11 0 070 Engine hoist
Note. For removing and installing engines
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N43, N45, N45T, N46, N46T, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 279
SI number: 1 16 96 (107)
Order number: 11 0 070
Engine hoist
Consisting of
1 = 11 0 071 Lifting beam
2 = 11 0 072 Carrying chain, long
3 = 11 0 073 Carrying chain, short
4 = 11 0 079 Shackle (2 x)
11 0 090 Engine support plates
In conjunction with: 00 1 450
Note. For securing engine on assembly stand
Engine: M40, M42, M43, M43TU, M44
SI number: 1 03 87 (738)
Order number: 11 0 090
Engine support plates
Scheme 280
11 0 190 Accessories
In conjunction with: 11 1 060, 11 1 065, 11 1 067, 11 3 131, 11 3 132
Note. For removing and installing valve springs
Engine: M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M57, M60, M62, M70, M73, S14, S38, S50B30, S50B32, S54, S62
Scheme 281
SI number: 1 09 91(416)
Order number: 11 0 190
Accessories
Consisting of
2 = 11 0 192 Guide tube
Note. Engine: all
4 = 11 0 194 Valve spring cage
Note. Engine: M41, M51, S50
11 0 220 Compression test kit
Minimum set: Mechanical tools
Note. For all petrol/gasoline and diesel engines.
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N43, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 282
11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note. For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240
Coupling
Scheme 283
11 0 310 Pressure testing fixture
Note. For leak testing cylinder head
Engine: M43, M44
SI number: 1 12 93(701)
Order number: 11 0 310
Pressure testing fixture
Scheme 284
Consisting of
1 = 11 0 311 Sealing strip
Note. Engine: M43
3 = 11 0 313 Rubber pad (2)
Note. Engine: M43
4 = 11 0 314 Cover for water pump connection
Note. Engine: M43
5 = 11 0 315 Cover for radiator connection with valve
Note. Engine: M43
6 = 11 0 316 Cover for heater connection
In conjunction with: 11 1 431, 11 1 433, 11 1 435, 11 1 436, 11 1 439
7 = 11 0 317 Screw plug (2)
Note. Engine: M43
8 = 11 0 318 Sealing strip
Note. Engine: M43
11 0 340 Accessories
In conjunction with: 11 1 060
Note. For removing and installing valve springs
Engine: M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M57, M57D25, M57D30, M60, M62, M67, M67TU, M70, M73, N40, N42, N62, N73, S14, S38, S50B30, S50B32, S54, S62
Scheme 285
SI number: 1 12 93(701)
Order number: 11 0 340
Accessories
Consisting of
1 = 11 0 341 Valve spring cage
Note. Engine: M43, M73
2 = 11 0 342 Pressure lever
Note. Engine: all, except M10
3 = 11 0 343 Hook
Note. Length 220 mm - Engine: all, except M10
5 = 11 0 345 Valve spring cage
Note. Engine: M44, M52, M62, S62, S54
6 = 11 0 346 Valve spring cage
Note. Engine: M47, M47TU, M57, N40, N42, M67, M67TU
11 1 200 Drift
Minimum set: Mechanical tools
Note. For fitting valve stem seals
Engine: M20, M21, M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N45, S14, S38, S50B30, S50B32, S54, S62
Storage location: B14, C14
Order number: 11 1 200
Drift
Scheme 286
11 1 260 Impact bush
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note. For fitting rotary shaft seal in rear crankshaft end cover
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M47, M50, M51, M52, M57, M57D25, M57D30, S14, S38, S50B30, S50B32, S54
Storage location: C19
Scheme 287
SI number: 1 03 95(900)
Order number: 11 1 260
Impact bush
11 1 430 Fixture
In conjunction with: 11 0 316 (M42, M44), 11 1 450 (M50, M52, S50)
Note. For pressure testing cylinder head
Engine: M42, M44, M50, M52, S50B30, S50B32, S54
SI number: 1 05 89(099)
Order number: 11 1 430
Fixture
Scheme 288
Consisting of
1 = 11 1 431 Sealing strip
Note. With 5 pins and rubber seal - Engine: M42, M44, M50, M52, S54
2 = 11 1 432 Rubber seal
Note. For sealing strip 11 1 431 - Engine: M42, M44, M50, M52
3 = 11 1 433 Sealing strip
Note. With 7 pins and rubber seal - Engine: M42, M44, M50, M52, S54
4 = 11 1 434 Rubber seal
Note. For sealing strip 11 1 433 - Engine: M42, M44, M50, M52
5 = 11 1 435 Formed plate
Note. With rubber seal - Engine: M42, M44
6 = 11 1 436 Bridge
Note. With rubber seal and 2 screws - Engine: M42, M44
7 = 11 1 437 Screw plug
Note. With valve and standard clip - Engine: M42, M44, M50, M52, S50
8 = 11 1 438 Screw plug and standard clip
Note. Engine: M42, M44, M50, M52
9 = 11 1 439 Standard parts
Note. Engine: M42, M44, M50, M52
11 1 440 Accessories
In conjunction with: 11 1 060, 11 1 065, 11 1 067, 11 1 068
Note. For removing and installing valve springs
Engine: M42, M44, M47, M47TU, M50, M52, M57, M67
SI number: 1 05 89(099)
Order number: 11 1 440
Accessories
Scheme 289
Consisting of
1 = 11 1 441 Placement board
2 = 11 1 442 Mounting bracket
Note. Engine: M52, M44, M50, M52, M47, M47TU, M57
In conjunction with: 11 1 065
11 1 443 Mounting bracket
Note. Engine: M67
In conjunction with: 11 1 065
11 1 480 Pliers
Minimum set: Mechanical tools
Note. For removing valve stem seal
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N12, N14, N43, N45, N47, N47S, N52, N53, N54, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11
Storage location: B10
Scheme 290
SI number: 1 01 93 (621)
Order number: 11 1 480
Pliers
11 1 960 Assembly sleeves
Minimum set: Mechanical tools
Note. For fitting valve stem seals, 6 mm diameter
Engine: M41, M42, M44, M47, M50, M51, M52, M52TU, M54, M56, M57, M57T2, M57TU, M60, M62, S50B30, S50B32, S54, S62
Order number: 11 1 960
Assembly sleeves
Scheme 291
11 2 030 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note. For driving the guide bearing into the crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving the centering support into the propeller shaft
Series: E28, E30, E32, E34, E36, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E92, RR1
Scheme 292
Storage location: A28
Order number: 11 2 030
Drift
11 2 150 Holder
Minimum set: Mechanical tools
Note. For locking crankshaft in position when releasing and tightening central bolt
Engine: M20, M40, M41, M43, M44, M50, M51, M52
Storage location: A1, B1
Order number: 11 2 150
Holder
Scheme 293
11 2 170 Holder
Minimum set: Mechanical tools
Note. For locking flywheel in position
Engine: M20, M21, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, S50B30, S50B32, S54
Storage location: C4
Order number: 11 2 170
Holder
Scheme 294
11 2 250 Torx socket E12
Minimum set: Mechanical tools
Note. With 1/2" extension for releasing and tightening cylinder head bolts
Engine: M42, M43, M44, M50, M52, M60, M62, S85
Storage location: A22
SI number: 1 05 89(099)
Order number: 11 2 250
Torx socket E12
Scheme 295
11 2 290 Placement board
Note. For placing pistons with connecting rods
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M60, M62, M70, M73, M88, S14, S38, S50B30, S50B32
Order number: 11 2 290
Placement board
Scheme 296
11 2 300 Plug mandrel
Minimum set: Mechanical tools
Note. For locking crankshaft in ignition TDC position when adjusting timing
Engine: M21, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57T2, M57TU, M60, M62, M62VAN, M70, M73, S50B30, S50B32, S54, S62
Storage location: C15
Order number: 11 2 300
Plug mandrel
Scheme 297
11 2 310 Extractor tool
Minimum set: Mechanical tools
Note. For removing rotary shaft seal in lower timing case cover
Engine: M40, M42, M43, M44
Storage location: C26
SI number: 1 03 87(739)
Order number: 11 2 310
Extractor tool
Scheme 298
Consisting of
1 = 11 2 311 Extractor
3 = 11 2 313 Thrust piece
Note. Engine: M42, M43, M44
4 = 11 2 314 Spindle M12x150
11 2 330 Mounting plate
Minimum set: Mechanical tools
Note. For timing case cover without removing cylinder head (M42, M43, M44), as well as for mounting top timing case cover (M43, M44)
Engine: M42, M43, M44
Storage location: C10, C11
SI number: 1 05 89(099)
Scheme 299
Order number: 11 2 330
Mounting plate
11 2 340 Extractor
Minimum set: Mechanical tools
In conjunction with: 11 2 016 (M60, M62)
Note. For guide bearing in crankshaft, stem diameter 15 mm
Scheme 300
Engine: M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, M70, M73, N40, N42, N43, N45, N45T, N46, N46T, S50B30, S50B32, S54, S62, S85
Storage location: C11
SI number: 1 05 90 (207)
Order number: 11 2 340
Extractor
Consisting of
1 = 11 2 341 Extractor claw with threaded bush
2 = 11 2 342 Extractor claw
3 = 11 2 343 Pressure spindle
4 = 11 2 344 Sleeve
11 2 350 Drift
Minimum set: Mechanical tools
Note. For fitting guide bearing of crankshaft
Engine: M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M70, M73, N40, N42, N43, N45, N45T, N46, N46T, S50B30, S50B32, S52US, S54, S62, S85
Scheme 301
Storage location: A15
SI number: 1 05 90 (207)
Order number: 11 2 350
Drift
11 2 410 Spacer ring
In conjunction with: 11 2 150
Note. For holder to lock crankshaft in position when releasing and tightening central bolt
Engine: M41, M43, M43TU, M44, M50, M52, M52TU, S52US
Scheme 302
Storage location: A26
SI number: 1 10 94(840)
Order number: 11 2 410
Spacer ring
11 3 030 Placement board for tappet
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, M88, S14, S38, S50B30, S50B32, S62
Order number: 11 3 030
Placement board for tappet
Scheme 303
11 3 240 Locking fixture
Note. For locking camshaft in position when adjusting timing
Engine: M42, M44, M50, M52, M52TU, M54, M56, S50US, S52US
Storage location: A11
SI number: 1 05 89(099)
Order number: 11 3 240
Locking fixture
Scheme 304
Consisting of
1 = 11 3 241 Gauge for inlet side
2 = 11 3 242 Gauge for exhaust side
4 = 11 3 244 Bracket
Note. For securing camshaft blocking fixture to cylinder head
11 3 250 Suction cup
Minimum set: Mechanical tools
Note. For lifting out tappets in cylinder head
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, S62
Storage location: A 104
SI number: 1 05 89(099)
Order number: 11 3 250
Suction cup
Scheme 305
Consisting of
1 = 11 3 251 Sucker (8 x)
11 3 340 Locking pin (2)
Minimum set: Mechanical tools
Note. For locking chain tensioner piston in position (e.g. when removing and installing cylinder head) as well as for locking drive belt tensioner
Engine: M41, M43, M44, M47, M47T2, M47TU, M51, M57, M57T2, M57TU, M62, N40, N42, N43, N45, N45T, N46, N46T, N47, N51, N52, N53, N54, N62, N63, N73
Storage location: B5, C5
Scheme 306
SI number: 1 09 91(416)
Order number: 11 3 340
Locking pin (2)
11 3 480 Guide mandrel (2)
Minimum set: Mechanical tools
Note. For installing connecting rods with pistons. Note: With the phase-in of engine S50B32 the guide mandrels have been revised and adapted to the new connecting rods.
Engine: M44, M52, M52TU, M54, M56, S50B30, S50B32, S62
Storage location: B2, C2
SI number: 1 12 92(606)
Scheme 307
Order number: 11 3 480
Guide mandrel (2)
11 4 110 Pin (4)
Minimum set: Mechanical tools
Note. For fixing metal gasket in position on upper timing case cover during assembly
Engine: M43, M44
Storage location: B1
SI number: 1 13 95(002)
Order number: 11 4 110
Pin (4)
Scheme 308
11 4 150 Installer bush
Minimum set: Mechanical tools
In conjunction with: Central bolt of crankshaft
Note. For fitting rotary shaft seal in bottom timing case cover
Engine: M43, M44
Storage location: A33
SI number: 1 12 93(701)
Order number: 11 4 150
Installer bush
Scheme 309
11 4 190 1/4" extension piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note. M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
Scheme 310
SI number: 1 06 94(801)
Order number: 11 4 190
1/4" extension piece
11 5 040 Open-ended spanner WAF 32
Minimum set: Mechanical tools
In conjunction with: Torque wrench 3/8" connection
Note. For loosening and tightening fan wheel
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57T2, M57TU, M60, M62, M70, M73, M88, N42, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62
Scheme 311
Storage location: B9, C9
SI number: 01 01 87 (670)
Order number: 11 5 040
Open-ended spanner WAF 32
11 5 050 Holder
Minimum set: Mechanical tools
Note. For pulley while loosening and tightening fan
Engine: M40, M41, M42, M43, M44, M60, M62, N62, S62
Storage location: B3, C3
SI number: 1 03 87(739)
Order number: 11 5 050
Holder
Scheme 312
11 5 130 Lever
Note. For pressing down valves while removing and installing rocker fingers
Engine: M44
Storage location: A5, B5
SI number: 1 13 95(002)
Order number: 11 5 130
Lever
Scheme 313
Consisting of
1 = 11 5 131 Lever
2 = 11 5 132 Compression fixture
3 = 11 5 133 Spring
11 5 461 Installation holder
Order number: 11 5 461
Installation holder
Scheme 314
11 5 462 Installation pliers
Order number: 11 5 462
Installation pliers
11 5 463 Installation drift
Order number: 11 5 463
Installation drift
11 5 464 Removal pliers
Order number: 11 5 464
Removal pliers
11 6 260 Mounting sleeves with case
Minimum set: Mechanical tools
Note. For installing pistons of 85 mm diameter (urgently required for pistons with U-Flex ring)
Engine: M43TU, M44, N51, N52, N52K, N53, N54
Order number: 11 6 260
Mounting sleeves with case
Scheme 315
Consisting of
1 = 11 6 261 Assembly bush
Note. Diameter 85.00 mm
2 = 11 6 262 Assembly bush
Note. Diameter 85.08 mm, repair
3 = 11 6 263 Assembly bush
Note. Diameter 85.25 mm, stage 1
4 = 11 6 264 Assembly bush
Note. Diameter 85.50 mm, stage 2
9 = 11 6 269 Case with foam inlay
Note. For holding assembly bushes, gauge 11 6 270 and lever gauge 11 6 250
11 6 400 Pressure testing fixture
Note. For closing off coolant outlet openings when pressure-testing cylinder head for water leaks
Engine: M20, M21, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M57, M57T2, M57TU, M70, M73, S50B30, S50B32, S50US, S52US
Scheme 316
SI number: 1 06 98(306)
Order number: 11 6 400
Pressure testing fixture
Consisting of
1 = 11 6 401 Sealing strips (2 x) with rubber seal
3 = 11 6 403 Cover
Note. Engine: M47, M57 / For water pump connection
6 = 11 6 406 M12 screw plug with valve
Note. Engine: M47, M57, M47TU
7 = 11 6 407 Retaining screws (14 x)
Note. M12 x 125 with nuts and 28 Uwashers for sealing strips
11 6 402 Rubber seal (2 x)
Note. For sealing strips 11 6 401
11 6 404 O-ring
Note. Engine: M47 / For spindle on cover 11 6 403
11 6 408 Sealing plate
Note. Engine: M57, M47TU / For sealing off coolant outlet opening
11 7 030 Socket wrench socket WAF 22
Minimum set: Mechanical tools
In conjunction with: 11 9 150
Note. For loosening and tightening oxygen sensor
Engine: M40, M43, M43TU, M44, M52, M52TU, M54, M56, M62, N40, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S62, S85
Storage location: B15
Scheme 317
SI number: 1 06 95 (963)
Order number: 11 7 030
Socket wrench socket WAF 22
11 7 300 Placement board
Note. For valves, valve springs, hydraulic tappet, rocker fingers etc.
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M60, M62, M70, M73, M88, S14, S38, S50B30, S50B32, S50US, S52US
Order number: 11 7 300
Placement board
Scheme 318
11 7 320 Gauge (8°)
Minimum set: Mechanical tools
Note. For setting hook nozzles in crankcase during assembly
Engine: M44
Storage location: B13
SI number: 1 13 95(002)
Order number: 11 7 320
Gauge (8°)
Scheme 319
11 7 330 Test connection and modified oil filter wrench
Minimum set: Mechanical tools
In conjunction with: 13 3 063 or 13 6 051 and pressure gauge 13 3 061 or BMW DIS
Note. for measuring oil pressure
Engine: M42, M43, M44
Storage location: B26
SI number: 1 21 00(642)
Order number: 11 7 330
Test connection and modified oil filter wrench
Scheme 320
Consisting of
1 = 11 7 331 Oil filter wrench
2 = 11 7 332 Oil filter cap with M12 connecting thread
3 = 11 7 333 Center rod
11 7 450 Simulator
In conjunction with: Standard workshop exhaust emission tester
Note. For Bosch oxygen sensor
Engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, S14, S38, S50B30, S50B32, S50US, S52US
Storage location: K 102
SI number: 2 07 93(700)
Order number: 11 7 450
Simulator
Scheme 321
Consisting of
1 = 11 7 451 Simulator (operator unit)
2 = 11 7 452 4-pin connecting cable, coding A
Note. Connection to wiring harness and oxygen sensor - engine: M40, M42, M43, M50, M70
3 = 11 7 453 4-pin plug connection, coding B
Note. Connection to oxygen sensor - engine: S50/B30
4 = 11 7 454 4-pin plug connection, coding B
Note. Connection to wiring harness - engine: S50/B30
5 = 11 7 455 1- and 3/4-pin plug connection
Note. Connection to oxygen sensor with Bosch or Cannon plug connection - engine: M10, M20, M30, S14
6 = 11 7 456 1- and 3/4-pin plug connection
Note. Connection to wiring harness with Bosch or Cannon plug connection - engine: M10, M20, M30, S14
8 = 11 7 458 Plug-in jumper
8 = 11 7 459 Operating instructions
11 9 000 Cylinder head expander tool
Minimum set: Mechanical tools
In conjunction with: Assembly stand 00 1 450
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 322
Storage location: Single
SI number: 1 03 02 (833)
Order number: 11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001 Fixture
2 = 11 9 002 Rod
3 = 11 9 003 Sliding block with M10 thread
4 = 11 9 004 Tab
5 = 11 9 005 Quick tensioner
6 = 11 9 006 Aluminum profile insert
7 = 11 9 007 Slide
8 = 11 9 008 Profile plastic part
9 = 11 9 009 Lever
10= 11 9 011 Hook
11= 11 9 012 Valve spring cage
Note. Engine M41, M51, S50
12= 11 9 013 Valve spring cage
Note. Engine M43, M73
13= 11 9 014 Valve spring cage
Note. Engine M44, M52, M54, M56, M62, S52, S54, S62
14= 11 9 015 Valve spring cage
Note. Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
15= 11 9 016 Valve spring cage
Note. Engine M21, M40
16= 11 8 421 Valve spring cage
Note. Engine: W10, W11, W17
17= 11 9 017 Valve spring cage
Note. Engine N52
11 9 110 6 degree plug gauge
Note. For fixing inlet camshaft in position while adjusting valve timing - engine with idle judder
Series: E36
Engine: M44
SI number: 1 07 98(332)
Order number: 11 9 110
6 degree plug gauge
Scheme 323
Scheme 324
Order number: 11 9 811
Holder
11 9 812 Screw
Order number: 11 9 812
Screw
