Passenger"s sport seat circuit for BMW Z3 E36 facelift (2000-2002)
Passenger"s sport seat circuit
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
FRONT POWER DISTRIBUTION BOX (ON LEFT REAR CORNER OF ENGINE COMPT)
FWD BACK
GRN WIRE
HOT AT ALL TIMES FUSE
NCA WIRE
ORG/ WIRE
PASS- ENGER'S SEAT CONTROL SWITCH
PASS- ENGER'S SEAT TILT ADJUST CUT-OFF RELAY (UNDER RIGHT FRONT SEAT)
PASSENGER'S SEAT HEIGHT MOTOR
PASSENGER'S SEAT LENGTH ADJUST CUT-OFF RELAY (UNDER RIGHT FRONT SEAT)
PASSENGER'S SEAT LIMIT SWITCH (UNDER RIGHT FRONT SEAT)
PASSENGER'S SEAT MOVEMENT MOTOR
RED/BLK WIRE
SEAT HEIGHT SWITCH
SEAT POSITION SWITCH
UP DOWN
VIO WIRE
WHT WIRE
