11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note. For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240
Coupling
Scheme 378
11 0 290 Holder
Minimum set: Mechanical tools
Note. For removing and installing triangular drive (vacuum pump) on crankcase.
Engine: N51, N52, N52K, N53, N54
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 0 290
Holder
Scheme 379
11 0 300 Plug mandrel
Minimum set: Mechanical tools
Note. For locking flywheel in TDC position
Engine: N43, N51, N52, N52K, N53, N54
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 0 300
Plug mandrel
Scheme 380
11 0 390 Clamping pin
Minimum set: Mechanical tools
Note. For securing the new N43 tensioning pulley (Poly-V-belt)
Engine: N43, N63
SI number: 01 15 07 (390)
Order number: 11 0 390
Clamping pin
Scheme 381
11 1 480 Pliers
Minimum set: Mechanical tools
Note. For removing valve stem seal
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N12, N14, N43, N45, N47, N47S, N52, N53, N54, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11
Storage location: B10
SI number: 1 01 93 (621)
Scheme 382
Order number: 11 1 480
Pliers
11 2 000 Puller
Minimum set: Mechanical tools
Note. For crankshaft sprocket
Engine: M10, M30, M50, M52, M60, M62, M70, M73, N62TU, N63, N73, S14, S38, W10, W11
Storage location: B9, C42
Order number: 11 2 000
Puller
Consisting of
Scheme 383
1 = 11 2 001 Bell housing
2 = 11 2 002 Plate
Note. Engine: M10, M30, S14, S38, N73
3 = 11 2 003 Spindle
Note. Engine: M10, M30, M70, M73, S14, S38, N73
4 = 11 2 004 Plate
Note. Engine: M50, M52, M60, M62
5 = 11 2 005 Spindle 165 mm
Note. Engine: M50, M52, M60, M62
6 = 11 2 006 Plate
Note. Engine: M70, M73, N73
7 = 11 2 007 Thrust piece
Note. Engine: N73
11 3 340 Locking pin (2 pieces)
Minimum set: Mechanical tools
Note. For locking chain tensioner piston in position (e.g. when removing and installing cylinder head) as well as for locking drive belt tensioner
Engine: M41, M43, M44, M47, M47T2, M47TU, M51, M57, M57T2, M57TU, M62, N40, N42, N43, N45, N45T, N46, N46T, N47, N51, N52, N53, N54, N57, N62, N73
Storage location: B5, C5
SI number: 1 09 91(416)
Order number: 11 3 340
Locking pin (2 pieces)
Scheme 384
11 3 460 Protractor
Minimum set: Mechanical tools
In conjunction with: 11 2 450
Note. For fitting on brace 11 2 450 when tightening central bolt using torsion angle tightening method
Engine: M60, M62, M73, N62, N62TU, N63, N73
Storage location: C1
SI number: 1 08 92 (555)
Scheme 385
Order number: 11 3 460
Protractor
11 4 050 Reducer
Minimum set: Mechanical tools
In conjunction with: 13 3 063 or 13 6 051
Note. For connection of pipe bend 13 6 054 to pressure gauge 13 3 061 or BMW DIS for checking oil pressure
Engine: M10, M20, M21, M30, M47, M47T2, M47TU, M50, M51, M52, M54, M56, M57, M57T2, M57TU, M60, M62, M70, M73, N43, N51, N52, N52K, N53, N54, N62, N63, N73, S14, S38, S50B30, S50B32, S62
Scheme 386
Storage location: A4
Order number: 11 4 050
Reducer
11 4 120 Locking pin
Minimum set: Mechanical tools
Note. For chain tensioner to lock chain tensioner piston in position (e.g. when removing and installing cylinder head)
Engine: M43, N47, N47S, N51, N52, N52K, N53, N54
Storage location: B5, C5
SI number: 1 12 93 (701)
Order number: 11 4 120
Locking pin
Scheme 387
11 4 160 Adapter
In conjunction with: 13 3 061, 13 3 063 or 13 6 051
Note. For pressure gauge 13 3 061 or BMW DIS; for checking oil pressure
Engine: M41, N53, N54
Storage location: A2, B2
SI number: 1 09 94 (839)
Order number: 11 4 160
Adapter
Scheme 388
11 4 180 Screwdriver socket Torx T60
Minimum set: Mechanical tools
Note. For releasing and tightening dual-mass flywheel - model year: from Jan 94
Engine: M57T2, M57TU, M60, M62, N43, N45T, N46T, N47, N47S, N52, N53, N54, S62, S85
Storage location: A11
SI number: 1 02 94 (777)
Order number: 11 4 180
Screwdriver socket Torx T60
Scheme 389
11 4 190 1/4" extension piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note. M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage Location: B6
SI number: 1 06 94(801)
Scheme 390
Order Number: 11 4 190
1/4" extension piece
11 4 260 Box spanner
Note. For removing and installing lambda oxygen sensors.
Engine: N45T, N51, N52, N53, N54
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 4 260
Box spanner
Scheme 391
11 4 280 Gauge
Minimum set: Mechanical tools
Note. For locating camshaft in TDC position.
Engine: N43, N51, N52, N52K, N53, N54
Storage location: B52
SI number: 1 17 04 (130)
Order number: 11 4 280
Gauge
Consisting of
Scheme 392
1 = 11 4 281 Gauge
2 = 11 4 282 Adapter
3 = 11 4 283 Bracket
4 = 11 4 284 Set of M6 screws
Note. Engine: N54
11 4 370 Pressing fixture
Note. For pressing out sealing compound for bedplate.
Engine: N43, N45T, N51, N52, N52K, N53, N54, S85
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 4 370
Pressing fixture
Scheme 393
11 4 420 Torx socket T50
Minimum set: Mechanical tools
Note. For removing and installing cylinder head.
Engine: N51, N52, N52K, N53, N54
Storage location: A51
SI number: 1 17 04 (130)
Order number: 11 4 420
Torx socket T50
Scheme 394
11 4 430 Seal plugs (2 x)
Minimum set: Mechanical tools
Note. For sealing off oil holes in oil pump.
Engine: N51, N52, N52K, N53, N54
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 4 430
Seal plugs (2 x)
Scheme 395
11 4 440 Engine support plate
In conjunction with: 00 1 450" 00 2 300
Note. For accommodating engine on assembly stand. Is replaced by 11 8 540.
Engine: N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 4 440
Engine support plate
Scheme 396
11 4 470 Cleaning kit
Minimum set: Mechanical tools
Note. For cleaning sealing surfaces on magnesium crankcase/cylinder head.
Engine: N43, N45T, N46T, N47, N51, N52, N52K, N53, N54, N63
SI number: 1 17 04 (130)
Order number: 11 4 470
Cleaning kit
Consisting of
Scheme 397
1 = 11 4 471 Scraper
2 = 11 4 472 Grindstone
11 4 480 Placement boards (2 x)
Minimum set: Mechanical tools
Note. For storing individual components of cylinder head.
Engine: N12, N14, N43, N45T, N47, N47S, N51, N52, N52K, N53, N54, N63
SI number: 1 17 04 (130)
Order number: 11 4 480
Placement boards (2 x)
Consisting of
Scheme 398
1 = 11 4 481 Placement board, inlet side
2 = 11 4 482 Placement board, exhaust side
11 5 190 Torx socket T60
Minimum set: Mechanical tools
Note. For removing and installing cylinder head.
Engine: N51, N52, N52K, N53, N54
Storage location: A51
SI number: 01 17 04 (130)
Order number: 11 5 190
Torx socket T60
Scheme 399
11 5 200 Spacer ring
Minimum set: Mechanical tools
In conjunction with: 11 9 280 Counterholder
Note. For releasing and tightening down central bolt.
Engine: N43, N51, N52, N52K, N53, N54
Storage location: B51
SI number: 1 17 04 (130)
Order number: 11 5 200
Spacer ring
Scheme 400
Consisting of
1 = 11 5 201 Shim
2 = 11 5 202 M8x40 mm screws (3 x)
11 6 250 Lever gauge (Puppitast)
Minimum set: Mechanical tools
Note. With small stand for measuring tooth backlash and axial clearance at balancing shafts, camshafts and crankshafts.
Engine: M43TU, M47T2, M57T2, M67TU, N57, N63, S85
SI number: 1 04 98(304)
Order number: 11 6 250
Lever gauge (Puppitast)
Scheme 401
Consisting of
1 = 11 6 251 Lever gauge
Note. With 0.8 mm measuring range in each direction
2 = 11 6 252 Hydraulic small stand with magnetic foot
4 = 11 6 254 Support plate
Note. Engine: M47T2" M57T2" S85
5 = 11 6 255 Locating plate M7
Note. Camshaft Engine: M67TU
6 = 11 6 256 Locating plate M8
Note. Crankshaft Engine: M67TU
11 6 260 Mounting sleeves with case
Minimum set: Mechanical tools
Note. For installing pistons of 85 mm diameter (urgently required for pistons with U-Flex ring)
Engine: M43TU, M44, N51, N52, N52K, N53, N54
Order number: 11 6 260
Mounting sleeves with case
Consisting of
Scheme 402
1 = 11 6 261 Assembly bush
Note. Diameter 85.00 mm
2 = 11 6 262 Assembly bush
Note. Diameter 85.08 mm, repair
3 = 11 6 263 Assembly bush
Note. Diameter 85.25 mm, stage 1
4 = 11 6 264 Assembly bush
Note. Diameter 85.50 mm, stage 2
9 = 11 6 269 Case with foam inlay
Note. For holding assembly bushes, gauge 11 6 270 and lever gauge 11 6 250
11 6 370 Puller
Minimum set: Mechanical tools
Note. For removing valve stem seal
Engine: M47, M47TU, M57, M57T2, M57TU, N40, N42, N43, N45, N45T, N46, N46T, N52, N62, N63, N73
Storage location: B15
SI number: 1 06 98(306)
Order number: 11 6 370
Puller
Scheme 403
11 6 380 Bush
Minimum set: Mechanical tools
Note. For fitting valve stem seal
Engine: M47, M47TU, M57, M57T2, M57TU, N12, N14, N40, N42, N43, N45, N45T, N46, N46T, N47, N47S, N51, N52, N52K, N53, N54, N57, N62, N63, N73
Storage location: B15
SI number: 1 06 98(306)
Order number: 11 6 380
Bush
Scheme 404
11 7 020 Socket wrench socket WAF 22
Minimum set: Mechanical tools
Note. For loosening and tightening oxygen sensor
Engine: M10, M20, M30, M40, M42, M50, M52TU, M54, M56, M57, M57T2, M60, M70, M73, N12, N14, N42, N45, N46, N47, N47S, N53, N54, N63, S14, S38, S50B30, S50B32, S50US, S52US, S54, W16
Storage location: A9
Order number: 11 7 020
Socket wrench socket WAF 22
Scheme 405
11 7 030 Socket wrench socket WAF 22
Minimum set: Mechanical tools
In conjunction with: 11 9 150
Note. For loosening and tightening oxygen sensor
Engine: M40, M43, M43TU, M44, M52, M52TU, M54, M56, M62, N40, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S62, S85
Storage location: B15
SI number: 1 06 95 (963)
Scheme 406
Order number: 11 7 030
Socket wrench socket WAF 22
11 7 200 Plug-on tool
In conjunction with: Commercially available torque wrench
Note. Open-ended spanner WAF 10 for tightening threaded connection of VANOS gear unit
Engine: N63, S54, S62
Storage location: C10
SI number: 1 23 98(390)
Order number: 11 7 200
Scheme 407
Plug-on tool
11 7 280 Piston ring pliers
Note. For installing piston with connecting rod in crankcase (for 89 mm diameter).
Engine: N63, N73
Storage location: B42, C42
SI number: 1 14 02 (939)
Order number: 11 7 280
Piston ring pliers
Scheme 408
11 7 310 Spacer
Minimum set: Mechanical tools
Note. For supporting engine during removal and installation of transmission
Engine: M62, M73, N53, N54
Storage location: B6
SI number: 1 11 94 (858)
Order number: 11 7 310
Spacer
Scheme 409
11 8 090 Holder
Note. For releasing central bolt.
Engine: N63
SI number: 01 05 08 436
Order number: 11 8 090
Holder
Scheme 410
11 8 150 Insertion tool
Minimum set: Mechanical tools
Note. For removing and installing connecting rods
Engine: M67, M73, N63, N73
Storage location: B2, C2
SI number: 1 12 99(452)
Order number: 11 8 150
Insertion tool
Consisting of
Scheme 411
1 = 11 8 151 Insertion aid 1 with spring clip, long
2 = 11 8 152 Insertion aid 2 with spring clip, short
11 8 180 Holder
Minimum set: Mechanical tools
Note. Blocking flywheel when releasing and tightening down central bolts on vibration damper
Engine: M47T2, M47TU, M57T2, M57TU, M67, N43, N45, N45T, N46, N46T, N47, N47S, N51, N52, N53, N54, W17
Storage location: C45, C46
SI number: 1 12 99 (452)
Order number: 11 8 180
Scheme 412
Holder
Consisting of
2 = 11 8 182 Locking piece
3 = 11 8 183 Basic body
4 = 11 8 184 Adapter
Note. E65/M67
5 = 11 8 185 Adapter with setting sleeve
Note. E46 M47TU
11 8 730 Adapter
Minimum set: Mechanical tools
In conjunction with: 11 0 220
Note. For compression testing.
Engine: N12, N14, N43, N53, N54, N63
SI number: 1 04 07 (352)
Order number: 11 8 730
Adapter
Consisting of
Scheme 413
1 = 11 8 731 Adapter
2 = 11 8 732 Sealing ring
Note. For firmly connecting test probe 11 0 222 and adapter 11 8 730/731.
11 8 510 Gauge
Note. For securing oil spray nozzles
Engine: N54
SI number: 1 20 06 (299)
Order number: 11 8 510
Gauge
Scheme 414
11 8 520 Gauge with screws
Minimum set: Mechanical tools
Note. For disconnecting camshaft sensor gears.
Engine: N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 520
Gauge with screws
Consisting of
1 = 11 8 521 Gauge
Scheme 415
2 = 11 8 522 M6x45 screws (2 x)
11 8 540 Engine support plate
In conjunction with: 00 1 450" 00 2 300
Note. For accommodating engine on assembly stand.
Engine: N51, N52, N52K, N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 540
Engine support plate
Scheme 416
Consisting of
1 = 11 8 541 Engine take-up
2 = 11 8 542 Set of screws (4 x)
11 8 550 Locating fixture
Minimum set: Mechanical tools
Note. For securing bearing strips when installing inlet camshaft.
Engine: N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 550
Scheme 417
1 = 11 8 551 Press-down tool
2 = 11 8 552 Knurled screw (4 x)
3 = 11 8 553 Thrust piece (6 x)
11 8 570 Locating tool
In conjunction with: 11 9 190
Note. For locating engine at TDC.
Engine: N63
SI number: 01 05 08 436
Order number: 11 8 570
Locating tool
Scheme 418
11 8 580 Wrench socket Torx T60
Minimum set: Mechanical tools
Note. For removing and installing cylinder head (outside dia. 13.5 mm).
Engine: N52K, N53, N54
Storage location: A20, B20
SI number: 1 20 06 (299)
Order number: 11 8 580
Wrench socket Torx T60
Scheme 419
11 8 590 Insertion tool
Note. For installing piston with conrod in cylinder head.
Engine: N54
SI number: 1 20 06 (299)
Order number: 11 8 590
Scheme 420
11 8 610 Wrench socket, hexagon socket WAF 5
Minimum set: Mechanical tools
Note. For removing and installing high-pressure pump (length 125 mm).
Engine: N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 610
Wrench socket, hexagon socket WAF 5
Scheme 421
11 8 620 Wrench socket WAF 10
Minimum set: Mechanical tools
Note. For removing and installing injector ground connection screws.
Engine: N54
SI number: 1 20 06 (299)
Order number: 11 8 620
Wrench socket WAF 10
Scheme 422
11 8 640 Torx socket E10
Minimum set: Mechanical tools
Note. For removing and installing oil pump triangle drive.
Engine: N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 640
Torx socket E10
Scheme 423
11 8 650 Holder
Minimum set: Mechanical tools
Note. For removing and installing oil pump drive ring gear.
Engine: N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 650
Scheme 424
11 8 660 Holder
Minimum set: Mechanical tools
Note. For locking flywheel with A-transmission installed.
Engine: N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 660
Holder
Scheme 425
11 8 670 Pliers
Note. For removing and installing boost air line.
Engine: N54
SI number: 1 20 06 (299)
Order number: 11 8 670
Scheme 426
11 8 680 Adapter
Note. For securing engine during removal and installation.
Engine: N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 680
Scheme 427
Minimum set: Mechanical tools
In conjunction with: 11 0 220
Note. For compression testing.
Engine: N12, N14, N43, N53, N54, N63
SI number: 1 04 07 (352)
Order number: 11 8 730
Adapter
Consisting of
1 = 11 8 731 Adapter
2 = 11 8 732 Sealing ring
Note. For firmly connecting test probe 11 0 222 and adapter 11 8 730/731.
11 8 840 Valve spring basket
In conjunction with: 11 9 000
Note. For removing and installing valves.
Engine: N47, N47S, N57, N63, W16
SI number: 1 05 07 (353)
Order number: 11 8 840
Valve spring basket
Scheme 428
11 8 920 Holder
In conjunction with: 11 9 280
Note. For removing oil pump flange.
Engine: N63
SI number: 01 05 08 436
Order number: 11 8 920
Scheme 429
11 8 930 Engine take-up
In conjunction with: 00 2 300
Note. For accommodating engine on engine assembly stand.
Engine: N63
SI number: 01 05 08 436
Order number: 11 8 930
Scheme 430
Consisting of
1 = 11 8 931 Engine take-up
2 = 11 8 932 Set of screws
11 9 000 Cylinder head expander tool
Minimum set: Mechanical tools
In conjunction with: Assembly stand 00 1 450
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 431
Storage location: Single
SI number: 1 03 02 (833)
Order number: 11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001 Fixture
2 = 11 9 002 Rod
3 = 11 9 003 Sliding block with M10 thread
4 = 11 9 004 Tab
5 = 11 9 005 Quick tensioner
6 = 11 9 006 Aluminium profile insert
7 = 11 9 007 Slide
8 = 11 9 008 Profile plastic part
9 = 11 9 009 Lever
10= 11 9 011 Hook
11 = 11 9 012 Valve spring cage
Note. Engine M41, M51, S50
12 = 11 9 013 Valve spring cage
Note. Engine M43, M73
13 = 11 9 014 Valve spring cage
Note. Engine M44, M52, M54, M56, M62, S52, S54, S62
14 = 11 9 015 Valve spring cage
Note. Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
15 = 11 9 016 Valve spring cage
Note. Engine M21, M40
16 = 11 8 421 Valve spring cage
Note. Engine: W10, W11, W17
17 = 11 9 017 Valve spring cage
Note. Engine N52
11 9 150 Special wrench
Minimum set: Mechanical tools
In conjunction with: 11 7 030
Note. For releasing and tightening down oxygen sensors
Engine: M54, M56, N12, N14, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S85
Storage location: A42
SI number: 01 15 00 (609)
Scheme 432
Order number: 11 9 150
Special wrench
11 9 180 Installer
Minimum set: Mechanical tools
Note. For RSS into engine block at rear
Engine: N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 180
Installer
Scheme 433
Consisting of
1 = 11 9 181 Bushing
2 = 11 9 182 Thrust piece
3 = 11 9 183 Nut
4 = 11 9 184 Screws (2 x)
11 9 190 Plug mandrel
Minimum set: Mechanical tools
Note. For locking flywheel in TDC position
Engine: N40, N42, N62, N62TU, N63, N73
Storage location: B43
SI number: 1 01 01(662)
Order number: 11 9 190
Plug mandrel
Scheme 434
11 9 200 Puller
Minimum set: Mechanical tools
Note. For RSS out of engine block at rear
Engine: N40, N42, N43, N45, N45T, N46, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 200
Scheme 435
11 9 220 Puller
Minimum set: Mechanical tools
Note. For RSS out of engine block at front
Engine: N40, N42, N43, N45, N45T, N46, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 220
Puller
Scheme 436
Consisting of
1 = 11 9 221 Thrust member
In conjunction with
4 = 11 9 224 Screws (3 x)
5 = 11 9 225 Screw
6 = 11 9 226 Extractor
11 9 230 Installer
Minimum set: Mechanical tools
Note. For RSS into engine block at front
Engine: N40, N42, N43, N45, N45T, N46, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 230
Installer
Scheme 437
Consisting of
1 = 11 9 231 Bushing
2 = 11 9 232 Spindle
3 = 11 9 233 Nut
4 = 11 9 234 Screws (3 x)
11 9 240 Oil filter wrench
Minimum set: Mechanical tools
Note. For unfastening and tightening oil filter cap
Engine: N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54, N63
Storage location: A43
SI number: 1 01 01 (662)
Order number: 11 9 240
Scheme 438
11 9 260 Counter support with screw connection
Minimum set: Mechanical tools
Note. For locking flywheel with transmission removed
Engine: M47TU, M54, M57T2, M57TU, N40, N42, N43, N45, N45T, N46, N46T, N47, N47S, N51, N52, N53, N54, N62, N63, N73, S65, S85, W17
Storage location: B43
SI number: 1 01 01 (662)
Order number: 11 9 260
Scheme 439
Counter support with screw connection
Consisting of
1 = 11 9 261 Counterholder, individual
2 = 11 9 262 Bolt (M10 thread) with washer
Note. For bolting down counterholder
3 = 11 9 263 Sleeve for counterholder
Note. For counterholder for locking flywheel with transmission removed engine: N62, N73
4 = 11 9 264 Bolt (M12 thread)
Note. For counterholder for locking flywheel with transmission removed
5 = 11 9 265 Sleeve
6 = 11 9 266 Sleeve
Note. For counterholder for locking flywheel with transmission removed Engine: M57TU2
11 9 280 Holder
Minimum set: Mechanical tools
Note. For crankshaft when releasing/tightening central bolt
Engine: N12, N14, N40, N42, N43, N45, N46, N51, N52, N52K, N53, N63
Storage location: A43, B43, C43
SI number: 1 01 01(662)
Order number: 11 9 280
Holder
Scheme 440
11 9 340 Chain tensioner, complete
Minimum set: Mechanical tools
Note. For tensioning timing chain when adjusting timing
Engine: N12, N14, N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54
Storage location: B43
SI number: 1 01 01(662)
Order number: 11 9 340
Chain tensioner, complete
Scheme 441
Consisting of
1 = 11 9 341 Screw
2 = 11 9 342 Spindle
11 9 360 Drift
Minimum set: Mechanical tools
Note. For driving valve into engine block (sealing compound)
Engine: N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54, S85
Storage location: A43
SI number: 1 01 01(662)
Order number: 11 9 360
Drift
Scheme 442
11 9 410 Puller
Minimum set: Mechanical tools
Note. For pulling radial seal out of engine block at front
Engine: N62, N62TU, N63, N73
Storage location: A45
SI number: 1 14 01(766)
Order number: 11 9 410
Puller
Scheme 443
11 9 420 Installer
Minimum set: Mechanical tools
Note. For drawing in radial shaft seal in gearcase cover at bottom
Engine: N62, N62TU, N63, N73
Storage location: C45
SI number: 1 14 01(766)
Order number: 11 9 420
Installer
Scheme 444
11 9 450 Counter holder w/ socket & pointer
Minimum set: Mechanical tools
Note. For gripping crankshaft when releasing/tightening central bolt
Engine: N62, N62TU, N63, N73
Storage location: A45, C42
SI number: 1 14 01 (766)
Order number: 11 9 450
Counter holder w/ socket & pointer
Scheme 445
Consisting of
1 = 11 9 451 Lever
2 = 11 9 452 Disk
Note. Height 22.5 mm with hexagon screw
3 = 11 9 453 Pointer
4 = 11 9 454 Socket WAF 27
5 = 11 9 455 Disk
Note. Height 10 mm with hexagon screw
11 9 811 Holder
Order number: 11 9 811
Holder
Scheme 446
11 9 812 Screw
Order number: 11 9 812
Screw
11 9 900 Chain tensioner
Note. For pretensioning timing chain when adjusting timing.
Engine: N63
SI number: 01 05 08 436
Order number: 11 9 900
Chain tensioner
Consisting of
1 = 11 9 901 Chain tensioner
Scheme 447
2 = 11 9 902 Set of screws
