Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Accessory AC& DC Power Control Module Nut | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Visual/Physical Inspection
- Inspect for aftermarket devices which can affect the operation of the power outlets. Refer to «Checking Aftermarket Accessories»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories)
- Inspect the accessible system components or the visible system components for obvious damage or for obvious conditions which can cause the symptom.
Intermittent
Electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections
Symptom List
Refer to Power Outlet Receptacle Malfunction (12V DC) , Power Outlet Receptacle Malfunction (110V AC) in order to diagnose the system.
Diagnostic Instructions
- Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
- Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
- «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
Diagnostic Fault Information
| Circuit | Short to Ground | Open/High Resistance | Short to Voltage | Signal Performance |
|---|---|---|---|---|
| B+ | 1 | 1 | ||
| Ground | 1 | |||
| 1. Accessory Power Receptacle Malfunction | ||||
Circuit/System Description
The accessory power receptacles are supplied B+ all the time.
Reference Information
Schematic Reference
Connector End View Reference
Description and Operation
Electrical Information Reference
- «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
- «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
- «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
- «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)
Circuit/System Testing
- Ignition OFF, disconnect the harness connector at the appropriate X80 accessory power receptacle.
- Test for less than 5 ohms between the ground circuit terminal C and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
- Ignition ON, verify that a test lamp illuminate between the B+ circuit terminal A and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
- If all circuits test normal, test or replace the X80 accessory power receptacle.
Repair Instructions
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- Perform the «Diagnostic System Check - Vehicle»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
- Review «Strategy Based Diagnosis»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
- «Diagnostic Procedure Instructions»(/buick/enclave/i-2007-2013/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
| Circuit | Short to Ground | Open/High Resistance | Short to Voltage | Signal Performance |
|---|---|---|---|---|
| B+ | 1 | 1 | ||
| IGN | 1 | 1 | ||
| Signal | 1 | 1 | 2 | |
| AC Terminal 4 X1 | 1 | 1 | 1 | |
| Low Reference | 1 | 1 | 1 | |
| Ground | 1 | |||
| 1. Accessory DC/AC Power Inverter Module Always OFF 2. Accessory DC/AC Power Inverter Module Always ON | ||||
The accessory DC/AC power inverter module converts 12 V direct current (DC) battery voltage to 110 V at 60 Hertz (Hz) alternating current (AC) in order to operate AC powered devices. The accessory DC/AC power inverter module provides up to 150 watts of power. The accessory DC/AC power inverter module is connected to a chassis ground circuit and receives fuse protected battery voltage.
The accessory power receptacle - 110 V AC has an internal switch, that detects when an AC powered device is plugged into the receptacle. When the ignition is ON and an AC powered device is plugged into the accessory power receptacle - 110 V AC, the normally open switch in the accessory power receptacle - 110 V AC, closes. When the accessory DC/AC power inverter module detects the voltage from the accessory power receptacle - 110 V AC switch, the inverter module begins to supply 110 V AC to the accessory power receptacle - 110 V AC after a 1.5 second delay.
Schematic Reference
Connector End View Reference
Description and Operation
Electrical Information Reference
- «Circuit Testing»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
- «Connector Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
- «Testing for Intermittent Conditions and Poor Connections»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
- «Wiring Repairs»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)
Circuit/System Verification
- Ignition ON, connect an AC power extension cord to the X81 accessory power receptacle - 110 V AC. Inserting the extension cord plug into the X81 accessory power receptacle - 110 V AC turns the T1 accessory DC/AC power inverter module ON.
- Test for 110-120 V between the terminals at the extension cord.
- Test for 59-61 Hz AC across the line A and line B terminals of the extension cord.
- Ignition OFF, nothing plugged into the X81 accessory power receptacle - 110 V AC, disconnect the harness connectors at the T1 accessory DC/AC power inverter module.
- Test for less than 5 ohms between the ground circuit terminal 1 X2 and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
- Verify that a test lamp illuminates between the B+ circuit terminal 2 X2 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
- Test for less than 1.0 V between the signal circuit terminal 2 X1 and ground. If greater than the specified value, test the signal circuit for a short to voltage. If the circuit tests normal, test or replace the X81 accessory power receptacle - 110 V AC.
- Test for infinite resistance between the signal circuit terminal 2 X1 and ground. If less than the specified value, test the signal circuit for a short to ground.
- Test for less than 1.0 V between the AC circuit terminals listed below and ground: Terminal 4 X1 Terminal 6 X1 If greater than the specified value, test the AC circuit for a short to voltage. If the circuit tests normal, test or replace the X81 accessory power receptacle - 110 V AC.
- Test for infinite resistance between the AC circuit terminals listed below and ground: Terminal 4 X1 Terminal 6 X1 If less than the specified value, test the signal circuit for a short to ground.
- Test for less than 5 ohms between the terminals listed below: X81 accessory power receptacle - 110 V AC terminal 3 and the T1 accessory DC/AC power inverter module terminal 4 X1. X81 accessory power receptacle - 110 V AC terminal 6 and the T1 accessory DC/AC power inverter module terminal 6 X1. If greater than the specified range, test the appropriate line circuit for an open/high resistance. If the circuit tests normal, test or replace the X80 accessory power receptacle - 110 V AC.
- Disconnect the harness connector at the X80 accessory power receptacle - 110 V AC.
- Ignition ON, verify that a test lamp illuminates between the ignition voltage circuit terminal 4 and ground. If the test lamp does not illuminate, test the ignition voltage circuit for a short to ground or an open/high resistance.
- Ignition OFF, connect the harness connector at the X80 accessory power receptacle - 110 V AC.
- Connect an AC powered device to the X80 accessory power receptacle - 110 V AC.
- Ignition ON, verify that a test lamp illuminates between the T1 accessory DC/AC power inverter module signal circuit terminal 2 X1 and ground. If the test lamp does not illuminate, test the signal circuit for an open/high resistance. If the circuit tests normal, test or replace the X80 accessory power receptacle - 110 V AC.
- If all circuits test normal, replace the T1 accessory DC/AC power inverter module.
Component Testing
Accessory Power Outlet
- Ignition OFF, remove the X80 accessory power receptacle - 110 V AC.
- Test for greater than 1 M ohms between terminal 3 and terminal 6. If less than the specified range, replace the X80 accessory power receptacle - 110 V AC.
- Test for less than 3 ohms between the following terminals: The terminal 3 and the applicable receptacle terminal The terminal 6 and the applicable receptacle terminal If greater than the specified range, replace the X80 accessory power receptacle - 110 V AC.
- Test for infinite resistance between terminal 1 and terminal 4. If not the specified value, replace the X80 accessory power receptacle - 110 V AC.
- Connect an AC powered device to the X80 accessory power receptacle - 110 V AC.
- Test for less than 3 ohms between terminal 1 and terminal 4. If greater than the specified range, replace the X80 accessory power receptacle - 110 V AC.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «120-Volt Accessory Power Receptacle Replacement»(/buick/enclave/i-2007-2013/remont/body-electrical/#power-outlets)
- «Accessory AC and DC Power Control Module Replacement»(/buick/enclave/i-2007-2013/remont/body-electrical/#power-outlets)
- «Control Module References»(/buick/enclave/i-2007-2013/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for control module replacement, setup, and programming
Cigar Lighter Receptacle or 12-Volt Accessory Power Receptacle Replacement
Tools Required
J 42059 Cigar Lighter Socket Remover
Removal Procedure
- Remove the auxiliary power outlet fuse from the fuse block.
- Remove the receptacle: Look into the receptacle. There are two 3 mm (0.11 in) tab windows 12 mm (0.47 in) from the front of the receptacle. The J 42059 cigar lighter socket remover pushes the plastic latches from these tab windows and the receptacle can be pulled straight out. Place one side of the "T" portion of the J 42059 cigar lighter socket remover into the tab window. The J 42059 cigar lighter socket remover will not fit straight into the receptacle. Angle the J 42059 cigar lighter socket remover slightly for insertion into the receptacle. Insert the other side of the "T" into the opposite tab window. You must move the J 42059 cigar lighter socket remover handle toward horizontal to engage the other tab window. Use the J 42059 cigar lighter socket remover to pull the receptacle straight out.
- If J 42059 cigar lighter socket remover tool fails to release the lighter socket from the retainer, perform the following alternate method: Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 cigar lighter socket remover as directed above to remove the socket.
Installation Procedure
- Route the connector through the retainer. Align the accessory power receptacle retainer to the slot in the opening.
- Install the retainer by pressing into place fully seated.
- Connect the electrical connector to the receptacle.
- Align the tabs on the receptacle to the slots in the retainer. Install the accessory power receptacle by pressing into place until fully seated.
- Install the accessory power receptacle fuse.
Scheme 3
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the quarter lower rear trim panel. Refer to Quarter Lower Rear Trim Panel Replacement (Acadia with TB5) , Quarter Lower Rear Trim Panel Replacement (Traverse with TB5) , Quarter Lower Rear Trim Panel Replacement (Traverse with TB4) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB5) , Quarter Lower Rear Trim Panel Replacement (Acadia with TB4) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB4) . | |
| 1 | Accessory AC/DC Power Control Module Assembly Procedure Disconnect the electrical connections. Remove the jack assembly. |
Accessory AC and DC Power Control Module Replacement
Scheme 4
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the front floor console rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement . | |
| 1 | Accessory Power Receptacle Assembly Procedure Push in the 4 tabs to release the accessory power receptacle from the rear console trim plate. |
120-Volt Accessory Power Receptacle Replacement
12 Volt Power Outlet Receptacle Description and Operation
The 12 V accessory power receptacles are supplied B+ all the time.
110 Volt Power Outlet Receptacle System Description
The alternating current (AC) accessory power outlet system consists of the accessory DC/AC power inverter module and the accessory power receptacle - 110 V AC. The accessory DC/AC power inverter module converts 12 V direct current (DC) battery power to 110 V at 60 Hertz (Hz) AC power to operate AC powered devices. The accessory DC/AC power inverter module provides up to 150 watts of power. The accessory power receptacle - 110 V AC provides the usual connection for AC powered devices.
110 Volt Power Outlet Receptacle System Operation
The accessory DC/AC power inverter module receives fuse protected battery voltage and is connected to the 12 V electrical system ground. The accessory power receptacle - 110 V AC has an internal switch, that detects when an AC powered device is plugged into the outlet. When the ignition is ON, and an AC powered device is plugged into the accessory power receptacle - 110 V AC, the normally open switch in the accessory power receptacle - 110 V AC, closes. When the accessory DC/AC power inverter module detects the voltage from the accessory power receptacle - 110 V AC switch, the inverter module begins to supply 110 V AC to the accessory power receptacle - 110 V AC after a 1.5 second delay. The accessory AC power system is protected against circuit overload and circuit shorts to ground.
110 Volt Power Outlet Receptacle Isolation Fault Protection
The accessory DC/AC power inverter module contains a ground fault circuit interrupter (GFCI). GFCI monitors the 110 V circuit for a short to vehicle chassis ground. If a 110 V AC short to ground is detected, the accessory DC/AC power inverter module will turn OFF. The module remains OFF, until the AC powered device is unplugged from the outlet, and then plugged into the outlet after a 3 second delay.
110 Volt Power Outlet Receptacle Overload Shutdown
The accessory DC/AC power inverter module will turn OFF if the current in the 110 V circuit is greater than 3.8 A for 1 second, or 2.5 A for 10 seconds. The module will turn ON again, when the AC powered device is unplugged from the outlet, and then plugged into the outlet after a 3 second delay.
110 Volt Power Outlet Receptacle Internal Shutdown
The accessory DC/AC power inverter module will turn OFF if the B+ supply voltage is greater than 16.5 V or less than 11 V. The module will also turn OFF if the device temperature is greater than 85°C (185°F). The module will turn ON again, after the shutdown condition is corrected, and the AC powered device is unplugged from the outlet, and then plugged into the outlet.
Special Tools
Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
