IDENTIFICATION
| WARNING | Vehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see appropriate AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIR BAG RESTRAINT SYSTEMS article. |
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
ENGINE COMPARTMENT
Engine compartment fuse panel (Engine Electronics Fuse Carrier - A8682) is located at the left rear of engine compartment (Scheme 24)
Scheme 24
Engine compartment fuse is protection for
- F07: 3.0L (N52) - 40A - WT Relay 3.0L Twin Turbo (N54) - 50A - Electric Coolant Pump
PASSENGER COMPARTMENT
Fuse panel (Junction box - A410) is located behind glove box (Scheme 25) For identification of fuse assignments (Scheme 26), (Scheme 27), or (Scheme 28).
Scheme 25
Scheme 26
Scheme 27
Scheme 28
LUGGAGE COMPARTMENT
Rear fuse holder (A46) is located below luggage compartment floor hatch (Scheme 29)
Scheme 29
Luggage compartment fuses are protection for
- F101: 80A - Engine Compartment Fuse Carrier (A4682)
- F103: 250A - Passenger Compartment Junction Box (A4010)
- F104: 40A - Amplifier Relay
- F105: 40A - Parking Brake Control Module
- F106: 40A - Parking Brake Control Module
- F107: 50A - Hard Top Drive Unit Relays (1 and 2)
- F108: 80A - Electronic Power Steering (EPS)
FUSE ASSIGNMENT SYMBOL DEFINITIONS
For help determining the meaning of the symbols on fuse assignment legends, see FUSE ASSIGNMENT SYMBOL DEFINITIONS.
WIRING DIAGRAMS
Note. For wiring diagrams, see appropriate SYSTEMS WIRING DIAGRAM article in ELECTRICAL.
See also:
• FUSE ASSIGNMENT SYMBOL DEFINITIONS.
