24 1 010 INSTALLATION SLEEVE
Note. For removing disc pack (4th gear) as well as fitting needle bearing in oil pump housing (A5S 560Z)
Transmission: 4 HP 22, 4 HP 24, A5S 560Z
Storage location: A18
Order number: 24 1 010
Installation sleeve
Scheme 334
24 1 200 INSTALLATION SLEEVE
Minimum set: Mechanical tools
Note. For preventing damage to rotary shaft seal while fitting on gearshift shaft
Transmission: A5S 310Z
Storage location: B18
SI number: 1 09 90(282)
Order number: 24 1 200
Installation sleeve
Scheme 335
24 1 260 REMOVAL AND MOUNTING FIXTURE
Note. For removing and installing cylinder D/E with planetary gear train
Transmission: A5S 560Z
Storage location: C1, C2
SI number: 1 01 95(892)
Order number: 24 1 260
Removal and mounting fixture
Scheme 336
Consisting of
1 = 24 1 261 Handle
2 = 24 1 262 Spindle with knurled nut
3 = 24 1 263 Centering bush
24 1 270 REMOVAL AND MOUNTING FIXTURE
Note. For removing and installing clutch A/B/C
Transmission: A5S 560Z
Storage location: B14, B15, B3
SI number: 1 01 95(892)
Order number: 24 1 270
Removal and mounting fixture
Consisting of
1 = 24 1 271 Lifting tube with eye bolt
2 = 24 1 272 Lock pin
Scheme 337
24 1 280 REMOVAL AND MOUNTING FIXTURE
Note. For removing and installing brake clutch F
Transmission: A5S 560Z
Storage location: C20
SI number: 1 01 95(892)
Order number: 24 1 280
Removal and mounting fixture
Scheme 338
Consisting of
1 = 24 1 281 Handle with spindle
2 = 24 1 282 Knurled nut
3 = 24 1 283 Centering handle
