Engine- Special Tools - M-Coupe & Z3 (E36): Other BMW Z3 E36 рестайлинг

Mechanical 40 illustrations ~454 words

11 0 000 Engine lifter for removing and installing engines

Minimum set: Mechanical tools

EngineM10, M47T2, M47TU, M52, M52TU, M54, M56, M60, M62, M67, M70, M73, N52, N62, N73, S14, S54, S62, W10, W11
SI number1 13 94 (888)
Order number11 0 000
Engine lifter for removing and installing engines
Consisting of
1 = 11 0 001Lifting beam
2 = 11 0 002Chain, long
3 = 11 0 003Chain, short
4 = 11 0 009Shackle (2 x)

SPECIAL TOOL

Scheme 401

Scheme 401
Scheme 401

11 0 070 Engine hoist

NoteFor removing and installing engines
EngineM10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N45, N46, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
SI number1 16 96 (107)
Order number11 0 070
Engine hoist
Consisting of
1 = 11 0 071Lifting beam
2 = 11 0 072Carrying chain, long
3 = 11 0 073Carrying chain, short
4 = 11 0 079Shackle (2 x)

SPECIAL TOOL

Scheme 402

Scheme 402
Scheme 402

11 0 190 Accessories

In conjunction with11 1 060, 11 1 065, 11 1 067, 11 3 131, 11 3 132
NoteFor removing and installing valve springs
EngineM20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M57, M60, M62, M70, M73, S14, S38, S50B30, S50B32, S54, S62
SI number1 09 91(416)
Order number11 0 190
Accessories
Consisting of
2 = 11 0 192Guide tube
NOTE: Engine: all
4 = 11 0 194Valve spring cage
NOTE: Engine: M41, M51, S50
NOTE
Engine: all
NOTE
Engine: M41, M51, S50

SPECIAL TOOL

Scheme 403

Scheme 403
Scheme 403

11 0 240 Coupling

In conjunction with11 0 222, 11 0 226, 11 0 227, 11 0 225
NoteFor adapting test probes to pressure gauge 11 0 162
EngineAll models
Order number11 0 240
Coupling

SPECIAL TOOL

Scheme 404

Scheme 404
Scheme 404

11 0 280 Holder

Minimum set: Mechanical tools

NoteFor holding central bolts during loosening and tightening operations
EngineS54, S85
SI number1 15 00(609)
Order number11 0 280
Holder

SPECIAL TOOL

Scheme 405

Scheme 405
Scheme 405

11 0 340 Accessories

In conjunction with11 1 060
NoteFor removing and installing valve springs Engine: M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M57, M57D25, M57D30, M60, M62, M70, M73, N40, N42, N62, N73, S14, S38, S50B30, S50B32, S54, S62
SI number1 12 93(701)
Order number11 0 340
Accessories
Consisting of
1 = 11 0 341Valve spring cage
NOTE: Engine: M43, M73
2 = 11 0 342Pressure lever
NOTE: Engine: all, except M10
3 = 11 0 343Hook
NOTE: Length 220 mm - Engine: all, except M10
5 = 11 0 345Valve spring cage
NOTE: Engine: M44, M52, M62, S62, S54
6 = 11 0 346Valve spring cage
NOTE: Engine: M47, M47TU, M57, N40, N42
NOTE
Engine: M43, M73
NOTE
Engine: all, except M10
NOTE
Length 220 mm - Engine: all, except M10
NOTE
Engine: M44, M52, M62, S62, S54
NOTE
Engine: M47, M47TU, M57, N40, N42

SPECIAL TOOL

Scheme 406

Scheme 406
Scheme 406

11 1 200 Drift

Minimum set: Mechanical tools

NoteFor fitting valve stem seals
EngineM20, M21, M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, S14, S38, S50B30, S50B32, S54, S62
Storage locationB14, C14
Order number11 1 200
Drift

SPECIAL TOOL

Scheme 407

Scheme 407
Scheme 407

11 1 260 Impact bush

Minimum set: Mechanical tools

In conjunction with00 5 500
NoteFor fitting rotary shaft seal in rear crankshaft end cover
EngineM10, M20, M21, M30, M40, M41, M42, M43, M44, M47, M50, M51, M52, M57, M57D25, M57D30, S14, S38, S50B30, S50B32, S54
Storage locationC19
SI number1 03 95(900)
Order number11 1 260
Impact bush

SPECIAL TOOL

Scheme 408

Scheme 408
Scheme 408

11 1 430 Fixture

In conjunction with11 0 316 (M42, M44), 11 1 450 (M50, M52, S50)
NoteFor pressure testing cylinder head
EngineM42, M44, M50, M52, S50B30, S50B32, S54
SI number1 05 89(099)
Order number11 1 430
Fixture
Consisting of
1 = 11 1 431Sealing strip
NOTE: With 5 pins and rubber seal Engine: M42, M44, M50, M52, S54
2 = 11 1 432Rubber seal
NOTE: For sealing strip 11 1 431 - Engine: M42, M44, M50, M52
3 = 11 1 433Sealing strip
NOTE: With 7 pins and rubber seal Engine: M42, M44, M50, M52, S54
4 = 11 1 434Rubber seal
NOTE: For sealing strip 11 1 433 - Engine: M42, M44, M50, M52
5 = 11 1 435Formed plate
NOTE: With rubber seal - Engine: M42, M44
6 = 11 1 436Bridge
NOTE: With rubber seal and 2 screws Engine: M42, M44
7 = 11 1 437Screw plug
NOTE: With valve and standard clip Engine: M42, M44, M50, M52, S50
8 = 11 1 438Screw plug and standard clip
NOTE: Engine: M42, M44, M50, M52
9 = 11 1 439Standard parts
NOTE: Engine: M42, M44, M50, M52
NOTE
With 5 pins and rubber seal Engine: M42, M44, M50, M52, S54
NOTE
For sealing strip 11 1 431 - Engine: M42, M44, M50, M52
NOTE
With 7 pins and rubber seal Engine: M42, M44, M50, M52, S54
NOTE
For sealing strip 11 1 433 - Engine: M42, M44, M50, M52
NOTE
With rubber seal - Engine: M42, M44
NOTE
With rubber seal and 2 screws Engine: M42, M44
NOTE
With valve and standard clip Engine: M42, M44, M50, M52, S50
NOTE
Engine: M42, M44, M50, M52
NOTE
Engine: M42, M44, M50, M52

SPECIAL TOOL

Scheme 409

Scheme 409
Scheme 409

11 1 480 Pliers

Minimum set: Mechanical tools

NoteFor removing valve stem seal
EngineM40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N52, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11
Storage locationA10, B10
SI number1 01 93(621)
Order number11 1 480
Pliers

SPECIAL TOOL

Scheme 410

Scheme 410
Scheme 410

11 2 030 Drift

Minimum set: Mechanical tools

In conjunction with00 5 500
NoteFor driving the guide bearing into the crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving the centering support into the propeller shaft
SeriesE28, E30, E32, E34, E36, E38, E39, E46, E52, E65, E66, E85, E87, E90, RR1
Storage locationA28
Order number11 2 030
Drift

SPECIAL TOOL

Scheme 411

Scheme 411
Scheme 411

11 2 050 Guide pins

Minimum set: Mechanical tools

NoteFor installing pistons for engines with M10x1.25 conrod bolts
EngineM21, M43, M43TU, M70, M73, N40, N42, N45, N46, S54
Storage locationA1, B1
Order number11 2 050
Guide pins

SPECIAL TOOL

Scheme 412

Scheme 412
Scheme 412

11 2 170 Holder

Minimum set: Mechanical tools

NoteFor locking flywheel in position
EngineM20, M21, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, S50B30, S50B32, S54
Storage locationC4
Order number11 2 170
Holder

SPECIAL TOOL

Scheme 413

Scheme 413
Scheme 413

11 2 300 Plug mandrel

Minimum set: Mechanical tools

NoteFor locking crankshaft in ignition TDC position when adjusting timing
EngineM21, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, M70, M73, S50B30, S50B32, S54, S62
Storage locationC32
Order number11 2 300
Plug mandrel

SPECIAL TOOL

Scheme 414

Scheme 414
Scheme 414

11 2 340 Extractor

Minimum set: Mechanical tools

In conjunction with11 2 016 (M60, M62)
NoteFor guide bearing in crankshaft, stem diameter 15 mm
EngineM41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, M70, M73, N40, N42, N45, N46, S50B30, S50B32, S54, S62, S85
Storage locationC26
SI number1 05 90(207)
Order number11 2 340
Extractor
Consisting of
1 = 11 2 341Extractor claw with threaded bush
2 = 11 2 342Extractor claw
3 = 11 2 343Pressure spindle
4 = 11 2 344Sleeve

SPECIAL TOOL

Scheme 415

Scheme 415
Scheme 415

11 2 350 Drift

Minimum set: Mechanical tools

NoteFor fitting guide bearing of crankshaft
EngineM41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M70, M73, N40, N42, N45, N46, S50B30, S50B32, S52US, S54, S62, S85
Storage locationA28
SI number1 05 90(207)
Order number11 2 350
Drift

SPECIAL TOOL

Scheme 416

Scheme 416
Scheme 416

11 2 380 Puller

Minimum set: Mechanical tools

NoteFor removing rotary shaft seal from timing case cover
Engine: M41, M47, M50, M51, M52, M52TU, M54, M56, M60, M62, S50B30, S50B32, S54, S62, W10, W11
Storage locationA38, C25
SI number1 05 92(507)
Order number11 2 380
Puller
Consisting of
1 = 11 2 381Threaded bell housing
2 = 11 2 382Spindle
3 = 11 2 383Thrust piece
NOTE: Engine: M41, M47, M50, M51, M52, M60, M62, PENT
11 2 384Thrust piece
NOTE: Engine: S50, S54
11 2 385Spacer bushing
NOTE: Engine: M41, M50, M51, M52
11 2 386Thrust piece
NOTE: Engine: S62
NOTE
Engine: M41, M47, M50, M51, M52, M60, M62, PENT
NOTE
Engine: S50, S54
NOTE
Engine: M41, M50, M51, M52
NOTE
Engine: S62

SPECIAL TOOL

Scheme 417

Scheme 417
Scheme 417

11 3 160 Holder with feeler gauges

Minimum set: Mechanical tools

NoteFor adjusting valves
EngineM88, S14, S38, S54
StorageLocation: B30, C30
Order number11 3 160
Holder with feeler gauges
Consisting of
1 = 11 3 161Support bracket
2 = 11 3 162Feeler gauges (5)
NOTE: 0.25 / 0.30 / 0.35 / 0.40 / 0.45 mm
3 = 11 3 163Feeler gauges (2)
NOTE: 0.15 / 0.20 mm - engine: S54
NOTE
0.25 / 0.30 / 0.35 / 0.40 / 0.45 mm
NOTE
0.15 / 0.20 mm - engine: S54

SPECIAL TOOL

Scheme 418

Scheme 418
Scheme 418

11 4 190 1/4" extension piece

Minimum set: Mechanical tools

In conjunction with11 3 390, 00 2 050
NoteM73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
SeriesAll models
Storage locationB6
SI number1 06 94(801)
Order number11 4 190
1/4" extension piece

SPECIAL TOOL

Scheme 419

Scheme 419
Scheme 419

11 4 380 Press-down device

NoteFor pressing down camshaft
EngineS54
SI number1 15 00(609)
Order number11 4 380
Press-down device
Consisting of
1 = 11 4 381Device
2 = 11 4 382Screws (2 x)
3 = 11 4 383Screws (2 x)

SPECIAL TOOL

Scheme 420

Scheme 420
Scheme 420

11 4 390 Adapter screw

In conjunction with13 3 063 and 13 3 061
NoteFor oil pressure testing
EngineS50B32, S54
SI number1 15 00(609)
Order number11 4 390
Adapter screw

SPECIAL TOOL

Scheme 421

Scheme 421
Scheme 421

11 4 400 Holder with magnet

NoteFor removing and installing valve adjustment plates
EngineS54
SI number1 15 00(609)
Order number11 4 400
Holder with magnet

SPECIAL TOOL

Scheme 422

Scheme 422
Scheme 422

11 5 030 Holder

Minimum set: Mechanical tools

NoteFor pulley on water pump when releasing and tightening fan / Model year: From 80
EngineM10, M20, M21, M30, M50, M51, M52, M52TU, M54, M56, M70, M73, S14, S38, S50B30, S50B32, S54
Storage locationB3, C3
Order number11 5 030
Holder

SPECIAL TOOL

Scheme 423

Scheme 423
Scheme 423

11 5 040 Open-ended spanner WAF 32

Minimum set: Mechanical tools

In conjunction withTorque wrench 3/8" connection
NoteFor loosening and tightening fan wheel
EngineM10, M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M60, M62, M70, M73, M88, N42, N62, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62
Storage locationA11, B11
SI number1 01 87(670)
Order number11 5 040
Open-ended spanner WAF 32

SPECIAL TOOL

Scheme 424

Scheme 424
Scheme 424

11 5 090 Fixture

In conjunction with11 1 220
NoteFor fitting rotary shaft seal on crankshaft in timing case cover
EngineS50B30, S50B32, S54
Storage locationA16
SI number1 12 92(606)
Order number11 5 090
Fixture

SPECIAL TOOL

Scheme 425

Scheme 425
Scheme 425

11 5 100 Adapter with socket wrench

NoteFor turning over engine at crankshaft when adjusting valve timing
EngineS50B30, S50B32, S54
Storage locationA15
SI number1 12 92(606)
Order number11 5 100
Adapter with socket wrench

SPECIAL TOOL

Scheme 426

Scheme 426
Scheme 426

11 7 020 Socket wrench socket WAF 22

Minimum set: Mechanical tools

NoteFor loosening and tightening oxygen sensor
EngineM10, M20, M30, M40, M42, M50, M52TU, M54, M56, M57, M60, M70, M73, N42, N45, N46, S14, S38, S50B30, S50B32, S50US, S52US, S54
Storage locationC13
Order number11 7 020
Socket wrench socket WAF 22

SPECIAL TOOL

Scheme 427

Scheme 427
Scheme 427

11 7 030 Socket wrench socket WAF 22

Minimum set: Mechanical tools

NoteFor loosening and tightening oxygen sensor
EngineM40, M43, M43TU, M44, M52, M52TU, M54, M56, M62, N40, N42, N45, N46, N62, N62TU, N73, S54, S62
Storage locationB15
SI number1 06 95(963)
Order number11 7 030
Socket wrench socket WAF 22

SPECIAL TOOL

Scheme 428

Scheme 428
Scheme 428

11 7 130 Connection piece

NoteFor compressed air hose for applying compressed air to VANOS unit during assembly
EngineS54, S62
SI number1 23 98(390)
Order number11 7 130
Connection piece

SPECIAL TOOL

Scheme 429

Scheme 429
Scheme 429

11 7 160 Hook wrench

NoteFor adjusting spline hub on camshaft when fitting helical gearing of VANOS adjustment unit
EngineS54
SI number1 15 00(609)
Order number11 7 160
Hook wrench

SPECIAL TOOL

Scheme 430

Scheme 430
Scheme 430

11 7 200 Plug-on tool

In conjunction withCommercially available torque wrench
NoteOpen-ended spanner WAF 10 for tightening threaded connection of VANOS gear unit
EngineS54, S62
SI number1 23 98(390)
Order number11 7 200
Plug-on tool

SPECIAL TOOL

Scheme 431

Scheme 431
Scheme 431

11 7 240 Slip bush

NoteFor installing shaft seal in timing case cover
EngineS50B30, S50B32, S50US, S54
Storage locationB42
SI number1 15 00(609)
Order number11 7 240
Slip bush

SPECIAL TOOL

Scheme 432

Scheme 432
Scheme 432

11 8 040 Engine support plate

In conjunction with00 1 450
NoteFor securing engine on assembly stand
EngineM41, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, S50B30, S50B32, S54
SI number1 09 94(839)
Order number11 8 040
Engine support plate

SPECIAL TOOL

Scheme 433

Scheme 433
Scheme 433

11 9 000 Cylinder head expander tool

Minimum set: Mechanical tools

In conjunction withAssembly stand 00 1 450
EngineM10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N45, N46, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Storage locationSingle
SI number1 03 02 (833)
Order number11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001Fixture
2 = 11 9 002Rod
3 = 11 9 003Sliding block with M10 thread
4 = 11 9 004Tab
5 = 11 9 005Quick tensioner
6 = 11 9 006Aluminium profile insert
7 = 11 9 007Slide
8 = 11 9 008Profile plastic part
9 = 11 9 009Lever
10= 11 9 011Hook
11= 11 9 012Valve spring cage
NOTE: Engine M41, M51, S50
12= 11 9 013Valve spring cage
NOTE: Engine M43, M73
13= 11 9 014Valve spring cage
NOTE: Engine M44, M52, M54, M56, M62, S52, S54, S62
14= 11 9 015Valve spring cage
NOTE: Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
15= 11 9 016Valve spring cage
NOTE: Engine M21, M40
16= 11 8 421Valve spring cage
NOTE: Engine: W10, W11, W17
18= 11 9 017Valve spring cage
NOTE: Engine N52
NOTE
Engine M41, M51, S50
NOTE
Engine M43, M73
NOTE
Engine M44, M52, M54, M56, M62, S52, S54, S62
NOTE
Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
NOTE
Engine M21, M40
NOTE
Engine: W10, W11, W17
NOTE
Engine N52

SPECIAL TOOL

Scheme 434

Scheme 434
Scheme 434

11 9 120 Piston pliers

NoteFor piston installation - new piston diameter 87.0 mm
EngineS54
SI number1 15 00(609)
Order number11 9 120
Piston pliers

SPECIAL TOOL

Scheme 435

Scheme 435
Scheme 435

11 9 130 Setting gauge

In conjunction with11 7 342
NoteWith correction angle for control diagram
EngineS54
SI number1 15 00(609)
Order number11 9 130
Setting gauge

SPECIAL TOOL

Scheme 436

Scheme 436
Scheme 436

11 9 140 Gauge

NoteFor control diagram
EngineS54
SI number1 15 00(609)
Order number11 9 140
Gauge

SPECIAL TOOL

Scheme 437

Scheme 437
Scheme 437

11 9 150 Special wrench

Minimum set: Mechanical tools

In conjunction with11 7 030
NoteFor releasing and tightening down oxygen sensors
EngineM54, M56, N42, N45, N46, N62, N62TU, N73, S54
Storage locationA42
SI number01 15 00 (609)
Order number11 9 150
Special wrench

SPECIAL TOOL

Scheme 438

Scheme 438
Scheme 438

11 9 160 Pliers

NoteFor opening and closing hose clips on intake manifold
EngineS54
SI number1 15 00 (609)
Order number11 9 160
Pliers

SPECIAL TOOL

Scheme 439

Scheme 439
Scheme 439

11 9 170 Spacer

NoteFor maintaining a prespecified distance during installation of VANOS adjustment unit
EngineS54
SI number1 15 00(609)
Order number11 9 170
Spacer

SPECIAL TOOL

Scheme 440

Scheme 440
Scheme 440

More articles — Engine- Special Tools - M-Coupe & Z3 (E36)
