pump and level sensor assembly | Fuel Tank Components | B46B Fuel Level Sensor - Secondary (F46) |
| B47 | B47 Fuel Pressure Sensor | FHA | In the engine compartment, on top of the engine towards the right rear, at the end of the fuel rail | B47 Fuel Pressure Sensor | |
| B52A | Heated Oxygen Sensor 1 | In the engine compartment, in front of the engine, in the exhaust manifold | Left Front of Engine Components (LUJ/LUV) | B52A Heated Oxygen Sensor 1 | |
| B52B | Heated Oxygen Sensor 2 | In the engine compartment, behind the engine, in the exhaust pipe | B52B Heated Oxygen Sensor 2 | ||
| B55 | Hood Ajar Switch | BTV/UTJ | In the front of the engine compartment, by the hood latch assembly | Front of Engine Compartment Components | B55 Hood Ajar Switch (UTJ) |
| B59 | Front Impact Sensor | AYC/ADL | In the front of the engine compartment, in the center, above the radiator | Front of Engine Compartment Components | B59 Front Impact Sensor (AYC or ADL) |
| B59L | Front Impact Sensor - Left | AY0/AYF | In the front of the engine compartment, in the center, above the radiator | ||
| B59R | Front Impact Sensor - Right | AY0/AYF | In the front of the engine compartment, in the center, above the radiator | ||
| B60 | Passenger Presence Sensor | In the passenger compartment, under the passenger seat | B60 Passenger Presence Sensor | ||
| B63L | Side Impact Sensor - Left | AYC/ADL | In the passenger compartment, at the bottom of the left B-pillar, behind the trim panel | Front of Vehicle Components | B63L Side Impact Sensor - Left (AYC or ADL) |
| B63LF | Side Impact Sensor - Left Front | AY0/AYF | In the passenger compartment, In Left front door. Close to where wires for left front door enter door. | B63LF Side Impact Sensor - Left Front (AY0 or AYF) | |
| B63LR | Side Impact Sensor - Left Rear | AY0/AYF | In the passenger compartment, at the bottom of the left C-pillar, behind the trim panel | ||
| B63R | Side Impact Sensor - Right | AYC/ADL | In the passenger compartment, at the bottom of the right B-pillar, behind the trim panel | Front of Vehicle Components | B63R Side Impact Sensor - Right (AYC or ADL) |
| B63RF | Side Impact Sensor - Right Front | AY0/AYF | In the passenger compartment, In right front door. Close to where wires for right front door enter door. | B63RF Side Impact Sensor - Right Front (AY0 or AYF) | |
| B63RR | Side Impact Sensor - Right Rear | AY0/AYF | In the passenger compartment, at the bottom of the right C-pillar, behind the trim panel | ||
| B68 | Knock Sensor | In the engine compartment, on the back of the engine block, below the intake manifold | B68 Knock Sensor | ||
| B74 | Mainfold Absolute Pressure Sensor | In the engine compartment, towards the left rear of the engine, on the side of the intake manifold | B74 Manifold Absolute Pressure Sensor | ||
| B75B | Mass Air Flow/Intake Air Temperature Sensor | 2H0 | In the engine compartment, attached to the air intake tube | B75B Mass Air Flow/Intake Air Temperature Sensor (2H0) | |
| B75C | Multifunction Intake Air Sensor | LUV/LUJ | In the engine compartment, attached to the air intake tube | Left Front of Engine Components (LUJ/LUV) | B75C Multifunction Intake Air Sensor (LUV/LUJ) |
| B78E | Rear Object Sensor - Left Middle | UD7 | Outside the rear of the vehicle, behind the rear fascia, left middle position | Rear of Vehicle Components | B78E Rear Object Sensor - Left Middle |
| B78F | Rear Object Sensor - Right Middle | UD7 | Outside the rear of the vehicle, behind the rear fascia, right middle position | Rear of Vehicle Components | B78F Rear Object Sensor - Right Middle |
| B78G | Rear Object Sensor - Left Outer | UD7 | Outside the rear of the vehicle, behind the rear fascia, left outer position | Rear of Vehicle Components | B78G Rear Object Sensor - Left Outer |
| B78H | Rear Object Sensor - Right Outer | UD7 | Outside the rear of the vehicle, behind the rear fascia, right outer position | Rear of Vehicle Components | B78H Rear Object Sensor - Right Outer |
| B80 | Park Brake Switch | In the passenger compartment, under the center console, at the base of the park brake handle | B80 Park Brake Switch | ||
| B81B | Park Position Switch | M97 | Internal to S3 Transmission Shift Lever | ||
| B87 | Rearview Camera | UVC | At rear of vehicle. on Outside of vehicle, above license plate, Between license plate lamp. | Rear of Vehicle Components | B87 Rearview Camera (UVC) |
| B88D | Seat Belt Switch -Driver | In Seat Belt Buckle- Driver | B88D Seat Belt Switch - Driver | ||
| B88P | Seat Belt Switch - Passenger | In Seat Belt Buckle- Passenger | |||
| B99 | Steering Wheel Angle Sensor | Inside the vehicle, on the steering collumn, behind the steering wheel air bag coil | Steering Column Components | B99 Steering Wheel Angle Sensor | |
| B107 | Accelerator Pedal Position Sensor | In the passenger compartment, under the driver side of the instrument panel, above the accelerator pedal | B107 Accelerator Pedal Position Sensor | ||
| B111B | Turbocharger Boost/Intake Air Temperature Sensor | LUV/LUJ | In the engine compartment, In the intake tube before the Throttle Body. | Left Front of Engine Components (LUJ/LUV) | |
| B150 | Fuel Tank Pressure Sensor | LUV/LUJ | Under Car, On the fuel tank harness. Between Fuel tank and bottom of car. | B150 Fuel Tank Pressure Sensor | |
| B153D | Seat Belt Buckle - Driver | In the passenger compartment, between the driver seat and the center console | B153D Seat Belt Buckle - Driver | ||
| B153P | Seat Belt Buckle - Passenger | In the passenger compartment, between the passenger seat and the center console | |||
| B203 | Engine Coolant Radiator Temperature Sensor | In the engine compartment, Near the Radator | |||
| B272 | B272 Child Security Lock Switch | NCG | |||
| C1 | Battery | In the front left corner of the engine compartment | |||
| C3 | Telematics Communication Interface Control Module Battery | UE1 | In passenger compartment, behind dash on passenger side. | ||
| E2LF | Side Marker Lamp - Left Front | Front of Vehicle Components | |||
| E2RF | Side Marker Lamp - Right Front | Front of Vehicle Components | |||
| E2LR | Side Marker Lamp - Left Rear | Inside Tail Lamp Assembly - Left | E2LR Side Marker Lamp - Left Rear | ||
| E2RR | Side Marker Lamp - Right Rear | Inside Tail Lamp Assembly - Right | E2RR Side Marker Lamp - Right Rear | ||
| E4D | Daytime Running Lamp - Right | Inside Headlamp - Right | |||
| E4C | Daytime Running Lamp - Left | Inside Headlamp - Left | |||
| E4E | Headlamp - Left High Beam | Inside Headlamp - Left | E4E Head Lamp - Left High Beam | ||
| E4F | Headlamp - RightHigh Beam | Inside Headlamp - Right | E4F Head Lamp - Right High Beam | ||
| E4G | Headlamp - Left Low Beam | Inside Headlamp - Left | E4G Head Lamp - Left Low Beam | ||
| E4H | Headlamp - Right Low Beam | Inside Headlamp - Right | E4H Head Lamp - Right Low Beam | ||
| E4J | Park Lamp - Left Front | Inside Headlamp - Left | |||
| E4K | Park Lamp - Right Front | Inside Headlamp - Right | |||
| E4LF | Turn Signal Lamp - Left Front | On the vehicle exterior, on the left front corner | |||
| E4LR | Turn Signal Lamp - Left Rear | In the Tail Lamp Assembly - Left | |||
| E4RF | Turn Signal Lamp - Right Front | On the vehicle exterior, on the right front corner | |||
| E4RR | Turn Signal Lamp - Right Rear | In the Tail Lamp Assembly - Right | |||
| E4Y | Turn Signal Repeater Lamp - Left | On the outside of the vehicle, near the rear of the left front fender | Front of Vehicle Components | E4Y Turn Signal Repeater Lamp - Left (T39) | |
| E4Z | Turn Signal Repeater Lamp - Right | On the outside of the vehicle, near the rear of the right front ffender | Front of Vehicle Components | E4Z Turn Signal Repeater Lamp - Right (T39) | |
| E5A | Backup Lamp - Left | In rear of vehicle, In Tail Lamp Assembly - Left | E5A Backup Lamp - Left | ||
| E5B | Backup Lamp - Right | In rear of vehicle, In Tail Lamp Assembly - Right | E5B Backup Lamp - Right | ||
| E5AB | Tail/Stop Lamp - Right | In rear of vehicle, In Tail Lamp Assembly - Right | |||
| E5E | Tail Lamp - Left | At the rear of the vehicle, internal to E42L Tail Lamp Assembly - Left | |||
| E5F | Tail Lamp - Right | At the rear of the vehicle, internal to E42R Tail Lamp Assembly - Right | |||
| E5L | Stop Lamp - Left | In rear of vehicle, In Tail Lamp Assembly - Left | |||
| E5R | Stop Lamp - Right | In rear of vehicle, In Tail Lamp Assembly - Right | |||
| E6 | Center High Mounted Stop Lamp | In the rear of the passenger compartment, at the top of the liftgate glass | Rear of Vehicle Components | E6 Center High Mounted Stop Lamp | |
| E7L | License Plate Lamp - Left | Outside of the liftgate, left of center, above the license plate | Rear of Vehicle Components | E7L License Plate Lamp - Left | |
| E7R | License Plate Lamp - Right | Outside of the liftgate, right of center, above the license plate | Rear of Vehicle Components | E7R License Plate Lamp - Right | |
| E8S | Rear Compartment Courtesy Lamp | In the rear compartment, on the left side | Left Side of Passenger Compartment Components (2 of 2) | E8S Rear Compartment Courtesy Lamp | |
| E13LA | Headlamp Assembly - Left | Outside, left front corner of the vehicle | Front of Vehicle Components | E13LA Headlamp Assembly - Left | |
| E13RA | Headlamp Assembly - Right | Outside, right front corner of the vehicle | Front of Vehicle Components | E13RA Headlamp Assembly - Right | |
| E14B | Seat Heating Element - Driver Cushion | KA1 | In the passenger compartment, under the driver seat cushion cover | E14B Seat Heating Element - Driver Cushion | |
| E14D | Seat Heating Element - Passenger Cushion | KA1 | In the passenger compartment, under the passenger seat cushion cover | E14D Seat Heating Element - Passenger Cushion | |
| E15 | Steering Wheel Heater | KA1 | In the passenger compartment, In steering wheel Column. | ||
| E18 | Rear Defogger Grid | In the passenger compartment, on the inside of the liftgate window | Rear of Vehicle Components | E18 Rear Defogger Grid X1 E18 Rear Defogger Grid X2 | |
| E29LF | Fog Lamp - Left Front | T3U | Outside, left front, lower corner of the vehicle, in the front fascia | Front of Vehicle/Engine Compartment Component Views | E29LF Fog Lamp - Left Front (T3U) |
| E29LR | Fog Lamp - Left Rear | Outside the vehicle, Left rear of Vehicle | Rear of Vehicle Components | E29LR Fog Lamp - Left Rear (VD1) | |
| E29RR | Fog Lamp - Right Rear | Outside the vehicle, Right rear of Vehicle | Rear of Vehicle Components | E29RR Fog Lamp - Right Rear (VD1) | |
| E29RF | Fog Lamp - Right Front | T3U | Outside, right front, lower corner of the vehicle, in the front fascia | Front of Vehicle/Engine Compartment Component Views | E29RF Fog Lamp - Right Front (T3U) |
| E32 | Cigarette Lighter Receptacle | Inside passenger compartment, In center of dash. Below HVAC controls. | E32 Cigarette Lighter Receptacle | ||
| E36AH | Dome Lamp | Inside passenger compartment, In headliner over second row seats. | |||
| E37A | Dome/Reading Lamps | In the passenger compartment, front and center of the headliner, between the sun visors | Left Side of Passenger Compartment Components (2 of 2) | E37A Dome/Reading Lamps | |
| E41 | Engine Coolant Thermostat Heater | In the engine compartment, towards the right front of the engine, in the water outlet assembly | E41 Engine Coolant Thermostat Heater | ||
| E42L | Tail Lamp Assembly - Left | Outside, left rear corner of the vehicle | Rear of Vehicle Components | ||
| E42R | Tail Lamp Assembly - Right | Outside, right rear corner of the vehicle | Rear of Vehicle Components | ||
| F101 | Passenger Instrument Panel Air Bag | In the passenger compartment, in the instrument panel, in front of the passenger seat | |||
| F105L | Roof Rail Air Bag - Left | In the passenger compartment, on the left roof rail, behind the trim panel | Left Side of Passenger Compartment Components (2 of 2) | F105L Roof Rail Air Bag - Left | |
| F105R | Roof Rail Air Bag - Right | In the passenger compartment, on the right roof rail, behind the trim panel | Front of Vehicle Components | F105R Roof Rail Air Bag - Right | |
| F106D | Seat Side Air Bag - Driver | In the passenger compartment, In the Driver Seat | Driver Seat Components (Manual) | ||
| F106P | Seat Side Air Bag - Passenger | In the passenger compartment, In the Passenger Seat | Passenger Seat Components (Manual) | ||
| F106LR | Seat Side Air Bag - Left Rear | In the passenger compartment, In the Left side of the roof over the Left rear door | |||
| F106RR | Seat Side Air Bag - Right Rear | In the passenger compartment, In the Right side of the roof over the right rear door | |||
| F107 | Steering Wheel Air Bag | In the passenger compartment, on the center of the steering wheel | |||
| F112D | Seat Belt Retractor Pretensioner - Driver | In the passenger compartment, at the base of the driver side B-pillar, part of the driver seat belt retractor | Front of Vehicle Components | ||
| F112P | Seat Belt Retractor Pretensioner - Passenger | In the passenger compartment, at the base of the passenger side B-pillar, part of the passenger seat belt retractor | Front of Vehicle Components | ||
| F114D | Knee Airbag - Driver | In the passenger compartment, In passenger area of the dash on the drivers side | |||
| F114P | Knee Airbag - Passenger | In the passenger compartment, In the knee area of the dash on the passenger side. | |||
| F113D | Seat Belt Anchor Pretensioner - Driver | In the passenger compartment, between the center console and the driver seat, at the base of the driver seat belt buckle | |||
| F113P | Seat Belt Anchor Pretensioner - Passenger | In the passenger compartment, between the center console and the passenger seat, at the base of the passenger seat belt buckle | |||
| G10 | Cooling Fan Motor | In the front center of the engine compartment, mounted to the back of the radiator | |||
| G12 | Fuel Pump | Under Vehicle. At rear of vehicle, in fuel tank. | |||
| G13 | Generator | In the engine compartment, on the lower right rear side of the engine | G13 Generator X1 | ||
| G24 | Windshield Washer Pump | Outside the left front corner of the vehicle, behind the front fascia, in the bottom of the washer solvent reservoir | Front of Engine Compartment Components | G24 Windshield Washer Pump | |
| K9 | Body Control Module | In the passenger compartment, behind the left side of the instrument panel | Rear of Instrument Panel Components (2 of 2) | K9 Body Control Module X1 K9 Body Control Module X2 K9 Body Control Module X3 K9 Body Control Module X4 K9 Body Control Module X5 K9 Body Control Module X6 K9 Body Control Module X7 | |
| K17 | Electronic Brake Control Module | At the rear of the engine compartment, driver's side, to the left of the brake master cylinder | Left of Engine Compartment Components | K17 Electronic Brake Control Module | |
| K18 | Compass Module | U80 | |||
| K20 | Engine Control Module | In the left front of the engine compartment, on the right side of the battery | K20 Engine Control Module X1 (LUV/LUJ) K20 Engine Control Module X1 (2H0+F46) K20 Engine Control Module X1 (2H0 Except F46) K20 Engine Control Module X2 (LUV/LUJ) K20 Engine Control Module X2 (2H0+F46) K20 Engine Control Module X2 (2H0 Except F46) K20 Engine Control Module X3 (LUV/LUJ) K20 Engine Control Module X3 (2H0+F46) | ||
| K27 | Fuel Pump Control Module | FHA | K27 Fuel Pump Control Module (FHA) | ||
| K29 | Seat Heating Control Module | KA1 | In the passenger compartment, under the front of the driver seat | K29 Seat Heating Control Module X1 K29 Seat Heating Control Module X2 K29 Seat Heating Control Module X3 | |
| K33 | HVAC Control Module | In the passenger compartment, in the center of the instrument panel, under the radio | Front of Instrument Panel (MT) | K33 HVAC Control Module X1 K33 HVAC Control Module X2 K33 HVAC Control Module X3 | |
| K35 | Ignition Coil Module | In the engine compartment, mounted to the top of the engine | |||
| K36 | Inflatable Restraint Sensing and Diagnostic Module | In the passenger compartment, under the instrument panel, in front of the center console | Rear of Instrument Panel Components (1 of 2) | K36 Inflatable Restraint Sensing And Diagnostic Module X1 K36 Inflatable Restraint Sensing And Diagnostic Module X2 | |
| K41R | K41R Rear Parking Assist Control Module | UD7 | Inside of the passenger compartment. | Front of Vehicle Components | K41R Rear Parking Assist Control Module X1 K41R Rear Parking Assist Control Module X2 |
| K43 | Power Steering Control Module | NJ1 | In the passenger compartment, under the instrument panel, part of the steering column, near the base | Steering Column Components | K43 Power Steering Control Module (NJ1) |
| K47 | Rear Differential Clutch Control Module | F46 | In the rear of the vehicle. Under Vehicle on rear axle | K47 Rear Differential Clutch Control Module X1 (F46) K47 Rear Differential Clutch Control Module X2 (F46) | |
| K61 | Sunroof Control Module | CF5 | In the passenger compartment, above the headliner, at the front of the sunroof | K61 Sunroof Control Module (CF5) | |
| K71 | Transmission Control Module | MH8/MHB | In Side the Automatic Transmission Assembly | ||
| K73 | Telematics Communication Interface Control Module | UE1 | In the passenger compartment, behind the instrument panel, in front of the passenger seat | K73 Telematics Communication Interface Control Module (UE1) | |
| K77 | Remote Control Door Lock Receiver | In the passenger compartment, under the instrument panel center upper molding | Left Side of Passenger Compartment Components (2 of 2) | K77 Remote Control Door Lock Receiver | |
| K85 | Passenger Presence Module | AL0 | Passenger Seat Components (Power) | K85 Passenger Presence Module (AL0) | |
| K89 | Immobilizer Control Module | In the passenger compartment, on the right side of the steering column, around the ignition lock cylinder | Steering Column Components | K89 Immobilizer Control Module | |
| M4 | Air Inlet Door Actuator | In passenger compartment, Behind Dash. On drivers side of vehicle | M4 Air Inlet Door Actuator | ||
| M7 | Transmission Shift Lock Control Solenoid Actuator | MH8/MHB | Inside the Transmission Shift lever | ||
| M8 | Blower Motor | In passenger compartment, Behind Dash. On passenger side of vehicle. | M8 Blower Motor | ||
| M9 | Brake Booster Pump Motor | At the rear of the engine compartment, driver's side, below the master cylinder | |||
| M29L | Headlamp Leveling Actuator - Left | Inside Headlamp - Left | |||
| M29R | Headlamp Leveling Actuator - Right | Inside Headlamp - Right | |||
| M30 | Liftgate Latch | Inside the bottom center of the liftgate | Liftgate Components | M30 Liftgate Latch | |
| M32 | Differential Clutch Pump | F46 | |||
| M38 | Power Steering Motor | NJ1 | |||
| M45 | Rear Wiper Motor | Inside the center of the liftgate, at the bottom of the liftgate glass | Liftgate Components | M45 Rear Wiper Motor | |
| M50D | Seat Front Vertical Motor - Driver | Inside passenger compartment. In front driver seat | |||
| M50P | Seat Front Vertical Motor - Passegner | Inside passenger compartment. In front passenger seat | |||
| M51D | Seat Horizontal Motor - Driver | Inside passenger compartment. In front driver seat | |||
| M53D | Seat Lumbar Support Motor - Driver | Driver Seat Components (Power) | |||
| M55D | Seat Rear Vertical Motor - Driver | Inside passenger compartment. In front driver seat | |||
| M64 | Starter Motor | In the engine compartment, on the lower left rear of the engine | M64 Starter Motor X1 | ||
| M74D | Window Motor - Driver | Inside driver door. | Driver Door Components (without panel) | M74D Window Motor - Driver | |
| M74P | Window Motor - Passenger | Inside passenger door | Passenger Door Components (with panel) | M74P Window Motor - Passenger | |
| M74LR | Window Motor - Left Rear | Inside the left rear door, below the window | Left Rear Door (without panel) | M74LR Window Motor - Left Rear | |
| M74RR | Window Motor - Right Rear | Inside the right rear door, below the window | Right Rear Door (without panel) | M74RR Window Motor - Right Rear | |
| M75 | Windshield Wiper Motor | In the left rear of the engine compartment, at the base of the windshield, under the air inlet grille | Left of Engine Compartment Components | M75 Windshield Wiper Motor | |
| M93 | M93 Key Capture Solenoid Actuator | M97 | |||
| M97 | Fuel Door Lock Actuator | N08 | On the right side of the vehicle, just inside the fuel door, towards the rear | M97 Fuel Door Lock Actuator (N08) | |
| P2 | Transmission Shift Lever Position Indicator | MH8 | In the passenger compartment, on the center console, next to the automatic transmission shift lever | P2 Transmission Shift Lever Position Indicator | |
| P9 | Driver Information Center Display | In the passenger compartment, part of the instrument cluster assembly | P9 Driver Information Center Display | ||
| P12A | P12A Horn - High Note | U05 | Outside the left front corner of the vehicle, behind the front fascia | Front of Engine Compartment Components | P12A Horn - High Note |
| P12B | P12B Horn - Low Note | Outside the left front corner of the vehicle, behind the front fascia | Front of Engine Compartment Components | P12B Horn - Low Note | |
| P14 | Passenger Air Bag Disable Indicator | LHD | In the passenger compartment, on the center of the instrument panel, right of the hazard lamps switch | P14 Passenger Air Bag Disable Indicator | |
| P16 | Instrument Cluster | In the passenger compartment, on the upper part of the instrument panel, in front of the driver seat | P16 Instrument Cluster | ||
| P19 | Speakers | P19 Speakers | |||
| P19AG | Speaker - Left Front Door | In the passenger compartment, at the lower front of the left front door | Driver Door Components (without panel) | ||
| P19AH | Speaker - Right Front Door | In the passenger compartment, at the lower front of the right front door | Passenger Door Components (without panel) | ||
| P19AL | Speaker - Left Rear Door | In the passenger compartment, at the lower front of the left rear door | Left Rear Door (without panel) | P19AL Speaker - Left Rear Door | |
| P19AM | Speaker - Right Rear Door | In the passenger compartment, at the lower front of the right rear door | Right Rear Door (without panel) | P19AM Speaker - Right Rear Door | |
| P19H | Speaker - Left Front Tweeter | In the passenger compartment, at the base of the left windshield side garnish molding | Headliner Components (With Sunroof) | ||
| P19V | Speaker - Right Front Tweeter | P19V Speaker - Right Front Tweeter | In the passenger compartment, at the base of the right windshield side garnish molding | Headliner Components (With Sunroof) | |
| Q2 | A/C Compressor Clutch | C60 | In the engine compartment, on the lower right front of the engine, part of the A/C compressor | Q2 A/C Compressor Clutch (C60) | |
| Q5 | Brake Pressure Modulator | Part of the Electronic Brake Control Module | |||
| Q6E | Camshaft Position Actuator Solenoid Valve - Exhaust | In the engine compartment, on the upper, right front of the engine | Q6E Camshaft Position Actuator Solenoid Valve - Exhaust | ||
| Q6F | Camshaft Position Actuator Solenoid Valve - Intake | In the engine compartment, on the upper, right rear of the engine | Q6E Camshaft Position Actuator Solenoid Valve - Intake | ||
| Q8 | Control Solenoid Valve Assembly | MH8/MHB | In the engine compartment, inside the automatic transmission assembly | Automatic Transmission Components (MH8/MHB) | |
| Q12 | Evaporative Emission Purge Solenoid Valve | In the engine compartment, towards the rear of the engine, on top of the intake manifold, near the fuel rail | Q12 Evaporative Emission Purge Solenoid Valve | ||
| Q13 | Evaporative Emission Purge Solenoid Valve | In the engine compartment, towards the rear of the engine | |||
| Q17A | Fuel Injector 1 | In the engine compartment, top right of the engine, above cylinder 1 | Q17 (A, B, C, D) Fuel Injector 1-4 | ||
| Q17B | Fuel Injector 2 | In the engine compartment, top center of the engine, above cylinder 2 | Q17 (A, B, C, D) Fuel Injector 1-4 | ||
| Q17C | Fuel Injector 3 | In the engine compartment, top center of the engine, above cylinder 3 | Q17 (A, B, C, D) Fuel Injector 1-4 | ||
| Q17D | Fuel Injector 4 | In the engine compartment, top left of the engine, above cylinder 4 | Q17 (A, B, C, D) Fuel Injector 1-4 | ||
| Q22 | Intake Manifold Tuning Solenoid Valve | In the engine compartment, rear of the engine, left of the intake manifold | Q22 Intake Manifold Tuning Solenoid Valve (2H0) | ||
| Q23 | Line Pressure Control Solenoid Valve | MH8 or MHB | Inside the Automatic Transmission assembly | ||
| Q27B | Pressure Control Solenoid Valve 2 | Inside Automatic Transmission Assembly | |||
| Q27C | Pressure Control Solenoid Valve 3 | Inside Automatic Transmission Assembly | |||
| Q27D | Pressure Control Solenoid Valve 4 | Inside Automatic Transmission Assembly | |||
| Q27E | Pressure Control Solenoid Valve 5 | Inside Automatic Transmission Assembly | |||
| Q28 | Rear Drive Clutch | Under rear of Vehicle, Inside Rear axle Housing | Q28 Rear Drive Clutch (F46) | ||
| Q32A | Shift Solenoid Valve 1 | Inside Automatic Transmission Assembly | |||
| Q38 | Throttle Body | In the engine compartment, on the right rear of the engine, on the intake manifold | Q38 Throttle Body | ||
| Q39A | Torque Converter Clutch Pressure Control Solenoid Valve | Inside Automatic Transmission Assembly | |||
| Q40 | Turbocharger Bypass Solenoid Valve | LUV/LUJ | In the engine compartment on the intake tube coming out to the Turbo | Q40 Turbocharger Bypass Solenoid Valve (LUV/LUJ) | |
| Q42 | Turbocharger Wastegate Solenoid Valve | LUV/LUJ | In the engine compartment, at the upper right front of engine | Left Front of Engine Components (LUJ/LUV) | |
| Q49 | Rear Differential Clutch Solenoid Valve | F46 | Under Vehicle, above rear axle | ||
| Q51D | Seat Lumbar Support Valve Assembly - Driver | AG9 | In passenger compartment. In the bottom of the driver seat. | ||
| R3 | Blower Motor Resistor | In the passenger compartment, behind the lower right side of the instrument panel, near the Blower motor | R3 Blower Motor Resistor | ||
| R10 | Cooling Fan Resistor | In the passenger compartment, behind the lower left side of the instrument panel | R10 Cooling Fan Resistor (2H0) | ||
| S2 | Transmission Manual Shift Switch | MH9 | In the passenger compartment, at the front of the center console. inside Transmission Shift Lever. | S2 Transmission Manual Shift Switch | |
| S3 | Transmission Shift Lever | MH9 | In the passenger compartment, at the front of the center console | S3 Transmission Shift Lever | |
| S13D | Door Lock Switch - Driver | In the passenger compartment, on the driver door. | Driver Door Components (with panel) | S13D Door Lock Switch - Driver | |
| S13P | Door Lock Switch - Passenger | In the passenger compartment, on the passenger door. | Passenger Door Components (with panel) | S13P Door Lock Switch - Passenger | |
| S26 | Hazard Warning Switch | In the passenger compartment, In center of Dash. Down by Shifter | Front of Instrument Panel (MT) | S26 Hazard Warning Switch | |
| S30 | Headlamp Switch | In the passenger compartment, on the left side of the instrument panel, between the steering column, and the driver door | S30 Headlamp Switch | ||
| S33 | Horn Switch | In the passenger compartment, on the center of the steering wheel | S33 Horn Switch | ||
| S39 | Ignition Switch | In the passenger compartment, on the right side of the steering column | Steering Column Components | S39 Ignition Switch | |
| S40 | Passenger Air Bag Disable Switch | In the passenger compartment, on the far right side of the instrument panel | S40 Passenger Air Bag Disable Switch | ||
| S46B | Liftgate Unlatch Switch | Outside the rear of the vehicle, on the center of the liftgate, between the license plate lamps | Liftgate Components | S46B Liftgate Unlatch Switch | |
| S47D | Seat Memory Switch - Driver | S47D Seat Memory Switch - Driver | |||
| S48C | S48C Multifunction Switch 1 - Instrument Panel | JL4 | S48C Multifunction Switch 1 - Instrument Panel | ||
| S51 | Telematics Button Assembly | UE1 | In the passenger compartment, In Rear View mirror. | ||
| S52 | Outside Rearview Mirror Switch | DG6 | In the passenger compartment, on the front of the driver door arm rest, in front of the window switch | Driver Door Components (with panel) | S52 Outside Rearview Mirror Switch |
| S64D | Seat Adjuster Switch - Driver | In the passenger compartment, On side of the driver seat | |||
| S65D | Seat Lumbar Support Switch - Driver | In the passenger compartment, On side of the driver seat | S65D Seat Lumbar Support Switch - Driver | ||
| S70L | Steering Wheel Controls Switch - Left | K33/K34 | In the passenger compartment, on the steering wheel, on the left side | S70L Steering Wheel Controls Switch - Left | |
| S70R | Steering Wheel Controls Switch - Right | UC3/NZA | In the passenger compartment, on the front of the steering wheel, right of center | S70R Steering Wheel Controls Switch - Right | |
| S72 | Sunroof Switch | CF5 | In the passenger compartment, in the front center of the headliner, in the dome lamp bezel | S72 Sunroof Switch | |
| S75 | Traction Control Switch | JL4 | S75 Traction Control Switch | ||
| S78 | Multifunction Switch | In the passenger compartment, mounted to the left side of the steering column | Steering Column Components | S78 Turn Signal/Multifunction Switch | |
| S79D | Window Switch - Driver | In the passenger compartment, on the driver door arm rest | Driver Door Components (with panel) | S79D Window Switch - Driver (A55+A33) S79D Window Switch - Driver | |
| S79LR | Window Switch - Left Rear | A33 | In the passenger compartment, on the left rear door arm rest | Left Rear Door (with panel) | S79LR Window Switch - Left Rear (A33) |
| S79P | Window Switch - Passenger | In the passenger compartment, on the passenger door arm rest | Passenger Door Components (with panel) | S79P Window Switch - Passenger (A66) S79P Window Switch - Passenger S79P Window Switch - Passenger X1 X1 | |
| S79RR | Window Switch - Right Rear | A33 | In the passenger compartment, on the right rear door arm rest | Right Rear Door (with panel) | S79RR Window Switch - Right Rear (A33) S79RR Window Switch - Right Rear |
| S82 | Windshield Wiper/Washer Switch | In the passenger compartment, on steering column. On the right side. | S82 Windshield Wiper/Washer Switch | ||
| S88 | Sunroof Tilt Switch | In the passenger compartment, in the headliner just above the rearview mirror | S88 Sunroof Tilt Switch | ||
| T3 | Audio Amplifier | Inside passenger compartment. In rear of vehicle. By rear wheel well. | T3 Audio Amplifier X1 T3 Audio Amplifier X2 T3 Audio Amplifier X3 | ||
| T4G | Cellular Phone, Navigation, and Digital Radio Antenna | UE1 | |||
| T4M | Radio Antenna | Outside the vehicle, at the center, rear of the roof | |||
| T4S | Wireless Communication Antenna - Bluetooth | UE1 | In side of Passenger compartment, part of the Telematics Communication Interface Control Module | ||
| T6 | Power Inverter Module | KI6 | Left Side of Passenger Compartment Components (2 of 2) | T6 Power Inverter Module | |
| T12 | Automotic Transmission Assembly | MH9 | In the engine compartment, mounted to the left side of the engine | T12 Automatic Transmission Assembly X1 | |
| X50A | Fuse Block - Underhood | In the left front corner of the engine compartment, left of the battery | Left of Engine Compartment Components | ||
| X50D | Fuse Block - Battery | In the engine compartment, on top of the battery | Left of Engine Compartment Components | ||
| X51A | Fuse Block - Instrument Panel | In the passenger compartment, under the left side of the instrument panel | Rear of Instrument Panel Components (1 of 2) | ||
| X53A | Fuse Block - Rear Body | In the passenger compartment, In the rear of the vehicle. | |||
| X70A | Relay Block - Underhood | In the engine compartment. Near the battery. | |||
| X81 | Accessory Power Receptacle - 110V AC | KI6 | In the passenger compartment, in the center console. | X81 Accessory Power Receptacle - 110V AC X1 X81 Accessory Power Receptacle - 110V AC X2 | |
| X83 | Auxiliary Audio Input | UF7/USR | In the passenger compartment, on the passenger side of the instrument panel, inside the upper storage compartment, on the left side | X83 Auxlliary Audio Input (UF7/USR) | |
| X84 | Data Link Connector | In the passenger compartment, under the driver side of the instrument panel | Rear of Instrument Panel Components (1 of 2) | X84 Data Link Connector | |
| X85 | Steering Wheel Air Bag Coil | In the passenger compartment, on the steering column, under the steering wheel | Steering Column Components | X85 Steering Wheel Air Bag Coil X1 X85 Steering Wheel Air Bag Coil X2 X85 Steering Wheel Air Bag Coil X3 X85 Steering Wheel Air Bag Coil X4 | |
| X105 | Forward Lamp Harness To Body Harness | Forward Lamp Harness Routing - Inside | X105 Forward Lamp Harness To Body Harness | ||
| X112 | Engine Harness To Body Harness | In engine compartment Left side of engine | Body Harness Routing - Engine Compartment | X112 Engine Harness To Body Harness | |
| X200 | Body Harness To Instrument Panel Harness (Left) | In the right front of the passenger compartment, below the instrument panel, behind the passenger kick panel | Body Harness Routing - Left Front of Passenger Compartment | X200 Body Harness To Instrument Panel Harness (Left) | |
| X202 | Body Harness To Instrument Panel Harness (Right) | In the right front of the passenger compartment, below the instrument panel, behind the passenger kick panel | Body Harness Routing - Right Front of Passenger Compartment | X202 Body Harness To Instrument Panel Harness (Right) | |
| X206 | Body Harness To Instrument Panel Harness (Antenna) | X206 Body Harness to Instrument Panel Harness (Antenna) | |||
| X207 | Instrument Panel Harness to Passenger Air Bag Harness | Behind the right side of the instrument panel, behind the passenger instrument panel air bag | Instrument Panel Harness Routing | X207 Instument Panel Harness to Passenger Air Bag Harness | |
| X208 | Body Harness To Headliner Harness (Left) | In the right front of the passenger compartment, below the instrument panel, behind the passenger kick panel | Body Harness Routing - Left Front of Passenger Compartment | X208 Body Harness To Headliner Harness (Left) | |
| X209 | Body Harness To Headliner Harness (Right) | Behind the passenger side of the instrument panel, near the passenger air bag | Body Harness Routing - Right Front of Passenger Compartment | X209 Body Harness To Headliner Harness (Right) | |
| X231 | Body Harness To Center Console Harness | In the passenger compartment, between Instrument panel and center console | Center Console Harness Routing | X231 Body Harness To Center Console Harness | |
| X301 | Body Harness To Driver Seat Harness | In the passenger compartment, under the front of the driver seat | Body Harness Routing - Left Front of Passenger Compartment | X301 Body Harness To Driver Seat Harness | |
| X302 | Body Harness To Passenger Seat Harness | In the passenger compartment, under the front of the passenger seat | Body Harness Routing - Right Front of Passenger Compartment | X302 Body Harness To Passenger Seat Harness | |
| X350 | Body Harness To Fuel Tank Harness | Inside passenger compartment, at rear of vehicle Near right rear strut tower. | Fuel Tank Harness Routing | X350 Body Harness To Fuel Tank Harness | |
| X400 | Rear Fascia Harness To Body Harness (Right) | Inside passenger compartment, at rear of vehicle Near right rear strut tower. | Rear Fascia Harness Routing | X400 Rear Fascia Harness To Body Harness (Right) | |
| X405 | Left Tail Lamp Harness to Body Harness | Inside the left rear corner of the rear compartment | Body Harness Routing - Left Rear of Passenger Compartment | X405 Left Tail Lamp Harness to Body Harness | |
| X406 | Right Tail Lamp Harness to Body Harness | Inside the right rear corner of the rear compartment | Body Harness Routing - Right Rear of Passenger Compartment | X406 Right Tail Lamp Harness to Body Harness | |
| X409 | Body Harness To All Wheel Drive Harness | F46 | Body Harness Routing - Left Rear Exterior | X409 Body Harness To All Wheel Drive Harness | |
| X500 | Driver Door Harness To Body Harness | At the front of the driver door, between the door and the body | Body Harness Routing - Left Front of Passenger Compartment | X500 Driver Door Harness To Body Harness | |
| X600 | Passenger Door Harness To Body Harness | At the front of the passenger door, between the door and the body | Body Harness Routing - Right Front of Passenger Compartment | X600 Passenger Door Harness To Body Harness | |
| X700 | Left Rear Door Harness To Body Harness | At the front of the left rear door, between the door and the body | Body Harness Routing - Left Front of Passenger Compartment | X700 Left Rear Door Harness To Body Harness | |
| X800 | Right Rear Door Harness To Body Harness | At the front of the right rear door, between the door and the body | Body Harness Routing - Right Front of Passenger Compartment | X800 Right Rear Door Harness To Body Harness | |
| X900 | Body Harness To Liftgate Harness | In the upper, left rear corner of the luggage compartment | Liftgate Harness Routing | X900 Body Harness To Liftgate Harness | |
| X901 | Liftgate Harness To Liftgate Extension Harness | In the liftgate, left of center, behind the liftgate trim | Liftgate Harness Routing | X901 Liftgate Harness To Liftgate Extension Harness | |
| X902 | Liftgate Extension Harness To License Lamp Harness | On the inside of the Liftgate, on the left side | License Lamp Harness Routing | X902 Liftgate Extension Harness To License Lamp Harness | |
| G100 | Forward Lamp Harness | In the engine compartment, on the left side, on the frame rail | G100 | ||
| G101 | Forward Lamp Harness | In the engine compartment, on the right side, on the frame rail | G101 | ||
| G102 | Body Harness | In the left side of the engine compartment, on the inner fender well | G102 | ||
| G103 | Engine Harness | In the left front of the engine compartment, below the battery | G103 | ||
| G104 | Engine Harness | In the left front of the engine compartment, below the battery | G104 (LFF Engine) | ||
| G105 | Engine Harness | In the left side of the engine compartment, on the frame rail, behind X101 | |||
| G106 | Engine Harness | ||||
| G107 | Engine Harness | In the left front of the engine compartment, below the battery | |||
| G200 | HVAC Harness | C32 | In the passenger compartment, behind the instrument panel | G200, G301, and G302 | |
| G201 | Body Harness | In the left front of the passenger compartment, under the instrument panel, behind the driver kick panel, just above the base of the left A-pillar | G201, G203, G303, and G305 | ||
| G202 | HVAC Harness | In the passenger compartment, behind the instrument panel | |||
| G203 | HVAC Harness | In the passenger compartment, behind the instrument panel | G201, G203, G303, and G305 | ||
| G204 | HVAC Harness | ||||
| G301 | Instrument Panel Harness | In the passenger compartment, under the center console, near G300 and G302 | G200, G301, and G302 | ||
| G302 | Instrument Panel Harness | In the passenger compartment, under the center console, near G300 and G301 | G200, G301, and G302 | ||
| G303 | Body Harness | In the left front of the passenger compartment, at the base of the left A-pillar | G201, G203, G303, and G305 | ||
| G304 | Body Harness | In the right front of the passenger compartment, near the base of the right A-pillar | G304 | ||
| G305 | Body Harness | NJ1 | In the left front of the passenger compartment, at the base of the left A-pillar, above G303 | G201, G203, G303, and G305 | |
| G401 | Body Harness | In the right of the luggage compartment, on top of the right rear wheel well | G401 | ||
| G402 | Body Harness | In the right of the luggage compartment, on top of the right rear wheel well | G402 and G404 | ||
| G404 | Body Harness | In the left of the luggage compartmen, on top of the left rear wheel well | G402 and G404 | ||
| J101 | Engine Harness | LUJ | In engine compartment Below K20 Engine Control Module | ENGINE HARNESS ROUTING - RIGHT FRONT (LFF) | |
| J102 | Engine Harness | LFF | In engine compartment on top of the engine near the ignition coils | ENGINE HARNESS ROUTING - LEFT REAR (LFF) | |
| J114 | Body Harness | In the left rear of the engine compartment, approximately 14.5 cm (5.71 in) left of the breakout to the brake fluid level switch | |||
| J117 | Engine Harness | ENGINE HARNESS ROUTING - LEFT REAR (LFF) | |||
| J118 | Engine Harness | On the rear left side of the engine, approximately 4.5 cm (1.77 in) into the breakout leading to the engine control module connectors | ENGINE HARNESS ROUTING - LEFT REAR (LFF) | ||
| J124 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp | |||
| J125 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp | |||
| J126 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp. By X100 | |||
| J129 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp | |||
| J137 | Body Harness | Left front fender. Under brake booster. | ENGINE HARNESS ROUTING (LUJ) | ||
| J138 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp. By X100 | |||
| J140 | Body Harness | In the left rear of the engine compartment, approximately 4.5 cm (1.77 in) left of J114 | |||
| J142 | Body Harness | In the left side of the engine compartment, Under brake booster | |||
| J175 | Body Harness | Left front corner of Vehicle. Behind Left Headlamp. By X100 | |||
| J200 | Body Harness | LHD | On the left side of the passenger compartment under left front seat. | ||
| J201 | Body Harness | On left side of passenger compartment under dash. Under kick panel | |||
| J203 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J207 | Instrument Panel Harness | In center of passenger compartment Near K33 HVAC | |||
| J211 | Instrument Panel Harness | In center of passenger compartment Near A11 Radio X1 | |||
| J212 | Instrument Panel Harness | On left side of passenger compartment Near S30 Headlamp Switch | |||
| J214 | Instrument Panel Harness | In center of passenger compartment Near K33 HVAC | INSTRUMENT PANEL HARNESS ROUTING | ||
| J215 | Instrument Panel Harness | In center of passenger compartment Near K33 HVAC | INSTRUMENT PANEL HARNESS ROUTING | ||
| J216 | Instrument Panel Harness | On left side of passenger compartment under dash. | INSTRUMENT PANEL HARNESS ROUTING | ||
| J225 | Body Harness | On the left side of the instrument panel, under kick panel | INSTRUMENT PANEL HARNESS ROUTING | ||
| J226 | Body Harness | On the left side of the instrument panel, approximately 10.5 cm (4.13 cm) below the breakout to the X114 | |||
| J227 | Instrument Panel Harness | In center of passenger compartment behind dash. Close to A5 Driver Information Center | INSTRUMENT PANEL HARNESS ROUTING | ||
| J228 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J229 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J230 | Body Harness | On the left side of the instrument panel, under kick panel | BODY HARNESS ROUTING - LEFT FRONT OF PASSENGER COMPARTMENT | ||
| J231 | Body Harness | On the right side of the passenger compartment Under kick panel Close to brake out for G304 | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | ||
| J232 | Body Harness | On the right side of the passenger compartment Under kick panel Close to brake out for G304 | BODY HARNESS ROUTING - RIGHT FRONT OF PASSENGER COMPARTMENT | ||
| J233 | Body Harness | On the right side of the passenger compartment Under kick panel | BODY HARNESS ROUTING - LEFT FRONT OF PASSENGER COMPARTMENT | ||
| J239 | Instrument Panel Harness | In center of dash, close to A11 Radio X2 | |||
| J247 | Instrument Panel Harness | On left side of passenger compartment under dash. Near breakout for the steering column. | INSTRUMENT PANEL HARNESS ROUTING | ||
| J249 | Instrument Panel Harness | On Center side of passenger compartment under dash. | INSTRUMENT PANEL HARNESS ROUTING | ||
| J255 | Instrument Panel Harness | On Right side of passenger compartment under dash. | INSTRUMENT PANEL HARNESS ROUTING | ||
| J256 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J267 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J281 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J290 | Instrument Panel Harness | Instrument Panel Harness Routing | |||
| J291 | Body Harness | Body Harness Routing - Right Front of Passenger Compartment | |||
| J313 | Body Harness | In the passenger compartment, On left side in the rear behind C pillar panel | BODY HARNESS ROUTING - LEFT REAR OF PASSENGER COMPARTMENT | ||
| J314 | Body Harness | On the left side of the passenger compartment, Under left front seat | |||
| J315 | Body Harness | In the passenger compartment, Under center console | |||
| J317 | Body Harness | Body Harness Routing - Center of Passenger Compartment | |||
| J325 | Headliner Harness | Headliner Harness Routing (Without Sunroof) | |||
| J326 | Body Harness | In the passenger compartment, under the left front seat. | BODY HARNESS ROUTING - LEFT FRONT OF PASSENGER COMPARTMENT | ||
| J327 | Body Harness | In the passenger compartment, under the left front seat. | HEADLINER HARNESS ROUTING (WITH SUNROOF) | ||
| J328 | Body Harness | In the passenger compartment, under the Left seat | BODY HARNESS ROUTING - LEFT FRONT OF PASSENGER COMPARTMENT | ||
| J329 | Body Harness | In the passenger compartment, Under right front seat | Body Harness Routing - Right Front of Passenger Compartment | ||
| J330 | Body Harness | Body Harness Routing - Left Front of Passenger Compartment | |||
| J331 | Body Harness | Body Harness Routing - Left Front of Passenger Compartment | |||
| J333 | Body Harness | Body Harness Routing - Right Front of Passenger Compartment | |||
| J335 | Body Harness | On the right side of the passenger compartment, Back by the X53A Fuse block rear body. | |||
| J336 | Body Harness | Body Harness Routing - Left Rear of Passenger Compartment | |||
| J339 | Body Harness | On the left side of the passenger compartment, Behind Dash on A piller | Headliner Harness Routing (Without Sunroof) | ||
| J345 | Body Harness | On the left side of the passenger compartment, Under Rear door trim. | |||
| J347 | Body Harness | Body Harness Routing - Right Front of Passenger Compartment | |||
| J348 | Headliner Harness | Headliner Harness Routing (With Sunroof) | |||
| J349 | Body Harness | BODY HARNESS ROUTING - LEFT FRONT OF PASSENGER COMPARTMENT | |||
| J355 | Body Harness | On the left side of the passenger compartment, Near breakout for X200. | Headliner Harness Routing (Without Sunroof) | ||
| J362 | Body Harness | On the left side of the passenger compartment, In rear of vehicle | Headliner Harness Routing (With Sunroof) | ||
| J387 | Body Harness | Body Harness Routing - Right Rear of Passenger Compartment | |||
| J400 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J401 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | |||
| J405 | Body Harness | On the left side of the passenger compartment, In rear of vehicle top of c piller | |||
| J411 | Body Harness | On the left side of the passenger compartment, In rear of vehicle close to the top of c piller | |||
| J412 | Body Harness | On the left side of the passenger compartment, In rear of vehicle close to the top of c piller | |||
| J421 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | REAR DIFFERENTIAL HARNESS ROUTING | ||
| J422 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | REAR DIFFERENTIAL HARNESS ROUTING | ||
| J423 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | REAR DIFFERENTIAL HARNESS ROUTING | ||
| J424 | Body Harness | On the left side of the passenger compartment, In rear of vehicle. | REAR DIFFERENTIAL HARNESS ROUTING | ||
| J446 | Body Harness | Body Harness Routing - Left Rear of Passenger Compartment | |||
| J450 | Body Harness | Body Harness Routing - Left Rear of Passenger Compartment | |||
| J504 | Driver Door | Behind the driver door trim panel after breakout for outside mirror. | |||
| J505 | Driver Door | DRIVER DOOR HARNESS ROUTING | Driver Door Harness Routing | ||
| J506 | Driver Door | Behind the driver door trim panel after breakout for outside mirror. | Driver Door Harness Routing | ||
| J507 | Driver Door | Behind the driver door trim panel after breakout for outside mirror. | Driver Door Harness Routing | ||
| J605 | Passenger Door | Passenger Door Harness Routing | |||
| J702 | Driver Door | Behind the left rear door trim panel, approximately 8 cm into the breakout to the window switch | LEFT REAR DOOR HARNESS ROUTING | ||
| J801 | Driver Door | Behind the right rear door trim panel, approximately 8 cm into the breakout to the window switch | |||
| J900 | Liftgate | Inside the liftgate, approximately 4 cm (1.57 in) left of the breakout to X901 | LIFTGATE HARNESS ROUTING | ||
| J902 | License Plate Lamp | On the outside of the liftgate, under the license lamp trim cover, approximately 24 cm (9.45 in) from the right license plate lamp | |||
| J903 | License Plate Lamp | On the outside of the liftgate, under the license lamp trim cover, approximately 29 cm (11.4 in) from the right license plate lamp | |||
| J905 | Liftgate Harness | Inside the liftgate. Close the to the breakout for the M30 Liftgate Latch. | M30 Liftgate Latch | ||
| J990 | Liftgate Harness | Liftgate Harness Routing | |||
| J991 | Liftgate Harness | Liftgate Harness Routing | |||
| JX203 | Instrument Panel Harness | Behind the instrument panel, near breakout to A11 radio X1 connector | |||
| JX404 | Body Harness | On the left side of luggage compartment, near breakout to X53A fuse block |
Master Electrical Component List (Trax)
Scheme 21
| Items |
|---|
| 1: E4Z Turn Signal Repeater Lamp - Right E4Z Turn Signal Repeater Lamp - Right (T39) |
| 2: E2RF Side Marker Lamp - Right Front |
| 3: E4RF Turn Signal Lamp - Right Front |
| 4: E4F Headlamp - Right High Beam |
| 5: E4E Headlamp - Left High Beam E4E Head Lamp - Left High Beam |
| 6: E4LF Turn Signal Lamp - Left Front |
| 7: E2LF Side Marker Lamp - Left Front |
| 8: E4Y Turn Signal Repeater Lamp - Left E4Y Turn Signal Repeater Lamp - Left (T39) |
| 9: E4G Headlamp - Left Low Beam |
| 10: E29LF Fog Lamp - Left Front E29LF Fog Lamp - Left Front (T3U) |
| 11: B9 Ambient Air Temperature Sensor B9 Ambient Air Temperature Sensor |
| 12: E29RF Fog Lamp - Right Front E29RF Fog Lamp - Right Front (T3U) |
| 13: E4H Headlamp - Right Low Beam |
Scheme 22
| Items |
|---|
| 1: R10 Cooling Fan Resistor R10 Cooling Fan Resistor (2H0) |
| 2: B59L Front Impact Sensor - Left |
| 3: B59 Front Impact Sensor B59 Front Impact Sensor (AYC or ADL) |
| 4: B55 Hood Ajar Switch B55 Hood Ajar Switch (UTJ) |
| 5: B59R Front Impact Sensor - Right |
| 6: B203 Engine Coolant Radiator Temperature Sensor |
| 7: G24 Windshield Washer Pump G24 Windshield Washer Pump |
| 8: P12B Horn - Low Note P12B Horn - Low Note |
| 9: P12A Horn - High Note P12A Horn - High Note |
Scheme 23
| Items |
|---|
| 1: B19B Brake Booster Vacuum Sensor B19B Brake Booster Vacuum Sensor |
| 2: M75 Windshield Wiper Motor M75 Windshield Wiper Motor |
| 3: K17 Electronic Brake Control Module K17 Electronic Brake Control Module |
| 4: X50D Fuse Block - Battery X50D Fuse Block - Battery X1 X50D Fuse Block - Battery X2 X50D Fuse Block - Battery X3 X50D Fuse Block - Battery X4 X50D Fuse Block - Battery X5 |
| 5: X50A Fuse Block - Underhood |
| 6: B18 Battery Current Sensor B18 Battery Current Sensor |
| 7: B20 Brake Fluid Level Switch B20 Brake Fluid Level Switch |
Scheme 24
| Items |
|---|
| 1: Q17A Fuel Injector 1 Q17 (A, B, C, D) Fuel Injector 1-4 |
| 2: Q17B Fuel Injector 2 Q17 (A, B, C, D) Fuel Injector 1-4 |
| 3: Q17C Fuel Injector 3 Q17 (A, B, C, D) Fuel Injector 1-4 |
| 4: Q17D Fuel Injector 4 Q17 (A, B, C, D) Fuel Injector 1-4 |
Scheme 25
| Items |
|---|
| 1: B75C Multifunction Intake Air Sensor B75C Multifunction Intake Air Sensor (LUV/LUJ) |
| 2: K35 Ignition Coil Module |
| 3: B74 Manifold Absolute Pressure Sensor B74 Manifold Absolute Pressure Sensor |
| 4: Q12 Evaporative Emission Purge Solenoid Valve Q12 Evaporative Emission Purge Solenoid Valve |
| 5: B52A Heated Oxygen Sensor 1 B52A Heated Oxygen Sensor 1 |
| 6: Q38 Throttle Body Q38 Throttle Body |
| 7: B34 Engine Coolant Temperature Sensor |
| 8: B37 Engine Oil Pressure Switch |
| 9: B1 A/C Refrigerant Pressure Sensor B1 A/C Refrigerant Pressure Sensor |
| 10: Q2 A/C Compressor Clutch Q2 A/C Compressor Clutch (C60) |
| 11: Q42 Turbocharger Wastegate Solenoid Valve Q42 Turbocharger Wastegate Solenoid Valve (LUV/LUJ) |
Scheme 26
| Items |
|---|
| 1: M64 Starter Motor M64 Starter Motor X1 |
| 2: B68 Knock Sensor B68 Knock Sensor |
| 3: Q40 Turbocharger Bypass Solenoid Valve Q40 Turbocharger Bypass Solenoid Valve (LUV/LUJ) |
| 4: B23F Camshaft Position Sensor - Intake B23F Camshaft Position Sensor - Intake |
| 5: Q6F Camshaft Position Actuator Solenoid Valve - Intake |
| 6: Q6E Camshaft Position Actuator Solenoid Valve - Exhaust Q6E Camshaft Position Actuator Solenoid Valve - Intake |
| 7: B23E Camshaft Position Sensor - Exhaust B23E Camshaft Position Sensor - Exhaust |
| 8: E41 Engine Coolant Thermostat Heater E41 Engine Coolant Thermostat Heater |
| 9: G13 Generator G13 Generator X1 |
| 10: B52B Heated Oxygen Sensor 2 B52B Heated Oxygen Sensor 2 |
| 11: B26 Crankshaft Position Sensor B26 Crankshaft Position Sensor |
Scheme 27
| Items |
|---|
| 1: B23E Camshaft Position Sensor - Exhaust B23E Camshaft Position Sensor - Exhaust |
| 2: B23F Camshaft Position Sensor - Intake B23F Camshaft Position Sensor - Intake |
| 3: Q17D Fuel Injector 4 Q17 (A, B, C, D) Fuel Injector 1-4 |
| 4: B75C Multifunction Intake Air Sensor B75C Multifunction Intake Air Sensor (LUV/LUJ) |
| 5: Q17A Fuel Injector 1 Q17 (A, B, C, D) Fuel Injector 1-4 |
| 6: Q17B Fuel Injector 2 Q17 (A, B, C, D) Fuel Injector 1-4 |
| 7: Q12 Evaporative Emission Purge Solenoid Valve Q12 Evaporative Emission Purge Solenoid Valve |
| 8: Q17C Fuel Injector 3 Q17 (A, B, C, D) Fuel Injector 1-4 |
| 9: B52B Heated Oxygen Sensor 2 B52B Heated Oxygen Sensor 2 |
| 10: B37 Engine Oil Pressure Switch |
| 11: B34 Engine Coolant Temperature Sensor B34 Engine Coolant Temperature Sensor |
| 12: E41 Engine Coolant Thermostat Heater E41 Engine Coolant Thermostat Heater |
Scheme 28
| Items |
|---|
| 1: Q6E Camshaft Position Actuator Solenoid Valve - Exhaust Q6E Camshaft Position Actuator Solenoid Valve - Exhaust |
| 2: Q6F Camshaft Position Actuator Solenoid Valve - Intake |
| 3: T8A Ignition Coil 1 T8 Ignition Coil |
| 4: T8B Ignition Coil 2 T8 Ignition Coil |
| 5: T8C Ignition Coil 3 T8 Ignition Coil |
| 6: Q38 Throttle Body Q38 Throttle Body |
| 7: T8D Ignition Coil 4 T8 Ignition Coil |
| 8: B52A Heated Oxygen Sensor 1 B52A Heated Oxygen Sensor 1 |
| 9: Q42 Turbocharger Wastegate Solenoid Valve Q42 Turbocharger Wastegate Solenoid Valve (LUV/LUJ) |
| 10: B1 A/C Refrigerant Pressure Sensor B1 A/C Refrigerant Pressure Sensor |
| 11: Q2 A/C Compressor Clutch Q2 A/C Compressor Clutch (C60) |
| 12: Q40 Turbocharger Bypass Solenoid Valve Q40 Turbocharger Bypass Solenoid Valve (LUV/LUJ) |
Scheme 29
| Items |
|---|
| 1: B74 Manifold Absolute Pressure Sensor B74 Manifold Absolute Pressure Sensor |
| 2: B68 Knock Sensor B68 Knock Sensor |
| 3: G13 Generator G13 Generator X1 |
| 4: B26 Crankshaft Position Sensor B26 Crankshaft Position Sensor |
| 5: M64 Starter Motor M64 Starter Motor X1 |
Scheme 30
| Items |
|---|
| 1: Q6E Camshaft Position Actuator Solenoid Valve - Exhaust Q6E Camshaft Position Actuator Solenoid Valve - Exhaust |
| 2: B75B Mass Air Flow/Intake Air Temperature Sensor |
| 3: Q6F Camshaft Position Actuator Solenoid Valve - Intake Q6F Camshaft Position Actuator Solenoid Valve - Intake |
| 4: Q12 Evaporative Emission Purge Solenoid Valve Q12 Evaporative Emission Purge Solenoid Valve |
| 5: K35 Ignition Coil Module |
| 6: B74 Manifold Absolute Pressure Sensor B74 Manifold Absolute Pressure Sensor |
| 7: B26 Crankshaft Position Sensor B26 Crankshaft Position Sensor |
| 8: B23F Camshaft Position Sensor - Intake B23F Camshaft Position Sensor - Intake |
| 9: B34 Engine Coolant Temperature Sensor |
| 10: B23E Camshaft Position Sensor - Exhaust B23E Camshaft Position Sensor - Exhaust |
| 11: E41 Engine Coolant Thermostat Heater E41 Engine Coolant Thermostat Heater |
| 12: B52A Heated Oxygen Sensor 1 B52A Heated Oxygen Sensor 1 |
| 13: B1 A/C Refrigerant Pressure Sensor B1 A/C Refrigerant Pressure Sensor |
| 14: Q2 A/C Compressor Clutch Q2 A/C Compressor Clutch (C60) |
Scheme 31
| Items |
|---|
| 1: Q22 Intake Manifold Tuning Solenoid Valve |
| 2: B74 Manifold Absolute Pressure Sensor B74 Manifold Absolute Pressure Sensor |
| 3: Q38 Throttle Body Q38 Throttle Body |
| 4: G13 Generator G13 Generator X1 |
| 5: B52B Heated Oxygen Sensor 2 B52B Heated Oxygen Sensor 2 |
| 6: M64 Starter Motor M64 Starter Motor X1 |
Scheme 32
| Items |
|---|
| 1: Q8 Control Solenoid Valve Assembly |
Scheme 33
| Items |
|---|
| 1: B16 Backup Lamp Switch B16 Backup Lamp Switch |
Scheme 34
| Items |
|---|
| 1: B16 Backup Lamp Switch B16 Backup Lamp Switch |
Scheme 35
| Items |
|---|
| 1: E1G Accent Lamp - Left Instrument Panel |
| 2: P16 Instrument Cluster P16 Instrument Cluster |
| 3: P17 Info Display Module |
| 4: B10B Ambient Light/Sunload Sensor B10B Ambient Light / Sunload Sensor |
| 5: S48C Multifunction Switch 1 - Instrument Panel S48C Multifunction Switch 1 - Instrument Panel |
| 6: A11 Radio A11 Radio X1 A11 Radio X2 |
| 7: E1W Accent Lamp - Instrument Panel |
| 8: E1H Accent Lamp - Right Instrument Panel |
| 9: A26 HVAC Controls |
| 10: B272 Child Security Lock Switch |
| 11: X83 Auxiliary Audio Input X83 Auxlliary Audio Input (UF7/USR) |
| 12: E32 Cigarette Lighter Receptacle E32 Cigarette Lighter Receptacle |
| 13: S112 Fuel Economy Mode Switch (KL9) |
| 14: X84 Data Link Connector X84 Data Link Connector |
| 15: A22 Radio Controls |
| 16: S30 Headlamp Switch S30 Headlamp Switch |
Scheme 36
| Items |
|---|
| 1: P16 Instrument Cluster P16 Instrument Cluster |
| 2: P9 Driver Information Center Display P9 Driver Information Center Display |
| 3: B10B Ambient Light/Sunload Sensor B10B Ambient Light / Sunload Sensor |
| 4: P17 Info Display Module |
| 5: S48C Multifunction Switch 1 - Instrument Panel S48C Multifunction Switch 1 - Instrument Panel |
| 6: A22 Radio Controls |
| 7: K73 Telematics Communication Interface Control Module K73 Telematics Communication Interface Control Module (UE1) |
| 8: S40 Passenger Air Bag Disable Switch |
| 9: E1H Accent Lamp - Right Instrument Panel |
| 10: A26 HVAC Controls |
| 11: E32 Cigarette Lighter Receptacle E32 Cigarette Lighter Receptacle |
| 12: S2 Transmission Manual Shift Switch |
| 13: P2 Transmission Shift Lever Position Indicator P2 Transmission Shift Lever Position Indicator |
| 14: S3 Transmission Shift Lever S3 Transmission Shift Lever |
| 15: X83 Auxiliary Audio Input X83 Auxlliary Audio Input (UF7/USR) |
| 16: B272 Child Security Lock Switch |
| 17: S48D Multifunction Switch 2 - Instrument Panel |
| 18: S30 Headlamp Switch S30 Headlamp Switch |
| 19: E1G Accent Lamp - Left Instrument Panel |
| 20: K9 Body Control Module K9 Body Control Module X1 K9 Body Control Module X2 K9 Body Control Module X3 K9 Body Control Module X4 K9 Body Control Module X5 K9 Body Control Module X6 K9 Body Control Module X7 |
Scheme 37
| Items |
|---|
| 1: P16 Instrument Cluster P16 Instrument Cluster |
| 2: B10B Ambient Light/Sunload Sensor B10B Ambient Light / Sunload Sensor |
| 3: A11 Radio A11 Radio X1 A11 Radio X2 |
| 4: S40 Passenger Air Bag Disable Switch |
| 5: K73 Telematics Communication Interface Control Module K73 Telematics Communication Interface Control Module (UE1) |
| 6: C3 Telematics Communication Interface Control Module Battery C3 Telematics Communication Interface Control Module Battery (UE1) |
| 7: X83 Auxiliary Audio Input X83 Auxlliary Audio Input (UF7/USR) |
| 8: P14 Passenger Air Bag Disabled Indicator |
| 9: S26 Hazard Warning Switch |
| 10: K33 HVAC Control Module K33 HVAC Control Module X1 K33 HVAC Control Module X2 |
| 11: E32 Cigarette Lighter Receptacle E32 Cigarette Lighter Receptacle |
| 12: S48D Multifunction Switch 2 - Instrument Panel |
| 13: S48C Multifunction Switch 1 - Instrument Panel S48C Multifunction Switch 1 - Instrument Panel |
| 14: S30 Headlamp Switch S30 Headlamp Switch |
| 15: X84 Data Link Connector X84 Data Link Connector |
| 16: K9 Body Control Module K9 Body Control Module X1 K9 Body Control Module X2 K9 Body Control Module X3 K9 Body Control Module X4 K9 Body Control Module X5 K9 Body Control Module X6 K9 Body Control Module X7 |
Scheme 38
| Items |
|---|
| 1: X51A Fuse Block - Instrument Panel X51A Fuse Block - Instrument Panel X1 X51A Fuse Block - Instrument Panel, Wire Entry |
| 2: X84 Data Link Connector X84 Data Link Connector |
| 3: K36 Inflatable Restraint Sensing and Diagnostic Module K36 Inflatable Restraint Sensing And Diagnostic Module X1 K36 Inflatable Restraint Sensing And Diagnostic Module X2 |
Scheme 39
| Items |
|---|
| 1: C3 Telematics Communication Interface Control Module Battery C3 Telematics Communication Interface Control Module Battery (UE1) |
| 2: K73 Telematics Communication Interface Control Module K73 Telematics Communication Interface Control Module (UE1) |
| 3: K36 Inflatable Restraint Sensing and Diagnostic Module K36 Inflatable Restraint Sensing And Diagnostic Module X1 K36 Inflatable Restraint Sensing And Diagnostic Module X2 |
| 4: K9 Body Control Module K9 Body Control Module X1 K9 Body Control Module X2 K9 Body Control Module X3 K9 Body Control Module X4 K9 Body Control Module X5 K9 Body Control Module X6 K9 Body Control Module X7 |
Scheme 40
| Items |
|---|
| 1: B7D Air Temperature Sensor - Duct Left Lower |
| 2: B7E Air Temperature Sensor - Duct Right Lower |
| 3: K33 HVAC Control Module K33 HVAC Control Module X1 K33 HVAC Control Module X2 |
| 4: B7H Air Temperature Sensor - Duct Left Upper |
| 5: B7J Air Temperature Sensor - Duct Right Upper |
| 6: M6R Air Temperature Door Actuator - Right |
| 7: M46 Air Recirculation Door Actuator |
| 8: M8 Blower Motor |
| 9: K8 Blower Motor Control Module K89 Immobilizer Control Module |
Scheme 41
| Items |
|---|
| 1: M37 Mode Door Actuator |
| 2: M6L Air Temperature Door Actuator - Left |
| 3: B39 A/C Evaporator Temperature Sensor |
Scheme 42
| Items |
|---|
| 1: B22 Brake Pedal Position Sensor B22 BRAKE PEDAL POSITION SENSOR (MH8/MHB) B22 BRAKE PEDAL POSITION SENSOR (M4P/MR5) |
| 2: B107 Accelerator Pedal Position Sensor B107 Accelerator Pedal Position Sensor |
Scheme 43
| Items |
|---|
| 1: B25 Clutch Pedal Position Switch |
| 2: B107 Accelerator Pedal Position Sensor B107 Accelerator Pedal Position Sensor |
| 3: B22 Brake Pedal Position Sensor B22 BRAKE PEDAL POSITION SENSOR (MH8/MHB) B22 BRAKE PEDAL POSITION SENSOR (M4P/MR5) |
Scheme 44
| Items |
|---|
| 1: E32 Cigarette Lighter Receptacle E32 Cigarette Lighter Receptacle |
| 2: B80 Park Brake Switch B80 Park Brake Switch |
Scheme 45
| Items |
|---|
| 1: S78 Turn Signal/Multifunction Switch S78 Turn Signal/Multifunction Switch |
| 2: X85 Steering Wheel Air Bag Coil X85 Steering Wheel Air Bag Coil X1 X85 Steering Wheel Air Bag Coil X2 X85 Steering Wheel Air Bag Coil X3 X85 Steering Wheel Air Bag Coil X4 |
| 3: S82 Windshield Wiper/Washer Switch S82 Windshield Wiper/Washer Switch |
| 4: K43 Power Steering Control Module K43 Power Steering Control Module (NJ1) |
| 5: S39 Ignition Switch S39 Ignition Switch |
| 6: K89 Immobilizer Control Module K89 Immobilizer Control Module |
| 7: B99 Steering Wheel Angle Sensor B99 Steering Wheel Angle Sensor |
Scheme 46
| Items |
|---|
| 1: S70L Steering Wheel Controls Switch - Left |
| 2: S70R Steering Wheel Controls Switch - Right |
| 3: S33 Horn Switch |
Scheme 47
| Items |
|---|
| 1: B200 Rain Sensor Module (CE1) |
| 2: K109 Frontview Camera Module (UFL) |
| 3: B160 Windshield Temperature and Inside Moisture Sensor B160 Windshield Temperature And Inside Moisture Sensor |
| 4: E37A Dome/Reading Lamps E37A Dome/Reading Lamps |
| 5: S88 Sunroof Tilt Switch S88 Sunroof Tilt Switch |
| 6: K61 Sunroof Control Module K61 Sunroof Control Module (CF5) |
| 7: E36AH Dome Lamp |
| 8: P19H Speaker - Left Front Tweeter P19H Speaker - Left Front Tweeter |
| 9: A10 Inside Rearview Mirror A10 INSIDE REARVIEW MIRROR |
| 10: A3L Sunshade - Left |
| 11: A3R Sunshade - Right |
| 12: P19V Speaker - Right Front Tweeter P19V Speaker - Right Front Tweeter |
| 13: B24 Cellular Phone Microphone B24 CELLULAR PHONE MICROPHONE |
| 14: S72 Sunroof Switch S72 Sunroof Switch |
Scheme 48
| Items |
|---|
| 1: F112D Seat Belt Retractor Pretensioner - Driver |
| 2: B63L Side Impact Sensor - Left B63L Side Impact Sensor - Left (AYC or ADL) |
| 3: K9 Body Control Module K9 Body Control Module X1 K9 Body Control Module X2 K9 Body Control Module X3 K9 Body Control Module X4 K9 Body Control Module X5 K9 Body Control Module X6 K9 Body Control Module X7 |
| 4: K36 Inflatable Restraint Sensing and Diagnostic Module K36 Inflatable Restraint Sensing And Diagnostic Module X1 K36 Inflatable Restraint Sensing And Diagnostic Module X2 |
| 5: B80 Park Brake Switch B80 Park Brake Switch |
Scheme 49
| Items |
|---|
| 1: E8S Rear Compartment Courtesy Lamp E8S Rear Compartment Courtesy Lamp |
| 2: F112D Seat Belt Retractor Pretensioner - Driver |
| 3: F105L Roof Rail Air Bag - Left F105L Roof Rail Air Bag - Left |
| 4: B63L Side Impact Sensor - Left B63L Side Impact Sensor - Left (AYC or ADL) |
| 5: K77 Remote Control Door Lock Receiver K77 Remote Control Door Lock Receiver |
| 6: X53A Fuse Block - Rear Body X53A Fuse Block - Rear Body, Wire Entry |
| 7: T6 Power Inverter Module |
Scheme 50
| Items |
|---|
| 1: T19 Power Supply Transformer (KL9) |
| 2: F105R Roof Rail Air Bag - Right F105R Roof Rail Air Bag - Right |
| 3: F112P Seat Belt Retractor Pretensioner - Passenger |
| 4: K41 Front and Rear Parking Assist Control Module K41R Rear Parking Assist Control Module X1 K41R Rear Parking Assist Control Module X2 |
| 5: B63R Side Impact Sensor - Right B63R Side Impact Sensor - Right (AYC or ADL) |
Scheme 51
| Items |
|---|
| 1: M50D Seat Front Vertical Motor - Driver |
| 2: K40 Seat Memory Control Module (AAG/KA1) |
| 3: E14B Seat Heating Element - Driver Cushion |
| 4: B153D Seat Belt Buckle - Driver |
| 5: E14B Seat Heating Element - Driver Cushion |
| 6: F106D Seat Side Air Bag - Driver |
| 7: M53D Seat Lumbar Support Motor - Driver |
| 8: F113D Seat Belt Anchor Pretensioner - Driver |
| 9: S64D Seat Adjuster Switch - Driver |
| 10: S65D Seat Lumbar Support Switch - Driver |
| 11: S47D Seat Memory Switch - Driver (AAG) |
| 12: M55D Seat Rear Vertical Motor - Driver |
| 13: M51D Seat Horizontal Motor - Driver |
Scheme 52
| Items |
|---|
| 1: B153D Seat Belt Buckle - Driver |
| 2: E14A Seat Heating Element - Driver Back |
| 3: F106D Seat Side Air Bag - Driver |
| 4: F113D Seat Belt Anchor Pretensioner - Driver |
| 5: K29 Seat Heating Control Module |
| 6: E14B Seat Heating Element - Driver Cushion |
Scheme 53
| Items |
|---|
| 1: M53P Seat Lumbar Support Motor - Passenger |
| 2: F106P Seat Side Air Bag - Passenger |
| 3: E14C Seat Heating Element - Passenger Back |
| 4: K85 Passenger Presence Module |
| 5: M50P Seat Front Vertical Motor - Passenger |
| 6: M55P Seat Rear Vertical Motor - Passenger |
| 7: M51P Seat Horizontal Motor - Passenger |
| 8: B153P Seat Belt Buckle - Passenger |
| 9: E14D Seat Heating Element - Passenger Cushion |
| 10: S65P Seat Lumbar Support Switch - Passenger |
| 11: S64P Seat Adjuster Switch - Passenger |
| 12: F113P Seat Belt Anchor Pretensioner - Passenger |
Scheme 54
| Items |
|---|
| 1: F106P Seat Side Air Bag - Passenger |
| 2: E14C Seat Heating Element - Passenger Back |
| 3: B153P Seat Belt Buckle - Passenger |
| 4: E14D Seat Heating Element - Passenger Cushion |
| 5: F113P Seat Belt Anchor Pretensioner - Passenger |
Scheme 55
| Items |
|---|
| 1: A23D Door Latch Assembly - Driver A23D DOOR LATCH ASSEMBLY - DRIVER |
| 2: A9A Outside Rearview Mirror - Driver A9A OUTSIDE REARVIEW MIRROR - DRIVER |
| 3: P19AG Speaker - Left Front Door P19AG Speaker - Left Front Door |
| 4: M74D Window Motor - Driver M74D Window Motor - Driver |
Scheme 56
| Items |
|---|
| 1: A23D Door Latch Assembly - Driver A23D DOOR LATCH ASSEMBLY - DRIVER |
| 2: S13D Door Lock Switch - Driver S13D Door Lock Switch - Driver |
| 3: S79D Window Switch - Driver S79D Window Switch - Driver (A55+A33) S79D Window Switch - Driver |
| 4: S52 Outside Rearview Mirror Switch S52 Outside Rearview Mirror Switch |
| 5: A9A Outside Rearview Mirror - Driver A9A OUTSIDE REARVIEW MIRROR - DRIVER |
Scheme 57
| Items |
|---|
| 1: A9B Outside Rearview Mirror - Passenger A9B OUTSIDE REARVIEW MIRROR - PASSENGER |
| 2: A23P Door Latch Assembly - Passenger A23P DOOR LATCH ASSEMBLY - PASSENGER |
| 3: M74P Window Motor - Passenger M74P Window Motor - Passenger |
| 4: P19AH Speaker - Right Front Door P19AH Speaker - Right Front Door |
Scheme 58
| Items |
|---|
| 1: A9B Outside Rearview Mirror - Passenger A9B OUTSIDE REARVIEW MIRROR - PASSENGER |
| 2: S13P Door Lock Switch - Passenger S13P Door Lock Switch - Passenger |
| 3: S79P Window Switch - Passenger S79P Window Switch - Passenger (A66) S79P Window Switch - Passenger S79P Window Switch - Passenger X1 X1 |
| 4: A23P Door Latch Assembly - Passenger A23P DOOR LATCH ASSEMBLY - PASSENGER |
Scheme 59
| Items |
|---|
| 1: A23LR Door Latch Assembly - Left Rear A23LR DOOR LATCH ASSEMBLY - LEFT REAR |
| 2: M74LR Window Motor - Left Rear M74LR Window Motor - Left Rear |
| 3: P19AL Speaker - Left Rear Door P19AL Speaker - Left Rear Door |
Scheme 60
| Items |
|---|
| 1: A23LR Door Latch Assembly - Left Rear A23LR DOOR LATCH ASSEMBLY - LEFT REAR |
| 2: S79LR Window Switch - Left Rear S79LR Window Switch - Left Rear (A33) |
Scheme 61
| Items |
|---|
| 1: P19AM Speaker - Right Rear Door P19AM Speaker - Right Rear Door |
| 2: M74RR Window Motor - Right Rear M74RR Window Motor - Right Rear |
| 3: M74RR Window Motor - Right Rear M74RR Window Motor - Right Rear |
Scheme 62
| Items |
|---|
| 1: S79RR Window Switch - Right Rear S79RR Window Switch - Right Rear (A33) S79RR Window Switch - Right Rear |
| 2: M74RR Window Motor - Right Rear M74RR Window Motor - Right Rear |
Scheme 63
| Items |
|---|
| 1: M45 Rear Wiper Motor M45 Rear Wiper Motor |
| 2: M30 Liftgate Latch M30 Liftgate Latch |
| 3: S46B Liftgate Unlatch Switch S46B Liftgate Unlatch Switch |
Scheme 64
| Items |
|---|
| 1: E42L Tail Lamp Assembly - Left |
| 2: E18 Rear Defogger Grid E18 Rear Defogger Grid X1 E18 Rear Defogger Grid X2 |
| 3: E6 Center High Mounted Stop Lamp E6 Center High Mounted Stop Lamp |
| 4: E42R Tail Lamp Assembly - Right |
| 5: B78H Rear Object Sensor - Right Outer B78H Rear Object Sensor - Right Outer |
| 6: E29RR Fog Lamp - Right Rear E29RR Fog Lamp - Right Rear (VD1) |
| 7: B78F Rear Object Sensor - Right Middle B78F Rear Object Sensor - Right Middle |
| 8: E7R License Plate Lamp - Right E7R License Plate Lamp - Right |
| 9: B87 Rearview Camera B87 Rearview Camera (UVC) |
| 10: E7L License Plate Lamp - Left E7L License Plate Lamp - Left |
| 11: B78E Rear Object Sensor - Left Middle B78E Rear Object Sensor - Left Middle |
| 12: E29LR Fog Lamp - Left Rear E29LR Fog Lamp - Left Rear (VD1) |
| 13: B78G Rear Object Sensor - Left Outer B78G Rear Object Sensor - Left Outer |
Scheme 65
| Items |
|---|
| 1: M97 Fuel Fill Door Lock Actuator M97 Fuel Door Lock Actuator (N08) |
| 2: B5RF Wheel Speed Sensor - Right Front B5RF WHEEL SPEED SENSOR - RIGHT FRONT |
| 3: B5LR Wheel Speed Sensor - Left Rear B5LR WHEEL SPEED SENSOR - LEFT REAR |
| 4: B5LF Wheel Speed Sensor - Left Front B5LF WHEEL SPEED SENSOR - LEFT FRONT |
| 5: B5RR Wheel Speed Sensor - Right Rear B5RR WHEEL SPEED SENSOR - RIGHT REAR |
Scheme 66
| Items |
|---|
| 1: P12A Horn - High Note P12A Horn - High Note |
| 2: P12B Horn - Low Note P12B Horn - Low Note |
Scheme 67
| Items |
|---|
| 1: A7 Fuel Pump and Level Sensor Assembly A7 FUEL PUMP AND LEVEL SENSOR ASSEMBLY |
| 2: B46B Fuel Level Sensor - Secondary B46B Fuel Level Sensor - Secondary (F46) |
Scheme 68
| Items |
|---|
| 1: K47 Rear Differential Clutch Control Module K47 Rear Differential Clutch Control Module X1 (F46) K47 Rear Differential Clutch Control Module X2 (F46) |
Scheme 69
| Items |
|---|
| 1: G100 |
Scheme 70
| Items |
|---|
| 1: G101 |
Scheme 71
| Items |
|---|
| 1: G102 |
Scheme 72
| Items |
|---|
| 1: G103 |
Scheme 73
| Items |
|---|
| 1: G104 |
Scheme 74
| Items |
|---|
| 1: G301 |
| 2: G200 |
| 3: G302 |
Scheme 75
| Items |
|---|
| 1: G203 |
| 2: G201 |
| 3: G305 |
| 4: G303 |
Scheme 76
| Items |
|---|
| 1: G304 |
Scheme 77
| Items |
|---|
| 1: G401 |
Scheme 78
| Items |
|---|
| 1: G404 |
| 2: G402 |
See also:
• A3L Sunshade - Left
• A3R Sunshade - Right
• A7 Fuel Pump And Level Sensor Assembly
• A9A Outside Rearview Mirror - Driver
• A9B Outside Rearview Mirror - Passenger
• A10 Inside Rearview Mirror
• A11 Radio X1
• A11 Radio X2
• A23D Door Latch Assembly - Driver
• A23LR Door Latch Assembly - Left Rear
• A23P Door Latch Assembly - Passenger
• A23RR Door Latch Assembly - Right Rear
• A26 HVAC Controls
• B1 A/C Refrigerant Pressure Sensor
• B5LF Wheel Speed Sensor - Left Front
• B5LR Wheel Speed Sensor - Left Rear
• B5RF Wheel Speed Sensor - Right Front
• B5RR Wheel Speed Sensor - Right Rear
• B7D Air Temperature Sensor - Duct Left Lower
• B7E Air Temperature Sensor - Duct Right Lower
• B7H Air Temperature Sensor - Duct Left Upper
• B7J Air Temperature Sensor - Duct Right Upper
• B9 Ambient Air Temperature Sensor
• B10 AMBIENT LIGHT SENSOR
• COMPONENT LOCATION
• B14A Transmission Output Shaft Speed Sensor
• B14C Transmission Input Shaft Speed Sensor (MH8 or MHB)
• B15 Transmission Internal Mode Switch
• B18 Battery Current Sensor
• B20 Brake Fluid Level Switch
• B23E Camshaft Position Sensor - Exhaust
• B23F Camshaft Position Sensor - Intake
• B24 Cellular Phone Microphone
• B26 Crankshaft Position Sensor
• B34A ENGINE COOLANT TEMPERATURE SENSOR 1
• B37B Engine Oil Pressure Sensor
• B39 A/C EVAPORATOR TEMPERATURE SENSOR
• B46B Fuel Level Sensor - Secondary
• B52A HEATED OXYGEN SENSOR 1
• B52B Heated Oxygen Sensor 2
• B55 Hood Ajar Switch
• B60 Passenger Presence Sensor
• B63LF SIDE IMPACT SENSOR - LEFT FRONT
• B63RF SIDE IMPACT SENSOR - RIGHT FRONT
• B68 Knock Sensor
• B74 Manifold Absolute Pressure Sensor
• B75C Multifunction Intake Air Sensor (LUJ)
• B78A FRONT OBJECT SENSOR - LEFT OUTER
• B78B FRONT OBJECT SENSOR - RIGHT OUTER
• B78C FRONT OBJECT SENSOR - LEFT MIDDLE
• B78D FRONT OBJECT SENSOR - RIGHT MIDDLE
• B78E REAR OBJECT SENSOR - LEFT MIDDLE
• B78F REAR OBJECT SENSOR - RIGHT MIDDLE
• B78G REAR OBJECT SENSOR - LEFT OUTER
• B78H REAR OBJECT SENSOR - RIGHT OUTER
• B80 Park Brake Switch
• B87 Rearview Camera (UVC)
• B88D Seat Belt Switch - Driver
• B88P Seat Belt Switch - Passenger
• B99 Steering Wheel Angle Sensor
• B104 Sunload Sensor
• B107 Accelerator Pedal Position Sensor
• B150 Fuel Tank Pressure Sensor
• B153D Seat Belt Buckle - Driver
• B160 Windshield Temperature And Inside Moisture Sensor
• B272 Child Security Lock Switch
• E1G ACCENT LAMP - LEFT INSTRUMENT PANEL (C93)
• E1H ACCENT LAMP - RIGHT INSTRUMENT PANEL (C93)
• E1W ACCENT LAMP - INSTRUMENT PANEL (C93)
• E2LR Side Marker Lamp - Left Rear
• E2RR Side Marker Lamp - Right Rear
• E4E Head Lamp - Left High Beam
• E4F Head Lamp - Right High Beam
• E4G Head Lamp - Left Low Beam
• E4H Head Lamp - Right Low Beam
• E5A Backup Lamp - Left
• E5B Backup Lamp - Right
• E6 Center High Mounted Stop Lamp
• E7L License Plate Lamp - Left
• E7R License Plate Lamp - Right
• E8S Rear Compartment Courtesy Lamp
• E13LA Headlamp Assembly - Left
• E13RA Headlamp Assembly - Right
• E14B SEAT HEATING ELEMENT - DRIVER CUSHION
• E14D Seat Heating Element - Passenger Cushion
• E18 Rear Defogger Grid X1
• E18 Rear Defogger Grid X2
• E27 Instrument Panel Compartment Lamp
• E29LF Fog Lamp - Left Front (T3U)
• E29RF Fog Lamp - Right Front (T3U)
• E32 Cigarette Lighter Receptacle
• E37A Dome/Reading Lamps
• E41 Engine Coolant Thermostat Heater
• F105L Roof Rail Air Bag - Left
• F105R Roof Rail Air Bag - Right
• F106D Seat Side Air Bag - Driver
• G13 Generator X1
• G24 Windshield Washer Pump
• K8 Blower Motor Control Module X1
• K9 Body Control Module X1
• K9 Body Control Module X2
• K9 Body Control Module X3
• K9 Body Control Module X4
• K9 Body Control Module X5
• K9 Body Control Module X6
• K9 Body Control Module X7
• K17 Electronic Brake Control Module
• K20 Engine Control Module X1 (LUJ)
• K20 Engine Control Module X1 (2H0 with MH8/MHB)
• K20 Engine Control Module X2 (LUJ)
• K20 Engine Control Module X2 (2H0 with MH8/MHB)
• K20 Engine Control Module X3 (LUJ)
• K20 Engine Control Module X3 (2H0 with MH8/MHB)
• K33 HVAC Control Module X2 (C67/CJ2)
• K33 HVAC Control Module X1 (CJ2)
• K33 HVAC Control Module X3 (CJ2/C67)
• K35 Ignition Coil Module
• K36 INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE X1
• K38 Chassis Control Module
• K40 SEAT MEMORY CONTROL MODULE X1
• K40 SEAT MEMORY CONTROL MODULE X2
• K40 SEAT MEMORY CONTROL MODULE X3
• K40 SEAT MEMORY CONTROL MODULE X4
• K40 SEAT MEMORY CONTROL MODULE X5
• K41 Front And Rear Parking Assist Control Module X1
• K43 POWER STEERING CONTROL MODULE
• K47 Rear Differential Clutch Control Module X1
• K61 Sunroof Control Module
• K73 Telematics Communication Interface Control Module
• K77 Remote Control Door Lock Receiver
• K85 Passenger Presence Module
• K89 Immobilizer Control Module
• K109 FRONTVIEW CAMERA MODULE
• M6L Air Temperature Door Actuator - Left
• M6R Air Temperature Door Actuator - Right
• M8 BLOWER MOTOR
• M30 Liftgate Latch
• M45 Rear Wiper Motor
• M51P Seat Horizontal Motor - Passenger
• M55P Seat Rear Vertical Motor - Passenger
• M64 Starter Motor X1
• M74D Window Motor - Driver
• M74P Window Motor - Passenger
• M74LR Window Motor - Left Rear
• M74RR Window Motor - Right Rear
• M75 Windshield Wiper Motor
• M97 Fuel Door Lock Actuator
• P2 Transmission Shift Lever Position Indicator
• P9 Driver Information Center Display
• P12A Horn - High Note
• P12B Horn - Low Note
• P16 Instrument Cluster
• P17 INFO DISPLAY MODULE
• P19AG Speaker - Left Front Door
• P19AH Speaker - Right Front Door
• P19AL Speaker - Left Rear Door
• P19AM Speaker - Right Rear Door
• P19H Speaker - Left Front Tweeter
• P19V Speaker - Right Front Tweeter
• Q2 A/C Compressor Clutch
• Q6E Camshaft Position Actuator Solenoid Valve - Exhaust
• Q6F Camshaft Position Actuator Solenoid Valve - Intake
• Q12 Evaporative Emission Purge Solenoid Valve
• Q17A Fuel Injector 1
• Q17B Fuel Injector 2
• Q17C Fuel Injector 3
• Q17D Fuel Injector 4
• Q38 Throttle Body
• Q40 Turbocharger Bypass Solenoid Valve
• Q42 Turbocharger Wastegate Solenoid Valve
• R10 Cooling Fan Resistor (LUJ/LUV)
• S3 Transmission Shift Lever
• S13D Door Lock Switch - Driver
• S13P Door Lock Switch - Passenger
• S30 Headlamp Switch
• S33 Horn Switch
• S39 Ignition Switch
• S46B Liftgate Unlatch Switch
• S52 Outside Rearview Mirror Switch
• S64D Seat Adjuster Switch - Driver
• S65D Seat Lumbar Support Switch - Driver
• S72 Sunroof Switch
• S78 Turn Signal/Multifunction Switch
• S79D Window Switch - Driver (A55+A33)
• S79LR Window Switch - Left Rear
• S79P WINDOW SWITCH - PASSENGER (A66)
• S79RR Window Switch - Right Rear
• S88 Sunroof Tilt Switch
• T3 Audio Amplifier X1
• T3 Audio Amplifier X2
• T3 Audio Amplifier X3
• T6 Power Inverter Module
• T12 Automatic Transmission Assembly X1
• X50A FUSE BLOCK - UNDERHOOD X1 (BUICK, NORTH AMERICA)
• X50A FUSE BLOCK - UNDERHOOD X2 (BUICK, NORTH AMERICA)
• X50A FUSE BLOCK - UNDERHOOD X3 (BUICK, NORTH AMERICA)
• X50D Fuse Block - Battery X1
• X50D Fuse Block - Battery X3
• X50D Fuse Block - Battery X5
• X53A Fuse Block - Rear Body, Wire Entry
• X70A Relay Block - Underhood, Wire Entry
• X84 Data Link Connector
• X85 Steering Wheel Air Bag Coil X1
• Forward Lamp Harness Routing - Outside
• X105 FORWARD LAMP HARNESS TO BODY HARNESS
• X112 Engine Harness To Body Harness
• X123 Front Fascia Harness To Forward Lamp Harness
• X200 Body Harness To Instrument Panel Harness (Left)
• X202 Body Harness To Instrument Panel Harness (Right)
• X231 Body Harness To Center Console Harness
• X301 Body Harness To Driver Seat Harness
• X302 Body Harness To Passenger Seat Harness
• X350 Body Harness To Fuel Tank Harness
• X400 Rear Fascia Harness To Body Harness (Right)
• X409 Body Harness To All Wheel Drive Harness
• X500 Driver Door Harness To Body Harness
• X600 Passenger Door Harness To Body Harness
• X700 Left Rear Door Harness To Body Harness
• X800 Right Rear Door Harness To Body Harness
• X900 Liftgate Harness To Body Harness
• X901 Liftgate Harness To Liftgate Extension Harness
• X902 Liftgate Extension Harness To License Lamp Harness
• X50D Fuse Block - Battery X2
• X50D Fuse Block - Battery X4
• X51A Fuse Block - Instrument Panel X1
• Fuel Tank Components
