ENGINE COMPARTMENT
Engine compartment fuse box (E-Box - A8680) is located at the left rear of engine compartment (Scheme 24)
Scheme 24
Engine compartment fuses are protection for
- F01: 30A - Ignition Coils (1-6)
- F02: 30A Vanos Exhaust Valve Vanos Inlet Valve DME Control Unit Individual Control Intake System Valve Idle Actuator Characteristic Map Cooling Thermostat Fuel Tank Vant Valve
- F03: 20A Camshaft Position Sensor 1 Camshaft Position Sensor 2 Crankshaft Position Sensor Hot Film Mass Airflow Sensor Reverse Light Relay Fuel Tankage Leakage Module E-Box Fan
- F04: 30A Oxygen Sensors (4) Transmission Control Module (w/A\T) Sequential Manual Transmission (SMG)
- F05: 30A - Fuel Injectors Relay
PASSENGER COMPARTMENT
Note. Numbers in text refer to numbers in figures.
Fuse panel (Power Distribution box - A41) is located behind glove box (Scheme 25) To access fuses, open glove box. Press the locks (1, 2) on the left and right. Swing glove box down. (Scheme 26) For identification of fuse assignments (Scheme 27)
Scheme 25
Scheme 26
Scheme 27
LUGGAGE COMPARTMENT
Rear fuse box (A400) is located below luggage compartment floor hatch (Scheme 28)
Scheme 28
Luggage compartment fuses are protection for
- F100: 250A - Passenger Compartment Fuse Box (A41)
- F101: 100A - (2007-08) Integrated Supply Module (IVM)
- F102: 40A - Amplifier (w/Top HiFi Sound System)
FUSE ASSIGNMENT SYMBOL DEFINITIONS
For help determining the meaning of the symbols on fuse assignment legends, see FUSE ASSIGNMENT SYMBOL DEFINITIONS.
