RIDE HEIGHT SPECIFICATIONS
Note. For ride height specifications, see RIDE HEIGHT SPECIFICATIONS (FRONT) or RIDE HEIGHT SPECIFICATIONS (REAR) table.
| Application | In. (mm) | |
|---|---|---|
| Standard Suspension | ||
| 16" Rim | 23.1 (589) | |
| 17" Rim | 23.8 (605) | |
| 18" Rim | 24.2 (617) | |
| 19" Rim | 24.8 (630) | |
| 20" Rim | 25.3 (643) | |
| Sports Suspension | ||
| 16" Rim | 22.5 (574) | |
| 17" Rim | 23.2 (590) | |
| 18" Rim | 23.7 (602) | |
| 19" Rim | 24.2 (615) | |
| 20" Rim | 25.2 (628) | |
RIDE HEIGHT SPECIFICATIONS (FRONT)
| Application | In. (mm) | |
|---|---|---|
| Standard Suspension | ||
| 16" Rim | 22.6 (576) | |
| 17" Rim | 23.3 (592) | |
| 18" Rim | 23.7 (604) | |
| 19" Rim | 24.2 (617) | |
| 20" Rim | 24.8 (630) | |
| Sports Suspension | ||
| 16" Rim | 22.0 (560) | |
| 17" Rim | 22.6 (576) | |
| 18" Rim | 23.1 (588) | |
| 19" Rim | 23.6 (601) | |
| 20" Rim | 24.4 (614) | |
RIDE HEIGHT SPECIFICATIONS (REAR)
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Spring Strut Mount To Wheel House | 25 (34) |
| Tie Rod Clamping Nut | 33 (45) |
| Trailing Arm Console-To-Body Bolt | 57 (77) |
| Upper/Lower Control Arms-To-Trailing Arm (Hexagon Collar Nut) | 81 (110) |
TORQUE SPECIFICATIONS
WHEEL ALIGNMENT SPECIFICATIONS
Car loaded down to normal position. Vehicle with complete equipment for normal operation with: 2 x 68 kg on front seats (seats in central position); 1 x 14 kg in luggage compartment (centre) and full fuel tank. For wheel alignment specifications (Scheme 1)and (Scheme 2).
