Rear Axle - Special Tools BMW Z4 E89

Axle Shafts 30 illustrations ~1899 words

Device MW

Replaced by: 0492079

Note. (Fixture) For all rear axle final drives - model year: From 88 - Replaced by 33 1 070.(0 492 079)

Scheme 15

Scheme 15: Device MW

Note. For pulling off drive flanges (also E46/16).

Storage Location

C18

C17

Consisting of

4 = 0494872 Plate

Note. (Adapter plate) Transmission: GS6-57DZ, GS6-53BZ (G-transmission) GS6-51DZ, GS6-51BZ (H-transmission)

Scheme 16

Scheme 16: Storage Location

5 = 0494873 Screw

Note. (Countersunk screws M10x30 (3 x)) Transmission: GS6-57DZ, GS6-53BZ (G-transmission) GS6-51DZ, GS6-51BZ (H-transmission)

1 = 0493265 Spindle

2 = 0493266 Mandrel

3 = 0494631 Washer

Note. For removing and installing rubber mount in support tube of rear axle final drive mounting.

SI number

01 01 89 (989)

Consisting of

1 = 0492394 Plate

Note. (Shaped plate, top) For removing

2 = 0492395 Plate

Note. (Shaped plate, top) For pulling in

3 = 0492396 Plate

Note. (Shaped plate, bottom) For pulling in

Scheme 17

Scheme 17: SI number

Device Minimum set: Mechanical tools MW

Note. (Device) For installing split rubber mounts.

A50

B50

01 15 04 (117)

Consisting of

1 = 0495038 Spindle

Note. (Spindle with handle)

Scheme 18

Scheme 18: SI number

2 = 0495039 Screw

Note. (Knurled screws (2 x))

3 = 0495040 Fixture

Note. (Fixture for diameter 46 mm)

4 = 0495041 Tensioning strap

Note. (Tensioning strap)

5 = 0495042 Fixture

Note. (Fixture for diameter 51 mm)

6 = 0495043 Tensioning strap

Note. (Tensioning strap)

Note. For extracting and press-fitting the rubber mount in the trailing arm.

01 01 89 (989)

Consisting of

1 = 0492379 Sleeve

Note. (support sleeve) During extraction

2 = 0492380 Sleeve

Note. (press-out sleeve)

3 = 0492381 Sleeve

Note. (press-in sleeve)

4 = 0492382 Shaped element

Note. For press-fitting

Scheme 19

Scheme 19: SI number

Note. For removing and installing the rubber mount in the wishbone

01 01 89 (989)

Consisting of

1 = 0492384 Sleeve

Note. (Support sleeve) For pressing out

2 = 0492385 Sleeve

Note. (Press-out sleeve)

3 = 0492386 Sleeve

Note. (Press-in sleeve)

4 = 0492387 Shaped element

Note. For pressing in

Scheme 20

Scheme 20: SI number

Note. For gripping output shafts when press-fitting constant-velocity joint

C23

01 06 94 (801)

Consisting of

1 = 0492166 Frame

2 = 0492167 Shell

Note. (shells) 2 pcs. Diameter 30 mm - model series: E38/model: 730i

Scheme 21

Scheme 21: SI number

3 = 0492168 Shell

Note. (shells) 2 pcs. Diameter 35 mm - model series: all, except E38

Note. For removing inner wheel bearing races on rear axle

01 05 99 (426)

Consisting of

1 = 0493816 Basic body

2 = 0493817 Spindle

3 = 0493818 Key

Note. (wrench)

Scheme 22

Scheme 22: SI number

4 = 0493819 Key

Note. (wrench)

5 = 0493820 Pliers

Note. (clamping ring (45...51 mm))

6 = 0493821 Pliers

Note. (clamping ring (50...55 mm))

7 = 0494617 Pliers

Note. (clamping ring (55...61 mm)) Model series: E67

8 = 0496538 Ring

Note. (clamping ring) Model series: F01, F02 See SI: 01 18 08 (482)

9 = 0496539 Synchronizing key

Note. Series: F01, F02 See SI: 01 18 08 (482)

Note. For removing and installing rubber mount in trailing arm, front, on rear axle.

C26

01 09 09 (532)

Consisting of

1 = 0496607 Synchronizing key

2 = 0496608 Bush

3 = 0496609 Washer

Note. (shaped disc)

Scheme 23

Scheme 23: SI number

Note. For removing and installing ball joint mount in wishbone.

01 01 89 (989)

Consisting of

1 = 0492389 Shaped element

Note. For hanging up when pressing out the ball joint

2 = 0492390 Bush

Note. (Pressure bushing) For pressing the ball joint out of the wishbone

3 = 0492391 Shaped element

Note. For hanging up the wishbone when pressing in the ball joint

4 = 0492392 Bush

Note. (Pressure bushing) For pressing the ball joint into the wishbone

Scheme 24

Scheme 24: SI number

01 22 06 (307)

Scheme 25

Scheme 25: SI number

01 22 06 (307)

01 22 06 (307)

01 22 06 (307)

Extension Minimum set: Mechanical tools MW

Note. (2 pieces) Pullout extension for 33 5 040, 33 5 050, 33 5 060.

A18

B18

01 21 06 (300)

Consisting of

1 = 0495592 Extension

Note. (Extension (1 piece))

Scheme 26

Scheme 26: SI number

Extractor MW

Note. (Rillex extractor) For bevel pinion and differential case (rear diff)/for installation of camshaft sprocket on crankshaft (M70)/for removing bearing inner race from drive flange (E36, E46)

B6

C6

Consisting of

Scheme 27

Scheme 27: Storage Location

2 = 0492098 Washer

Note. (Disc) Replaced by 33 1 311.(0 492 107)

3 = 0492099 Washer

Note. (Disc) Replaced by 33 1 311.(0 492 107)

4 = 0492100 Washer

Note. (Disc) Replaced by 33 1 311.(0 492 107)

1 = 0492097 Connector

Note. (basic body) For transmission S5D 260Z, S5D 310Z and S5D 320Z

5 = 0492101 Synchronizing key

Note. (Synchronizing key (old))

6 = 0492102 Synchronizing key

7 = 0492103 Synchronizing key

8 = 0492104 Synchronizing key

= 0492105

9 = 0492105 Synchronizing key

Note. For rear axle final drive and for installation of the camshaft sprocket on the crankshaft (M70)

1 = 0492107 Washer

Note. (washer)

2 = 0492108 Synchronizing key

Note. For pulling the bearing inner race off the drive flange - Series: E36/5

Fixture MW

Note. For mounting rear axle final drive during removal and installation.

Consisting of

2 = 0494831 Angle

Note. (Support angle) Replaced by 33 4 425. (0 495 317)

4 = 0495575 Adapter

Note. (mounting adapter) mounting for E85 Z4 M. SI 01 10 06 (264)

Scheme 28

Scheme 28: Fixture MW

1 = 0494829 Plate

Note. (Base plate)

2 = 0494830 Adapter

Note. (adapter kit)

4 = 0494832 Spindle

Note. (spindle with synchronizing key)

5 = 0495317 Angle

Note. (support angle)

Gauge MW

Note. (setting gauge) For aligning bearing support from side member to wheel center

01 19 99 (484)

Scheme 29

Scheme 29: SI number

01 22 06 (307)

01 22 06 (307)

Key MW

Note. (Key) To counter-hold the drive flange - Replaced by universal key

Mandrel Minimum set: Mechanical tools MW

Note. (drift) For driving radial shaft seal onto drive flange.

B26

01 09 09 (532)

Scheme 30

Scheme 30: SI number

Mandrel MW

Replaced by: 0491891

Note. (Drift) Replaced by 31 2 040.(0 491 891)

Replaced by: 0492338

Note. (Drift) For radial seal on output flange - Replaced by 33 3 420.(0 492 338)

Scheme 31

Scheme 31: Mandrel MW

Note. For driving the radial shaft seal of the output shaft into the rear axle final drive. Rear axle final drive: 188

C21

01 22 06 (307)

Scheme 32

Scheme 32: SI number

Replaced by: 0492338

Note. (Drift) For fitting the radial sealing ring, right-hand output end/Replaced by 33 3 420.(0 492 338)

Scheme 33

Scheme 33: Mandrel MW

Note. For driving in shaft seal on drive shaft.

A16

01 21 06 (300)

Scheme 34

Scheme 34: SI number

Replaced by: 0492339

Note. (Drift) For driving the radial seal into the output flange with flange diameter 38 mm - Replaced by 33 3 430.(0 492 339)

Scheme 35

Scheme 35: Mandrel MW

Mounting adapter

Note. Locator for E85 Z4 M. SI 01 10 06 (264)

01 10 06 264

Open-end wrench Minimum set: Mechanical tools MW

Note. Open-end spanner SW50 with retaining clip For releasing and tightening down the insert nuts for the screw connection of the propeller shaft on the rear axle final drive.

A18

01 21 06 (300)

Consisting of

2 = 0495582 Retaining bracket

Scheme 36

Scheme 36: SI number

3 = 0495583 Pin

Note. (Pin with chain (2 x))

1 = 0495581 Basic body

Spindle Minimum set: Mechanical tools MW

Note. (spindle TR12 with nut) For installing and removing rubber mounts, see "In conjunction with".

01 16 08 (476)

Consisting of

3 = 0496555 Nut

Note. (nut M12x1.5 (high wall))

1 = 0496553 Spindle

Note. (spindle TR12)

Scheme 37

Scheme 37: SI number

2 = 0496554 Nut

Note. (nut TR12 with thrust bearing)

Note. (spindle TR20 with nut) For installing and removing rubber mounts, see "In conjunction with".

01 16 08 (476)

Consisting of

1 = 0496535 Spindle

Note. (spindle TR20 (length 300 mm))

3 = 0496551 Nut

Note. (nut TR20)

2 = 0496536 Nut

Note. (nut TR20 with thrust bearing)

Scheme 38

Scheme 38: Thrust piece with splined key

Tool Minimum set: Mechanical tools MW

Note. (Tool set) For removing and installing rear wheel bearings Components 33 4 032, 33 4 038 and 33 4 039 are discontinued and are replaced in the order by 33 4 301, 33 4 302 and 33 4 303

C7

Consisting of

2 = 0492351 Spindle

Note. (Spindle) Series: E28 Replaced by 33 4 301 (0 496 535)

8 = 0492357 Nut

Note. (Nut with bearing) Series: E28 Replaced by 33 4 302 (0 496 536)

5 = 0492354 Washer

Note. (thrust washer) For installing wheel bearing, rear/Series: E28/model: 518, 520i

7 = 0492356 Washer

Note. (thrust washer) For installing wheel bearing, rear/Series: E28/model: 525i, 528i

9 = 0492358 Nut

Note. (nut)

1 = 0492350 Bell housing

Note. For counter support when removing the rear wheel bearing

3 = 0492352 Washer

Note. (thrust washer) For removing wheel bearing, rear/Series: E28/model: 518, 528i

Scheme 39

Scheme 39: Storage Location

4 = 0492353 Sleeve

Note. (guide sleeve) For installing wheel bearing, rear/Series: E28/model: 518, 520i

6 = 0492355 Sleeve

Note. (guide sleeve) For installing wheel bearing, rear/Series: E28/model: 525i, 528i

Note. (installation/removal tool) For removing and installing rubber mounts on rear axle final drive, rear

B34

01 12 95 (992)

Consisting of

1 = 0492427 Pipe

Note. (Support tube) For removing

Scheme 40

Scheme 40: SI number

2 = 0492428 Synchronizing key

Note. For installing

3 = 0492429 Plate

Note. (support plate) For installing

4 = 0492430 Synchronizing key

Note. For removing

Tool MW

Note. (Press-out/-in tool set) For pressing the rubber mount out of and into the control arm special tools 33 3 202 and 33 3 203 for E87 and E90

B32

01 05 90 (207)

Consisting of

1 = 0492261 Bush

Note. For accommodating control arm when pressing out rubber mount Series: E31

2 = 0492262 Thrust piece

Note. For pressing out rubber mount Series: E31, E46, E85, F01, F02

3 = 0492263 Sleeve

Note. (Spacer sleeve) For pressing rubber mount into control arm Series: E31, E46, E85, F01, F02

Scheme 41

Scheme 41: SI number

Note. (Tool set) For removing and installing wheel bearings, rear

C8

Consisting of

3 = 0492362 Nut

Note. Series: E30, E46 Replaced by 33 4 303 (0 496 551)

8 = 0492367 Bush

Note. (Draw-in bushing for rear axle shaft)

Scheme 42

Scheme 42: Storage Location

4 = 0492363 Bell housing

Note. For gripping when removing wheel bearing, rear/series: E30

6 = 0492365 Sleeve

Note. (Guide sleeve) For installing wheel bearing, rear/series: E30

5 = 0492364 Washer

Note. (Pullout disc)

7 = 0492366 Washer

Note. (Thrust washer) For installing wheel bearing, rear

9 = 0492368 Sleeve

Note. (Guide sleeve) For installing wheel bearings

= 0492360

1 = 0492360 Spindle

Note. (Spindle) Series: E30, E46 Replaced by 33 4 301/0 496 535

2 = 0492361 Nut

Note. (Nut with bearing) Series: E30, E46 Replaced by 33 4 302/0 496 536

Note. For removing and fitting camber arm rubber mount on rear axle support.

B49

C49

01 15 04 (117)

Consisting of

1 = 0494977 Washer

Note. (Draw-in disc)

Scheme 43

Scheme 43: SI number

2 = 0494978 Washer

Note. (Pullout disc)

3 = 0494979 Holder

Note. (Counter support)

4 = 0494980 Sleeve

Note. (Support sleeve)

5 = 0494981 Spindle

Note. (spindle 205 mm, M12)

6 = 0494982 Nut

Note. (Thrust nut)

Note. For removing and installing rubber mount of rear axle final drive mounting at rear.

C45

01 14 01 (766)

Consisting of

6 = 0496310 Washer

Note. (disc (draw-in dimension 3.5 mm)) model series: E83, E85 see SI 01 18 07 (396)

Scheme 44

Scheme 44: SI number

1 = 0494049 Bush

2 = 0494050 Washer

4 = 0494052 Washer

5 = 0495623 Washer

Note. (disc (draw-in dimension 5.0 mm)) model series: E85, E86

3 = 0494051 Bush

Note. (slip bush)
