Wiring diagram: Ground distribution — Ground distribution circuit BMW Z3 E36 facelift

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• 2 1
• 3 2
• A/C Relay, Motronic Wiper/ Washer Module
• A/C Relay/ Auxiliary Water Pump
• Air Conditioning/ Recirculating Switch Assembly2
• Air Conditioning/ Recirculation Switch Assembly
• Analog Clock2
• Anti- Theft Horn Dwa Siren
• Asc Switch Or Dsc Switch
• Auxiliary Fan Motor
• Auxiliary Water Pump
• Blower Motor2
• Blower Relay
• Board Computer
• Body Electronics Control Module2
• Brake Fluid Level Switch
• Canada
• Cd-Changer
• Central Locking Luggage Compartment Lid Motor Relay Left High Beam Light
• Chime Module
• Clutch Switch Remote Control Module
• Clutch — Switch
• Combination Switch
• Contact Ring
• Convertible Top Actuating Switch
• Convertible Top Relay
• Convertible Top Relay Ii
• Convertible Top-End Position Micro- Switch
• Coupe Roadster
• Crash Control Module
• Driver Seat Heater Switch
• Driver Side Impact Sensor
• Driver'S Power Window Switch
• Driver'S Seat Belt Switch
• Driver'S Seat Control Switch
• Driver'S Seat Control Switch Rear Defogger 1
• Driver'S Seat Heater
• Driver'S Seat Limit Switch
• Driver'S Seatback Heater
• Driver'S Side Mirror Mirror Control Switch
• Driver'S Window Motor Wiper/ Washer Switch
• Drivers Door Jamb Switch
• Dynamic Stability Control Unit
• E-Box Fan
• Early Production, M Versions W/ Dsc
• Electric Fuel Pump Relay, Times
• Electronic Immobilizer Control Module
• Engine Control Module
• Engine Hood Switch Front Lid Micro Switch
• Evaporator Controller2
• Evaporator Temperature Sensor2
• Fresh Air Recirculation Motor2
• Front Ashtray Light
• Front Cigar Lighter
• Front Cigar Lighter Light
• Front Dome Light/ Map Reading Assembly
• Gear Shift Lever Indicator
• Gear Step Transmission Switch
• Hard Top Connector 1
• Hazard Flasher Relay
• Hazard Switch
• Headlight/ Foglight Washer Pump
• Heat/ A/C Control Panel Illumination
• Heating/ A/C Control Panel
• Hifi Amplifier
• Ignition Coils
• Ignition — Switch
• Illumination
• Injection Valves Relay
• Instrument — Cluster2
• Late Production
• Late Production W/ Dsc
• Left Back-Up Light Left Brake Light
• Left Front Auxiliary Turn Light Left Front Turn Light
• Left Front Interior Light
• Left Front Marker Light
• Left Front Speed Sensor
• Left Headlamp Left Park Light
• Left License Plate Light
• Left Low Beam Light Data Link Connector
• Left Rear Light Assembly
• Left Washer Jet Heater
• Light Switch Left Park Light Relay
• Luggage Compart- Ment
• Luggage Compartment Light Switch
• Luggage Compartment Lock Motor
• M Versions With Dsc
• Obd Ii Connector2
• Oil Temperature Gauge
• Oil/Outside Temperature Gauge Control Module
• On-Board Computer Temperature Sensor Electro- Chromic Rear View Mirror
• Outside Temperature Gauge
• Passen- Ger'S Seat Heater
• Passenger Seat Heater Switch
• Passenger'S Door Jamb Switch
• Passenger'S Power Window Switch
• Passenger'S Seat Control Switch
• Passenger'S Seat Control Switch Passenger'S Seat Length Adjust Cut-Off Relay
• Passenger'S Seat Limit Switch
• Passenger'S Seat Tilt Adjust Cut-Off Relay
• Passenger'S Seatback Heater
• Passenger'S Side Mirror
• Passenger'S Window Motor
• Passengers Seatbelt Switch
• Pre- Charge Pump
• Pressure Switch
• Radio Anti- Theft Switch
• Rear Defogger
• Rear Window Defogger Switch
• Rear Wiper/Washer Interval Control Module
• Resistor 240 Ohm
• Right Back- Up Light Right Brake Light
• Right Front ABS Speed Sensor
• Right Front Auxiliary Turn Light
• Right Front Marker Light
• Right Headlight Right Park Light
• Right License Plate Light
• Right Park Light/License Plate Light Relay
• Right Rear Brake Pad Sensor
• Right Rear Light Assembly
• Right Washer Jet Heater
• Roadster
• Seat Occupancy Detector
• Secondary Air Pump Relay2
• Slip Control Module
• Starter Immobilization Switch
• Steering Angle Sensor
• Subwoofer Amplifier Module Subwoofer
• Supplemental Restraint System Control Module Passenger'S Side Impact Sensor
• Suppression Capacitor
• Telephone Connector
• Temperature Switch
• Thermal Oil Level Sensor Control Module Anti- Theft Control Module
• Thermal Oil Level Switch
• Tilt Sunroof Switch
• Tire Pressure Warning System Pushbutton
• Transmission Control Module
• Transmission Position Indicator Light
• Unloader Relay
• Variable Camshaft Control Valves
• W/O Hard Top Pro- Vision W/ Hard Top Pro- Vision
• W/O Headlight Washer
• W/O Sport Seat
• W/O Sport Seat Package W/ Sport Seat Package
• Wiper/ Washer Module
