Wiring Systems and Power Management - Component Locator - Front of Vehicle/engine Compartment Component Views Buick Enclave I

Electrical Component Locations 10 illustrations

Scheme 49

Scheme 49: Front Center of the Vehicle
Scheme 49: Front Center of the Vehicle
CalloutComponent Name
1Inflatable Restraint Front End Sensor- Left
2Inflatable Restraint Front End Sensor- Right
3Front Fascia

Scheme 50

Scheme 50: Front of the Condenser
Scheme 50: Front of the Condenser
CalloutComponent Name
1Front Fascia
2Ambient Air Temperature Sensor (CJ2)

Scheme 51

Scheme 51: Front Center of the Core Support
Scheme 51: Front Center of the Core Support
CalloutComponent Name
1Upper Tie Bar
2Hood Ajar Switch (BTV)

Scheme 52

Scheme 52: Front Lighting (X88)
Scheme 52: Front Lighting (X88)
CalloutComponent Name
1Headlamp- Right Low Beam
2Headlamp- Right High Beam
3Park/Turn Signal Lamp- Right
4Side Marker Lamp- Right Front
5Headlamp- Left High Beam
6Headlamp- Left Low Beam
7Side Marker Lamp- Left Front
8Park/Turn Signal Lamp- Left

Scheme 53

Scheme 53: Front of the Vehicle (W49)
Scheme 53: Front of the Vehicle (W49)
CalloutComponent Name
1Park/Side Marker Lamp - Left Front
2Headlamp - Left
3Turn Signal Lamp - Left Front
4Daytime Running Lamp (DRL) - Left (T61)
5Fog Lamp - Left Front (T96)
6Fog Lamp - Right Front (T96)
7Daytime Running Lamp (DRL) - Right (T61)
8Turn Signal Lamp - Right Front
9Headlamp - Right
10Park/Side Marker Lamp - Right Front

Scheme 54

Scheme 54: Front Lights (Z88)
Scheme 54: Front Lights (Z88)
CalloutComponent Name
1Headlamp- Right Low Beam (without TVD) or Headlamp- Left (TVD)
2Headlamp- Right High Beam (without TVD)
3Turn Signal Lamp- Right Front
4Headlamp- Left High Beam (without TVD)
5Turn Signal Lamp- Left Front
6Headlamp- Left Low Beam (without TVD) or Headlamp- Right (TVD)
7Park Lamp- Left Front
8Side Marker Lamp- Left Front
9Fog Lamp- Left Front (T96)
10Fog Lamp- Right Front (T96)
11Park Lamp- Right Front
12Side Marker Lamp- Right Front

Scheme 55

Scheme 55: Left Side of the Engine Compartment
Scheme 55: Left Side of the Engine Compartment
CalloutComponent Name
1Brake Fluid Level Switch
2Electronic Brake Control Module (EBCM)
3Variable Effort Steering Actuator (NV7)
4Brake Booster Vacuum Sensor

Scheme 56

Scheme 56: Right Front of the Engine Compartment
Scheme 56: Right Front of the Engine Compartment
CalloutComponent Name
1Fuse Block- Underhood
2Headlamp- Right

Scheme 57

Scheme 57: Front Center of the Engine Compartment
Scheme 57: Front Center of the Engine Compartment
CalloutComponent Name
1Engine Cooling Fan- Left
2Engine Cooling Fan- Right
3Horn- High Note
4Windshield Washer Fluid Pump
5Rear Window Washer Fluid Pump
6Windshield Washer Fluid Level Switch
7Horn- Low Note

Scheme 58

Scheme 58: Bottom of the Windshield and Left Rear of Engine Compartment
Scheme 58: Bottom of the Windshield and Left Rear of Engine Compartment
CalloutComponent Name
1Windshield
2Windshield Wiper Motor
