13 0 131 Compressed air hose with filter
Order number: 13 0 131
Compressed air hose with filter
Scheme 297
13 0 132 Adapter
Order number: 13 0 132
Adapter
13 0 133 Container
Order number: 13 0 133
Container
13 0 160 Socket wrench with adapter
Minimum set: Mechanical tools
In conjunction with: 00 1 440
Note. For releasing and tightening down fuel line screw connection on injector.
Engine: N63
SI number: 01 20 08 (490)
Order number: 13 0 160
Socket wrench with adapter
Scheme 298
Consisting of
1 = 13 0 161 Socket wrench 14 WAF open
2 = 13 0 162 Adapter 15 WAF
13 0 180 Drive-out tool
Minimum set: Mechanical tools
In conjunction with: 13 5 250
Note. For knocking out stuck injectors.
Engine: N53, N54
Storage location: A19
SI number: 1 20 06 (299)
Order number: 13 0 180
Drive-out tool
Scheme 299
13 3 010 Hose clip
Minimum set: Mechanical tools
Note. For disconnecting a hose for repair work
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93, F01, F02, R50, R52, R53, R55, R56, RR1, RR2, RR3
Storage location: C4
Order number: 13 3 010
Hose clip
Scheme 300
13 3 060 Fixture
Note. For checking fuel pressure on K-Jetronic and L-Jetronic as well as oil pressure
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N45, N45T, N46, N47, N47S, N51, N52, N52K, N53, N54, N62, N63, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17
Scheme 301
Order number: 13 3 060
Fixture
Consisting of
1 = 13 3 061 Pressure gauge 0...25 bar
2 = 13 3 062 2-way cock
Note. Engine: All, except S50, S54, N73
3 = 13 3 063 Connecting lines (2 x)
Note. For fuel and oil pressure testing
4 = 13 3 064 Connecting line
Note. With T-piece for L-Jetronic All except N73
5 = 13 3 065 Connecting piece distributor
Note. All except N73
6 = 13 3 066 Connecting piece warm-up sensor
Note. All except N73
7 = 13 3 067 Connecting hose
Note. For checking fuel pump delivery All except N73
In conjunction with: 13 3 020
8 = 13 3 068 Connecting piece distributor
Note. All except N73
In conjunction with: BMW SERVICE TEST
9 = 13 3 069 Connecting piece
Note. For warm-up sensor with hose all except N73
In conjunction with: BMW SERVICE TEST
13 5 020 Wrench WAF 17
Minimum set: Mechanical tools
Note. For loosening and tightening fuel injection lines
Engine: M21, M41, M47, M47T2, M47TU, M51, M57, M57T2, M57TU, N51, N52, N53, N54, N62, N62TU, N63, W16
Storage location: A9
Order number: 13 5 020
Wrench WAF 17
Scheme 302
13 5 160 Plugs (2)
Minimum set: Mechanical tools
Note. For sealing fuel lines when removing and installing engine.
Engine: M52, M52TU, M54, M56, M62, N12, N14, N40, N42, N43, N45, N46, N52, N52K, N53, N54, N62, N62TU, N73, S50B32, S85, W10, W11
SI number: 01 22 08 (498)
Order number: 13 5 160
Plugs (2)
Scheme 303
Consisting of
1 = 13 5 161 Seal (2 x)
Note. For sealing quick couplings
2 = 13 5 162 Seal (2 x)
Note. For sealing fuel lines.
13 5 250 Extractor
Minimum set: Mechanical tools
Note. For removing injection nozzles or injectors from cylinder head
Engine: M47, M47TU, M57, M57TU, M67, N43, N53, N54, N73, N73H, W10, W11, W17
Storage location: A11, B11
SI number: 01 06 98 (306)
Order number: 13 5 250
Extractor
Scheme 304
Consisting of
1 = 13 5 251 Guide rod
2 = 13 5 252 Threaded bush
3 = 13 5 253 Impact weight
5 = 13 5 255 Adapter
Note. For withdrawing steering spindle on E85. Refer to
13 5 280 Plugs for fuel lines
Note. For sealing fuel lines when removing and installing engine. 13 5 280 discontinued from 10/2008. Replaced by 13 5 160.
Engine: M52, M52TU, M54, M56, M62, N12, N14, N40, N42, N43, N45, N46, N52, N52K, N53, N54, N62, N62TU, N73, S50B32, S85, W10, W11
Storage location: B3, C3
SI number: 1 18 96 (163)
Order number: 13 5 280
Plugs for fuel lines
Scheme 305
13 6 050 Set of adapters for BMW DIS
Minimum set: Mechanical tools
Note. For measuring oil and fuel pressures
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N47, N47S, N51, N52, N52K, N53, N54, N62, N63, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17
Scheme 306
Storage location: A16, B16
SI number: 1 12 94 (859)
Order number: 13 6 050
Set of adapters for BMW DIS
Consisting of
1 = 13 6 051 Connecting hose
Note. For connecting reducers 13 6 052, 13 6 053, 13 6 55 and adapters 11 4 050, 11 4 160, 11 4 170, 13 5 131 to BMW DIS
2 = 13 6 052 Reducer
Note. For pipe elbows 24 0 023, 24 0 024, 24 0 140
In conjunction with: 13 6 051
3 = 13 6 053 Reducer for adapter 16 1 300
In conjunction with: 13 6 051
4 = 13 6 054 Pipe elbow
In conjunction with: 13 6 051, 11 4 050
5 = 13 6 055 Reducer for T-pieces 13 6 056 and 13 6 057
In conjunction with: 13 6 051
6 = 13 6 056 T-piece for 6 mm dia. line
7 = 13 6 057 T-piece for 8 mm dia. line
13 6 058 T-piece for 12 mm dia. line
Order number: 13 6 058
T-piece for 12 mm dia. line
