Fuses & Circuit Breakers - E71: Other BMW X6 E71

ENGINE COMPARTMENT

For location of engine compartment fuse holder (Engine Electronic Fuse Carrier) (Scheme 24)

Scheme 24

Engine compartment fuse(s) are protection for

Fuse F07 (Except X6 M)

1. 3.0L 40A - Electric Coolant Pump
2. 4.4L 15A - Intercooler Coolant Pump

PASSENGER COMPARTMENT

For passenger compartment junction box (A4010) location (Scheme 25)For amperage and components covered (Scheme 26)through (Scheme 28)

Scheme 25

Note. The fuse assignments below are based on vehicle manufacture dates given by BMW. Use the vehicle's VIN code to determine the correct set of fuse assignments.

Note. BMW does not provide fuse assignment data for vehicles manufactured from 10/2007 to 10/2008. Fuse assignments (Scheme 26)may or may not apply.

Scheme 26

Scheme 27

Scheme 28

Rear Power Distribution Box (A42)

Note. Rear Power Distribution Box (A42) is located in luggage compartment, at the RH panel. (Scheme 29)

For amperage and components covered (Scheme 26)through (Scheme 28)

Scheme 29

Fuse Box (A406)

Fuse box (A406) is located in luggage compartment, under the floor hatch. (Scheme 30)

Scheme 30

X6

Fuse box (A406) fuses are protection for

1. F171: 100A - Electric Fan Cutout Relay (w\Trailer Module).
2. F172: 100A - Rear Power Distribution Box (A42).
3. F173: 250A - Passenger Compartment Junction Box (A4010).
4. F175: 100A - Intelligent Battery Sensor.
5. F176: 80A - Terminal 15 Power-Saving Relay.
6. F177: 100A - Electric Aux. Heater.

X6 M

Fuse box (A406) fuses are protection for

1. F171: 100A - Electric Fan Cutout Relay (w\Trailer Module).
2. F172: 100A - Rear Power Distribution Box (A42).
3. F173: 250A - Passenger Compartment Junction Box (A4010).
4. F175: 100A - Intelligent Battery Sensor.
5. F176: 80A - Terminal 15 Power-Saving Relay.

FUSE ASSIGNMENT SYMBOL DEFINITIONS

For help determining the meaning of the symbols on fuse assignment legends, see FUSE ASSIGNMENT SYMBOL DEFINITIONS.
