Arrows and Symbols
This service manual uses various symbols in order to describe different service operations.
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Front of Vehicle |
| 2 | View Detail |
| 2 | View Detail |
| 3 | Ambient Air Mixed with Another Gas or Indicate Temperature Change |
| 4 | Motion or Direction |
| 5 | View Angle |
| 6 | Dimension (1:2) |
| 7 | Ambient/Clean Air Flow or Cool Air Flow |
| 8 | Lubrication Point- Oil or Fluid |
| 9 | Task Related |
| 10 | Sectioning (1:3) |
| 11 | Gas Other Than Ambient Air or Hot Air Flow |
| 12 | Lubrication Point- Grease or Jelly |
| 13 | Multidirectional Arrow |
Acronyms and Units
| Acronym | Meaning | Definition |
|---|---|---|
| 2WD | Two-Wheel Drive | Indicates that a vehicle has 2 driven wheels OR that a 4WD vehicle uses only 2 wheels for propulsion. So it can be the description of a vehicle configuration OR the operational mode of the drivetrain. |
| 4WD | Four-Wheel Drive | Four-wheeled vehicle with a drivetrain that allows all four wheels to receive power from the engine simultaneously which provides better control on various surfaces. Can be used to describe the configuration of the vehicle OR as the operational mode of the drivetrain. 4WD vehicles usually can turn 2 wheels off to be in a 2WD mode. See also AWD. |
| A/C | Air Conditioning | The cooling and dehumidification of indoor air for thermal comfort. |
| A/D | Analog to Digital | Used in context of converting electrical analog signals to digital signals. |
| ABS | Antilock Braking System | System on motor vehicles which prevents the wheels from locking while braking which helps the driver maintain control in heavy braking conditions. |
| AC | Alternating Current | An electrical current whose magnitude and direction vary cyclically. |
| AM | Amplitude Modulation | Method of impressing data onto an alternating-current (AC) carrier waveform. |
| APP | Accelerator Pedal Position | A pedal that controls the throttle valve. |
| AWD | All-Wheel Drive | All-wheel-drive systems are designed to function on all types of surfaces, both on- and off-road and most of them cannot be switched off. This can also be called full-time four wheel drive. See also 4WD. |
| AWG | American Wire Gauge | American wire gauge is a standardized wire gauge system used since 1857 predominantly in the United States for the diameters of round, solid, nonferrous, electrically conducting wire. E.g. a wire of AWG10 has a diameter of 2.588 mm, AWG20 corresponds to a diameter of 0.812 mm. |
| B+ | Battery Positive Voltage | The electrical potential on the positive terminal of the battery. |
| BARO | Barometric Pressure | Atmospheric pressure as measured by a barometer. |
| BCM | Body Control Module | This module supplies vehicle occupants with visual and audible information and controls various vehicle functions |
| BECM | Battery Energy Control Module | Control module used to regulate the battery voltage. |
| BPP | Brake Pedal Position | Position of the foot pedal that moves a piston in the master brake cylinder. |
| CAN | Controller Area Network | Serial data connection between control modules by Bosch |
| CCM | Chassis Control Module | The module that controls various vehicle functions on the Chassis, like Engine/Trans Mount, Active Grille Air Shutter, Load Leveling, etc. |
| CD | Compact Disc | A small optical disk on which data such as music, text or graphic images is digitally encoded. |
| CNG | Compressed Natural Gas | This a substitute for gasoline or diesel fuel. It is made by compressing natural gas (which is mainly composed by methane (CH4), in a percentage range of 70% to 98%) |
| CO | Carbon Monoxide | This is a product of the incomplete combustion of carbon-containing compounds, at room temperature this is a gas. It consists of one carbon atom covalently bonded to one oxygen atom. |
| CO2 | Carbon Dioxide | Chemical compound composed of two oxygen atoms covalently bonded to a single carbon atom. |
| CPA | Connector Position Assurance | Part of an electrical connector that prevents the connector from moving out of its socket. Usually needs to be pressed to unlock the connector when disconnecting it. |
| CPP | Clutch Pedal Position | A lever operated with the foot that controls the coupling that connects or disconnects driving and driven parts of a driving mechanism. |
| CV | Constant Velocity | Used in conjunction with CV joints, which connect two shafts at an angle while both shafts always have the same rotational speed without variations. |
| CVT | Continuously Variable Transmission | A transmission in which the ratio of the rotational speeds of two shafts, as the input shaft and output shaft of a vehicle or other machine, can be varied continuously within a given range, providing an infinite number of possible ratios which improves fuel economy. |
| D | Drive | D on the transmission gear selector lever. |
| DAB | Digital Audio Broadcast | Technology for broadcasting of audio using digital radio (carries information via digital signal) transmission. |
| DC | Direct Current | Continuous current, constant flow of electric charge. |
| DLC | Data Link Connector | This is an electronic connector typically located underneath the driver's side dashboard, just above the pedals. The connector has 16 pins. |
| DMM | Digital Multimeter | Electronic measuring instrument that combines several functions in one unit. The most basic instruments include an ammeter, voltmeter and ohmmeter. |
| DOHC | Dual Overhead Camshaft | Dual overhead camshafts (DOHC) are higher performance engines, they produce more power and can run at higher speeds because they allow an engine to have four valves per cylinder. Each camshaft operates two of the valves, one camshaft handles the intake valves and one handles the exhaust valves |
| DPF | Diesel Particulate Filter | Device designed to remove diesel particulate matter or soot from the exhaust gas of a diesel engine. |
| DRL | Daytime Running Lamps | White lights mounted on the front of an automobile that automatically switch on when the key is turned and are intended for daytime use, to increase the visibility of the automobile. |
| DSCC | Distance Sensing Cruise Control | A type of cruise control that automatically maintains the distance between vehicles. |
| DSP | Digital Signal Processor | A specialized microprocessor designed specifically for digital signal processing, generally in real-time computing. |
| DTC | Diagnostic Trouble Code | An electronic signal stored in an automotive computer, indicating the presence of a fault detected by that computer. |
| DVD | DVD | A popular optical disc storage media format the size of a CD. Used mainly for movies but also for data. DVD has no spelled out version (officially it does not mean Digital Video Disc or Digital Versatile Disc, it just means DVD). |
| EBCM | Electronic Brake Control Module | This module contains a microprocessor and software for antilock braking system operation. |
| ECM | Engine Control Module | This electronic module works with a vehicle's sensors and engine control devices to insure that the engine operates at maximum efficiency and performance. It performs three vital functions. Receives electronic signals from engine sensors. Analyzes the data and makes an engine performance decision (based on the pre-set parameters within the unit). Sends an "output command" to an actuator that adjusts engine performance. |
| ECT | Engine Coolant Temperature | A measure of how hot or cold the fluid which flows through the engine in order to prevent its overheating, transferring the heat produced by the device to other devices that utilize or dissipate it. |
| EEPROM | Electrically Erasable Programmable Read-Only Memory | A non-volatile storage chip used in computers and other devices to store small amounts of volatile data, e.g. calibration tables or device configuration. |
| EGR | Exhaust Gas Recirculation | Is an NOx (nitrogen oxide and nitrogen dioxide) reduction technique used in most gasoline and diesel engines. EGR works by recirculating a portion of an engine's exhaust gas back to the engine cylinders. |
| EMI | Electromagnetic Interference | Electromagnetic interference (also called radio frequency interference) is a disturbance that affects an electrical circuit due to either electromagnetic conduction or electromagnetic radiation emitted from an external source. |
| ESD | Electrostatic Discharge | The sudden and momentary electric current that flows between two objects at different electrical potentials. |
| EV | Electric Vehicle | A category of vehicles that only have an electric drive system. |
| EVAP | Evaporative Emission | A system that controls the fuel fumes in the fuel tank. |
| FM | Frequency Modulation | In telecommunication this is a way to convey information over a carrier wave by varying its frequency. |
| FWD | Front-Wheel Drive | A form of engine/transmission layout used in motor vehicles, where the engine drives the front wheels only. |
| GMLAN | General Motors Local Area Network | A local-area network is a computer network covering a small geographic area, like a home or vehicle. This specific type of LAN connects several controllers inside the vehicle and was developed by General Motors. |
| GPS | Global Positioning System | Satellite-based navigation system made up of a network of 24 satellites placed into orbit by the U.S. Department of Defense. |
| GSM | Global System for Mobile Communications | Globally accepted standard for digital cellular communication. |
| GVW | Gross Vehicle Weight | Maximum total weight of a road vehicle or trailer that is loaded, including the weight of the vehicle itself plus fuel, passengers, cargo and trailer tongue weight. |
| HD | Heavy Duty | Robust design to accommodate large work loads. |
| HID | High Intensity Discharge | A type of light that produces a bright light by using gas filled bulbs. (gas is usually mercury, metal halide and high-pressure sodium) Uses very little battery power and is a very "cool" light. |
| HO2S | Heated Oxygen Sensor | Heated oxygen sensors have an internal heater circuit that brings the sensor up to operating temperature more quickly than an unheated sensor. An oxygen sensor must be hot (about 600-650°F) before it will generate a voltage signal. The hot exhaust from the engine will provide enough heat to bring an O2 sensor up to operating temperature. |
| HVAC | Heating Ventilation Air Conditioning | This system is sometimes referred to as climate control. Ventilation air ducts installed throughout a vehicle that supply conditioned air to a room through rectangular or round outlet vents. |
| I 2 C | Inter-Integrated Circuit | Serial data connection between Integrated Circuits (microchips) inside a control module invented by Phillips |
| IAT | Intake Air Temperature | Temperature of the air entering intake air flow system of the engine. |
| ICE | Internal Combustion Engine | An engine in which the combustion of fuel and an oxidizer (typically air) occurs in a confined space called a combustion chamber. |
| ID | Identification | Number or Code that identifies a component or control module. Can be written on the part or be transmitted on a bus or via radio. |
| ISP | Internet Service Provider | A company that furnishes corporations and individual consumers with various services, mainly access to the Internet. |
| ISS | Input Shaft Speed | Rotational speed of the input shaft of a transmission. |
| LAN | Local Area Network | Standard network connection PC's. |
| LCD | Liquid Crystal Display | A thin, flat display device made up of any number of color or monochrome pixels arrayed in front of a light source or reflector. |
| LED | Light Emitting Diode | Small light bulbs that fit easily into an electrical circuit they do not have a filament that will burn out and they do not get especially hot. They are illuminated solely by the movement of electrons in a semiconductor material. |
| LIN | Local Interconnect Network | Computer networking bus system used within automotive network architectures. Similar to CAN, but cheaper and less powerful. |
| LPG | Liquefied Petroleum Gas | A mixture of mainly propane and butane, produced commercially and stored under pressure to keep it in a liquid state. |
| MAF | Mass Air Flow | The amount of air drawn into the engine |
| MAP | Manifold Absolute Pressure | Pressure in the engine intake system after the throttle valve referenced to a perfect vacuum. |
| MDI | Multiple Diagnostics Interface | A device used by GM dealers that enables a PC to communicate with the control modules in a vehicle. |
| MIL | Malfunction Indicator Lamp | An indicator of the internal status of a car engine. |
| MOST | Media Oriented Systems Transport | Serial communication bus to transmit audio and video information. |
| N | Neutral | A state of the transmission in which it is not engaged. |
| NiMH | Nickel Metal Hydride | A type of rechargeable battery that uses a hydrogen absorbing alloy for the negative electrode. |
| NOx | Nitrogen Oxides | Refers to any of the following oxygen compounds of nitrogen or a mixture of them. Nitric Oxide, Nitrogen dioxide, Nitrous Oxide, Dinitrogen trioxide, Dinitrogen tetroxide, Dinitrogen pentoxide. |
| O2 | Oxygen | A colorless, odorless, tasteless, gaseous chemical element with the chemical symbol O and atomic number 8. |
| O2S | Oxygen Sensor | An electronic device that measures the proportion of oxygen (O2) in the gas or liquid being analyzed. |
| OBD | On-Board Diagnostic | A generic term referring to a vehicle's self-diagnostic and reporting capability. |
| OEM | Original Equipment Manufacturer | A producer that provides a product to its customers, who proceed to modify or bundle it before distributing it to their customers. |
| OSS | Output Shaft Speed | Rotational speed of the output shaft of a transmission. |
| P | Park | A state in which the transmission is set so one can leave the vehicle. |
| PCB | Printed Circuit Board | A thin plate on which chips and other electronic components are placed. |
| PCM | Powertrain Control Module | A control module that features the functions of both, the engine and the transmission control module. |
| PCMCIA | Personal Computer Memory Card Industry Association | An international standards body and trade association with over 100 member companies that was founded in 1989 to establish standards for Integrated Circuit cards and to promote interchangeability among mobile computers where ruggedness, low power and small size were critical. |
| PIN | Personal Identification Number | A secret numeric password shared between a user and a system that can be used to authenticate the user to the system. |
| PPE | Personal Protective Equipment | Protective clothing, helmets, goggles or other garment designed to protect the wearer's body from injury. |
| PRNDL | Park, Reverse, Neutral, Drive, Low | Park, Reverse, Neutral, Drive, Low (automatic transmission positions). |
| PTC | Positive Temperature Coefficient | Refers to materials that experience an increase in electrical resistance when their temperature is raised. |
| PTO | Power Take-Off | A splined driveshaft, usually on a tractor or truck that can be used to provide power to an attachment or separate machine. This mechanism allows implements to draw energy from the tractor's engine. |
| PVC | Polyvinyl Chloride | A thermoplastic copolymer. |
| PWM | Pulse Width Modulation | Square shaped type of signal that carries the information in the ratio between on and off times. |
| R | Reverse | Rearward: directed or moving toward the rear |
| RAM | Random Access Memory | A type of computer data storage. It today takes the form of integrated circuits that allow the stored data to be accessed in any order. |
| RCT | Radiator Coolant Temperature | This is the heat intensity of the radiator coolant measured in degrees. The radiator is a part of the cooling system that removes the engine heat. Coolant is a mixture of water and antifreeze (ethylene glycol) which lowers the freezing point of the water in the coolant system, this fluid also picks up heat from the engine and transfers it to the air. |
| RDS | Radio Data System | A standard from the European Broadcasting Union for sending small amounts of digital information using conventional FM radio broadcasts. |
| RF | Radio Frequency | A frequency or rate of oscillation within the range of about 3 Hz and 300 GHz. This range corresponds to frequency of alternating current electrical signals used to produce and detect radio waves. |
| ROM | Read-Only Memory | A class of storage media used in computers and other electronic devices. Data stored in ROM cannot be modified. |
| RPO | Regular Production Option | A three digit/letter code given to parts, assemblies and systems originally installed on the vehicle. These RPO codes designate options and are assigned by General Motors. |
| RSA | Rear Seat Audio | An auxiliary set of controls that operate the main audio system from the rear seat. Rear passengers can also operate a different media source than the front passengers. |
| RWD | Rear-Wheel Drive | A common engine/transmission layout in which the engine is in the front of the vehicle, but the front mid-engine, rear mid-engine and rear engine layouts are also used. |
| SCV | Speed Controlled Volume | The volume control is set for a desired sound level in the vehicle as the vehicle increases its speed, the sound level is adjusted. |
| SDM | Sensing and Diagnostic Module | The name given to air bag modules used in General Motors vehicles. |
| SIM | Subscriber Identity Module | Part of a removable smart card Integrated Circuit Card. This is used for mobile cellular telephone devices such as mobile computers and mobile phones. SIM cards securely store the service-subscriber key used to identify a subscriber. The SIM card allows users to change phones by simply removing the SIM card from one mobile phone and inserting it into another mobile phone or broadband telephony device. |
| SIR | Supplemental Inflatable Restraint | Technical term for the air bag. Air bag is a stretchable membrane, which inflates during an automobile accident to provide cushioning to the passenger's head and torso to prevent injury to the passengers. |
| SPI | Serial Peripheral Interface | This is an interface that enables the serial (one bit at a time) exchange of data between two devices. An SPI operates in full duplex mode. This means that data can be transferred in both directions at the same time. It is a standard bus technology like CAN or I2C. |
| SPS | Service Programming System | System that enables repair facilities to update the software in control modules. |
| SUV | Sport Utility Vehicle | A passenger vehicle which combines the towing capacity of a pickup truck with the passenger-carrying space of a minivan. |
| SVS | Service Vehicle Soon | Indicator lamp or symbol for a malfunction related to a vehicle component or system. |
| TA | Traffic Announcement | Message spoken on radio regarding the movement of vehicles or pedestrians through an area or along a route. The buttons on radios that enable this announcements are also often labeled TA. |
| TAC | Throttle Actuator Control | A motor which moves the engine throttle plate or valve, controlled by the engine control module. A throttle plate limits the amount of air entering a internal combustion gasoline engine. |
| TAP | Transmission Adaptive Pressure | The transmission control module learns each component's characteristics and adjusts fluid pressure accordingly. |
| TCC | Torque Converter Clutch | Resides in a torque converter to connect an engine to an automatic transmission. The clutch is applied when conditions are correct to achieve a 1:1 ratio of engine crankshaft to transmission input shaft. |
| TCM | Transmission Control Module | A module that controls electronic automatic transmissions. It uses sensors from the vehicle as well as data provided by the Engine Control Module to calculate how and when to change gears in the vehicle for optimum performance, fuel economy and shift quality. |
| TDC | Top Dead Center | The piston is in its highest position relative to the combustion chamber. |
| TIS | Techline Information System | The PC-based global dealership diagnostic software that provides the technician the ability to reference the most recent service information via the service department's computer. |
| TPA | Terminal Position Assurance | An additional locking mechanism inside an electric connector that holds the pins in place. |
| TV | Television | A telecommunication system for broadcasting and receiving moving pictures and sound over a distance. |
| USB | Universal Serial Bus | A type of communication bus connection between a computer and a peripheral device. |
| VCI | Vehicle Communications Interface | A diagnostic tool that communicates to modules of multiple communication protocols in a vehicle by converting vehicle serial data into PC serial data communication. |
| VIN | Vehicle Identification Number | Used by manufacturers to uniquely identify motor vehicles using 17 characters. |
| VSCM | Vehicle Stability Control Module | This module uses information from several sensors to detect a loss of vehicle traction, then works with the antilock brake system to apply individual brakes to help keep the vehicle on its intended path. |
| VSS | Vehicle Speed Sensor | Sends data regarding how fast the car is traveling at the moment of driving. It is designed to be able to record the rate at which the vehicle's crankshaft is spinning. |
| WOT | Wide Open Throttle | When the throttle blade or valve is at its maximum open position, allowing maximum air to enter an internal combustion gasoline engine. |
| WLAN | Wireless Local Area Network | Standard to transmit digital data via radio frequency. |
| XM | XM (Satellite Radio) | XM Satellite Radio Holdings (XM) is one of two satellite radio services in the United States and Canada. XM provides pay-for-service radio, analogous to cable television. Its service includes 73 different music channels, 39 news, sports, talk and entertainment channels, 21 regional traffic and weather channels and 23 play-by-play sports channels (2008). |
| XML | Extensible Markup Language | A markup language that defines a set of rules for encoding documents in a format that is both human-readable and machine-readable. |
Acronyms
| Unit | Meaning | Definition |
|---|---|---|
| M 2 | Square Meter | Area |
| A | Ampere | Electrical |
| Ah | Ampere Hour | Electrical |
| C | Coulomb | Electrical |
| DBm | Decibel Meter | Electrical |
| DBmV | Decibel Millivolt | Electrical |
| MV/DIV | Millivolts per Division | Electrical |
| MV/s | Millivolts per Second | Electrical |
| Ohms | Ohm | Electrical |
| V | Volt | Electrical |
| V/DIV | Volts per Division | Electrical |
| V/ms | Volts per Millisecond | Electrical |
| W | Watt | Electrical |
| Mm 3 /stroke | Cubic Millimeters per Stroke | Flow |
| Gal/h | Gallons per Hour | Flow |
| G/s | Grams per second | Flow |
| G/stroke | Grams per Stroke | Flow |
| Kg/100km | Kilograms per 100 Kilometer | Flow |
| Kg/h | Kilograms per Hour | Flow |
| Km/L | Kilometer/liter | Flow |
| L/100km | Liters per 100 Kilometers | Flow |
| L/h | Liters per Hour | Flow |
| L/min | Liters per Minute | Flow |
| MPG | Miles per Gallon | Flow |
| Mg/s | Milligrams per Second | Flow |
| Mg/stroke | Milligrams per stroke | Flow |
| Ft | Feet | Length |
| In | Inch | Length |
| M | Meter | Length |
| Mi | Mile | Length |
| Bar | Bar | Mechanical |
| Bar/min | Bars per Minute | Mechanical |
| In. H2O | Inches of Water | Mechanical |
| In. H2O/s | Inches of Water per second | Mechanical |
| KPa/s | Kilopascals per Second | Mechanical |
| N | Newton | Mechanical |
| Newton Meter | Mechanical | |
| Pa | Pascal | Mechanical |
| Pa/s | Pascals per Second | Mechanical |
| Lb ft | Pound Foot | Mechanical |
| PSI | Pound-Force per Square Inch | Mechanical |
| Counts | Counts | Misc. |
| Cycles | Cycles | Misc. |
| DB | Decibel | Misc. |
| ° | Degree | Misc. |
| °C | Degree Centigrade | Misc. |
| °CA | Degree Crankshaft Angle | Misc. |
| °F | Degree Fahrenheit | Misc. |
| °/s | Degree per Second | Misc. |
| Hz | Hertz | Misc. |
| Kbit/s | Kilobit per second | Misc. |
| Lx | Lux | Misc. |
| Ppm | Parts per Million | Misc. |
| % | Percent | Misc. |
| %/min | Percents per Minute | Misc. |
| %/sec | Percents per Second | Misc. |
| Pulses | Pulses | Misc. |
| 1 | Ratio | Misc. |
| RPM | Revolutions per Minute | Misc. |
| Steps | Steps | Misc. |
| W/m 2 | Watts per Square Meter | Misc. |
| G | G (Acceleration) | Movement |
| Km/h | Kilometers per Hour | Movement |
| M/s | Meters per Second | Movement |
| M/s 3 | Meters per Second Cubed | Movement |
| M/s 2 | Meters per Second Squared | Movement |
| MPH | Miles per Hour | Movement |
| Mm/s | Millimeters per Second | Movement |
| D | Day | Time |
| H | Hour | Time |
| Hh:mm:ss | Hour:Minute:Second | Time |
| Ms/DIV | Milliseconds per Division | Time |
| Min | Minute | Time |
| S | Second | Time |
| S/DIV | Seconds per Division | Time |
| Yy-mm-dd | Year-Month-Day (2 digits) | Time |
| Yyyy-mm-dd | Year-Month-Day (4 digits, preferred) | Time |
| M 3 | Cubic Meter | Volume |
| Gal | Gallon | Volume |
| L | Liter | Volume |
| ML | Milliliters | Volume |
| US gal | US Gallon | Volume |
| US pt | US Pint | Volume |
| US qt | US Quart | Volume |
| Kg | Kilogram | Weight |
Units
Customer Concern Verification Sheets
The GM Customer Concern Verification Sheets have been designed to improve communications between the service customer and the technician. The more clearly the technician understands the concern and its symptoms, the more likely the concern will be fixed right the first time.
The GM-wide Customer Concern Verification Sheets are available in GM Global Connect. The Customer Concern Verification Sheets may be printed and reproduced locally.
Dealers
All U.S. GM Dealers participating in the Center of Learning/GM Service Technical College (STC) Programs can enroll through the Center of Learning website at https://www.centerlearning.com. Within the website, there are individual training paths that are designed to assist in planning the training needs for each individual and their job role. Dealers who have questions about Center of Learning Training should contact the Center of Learning help desk at 1-888-748-2687. The help desk is available Monday through Friday, 8:00 am - 9:00 pm Eastern Standard Time, excluding holidays. For GM Access support, contact the GM Access Help Desk at 1-888-337-1010.
Fleets
GM Fleet customers with GM Warranty In-Shop agreements are able to participate in service technical training through the Center of Learning/GM Service Technical College (STC).
Assistance for GM fleet registered customers using GM STC training is provided by the Center of Learning help desk at 1-888-748-2687. The help desk is available Monday through Friday, 8:00 am-9:00 pm Eastern Standard Time, excluding holidays. For GM Access support, contact the GM Access Help Desk at 1-888-337-1010.
Most GM STC course materials have associated charges.
To purchase authentic GM STC Training Materials, contact the GM Training Materials Headquarters at 1-800-393-4831.
Non-GM Dealer Technicians
Technician training for non-GM dealers is available through ACDelco. This training is for ACDelco PSC and Fleet program members employed in the automotive or truck service industry.
ACDelco courses are available at approved GM STC Training Centers. Availability and schedules can be obtained by calling 1-800-825-5886 (prompt 1) or contact us via the web at www.acdelcotechconnect.com and select the Training tab. Seminars are also offered through the ACDelco Warehouse Distribution channel. Contact your Local ACDelco representative or distributor directly for more information.
Scheme 3
The vehicle identification number (VIN) plate is the legal identifier of the vehicle. The VIN plate is located on the upper LH corner of the instrument panel (I/P). The VIN number can be seen through the windshield from the outside of the vehicle
| Position | Definition | Character | Description |
|---|---|---|---|
| 1 | Country of Origin | 1 | United States |
| 5 | |||
| 2 | Manufacturer | G | General Motors |
| 3 | Make | A | Buick MPV |
| K | GMC MPV | ||
| N | Chevrolet MPV | ||
| 4 | GVWR/Brake System/Body Style | K | Class E: 6, 001 lbs-7, 000 lbs, Hydraulic, Four Door Cab/Utility |
| 5-6 | Chassis/Series | R/A | Enclave Convenience Group (FWD) |
| R/B | Enclave Leather Group (FWD) | ||
| R/C | Enclave Premium Group (FWD) | ||
| R/F | Traverse LS (FWD) | ||
| R/G | Traverse 1LT (FWD) | ||
| R/H | Traverse 2LT (FWD) | ||
| R/J | Traverse LTZ (FWD) | ||
| R/N | Acadia SLE 1 (FWD) | ||
| R/P | Acadia SLE 2 (FWD) | ||
| R/R | Acadia SLT 1 (FWD) | ||
| R/S | Acadia SLT 2 (FWD) | ||
| R/T | Acadia Denali (FWD) | ||
| R/7 | Enclave FWD (Export - Non US, Non Canada) | ||
| R/8 | Traverse FWD (Export - Non US, Non Canada) | ||
| R/9 | Acadia FWD (Export - Non US, Non Canada) | ||
| V/A | Enclave Convenience Group (AWD) | ||
| V/B | Enclave Leather Group (AWD) | ||
| V/C | Enclave Premium Group (AWD) | ||
| V/F | Traverse LS (AWD) | ||
| V/G | Traverse 1LT (AWD) | ||
| V/H | Traverse 2LT (AWD) | ||
| V/J | Traverse LTZ (AWD) | ||
| V/N | Acadia SLE 1 (AWD) | ||
| V/P | Acadia SLE 2 (AWD) | ||
| V/R | Acadia SLT 1 (AWD) | ||
| V/S | Acadia SLT 2 (AWD) | ||
| V/T | Acadia Denali (AWD) | ||
| V/7 | Enclave AWD (Export - Non US, Non Canada) | ||
| V/8 | Traverse AWD (Export - Non US, Non Canada) | ||
| V/9 | Acadia AWD (Export - Non US, Non Canada) | ||
| 7 | Restraint System | E | Active Manual Belts, Airbags - Driver and Passenger Front (1st row), Front Seat Side (1st row), Roof Side (All seating rows) |
| K | Active Manual Belts, Airbags - Driver and Passenger - Front (1st row), Front Seat Side (1st row), Front Inboard Seat Side (1st row), Roof Side (All seating rows) | ||
| 8 | Engine Type | D | LLT - Engine, Gas, 6 Cylinder, 3.6L, SIDI |
| 9 | Check Digit | Check Digit | |
| 10 | Model Year | E | 2014 |
| 11 | Plant Location | J | Lansing Delta Township, MI |
| 12-17 | Plant Sequence Number | Plant Sequence Number |
Vehicle Identification Number (VIN) System
3.6L RPO LLT Engine ID and VIN Derivative Location
Refer to Engine Identification .
6T70/6T75 Transmission ID and VIN Derivative Location
Refer to Transmission Identification Information .
Scheme 4
| Callout | Description |
|---|---|
| Vehicle Certification Label The vehicle certification label is located on the driver door and displays the following assessments: Gross Vehicle Weight Rating (GVWR) Gross Axle Weight Rating (GAWR), front and rear The gross vehicle weight (GVW) is the weight of the vehicle and everything it carries. The gross vehicle weight must not exceed the GVWR. Include the following items when figuring the GVW: The base vehicle weight (factory weight) The weight of all vehicle accessories The weight of the driver and the passengers The weight of the cargo | |
| 1 | Name of Manufacturer |
| 2 | Gross Vehicle Weight Rating |
| 3 | Gross Axle Weight Rating (Front, Rear) |
| 4 | Canadian Safety Mark (w/RPO Z49) |
| 5 | Certification Statement |
| 6 | Vehicle Class Type (Pass Car, etc.) |
| 7 | Vehicle Identification Number |
| 8 | Date of Manufacture (Mo/Yr) |
| Tire Placard The tire placard label is located on the driver side of the B pillar and displays the following assessments | |
| 9 | Specified Occupant Seating Positions |
| 10 | Maximum Vehicle Capacity Weight |
| 11 | Tire Pressure, Front, Rear and Spare (Cold) |
| 12 | Original Equipment Tire Size |
| Service Parts ID Label The vehicle service parts identification label is located in the instrument panel (I/P) compartment. The label is use to help identify the vehicle original parts and options. | |
| 13 | Vehicle Identification Number |
| 14 | Engineering Model Number (Vehicle Division, Line and Body Style) |
| 15 | Interior Trim Level and Decor |
| 16 | Exterior (Paint Color) WA Number |
| 17 | Paint Technology |
| 18 | Special Order Paint Colors and Numbers |
| 19 | Vehicle Option Content |
| Anti-Theft Label | |
| 20 | The Federal law requires that General Motors label certain body parts on this vehicle with the VIN. The purpose of the law is to reduce the number of motor vehicle thefts by helping in the tracing and recovery of parts from stolen vehicles. Labels are permanently affixed to an interior surface of the part. The label on the replacement part contains the letter R, the manufacturer's logo and the DOT symbol. The anti-theft label must be covered before any painting and rustproofing procedures and uncovered after the procedures. Failure to follow the precautionary steps may result in liability for violation of the Federal Vehicle Theft Prevention Standard and possible suspicion to the owner that the part was stolen. |
Vehicle Certification, Tire Placard, Anti-Theft and Service Parts ID Label
RPO Code List
The following table provides the description of the RPO codes that are available on the vehicle. The vehicles RPO list is printed on the Service Parts Identification Label.
| RPO | Description |
|---|---|
| 17U | PRIMARY COLOR - EXTERIOR, SWITCHBLADE SILVER MET (09) |
| 192 | TRIM COMBINATION - LEATHER, EBONY (2) (00) |
| 193 | TRIM COMBINATION - LEATHER, EBONY (3) (00) |
| 19C | TRIM COMBINATION - CLOTH, EBONY (C) (00) |
| 19I | INTERIOR TRIM - EBONY (I) (00) |
| 1SD | PACKAGE - OPTION 04 |
| 1SL | PACKAGE - OPTION 11 |
| 1SN | PACKAGE - OPTION 13 |
| 1XL | PACKAGE - CXL OPTION 1 |
| 222 | TRIM COMBINATION - LEATHER, EBONY VERY DK CASHMERE |
| 223 | TRIM COMBINATION - LEATHER, EBONY/VERY DK CASHERE PERFORATED |
| 22I | INTERIOR TRIM - EBONY/VERY DK CASHMERE |
| 2XL | PACKAGE - CXL OPTION 2 |
| 3SA | PACKAGE - SLE OPTION 1 |
| 3SB | PACKAGE - SLE OPTION 2 |
| 40U | PRIMARY COLOR - EXTERIOR, WHITE (02) 8554 |
| 432 | TRIM COMBINATION - LEATHER, CHOCCOCHINO/COCOA |
| 43I | INTERIOR TRIM - CHOCCOCHINO/COCOA |
| 4SA | PACKAGE - SLT OPTION 1 |
| 4SB | PACKAGE - SLT OPTION 2 |
| 542 | TRIM COMBINATION - LEATHER, MINK/COCOA |
| 54I | INTERIOR TRIM - MINK/COCOA |
| 57U | PRIMARY COLOR - EXTERIOR, CYBER GRAY MET (09) |
| 58U | PRIMARY COLOR - EXTERIOR, CARBON FLASH MET (08) |
| 5AZ | ACCESSORY - SAFETY KIT - UNIVERSAL |
| 5SA | PACKAGE - DENALI OPTION 1 |
| 5Y3 | ACCESSORY - TOW BALL - TRAILER HITCH |
| 622 | TRIM COMBINATION - LEATHER, EBONY/MOJAVE |
| 623 | TRIM COMBINATION - LEATHER, EBONY/MOJAVE PERFORATED |
| 62C | TRIM COMBINATION - CLOTH, EBONY/MOJAVE |
| 62I | INTERIOR TRIM - EBONY/MOJAVE |
| 653 | TRIM COMBINATION - LEATHER, COCOA/DUNE |
| 65I | INTERIOR TRIM - COCOA/DUNE |
| 832 | TRIM COMBINATION - LEATHER, DK TITANIUM/LT TITANIUM (2) (07) |
| 833 | TRIM COMBINATION - LEATHER, DK TITANIUM/LT TITANIUM (3) (08) |
| 83C | TRIM COMBINATION - CLOTH, DK TITANIUM/LT TITANIUM (C) (07) |
| 83I | INTERIOR TRIM - DARK TITANIUM/LT TITANIUM (I) (08) |
| 89U | PRIMARY COLOR - EXTERIOR, CRYSTAL CLARET TINTCOAT (505Q) |
| 98U | PRIMARY COLOR - EXTERIOR, WHITE DIAMOND (02) |
| A45 | MEMORY - SEAT ADJUSTER, MIRROR, POWER, DRIVER, PERSONALIZATION |
| ABB | SEAT CONFIGURATION - #2 |
| ABC | SEAT CONFIGURATION - #3 |
| ACO | IDENTIFICATION - ACCESSORY CATALOG OFFERING |
| ACX | ACCESSORY - HIT THE ROAD |
| AG1 | ADJUSTER FRONT SEAT - POWER, MULTI-DIRECTIONAL, DRIVER |
| AG2 | ADJUSTER PASSENGER SEAT - POWER, MULTI-DIRECTIONAL |
| AG3 | ADJUSTER FRONT SEAT - POWER, 8 WAY, 5 POSITION MEMORY, DRIVER |
| AG5 | ADJUSTER PASSENGER SEAT - MANUAL, 2 WAY |
| AH3 | ADJUSTER FRONT SEAT - MANUAL, 4 WAY, DRIVER |
| AH5 | ADJUSTER FRONT SEAT - POWER, 8 WAY, NO MEMORY, DRIVER |
| AH8 | ADJUSTER PASS ST - POWER, 8 WAY |
| AL0 | SENSOR INDICATOR - INFLATABLE RESTRAINT, FRONT PASSENGER/CHILD PRESENCE DETECTOR |
| AM9 | SEAT REAR - SPLIT BACK, FOLDING |
| ANJ | WINDOW TINTED - EXPORT COMPLIANT, NON-DEEP |
| AP9 | NET - CONVENIENCE |
| AQ4 | SEAT REAR |
| AQQ | LOCK CONTROL, ENTRY REMOTE ENTRY, EXTENDED RANGE |
| AQY | RESTRAINT - HEAD, REAR SEAT, HEIGHT ADJUSTABLE |
| AR9 | SEAT - FRONT BUCKET, DELUXE |
| ARN | SEAT THIRD ROW - 60/40 BENCH, MANUAL FOLD |
| AT8 | RESTRAINT PROVISION - CHILD, REAR SEAT, REAR FACING |
| AXE | WINDOW - POWER OPERATED - EXPRESS UP/DOWN DRVR, EXPRESS DOWN PASSENGER REAR DISABLE |
| AXP | VEHICLE TYPE - MULTI-PURPOSE PASSENGER VEHICLE |
| AXX | VEHICLE TYPE - VEHICLE TYPE - NOT REQUIRED |
| AY0 | RESTRAINT SYSTEM - SEAT, INFLATABLE, DRIVER & PASS FRT, SEAT SIDE, ROOF SIDE |
| AYQ | RESTRAINT SYSTEM - SEAT, INFLATABLE, DRIVER & PASS FRT, FRT SEAT SIDE, FRT INBOARD SEAT SIDE, ROOF SIDE |
| B37 | COVERING - FLOOR MAT, FRT & RR, AUX |
| B3V | TEST - EXTENDED WATER |
| B56 | MOLDING ROCKER - BODY COLOR |
| B6A | MOLDING ROCKER - CUSTOM, BODY COLOR |
| B71 | MOLDING WHL OPENING - COLORED |
| B86 | MOLDING B/S - BODY COLOR |
| B88 | MOLDING B/S - CUSTOM |
| B8K | PLATE - DOOR SILL CVR "DENALI" |
| BAG | PARTS PKG - EXPORT |
| BDF | COVERING - FLOOR MAT FRT DELUXE |
| BS1 | INSULATION - ACOUSTICAL PACKAGE |
| BS2 | INSULATION - ACOUSTICAL PACKAGE, ADDED MATERIAL |
| BTV | CONTROL - REMOTE ENGINE START |
| C3U | ROOF - SUN, GLASS, SLIDING, ELECTRIC, TRANSPARENT GLASS FIXED |
| C67 | HVAC SYSTEM - AIR CONDITIONER FRONT, ELECTRONIC CONTROLS |
| C98 | MODULE - INFLATABLE RESTRAINT SUPPRESSION |
| CJ2 | HVAC SYSTEM - AIR CONDITIONER FRONT, AUTO TEMPERATURE CONTROL, AUXILIARY TEMPERATURE CONTROL |
| CU7 | COUNTRY - KUWAIT |
| CU8 | COUNTRY - SAUDI ARABIA |
| CV3 | COUNTRY - MEXICO |
| CV4 | COUNTRY - ISRAEL |
| CV6 | COUNTRY - CHILE |
| CW2 | COUNTRY - GULF AREAS (BAHRAIN, KUWAIT, OMAN, QATAR, SAUDI ARABIA, UAE) |
| CW4 | COUNTRY - CARIBBEAN (ANTIGUA, ANTILLES, BAHAMAS, BARBADOS, BERMUDA, CAY, HAITI, DMINCN, JAMAICA, NASSAU, S.M., TRINIDAD) |
| CX2 | COUNTRY - COLOMBIA |
| CX3 | COUNTRY - ECUADOR |
| CZ1 | COUNTRY - CENTRAL AMERICA (BELIZ, COSTA RICA, EL SALVADOR, GUATEMALA, HONDURAS, NICARAGUA, PANAMA) |
| CZ2 | COUNTRY - CHINA |
| D2D | COUNTRY - PHILIPPINES |
| D7E | TRAY - LOAD FLOOR, STORAGE |
| DCP | PROCESSING - DIRECTIONS AND CONNECTIONS SERVICE PACKAGE |
| DD8 | MIRROR INSIDE REARVIEW - LIGHT SENSITIVE |
| DL6 | MIRROR OUTSIDE - LEFT AND RIGHT, REMOTE CONTROL, ELECTRIC, MANUAL FOLDING, COLOR |
| DLT | PLANT CODE - LANSING DELTA TOWNSHIP, MI |
| DM8 | MIRROR O/S - LH & RH, REMOTE CONTROL, ELECTRIC, HEATED, MANUAL FOLDING, TURN SIG IND, LT SENSITIVE/DRIVER, COLOR |
| DNP | MIRROR OUTSIDE - LEFT AND RIGHT, REMOTE CONTROL, ELECTRIC, HEATED, POWER FOLDING, TURN SIGNAL INDICATOR, LIGHT SENSITIVE/DRIVER, COLOR |
| DS3 | MIRROR OUTSIDE - LEFT AND RIGHT, REMOTE CONTROL, ELECTRIC, HEATED, MANUAL FOLDING, TURN SIGNAL INDICATOR, COLOR |
| DTM | MIRROR AUX - O/S, RH & LH, MFOV |
| EF7 | COUNTRY - UNITED STATES OF AMERICA (USA) |
| EXP | EXPORT |
| FCN | FREQUENCIES - CHINA |
| FE2 | SUSPENSION SYSTEM - RIDE, HANDLING |
| FE9 | CERTIFICATION - EMISSION, FEDERAL |
| GVU | PRIMARY COLOR - EXTERIOR, MOCHA BRONZE MET (518Q) |
| GW5 | RATIO - TRANSAXLE FINAL DRIVE 3.16 |
| GWT | PRIMARY COLOR - EXTERIOR, CHAMPAGNE SILVER MET (102V) |
| GWY | PRIMARY COLOR - EXTERIOR, ATLANTIS MET (106V) |
| GXG | PRIMARY COLOR - EXTERIOR, IRIDIUM MET (121V) |
| GZV | GVW RATING - 6, 411 LBS/2, 908 KG |
| GZW | GVW RATING - 6, 459.5 LBS/2, 930 KG |
| I14 | ENGINEERING YEAR - 2014 |
| IP2 | TRIM - INTERIOR DESIGN (P2) |
| IP3 | TRIM - INTERIOR DESIGN (P3) |
| IPC | TRIM - INTERIOR DESIGN (PC) |
| JJD | INSTRUMENT PANEL SUBASSEMBLY - NOT INSTALLED (MODULAR OPTIMIZATION METHOD ONLY) |
| JJJ | SUSPENSION FRONT - INSTALLED (MODULAR OPTIMIZATION METHOD ONLY) |
| JJK | SUSPENSION REAR - INSTALLED (MODULAR OPTIMIZATION METHOD ONLY) |
| JJS | CONSOLE FRONT FLOOR - NOT INSTALLED (MODULAR OPTIMIZATION METHOD ONLY) |
| JL9 | BRAKE SYSTEM - POWER, FRONT AND REAR DISC, ANTILOCK, FRONT AND REAR WHEEL |
| K05 | HEATER ENGINE - BLOCK |
| K34 | CRUISE CONTROL - AUTOMATIC, ELECTRONIC |
| KA1 | HEATER - SEAT, FRONT |
| KB6 | HEATER - SEAT, COOLING, FRONT |
| K16 | RECEPTACLE - ELECTRICAL, FRT CONSOLE RR 110 VOLT |
| KI7 | RECEPTACLE - ELECTRICAL, FRT CONSOLE RR 230 VOLT |
| KJ1 | LANGUAGE LABEL - CHINESE/ENGLISH |
| KV1 | INVERTER - POWER PORT, 110 VOLT |
| KW7 | GENERATOR - 170 AMP |
| KYQ | GOVERNOR - VEHICLE SPEED - 200 KILOMETERS/125 MPH |
| LLT | Engine - Gas, 6 Cylinder, 3.6L, SIDI, V6, Aluminum, 60°, 224 KW, GM |
| M7V | TRANSMISSION - AUTO 6 SPD, 6T75, FWD, GEN 2 |
| M7X | TRANSMISSION - AUTO 6 SPD, 6T75, AWD, GEN 2 |
| N05 | LOCK CONTROL - FUEL FILLER CAP |
| N30 | STEERING WHEEL - DELUXE |
| N37 | STEERING COLUMN - TILT, TELESCOPING |
| N38 | STEERING COLUMN - TILT, TELESCOPING, POWER |
| N3R | STEERING WHEEL - URETHANE |
| NB5 | EXHAUST SYSTEM - SINGLE |
| NE1 | CERTIFICATION - EMISSION, GEOGRAPHICALLY RESTRICTED REGISTRATION FOR VEHICLES UP TO 14, 000 LBS GVW |
| NE9 | EMISSION SYSTEM - EEC 09 |
| NEA | EXHAUST SYSTEM - DUAL TAILPIPE EXTENSIONS, BRIGHT |
| NEB | EXHAUST SYSTEM - DUAL TAILPIPE EXTENSIONS, NON-BRIGHT |
| NK5 | STEERING WHEEL - STANDARD |
| NP5 | STEERING WHEEL - LEATHER WRAPPED |
| NPM | EXHAUST SYSTEM - DUAL DOWNTURN TAILPIPE |
| NT7 | EMISSION SYSTEM - FEDERAL, TIER 2 |
| NU5 | EMISSION SYSTEM - CALIFORNIA, BIN 4 |
| NV7 | STEERING - POWER, VARIABLE EFFORT |
| NW9 | TRACTION CONTROL - ELECTRONIC |
| NX7 | WHEEL - 17 X 7.5, J, STEEL |
| P34 | TIRE AND WHEEL SPARE |
| P6A | WHEEL - 19 X 7.5 ALUMINUM, CHROME CLAD |
| PEJ | WHEEL - 20 X 7.5, J, ALUMINUM, PAINTED SPOKES, BRIGHT RIM |
| PPE | WHEEL - 20 X 7.5 ALUMINUM, CHROME, TECH |
| PZ3 | WHEEL - 18 X 7.5 ALUMINUM, PAINTED |
| QCW | TIRE ALL - P255/60R19-108H BW TL AL3 |
| QD5 | WHEEL SPARE - COMPACT, ALUMINUM |
| QD6 | WHEEL SPARE - COMPACT, STEEL |
| QLW | TIRE ALL - P255/65R18-109S BW TL ALS |
| QPR | TIRE ALL - P245/70R17 SL 108S BW ALS |
| QQD | TIRE ALL - P255/55R20-107H BW TL AL3 |
| QS6 | WHEEL - 18 X 7.5, J, ALUMINUM, MACHINED |
| QUP | TIRE ALL - P255/60R19-108S BW TL ALS |
| R6V | CONTROL - SALES ITEM NO. 21 |
| RCA | CONTROL - REAR CARGO, RADIO, REDUNDANT |
| RCM | WHEEL - 20 X 7.5, J, ALUMINUM, ULTRABRITE |
| RSZ | WHEEL - 18 X 7.5, J, ALUMINUM, DESIGN 1 |
| RVG | ACCESSORY - ADAPTER - TRAILER HARNESS |
| RVX | ACCESSORY - BALL MOUNT - TRAILER HITCH |
| RWP | ACCESSORY - CABLE - PORTABLE MUSIC PLAYER |
| RWS | ACCESSORY - FLOOR MATS - CARPET |
| RWU | ACCESSORY - CARGO AREA ORGANIZER - COLLAPSIBLE |
| RXH | ACCESSORY - CENTER CAP - WHEEL - DESIGN 1 |
| RXJ | ACCESSORY - CENTER CAP - WHEEL - DESIGN 2 |
| RYJ | SHADE - CARGO AREA, RETRACTABLE |
| RZA | WHEEL - 19 X 7.5, J, ALUMINUM, DESIGN 2 |
| RZW | ACCESSORY - HARNESS - TRAILER HITCH |
| S02 | ACCESSORY - HEADPHONES - NOISE CANCELING |
| S08 | ACCESSORY - HIGHWAY SAFETY KIT |
| S0A | ACCESSORY - HOLDER - LICENSE PLATE |
| S0M | ACCESSORY - ILLUMINATED DOOR SILLS |
| S1V | ACCESSORY - HEADPHONES - RSE |
| S44 | ACCESSORY - LOCKING PIN - TRAILER HITCH |
| S45 | ACCESSORY - LUG NUT AND WHEEL LOCK KIT |
| S49 | ACCESSORY - LUGGAGE RACK - ROOF MOUNTED |
| S4Q | WHEEL - 20 X 7.5, J, ALUMINUM, DESIGN 2 |
| S6P | ACCESSORY - REMOTE START KIT |
| S6Q | ACCESSORY - ROADSIDE ASSISTANCE PACKAGE |
| SA9 | ACCESSORY - SIDE RAILS - ROOF RACK |
| SAO | ACCESSORY - SMOKERS PACKAGE |
| SDS | ACCESSORY - WEATHER DEFLECTORS - SIDE WINDOW - SMOKED |
| SED | ACCESSORY - WHEEL - 19" - ALUMINUM - DESIGN 1 |
| SFE | ACCESSORY - WHEEL LOCKS |
| SFV | ACCESSORY - WIRELESS NETWORK INTERFACE MODULE |
| T26 | HEADLAMPS - HEADLAMPS STEERABLE HEADLIGHTS, CHINA VERSION |
| T43 | SPOILER - REAR |
| T61 | LAMP SYSTEM - DAYTIME RUNNING |
| T62 | LAMP SYSTEM - DAYTIME RUNNING - DELETE |
| T79 | LAMP - FOG, REAR |
| T83 | HEADLAMPS CONTROL - AUTOMATIC ON-OFF |
| T89 | LAMP - TAIL AND STOP, EXPORT |
| T96 | LAMP - FRONT FOG, FMVSS |
| T97 | HEADLAMPS - HIGH INTENSITY DISCHARGE (XENON) |
| T98 | STAMPING - VEHICLE IDENTIFICATION NUMBER |
| TB4 | BODY EQUIPMENT - LIFT GATE, MANUAL |
| TB5 | BODY EQUIPMENT - LIFT GATE, POWER |
| TGJ | LANGUAGE CONTROL - ENGLISH, FRENCH, CHINESE |
| TR8 | REFLECTOR - WARNING, DISABLED VEHICLE |
| TSH | HEADLAMPS - STEERABLE HEADLIGHTS |
| TVD | HEADLAMPS - HID PROJECTOR LOW BEAM, HALOGEN PROJECTOR HI BEAM |
| U05 | HORN - DUAL |
| U19 | SPEEDOMETER - INSTRUMENT, KILOMETERS AND MILES, KILOMETER ODOMETER |
| U2J | DIGITAL AUDIO SYSTEM - S-BAND, NOT INSTALLED |
| U2K | DIGITAL AUDIO SYSTEM - S-BAND |
| U42 | ENTERTAINMENT PACKAGE - REAR SEAT, SINGLE DISPLAY, REMOTE CONTROL, AUXILIARY JACK, 2 - WIRELESS DUAL CHANNEL HEADPHONES |
| U80 | DISPLAY - COMPASS |
| UA1 | BATTERY - HIGH CAPACITY, WET |
| UBS | DIGITAL AUDIO SYSTEM - S-BAND AND TRAFFIC |
| UC1 | SPEEDOMETER - INSTRUMENT, MILES |
| UC2 | SPEEDOMETER - INSTRUMENT, KILOMETER AND MILES, KILOMETER ODOMETER, POSITIVE BIAS |
| UD4 | ALARM - VEHICLE SPEED, 120 KM/H |
| UD7 | SENSOR INDICATOR - REAR PARKING ASSIST |
| UE0 | COMMUNICATION SYSTEM - VEHICLE, GPS - NOT INSTALLED |
| UE1 | COMMUNICATION SYSTEM - VEHICLE, GPS 1 |
| UFT | SENSOR INDICATOR - SIDE OBSTACLE DETECTION |
| UG1 | OPENER - GARAGE DOOR, UNIVERSAL |
| UG4 | RADIO - AM/FM/XM, TOUCHSCREEN, CONNECTED, HD, CD, AUX JACK, USB PORT |
| UGU | RADIO - AM/FM/XM, TOUCHSCREEN, CONNECTED, HD, CD, DVD, AUX JACK, USB PORT, DVD RSE |
| UGX | RADIO - AM/FM/XM, TOUCHSCREEN, NAVIGATION, CONNECTED, HD, CD, DVD, AUX JACK, USB PORT, DVD, RSE |
| UGY | RADIO - AM/FM/XM, TOUCHSCREEN, NAVIGATION, CONNECTED, HD, CD, AUX JACK, USB PORT |
| UH8 | CLUSTER - INSTRUMENT, COOL TEMPERATURE, TRIP ODOMETER, TACHOMETER |
| UH9 | CLUSTER - INSTRUMENT, COOL TEMPERATURE, TRIP ODOMETER, TACHOMETER, DRIVER INFORMATION CENTER |
| UHU | RADIO - AM/FM/XM, TOUCHSCREEN, NON-CONNECTED, HD, CD, AUX JACK, USB PORT |
| UJ2 | INDICATOR - ENGINE OIL LIFE |
| UJ5 | ACCESSORY - DVD ENTERTAINMENT SYSTEM - HEADREST - DUAL |
| UJL | RADIO - AM/FM/XM, TOUCHSCREEN, NON-CONNECTED, HD, CD, AUX JACK, USB PORT, DVD RSE |
| UJM | TIRE PRESS INDICATOR MANUAL LEARN |
| UK3 | CONTROL - STEERING WHEEL, ACCESSORY |
| UL2 | FREQUENCIES - EUROPEAN |
| UL4 | FREQUENCIES - SOUTH AMERICA |
| UL8 | FREQUENCIES - SAUDI ARABIAN |
| ULD | AUDIO CONTROL REAR SEAT AND EARPHONE JACKS, DISPLAY |
| UPF | WIRELESS INTERFACE - SHORT RANGE, VOICE REC |
| UQA | SPEAKER SYSTEM - PREMIUM AUDIO BRANDED WITH AMPLIFIER |
| UQF | SPEAKER SYSTEM - STANDARD AUDIO |
| UQS | SPEAKER SYSTEM - PREMIUM AUDIO BRANDED WITH SURROUND AMPLIFIER |
| UUD | ANTENNA - HEX FIXED, 200 MM MAST, AM/FM SATELLITE AND GPS |
| UUF | ANTENNA - QUAD FIXED, 200 MM MAST, AM/FM AND GPS |
| UUI | RADIO AM/FM STEREO, SEEK/SCAN, CD AUTO TONE, CLOCK, ETR MP3, RDS, USB PORT |
| UV6 | DISPLAY - HEAD UP |
| UVC | CAMERA - REAR VIEW |
| UVD | HEATER - STEERING WHEEL |
| UVF | CAMERA - FRONT MODULE (DO NOT USE AFTER MY15) |
| V08 | COOLING SYSTEM - HEAVY DUTY |
| V2P | LUGGAGE CARRIER - RF RAIL |
| V6K | LUGGAGE CARRIER - ROOF RAIL, BRIGHT CHROME |
| V78 | VEHICLE STATEMENT - (NONE) |
| V8C | VEHICLE STATEMENT - MEXICO |
| V8D | VEHICLE STATEMENT - US |
| V8I | VEHICLE STATEMENT - ISRAEL |
| V92 | TRAILER PROVISIONS |
| VAV | ACCESSORY - FLOOR MATS - ALL WEATHER |
| VBX | LANGUAGE LABEL - ARABIC |
| VC5 | LABEL - SHIPPING, EXCEPT US, US POSSESSIONS OR JAPAN |
| VFF | VIDEO FORMAT - REGION 1, NTSC |
| VFJ | VIDEO FORMAT - REGION 2, PAL |
| VFK | VIDEO FORMAT - REGION 3, NTSC |
| VFM | VIDEO FORMAT - REGION 4, NTSC |
| VFQ | VIDEO FORMAT - REGION 6, PAL |
| VG1 | PROTECTOR - UNDERHOOD COMPOUND, CORROSION PREVENTIVE, WATER BASED, CLEAR |
| VG4 | PROTECTOR - UNDERVEHICLE COMPOUND, CORROSION PREVENTIVE, WATER BASED, BLACK |
| VGC | PROTECTOR - FILM, PAINT ETCH PREVENTIVE |
| VH9 | ENVELOPE - OWNER INFORMATION MANUAL |
| VHQ | FASCIA - FRT, CUSTOM, CHROME |
| VK3 | LICENSE PLATE FRONT - FRONT MOUNTING PACKAGE |
| VKN | ACCESSORY - FLOOR MATS - ALL WEATHER - 3RD ROW |
| VL2 | LABEL, SPARE - CAUTION, COMPACT SPARE |
| VL5 | LICENSE PLATE - REAR MOUNTING PACKAGE, EXPORT |
| VLF | LICENSE PLATE FRONT - FRONT MOUNTING PACKAGE, CHINA |
| VLI | ACCESSORY - MAT - TRUNK/CARGO AREA |
| VPH | VEHICLE PREPARATION - OVERSEAS DELIVERY |
| VPM | MODIFICATION - NOISE CONTROL, MEXICO |
| VQK | ACCESSORY - SPLASH GUARDS - CUSTOM MOLDED |
| VQL | ACCESSORY - FUEL DOOR - DESIGN 1 |
| VQM | ACCESSORY - ASSIST STEPS - CHROME |
| VQP | ACCESSORY - CROSS RAILS - ROOF RACK - INTEGRATED - BRIGHT |
| VQQ | ACCESSORY - CROSS RAILS - ROOF RACK - INTEGRATED - BLACK |
| VQR | ACCESSORY - CARGO SHADE AND NET CONVENIENCE PACKAGE |
| VR2 | TRAILER HITCH - FACTORY INSTALLED |
| VR6 | HOOK - TIE-DOWN SHIPPING |
| VRK | VAA/COMPONENT REL - ROOF TRIM |
| VRS | ACCESSORY - CARGO SECURITY SHADE |
| VT7 | OWNERS MANUAL - ENGLISH LANGUAGE |
| VUB | ACCESSORY - ULTIMATE ENTERTAINMENT PACKAGE |
| VXH | ACCESSORY - ASSIST STEPS - TUBULAR - CHROME - OVAL |
| VXW | ACCESSORY - ASSIST STEPS - MOLDED |
| VZ3 | LABEL - MERCURY DISPOSAL NOTIFICATION |
| VZE | VIN MODEL YEAR - 2014 |
| VZR | ACCESSORY - WHEEL - 20" - ALLOY - CHROME 6 DOUBLE SPOKE DESIGN |
| VZS | ACCESSORY - WHEEL - 20" - ALLOY - CHROME - 6 THIN DOUBLE SPOKE DESIGN |
| VZU | ACCESSORY - WHEEL - 20" - ALLOY - CHROME - 12 SPOKE DESIGN |
| W2D | ACCESSORY - CARGO NET |
| W49 | MARKET BRAND - BUICK |
| X88 | MARKET BRAND - CHEVROLET |
| XL7 | FREQUENCIES RATING 315 MHZ, LONG DISTANCE |
| XL8 | FREQUENCIES RATING - 433 MHZ |
| Y91 | MERCHANDISED PACKAGE - LUXURY EDITION |
| Y92 | MERCHANDISED PACKAGE - SPECIAL EDITION |
| Y93 | MERCHANDISED PKG - GLS |
| Y94 | MERCHANDISED PKG - CD |
| YF5 | CERTIFICATION - EMISSION, CALIFORNIA |
| YM8 | IDENTIFICATION - LIMITED PERSONALIZATION OPTION (LPO) |
| Z49 | EXPORT - CANADIAN MODIFIED MANDATORY BASE EQUIPMENT |
| Z5X | MIRROR PROVISIONS - ARABIC LANGUAGE |
| Z88 | MARKET BRAND - GMC |
RPO Code List
Metric Fasteners
This vehicle provides fastener dimensions using the metric system. Most metric fasteners are approximate in diameter to equivalent English fasteners. Make replacements using fasteners of the same nominal diameter, thread pitch and strength.
A number marking identifies the OE metric fasteners except cross-recess head screws. The number also indicates the strength of the fastener material. A Posidrive® or Type 1A cross-recess identifies a metric cross-recess screw. For best results, use a Type 1A cross-recess screwdriver or equivalent, in Posidrive® recess head screws.
GM Engineering Standards and North American Industries have adopted a portion of the ISO-defined standard metric fastener sizes. The purpose was to reduce the number of fastener sizes used while retaining the best thread qualities in each thread size. For example, the metric M6.0 X 1 screw, with nearly the same diameter and 25.4 threads per inch replaced the English 1/4-20 and 1/4-28 screws. The thread pitch is midway between the English coarse and fine thread pitches.
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | English Bolt, Grade 2 (Strength Class) |
| 2 | English Bolt, Grade 5 (Strength Class) |
| 3 | English Bolt, Grade 7 (Strength Class) |
| 4 | English Bolt, Grade 8 (Strength Class) |
| 5 | Metric Nut, Strength Class 9 |
| 6 | Metric Bolts, Strength Class Increases as Numbers Increase |
The most commonly used metric fastener strength property classes are 9.8 and 10.9. The class identification is embossed on the head of each bolt. The English, inch strength classes range from grade 2 to grade 8. Radial lines are embossed on the head of each bolt in order to identify the strength class. The number of lines on the head of the bolt is 2 lines less than the actual grade. For example, a grade 8 bolt will have 6 radial lines on the bolt head. Some metric nuts are marked with a single digit strength identification number on the nut face.
The correct fasteners are available through GM SPO. Many metric fasteners available in the aftermarket parts channels are designed to metric standards of countries other than the United States and may exhibit the following
- Lower strength
- No numbered head marking system
- Wrong thread pitch
The metric fasteners on GM products are designed to new, international standards. The following are the common sizes and pitches, except for special applications
- M6.0 X 1
- M8 X 1.25
- M10 X 1.5
- M12 X 1.75
- M14 X 2.00
- M16 X 2.00
Thread Inserts
General Purpose Thread Repair Kits.
These kits are available commercially.
Scheme 6
Scheme 7
- Determine the size, the pitch and the depth of the damaged thread. If necessary, adjust the stop collars on the cutting tool and tap to the required depth. WARNING: Refer to «Safety Glasses Warning»(ref-610030-S11562800352014042100000) . NOTE: Refer to the thread repair kit manufacturer's instructions regarding the size of the drill and tap to use. Avoid any buildup of chips. Back out the tap every few turns and remove the chips.
- Drill out the damaged threads. Clean out any chips.
- Lubricate the tap with light engine oil. Tap the hole. Clean the threads.
- Thread the thread insert onto the mandrel of the installer. Engage the tang of the insert onto the end of the mandrel.
- Lubricate the insert with light engine oil, except when installing in aluminum and install the insert. NOTE: The insert should be flush to one turn below the surface.
- If the tang of the insert does not break off when backing out the installer, break the tang off with a drift.
Registered and Non-Registered Trademarks
Listed below are Registered Trademarks(®) or Non-Registered Trademarks(™) which may appear in this service manual.
| A |
|---|
| AC® |
| ACCUTURN® |
| ACDelco® |
| Active Fuel Management™ |
| Acuzinc® |
| Airbank® |
| Allison® |
| AMMCO® |
| AUTOFUSE® |
| AUTOTRAC® |
| B |
| Bendix® |
| Bluetooth® |
| BON-AMI® |
| Bosch® |
| Bose® |
| C |
| Caterpillar® |
| CAT® |
| C-Quam® |
| D |
| Delco® |
| Delco Bose® |
| Delco Electronics® |
| Delco Freedom® |
| Delco LOC II® |
| Delco Moraine® |
| Delco Remy® |
| Delco Sound® |
| Delco Supreme® |
| Delco Tech® |
| DELCORE® |
| Delphi® |
| DEX-COOL® |
| DEXOIL® |
| DEXRON® |
| DEXSTEER™ |
| DNR® |
| Dolby® |
| DR® |
| Duracell® |
| Duraguard® |
| Durastop® |
| Duramax™ |
| E |
| Eaton Corporation® |
| EMD® |
| ETR® |
| F |
| FLO-LITE® |
| G |
| General Motors® |
| GM® |
| GM Goodwrench Service® |
| GM Optikleen® |
| GM Parts™ |
| GM Pass® |
| GM Ultralite® |
| GMAC® |
| Goodwrench® |
| GTP® |
| H |
| Homelink™ |
| HYDRA-MATIC® |
| I |
| Illumination® |
| INSTA-TRAC® |
| Intune® |
| L |
| LOCTITE™ |
| Lord Fusor™ |
| M |
| MAGNASTEER® |
| Maxifuse® |
| Metripack® |
| Micropack® |
| Minifuse® |
| Mr Goodwrench® |
| N |
| Northstar® |
| O |
| OnStar® |
| Optikleen® |
| P |
| PASS-KEY® |
| PASS-KEYII® |
| PASSLOCK™ |
| PK3® |
| Posidrive® |
| Pro® |
| Q |
| Quad 4® |
| R |
| RAINSENSE™ |
| Rapid Fire® |
| S |
| ScotchBrite™ |
| Scotchguard™ |
| Signals® |
| Sikkens™ |
| Soft-Ray® |
| Solar-Ray® |
| Stabilitrak® |
| Sunrayce® |
| Superlube® |
| Syclone® |
| T |
| Tech 2® |
| Techline® |
| Teflon® |
| Tefzel® |
| Theft-I® |
| Theftlock® |
| Tiltmaster® |
| TORX® |
| Transjel® |
| Transguide® |
| Twilight Sentinel® |
| U |
| Ultralite® |
| V |
| Velcro® |
| W |
| Weatherpack™ |
Registered and Non-Registered Trademarks
Ignition Lock Cylinder
The ignition lock cylinder uses only 7 of the 10 cut positions, 2 through 8. The ignition cylinder tumblers (3) are located on alternate sides of the cylinder (1). They are snap-in and self-retaining. It follows the key code with the first tumbler being the first depth of the key code, closest to the head of the key.
Scheme 8
- Hold the ignition cylinder assembly (1) so the side with the tumbler spring pocket located closest to the head of the cylinder is facing up.
- Insert the tumbler spring (2) into each of the 4 spring pockets of the cylinder assembly.
- The first tumbler (3) to be loaded will be the second key cut position, which is the second number in the key code. Install the first tumbler in the slot over the spring. Install the remaining tumblers for cuts 4, 6 and 8 following the key code and same process, pressing the tumblers in place until they are secure.
- Rotate the cylinder assembly. Insert the tumbler spring into each of the spring pockets of the cylinder assembly.
- The first tumbler to be loaded will be the third key cut position, the third number in the key code. Install the first tumbler in the slot over the spring. Install the remaining tumblers for cuts 5 and 7 following the key code and same process, pressing the tumblers in place until they are secure.
- Inspect for correct loading of the tumblers by inserting the key into the cylinder. All tumblers should drop flush with the lock cylinder body diameter.
- Lightly lubricate the outside surface in the tumbler area of the lock body and down the key slot using the provided grease. Insert and extract the key 5 times to lubricate the keyway.
- With the key in the cylinder assembly, insert the actuator (4) in the actuator pocket and hold. Rotate the cylinder assembly and insert the retainer spring (6) in the retainer slot located in the cylinder assembly. Insert the retainer (7) lining it up in the slot over the spring. Depress the retainer and hold.
- Insert the cylinder into the sleeve (5) as shown in the print. Make sure the actuator stays located properly in the cylinder.
- When the key is removed, the lock should stay together.
- Insert the key and function the lock 3 times to distribute the grease inside the sleeve.
- Verify the key position for inserting the lock into the column.
Door Lock Cylinder
The door lock cylinder only uses 7 of the 10 cut positions, 4 through 10. The tumbler positions are staggered from side to side, 4 on one side and 3 on the other are self-retaining. The left and right door lock cylinders are identical. The lever assembly determines which side of the vehicle the lock cylinder is for. After removing the current lock, record which lever is used and the orientation of the rod clip.
Scheme 9
- Rotate the cylinder (1) so the side with the 4 tumblers spring wells faces up.
- Insert the tumblers springs (2) into the 4 spring wells.
- Install the tumbler (3) for key cut position 4 in the slot closest to the cylinder head. Install the remaining tumblers, key cut positions 6, 8, 10, following the key code and same process. Press tumblers in place until they are secure.
- Check the correct loading of the tumblers by inserting the key into the cylinder. All tumblers should be flush with the lock cylinder body.
- Turn the cylinder so the side with the 3 tumblers spring wells faces up.
- Insert the tumbler springs into the 3 spring wells.
- The first tumbler closest to the front of the lock cylinder to be loaded will be the fifth key cut position. Install the remaining tumblers for the key cut positions 7 and 9. Press tumblers in place until they are secure.
- Check the correct loading of the tumblers by inserting the key into cylinder. All of the tumblers should be flush with the lock cylinder body.
- Apply lubricant to cylinder body and tumbler surfaces along with a small amount in head of cylinder using the supplied grease.
- Install 2 springs (4) into the spring wells in head section of lock cylinder.
- Snap the shutter assembly (5) into the cylinder.
- Place the detent spring (6) into the spring well located on side of cylinder.
- Carefully place the detent ball (7) on detent spring. Depress the detent ball into the cylinder and assemble into case (8). Detent ball should rest in case slot at front of case.
- Align dimples of the cylinder cap (9) with the 4 recesses in the cap. Secure by pressing the cap into place with light hand pressure.
- If required, assemble rod clip to lever (10) using the recorded lever information.
- Assemble lever to lock. Use e-clip (11) to retain lever assembly.
- Insert the key into the lock and function lock to check for proper assembly and smooth operation.
Lifting and Jacking the Vehicle
| WARNING | To avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed and strap the vehicle to the hoist. |
| CAUTION | When you are jacking or lifting a vehicle at the frame side rails or other prescribed lift points, be certain that the lift pads do not contact the catalytic converter, the brake pipes or the fuel lines. If such contact occurs, vehicle damage or unsatisfactory vehicle performance may result. |
| CAUTION | Perform the following steps before beginning any vehicle lifting or jacking procedure: Remove or secure all of the vehicle contents in order to avoid any shifting or any movement that may occur during the vehicle lifting or jacking procedure. The lifting equipment or the jacking equipment weight rating must meet or exceed the weight of the vehicle and any vehicle contents. The lifting equipment or the jacking equipment must meet the operational standards of the lifting equipment or jacking equipment manufacturer. Perform the vehicle lifting or jacking procedure on a clean, hard, dry, level surface. Perform the vehicle lifting or jacking procedure only at the identified lift points. DO NOT allow the lifting equipment or jacking equipment to contact any other vehicle components. Failure to perform the previous steps could result in damage to the lifting equipment or the jacking equipment, the vehicle and/or the vehicle contents. |
Scheme 10
Vehicle Lifting-Frame Contact Lift
Front Lift Pads
When lifting the vehicle with a frame-contact lift, place the front lift pads on the torque box, inboard of the rocker inner panel and outboard of the engine cradle rear mounting location.
Rear Lift Pads
When lifting the vehicle with a frame contact lift, place the rear lift pads on the inner rocker panel, on or near the shipping tie down locations.
Scheme 11
| CAUTION | When you are jacking the vehicle at the front locations, be certain that the jack or the jack lift pad does not contact the front fascia, front fascia air dam or the front fenders. If such contact occurs, vehicle damage may result. When jacking at selected front locations additional clearance may be required for the jacking points. |
Note. When you are lifting a vehicle with a service jack, block the wheels at the opposite end from which you are lifting. Use jackstands to provide additional support.
Front of the Vehicle
When using a service jack under the front of the vehicle use one of the following locations
- Place the service jack pad under the rear portion of the engine cradle near the torque box locations.
- Place the service jack under the front frame crossmember, as shown.
Rear of the Vehicle
Note. Place jackstands ONLY under strong and stable vehicle structures.
When using a service jack under the rear of the vehicle, place the jack pad on the rear suspension front mounting locations.
