Maintenance Information (fwd) Buick Electra VI

Procedures 14 illustrations ~4049 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 1

Scheme 1: VIN Code ID Explanation
Scheme 1: VIN Code ID Explanation

SHORT TRIP/CITY & LONG TRIP/HIGHWAY SERVICE DEFINITIONS

Note. Starting in the 1996 model year, General Motors has renamed their maintenance schedules; One is referred to as the Short-Trip/City and the other is the Long Trip/Highway schedule. These schedule requirements are similar to the familiar Severe Service and Normal schedules and can be used in place of one another.

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (4 Miles Or Less)
  2. When Most Trips Are Less Than 10 Miles And Outside Temperatures Remain Below Freezing.
  3. Towing Or Heavily Loaded
  4. Severe Dust Conditions
  5. Hot Weather, Stop-And-Go Driving
  6. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Severe Service Operating Conditions

Scheme 2

Scheme 2: SERVICE POINT LOCATIONS
Scheme 2: SERVICE POINT LOCATIONS

Scheme 3

Scheme 3: INFORMATION LABEL LOCATIONS
Scheme 3: INFORMATION LABEL LOCATIONS

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

The tire specification decal, located on rear of the driver's door, lists maximum vehicle load, recommended tire size and cold inflation pressure.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 100 ft. lbs. (135 N.m).

BATTERY SPECIFICATIONS

Vehicles are delivered with maintenance free battery. Water need never be added to a maintenance free battery. The battery contains a visual tester. A Green indicator is visible when an adequate charge level exists; a Black indicator implies charging is required and a Yellow indicator appears when replacement is necessary.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)

Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.

Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section.

Modification to the air bag system component or wiring can adversely affect system performance and possibly cause injury.

CAUTIONThe Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the inflator module for up to 10 minutes after the ignition switch is turned off and the battery is disconnected. Many of the service procedures require disconnection of the inflator module to avoid an accidental deployment.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

AIR CONDITIONING SERVICING

CAUTIONAvoid breathing R-134a refrigerant and PAG lubricant vapors, exposure may irritate eyes, nose and throat. To remove R-134a from system use R-134a recycling equipment that meets SAE J2210 specifications. If accidental system discharge occurs, ventilate work area before resuming service.
WARNINGR-134a service equipment or vehicle A/C systems SHOULD NOT be pressure tested or leak tested with compressed air. Some mixtures of air/R134a have shown to be combustible at elevated pressures. These mixtures are dangerous and may cause fire and/or explosions. See the appropriate A/C SYSTEM GENERAL SERVICING article in the AIR CONDITIONING & HEAT section.

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See the COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER (GASOLINE MODELS)

CAUTIONTo prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes.

COOLANT (DEX-COOL 1995-96 MODELS)

CAUTIONSome 1995 build-out and all 1996 models have DEX-COOL engine coolant installed at the factory. DEX-COOL coolant is a silicate-free coolant that is orange in color. It should not be mixed with regular ethylene-glycol coolant. To avoid possible damage to vehicle cooling system, visually check engine coolant color before adding and/or changing engine coolant. Vehicle should have an identification label placed under the hood stating what type coolant is installed.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C)
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component.

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

METHANOL GASOLINE

CAUTIONFuel that is more than 5% methanol should not be used in this vehicle. It can corrode metal parts in the fuel system, and damage plastic and rubber parts. Even at 5% methanol or less, solvents and corrosion preventers must be used with this fuel to avoid these problems.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

TRACTION CONTROL SYSTEM (IF EQUIPPED)

CAUTIONIf tires are allowed to spin at high speeds when TRACTION OFF light is on, tires can explode. Also, spinning the tires with the warning light on can cause the transaxle to overheat. DO NOT spin wheels above 35 MPH.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BUMPER-TO-BUMPER PLUS COVERAGE LIMITED WARRANTY

Everything is covered for 3 years or 50,000 miles, whichever occurs first. Also covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts by the Dealer. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first. Maintenance items are covered up to their first scheduled replacement interval only.

Note. 1992-93 vehicles are covered for 3 years or 36,000 miles with no deductible.

CORROSION COVERAGE (ALL MODELS)

Covers any body-sheet metal panel that is perforated due to corrosion is covered for 6 years or 100,000 miles whichever occurs first.

SUPPLEMENTAL INFLATABLE RESTRAINT COVERAGE (ALL MODELS)

Covers supplemental restraint system (if equipped) for 3 years, regardless of mileage.

EMISSIONS "DEFECT" & "PERFORMANCE" WARRANTIES (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.

EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSION "DEFECT" WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

Scheme 4

Scheme 4: FUSE PANEL ID (1985 ELECTRA)
Scheme 4: FUSE PANEL ID (1985 ELECTRA)

Fuse & Circuit Breaker Identification

  1. 1 - 5 Amp - Spare
  2. 2 - 10 Amp - Spare
  3. 3 - 15 Amp - Spare
  4. 4 - 20 Amp - Spare
  5. 5 - 25 Amp - Spare
  6. 6 - 10 Amp - Radio & Power Antenna
  7. 7 - 25 Amp - Wiper/Washer
  8. 8 - 5 Amp - Instrument Panel
  9. 9 - 15 Amp - Airflow Sensor Spark Controls (VIN 3) Emission Controls (Gasoline Engines) Engine Data Sensors (VIN E) Not Used (Diesel Models)
  10. 10 - 20 Amp - Fuel Control Idle Air Control (VIN 3) Not Used (VIN E & Diesel Models)
  11. 11 - 20 Amp - Twilight Sentinel Lights Cornering Lights Front Marker & Parking Lights Instrument Panel Lights License & Opera Lights Rear Marker & Taillights Radio
  12. 12 - 20 Amp - Electronic Level Control
  13. 13 - 20 Amp - Stoplights & Hazard Lights
  14. 14 - 20 Amp - Air Conditioning Engine Compartment Light Front Cigarette Lighter Radio & Power Antenna Seat Belt Warning Theft Deterrent System
  15. 15 - 20 Amp - Courtesy & Dome Lights Reading & Vanity Mirror Light Rear Cigarette Lighter Trunk Light Warning Lights Power Remote Mirrors
  16. 16 - 20 Amp - Automatic Door Locks Brake Warning System Charging System Cruise Control Electronic Level Control Glove Box Light Illuminated Entry Lights Instrument Panel Lights Memory Seats Seat Belt Warning Theft Deterrent System Torque Converter Clutch
  17. 17 - 10 Amp (Gasoline Engines) - Fuel Injectors (VIN 3)
  18. 17 - 15 Amp (Diesel Engines) - Fuel Control Glow Plug Control Torque Converter Clutch
  19. 18 - 5 Amp - Cruise Control Torque Converter Clutch
  20. 19 - 15 Amp - Back-Up Lights Turn Signal Lights
  21. 20 - 20 Amp - Fuel Door & Trunk Release
  22. 21 - 20 Amp - Choke Heater Cooling Fans Fuel Control
  23. 22 - 25 Amp - Air Conditioning
  24. 23 - 30 Amp (Circuit Breaker) - Power Windows Sun Roof
  25. 24 - 30 Amp (Circuit Breaker) - Automatic Door Locks Rear Window Defogger Keyless Entry Power Door Locks Power Seats Trunk Lid Pull-Down
  26. 25 - 10 Amp - Fuel Control (VIN E)

Scheme 5

Scheme 5: FUSE PANEL ID (1985 98/REGENCY)
Scheme 5: FUSE PANEL ID (1985 98/REGENCY)
  1. 1 - Not Used
  2. 2 - Not Used
  3. 3 - Not Used
  4. 4 - Not Used
  5. 5 - 10 Amp - Electronic Instrument Cluster
  6. 6 - 10 Amp - Radio
  7. 7 - 25 Amp - Wiper/Washer System
  8. 8 - 5 Amp - Instrument Panel Lights
  9. 9 - 15 Amp - Airflow Sensor Spark Controls (MPFI) Emission Controls (Gasoline Engines) Engine Data Sensors (3.0L VIN E) Not Used On Diesel Models
  10. 10 - 20 Amp - Fuel & Idle Air Control (MPFI) Electronic Cluster Not Used On Diesel Models Not Used on 3.0L (VIN E)
  11. 11 - 20 Amp - Cornering Lights Engine Compartment Light Front Marker & Parking Lights License Plate Light Opera Lights Rear Marker & Taillights Twilight Sentinel
  12. 12 - 20 Amp - Electronic Level Control
  13. 13 - 20 Amp - Hazard & Stop Lights
  14. 14 - 20 Amp - A/C Controls Front Cigarette Lighter Glove Box Light Instrument Panel Light Radio & Power Antenna Seat Belt Reminder Trip Calculator Reminder Package Horn Relay
  15. 15 - 20 Amp - Courtesy & Dome Light Reading & Vanity Mirror Lights Trunk Light Rear Cigarette Lighters Power Remote Mirrors Power Door Locks Automatic Door Locks Memory Seat
  16. 16 - 20 Amp - Charging System Automatic Door Locks Automatic Day/Night Mirror CHECK ENGINE Light Illuminated Entry Instrument Panel Memory Seats Seat Belt Reminder Trip Calculator Transaxle Converter Clutch Voice Reminder Reminder Package
  17. 17 - 10 Amp (Gasoline Engines) - Fuel Injectors
  18. 17 - 15 Amp (Diesel Engines) - Fuel Control Glow Plug Control Transaxle Converter Clutch
  19. 18 - 5 Amp - Cruise Control
  20. 19 - 15 Amp - Back-Up Lights Turn Signal Lights Automatic Day/Night Mirror Lights Decoder Module
  21. 20 - 20 Amp - Trunk Release Fuel Door Release
  22. 21 - 20 Amp - Cooling Fans Choke Heater (3.0L VIN E)
  23. 22 - 25 Amp - Air Conditioning
  24. 23 - 30 Amp (Circuit Breaker) - Power Windows Sun Roof
  25. 24 - 30 Amp (Circuit Breaker) - Power Seats Power Door Locks Power Seat Recliner Rear Window Defogger Delco-Bose Radio
  26. 25 - 10 Amp - Fuel Control (3.0L VIN E)

Scheme 6

Scheme 6: FUSE PANEL ID (1986-87 ELECTRA/PARK AVENUE)
Scheme 6: FUSE PANEL ID (1986-87 ELECTRA/PARK AVENUE)
  1. 1 - Not Used
  2. 2 - Not Used
  3. 3 - 10 Amp - Radio
  4. 4 - 25 Amp - Wiper/Washer System
  5. 5 - 10 Amp - Gear Select Switch Decoder Module Instrument Panel
  6. 6 - 20 Amp - High/Low Speed Cooling Fan Relay Heavy Duty Cooling Fan Relay ELC
  7. 7 - 25 Amp - Electronic/Manual Control A/C
  8. 8 - 5 Amp - Hydraulic Pump Motor Relay Anti-Lock Brake Controller Logic Module
  9. 9 - 15 Amp - Power Steering Cutout Switch Canister Purge Solenoid A/C Constant Run Relay EVRV
  10. 10 - 20 Amp - Oil Pressure Switch Warning Light Relay Fuel Pump Relay C(3)I & Fuel Injectors
  11. 11 - 20 Amp - Park & Headlight Switch (LeSabre)
  12. 12 - 20 Amp - Electronic Level Control
  13. 13 - 20 Amp - Brakelight 4-Way Hazard Light Switch
  14. 14 - 20 Amp - Engine Compartment Light Antenna Relay A/C Control Head Multifunction Chime Module Front Cigar Lighter Radio Instrument Panel
  15. 15 - 20 Amp - Courtesy Light Dome & Vanity Mirror Lights Outside Mirror Control Switch DOOR AJAR Warning Light Door Lock Switch Front Fiber Optic Door Lock Light Rear Cigarette Lighter Keyless Entry Module
  16. 16 - 20 Amp - Instrument Panel Printed Circuit Multifunction Chime Module Glove Box Light Illuminated Entry Timer Theft Deterrent Controller Seat Memory Module Automatic Door Lock Controller Digital Cluster Display
  17. 17 - 10 Amp - ECM MAF Sensor ESC C(3)I TCC Brake Switch
  18. 17 - 15 Amp - ECM MAF Sensor ESC C(3)I
  19. 18 - 5 Amp - Multifunction Lever Speed Sensor Buffer
  20. 19 - 15 Amp - Gear Selector Switch Turn Signals Decoder Module
  21. 20 - 20 Amp - Trunk Release Fuel Door Release
  22. 21 - Not Used
  23. 22 - Not Used
  24. 23 - 30 Amp (Circuit Breaker) - Driver's Master Switch Single Power Window Switches Moon Roof Controls
  25. 24 - 30 Amp (Circuit Breaker) - Defroster Control Seat Control Switches Door Lock Relay Keyless Entry Module Trunk Pull-Down Unit
  26. 25 - 5 Amp (Circuit Breaker) - Instrument Panel Light
  1. 1 - Not Used
  2. 2 - Not Used
  3. 3 - Not Used
  4. 4 - Not Used
  5. 5 - 10 Amp - Electronic Instrument Cluster
  6. 6 - 10 Amp - Radio
  7. 7 - 25 Amp - Wiper/Washer System
  8. 8 - 5 Amp - Instrument Panel Lights
  9. 9 - 15 Amp - Airflow Sensor Spark Controls (MPFI) Engine Data Sensors (3.0L)
  10. 10 - 20 Amp - Fuel Control Idle Air Control (MPFI) Electronic Cluster
  11. 11 - 20 Amp - Cornering Lights Engine Compartment Light Front & Rear Marker Front Parking Lights License Plate Lights Opera & Taillights Twilight Sentinel
  12. 12 - 20 Amp - ELC
  13. 13 - 20 Amp - Stop & 4-Way Hazard Lights
  14. 14 - 20 Amp - A/C Controls Front Cigar Lighter Glove Box Light Instrument Panel Power Antenna Radio Seat Belt Reminder Trip Calculator Reminder Package Horn Relay
  15. 15 - 20 Amp - Courtesy & Dome Lights Reading & Vanity Mirror Lights Trunk Light Rear Cigar Lighter Power Remote Mirrors Power Door Locks Automatic Door Locks Memory Seat
  16. 16 - 20 Amp - Charging System Automatic Door Locks Automatic Day/Night Mirror CHECK ENGINE Light Illuminated Entry Instrument Panel Memory Seats Seat Belt Reminder Trip Calculator Transaxle Converter Clutch Voice Reminder Reminder Package
  17. 17 - 10 Amp - Fuel Injectors
  18. 18 - 5 Amp - Cruise Control
  19. 19 - 15 Amp - Back-Up Lights Turn Signal Lights Automatic Day/Night Mirrors Decoder Module
  20. 20 - 20 Amp - Trunk & Fuel Door Release
  21. 21 - 20 Amp - Cooling Fans Choke Heater (3.0L VIN L)
  22. 22 - 25 Amp - Air Conditioning
  23. 23 - 30 Amp (Circuit Breaker) - Power Windows Sun Roof
  24. 24 - 30 Amp (Circuit Breaker) - Power Seats Power Door Locks Rear Window Defroster Radio
  25. 25 - 10 Amp - Fuel Control (3.0L VIN L)

Scheme 7

Scheme 7: FUSE PANEL ID (1988-89 ELECTRA)
Scheme 7: FUSE PANEL ID (1988-89 ELECTRA)
  1. 1 - 5 Amp - Cruise Control
  2. 2 - 5 Amp - Instrument Illumination Headlight-On Warning Electronic Touch A/C
  3. 3 - Blank
  4. 4 - 20 Amp - Electric Choke Oil Pressure Switch
  5. 5 - 30 Amp (Circuit Breaker) - Power Windows Tailgate Power Window
  6. 6 - Blank
  7. 7 - 25 Amp - Heater System Air Conditioning Radio Capacitor
  8. 8 - 10 Amp - ECM Feed
  9. 9 - Blank
  10. 10 - 10 Amp - Stoplights, Hazard Lights
  11. 11 - 10 Amp - Radio Power Antenna
  12. 12 - 30 Amp (Circuit Breaker) - Power Seats Power Door Locks Rear Window Defogger
  13. 13 - 20 Amp - Dome & Trunk Lights Sail Panel Reading & Vanity Lights Power Mirrors Illuminated Entry Interior Lights Automatic Door Locks Rear Cigarette Lighter Power Door Locks Tailgate Door Ajar
  14. 14 - Blank
  15. 15 - Blank
  16. 16 - 20 Amp - Gauges Indicator Lights Vehicle Speed Sensor SERVICE ENGINE SOON Light SERVICE ENGINE SOON Instrument Panel Driver Module Torque Converter Clutch Automatic Level Control
  17. 17 - Blank
  18. 18 - 10 Amp - ECM
  19. 19 - 20 Amp - Clock Cigar Lighter Glove Box Light Key Muted Electronic Tone Power Antenna Clock Radio Headlight-On Warning Electronic Touch A/C Seat Belt Muted Electronic Tone
  20. 20 - 20 Amp - Turn Signals Back-Up Lights Automatic Door Locks
  21. 21 - Blank
  22. 22 - 20 Amp - Tail & Rear Cornering Lights Side Marker Lights Parking & License Plate Lights Twilight Sentinel ETR Radio Underhood Light
  23. 23 - 20 Amp - Seat Belt Light Muted Electronic Tone Rear Defogger Relay Brake Warning System Illuminated Entry
  24. 24 - Blank
  25. 25 - Blank
  26. 26 - Blank
  27. 27 - 25 Amp - Windshield Wiper/Washer System Low Washer Fluid Light
  28. 28 - 30 Amp - Powermaster Brake
  29. 29 - Blank

Scheme 8

Scheme 8: FUSE PANEL ID (1990 ELECTRA)
Scheme 8: FUSE PANEL ID (1990 ELECTRA)
  1. 1 - 5 Amp - Spare
  2. 2 - 20 Amp - Spare
  3. 3 - 10 Amp - Digital Cluster
  4. 4 - 10 Amp - Radio
  5. 5 - 25 Amp - Wiper/Washer System
  6. 6 - 5 Amp - Cooling Fans
  7. 7 - 25 Amp - Air Conditioning Electronic Level Control Rear Defogger
  8. 8 - 5 Amp - Anti-Lock Brake System
  9. 9 - 5 Amp - Anti-Lock Brake System
  10. 10 - Not Used
  11. 11 - 20 Amp - Remote Keyless Entry Alarm & Warning System Front Cigarette Lighter Radio Power Antenna Instrument Cluster Horn Air Conditioning Engine Compartment Light Trunk Light
  12. 12 - 20 Amp - Electronic Level Control
  13. 13 - 20 Amp - Exterior Lights Cruise Control
  14. 14 - 20 Amp - Headlights Twilight Sentinel Running Lights
  15. 15 - 20 Amp - Interior Lights Rear Cigarette Lighter Power Mirrors Power Door Locks Remote Keyless Entry Illuminated Entry
  16. 16 - 20 Amp - Automatic Day/Night Mirror Theft Deterrent Illuminated Entry Memory Seats Automatic Door Locks Alarm & Warning System Instrument Panel Lights Instrument Panel Compartment Lights
  17. 17 - 10 Amp - Electronic Control Module Emission Control
  18. 18 - 5 Amp - Cruise Control
  19. 19 - 15 Amp - Turn Signals Back-Up Lights
  20. 20 - 20 Amp - Trunk Lid Release Fuel Door Release Remote Keyless Entry
  21. 21 - 10 Amp - Spare
  22. 22 - 25 Amp - Spare
  23. 23 - 30 Amp (Circuit Breaker) - Power Windows Power Seats Sun Roof
  24. 24 - 30 Amp (Circuit Breaker) - Power Seats Power Door Locks Rear Defogger Trunk Lid Pull-Down
  25. 25 - 5 Amp - Interior Light Dimmer

Scheme 9

Scheme 9: FUSE PANEL ID (1991-93 98/REGENCY)
Scheme 9: FUSE PANEL ID (1991-93 98/REGENCY)

Scheme 10

Scheme 10
Scheme 10
  1. 1 - 10 Amp - Start-up Signal - SIR
  2. 2 - 20 Amp - Back-Up Lights/Truck Release Fuel Door Release
  3. 3 - 30 Amp (Circuit Breaker) - Power Window, Sun Roof
  4. 4 - 30 Amp (Circuit Breaker) - Power Accessory
  5. 5 - Blank
  6. 6 - 15 Amp - Gauges, Retained Accessory Control Illuminated Entry
  7. 7 - 10 Amp - Supplemental Inflatable Restraint
  8. 8 - 20 Amp - Turn Signal, Cornering Lights
  9. 9 - 10 Amp - Spare
  10. 10 - 15 Amp - Spare
  11. 11 - 15 Amp - Chime, Cigarette Lighter, Radio Power Antenna, Oil Level Electronic Control
  12. 12 - 20 Amp - Electronic Level Control
  13. 13 - 20 Amp - Brake Lights, Hazard Warning Flashers
  14. 14 - 15 Amp - Parking Lights
  15. 15 - 15 Amp - Left Courtesy Lights, Power Door Lock Power Mirrors
  16. 16 - 10 Amp - Cooling Fan, Transmission
  17. 17 - 25 Amp (1992-93) - Air Conditioning Blank (1991)
  18. 18 - 10 Amp (1992) - Heated Windshield 15 Amp (1991) - Air Conditioning Not Used (1993)
  19. 19 - 10 Amp - Anti-Lock Brake System
  20. 20 - 10 Amp - Low Coolant, Light Monitor Oil Level
  21. 21 - 10 Amp - Instrument Panel Lights
  22. 22 - 20 Amp - Spare
  23. 23 - 25 Amp - Spare
  24. 24 - 10 Amp (1992-93) 25 Amp (1991) - Radio
  25. 25 - 25 Amp - Wiper & Washer

Scheme 11

Scheme 11: FUSE PANEL ID (1991-93 PARK AVENUE)
Scheme 11: FUSE PANEL ID (1991-93 PARK AVENUE)
  1. 1 - 10 Amp - Supplemental Inflatable Restraint (SIR) Spare (1991)
  2. 2 - 20 Amp (1992-93) - Luggage Compartment Lid Release/ Pull-Down & Fuel Door Release 15 Amp (1991) - Spare
  3. 3 - 30 Amp (Circuit Breaker) - Power Windows, Sun Roof
  4. 4 - 30 Amp (Circuit Breaker) - Memory Seat/Mirrors, Power Door Locks, Power Seats, Remote Keyless Entry/ Automatic Door Locks, Rear Defogger
  5. 5 - Not Used (1992-93) 20 Amp (1991 Circuit Breaker) Headlights, Exterior Lights
  6. 6 - 15 Amp - Automatic Day/Night Mirror, Memory Seat/ Mirrors, Instrument Panel, Warnings & Chimes, SIR, Retained Accessory Power
  7. 7 - 10 Amp - Supplemental Inflatable Restraint (SIR)
  8. 8 - 20 Amp - Exterior Lights
  9. 9 - Spare (1992-93) 10 Amp (1991) - Supplemental Inflatable Restraint (SIR)
  10. 10 - Spare (1992-93) 20 Amp (1991) - Luggage Compartment Lid Release/ Pull-Down And Fuel Door Release
  11. 11 - 15 Amp - Instrument Panel, Lamp Monitor, Power Antenna, Interior Lights/Dimming, Air Conditioning, Warnings & Chimes, Retained Accessory Power, Radio
  12. 12 - 20 Amp - Electronic Level Control
  13. 13 - 20 Amp - Exterior Lights Anti-Lock Brake System
  14. 14 - 15 Amp - Headlights Exterior Lights
  15. 15 - 15 Amp - Interior Lights Power Mirrors/Door Locks Memory Seat/Mirrors Illuminated Entry
  16. 16 - 10 Amp - Coolant Fans, Sequential Fuel Injection
  17. 17 - 25 Amp - Electronic Air Conditioning, Heated Windshield, Rear Defogger, Electronic Level Control
  18. 18 - 10 Amp (1992-93) - Heated Windshield 15 Amp (1991) - Dual Air Conditioning, Heated Windshield, Rear Defogger, Electronic Level Control
  19. 19 - 10 Amp - Anti-Lock Brake System
  20. 20 - 10 Amp - Lamp Monitor, Instrument Panel
  21. 21 - 10 Amp - Interior Lights/Dimming
  22. 22 - 20 Amp - Spare
  23. 23 - 25 Amp - Spare
  24. 24 - 10 Amp - Radio, Interior Lights/Dimming
  25. 25 - 25 Amp - Wiper/Washer

Scheme 12

Scheme 12: FUSE PANEL ID - 1994-96 NINETY EIGHT & PARK AVENUE
Scheme 12: FUSE PANEL ID - 1994-96 NINETY EIGHT & PARK AVENUE

Scheme 13

Scheme 13: Fuse & Circuit Breaker Identification
Scheme 13: Fuse & Circuit Breaker Identification

Scheme 14

Scheme 14
Scheme 14
  1. A - Circuit Breaker - Power Windows, Sunroof
  2. B - Not Used
  3. C - Circuit Breaker - Power Seats
  4. D - Not Used
  5. E - Not Used
  6. 1A - Start-Up Signal - Air Bag
  7. 2A - Spare
  8. 3A - Not Used
  9. 4A - Interior Lamps
  10. 5A - Ignition (Run), Automatic A/C Control
  11. 6A - Courtesy Lights, Power Mirrors
  12. 7A - Not Used
  13. 8A - Not Used
  14. 9A - Cigar Lighter
  15. 1B - Turn Signal, Back-Up Lights, Cornering Lights, Brake-Transaxle Shift Interlock
  16. 2B - Spare
  17. 3B - Not Used
  18. 4B - Not Used
  19. 5B - Anti-Lock Brake System, Firm Ride
  20. 6B - Brake & Hazard Lamps
  21. 7B - Not Used
  22. 8B - Not Used
  23. 9B - Level Control
  24. 1C - Air Bag
  25. 2C - Spare
  26. 3C - Not Used
  27. 4C - Not Used
  28. 5C - Cooling Fan, Transaxle
  29. 6C - Parking Lamps
  30. 7C - Not Used
  31. 8C - Not Used
  32. 9C - Batttery Chime, Radio, Cluster
  33. 1D - Ignition (Run/Crank), Chime, Cluster
  34. 2D - Spare
  35. 3D - Heated Mirror
  36. 4D - Not Used
  37. 5D - Base A/C
  38. 6D - Not Used
  39. 7D - Not Used
  40. 8D - Radio
  41. 9D - Not Used
  42. 1E - Auxiliary Outlet
  43. 2E - Not Used
  44. 3E - Ignition (Off/Unlock)
  45. 4E - Not Used
  46. 5E - Not Used
  47. 6E - Not Used
  48. 7E - Not Used
  49. 8E - Wipers, Washer
  50. 9E - Rear Defog
  51. 1 - Circuit Breaker - Power Windows, Sunroof
  52. 2 - Not Used
  53. 3 - Circuit Breaker - Power Seats
  54. 4 - Not Used
  55. 5 - Not Used
  56. 1A - PASS-Key II
  57. 2A - Spare
  58. 3A - Not Used
  59. 4A - Not Used
  60. 5A - Ignition (Run), Automatic A/C Control, Cruise, Base Cluster
  61. 6A - Courtesy Lights, Power Mirrors, Memory Seat Switch
  62. 7A - Not Used
  63. 8A - Not Used
  64. 9A - Cigar Lighter
  65. 1B - Turn Signal, Back-Up Lights, Cornering Lights, Brake-Transaxle Shift Interlock
  66. 2B - Spare
  67. 3B - Not Used
  68. 4B - Not Used
  69. 5B - Anti-Lock Brake System, Firm Ride
  70. 6B - Brake & Hazard Lamps
  71. 7B - Not Used
  72. 8B - Interior Lamps
  73. 9B - Level Control
  74. 1C - Air Bag
  75. 2C - Spare
  76. 3C - Not Used
  77. 4C - Not Used
  78. 5C - Cooling Fan, Transaxle
  79. 6C - Parking Lamps
  80. 7C - Not Used
  81. 8C - Not Used
  82. 9C - Radio, Cluster, Battery
  83. 1D - Ignition (Run/Crank), Chime, Cluster
  84. 2D - Spare
  85. 3D - Heated Mirror
  86. 4D - Not Used
  87. 5D - Base A/C
  88. 6D - Fog Lamps
  89. 7D - Not Used
  90. 8D - Radio
  91. 9D - Not Used
  92. 1E - Auxiliary Outlet
  93. 2E - Air Bag, PASS-Key
  94. 3E - Ignition (Off/Unlock)
  95. 4E - Not Used
  96. 5E - Rear Defog
  97. 6E - Not Used
  98. 7E - Not Used
  99. 8E - Wipers, Washer
  100. 9E - Not Used
  101. 1 - Door Locks, Trunk Pull Down, Fuel Door Release
  102. 2 - Power Antenna, Trunk Release
  103. 3 - Horns
  104. 4 - Not Used
  105. 5 - Misc. Engine Controls
  106. 6 - Fuel Pump
  107. 7 - Injectors
  108. 8 - Powertrain Control Module
  109. 9 - Not Used
  110. 10 - Not Used
  111. 11 - A/C Programmer
  112. 12 - Not Used

More articles — Maintenance
