Fully Automatic Top Only BMW Z3 E36

Convertible Top - Repair 1 illustration ~107 words

Fully Automatic Top Only

Press and hold top switch. All side windows lower automatically regardless of their position, by a signal from top module to General module (ZKE IV).

Scheme 16

Scheme 16: Fully Automatic Top Only

Scheme 16: Fully Automatic Top Only

The top lock motor is powered in unlock direction. The left and right side locks are mechanically released via drive cables. Microswitch S7 opens indicating top is unlatched from windshield frame.
Once locks are completely released, top lock motor continues to run lifting front bow above tension point via tension rods. As front bow passes tension point, microswitch S8 closes. The top lock motor switches off and top motor is switched on.
