TORQUE CONVERTER

In standard transmissions the crankshaft is linked to the transmission input shaft via the clutch assembly. Power flows from the crankshaft through the flywheel. The pressure plate transfers power to the clutch disc which is splined to the transmission input shaft. The pressure plate is used to disconnect (or interrupt) power flow to the transmission input shaft. Because the engine is mechanically connected to the driveline, power flow must be interrupted when the vehicle is stationary. Otherwise the engine would stall. In automatic transmissions, there is a fluid coupling between the engine and transmission. This fluid coupling is more commonly referred to as the torque converter. In the torque converter there is no rigid connection between the engine and transmission (except for lock up clutch). In order to understand the operation of the torque converter, we must first start with the components. The breakdown of the components are as follows

1. The Impeller, which is rigidly connected to the torque converter housing.
2. The Turbine, which is splined to the input shaft (turbine shaft) of the transmission.
3. The Stator, which has a one-way clutch. The inner race of the one-way clutch is splined to a stationary shaft attached to the transmission. (Scheme 107)

The addition of the stator allows the fluid coupling to be referred to as a torque converter. The stator provides for a multiplication of torque at low speeds. Without the stator there would be no multiplication of torque.

Scheme 107

When the engine is running, the impeller which is directly connected to the converter housing, rotates at engine speed. Fluid is directed from the impeller blades to the turbine blades. The fluid drives the turbine which is splined to the input (turbine) shaft of the transmission. This functions the same way as a waterfall acting on a paddle wheel. The ratio of the impeller speed to turbine speed is approximately 1.1 to 1. This ratio is improved to 1:1 with the addition of the torque converter clutch which is discussed later.

Scheme 108

1. At low engine speeds there is a large difference in rotational speed between the impeller and the turbine
2. Fluid flow is directed from the impeller to the turbine. Fluid strikes the vanes of the turbine. The turbine is driven forward in the direction of engine rotation.
3. Fluid flow is then directed back towards the impeller.
4. Before the fluid reaches the impeller, the fluid strikes the vanes of the stator.
5. When the fluid strikes the stator, the one way clutch prevents the stator from rotating.
6. The fluid is then re-directed by the curved vanes of the stator. The fluid is now flowing in the same direction as the impeller.
7. The fluid that is acting on the impeller increases the force on the impeller which multiplies torque. (Scheme 108)

Scheme 109

1. As engine speed increases, the turbine speed approaches the speed of the impeller.
2. The fluid flow is directed from the turbine to the back side of the impeller blades.
3. The one-way clutch in the stator unlocks and the stator blades turn in the direction of engine rotation.
4. Fluid is no longer re-directed and torque multiplication no longer takes place.
5. This is referred to as "Coupling Speed". The turbine never reaches the same speed as the impeller as fluid flow would come to a halt. Ratio is approximately 1.1 to 1. (Scheme 109)

Torque Converter Clutch

Since the efficiency of the torque converter at coupling speed is approximately 1.1 to 1, fuel economy is compromised. To offset this a torque converter clutch was added on EH controlled transmissions. The torque converter clutch locks the turbine to the converter housing. This creates a mechanical coupling with a ratio of 1:1. This can only be achieved at higher engine speeds. The torque converter clutch must be disengaged at low engine speeds to prevent stalling. There are two methods for controlling the torque converter clutch on BMW transmissions

1. A4S310/270R, 4HP22/24 EH, A5S310Z - These transmission use an on/off control method to lock and unlock the torque converter. The TCC is either completely engaged or completely disengaged. This method of engagement provides an abrupt sensation when the TCC is locking and unlocking. This abrupt sensation can be unpleasant and undesirable to some drivers.
2. A5S560Z, A5S440Z, A5S325Z, GA6HP26Z, A5S360/390R - These transmissions use a gradual approach to TCC control. The TCC is gradually applied and released, this method reduces the abrupt feel of the on/off type TCC. The TCC solenoid is controlled by pulse width modulation. This allows fluid to be gradually introduced and released to the TCC.

The TCC is spring loaded to the engaged position. Pressurized fluid releases the TCC, when the pressurized fluid is released, the TCC is engaged. Depending on transmission application, the TCC can be engaged in 3rd, 4th or 5th gear. The TCC must be disengaged at low speeds to prevent stalling. See

(Scheme 110)

and

(Scheme 111)

Scheme 110

Scheme 111
