Residual Pressure

Fuel injection systems require a residual pressure to present after the engine is switched off. This allows the engine to start immediately after the vehicle has been parked.

If the residual fuel pressure diminishes after the vehicle has been shut off. Upon restart, there will be an extended cranking period before engine start. This is due to the fuel pump attempting to supply enough fuel for startup.

When the fuel system is at rest, there a three components which allow the fuel system to retain sufficient residual pressure. These items are, the fuel pump check valve, the fuel pressure regulator and the fuel injectors.

Scheme 167

If any of these items are leaking and fail to hold pressure in the fuel rail, the vehicle will be difficult to start. The cranking time will be excessive and possibly not start at all. For example, If the fuel injectors are leaking, the vehicle will exhibit black smoke on startup.

Diagnosis of these concerns requires a fuel pressure gauge. The residual pressure is monitored on the fuel pressure gauge when the engine is shutoff. Diagnosis is determined by watching the drop in fuel pressure over time. The fuel pressure should not drop more than .5 bar in 30 minutes. If the pressure drops more than .5 bar, the concern should be investigated.

Scheme 168

Depending on the type of fuel system used, diagnosis will vary. On older fuel systems, diagnosis is simplified due to the ability to clamp off certain components to determine, the origin of the leakdown.

Scheme 169

Newer fuel system use a non-return type fuel system with some components mounted externally. Most recently, many of the new vehicle have most of the fuel system components mounted in the fuel tank. This includes the fuel pump, fuel filter and fuel pressure regulator. The only fuel system component outside the fuel tank is the fuel feed line, fuel rail and fuel injectors.

This makes the diagnosis of residual pressure concerns more difficult. Diagnosis of this type of system sometimes requires process of elimination.

If one or more of the fuel injectors is suspected as the cause of the loss in residual fuel pressure. They can be tested using a special tool to "bubble test" the injectors.

Scheme 170

First the injectors are connected to the test fuel rail supplied with the tool. Then, the fuel injectors are subjected to compressed air. The injectors are then triggered by the test harness to "blow out" any residual fuel.

The test harness is disconnected and the tips of the injectors are immersed in water. The injector tips are observed for any bubbles over time. Any excessive bubbles indicate a defective injector.

Engine Adaptation Values

Engine adaptation values can be broken down into two categories

1. Additive Mixture Adaptation - additive adaptation refers to "long term fuel trim". These adaptation are made by the ECM (DME) at idle during "closed loop" fuel control. These values are measured in milliseconds and are expressed in negative and positive values.
2. Multiplicative Mixture Adaptation - multiplicative adaptation occurs during part load conditions and are performed by the ECM during "closed loop" fuel control. These values are measured in percent and are also expressed as negative and positive values. This is also referred to as "short term fuel trim".

Additive mixture adaptation corrects for variations in idle mixture. The ECM monitors the oxygen sensor signals to evaluate the exhaust mixture. When a lean (or rich) mixture is detected, the ECM increases (or decreases) the injector "on-time" to correct accordingly.

As long as the fuel trim correction is not excessive, the ECM will not register a fault code. The ECM will correct in increments of +/- .1 ms. When the fuel trim correction exceeds a predetermined threshold value, the check engine light (MIL) will illuminate and store appropriate fault codes for additive mixture adaptation.

Additive values which are excessively positive, would indicate a lean condition. This can be caused by

1. Un-metered air leaks - such as broken vacuum lines or a leaky intake manifold or gasket.
2. Faulty crankcase ventilation system - crankcase vent valve stuck open.
3. Low fuel pressure - Faulty fuel pressure regulator or fuel pump.
4. Faulty HFM - can be sending erroneous load signal information which would cause the ECM to falsely enrich the mixture.

Additive values which are excessively negative, would indicate a rich condition. This can be caused by

1. An air restriction - any restriction to airflow such as a clogged air filter would create a rich fuel mixture. (this may also be indicated by negative multiplication values)
2. Faulty crankcase ventilation system - crankcase vent valve stuck closed.
3. High fuel pressure - Possible faulty fuel pressure regulator or restricted return line
4. Faulty HFM - can be sending erroneous load signal information which would cause the ECM to falsely lean out the mixture.

Note. Some newer engine management systems use the term mg/stroke or milligrams per stroke. Treat these values as you would millisecond values.

Multiplicative mixture adaptation corrects for variations in fuel mixture under part load conditions. The ECM monitors the oxygen sensor signals to evaluate the exhaust gas mixture. When a lean (or rich) mixture is detected the ECM adjusts the injector "on-time" accordingly over a "short term" period to adapt for the existing situation.

Multiplicative values are expressed in percent and can be negative or positive. Negative values indicate a rich mixture and positive values indicate a lean mixture. When the Multiplicative values exceed a predetermined threshold value, the check engine light (MIL) will illuminate and store relevant fault codes for Multiplicative adaptation.

When multiplicative values are excessively positive, a lean condition exists. The ECM is attempting to add fuel to maintain the proper fuel mixture (close to lambda value 1). This situation can be caused by a faulty HFM, low fuel volume, restricted fuel filter or faulty fuel pressure regulator.

When the values are negative, the ECM is attempting to lean out (remove fuel) the fuel mixture to compensate for a rich condition. This can be caused by

1. Excessive fuel pressure - from a faulty fuel pressure regulator or restriction in the return line.
2. A faulty HFM - the HFM can be sending erroneous load signal information which would cause the ECM to falsely enrich the mixture.
3. An Air restriction - any restriction to airflow such as a clogged air filter would create a rich fuel mixture.
4. Any system failure which would cause the mixture to be falsely enriched. This could be caused by erroneous signal information from sensors such as the engine coolant temperature sensor or intake air temperature sensor.

Smooth Running Measurement

The DISplus/GT-1 are helpful in pinpointing the cause of an engine misfire. Once the short test is completed, the fault memory of the ECM can be read out to determine which cylinder or cylinders have set misfire faults. There may or may not be any faults present. The engine could be running rough, however no misfire thresholds may have been exceeded.

Engine smoothness can be further evaluated by looking at the smooth running values. In the "Control Unit Functions" screen under "Diagnosis Requests" there is a value indicated for each cylinder which can be compared for each cylinder. This value is an indication of crankshaft speed variations in each cylinder.

Scheme 171

Valvetronic N62

In addition to the usual valvetrain diagnosis, the Valvetronic system has some additional components which need to be taken into consideration during diagnosis. The tolerances on the eccentric shaft and intermediate levers are critical in maintaining proper cylinder filling especially at idle. Any deviations in tolerances of these components will contribute to rough running complaints.

The intermediate levers are available in 5 classifications, the classification numbers are marked on the levers. On the N62, each cylinder head must use intermediate levers with the same classification. It is not necessary to have the same classification between cylinder heads.

Scheme 172

Depending on the engine/vehicle, the minimum valve lift can be set from .3 to .8 mm. At these low valve lifts, any variation in tolerance will affect idle quality. When a diagnosis determines that there is a problem in the Valvetronic system, the components need to be inspected. The intermediate levers or eccentric shaft can be worn. The intermediate levers could be of the wrong classification.

The illustration below shows a worn eccentric shaft. The areas shown should be inspected for any wear. Grooves and scoring indicate a worn eccentric shaft which should be replaced.

Scheme 173

The following pages contain testing information which will assist in the diagnosis of idle quality concerns on the N62.

MKA Adapter

The Multi-Channel Adapter (MKA) tool is used in conjunction with the DISplus to diagnose ignition and injection system concerns on the N62 engine. The MKA adapter is installed (in series) between the ECM and the engine harness at connectors 1, 3 and 5. In addition the four cables of MFK 2 are plugged into the MKA as well.

Scheme 174

The MKA test module is found under the path > Service Functions > Drive > Engine Management ME9 > Test Runs > Ignition and Injection diagnosis N62.

The MKA engine test checks the integrity of the ignition system by looking at the primary ignition voltage on each cylinder.

The injection system is also checked by examining the voltage pattern of the injection circuit.
