Front Power Distribution Box

For location of engine compartment Front Power Distribution Box (Scheme 1) For Front Power Distribution Box fuse assignments (Scheme 2)

Scheme 1: Front Power Distribution Box

Fuse holder is located right rear of engine compartment, in e-box.

Right Rear Fuse Holder fuses protect

F201: 15A - High Beam Light Relay
F202: 30A Fuel Injectors (1-6) Engine Control Module (DME) Variable Camshaft Control Valves (1 and 2) Individual Control Intake System Valve Idle Speed Control Valve Evaporative Emission Valve Secondary Air Pump Valve
F203: 20A Front Power Distribution Box (Fuse F13) Camshaft Position Sensors (1 and 2) Thermostat Characteristic MAP Cooling Hot Film Mass Air Meter Crankshaft Position/RPM Sensor
F204: 30A Oxygen Sensors (4) Leakage Diagnosis Pump Secondary Air Pump Relay Solenoid Valve (Running Losses) Transmission Control Module (EGS)
F205: 30A - Unloader Relay

B+ Junction Point is located under left side of dash.

B+ Junction Point fuses protect

F101: 80A - Fuse F34 in Engine Compartment Front Power Distribution Box
F102: 80A - Fuses F14, F18, F20 in Engine Compartment Front Power Distribution Box, and Passenger Compartment Auxiliary Fuse Box
F103: 80A - Fuses F1, F2, F6, F19 in Engine Compartment Front Power Distribution Box, Data Link Connector, High Beam Light Relay or Daylight Relay Module
F104: 80A - Fuses F5, F7, F8 F9, F10 in Engine Compartment Front Power Distribution Box, Front Fog Light Relay, Low Beam Light Relay
F105: 80A - Fuses F37, F38 in Engine Compartment Front Power Distribution Box
F106: 50A - Ignition Switch
F107: 50A - Secondary Air Pump Relay
F108: 80A - Engine Compartment B+ Junction Point in E-Box

Auxiliary Fuse Box is located under left side of dash.

Auxiliary Fuse Box fuses protect

Fuse Holder is located under left side of dash.

Fuse Holder fuse protects
