Scheme 1

Diagnostic Code Index

DIAGNOSTIC CODE INDEX

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

Circuit/System Description

The cruise control switch is an input to the body control module (BCM). The BCM monitors the cruise control set/coast and resume/accelerate switch signal circuit in order to detect when the driver has requested to perform a cruise control function. The BCM detects a specific voltage signal on the cruise control switch signal circuit when a switch is applied. The BCM sends a serial data message to the engine control module (ECM), indicating the status of the cruise control switches.

Conditions for Running the DTC

1. The ignition is ON.
2. The cruise switch is ON.

Conditions for Setting the DTC

B3794 08

The BCM detects an invalid voltage signal on the cruise control switch signal circuit for 0.5 seconds.

B3794 61

Stuck switch for either Resume/Accel or Set/Coast button for 60 seconds.

Actions Taken When the DTC Sets

1. The malfunction indicator lamp (MIL) will not illuminate.
2. The cruise control system is disabled.

Conditions for Clearing the DTC

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear after 40 malfunction-free ignition cycles have occurred.

Reference Information

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Engine ON, while rotating the steering wheel to both steering stops, observe the scan tool Cruise Control Switch parameter while pressing each of the cruise control switches. The parameter should toggle between On, Off, Resume, Set, and Cancel as the applicable switch is pressed

Circuit/System Testing

1. Ignition OFF, disconnect the harness connector at the steering wheel controls switch - left.
2. Ignition ON, test for B+ between the B+ circuit terminal 1 and ground. If less than the specified value, test the circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
3. Test for B+ between the B+ circuit terminal 1 and the signal circuit terminal 3. If less than the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
4. Ignition OFF, disconnect the X1 harness connector at the BCM.
5. Test for infinite resistance between the signal circuit terminal 3 and ground. If less than the specified value, test the signal circuit for a short to ground.
6. If all circuits test normal, test or replace the steering wheel control switch-left.

Component Testing

1. Disconnect the harness connector at the steering wheel controls switch - left.
2. Cruise control switch ON, measure the resistance between terminal 1 and terminal 3 while individually activating and holding each cruise control function switch and compare the resistance reading to the values in the table below. If not within the specified resistance range, replace the steering wheel controls switch - left.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Traverse)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system) , «Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system)
2. «Control Module References»(/buick/enclave/i-2007-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The cruise control switch is an input to the body control module (BCM). The BCM monitors the cruise control on/off, set/coast, resume/accelerate and cancel switches via the cruise control switch signal circuit in order to detect when the driver has requested to perform a cruise control function. The BCM detects a specific voltage signal on the cruise control switch signal circuit when a switch is applied. The BCM sends a serial data message to the ECM indicating the status of the cruise control switches.

1. The ignition is ON.
2. The cruise switch is ON.

P0564

The ECM detects an invalid voltage signal on the cruise control switch signal circuit for greater than 2 seconds.

P0567

The ECM detects that the Resume switch is applied for longer than 90 seconds.

P0568

The ECM detects that the Set/Coast switch is applied for longer than 90 seconds.

1. The malfunction indicator lamp (MIL) will not illuminate.
2. The cruise control system is disabled.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear after 40 malfunction-free ignition cycles have occurred.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Engine ON, while rotating the steering wheel to both steering stops, observe the scan tool Cruise Control Switch parameter while pressing each of the cruise control switches. The parameter should toggle between On, Off, Resume, and Set as the applicable switch is pressed.

Cruise Control Switch Circuit Malfunction

1. Ignition OFF, disconnect the harness connector at the steering wheel controls switch - left.
2. Ignition ON, test for B+ between the B+ circuit terminal 1 and ground. If less than the specified value, test the circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
3. Test for B+ between the B+ circuit terminal 1 and the signal circuit terminal 3. If less than the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
4. Ignition OFF, disconnect the X1 harness connector at the BCM.
5. Test for infinite resistance between the signal circuit terminal 3 and ground. If less than the specified value, test the signal circuit for a short to ground.
6. If all circuits test normal, test or replace the steering wheel control switch - left.

Steering Wheel Control Switch - Left

1. Disconnect the harness connector at the steering wheel controls switch - left.
2. Cruise control switch ON, measure the resistance between terminal 1 and terminal 3 while individually activating and holding each cruise control function switch and compare the resistance reading to the values in the table below. If not within the specified resistance range, replace the steering wheel controls switch - left.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Traverse)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system) , «Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system)
2. «Control Module References»(/buick/enclave/i-2007-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The brake applied signal circuit is a high voltage input from the body control module (BCM) to the engine control module (ECM) and transmission control module (TCM). The ECM monitors the stop lamp switch circuit to detect when the brake pedal has been applied. The BCM monitors the brake pedal position sensor to determine when the brake pedal is applied. When the brake pedal is applied, the BCM supplies a high voltage signal on the brake applied signal circuit and also sends a serial data message to the ECM indicating that the brake pedal has been applied. The ECM senses a high voltage signal on the brake applied signal circuit when the brake pedal has been applied.

1. The engine is running.
2. Battery voltage is greater than 11.5 V.

The ECM detects either a low voltage signal on the brake applied signal circuit when the serial data message from the BCM indicates the brakes are applied, or a high voltage signal on the brake applied signal circuit when the serial data message from the BCM indicates the brakes are not applied.

1. The malfunction indicator lamp (MIL) will not illuminate.
2. The cruise control system is disabled.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear after 40 malfunction-free ignition cycles have occurred.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the X2 harness connector at the ECM.
2. Connect a test lamp between the control circuit terminal 52 X2 and ground.
3. Ignition ON, verify the test lamp turns ON and OFF when pressing and releasing the brake pedal. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
4. If all circuits test normal, replace the ECM.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for BCM, ECM, or TCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The stop lamp switch signal circuit is a B+ input from the body control module (BCM) to the engine control module (ECM). The ECM monitors the stop lamp switch circuit to detect when the brake pedal has been applied. The BCM monitors the brake pedal position sensor to determine when the brake pedal is applied. When the brake pedal is applied, the BCM supplies B+ on the stop lamp switch signal circuit and also sends a serial data message to the ECM indicating that the brake pedal has been applied.

1. The engine is running.
2. Battery voltage is greater than 11.5 V.

P0572

This DTC will set when the ECM detects a short to ground or an open on the discrete brake signal circuit when the serial data message from the BCM indicates the brakes are applied. This diagnostic will run when the serial data message and the voltage signal on the brake switch signal circuit do not match for 8 out 10 times, and the condition is present for greater than 2 seconds.

P0573

This DTC will set when the ECM detects a short to voltage on the discrete brake signal circuit when the serial data message from the BCM indicates the brakes are NOT applied. This diagnostic will run when the serial data message and the voltage signal on the brake switch signal circuit do not match for 8 out 10 times, and the condition is present for greater than 2 seconds.

1. The malfunction indicator lamp (MIL) will not illuminate.
2. The cruise control system is disabled.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear after 40 malfunction-free ignition cycles have occurred.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the X2 harness connector at the K20 engine control module.
2. Connect a test lamp between the signal circuit terminal 52 and ground.
3. Ignition ON, verify the test lamp turns ON and OFF when pressing and releasing the brake pedal. If the test lamp is always ON, test the signal circuit for a short to voltage. If the circuit tests normal, replace the K9 body control module. If the test lamp is always OFF, test the signal circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the K9 body control module.
4. If all circuits test normal, replace the K20 engine control module.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for BCM or ECM, replacement, programming and setup

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

When a cruise control function switch is activated, the body control module (BCM) detects a predetermined voltage signal. The BCM sends a serial data message to the engine control module (ECM) indicating the function that has been requested.

The ignition is ON.

The ECM receives an invalid cruise control switch status serial data message from the BCM.

1. The cruise control system is disabled.
2. The malfunction indicator lamp (MIL) will not illuminate.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear after 40 malfunction-free ignition cycles have occurred.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Verify that DTC B3794 is not set. If DTC is set, refer to «DTC B3794»(/buick/enclave/i-2007-2013/remont/cruise-control-systems/#cruise-control-system)
2. Road test the vehicle and attempt to engage cruise. Verify that cruise control engages properly and the DTC P0575 is not set. If DTC resets, replace the BCM. Clear the DTC, road test the vehicle and attempt to engage cruise. If the DTC resets, replace the ECM.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for BCM or ECM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The body control module (BCM) monitors the brake pedal position sensor. When the brake pedal is applied, the BCM detects a predetermined voltage signal. The BCM sends a serial data message to the engine control module (ECM) indicating the status of the stop lamps.

The engine is ON.

1. The ECM receives an invalid brake pedal status serial data message from the BCM.
2. This diagnostic runs continuously.

1. The malfunction indicator lamp (MIL) will not illuminate.
2. The cruise control system is disabled.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear after 40 malfunction-free ignition cycles have occurred.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Verify that DTC P0572 or P0573 is not set. If DTC is set, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-trouble-code-dtc-list) .
2. Verify that DTC P0703 is not set. If DTC is set, replace the K9 BCM. Clear the DTC and road test the vehicle. If DTC resets, replace the K20 ECM.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for BCM or ECM replacement, setup, and programming

Symptoms - Cruise Control

1. Before using the symptom diagnostic table, perform the «Diagnostic Trouble Code (DTC) List - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-trouble-code-dtc-list) in order to verify the following conditions: There are no DTCs set. The module can communicate via the GM LAN.
2. Review the system operation in order to understand the system functions. Refer to «Cruise Control Description and Operation»(/buick/enclave/i-2007-2013/remont/cruise-control-systems/#cruise-control-system__cruise-control-description-and-operation) .

Visual/Physical Inspection

1. Inspect for aftermarket devices which can affect the operation of the Cruise Control System. Refer to «Checking Aftermarket Accessories»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories) .
2. Inspect the accessible system components or the visible system components for obvious damage or for obvious conditions which can cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Cruise Control Malfunction»(/buick/enclave/i-2007-2013/remont/cruise-control-systems/#cruise-control-system) .
2. «Cruise Control Switch Indicator Inoperative»(/buick/enclave/i-2007-2013/remont/cruise-control-systems/#cruise-control-system)

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The instrument panel cluster (IPC) illuminates the cruise control engaged indicator based on serial data messages received from the body control module (BCM). The indicator is commanded ON when the cruise control system is controlling vehicle speed, and turned OFF with the system disengaged.

Schematic Reference

1. «Cruise Control Schematics»(/buick/enclave/i-2007-2013/remont/cruise-control-systems/#cruise-control-system)
2. «Instrument Cluster Schematics»(/buick/enclave/i-2007-2013/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges)

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

1. «Cruise Control Description and Operation»(/buick/enclave/i-2007-2013/remont/cruise-control-systems/#cruise-control-system__cruise-control-description-and-operation)
2. «Indicator/Warning Message Description and Operation»(/buick/enclave/i-2007-2013/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges)

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, with a scan tool perform the Lamp Test for the instrument panel cluster (IPC) and observe the cruise control indicator.

1. If the cruise control indicator illuminates during the test, replace the BCM.
2. If the cruise control indicator does not illuminates during the test or remains illuminated at all times, replace the IPC.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for BCM or IPC replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The body control module (BCM) monitors the cruise control indicator switch. When the cruise on/off switch is pressed ON, the cruise control switch is closed and the signal circuit is low. When the cruise on/off switch is pressed OFF, the cruise control switch is open and the signal circuit is high.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the steering wheel controls switch-left.
2. Ignition ON, verify that a test lamp illuminates between the low reference circuit terminal 9 and B+. If the test lamp does not illuminate, test the low reference circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
3. If all circuits test normal, test or replace the steering wheel controls switch-left.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Traverse)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system) , «Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system)
2. «Control Module References»(/buick/enclave/i-2007-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The cruise control switch is an input to the body control module (BCM). The BCM monitors the cruise control switch signal circuit in order to detect when the driver has requested to perform a cruise control function. The BCM detects a specific voltage signal on the cruise control switch signal circuit when a switch is applied.

Schematic Reference

1. «Cruise Control Schematics»(/buick/enclave/i-2007-2013/remont/cruise-control-systems/#cruise-control-system)
2. «Exterior Lights Schematics»(/buick/enclave/i-2007-2013/remont/exterior-lights/#lighting-system)

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Engine ON, while rotating the steering wheel to both steering stops, observe the scan tool Cruise Control Switch parameter while pressing each of the cruise control switches. The parameter should toggle between On, Off, Resume, Set, and Cancel as the applicable switch is pressed.

1. Ignition OFF, disconnect the harness connector at the steering wheel controls switch-left.
2. Ignition ON, test for B+ between the B+ circuit terminal 1 and ground. If less than the specified value, test the circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
3. Test for B+ between the B+ circuit terminal 1 and the signal circuit terminal 3. If less than the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
4. Ignition OFF, disconnect the X1 harness connector at the BCM.
5. Test for infinite resistance between the signal circuit terminal 3 and ground. If less than the specified value, test the signal circuit for a short to ground.
6. If all circuits test normal, test or replace the steering wheel control switch-left.

1. Disconnect the harness connector at the steering wheel controls switch-left.
2. Cruise control switch ON, measure the resistance between terminal 1 and terminal 3 while individually activating and holding each cruise control function switch and compare the resistance reading to the values in the table below. If not within the specified resistance range, replace the steering wheel controls switch-left.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Steering Wheel Control Switch Assembly Replacement (Traverse)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system) , «Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)»(/buick/enclave/i-2007-2013/remont/memory-modules/#secondary-and-configurable-customer-control-system)
2. «Control Module References»(/buick/enclave/i-2007-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

Cruise Control Description and Operation

Cruise control is a speed control system that maintains a desired vehicle speed under normal driving conditions at vehicle speeds above 40 km/h (25 mph). Steep grades may cause variations in the selected vehicle speeds.

The following are the main components of the cruise control system

1. The accelerator pedal
2. The brake pedal position (BPP) sensor
3. The body control module (BCM)
4. The engine control module (ECM)
5. The on/off switch
6. The cancel switch
7. The + RES switch, equivalent to resume/accel switch
8. The - SET switch, equivalent to set/coast switch
9. The vehicle speed sensor

The body control module (BCM) monitors the signal circuit of the cruise control switches, which are located on the steering wheel. The BCM relays the cruise control switch status to the engine control module (ECM) via the GMLAN serial data circuit. The ECM uses the status of the cruise control switch to determine when to capture and maintain the vehicle speed. The ECM monitors the vehicle speed signal circuit in order to determine the desired vehicle speed.

Voltage is supplied to the cruise control switch via the steering wheel control switch reference voltage circuit supplied by the BCM. The cruise control function switches are arranged in a resistive ladder design, with each cruise control function switch having a different resistance value. The BCM detects a specific voltage value that is associated with the cruise control function switch being activated. When the normally open cruise control on/off switch is turned ON, the switch closes and the BCM supplies a ground to the cruise control switch ON indicator circuit as it becomes illuminated. The BCM sends a GMLAN serial data message to the ECM indicating that the on/off switch is active. Similarly, when the normally open + RES switch or the normally open - SET switch are pressed, the switch closes and the BCM detects the predetermined voltage signal on the cruise control resume/accel and set/coast switch signal circuit. The BCM sends a GMLAN serial data message to the ECM indicating that the + RES switch or the - SET switch is active. The + RES switch or the - SET switch will remain inactive when the BCM has not received the predetermined voltage signal from the on/off switch.

Cruise Control Engaged

The cruise control system will engage and adjust vehicle speeds, based on the activation of the following cruise control switches, which are located on the steering wheel

1. On/off
2. + RES
3. SET

To engage the Cruise Control System, ensure that the vehicle speed is above 40.2 km/h (25 mph), turn the cruise On/Off switch ON and momentarily press the - SET switch. The ECM will engage the Cruise Control System and record the vehicle speed. The ECM sends a GMLAN serial data message to the instrument panel cluster (IPC) in order to illuminate the Cruise Engaged indicator in the IPC. The ECM also sends a GMLAN serial data message to the driver information center (DIC) in order to illuminate the CRUISE SET TO ### message.

Pressing the accelerator pedal while the cruise control system is engaged, allows the driver to override the cruise control system in order to accelerate the vehicle beyond the current set vehicle speed. When the accelerator pedal is released, the vehicle will decelerate and resume the current set vehicle speed. The driver can also override the current set vehicle speed via the - SET switch and the + RES switch. When the cruise control system is engaged, pressing and holding the - SET switch will allow the vehicle to decelerate from the current set vehicle speed without deactivating the cruise control system. When the - SET switch is released, the ECM will record the vehicle speed and maintain the vehicle speed as the new set vehicle speed. When the cruise control system is engaged, momentarily pressing the - SET switch will allow the vehicle to decelerate at 1.6 km/h (1 mph) increments for each time that the - SET is momentarily pressed, with a minimum vehicle speed of 37 km/h (23 mph).

Pressing and holding the + RES switch, when the cruise control system is engaged, will allow the vehicle to accelerate to a greater vehicle speed than the current set vehicle speed. When the + RES switch is released, the ECM will record the vehicle speed and maintain the vehicle speed as the new set vehicle speed. When the cruise control system is engaged, momentarily pressing the + RES switch will allow the vehicle to accelerate at 1.6 km/h (1 mph) increments for each time that the + RES switch is momentarily pressed, with the maximum acceleration total of 16 km/h (10 mph) over the current set vehicle speed. Momentarily activating the + RES switch will recall the previous vehicle speed, after the cruise control system is disengaged by pressing the brake pedal or by activating the CANCEL switch.

Cruise Control Disengaged

The engine control module (ECM) disengages the cruise control operation based on the signals from the following switches

1. The on/off switch
2. The cancel switch
3. The brake pedal position (BPP) sensor

The cruise control system will disengage when the brake pedal is applied. The body control module (BCM) monitors the BPP sensor via the BPP sensor signal circuit as the voltage signal increases while the pedal reaches the fully applied position. The ECM monitors the BPP signal through a discrete input and a GMLAN serial data message signal from the BCM indicating the brake status. When both signals indicate the brake pedal is applied, the ECM will disengage the cruise control system. For further information on the BPP sensor, refer to Exterior Lighting Systems Description and Operation .

The cruise control system will also disengage when the cruise control on/off switch is switched OFF, or the cruise control cancel switch is activated. The body control module (BCM) determines when the cruise control cancel switch is activated. When the normally open cancel switch is closed, the BCM detects the predetermined voltage signal on the cruise control function switch circuit. The vehicle speed stored in the memory of the engine control module will be erased when the cruise control On/Off switch is turned OFF, or the ignition switch is turned OFF. The BCM sends a GMLAN serial data message to the ECM in order to disengage the cruise control system. The cruise control system will disengage when the ECM detects that a driver override function has been active for approximately 60 seconds. When the cruise control system has been disengaged, the ECM sends a GMLAN serial message to the instrument panel cluster (IPC) in order to turn OFF the Cruise Engaged indicator. The ECM also sends a GMLAN serial data message to the driver information center (DIC) in order to turn OFF the CRUISE SET TO ### message.

Every time the Cruise Control System is disengaged, the ECM will keep track of the reason for system disengagement. The last 8 disengagement reasons will be recorded within the ECM memory. The scan tool will display the last 8 Cruise Disengage History parameters, in which one out of approximately 50 possible reasons will be displayed in each of these 8 parameters. For the disengagement reason to be displayed within the scan tool parameter either the Cruise Control System is active and disengagement is requested, or engagement of the system is requested but a fault is present. For a list of each disengagement reason along with each definition, refer to Scan Tool Data Definitions Disengage History.

Cruise Control Inhibited

The engine control module (ECM) inhibits the cruise control operation when any of the following conditions exist

1. The ECM has not detected a brake pedal activation from the body control module (BCM).
2. A cruise control related DTC has been set.
3. The antilock brake system/traction control system is active for more than 2 seconds.
4. The engine RPM is too low.
5. The engine RPM is too high.
6. The system voltage is not between 9-16 volts.
7. The vehicle speed is less than 40 km/h (25 mph).
8. The vehicle speed is too high.
9. The vehicle is in PARK, REVERSE, NEUTRAL, or 1st gear.

Cruise Control Inhibit Reasons

This is a general list of inhibit reasons. Not every inhibit reason is applicable to all vehicles. Refer to the scan tool inhibit reason list for the last 8 reasons that have been recorded during the current key cycle.

Cruise Control Description and Operation

See also:
• Diagnostic System Check - Vehicle
• Strategy Based Diagnosis
• Diagnostic Procedure Instructions
• COMPONENT CONNECTOR END VIEWS - INDEX
• Circuit Testing
• Connector Repairs
• Testing for Intermittent Conditions and Poor Connections
• Wiring Repairs
• Control Module References
• Diagnostic Repair Verification
• Steering Wheel Control Switch Assembly Replacement (Traverse)
• Diagnostic Trouble Code (DTC) List - Vehicle
• Checking Aftermarket Accessories
• Instrument Cluster Schematics
• Exterior Lights Schematics
• DTC B3794
• Cruise Control Description and Operation
