Wiring diagram: Transmission — A/t circuit BMW X5 G18 facelift
All systems — 36 systems
- Air conditioning 4
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines 2
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering
- Electronic suspension 2
- Engine performance 3.0l turbo hybrid
- Engine performance 4.4l turbo hybrid
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 6
- Navigation 14
- Passive restraints
- Power distribution
- Power door locks
- Power mirrors
- Power seats 13
- Power top/sunroof
- Power windows
- Radio 4
- Shift interlock
- Starting/charging 3.0l turbo hybrid 3
- Starting/charging 4.4l turbo hybrid 3
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door 4
- Warning systems
- Wiper/washer
Components on these wiring diagrams 16
Click a component to highlight it on every diagram it appears on.
