Power Flow Schematic

In order to understand power flow schematics, a relationship must be drawn between the actual components and the schematic representation. In our example, we are going to use the 4HP22/24 power flow schematic. The 4HP22/24 transmission uses a Simpson Planetary Gearset and an auxiliary gearset. The auxiliary gear set is a simple planetary gearset.

Scheme 38

Scheme 38: Power Flow Schematic

Scheme 39

Scheme 39

Power flow in first gear - Drive torque is applied to the torque converter impeller and transferred to the turbine. The turbine shaft rotates clockwise (CW). The "A" clutch locks the turbine shaft to the rear input ring gear. The rear input ring gear rotates CW driving the rear planet pinions CW. The planetary pinions drive the common sun gear CCW, which in turn drive the front planet pinions CW. The front planetary carrier is held from rotating CCW by one way clutch "J". The front planetary pinions which are rotating CW drive the front ring gear/rear carrier CW. The rear planetary carrier is rotating CW and is driving the planetary carrier from the auxiliary gear set. The "E" clutch in the auxiliary gear set is holding the Sun gear and the ring gear together. Therefore the auxiliary gear set is locked in a 1:1 ratio.

One Way Clutch "J" is locked prevent the front planetary carrier from rotating CCW. One Way Clutch "H" is not used and One Way Clutch "K" is locked. One way clutch "K" is used to prevent an interruption in power flow before the "E" clutch is locked during the 4-3 shift.

Scheme 40

Scheme 40

Scheme 41

Scheme 41: Second Gear

Second Gear - Drive torque is applied to the torque converter impeller and transferred to the turbine. The turbine shaft rotates clockwise (CW). The "A" clutch locks the turbine shaft to the rear input ring gear. The rear input ring gear rotates CW driving the rear planet pinions CW. The sun gear is held stationary by the C' clutch. The rear planet pinions rotate around the fixed sun gear CW. The rear planetary carrier will rotate CW. The rear planetary carrier will drive the auxiliary gear set will rotate as a complete unit. The auxiliary gear set is locked in a 1:1 ratio due to the "E" clutch locking the sun and ring gear together.

The "C" clutch is locking the outer race of the "H" freewheel to the case. This is used for the 3/2 downshift. Freewheel "J" is not active and Freewheel "K" is locked.

Scheme 42

Scheme 42

Scheme 43

Scheme 43: Third Gear

Third Gear - Drive torque is applied to the torque converter impeller and transferred to the turbine. The turbine shaft rotates clockwise (CW). The "A" clutch and the "B" clutch are locked, this causes the rear input ring gear to be locked to the sun gear in the Simpson Gear set. The Simpson gear set is locked in a 1:1 ratio. The "E" clutch is locked which locks the ring gear to the sun gear in the Simpson gear set. The entire transmission planetary system is now locked in a 1:1 ratio.

Freewheel "H" is overrun and freewheel "J" is not used. Freewheel "K" continues to be locked.

Scheme 44

Scheme 44

Scheme 45

Scheme 45: Fourth Gear

Fourth Gear - Drive torque is applied to the torque converter impeller and transferred to the turbine. The turbine shaft rotates clockwise (CW). (The turbine shaft can also be driven by the lock up clutch when engaged). The "A" clutch and the "B" clutch are locked, this causes the rear input ring gear to be locked to the sun gear in the Simpson Gear set. The Simpson gear set is locked in a 1:1 ratio. The "F" clutch is locked which locks the sun gear in the auxiliary gear set to the case. The Simpson gear set drives the planetary carrier CW. The planet pinions walk around the fixed sun gear in a CW direction. This causes the ring gear to rotate CW as well. The ring gear, which is the output of the transmission is driven in a overdrive ratio.

Freewheel "H" and "K" are overrun. Freewheel "J" is not used.

Scheme 46

Scheme 46

Scheme 47

Scheme 47: Reverse Gear

Reverse Gear - Drive torque is applied to the torque converter impeller and transferred to the turbine. The turbine shaft rotates clockwise (CW). The "B" clutch is locked which drives the sun gear in the Simpson gear set CW. The sun gear drives the planet pinions CCW. The planetary carrier is held stationary by the "D" clutch. The planet pinions cause the front ring gear to rotate CCW. The front ring gear (and rear carrier) drive the auxiliary gear set CCW which rotates at a ratio of 1:1 due to the "E" clutch locking the sun and ring gear of the auxiliary gear set.

Freewheel "H" and "J" are not used. Freewheel "K" is locked.

Scheme 48

Scheme 48
